Hisense RF632N4BBF Mounting instructions

RF632N4BBF

Brief introduction
Contents
Safety and warning information....................................................3
Installing your new appliance.....................................................11
Appliance Description ................................................................................14
Control Panel.............................................................................16
Using your appliance.................................................................18
Helpful hints and tips..................................................................22
Cleaning and Care....................................................................23
Troubleshooting.........................................................................25
Disposal of the appliance ..........................................................26
2
Thank you for choosing . We are sure you will find your new refrigerator a
pleasure to use. However, before you use the appliance, we recommend that you
carefully read the instructions, which provide details about installing and using the
product. Please keep this manual for future reference.
our appliance

Brief introduction
Your safety and the safety of others are very important.
DANGER
WARNING
CAUTION
Safety and warning information
Safety and warning information
For your safety and correct usage, before installing and
first using the appliance, read this user manual
carefully, including its hints and warnings.To avoid
unnecessary mistakes and accidents, it is important to
make sure that all people using the appliance are
thoroughly familiar with its operation and safety
features. Save these instructions and be sure that they
remain with the appliance if it is moved or sold, so that
anyone using it throughout its life, will be properly
informed on its usage and safety notices.
For the safety of life and property, keep the precautions
of these user's instructions as the manufacturer is not
responsible for damages caused by omission.
We have provided many important safety messages in this manual and on your
appliance. Always read and obey all safety messages.
These words mean:
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you
and others. All safety messages will follow the safety alert symbol and
either the word “DANGER,”“WARNING” or “CAUTION.”
An imminently hazardous situation.You could be killed or
seriously injured if you don’t immediately follow
A potentially hazardous situation which, if not avoided,
could result in death or serious bodily injury.
A potentially hazardous situation which, if not avoided,
may result in moderate or minor injury.
3
All safety messages will tell you what the potential hazard is, tell you how to reduce
the chance of injury, and tell you what can happen if the instructions are not
followed.

Safety for children and others who are vulnerable people
According to EN standard
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision. Children aged from 3 to 8 years are
allowed to load and unload refrigerating appliances.
According to IEC standard
This appliance is not intended for use by persons
(including children) with reduced physical sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.
Keep all packaging away from children as there is risk
of suffocation.
If you are discarding the appliance, pull the plug out
of the socket, cut the connection cable (as close to
the appliance as you can) and remove the door to
prevent children playing from suffering an electric
shock or from closing themselves inside it.
If this appliance, featuring a magnetic door seals, is to
replace an older appliance having a spring lock
(latch) on the door or lid, be sure to make the spring
lock unusable before you discard the old appliance.
This will prevent it from becoming a death trap for a
child.
4

General safety
WARNING —This appliance is intended to be used in
household and similar applications such as
-staff kitchen areas in shops, offices and other working
environments;
-farm houses and by clients in hotels, motels and other
residential type environments;
-bed and breakfast type environments;
-catering and similar non-retail applications.
WARNING — Do not store explosive substances such
as aerosol cans with a flammable propellant in this
appliance.
WARNING — If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
WARNING — Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear
of obstruction.
WARNING — Do not use mechanical devices or other
means to accelerate the defrosting process, other
than those recommended by the manufacturer.
WARNING — Do not damage the refrigerant circuit.
WARNING — Do not use electrical appliances inside
the food storage compartments of the appliance,
unless they are of the type recommended by the
manufacturer.
WARNING — The refrigerant and insulation blowing
gas are flammable. When disposing of the appliance,
do so only at an authorized waste disposal centre. Do
not expose to flame.
WARNING —When positioning the appliance, ensure
the supply cord is not trapped or damaged.
5

