Hisense FV298N4AWE User manual

FV298N4AWE
FV298N4ACE
FV298N4AWF
FV298N4ACF

2
Contents
Safety and warning formation…………....2
Installing your new appliance…………7
Description of the appliance……………9
Display controls…………………………10
Using your appliance…………………… 12
Cleaning and care………………………13
Helpful hints and tips……………………15
Troubleshooting………………………….16
Disposal of the appliance………………20
Safety and warning information
For your safety and correct usage, before installing and first using the appliance,
read this user manual carefully, including its hints and warnings. To avoid
unnecessary mistakes and accidents, it is important to make sure that all people
using the appliance are thoroughly familiar with its operation and safety features.
Save these instructions and be sure that they remain with the appliance if it is
moved or sold, so that anyone using it throughout its life, will be properly
informed on its usage and safety notices.
For the safety of life and property, keep the precautions of these user's
instructions as the manufacturer is not responsible for damages caused by
omission.
Safety for children and others who are vulnerable people
●According to EN standard
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
●According to IEC standard
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person being responsible for their safety.
●Children should be supervised to ensure that they do not play with the
appliance.
Keep all packaging away from children as there is risk of suffocation.
If you are discarding the appliance, pull the plug out of the socket, cut the
connection cable (as close to the appliance as you can) and remove the
door to prevent children playing from suffering an electric shock or from
closing themselves inside it.
If this appliance, featuring a magnetic door seals, is to replace an older
appliance having a spring lock (latch) on the door or lid, be sure to make
the spring lock unusable before you discard the old appliance. This will

3
prevent it from becoming a death trap for a child.
General safety
WARNING —This appliance is intended to be used in household
and similar applications such as
-staff kitchen areas in shops, offices and other working environments;
-farm houses and hotels, motels and other residential type environments;
-bed and breakfast type environments;
-catering and similar non-retail applications.
WARNING — Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
WARNING — If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to
avoid a hazard.
WARNING — Keep ventilation openings, in the appliance enclosure or in
the built-in structure, clear of obstruction.
WARNING — Do not use mechanical devices or other means to
accelerate the defrosting process, other than those recommended by the
manufacturer.
WARNING — Do not damage the refrigerant circuit.
WARNING — Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type recommended
by the manufacturer.
WARNING — The refrigerant and insulation blowing gas are flammable.
When disposing of the appliance, do so only at an authorized waste
disposal centre. Do not expose to flame.
WARNING —When positioning the appliance, ensure the supply cord is
not trapped or damaged.
WARNING —Do not locate multiple portable socket-outlets or portable
power supplies at the rear of the appliance.
Replacing the illuminating lamps
WARNING—The illuminating lamps must not be replaced by the user! If
the illuminating lamps is damaged, contact the customer helpline for
assistance. This warning is only for refrigerators that contain illuminating
lamps.
Refrigerant
The refrigerant isobutene (R600a) is contained within the refrigerant circuit of
the appliance, a natural gas with a high level of environmental compatibility,
which is nevertheless flammable. During transportation and installation of the
appliance, ensure that none of the components of the refrigerant circuit
becomes damaged.

4
The refrigerant (R600a) is flammable.
WARNING — Refrigerators contain refrigerant and gases in the insulation.
Refrigerant and gases must be disposed of professionally as they may cause
eye injuries or ignition. Ensure that tubing of the refrigerant circuit is not
damage prior to proper disposal.
It is hazardous for anyone other than an Authorized Service Person to service
this appliance. In Queensland the Authorized Service Person Must hold a Gas
Work Authorized for hydrocarbon refrigerants to carry out servicing or repairs
which involve removal of covers.
WARNING: risk of fire
If the refrigerant circuit should be damaged:
-Avoid opening flames and sources of ignition.
-Thoroughly ventilate the room in which the appliance is situated.
It is dangerous to alter the specifications or modify this product in any way.
Any damage to the cord may cause a short circuit, fire, and/or electric shock.
Electrical safety
1. The power cord must not be lengthened.
2. Make sure that the power plug is not crushed or damaged. A crushed or
damaged power plug may overheat and cause a fire.
3. Make sure that you can access the main plug of the appliance.
4. Do not pull the main cable.
5. If the power plug socket is loose, do not insert the power plug. There is a
risk of electric shock or fire.
6. You must not operate the appliance without the interior lighting lamp cover.
7. The fridge is only applied with power supply of single phase alternating
current of 220~240V/50Hz. If fluctuation of voltage in the district of user is so
large that the voltage exceeds the above scope, for safety sake, be sure to
apply A.C. Automatic voltage regulator of more than 350W to the fridge. The
fridge must employ a special power socket instead of common one with other
electric appliances. Its plug must match the socket with ground wire.
Daily use
Do not store flammable gas or liquids in the appliance, There is a risk of
an explosion.
Do not operate any electrical appliances in the appliance (e.g. electric ice
cream makers, mixers etc.).
When unplugging always pull the plug from the mains socket, do not pull
on the cable.
Do not place hot items near the plastic components of this appliance.
Do not place food products directly against the air outlet on the rear wall.

