Himunication HM360 DSC MAX User manual

VHF MARINE RADIO
HM360 DSC MAX
User Manual
http://www.himunication.com
Please Scan the QR Code to Download
EN/FR/ES/ITA Multi-language User Manual

HM360 DSC MAX
1
CONTENTS
HM360 DSC MAX CONTROLS.......................................................................................................4
HM360 DSC MAX KEY FUNCTION...............................................................................................5
HM360 DSC MAX LCD DISPLAY.................................................................................................. 5
MENU SCREEN OPERATION......................................................................................................... 6
THE DESCRIPTION ON OF THE MENU FEATURES.................................................................. 6
DSC MENU........................................................................................................................................ 6
FOR MY MMSI ID SETUP............................................................................................................... 7
FOR INDIVIDUAL CALL, POSITION REQUEST......................................................................... 7
FOR ALL SHIP CALL........................................................................................................................7
RECEIVE CALL LOG....................................................................................................................... 8
SEND CALL LOG..............................................................................................................................8
PHONE BOOK................................................................................................................................... 8
DSC SETUP........................................................................................................................................8
DISTRESS MENU..............................................................................................................................8
SEND THE DISTRESS MESSAGE.................................................................................................. 8
MAIN MENU..................................................................................................................................... 9
FOR VHF OPERATION.....................................................................................................................9
FOR GPS SETTING...........................................................................................................................9
FOR SYSTEM CONFIG.................................................................................................................. 10
CONTROLS OPERATION.............................................................................................................. 10
POWER ON/OFF(KNOB)............................................................................................................... 10
VOLUME,SQUELCH &CHANNEL SELECT(KNOB).................................................................10
VOLUME CONTROL (KNOB).......................................................................................................10
SQUELCH CONTROL (KNOB)..................................................................................................... 10
CHANNEL UP/DOWN (KNOB).....................................................................................................10
SPECIAL FUNCTION: DISTRESS KEY AND REAL DSC......................................................... 10
REC/PLAY KEY...............................................................................................................................10
WP/GOTO KEY............................................................................................................................... 10
16/9 KEY...........................................................................................................................................10
SELECT THE SECOND PRIORITY CHANNEL...........................................................................11
H/M/L/LOCK KEY...........................................................................................................................11
CH/*/WX/ KEY................................................................................................................................ 11
SCAN KEY.......................................................................................................................................11
MEM KEY........................................................................................................................................ 11
DW/TRIW KEY (DUAL WATCH/TRI WATCH)............................................................................12
TORCH/R/W.....................................................................................................................................12
BACKLIGHT....................................................................................................................................12
QUAKE WATER.............................................................................................................................. 12
OTHER FEATURES AND SOLUTIONS:...................................................................................... 12
SPECIAL FUNCTION KEYS..........................................................................................................12
TX TIME OUT..................................................................................................................................12
WDT–WATER DISPLACEMENT TECHNOLOGY...................................................................... 12
BUILD IN BATTERY...................................................................................................................... 12
THE LOCAL TIME AND DATE ON SCREEN..............................................................................13
APPENDIX A – NEAR LIGHTNING STRIKE TEST....................................................................14
APPENDIX B – CHANNEL LIST...................................................................................................15
EUROPEAN PRIVATE CHANNELS AND FREQUENCIES........................................................22
WEATHER CHANNELS AND FREQUENCIES...........................................................................22
SPECIFICATIONS........................................................................................................................... 23

HM360 DSC MAX
2
HM360 DSC MAX User Manual
Introduction
Your transmitter-receiver HM360 DSC MAX by HIMUNICATION was developed by using high
technologies. Designed for an international use, it allows you to emit and to receive on all the
international channels of the marine band VHF such as specified by the international union (ITU)
The device is a high-quality electronic equipment, builds according to the rule book with the best
components, it answers all the standards of the market to supply you with clear and reliable
communications.
Your transmitter-receiver is designed to supply reliable years of functioning, it thanks to a
microprocessor with optimized performances.

HM360 DSC MAX
3
EU Regulatory Conformance
As certified by the qualified laboratory, the product is in compliance with the essential requirements and
other relevant provisions of the Directive 2014/53/EU. Please note
that the above information is applicable to EU countries only.
Fabricant: HIMUNICATION
Numbel: 11005103
Adresse: Address:7th Floor, building 13, Run Dong Sheng Industrial Park, National Road 107,
Longzhu community, Xixiang, baoan district, Shenzhen,China
Hereby, HIMUNICATION declares that this Maritime Radio is in compliance with essential
requirements and other relevant provisions of Directive 2014/53/EU.
Caution
1. Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries
according to the instructions.
2. Adapter shall be installed near the equipment and shall be easily accessible.
3. The device operating temperature range is -15~55℃.
4. The plug considered as disconnect device of adapter.
5. The device complies with RF specifications when the device used at 25mm from your
front face and 0mm from your body.
6. Declaration of Conformity.
The information listed above provides the user with information needed to make him or her aware of a RF
exposure, and what to do to assure that this radio operates within the CE exposure limits of this radio.
The device complies with RF specifications when the device used at 25mm from your front face and 0mm
from your body.Third-party belt-clips, holsters, and similar accessories used by this device should not
contain any metallic components. Body-worn accessories that do not meet these requirements may not
comply with RF exposure requirements and should be avoided. Maximun SAR Value (10g):0.459W/Kg.
Waterproof design Warning:
This product is the IPX8 waterproof design, in order to achieve the best performance.