WARNING —Do not locate multiple portable socket-
outlets or portable power supplies at the rear of the
appliance.
WARNING —Food needs to be packed in bags before
putting into the refrigerator, and liquids need to be
packed in bottles or containers to avoid the problem
that the product design structure is not easy to clean.
The symbol is a warning and indicates the
refrigerant and insulation blowing gas are flammable.
Warning: Risk of fire / flammable materials
Replacing the illuminating lamps
WARNING—The illuminating lamps must not be
replaced by the user! If the illuminating lamps is
damaged, contact the customer helpline for
assistance. This warning is only for refrigerators that
contain illuminating lamps.
Refrigerant
The refrigerant isobutene (R600a) is contained within
the refrigerant circuit of the appliance, a natural gas
with a high level of environmental compatibility, which
is nevertheless flammable. During transportation and
installation of the appliance, ensure that none of the
components of the refrigerant circuit becomes
damaged.
The refrigerant (R600a) is flammable.
WARNING — Refrigerators contain refrigerant and
gases in the insulation. Refrigerant and gases must be
disposed of professionally as they may cause eye
injuries or ignition. Ensure that tubing of the
refrigerant circuit is not damage prior to proper
disposal.
6

WARNING: risk of fire
If the refrigerant circuit should be damaged:
Avoid opening flames and sources of ignition.
Thoroughly ventilate the room in which the appliance
is situated.
It is dangerous to alter the specifications or modify this
product in any way.
Any damage to the cord may cause a short circuit,
fire, and/or electric shock.
Electrical safety
The power cord must not be lengthened.
Make sure that the power plug is not crushed or
damaged. A crushed or damaged power plug may
overheat and cause a fire.
Make sure that you can access the main plug of the
appliance.
Do not pull the main cable.
If the power plug socket is loose, do not insert the
power plug. There is a risk of electric shock or fire.
You must not operate the appliance without the
interior lighting lamp cover.
The fridge is only applied with power supply of single
phase alternating current of 220~240V/50Hz. If
fluctuation of voltage in the district of user is so large
that the voltage exceeds the above scope, for safety
sake, be sure to apply A.C. Automatic voltage
regulator of more than 350W to the fridge. The fridge
must employ a special power socket instead of
common one with other electric appliances. Its plug
must match the socket with ground wire.
7

Daily use
Do not store flammable gass or liquids in the
appliance,There is a risk of an explosion.
Do not operate any electrical appliances in the
appliance (e.g.electric ice cream makers,mixers etc.).
When unplugging always pull the plug from the mains
socket,do not pull on the cable.
Do not place hot items near the plastic components
of this appliance.
Do not place food products directly against the air
outlet on the rear wall.
Store pre-packed frozen food in accordance with the
frozen food manufacture’s instructions.
The appliances manufactures storage
recommendations should be strictly adhered to.Refer
to relevant instructions for storage.
Do not place carbonated or fizzy drinks in the freeze
compartment as it creates pressure on the
container,which may cause it to explode,resulting in
damage to the appliance.
Frozen food can cause frost burns if consumed
straight from the freezer compartment.
Do not place the appliance in direct sunlight.
Keep buring candles,lamps and other items with
naked flames away from the appliance so that do not
set the appliance on fire.
The appliance is intended for keeping food stuff and/
or beverages in normal household as explained in this
instruction booklet The appliance is heavy.Care
should be taken when moving it.
8

9
Do not remove nor touch items from the freezer
compartment if your hands are damp/wet,as this
could cause skin abrasions or frost/freezer burns.
Never use the base,drawers, doors etc. to stand on or
as supports.
Frozen food must not be refrozen once it has been
thawed out.
Do not consume ice popsicles or ice cubes straight
from the freezer as this can cause freezer burn to the
mouth and lips.
To avoid items falling and causing injury or damage to
the appliance, do not overload the door racks or put
too much food in the crisper drawers.
Caution!
Care and cleaning
Before maintenance, switch off the appliance and
disconnect the mains plug from the mains socket.
Do not clean the appliance with metal objects, steam
cleaner, ethereal oils, organic solvents or abrasive
cleansers.
Do not use sharp objects to remove frost from the
appliance. Use a plastic scraper.
Installation Important!
For electrical connection carefully, follow the
instructions given in this manual.
Unpack the appliance and check if there are
damages on it. Do not connect the appliance if it is
damaged. Report possible damages immediately to
the place you bought it. In this case retain packing.
This refrigerating appliance is not intended to be used as a
built-in appliance .

