TL 2020
Part No. IES050121
USER MANUAL
LCD COLOR TV
R
LANGUAGE ENGLISHLANGUAGE ENGLISH

Important safety instructions ...... .......... .......... .......... .......... .......... .......... .......... ..........
Brief product overview ..................................... .......... .......... .......... .......... .......... .....
Learning about your new TV ........................... ......... .......... .......... .......... .......... ..........
Selecting a location for the TV............................... .......... .......... .......... .......... .......... .....
Connecting your TV......................................... .......... .......... .......... .......... .......... .....
Connecting audio/visual equipment .............. .......... .......... .......... .......... .......... ..........
Connecting the PC or Notebook ........................ .......... .......... .......... .......... .......... .....
Connecting to an Aerial / Cable antenna............... .......... .......... .......... .......... .......... .....
Preparation for using your new TV using the remote control .......... .......... .......... .......... ..........
Preparing the remote control for use.................... .......... .......... .......... .......... .......... .....
Shortcut keys operation .................................... .......... .......... .......... .......... .......... .....
Menu operation............................................. .......... .......... .......... .......... .......... .....
Using the Picture Parameters menu ................... .......... .......... .......... .......... .......... ....
Using the Audio Setting menu ........................ .......... .......... .......... .......... .......... .....
Using the Geometry menu ............................ .......... .......... .......... .......... .......... .....
Using the General Settings menu ...................... .......... .......... .......... .......... .......... .....
Using the Search menu ................................ .......... .......... .......... .......... .......... .....
Appendix ................................................... .......... .......... .......... .......... .......... .....
Cleaning and care ...................................... .......... .......... .......... .......... .......... .....
Trouble shooting ....................................... .......... .......... .......... .......... .......... .....
Specifications .......................................... .......... .......... .......... .......... .......... .....
This is an IEC safety class product and must be grounded for safety.
SAFETY CLASS
Please read all the safety and operating instructions carefully before you begin.
CONTENTS
2
4
6
7
7
7
8
8
10
10
11
14
14
14
15
15
18
19
19
20
21
-1-
LANGUAGE ENGLISHLANGUAGE ENGLISH

-2-
Important safety instructions
CAUTION
CAUTION: TO REDUCE THE RISK OF ELEC-
TRIC SHOCK, DO NOT REMOVE
COVER (OR BACK) .NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flashwith arrowhead symbol within an
equilateral triangle isintended to alertthe user tothe
presence of uninsulateddangerous voltage withinthe
product s enclosure thatmay be ofsufficient magnitude
to constitute arisk of electricshock.
'
The exclamation pointwithin an equilateraltriangle is
intended to alertthe user tothe presence of important
operating and maintenance( servicing )instructions in
the literature accompanyingthe set.
CAUTION: CHANGES OR MODIFICATIONS NOT EXPRESSLYAPPROVED BYTHE PARTY
RESPONSIBLE FOR COMPLIANCE WITH THE FCC RULES COULD VOID THE
USER S AUTHORITYTO OPERATE THIS EQUIPMENT.'
WARNING: TO PREVENT FIRE OR SHOCKHAZARD, DO NOTEXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
1. READ THESEINSTRUCTIONS
All the safetyand operating instructionsshould be read before the productis operated.
2. KEEP THESE INSTRUCTIONS
Retain safety andoperating instructions forfuture reference.
3. HEEDALL WARNINGS
Adhere to allwarnings on theproduct and inthe operating instructions.
4. FOLLOWALL INSTRUCTIONS
Follow all operatingand use instructions.
5. DO NOTUSE THIS APPARATUS NEAR WATER
Do not usethe product nearwater. Forexample, near abathtub, washbowl, kitchensink, or laundrytub, in awet
basement, or neara swimming pool,and the like.
6. CLEAN ONLY WITHDRY CLOTH
Unplug the TV from thewall outlet before cleaning. Do notuse liquid cleaners or aerosol cleaners.Clean only witha
dry cloth.
7. DO NOTBLOCK ANYVENTILATION OPENINGS
Slots and openingsin the cabinetback or bottomare provided forventilation, to ensurereliable operation ofthe
TV and toprotect it fromoverheating. These openings must notbe blocked orcovered. The openings should never
be blocked byplacing the producton a bed,sofa, rug, orother similar surface.This product should never beplaced
near or overa radiator orheat resource. This product shouldnot be placedin a built-ininstallation such asa bookcase
or rack unlessproper ventilation isprovided or the manufacturer's instructions havebeen adhered to.
8. DO NOTINSTALL NEAR ANYHEAT SOURCES
This product shouldbe situated awayfrom heat sources such as radiators,stoves, or other products (including amplifiers)
that produce heat.
9. DO NOTDEFEAT THE SAFETY PURPOSE OF THEPOLARIZED OR GROUNDING-TYPEPLUG
A polarizedplug has twoblades with one wider than theother.A grounding-type plug hastwo blades anda third grounding
prong. The wide blade orthe third prongis provided foryour safety. If theprovided plug doesnot fit into your outlet, consult
an electrician forreplacement of theobsolete outlet.
10. PROTECT THEPOWER CORD FROMBEING WALKEDON OR PINCHEDPARTICULARLY AT PLUGS, CONVENIENCE
RECEPTACLES, AND THE POINT WHERE THEYEXIT FROM THEAPPARATUS.
11. ONLY USEATTACHMENTS/ACCESSORIES SPECIFIED BYTHE MANUFACTURER.
LANGUAGE ENGLISHLANGUAGE ENGLISH