HM360 DSC MAX
4
HM360 DSC MAX Controls
DISPLAY
MARINE TORCH KEY
R/W
MULTI - FUNCTION KNOB
POWER ON / OFF/ VOL /
SQL / CH / MENU SELECT
DISTRESS KEY
PRIVATE CHANNELS
WEATHER CHANNEL SET
CH16 / CH09
MEMORY
SCAN
PUSH TO TALK
RECORD / PLAY VOICE
LOOP PLAY
WP / GOTO
CALL / MENU
H/M/L POWER KEY
LOCK
DUAL WATCH
TRIPLE WATCH
HEADSET JACK
VHF ANTENNA
TORCH
USB JACK

HM360 DSC MAX
5
HM360 DSC MAX Key Function
HM360 DSC MAX LCD Display
Keys
Short press less than 3 seconds
Long press more than 3 seconds
Power Knob(Push)
Power ON/Menu Select
Power Off
Power Knob
Adjust the Volume Level
Power Knob(Push 1)
Adjust the Squelch Level
Power Knob(Push 2)
Adjust the Channel Up/Down and Scan Direction
Torch/R/W
Torch On/Off
Toggle Red and White Torch
REC/PLAY
Record Voice Enable/Disable
Play Voice Enable/Disable
WP/GOTO
Set Way Point
Go to the Way Point
SCAN+Power On
Quake Water
H/M/L /Lock
TX Power High/Middle/Low
Key Lock/key Unlock
16/9
CH16
CH09
DW/TRIW
Dual Watch Mode
Triple Watch Mode
CH/*/WX
Privater Channel
WX Band
SCAN
All Scan/all Memory Scan
Priority all/Memory Scan
MEM
Memory Mode
Save/Delete Memory Channel
CALL/MENU
DSC Call Menu
Main Setup Menu
DISTRESS
Distress Menu
Distress Alert Calling
UTC Time
Month
Date
Distress Mode
Current Channel
Squelch Level
Volume Level
High Power
RX Indicator
Digital
Selective
Calling
Memory Icon
Battery Level
Record
Dual Watch
Memory Mode
GPS Position
Band
Message

HM360 DSC MAX
6
Menu Screen Operation
The description on of the menu features:
DSC Menu
Short press the Call/Menu key will saw below DSC Call Menu as below.
Then the CH/*/WX key will became the Exit key and the Call/Menu key will became the Enter key. Turn the coding knob
to choose the item at the menu without the changes.
DSC Menu
Individual Call
Input Address
From Phonebook
Position Request
Input Address
From Phonebook
All Ship Call
Safety
Urgency
Group Call
Input Address
From Phonebook
Test Call
Input Address
From Phonebook
Receive Call Log
Distress Call
Others Call
Send Call Log
Distress Call
MOB Call
Others Call
Phone Book
Buddy List
Group List
DSC Setup
Position Input
Position Reply
Test Ack
My MMSI ID
My MMSI ID
100000008
Main Menu
VHF Operation
Channel Band Set
Priority 2nd Ch
GPS Setup
GPS Type
GPS Setting
GPS ON/OFF
ATIS Operation
My ATIS ID
ATIS Function
DSC Operation
My MMSI ID
DSC Function
System Config
LCD Back Light
Back Light Time
LCD Contrast
Key Beep
Torch Color
Version Info
Factory Reset
Language Select
DSC Menu
Individual Call
Position Request
All Ship Call
Group Call
Test Call
Receive Call Log
Send Call Log
Exit Enter

HM360 DSC MAX
7
For My MMSI ID setup
Firstly, set up the MMSI ID, to click the My MMSI ID and
Enter, then you are able to set up your related MMSI ID as
below generally you need to double confirm the MMSI ID
then your MMSI ID will be locked by this radio.
When you input 9 digits, Turn the coding knob to choose
the number from1-9,you need to input all numbers from the
left to right one by one When you input all 9 digits then
press the enter to confirm.
After you enter 123000001 these nine figures, the screen
will be displayed as below
For Individual Call, Position Request, Group
Call and Test Call
Click the preferred item then you able to find the target
MMSI ID to call by Input Address or From Phonebook. We
take the individual call as an example.
When you selected the input address item to click and input
9 digits such as the 100000000 for your address as below.
Then select the type of individual call such as the safety
Then select the channels such as the 06 port operation then
confirm to call
Then the individual call is sent
Then the individual call is sent
For All Ship Call
Select the All Ship Call item
Input Address
Input 9 digits
123- - - - - -
Exit Enter
Input Address
Input 9 digits
123000001
Exit Enter
Input Address
Input 9 digits
100000000
Exit Enter
Individual Call
Routine
Safety
Urgency
Exit Enter
My MMSI ID
123456789
Exit Enter
Individual Call
To:100000000
Safety
Telephony by
Channel 06
Exit Enter
Individual Call
Select Channel:
06 safety
08 commercial
09 calling
10 commercial
11 vts
12 portops/vts
Exit Enter
DSC Menu
Individual Call
Position Request
All Ship Call
Group Call
Test Call
Receive Call Log
Send Call Log
Exit Enter
DSC INT
1W
SQL:5
VOL:8 SAFETY
Elapsed 03:55
Exit
06