10
in the compressor.
Adequate air circulation should be around the
appliance,lacking this leads to overheating.To
achieve sufficient ventilation, follow the instructions
relevant to installation.
Wherever possible the back of the product should not
be too close to a wall to avoid touching or catching
warm parts (compressor,condenser) to prevent the
risk of a fire, follow the instructions relevant to
installation.
The appliance must not be locate close to radiators
or cookers.
Make sure that the mains plug is accessible after the
installation of the appliance
Service
Any electrical work required to do the servicing of the
appliance should be carried out by qualified
electrician or competent person.
This product must be serviced by an authorized
Service Center, and only genuine spare parts must be
used.
1. If the appliance is Frost Free.
2.If the appliance contains freezer compartment.
It is advisable to wait at least four hours before
connecting the appliance to allow the oil to flow back

11
To avoid contamination of food, please respect the
following instructions
Opening the door for long periods can cause a significant
increase of the temperature in the compartments of the
appliance.
Clean regularly surfaces that can come in contact with food
and accessible drainage systems.
Store raw meat and fish in suitable containers in the
refrigerator, so that it is not in contact with or drip onto other
food.
Two-star frozen-food compartments are suitable for storing
pre-frozen food, storing or making icecream and making ice
cubes.
One-, two- and three-star compartments are not suitable for
the freezing of fresh food.

2000mm
C
100mm
100mm
mm
50-70mm
956mm
1132mm
971mm
956mm
982mm
Brief introduction
Installing your new appliance
Ventilation of appliance
In order to improve efficiency of the
cooling system and save energy, it is
necessary to maintain good ventilation
around the appliance for the
dissipation of heat. For this reason,
sufficient clear space should be
available around the refrigerator.
Suggest:
It is advisable for there to be 50-70mm of
space from the back to the wall, at least
100mm from its top, at least 100mm from
its side to the wall and a clear space in
front to allow the doors to open 130°. As
shown in follow diagrams.
Before using the appliance for the first
time,you should be informed of the
following tips.
Warning!
For proper installation,this refrigerator
must be placed on a level surface of
hard material that is the same height as
the rest of the flooring.This surface
should be strong enough to support a
fully loaded refrigerator.
The rollers,which are not castors,should
be only used for forward or backward
movement. Moving the refrigerator
sideways may damage your floor and
the rollers.
Note:
100
950mm
12

Stand your appliance in a dry place to
avoid high moisture.
Keep the appliance out of direct sunlight
,
rain or frost. Stand the appliance away
from heat sources such as stoves, fires or
heaters.
Adjustable bottom feet
10-15mm
AC
A
A
B
C
Adjustable bottom
feet
Front roller
Rear roller B
Leveling of appliance
For sufficient leveling and air circulating
in the lower rear section of the
appliance, the bottom feet may need to
be adjusted.You can adjust them
manually by hand or by using a suitable
spanner.
To allow the doors to self-close, tilt the
top backwards by 10-15mm.
1. The freezer compartment is provided
with an upper drawer, a lower drawer ,
two trays and an ice box;
2. Open the freezer door; Pull up the
ad usting block (A) of the slide guides,
and pull out the freezer door drawer (A)
to the final position.
1. The freezer compartment is provided
with an upper drawer, a lower drawer ,
two trays and an ice box;
2. Open the freezer door; Pull up the
ad usting block (A) of the slide guides,
and pull out the freezer door drawer (A)
to the final position.
Disassembling the freezer drawer
Disassembling the freezer drawer
3. Take out the tray (B) by lifting it up in the
direction of the arrow.
4. Remove the lower freezer drawer (C) by
lifting it up.
13

Installing the lower drawer
1. Push down the lower drawer to the
final position in the direction of the
arrow.
2. Put the tray on the drawer and
push it award and ensure the
tray’s rollers on the freezer liner
(D ’s fillets.
●
14
Re-assembling the freezer drawer
To reattach the drawer after you moved the
appliance to its final location, assemble the
parts in reverse order.
3. Push the freezer door along the arrow and close it.