S3126A
-3-
Important safety instructions
12. USE ONLY WITHCART,STAND, TRIPOD, BRACKET ORTABLE SPECIFIED BY
THE MANUFACTURER,OR SOLD WITHTHE APPARATUS. WHEN ACART IS USED,
USE CAUTION WHENMOVING THE CART/APPARATUS COMBINATION TO AVOID
INJURY FROMTIP-OVER.
Do not placethis TV on a unstablecart, stand, tripod,bracket ,or table.The TV may
fall, causing seriousinjury to someone,and serious damageto the appliance.An TV
and cart combinationshould be movedwith care. Quickstops, excessive force,and
uneven surfaces maycause the productand cart combinationto overturn.
POWER SOURCE
This TV should be operatedonly from thetype of powersource indicated onthe marking label.If you are not sure ofthe type
of power supplyto your home,consult your appliancedealer or localpower company .For TVs intended to operatefrom
battery power,or other sources,refer to theoperating instructions.
16. POWER CORDPROTECTION
Power-supply cords shouldbe routed sothat they arenot likely tobe walked onor pinched byitems placed uponor against
them, paying particularattention to cordsat plugs, conveniencereceptacles, and thepoint where theyexit from theappliance.
17. OUTDOORANTENNA GROUNDING
If an outsideantenna or cablesystem is connectedto
the TV, be sure the antenna orcable system isgrounded
to provide someprotection against voltagesurges
and built-up staticcharges. Section 810of the National
Electrical Code,ANSI/NFPANO.70, provides
information with respectto proper grounding
of the mastand supporting structure,grounding
of the lead-inwire to anantenna discharge unit,
size of groundingconductors, location of
antenna discharge unit,connection to grounding
electrodes, and requirementsfor the grounding
electrode (Fig.A).
18. LIGHTNING
For added protectionfor this TV receiver during
a lightning storm,or when itis left unattendedand
unused for longperiods of time,unplug it fromthe wall outletand disconnect theantenna or cable system. This will prevent
damage to theTV due to lightning andpower line surges.
19. POWER LINES
An outsideantenna system shouldnot be locatedin the vicinityof overhead powerlines, or other electric light orpower
circuits, or whereit can fallinto such powerlines or circuits.When installing anoutside antenna system, extreme care should
be taken tokeep from touchingsuch power linesor circuits ascontact with themmight be fatal.
20. OVERLOADING
Do not overloadwall outlets andextension cords asthis can resultin a riskof fire orelectric shock.
21. OBJECTAND LIQUID ENTRY
Never push objectsof any kindinto this TV through openingsas they maytouch dangerous voltagepoints or shortout parts
that could resultin fire orelectric shock. Neverspill liquid ofany kind intothe TV.
22. SERVICING
Do not attemptto service thisTV yourself as opening orremoving covers mayexpose you todangerous voltage orother
hazards. Refer allservicing to qualifiedservice personnel.
23. REPLACEMENT PARTS
When replacement partsare required, besure the service technician uses replacementparts specified bythe manufacturer
that have thesame characteristics asthe original part.Unauthorized substitutions mayresult in fire,electric shock, injuryto
persons or otherhazards.
24. SAFETY CHECK
Upon completion ofany service orrepairs to thisTV,ask the servicetechnician to perform routine safety checksto determine
that the TV is inproper operating condition.
13. UNPLUG THISAPPARATUS DURING LIGHTNINGSTORMS OR WHEN UNUSED
FOR LONG PERIODSOF TIME.
For added protectionfor this TV receiver duringa lightning storm,or when itis left
unattended and unusedfor long periodof time, unplug it from thewall outlet and
disconnect the antennaor cable system.This will prevent damage tothe TV due to
lightning and powerline surges.
14. REFERALL SERVICING TO QUALIFIED SERVICE PERSONNEL.SERVICING IS REQUIRED WHEN THEAPPARATUS
HAS BEEN DAMAGEDIN ANYWAY,SUCH AS POWER-SUPPLYCORD OR PLUGIS DAMAGED, LIQUIDHAS BEEN
SPILLED OR OBJECTSHAVE FALLEN INTO THEAPPARATUS, THE APPARATUS HAS BEENEXPOSED TO RAIN OR
MOISTURE, DOES NOTOPERATE NORMALLY, OR HASBEEN DROPPED.
15.
ANTENNA LEAD
IN WIRE
ANTENNA
DISCHARGE UNIT
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
ELECTRIC
SERVICE
EQUIPMENT
GROUND
CLAMP
EXAMPLE OF ANTENNA GROUNDINGAS PER
NATIONAL ELECTRICAL CODE
FIGURE A
S2898A
GROUNDING WIRES
LANGUAGE ENGLISHLANGUAGE ENGLISH