HM360 DSC MAX
8
Then select the type of All Ship Call such as the Urgency
Then select the channels such as the 07 Commercial then
confirm to call
Then the All Ship Call is sent
Receive Call Log
When receive the DSC call and you able to check the
message from the Distress Call then able to see the exact
message.
Send Call Log
To press the Send Call Log able to saw the previous
Distress Call MOB Call and Other Call you have sent
Phone Book
Able to check the contact ship by Buddy list and
Group list
DSC Setup
The DSC setup menu got the 4 item to choose as the
Position Input, Position Reply and Test Ack.
For Position Input you can set up the GPS position
and UTC time by manual operation.
For Position Reply and Test Ack you can choose the
Automatic or Manual by you interests.
Distress Menu
Pull the Distress red cover then press the Distress key
You are able to saw the Distress Menu in below.
Send the distress Message
Choose one distress item such as the Sinking the press and
hold the distress key for 3 seconds the Sinking distress
message will be sent.
All Ship Call
Safety
Urgency
Exit Enter
Urgency
Select Channel:
03 telephone
04 port ops
05 port ops/vts
06 safety
07 port ops
08 commercial
Exit Enter
All Ship Call
To : All Ship
Urgency
Telephony by
Channel 07
Exit Enter
DSC Menu
Individual Call
Position Request
All Ship Call
Group Call
Test Call
Receive Call Log
Send Call Log
Exit Enter
Receive Call Log
Distress Call
Others Call
Exit Enter
Received DSC
Distress Call
Undesignated
From: 123456789
GPS POS: Unknown
Time: Unknown
Exit Delete
Distress Menu
Undesignated
Fire,Explosion
Flooding
Collision
Grounding
Capsizing
Sinking
Exit
DSC INT
1W
SQL:5
VOL:8 PORT
OPERA
Elapsed 03:38
Exit
07

HM360 DSC MAX
9
You also able to choose to resend pause or Exit after the
message be sent.
Main Menu
Long press the Call/Menu key will saw below Main Menu
as below.
For VHF Operation
Select the VHF operation to enter will see Channel Band
Set and Priority 2nd Ch options in below
For VHF Operation, you are able to choose the wanted
channel band from those three options USA, INT and CAN
For Priority 2nd Ch you can select you wanted priority
2nd channel.
For GPS Setup
Long press the Call/Menu key will saw below Main Menu
as below.
Distress Menu
Undesignated
Fire,Explosion
Flooding
Collision
Grounding
Capsizing
Sinking
Exit
Distress Call
Sinking
Push the key
For 3 Seconds!
Main Menu
VHF Operation
GPS Setup
ATIS Operation
DSC Operation
System Config
Exit Enter
VHF Operation
Channel Band Set
Priority 2nd Ch
Exit Enter
Channel Band Set
USA
√ INT
CAN
Exit Enter
Priority 2nd Ch
Select Channel:
01 telephony
04 sar
05 port ops/ vts
06 inter ship
07 commercial
08 commercial
Exit Enter
GPS Setup
GPS Type
GPS Setting
GPS ON/OFF
Exit Enter
Enter
GPS Setting
Time Display
Time Offset
COG/SOG
Speed Unit
Exit Enter
DSC INT
6W
P-2nd
SQL:5
DISTRESS
Resend in
4:09
Exit Pause
Send
16