1
9
15
Fridge
Freezer
Fridge Gasket
R1-room Door
Control Panel
Up Rack
Middle Rack
Glass shelf
Wind Chanel
R2-room Door
2
1
3
5
4
6
7
8
9
Flexible wine rack(optional)
10
1111
12
1111
12
13
14
Cool Fresh Box cover
Cool Fresh Box
Crisper cover
Fruit & Vegetable Crisper
F1-room Door
Freezer Upper Dawer
Tray Part
9
15
16
17
18
19
20
21
21
20
18
19
F2-room Door
Freezer Lower Drawer
Tray Part
Ice Box
22
22
22 Adjustable bottom
feet
1
2
3
4
5
6
7
8
9
10
1111 11111111
12
16
17
13
14
15
22
N
Note: To get the best energy efficiency of this product, please place all shelves, drawers on
their original position as the illustration above.
ote: Your model may look different from this and other images in this manual,
depending on your model’s features.
Rotary Separator

16
Fridge
Freezer
Up Rack
Middle Rack Part
Fridge Gasket
Middle Rack
Control Panel
Wind Chanel
Glass shelf
2
1
3
5
4
Water storage box part
6
Flexible wine rack(optional)
1
9
10
1111
12
1111
12
13
14
9
15
16
17
18
19
20
21
22
R2-room Door
Cool Fresh Box
Crisper cover
Fruit & Vegetable Crisper
F1-room Door
Tray Part
18
22
11111111
12
16
17
13
14
15
22
Cool Fresh Box cover
9
19
20
21
23
F2-room Door
Freezer Lower Drawer
Tray Part
Ice Box
Adjustable bottom
feet
Freezer Upper Dawer
23
23
N
Note: To get the best energy efficiency of this product, please place all shelves, drawers on
their original position as the illustration above.
ote: Your model may look different from this and other images in this manual,
depending on your model’s features.
7
8
9
Rotary Separator

Brief introduction
Control panel
Use your appliance according to the following control regulations, your appliance has the
corresponding functions and modes as the display panels showed in the pictures below.
When the appliance is powered on for the first time, the backlighting of the icons on display
panel starts working. If no buttons have been pressed and the doors are closed, the
backlighting will turn off.
Power Icon
A
Power Control
B
Fridge Compartment
Temp Icon
C
Freezer Compartment
Temp Icon
D
Zone Choice
E
Celsius Indicator
F
Temperature
G
Temp Control
H
ISuper Cool Icon
Holiday Icon
J
Super Freeze Icon
K
Mode Control
L
Press POWER 3 seconds to turn the power
on, and press 3 seconds to turn the power
off and will display “OF”.
When you set a temperature, you are
setting an average temperature for the
entire compartment. The actual
compartment temperatures may vary from
the temperatures displayed depending on
the amount and placement of stored food,
and the surrounding room temperature.
1.Press ZONE repeatedly until the Fridge
icon appears.
1.Press ZONE repeatedly until the Freezer
Choice appears.
2.When Freezer is on, is illuminated and
then press TEMP. repeatedly to cycle
through the available temperature settings,
from -14°C to -24°C.
NOTE: Each press of the button advances
the setting by one degree.
The Super Cool feature helps to keep food
stored in the refrigerator at the set
temperature during periods of high usage,
large grocery loads, or temporarily warm
room temperatures.The Super Cool feature
lowers the temperature in the fridge
compartment to 2°C to cool food faster.
3.Release the TEMP. Control when the
desired temperature setting appears.
3.Release the TEMP. Control when the
desired temperature setting appears.
2. When Fridge is on, is illuminated and
then press TEMP. repeatedly to cycle
through the available temperature settings,
from 8°C to 2°C.
NOTE: Each press of the button advances
the setting by one degree.
Recommended Temperature Settings
Freezer Compartment Temperature
Refrigerator (Fridge) Compartment
Temperature
Setting Compartment Temperatures
• Fridge Compartment: 4°C
• Freezer Compartment: -18°C
8°C 7°C 6°C 5°C
4°C3°C2°C
-24°C -23°C
-14°C -15°C .........
Super Cool
1. Press MODE repeatedly until the Super
Cool icon appears.
NOTE: When Super Cool is on, is
illuminated and 2°C appears in the
temperature display.
2. Press MODE to manually turn off Super
Cool and return to the previously set
temperature.
17