Brief product overview
1.Connection
Connect the antenna lead or CATV cable or external equipment (such as Antenna, Cable TV, VCD, DVD,
VCR, Set top box, etc.) to the corresponding terminals or interface on the TV rear (please refer to the owner s
manual of the equipment to be connected as well) and confirm that the signal source is available and works.
normally.
2.The remote control
Open the back battery cover on the remote control and insert 2 x 'AAA' size batteries, noting the correct
polarities marked inside the battery compartment . Next close the battery cover.
-4-
AC IN
PC IN
AV OUT
ANT.IN
L R
AUDIO
S-VIDEOVIDEO
COMPONENT
Y P/C P /C
B B R R
OKOK
11
44
2233
77
5566
8899
00
SOURCE SCAN
CCD PARENT LOCK
MENU
SAP
MUTE
P.MODE
S.MODE
RECALL
VOL CH
SLEEP DISPLAY
SCAN: Scan availablechannels
POWER: Power on/off
SOURCE: Select oneof five inputsignal sources
PARENT: Parental control function
LOCK: Set childlock
CCD: Closed captionfunction
SAP: SAP/stereo/mono audio setting selection
MUTE: Mute thesound
MENU: Call upthe main menu
RECALL: Return toprevious channel
S.MODE: Select thesound mode
P.MODE: Select thepicture mode
VOL+/-:Volume up/down
CHANNEL NUMBER: Direct Channelselection
SLEEP: Set thesleep timer
DISPLAY: Display currentStatus information
CH+/-: Channel up/down
/
/
OK: Confirm selectedfunction or returnto the previous menu
: Cursor up/down
: Select oradjust from aparticular menu
LANGUAGE ENGLISHLANGUAGE ENGLISH