HM360 DSC MAX
10
System Config
Back Light Time
LCD Contrast
Key Beep
Torch Color
Version Info
Factory Reset
Language Select
Exit Enter
Turn the knob to switch the GPS satellite location map.
For System Config
Select the system Config and you are able to see the below
menu to check and adjust the LCD/Key Beep figure,
version info and factory reset.
CONTROLS OPERATION
Power ON/OFF(Knob)
Push the coding knob until a click sound heard the unit will
power on.
The unit will start with Normal mode
- Turn on the 1000Hz tone for 100ms
- Turn on the backlit in full scale for 5 sec
- Recall the last channel number, TX power settings
and operational mode
- If no last channel info, go to Channel 16, TX Power
be Hi
- Volume set level 5 (default),max is level 9
- Squelch set levle 5 (default),max is level 9
Volume、Squelch &Channel Select (Knob)
Volume Control (Knob)
Turn the coding knob to control the loudspeaker volume
level.
Clockwise-volume up, anti-clockwise-volume down.
Squelch Control (Knob)
At the radio normal mode to adjust the squelch level, short
press the coding knob will
Flash SQL’s level , clockwise or anti clockwise the coding
knob to select SQL level accordingly.
Channel UP/DOWN (Knob)
At the radio normal mode to adjust Channel Up/Down.
short press the coding knob twice will Flash Channel
Number , clockwise or anti clockwise the coding knob to
select Channel Number according,then short press the
coding knob to exit the setting status.
Special function: Distress Key and Real DSC
Send the Distress message:
Pull the Distress key cover then able to Press the Red key
into the Distress Menu selection. Then select the current
distress situation such as the “Flooding” then press and
hold for 3 seconds, the selected DSC message will be send.
This message also will be resend within 4 minutes, press
the Up key will pause or resume the resend, press
Call/Menu key will resend immediately. Press the
CH/WX/UIC key will exit the current menu and give the
option on cancel of this selected distress alert.
Receive the Distress message:
The HM360 DSC MAX model has two receivers, one
receiver used for receiving/transmit voice and another
receiver used for to continually monitor 70 channels. The
DSC function for HM360 DSC MAX model is operated by
individual way.Even you are using the HM360 DSC MAX
to make the transmit or receive, when the DSC message is
arrived.The HM360 DSC MAX handheld model always
can receive all of the DSC message as a fixed mounted
marine radio.Press the Call/Menu key and select the
receive call log then press the enter to see all received DSC
message.
REC/PLAY key
The record IC can record voice 60 seconds.Short press the
REC key will switch record function enable or disable. If
record function enable and the squelch open, The record IC
will record the receiving voice. Short press PLAY/ LOOP
key will switch play function enable or disable.Long press
PLAY/LOOP key will enter loop play voice in record IC.
WP/GOTO key
Waypoint Navigation
The Navigation function navigates from your current
position to an entered regular Waypoint or MOB waypoint.
16/9 key
At the normal mode ,pressing the 16 / 9 Key (short press to
jump to priority CH16 at High Power and long press to
jump to priority CH9 at High Power) if the current channel

HM360 DSC MAX
11
is not the priority channel.
After the channel is tuned to the priority channel, the
“P-CH” and “P-2nd”icon is lit to indicate that the priority
CH16 or CH9 has been reached.
Select the second priority channel
Change the second priority channel by 16/9 key: normally
the second priority channel is initially sets as the channel
9.At the normal mode, Long press the 16/9 Key will
display the second priority channel as channel 9.Then long
press the 16/9 Key again and the “2nd Prior” icon will
display on the screen. Turn the coding knob to choose your
prefer channel as the second priority channel then long
press the 16/9
Key to confirm it Change the second priority channel by
Menu key: Press the 16 / 9 Key then press the Call/ Main
key to select VHF operation option then press Enter to
select the Priority 2nd Ch then press Enter and select you
preferred channel by the coding knob then press Enter to
confirm
H/M/L/LOCK Key
Short press the H/M/L/LOCK key will toggle the TX
power from H to M or L vice versa.The corresponding “6W
to 3W or 1W” icon will turn on to display on the LCD.
Some of the channel such as channel 16 only for high
power/channel 13&67 only for low power) has been
limited to be low power only or high power only. Thus, the
software needs to check against the channel setting stored
in the EEPROM
Long press the H/M/L/LOCK key will lock the keys and
the “lock ” icon will appear ，then all of the key will be
locked to use except the PTT key and Distress key. Long
press the H/M/L/LOCK key again to cancel the lock mode
and the “lock ” icon will disappear.
CH/*/WX/ key
NOTE: In European version, WX function from the
CH/*/WX key will be changed to PRIVATE CHANNEL
function. Weather Channels will not be available for
HM360 DSC MAX (European).
Short press CH/*/WX key will enter Wx mode. Turn the
coding knob to change Wx channel. The “WX”icon will
display on the screen.
When Dual or Tri watch is being activated in the Wx mode,
the watch will monitor the current WX channel and priority
channel(s).
Weather Alert Operation (WAT)
At the weather mode, Long press the CH/*/WX key will
switch on the weather alert function. Toggling the Weather
Alert function ON and OFF will toggle the icon “WAT”
accordingly
When Weather Alert function is enabled. Every 4 seconds
the last used weather channel should be checked for
weather alert tone when the radio is tuned to working
channel. With Weather Alert Function enable, the “WX”
and “Cloud” symbol should display.if the alert tone is
detected, A short alarm tone should sound. The radio would
automatically tune to the current monitor WX channel
where the weather alert has been detected. The alert should
be detected in all the modes of Dual and Tri-watch, Scan
etc.)
SCAN Key
This is the function to scan for currently working channels.
When a signal is detected, the scan pauses until the signal
disappears.
Short press the Scan Key, to activate the SCAN function.
Scan all channels.
Long press the Scan Key, to activate the Priority Scan.
MEM Key
Enter /Exit the memory mode
Short press the MEM key to enter the memory mode, the
memory channel will mark as the “M” icon at the right side
of channel number. At the left side of the current channel
will mark as the “user “icon means as already enter the
user memory mode.
At the Memory mode, short press the MEM key to exit the
memory mode. The “M” icon ( at the right side of channel
number) and the “user”icon (at the left side of the current
channel) will disappear.
Adding/Deleting memory CH:
During the normal mode, Turn the coding knob to select
the desired channel for programming.
Long press the MEM key to store up the channel as
memory channel.
The “M” icon at the right side of current channel number
will shows up to indicate the current CH has been saved in
the memory. No limited of memory channels.
Separate memory channel exists for USA, International,
and Canadian Frequency group.
During the normal mode, Turn the coding knob to select
the memory channel to be deleted.
Long press the MEM key to delete the selected channel
from the memory.