5
Store pre-packed frozen food in accordance with the frozen food
manufacturer’sinstructions.
The appliances manufactures storage recommendations should be strictly
adhered to. Refer torelevant instructions for storage.
Do not place carbonated or fizzy drinks in the freezer compartment as it
creates pressure on the container, which may cause ittoexplode,
resulting in damage to the appliance.
Frozen food can cause frost burns ifconsumed straight from the freezer
compartment.
Do not place the appliance in direct sunlight.
Keep burning candles, lamps and other items with naked flames away
from the appliance so that do not set the appliance on fire.
The appliance is intended for keeping food stuff and/or beverages in
normal household as explained in this instruction booklet. You should take
care when move it as the appliance is heavy.
Do not remove nor touch items from the freezer compartment ifyour
hands are damp/wet, as this could cause skin abrasions or frost/freezer
burns.
Never use the base, drawers, doorsetc. tostand on or as supports.
Frozen food must not be refrozen once ithas been thawed out.
Do not consume ice popsicles or ice cubes straight from the freezer as
this can cause freezer burn to the mouth and lips.
To avoid items falling and causing injury or damage to the appliance, do
not overload the door racks or put too much food in the crisper drawers.
This refrigerating appliance is not intended to be used as a built-in
appliance.
caution!
Care and cleaning
Before maintenance, switch off the appliance and disconnect the mains
plug from the mains socket.
Do not clean the appliance with metal objects, steam cleaner, ethereal
oils, organic solvents or abrasive cleansers.
Do use a plastic scraper instead of a sharp objects to remove frost from
the appliance.
Installation Important!
For electrical connection carefully, follow the instructions given in this
manual. Unpack the appliance and check if there are damages on it.
Do not connect the appliance if it is damaged. Report possible damages
immediately to the place you bought it. In this case retain packing.
It is advisable to wait at least four hours before connecting the appliance
to allow the oil to flow back in the compressor.

6
Adequate air circulation should be around the appliance, lacking this leads
to overheating. To achieve sufficient ventilation, follow the instructions
relevant to installation.
Wherever possible the back of the product should not be too close to a
wall to avoid touching or catching warm parts (compressor) to prevent the
risk of a fire, follow the instructions relevant to installation.
The appliance must not be locate close to radiators or cookers.
Make sure that the mains plug is accessible after the installation of the
appliance.
Service
Any electrical work required to do the servicing of the appliance should be
carried out by qualified electrician or competent person.
This product must be serviced by an authorized Service
Center, and only genuine spare parts must be used.
1) If the appliance is Frost Free.
2) If the appliance contains freezer compartment.

7
Installing your new appliance
Before using the appliance for the first time,
you should be informed of the following tips.
Warning!
For proper installation, this freezer must be
placed on a level surface of hard material
that is the same height as the rest of the
flooring. This surface should be strong
enough to support a fully loaded freezer.
The rollers, which are not castors, should
be only used for forward or backward
movement. Moving the freezer sideways
may damage your floor and the rollers.
Ventilation of appliance
In order to improve efficiency of
the cooling system and save
energy, it is necessary to
maintain good ventilation around the
appliance for the dissipation of heat. For
this reason, sufficient clear space should
be available around the freezer.
Suggest: It is advisable for there to be
50-75mm of space from the back to the
wall, at least 100mm from its top, at least
100mm from its side to the wall and a
clear space in front to allow the doors to
open 130°. As shown in follow diagrams.
Note:
This appliance performs well within the
climate class from SN to T showed in the
table below. It may not work properly if
being left at a temperature above or below
the indicated range for a long period.
Climate class Ambient temperature
SN +10°C to +32°C
N +16°C to +32°C
ST +16°C to +38°C
T +16°C to +43°C
Stand your appliance in a dry place to
avoid high moisture.