Note 2: For more detailed information, please refer to the pages that follow.
Note 1: Allbuttons mentioned above are on the remote control unless indicated otherwise.
-5-
3.Switching on/off
1) Connect the TV to power outlet. Switch on the power switch located on the back of the TV (See page 6,
item 21 for location), if the power indicator is red, it means the TV is off now. You need to press the
POWER switch on the TV or the POWER button on the remote control to turn on the TV, and the power
indicator will light up in blue.
2) Press the power switch or the POWER button on the remote control again to turn off the TV.
4.Signal source selection
Press the number [1-9]button or CH+ or CH- button to select TV input;press the SOURCE button to selectTV,
Video, S-Video,VGA,Component.
6.Channel search
In order to accessthis setting, you needto be in theAntenna (TV)source mode
(press SOURCE button repeatedly).
1) Press theMENU button to enter themain menu.
2) Press the button to selectthe itemSearch, and press the button toenter Search menu.
3) Press the button to selectthe itemAuto Search.
4) Press the button to start auto searching for all available channels.
5)Once all the availablechannels have been memorized,you are now ableto use the numericalbuttons
or channel + / - buttonsto watch the channelnumber you desire.
7.Picture adjustment
1) Press the MENU button to enter the main menu.
2) Press the button to select the item Picture Parameters,
and press the button to enter Picture Parameters menu.
3) Press the button to select the item you want to adjust.
4) Press the button to adjust the level.
5) Press OK button to confirm your selection. Press OK again to exit from the menu.
8.Audio adjustment
1) Press the MENU button to enter the main menu.
2) Press the button to select the item Audio Settings,
and press the button to enter Audio Settings menu.
3) Press the button to select the item you want to adjust.
4) Press the button to adjust the level.
5) Press OK button to confirm your selection. Press OK again to exit from the menu.
[ or ]
[ or ]
[ or ]
[ or ]
[ or ]
[ or ]
[ ]
[ ]
[ ]
[ or ]
[ or ] [ ]
quAlier
Treble
Bass
Balance
HeadPhone
Equalizer
50
50
50
Audio Settings
Equalier
Britghtness
Contrast
Saturation
Sharpness
Color Temp Normal
50
50
50
50
Picture Parameters
Hue
50
5.Air/Cable selection
In order to accessthis setting, you needto be in theAntenna (TV)source mode (press SOURCEbutton repeatedly).
You can select thesignal receiving method accordingto the following steps:
1) Press theMENU button to enter themain menu.
2) Press the button to selectthe item Search and press the
buttonto enterSearch menu.
3) Press the button to selectthe item Tuning Mode.
4) Press the button to change the item among Air, Cable.
5) Press OK button to confirm your selection. Press OK again to exit fromthe menu.
[ or ]
[ ]
[ or ]
[ ]
LANGUAGE ENGLISHLANGUAGE ENGLISH

-6-
Learning about your new TVLearning about your new TV
Youcan operate yourTV by using the buttonson the front panel or theremote control. Theterminals on the
side and therear panel provideall the connectionsyou will needto connect otherequipment to yourTV.
Side Controls /
Connections
Note: The above figures are for reference only. Please refer to the actual connection jacks to determine their
appearance.
Rear Connections
MENU
TV/AV
CH
VOL
VOL
CH
7
8
10
AC IN
PC IN
AV OUT
ANT.IN
L R
AUDIO
S-VIDEOVIDEO
YPB/CBPR/CR
COMPONENT
88
20
9
21
THEAC SWITCH BE
ON THE BACK COVER.
.
LANGUAGE ENGLISHLANGUAGE ENGLISH

-7-
Learning about your new TV
Selecting a location for the TV
1)Place the TV on the floor or on a sturdy platform in a location where light does not directly hit the screen.
2)Place the TV far enough from the walls to allow proper ventilation. Inadequate ventilation may cause
overheating, which may damage the TV.
Caution: Do not plug the TV in until you have finished connecting all of your equipment.
Connecting your TV
Follow the instructions below to hookup a VCR, DVD, satellite receiver, camcorder, audio amplifier, etc. (Cables not
included). Use the SOURCE button on your remote control to select signal sources.
Connecting audio/visual equipment
AV outputs
20
Remote control sensor
POWER button (standby)
POWER indicator
Channel up / cursor up
Channel down / cursor down
Volume up / cursor right
Volume down / cursor left
TV / AV / PC input select
MENU button
AV audio input L
CATV antenna input
AV Video input
S-Video input
Y PB/CB PR/CRinput (Component)
PC VGAinput
POWER Plug
AV audio input R
Headphone jack
9Wall mountinglocating hole
AC IN
PC IN
ANT.IN
L R
AUDIO
S-VIDEOVIDEO
YPB/CBPR/CR
CC
VCD, DVD, STB
Pb Pr
Power switch
21
Wall Mounting your TV
The TL2020 is a VESA compliant LCD TV which means that it can be wall mounted using a standard VESA
compliant mounting bracket. VESAcompliant mounting brackets are available at your local electronics
store. The sizing of the bracket should be 100mm x 100mm. Please consult the store you are purchasing
the bracket from for details. Note that the base of the TV needs to be removed before attaching the wall
mounting bracket. Simply place the LCD screen, face down, on a soft, cushioned, non slip, non abrasive
surface, making sure that it cannot slip or slide. Now remove the screws that are holding the base in place.
Connection Details:
Connect using AV inputs (RCAComposite)
- Use 1, 2,4
Connect using S-Video inputs
- Use 1, 2,3
Connect using Y Pb/CbPr/Cr inputs (Component)
- Use 1, 2,5, 6, 7
27 4
3
16
5
LANGUAGE ENGLISHLANGUAGE ENGLISH