HM360 DSC MAX
12
DW/Triw key (Dual Watch/Tri Watch)
At the normal mode, short press DW/TRIW key to activate
the DUAL WATCH mode. Monitor the current channel
and Ch 16 in cycle. Whenever, Weather Alert is activated,
the Wx Alert channel will be monitored once every 4sec.
Long press DW/TRI key to activate the TRI WATCH mode.
Monitor the Ch 16, current channel and 1 programmed
channels in cycle.
Torch/R/W
The torch can work at two color :red and white.Short press
the Torch/R/W key will switch the torch on or off, If
quickly short press the Torch/R/W key, the torch will
sequence produces this phenomenon: no flash,fastly
flash,slowly flash (SOS) the led. Long press the Torch/R/W
key will toggle red color torch or white color torch.
Backlight
Any key press will turn on the backlit (if backlit setting is
ON ) except the PTT key. The backlit should be remaining
on for 5 seconds if no any keys pressed. The time out will
be reset if any key pressed within the time frame.
Quake Water
To activate Quake Water press and hold the SCAN key
whilst switching on the HM360 DSC MAX. You will be
prompted with a beep tone and the letter‘Shock Wave Short
Press the SCAN to run it ’will display. Press SCAN to
activate Quake Wate and hold the HM360 DSC MAX face
down. After the water completely kick off from the speaker
grids,short press the 'SCAN 'key to stop the Quake Wate
feature. Then reset the HM360 DSC MAX again.
Other features and solutions
Special function keys
If you press the call/menu key
and power key then you can
enter the up grade mode directly
Press the DW/TRW key and
the power key，then you can
enter the writing channel mode
Directly
TX Time Out
The transmission will be automatically turn off after PTT
key pressed over 5 consecutive minutes. The TX mode will
be terminate and back to Rx mode. To indicate the PTT key
as the stuck condition. Once the PTT key is released, the
TX time out timer will be reset. PTT key will work back
normally.
WDT–Water Displacement Technology
To activate WDT press and hold the SCAN key whilst
switching on the HM360 DSC MAX. You will be
prompted with a beep tone and the letter‘Shock Wave Short
Press the SCAN to run it ’will display. Press SCAN to
activate WDT and hold the HM360 DSC MAX face down.
After the water completely kick off from the speaker
grids,short press the 'SCAN 'key to stop the WDT feature.
Then reset the HM360 DSC MAX again.
Build in Battery
The HM360 DSC MAX model has the Build in Battery
design likes the iphone there are three steps to installation
and removal the battery in below diagram.
Step1
Step2
Step3
The software’s
Upgrading by PC
Please wait----
The Private
Channels are
Cloning by PC
Please wait----

HM360 DSC MAX
13
Connection Cable
The length of the Type-C USB Cable is 1 meter, the cable
can be used for the software update and charge.
While the charger is connected the display will
show the battery charging state by animating the
battery icon.
when the radio is on, the
battery symbol animates
in the corner of the display.
when the radio is switched
off, the battery symbol
animates in the centre
of the display.
The local time and date on screen
UTC TIME LOCAL TIME
When the HM360 DSC MAX cannot receive the GPS
signal to display the current position, the screen will
automatic display the UTC local time and date.
The user can press the menu to switching your local time
based on the UTC time. Long press the Call/Menu key
then select the GPS setup item to enter. Then you can saw
the GPS setting item and click the enter to select the Time
offset item Then you are able to adjust your location time
based on the time difference with the UTC time then press
the enter to confirm. (You need to pass the entire item from
the hour-minutes – seconds then able to saw the enter
option to click and confirm).
Time offset
UTC —08:00
Exit Enter