8
Keep the appliance out of direct sunlight,
rain or frost. Stand the appliance away
from heat sources such as stoves, fires or
heaters.
Leveling of appliance
For sufficient leveling and air circulating in
the lower rear section of the appliance, the
bottom feet may need to be adjusted. You
can adjust them manually by hand or by
using a suitable spanner.
To allow the doors to self-close, tilt the top
backwards by 10-15mm.
Installing the door handles
For the convenience of transportation, the
door handles are separately provided in a
plastic bag, you can install the door
handles as follows.
1. Lever screw covers on the left side of
the door, and then put them back to the
plastic bag.
2. Match the handle on the left side of the
door, keeping axes of the screw holes
in the handle and the door in a line, as
the picture shows.
3. Fix the handle with the special screws
provided in the plastic bag.

9
Description of the appliance
View of the appliance
1. Cabinet
2. LED light
3. Glass shelf
4. Upper drawer parts
5. Display
6. Middle drawer parts
7. Lower drawer part
8. Adjustable bottom feet
9. Freezer door
10. Handle（optional）
11. Freezer gasket
Note！
Due to unceasing modification of our products, your freezer may be slightly different from
this instruction manual, but its functions and using methods remain the same.
To get the best energy efficiency of this product, please place all shelves, drawers and
baskets on their original position as the illustration above.

10
Display controls
Use your appliance according to the
following control regulations, your
appliance has the corresponding functions
and modes as the control panels showed
in the pictures below. When the appliance
is powered on for the first time, the
backlighting of the icons on display panel
starts working. If no buttons have been
pressed and the doors are closed, the
backlighting will turn off.
Display panel inside
Controlling the temperature
For optimum food preservation,
We recommend that when you start your
freezer for the first time，the
temperature for the freezer is set to
-18°C (0°F)，if you want to change the
temperature，follow the instructions
below.
Caution！
When you set temperature，you set an
average temperature for the whole freezer
cabinet. Temperature inside each
compartment may vary from the
temperature values displayed on the
panel，depending on how much food you
store and where you place them. Ambient
temperature may also affect the actual
temperature inside the appliance.
Note：High temperature setting will
accelerate food waste.
1. Temp
In the unlocked state, you can switch the
display mode from °C to °F by press the
button for 3 seconds,
In the unlocked state, press
button, when the light is on，the
freezer set temperature is cyclically
adjusted between -14°C and -24°C.
when the light is on, the freezer set
temperature is cyclically adjusted between
7°F and -11°F.

11
2. Super Freeze
Super Freeze will
quickly lower the temperature within the
freezer so food will freeze faster.
This feature also helps to keep the
vitamins and nutrition of fresh food for
longer period.
●In the unlocked state, press
button to enter the Super
Freeze mode, the Super Freeze icon is lit
and the temperature is set to -24°C(-
11°F).
To freeze fresh food activate
the Super Freeze function at
least 24 hours before placing
the food to complete prefreezing
●Super Freeze mode automatically exits
after about 52 hours.
●When Super Freeze function is on, in
the unlocked state, you can switch it off by
pressing button and the
freezer temperature setting will revert
back to the previous setting.
3. Eco
If you are going to
be away for a long period of time, you can
turn it to Eco mode to save on electricity.
●In the unlocked state, press
button to enter the Eco
mode, the Eco icon is lit and the
temperature is set to -17°C（1°F）.
●When the Eco function is on, in the
unlocked state, you can switch it off by
pressing button.The
freezer temperature setting will revert
back to the previous setting.
4. Child Lock
●When the light is on. the freezer is
locked. Press and hold the
button for 3 seconds, the
light is off, the freezer is in the
unlocked state. it can perform other button
operation.
●If no button have been press for 20
seconds, the light will be on.
5. Alarm
In case of alarm, icon will
be flashing and there will be buzzing
sound.
Door Alarm
●When the door is open for over 2
minutes，the door alarm will sound,
meanwhile the display panel show
“dr”.In case of door alarm, buzzer will
sound 3 times every 1 min.
●After the door alarm time exceeds more
than 10 minutes, the buzzer stops
beeping, the icon is off, and the
display screen shows normal. The door
alarm can also be cleared by closing the
door.
●To save energy, please avoid keeping
the door open for a long time when using
the appliance.
6. Power
Pressing and hold the
button for 3 seconds to turn the

12
power function on or off.
●When the freezer is working, In the
unlocked state, you can switch the
appliance off by pressing
button for 3 seconds, the light is on,
meanwhile the display panel show“- -”.
Important！Do not store any food in the
freezer during this time.
●When the freezer is in standby mode
and unlocked, press the button
for 3 seconds, the light is off, the
freezer will turn on and the display will
shows normal.
Note：The display control only can be
setted in the unlocked state
Using your appliance
Your appliance has the accessories as the“Description of the appliance”showed in
general, with this part instruction you can have the right way to use them. We
recommend that you read through them carefully before using the appliance
Shelf in Refrigerator chamber
●There are shelves in freezer chamber,
and they can be taken out to be cleaned.
Freezer Drawer
●It is sued to store food which needs to
be frozen, including meat, fish, ice cream,
etc.
Installing refrigerators in pairs
●Your freezer can be installed with
fridge in pairs.
●It can be installed by installation pairs
supplied like this, but the energy
consumption will increase slightly.