Connecting your TV
-8-
To enjoy the terrestrial signal transmitted by your local TV station, you need an indoor or outdoor aerial (not supplied).
Perfect picture quality requires a good signal and generally means that an outdoor aerial must be implemented. The
exact type and location of the aerial will depend on your particular area. Consult your local dealer or service
personnel for best advice. If you are a subscriber of your local CATV provider, the outdoor or indoor aerial is not needed.
Connect the equipment as follows:
REAR VIEW
Connecting to an Aerial / Cable antenna
PC/NB
To VGA
RGB line
You can use your TV as a monitor for connecting through the PC IN (VGA) connection jack. your PC or Notebook by Connect
the devices as shown below.
Connecting to a Personal Computer or Notebook
NOTE: 1) Headphones are not included.
2) No sound will be heard from the
main unit speakers when a
headphone mini-plug is connected
into the headphone jack.
The refresh rate of your PC & Notebook must be adjusted to 60Hz or below.
NOTE:
Headphone
PC IN
ANT.IN
AERIAL SOCKET
Loosen the screw Insert the feeder in Tighten the screw
Plug(not supplied)
Adaptor (not supplied)
The signal comes from:
An outdoor antenna
An indoor antenna
CATV net
TWIN-LEAD FEEDER(300 W)
COAXIAL CABLE (75W)
(cable not included)
LANGUAGE ENGLISHLANGUAGE ENGLISH

- 9 -
Connecting to a cable converter box
This television has an extended tuning range and can tune into most cable channels without using a cable
company suppliedconverter box.Some cablecompanies offerpremium pay channels in which the signal is
scrambled. Descramblingthese signals for normal viewing requires the use of a descrambler device which
is generally provided by the cable company.
For subscribers to Basic Cable TV Service
For basic cable service, you do not require a Converter/Descrambler box. Connect the CATV 75 ohm Coaxial
Cable directly to the Antenna Jack on the back of the television.
For subscribers to Scrambled Cable TV Service
If you subscribe to a cable service which requires the use of a Converter/Descrambler box, connect the
incoming cable to the Converter/Descrambler box and connect the output of the box to the Antenna Jack
on the back of the television. Follow the connections shown below. Set the television to the output of the
Converter/Descrambler box (usually channel 3 or 4)and use the Converter/Descrambler box remote control
to select channels.
For Subscribers to Unscrambled Basic Cable with Scrambled Premium Channels
If you subscribe to a cable service in which basic cable channels are unscrambled and premium channels
require the use of a Converter/Descrambled box, you may wish to use a two-set signal splitter (sometimes
Called two set coupler) and an A/B Switch box from the cable installer or an electronics supply store.
Follow the connections shown below. With the switch in the B position, you can directly tune into any
nonscrambled channels on your TV. With the switch in the Aposition, tune your TV to the output of the
Converter/Descrambler box (usually channel 3 or 4) and use the box to tune into scrambled channels.
Note:
When you use a converter box with your TV, there may be TV features that you cannot
access using the remote control that's provided with the converter box. Therefore keep
the TV remote handy.
Preparation for using your new TV
Converter/Descrambler
Converter/Descrambler
Splitter A/B Switch
ANT 75¦¸
LANGUAGE ENGLISHLANGUAGE ENGLISH