HM360 DSC MAX
14
Appendix A – Near Lightning Strike Test
This appendix describes the general procedure for evaluating the immunity to near lightning strikes (NLS) of the HM360
DSC MAX VHF Radio.
The test simulates a slow, high-energy pulse produced by an NLS event.
List of Abbreviations
AE
Auxiliary Equipment
CE
Conducted Emissions
EMC
Electromagnetic Compatibility
EN
European Norm
EUT
Equipment Under Test
FTB
Fast Transient Burst
MED
Marine Equipment Directive
QP
Quasi Peak
Safety
The high voltage interference pulse can contain a very large quantity of energy and every precaution shall be taken to avoid
contact with EUT during a test. It is highly recommended that at least one other person is present (or very close by) during
the test.
Test Configuration
EUT Setup
The EUT shall be setup in a typical system configuration on an isolated wooden bench with NO GROUNDPLANE. The
power to the EUT and auxiliary equipment shall be from 12V or 24V sealed lead-acid batteries via a suitable fuse. The
length of the EUT power cable shall be no more than 2m. Any screens within the system shall be terminated at the battery
–ve connection.
EUT Operating Configuration
All operating configurations should be tested with appropriate performance criteria defined for each test.

HM360 DSC MAX
15
Appendix B – Channel List
International Marine VHF Channels & Frequencies
CH
TX Freq
RX Freq
Simplex
Freq Use
1
156.050
160.650
Public Correspondence, Port Operations and Ship Movement
2
156.100
160.700
Public Correspondence, Port Operations and Ship Movement
3
156.150
160.750
Public Correspondence, Port Operations and Ship Movement
4
156.200
160.800
Public Correspondence, Port Operations and Ship Movement
5
156.250
160.850
Public Correspondence, Port Operations and Ship Movement
6
156.300
156.300
x
Inter-ship [1]
7
156.350
160.950
Public Correspondence, Port Operations and Ship Movement
8
156.400
156.400
x
Inter-ship
9
156.450
156.450
x
Inter-ship, Port Operations and Ship Movement
10
156.500
156.500
x
Inter-ship, Port Operations and Ship Movement [2]
11
156.550
156.550
x
Port Operations and Ship Movement
12
156.600
156.600
x
Port Operations and Ship Movement
13
156.650
156.650
x
Inter-ship Safety, Port Operations and Ship Movement [3]
14
156.700
156.700
x
Port Operations and Ship Movement
15
156.750
156.750
x
Inter-ship and On-board Communications at 1W only [4]
16
156.800
156.800
x
Distress, Safety and Calling
17
156.850
156.850
x
Inter-ship and On-board Communications at 1W only [4]
18
156.900
161.500
Public Correspondence, Port Operations and Ship Movement
19
156.950
161.550
Public Correspondence, Port Operations and Ship Movement
1019
156.950
156.950
Public Correspondence, Port Operations and Ship Movement
2019
161.550
161.550
Public Correspondence, Port Operations and Ship Movement
20
157.000
161.600
Public Correspondence, Port Operations and Ship Movement
1020
157.000
157.000
Public Correspondence, Port Operations and Ship Movement
2020
161.600
161.600
Public Correspondence, Port Operations and Ship Movement
21
157.050
161.650
Public Correspondence, Port Operations and Ship Movement
22
157.100
161.700
Public Correspondence, Port Operations and Ship Movement
23
157.150
161.750
Public Correspondence, Port Operations and Ship Movement
24
157.200
161.800
Public Correspondence, Port Operations and Ship Movement
25
157.250
161.850
Public Correspondence, Port Operations and Ship Movement
26
157.300
161.900
Public Correspondence, Port Operations and Ship Movement
27
157.350
161.950
Public Correspondence, Port Operations and Ship Movement
28
157.400
162.000
Public Correspondence, Port Operations and Ship Movement
60
156.025
160.625
Public Correspondence, Port Operations and Ship Movement
61
156.075
160.675
Public Correspondence, Port Operations and Ship Movement
62
156.125
160.725
Public Correspondence, Port Operations and Ship Movement
63
156.175
160.775
Public Correspondence, Port Operations and Ship Movement
64
156.225
160.825
Public Correspondence, Port Operations and Ship Movement
65
156.275
160.875
Public Correspondence, Port Operations and Ship Movement
65A
156.275
156.275
Non-Commercial
66
156.325
160.925
Public Correspondence, Port Operations and Ship Movement