13
Cleaning and care
For hygienic reasons the appliance
(including exterior and interior accessories)
should be cleaned regularly (at least every
two months.
Warning!
The appliance must not be connected to
the mains during cleaning as there is a
danger of electrical shock! Before cleaning
switch the appliance off and remove the
plug from the mains socket.
Exterior cleaning
Wipe the control panel with a clean, soft
cloth.
Spray water onto the cleaning cloth
instead of spraying directly on the surface
of the appliance. This helps ensure an
even distribution of moisture to the
surface.
Clean the doors, handles and cabinet
surfaces with a mild detergent and then
wiped dry with a soft cloth.
Caution!
Don’t use sharp objects as they are likely
to scratch the surface.
Don’t use Thinner, Car detergent, Clorox,
ethereal oil, abrasive cleansers or organic
solvent such as Benzene for cleaning.
They may damage the surface of the
appliance and may cause fire.
Interior cleaning
You should clean the appliance interior
regularly. It will be easier to clean when
food stocks are low. Wipe the inside of the
freezer with a weak solution of bicarbonate
of soda, and then rinse with warm water
using a wrung-out sponge or cloth. Wipe
completely dry before replacing the
shelves and baskets. Thoroughly dry all
surfaces and removable parts before
putting them back into place.
Caution!
Do not use sharp objects to remove frost
from the freezer compartment. Only after
the interior is completely dry should the
appliance be switched back on and
plugged back into the mains socket.
Door seals cleaning
Take care to keep door seals clean. Sticky
food and drinks can cause seals to stick to
the cabinet and tear when you open the
door. Wash seal with a mild detergent and

14
warm water. Rinse and dry it thoroughly
after cleaning.
Caution! Only after the door seals are
completely dry should the appliance be
powered on
Replacing the LED light:
This product contains a light source of
energy efficiency class F.
Warning:
The LED light should be replaced by a
competent person. If the LED light is
damaged, contact the customer helpline
for assistance. To replace the LED light,
the below steps can be followed:
1. Unplug your appliance.
2. Remove light cover by pushing up and
out.
3. Detach the LED and pull it while
pressing the connector latch.
4. Replace LED light and snap it correctly
in place.

15
Helpful hints and tips
Energy saving tips
We recommend that you follow the tips
below to save energy.
Try to avoid keeping the door open for
long periods in order to conserve energy.
Ensure the appliance is away from any
sources of heat (Direct sunlight, electric
oven or cooker etc)
Don‘t set the temperature colder than
necessary.
Don’t store warm food or evaporating
liquid in the appliance.
Place the appliance in a well ventilated,
humidity free, room. Please refer to
Installing your new appliance chapter.
If the diagram shows the correct
combination for the drawers, crisper and
shelves, do not adjust the combination as
this is designed to be the most energy
efficient configuration.
Hints for freezing
When first starting-up or after a period out
of use, let the appliance run at least 2
hours on the higher settings before putting
food in the compartment.
Prepare food in small portions to enable it
to be rapidly and completely frozen and to
make it possible to subsequently thaw only
the quantity required.
Wrap up the food in aluminum foil or
polyethylene wraps which are airtight,
Do not allow fresh，unfrozen food to touch
the food which is already frozen to avoid
temperature rise of the latter.
Iced products，if consumed immediately
after removal from the freezer
compartment, will probably cause frost
burns to the skin.
It is recommended to label and date each
frozen package in order to keep track of the
storage time.
Hints for the storage of frozen food
Ensure that frozen food has been stored
correctly by the food retailer.
Once defrosted ，food will deteriorate
rapidly and should not be re-frozen. Do not
exceed the storage period indicated by the
food manufacturer.
Switching off your appliance
If the appliance needs to be switched off for
an extended period, the following steps
should be taken prevent mould on the
appliance.
1. Remove all food.
2. Remove the power plug from the mains
socket.
3. Clean and dry the interior thoroughly.
4. Ensure that all the doors are wedged
open slightly to allow air to circulate.