Door Open Alarm
If the fridge door is opened for longer than
2 minutes, the control panel will display “dr”,
and it will return to the previous set
temperature after 8 minutes.
• To turn off the alarm, close the fridge door
completely.
18
NOTE: Super Cool will automatically turn off
after 3 hours, and the refrigerator will revert
to its previous temperature setting.
If leaving the appliance for a long period of
time, you can switch the appliance over to
the holiday mode.
Important!
Do not store any food in the fridge
compartment during this time.
1.Press MODE until the Holiday icon appears.
The appliance automatically sets the
following temperatures:
2. Press TEMP. to turn off Holiday mode and
the refrigerator temperature will revert to its
previous temperature setting.
• Fridge compartment: 15 °C
• Freezer compartment: -18°C
Holiday
The Super Freeze feature helps to keep the
food stored in the freezer at the set
temperature during periods of high usage,
large grocery loads, or temporarily warm
room temperatures.
The Super Freeze feature lowers the
temperature in the freezer compartment to
-24°C to freeze food faster.
1.Press MODE repeatedly until the Super
Freeze icon appears.
2. Press TEMP. to manually turn off Super
Freeze and return to the previously set
temperature.
When selecting the Super Freeze function.
ensure there are no bottled in the freezer
compartment. Bottles and cans may
explode.
Super Freeze
NOTE: When Super Freeze is on, is
illuminated and -24°C appears in the
temperature display.
NOTE: Super Freeze will automatically turn
off after 52 hours, and the freezer will revert
to its previous temperature setting. NOTE: High temperature setting will
accelerate food waste.

Brief introduction
Using your appliance
Your appliance has the accessories as
the“Description of the appliance”showed
in general, with this part instruction you
can have the right way to use them.. We
recommend that you read through
them carefully before using the
appliance.
Door rack
It is suitable for the storage of eggs,
canned liquid,bottled drinks and
packed food, etc. Do not place too
many heavy things in the racks.
The door racks can be placed at different
heights according to your requirements.
Please take food out of the shelf before
lifting vertically to reposition.
Shelf in Refrigerator chamber
The shelves in refrigerator chamber can
be taken out to be cleaned.
All the door racks are completely
removable for cleaning.
Flexible wine rack(optional)
It is for storing bottled wine or drinks, and it
In certain mode, there will be an extra fresh
box(drawer). In this drawer you can get a
lower temperature to store fish, meat and
other erodible food.
Normally it will be about 1°C lower than the
other part of the fresh compartment. There
are some commendations in the below
table which you can consult.
can be taken out to clean.
Cool fresh box
Fruit & Vegetable crisper
Crisper and Humidity control
The crisper is suitable for storage of
vegetables and fruit, etc.
You can rotate the knob on the crisper
cover to keep different humidity in the
crisper. Push the knob to the left, you will
keep a higher humidity which can storage
vegetable and fruit long and fresh, to the
right will be lower humidity. It is for
controlling the temperature of the crisper
and avoiding the vegetable losing moisture.
Freezer drawer
It is used to store food which need to be
frozen, including meat, fish and ice cream,
etc.
Note:The actual temperature of Cool fresh
box may lower than zero, so it is normal
that liquid in this drawer was frozen.
Note:Do not place the bottled wine or
drinks directly in front of the air outlet on the
wind channel, which may cause it to freeze.
1
9
temp. setting of
fridge compartment type of food suggested storage
period
5 or 6°C
7 or 8°C
2 or 3 or 4°Cfish or meat
≤2days
＜2weeks
<5days
fruit
vegetables
compartment.

Water Dispenser(only for appliance with
dispenser)
The water dispenser, located in the fridge
door, is for storing drinking water. With this
appliance you can obtain chilled water
easily without opening the refrigerator. You
should review of following tips.
dispenser Pad
,
Caution!
Drain the water tank before you take it down
then put on the middle rack well .
guide
guide
Before using
Before using this appliance for the first time,
you should use it as follows.
1.Hold one bottom side of the door rack by
a hand, lift up the opposite side by the other
hand, when the slot of the door rack is off
from the guide, change hands to repeat
these steps.
2.Hold one bottom side of the water tank
by a hand, lift up the opposite side by the
other hand, when the slot of the water tank
is off from the guide, change hands to
repeat these steps.
3.Hold the two side of the water tank
tightly, lift up and put out of the water tank.
4.Unsrew the head, then clean head, lids
and the water tank.
head
①②
③
④
①
seal ring
② ③
④
20