HM360 DSC MAX
16
66A
156.325
156.325
Non-Commercial
67
156.375
156.375
x
Inter-ship, Port Operations and Ship Movement [2]
68
156.425
156.425
x
Port Operations and Ship Movement
69
156.475
156.475
x
Inter-ship, Port Operations and Ship Movement
71
156.575
156.575
x
Port Operations and Ship Movement
72
156.625
156.625
x
Inter-ship
73
156.675
156.675
x
Inter-ship [2]
74
156.725
156.725
x
Port operations and Ship movement
75
156.775
156.775
x
See Note [5]
76
156.825
156.825
x
See Note [5]
77
156.875
156.875
x
Inter-ship
78
156.925
161.525
Public correspondence, Port Operations and Ship Movement
1078
156.925
156.925
Public correspondence, Port Operations and Ship Movement
2078
161.525
161.525
Public correspondence, Port Operations and Ship Movement
79
156.975
161.575
Public correspondence, Port Operations and Ship Movement
1079
156.975
156.975
Public correspondence, Port Operations and Ship Movement
2079
161.575
161.575
Public correspondence, Port Operations and Ship Movement
80
157.025
161.625
Public correspondence, Port Operations and Ship Movement
81
157.075
161.675
Public correspondence, Port Operations and Ship Movement
82
157.125
161.725
Public correspondence, Port Operations and Ship Movement
83
157.175
161.775
Public correspondence, Port Operations and Ship Movement
84
157.225
161.825
Public correspondence, Port Operations and Ship Movement
85
157.275
161.875
Public correspondence, Port Operations and Ship Movement
86
157.325
161.925
Public correspondence, Port Operations and Ship Movement
87
157.375
157.375
x
Port Operations and Ship Movement
88
157.425
157.425
x
Port Operations and Ship Movement
Inter-ship channels are for communications between ship stations. Inter-ship communications should be restricted to
Channels 6, 8, 72 and 77. If these are not available, the other channels marked for Inter-ship may be used.
Channel 70 is used exclusively for Digital Selective Calling (DSC) and is not available for regular voice
communications.
Notes:
1. Channel 06 may also be used for communications between ship stations and aircraft engaged in coordinated search and
rescue operations. Ship stations should avoid harmful interference to such communications on channel 06 as well as to
communications between aircraft stations, ice breakers and assisted ships during ice seasons.
2. Within the European Maritime Area and in Canada, channels 10, 67 and 73 may also be used by the individual admini
strations concerned for communication between ship stations, aircraft stations and participating land stations engaged
in coordinated search and rescue and anti-pollution operations in local areas. Channels 10 or 73 (depending on location)
are also used for the broadcast of Marine Safety Information by the Maritime and Coast Guard Agency in the UK only.
3. Channel 13 is designated for use on a worldwide basis as a navigation safety communication channel, primarily for
inter-ship navigation safety communications.
4. Channels 15 and 17 may also be used for on-board communications provided the effective radiated power does not
exceed 1 Watt.
5. The use of Channels 75 and 76 should be restricted to navigation related communication only and all precautions
should be taken to avoid harmful interference to channel 16. Transmit power is limited to 1 Watt.

HM360 DSC MAX
17
U.S. Marine VHF Channels and Frequencies
CH
TX Freq
RX Freq
Simplex
Freq Use
01A
156.050
156.050
x
Port Operations and Commercial, VTS. Available only in New Orleans /
Lower Mississippi area.
03A
156.150
156.150
x
U.S. Government only
05A
156.250
156.250
x
Port Operations or VTS in the Houston, New Orleans and Seattle areas.
6
156.300
156.300
x
Inter-ship Safety
07A
156.350
156.350
x
Commercial
8
156.400
156.400
x
Commercial (Inter-ship only)
9
156.450
156.450
x
Boater Calling. Commercial and Non-Commercial.
10
156.500
156.500
x
Commercial
11
156.550
156.550
x
Commercial. VTS in selected areas.
12
156.600
156.600
x
Port Operations. VTS in selected areas.
13
156.650
156.650
x
Inter-ship Navigation Safety (Bridge-to-bridge). Ships >20meters in length
maintain a listening watch on this channel in US waters.
14
156.700
156.700
x
Port Operations. VTS in selected areas.
15
–
156.750
x
Environmental (Receive only). Used by Class ‘C’ EPIRBS.
16
156.800
156.800
x
International Distress, Safety and Calling. Ships required to carry radio,
USCG, and most coast stations maintain a listening watch on this channel.
17
156.850
156.850
x
State Control
18A
156.900
156.900
x
Commercial
19A
156.950
156.950
x
Commercial
20
157.000
161.600
Port Operations (duplex)
20A
157.000
157.000
x
Port Operations
21A
157.050
157.050
x
U.S. Coast Guard only
22A
157.100
157.100
x
Coast Guard Liaison and Maritime Safety Information Broadcasts.
Broadcasts announced on channel 16.
23A
157.150
157.150
x
U.S. Coast Guard only
24
157.200
161.800
Public Correspondence (Marine Operator)
25
157.250
161.850
Public Correspondence (Marine Operator)
26
157.300
161.900
Public Correspondence (Marine Operator)
27
157.350
161.950
Public Correspondence (Marine Operator)
28
157.400
162.000
Public Correspondence (Marine Operator)
61A
156.075
156.075
x
U.S. Government only
63A
156.175
156.175
x
Port Operations and Commercial, VTS. Available only in New Orleans /
Lower Mississippi area.
64A
156.225
156.225
x
U.S. Coast Guard only
65A
156.275
156.275
x
Port Operations
66A
156.325
156.325
x
Port Operations