16
Troubleshooting
If you experience a problem with your appliance or are concerned that the appliance is not
functioning correctly, you can carry out some easy checks before calling for service, please
see below.
Warning! Don’t try to repair the appliance yourself. If the problem persists after you have
made the checks mentioned below, contact a qualified electrician, authorized service
engineer or the shop where you purchased the product.
Problem Possible cause & Solution
Appliance is not working
correctly
Check whether the power cord is plugged into the power outlet
properly.
Check the fuse or circuit of your power supply, replace if
necessary.
It is normal that the freezer is not operating during the defrost
cycle, or for a short time after the appliance is switched on to
protect the compressor.
Odours from the
compartments
The interior may need to be cleaned
Some food, containers or wrapping cause odours.
Noise from the
appliance
The sounds below are quite normal:
Compressor running noises.
Air movement noise from the small fan motor in the freezer
compartment or other compartments.
Gurgling sound similar to water boiling.
Popping noise during automatic defrosting.

Clicking noise before the compressor starts.
Other unusual noises are due to the reasons below and may
need you to check and take action:
The cabinet is not level.
The back of appliance touches the wall.
Bottles or containers fallen or rolling.
The motor runs
continuously
It is normal to frequently hear the sound of the motor, it will
need to run more when in following circumstances:
Temperature setting is set colder than necessary

Large quantity of warm food has recently been stored within
the appliance.
The temperature outside the appliance is too high.
Doors are kept open too long or too often.

After your installing the appliance or it has been switched off
for a long time.
A layer of frost occurs in
Check that the air outlets are not blocked by food and ensure

17
the compartment
food is placed within the appliance to allow sufficient
ventilation. Ensure that door is fully closed. To remove the
frost, please refer to the
“
Cleaning and care
”
chapter.
Temperature inside is
too warm
You may have left the doors open too long or too frequently; or
the doors are kept open by some obstacle; or the appliance is
located with insufficient clearance at the sides, back and top
Temperature inside is
too cold
Increase the temperature by following the “controls panel”
chapter.
Doors can’
t be closed
easily
Check whether the top of the refrigerator is tilted back by 10-
15mm to allow the doors to self close, or if something inside is
preventing the doors from closing.
Reversing the door
The side in which the door opens can be
changed from the right side (as supplied)
to the left side, if the installation site
allows for it. Tools you will need:
Note: Before you start lay the freezer on
it’s back in order to gain access to the
base, you should rest it on soft foam
packaging or similar material to avoid
damaging the backboard of the freezer. To
reverse the door. The following steps are
generally recommended.
1．Stand the freezer upright.
Remove the screw hole cover and upper
hinge cover（right）as follow diagram.
2. Remove the three screws as follow
diagram. Lift the right upper hinge part.
3.Lift the door and place it on a padded
surface to prevent scratching.

18
4. Loose screws ③， remove part ①
and part ②，then replace them to the left
side and tighten securely with screws ③.
①Door stopper
②Limit block
③Self-tapping screw
5. Lay the freezer on soft foam packaging
or similar material. Remove part ①part
②, and part ③by unscrewing the
screws ④.
①Screw cover
②Adjustable bottom feet part
③Right lower hinge part
④Special flange self-tapping
screw
6. Replace part ③to the left side and
fixing it with the screws ④. Replace
part ①and part ②to another side and
fixing it.

19
Note: 1. You need move hinge axis from
hole ①to ②, move adjustable bottom
feet part from hole ③to ④before
transfer.
7. Set the door into its new place making
sure the pin enters the bushing at the
lower frame section.
8. Replace the lid by fitting the upper
hinge core into the upper door's hole,
securing it with the 3 screws.
9. Put the screw hole cover and upper
hinge cover（left）as follow diagram.
10. Switch the handles from the left to the
right（only for the model with handles）.

20
①Handle cover
②Screw
③Handle part
④Cover-screw cap
Note！
Due to unceasing modification of our
products, handle may be slightly different
from this instruction manual, but its
functions and using methods remain the
same. Switch the handles from the left to
the right as follow diagram.
.
①Screw cover
②Screw
③Handle part
④Cover-screw cap
Warning！
When changing the side at which the door
opens, the appliance must not be
connected to the mains. Remove plug
from the mains beforehand.
Disposal of the appliance
It is prohibited to dispose of this appliance as household waste.
Packaging materials
Packaging materials with the recycle symbol are recyclable. Dispose of the packaging into
a suitable waste collection container to recycle it.
Before disposal of the appliance
1. Pull out the mains plug from the mains socket.
2. Cut off the power cord and discard with the mains plug
Warning! Refrigerators contain refrigerant and gases in the insulation. Refrigerant and
gases must be disposed of professionally as they may cause eye injuries or ignition.