HM360 DSC MAX
18
67
156.375
156.375
x
Commercial. Used for Bridge-to-bridge communications in lower
Mississippi River. Inter-ship only.
68
156.425
156.425
x
Non-Commercial
69
156.475
156.475
x
Non-Commercial
70
156.525
156.525
x
Non-Commercial
71
156.575
156.575
x
Non-Commercial
72
156.625
156.625
x
Non-Commercial (Inter-ship only)
73
156.675
156.675
x
Port Operations
74
156.725
156.725
x
Port Operations
77
156.875
156.875
x
Port Operations (Inter-ship only)
78A
156.925
156.925
x
Non-Commercial
79A
156.975
156.975
x
Commercial. Non-Commercial in Great Lakes only.
80A
157.025
157.025
x
Commercial. Non-Commercial in Great Lakes only
81A
157.075
157.075
x
U.S. Government only – Environmental protection operations.
82A
157.125
157.125
x
U.S. Government only
83A
157.175
157.175
x
U.S. Coast Guard only
84
157.225
161.825
Public Correspondence (Marine Operator)
84A
157.225
157.225
Non-Commercial
85
157.275
161.875
Public Correspondence (Marine Operator)
85A
157.275
157.275
Non-Commercial
86
157.325
161.925
Public Correspondence (Marine Operator)
86A
157.325
157.325
Non-Commercial
87
157.375
161.975
Public Correspondence Marine Operator)
87A
157.375
157.375
Non-Commercial
88
157.425
162.025
Public Correspondence only near Canadian border
88A
157.425
157.425
x
Commercial, Inter-ship only
Recreational boaters normally use channels listed as Non-Commercial: 68, 69, 71, 72, 78A.
Channel 70 is used exclusively for Digital Selective Calling (DSC) and is not available for regular voice
communications.
Channels 75 and 76 are reserved as guard bands for Channel 16 and are not available for regular voice
communications.
Notes:
1. The letter “A” following a channel number indicates simplex use of the ship station transmit side of an international
semi-duplex channel. Operations are different from that of international operations on that channel.
2. Channel 13 should be used to contact a ship when there is danger of collision. All ships of length 20 meters or greater
are required to guard VHF channel 13, in addition to VHF channel 16, when operating within U.S. territorial waters.
3. Channel is Receive Only.
4. Channel 16 is used for calling other stations or for distress alerting.
5. Output power is fixed at 1 watt only.
6. Output power is initially set to 1 watt. User can temporarily override this restriction to transmit at high power.

19
Canadian Marine VHF Channels and Frequencies
CH
TX Freq
RX Freq
Area of Operation Use
1
156.050
160.650
PC Public Correspondence
2
156.100
160.700
PC Public Correspondence
3
156.150
160.750
PC Public Correspondence
04A
156.200
156.200
PC Inter-ship, Ship/Shore and Safety: Canadian Coast Guard S&R
05A
156.250
156.250
Ship Movement
6
156.300
156.300
All areas Inter-ship, Commercial, Non commercial and Safety: May Be used for search
and rescue communications between ships and aircraft.
07A
156.350
156.350
All areas Inter-ship, Ship/Shore, Commercial
8
156.400
156.400
WC, EC Inter ship, Commercial and Safety: Also assigned for operations in the Lake
Winnipeg area.
9
156.450
156.450
AC Inter-ship, Ship/Shore, Commercial, Non-commercial and Ship Movement: May
be used to communicate with aircraft and Helicopters in predominantly maritime
support operations.
10
156.500
156.500
AC, GL Inter-ship, Ship/Shore, Commercial, Non-commercial, Safety and Ship
Movement: May also be used for communications with aircraft engaged in coordinated
search and rescue and antipollution operations.
11
156.550
156.550
PC, AC, GL Inter-ship, Ship/Shore, Commercial, Non-commercial and Ship
Movement: Also used for pilotage purposes.
12
156.600
156.600
WC, AC, GL Inter-ship, Ship/Shore, Commercial, Non-commercial and Ship
Movement: Port operations and pilot information and messages.
13
156.650
156.650
All areas Inter-ship, Commercial, Non-commercial and Ship Movement: Exclusively
for bridge-to-bridge navigational traffic. Limited to 1-watt maximum power.
14
156.700
156.700
AC, GL Inter-ship, Ship/Shore, Commercial, Non-commercial and Ship Movement:
Port operations and pilot information and Messages.
15
156.750
156.750
All areas Inter-ship, Ship/Shore, Commercial, Non-commercial and Ship Movement:
All May also be used for on-board Communications.
16
156.800
156.800
All areas International Distress, Safety and Calling.
17
156.850
156.850
All areas Inter-ship, Ship/Shore, Commercial, Non-commercial and Ship Movement:
All operations limited to 1-watt maximum power. May also be used for on-board
Communications.
18A
156.900
156.900
All areas Inter-ship, Ship/Shore and Commercial: Towing on the Pacific Coast.
19A
156.950
156.950
All areas except PC Inter-ship and Ship/Shore: Canadian Coast Guard only.
20
157.000
161.600
All areas Ship/Shore, Safety and Ship Movement: Port operation
21A
157.050
157.050
All areas Inter-ship and Ship/Shore: Canadian Coast Guard only.
21B
–
161.650
All areas Safety: Continuous Marine Broadcast (CMB) service.
