Hisense RB291D4CWF Mounting instructions

RB291D4CWF
RB291D4CDF

●
2
Safety and warning information_ _ _ _ _ 2
Description of the appliance _ _ _ _ _ _
Operation_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Helpful hints and tips _ _ _ _ _ _ _ _ _ _
Cleaning and care _ _ _ _ _ _ _ _ _ _ _
Installing your new appliance_ _ _ _ _ _
Reversing the door _ _ _ _ _ _ _ _ _ _ _
12
13
15
8
9
Troubleshooting_ _ _ _ _ _ _ _ _ _ _ _ _
Disposal of the appliance_ _ _ _ _ _ _ _
16
18
19
Using your appliance _ _ _ _ _ _ _ _ _ _14
Children aged from 3 to 8 years are allowed to load and
unload refrigerating appliances.
For your safety and correct usage, before installing and first
using the appliance, read this user manual carefully, including
its hints and warnings. To avoid unnecessary mistakes and
accidents, it is important to make sure that all people using the
appliance are thoroughly familiar with its
operation and safety features. Save these instructions and be
sure that they remain with the appliance if it is moved or sold,
so that anyone using it throughout its life, will be properly
informed on its usage and safety notices.
For the safety of life and property, keep the precautions of
these user's instructions as the manufacturer is not
responsible for damages caused by omission.
Hisense Refrigerator
Safety for children and other swho are vulnerable people
According to EN standard
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
According to IEC standard
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning

3
Children should be supervised to ensure that they do not
play with the appliance.
Hisense Refrigerator
Keep all packaging away from children as there is risk of
suffocation.
If you are discarding the appliance, pull the plug out of the
socket, cut the connection cable (as close to the appliance
as you can) and remove the door to prevent children playing
from suffering an electric shock or from closing themselves
inside it.
If this appliance, featuring a magnetic door seals, is to
replace an older appliance having a spring lock (latch) on the
door or lid, be sure to make the spring lock unusable before
you discard the old appliance. This will prevent it from
becoming a death trap for a child.
General safety
WARNING —This appliance is intended to be used in
household and similar applications such as
-staff kitchen areas in shops, offices and other working
environments;
-farm houses and by clients in hotels, motels and other
residential type environments;
-bed and breakfast type environments;
-catering and similar non-retail applications.
WARNING — Do not store explosive substances such as
aerosol cans with a flammable propellant in this appliance.
WARNING — If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
WARNING — Keep ventilation opening, in the appliance
enclosure or in the built-in structure, clear of obstruction.
WARNING — Do not use mechanical devices or other
means to accelerate the defrosting process, other than those
recommended by the manufacturer.
WARNING — Do not damage the refrigerant circuit.
WARNING — Do not use electrical appliances inside the
food storage compartments of the appliance, unless they are
of the type recommended by the manufacturer.
use of the appliance by a person responsible for their safety.

4
WARNING ―Food needs to be packed in bags before
putting into the refrigerator, and liquids need to be packed
in bottles or capped containers to avoid the problem that
the product design structure is not easy to clean.
The symbol is a warning and indicates the
refrigerant and insulation blowing gas are flammable.
Warning: Risk of fire / flammable materials
Hisense Refrigerator
WARNING — The refrigerant and insulation blowing gas are
flammable. When disposing of the appliance, do so only at
an authorized waste disposal centre. Do not expose to
flame.
WARNING —When positioning the appliance, ensure the
supply cord is not trapped or damaged.
WARNING —Do not locate multiple portable socket-outlets
or portable power supplies at the rear of the appliance.
Refrigerant
The refrigerant isobutene (R600a) is contained within the
refrigerant circuit of the appliance, a natural gas with a high
level of environmental compatibility, which is nevertheless
flammable. During transportation and installation of the
appliance, ensure that none of the components of the
refrigerant circuit becomes damaged.
The refrigerant (R600a) is flammable.
If the refrigerant circuit should be damaged:
WARNING — Refrigerators contain refrigerant and gases in
the insulation. Refrigerant and gases must be disposed of
professionally as they may cause eye injuries or ignition.
Ensure that tubing of the refrigerant circuit is not damage
prior to proper disposal.
Replacing the illuminating lamps
WARNING—The illuminating lamps must not be replaced by
the user! If the illuminating lamps is damaged, contact the
customer helpline for assistance.
This warning is only for refrigerators that contain illuminating
lamps.

5
Hisense Refrigerator
Daily use
Do not store flammable gases or liquids in the appliance,
There is a risk of an explosion.
Do not operate any electrical appliances in the appliance
(e.g.electric ice cream makers,mixers etc.).
When unplugging always pull the plug from the mains
socket,do not pull on the cable.
Do not place hot items near the plastic components of this
appliance.
Electrical safety
1.The power cord must not be lengthened.
2. Make sure that the power plug is not crushed or damaged.
A crushed or damaged power plug may overheat and cause a
fire.
3. Make sure that you can access the main plug of the
appliance.
4. Do not pull the main cable.
5. If the power plug socket is loose, do not insert the power
plug. There is a risk of electric shock or fire.
6.You must not operate the appliance without the interior
lighting lamp cover.
7.The fridge is only applied with power supply of single phase
alternating current of 220~240V/50Hz. If fluctuation of voltage
in the district of user is so large that the voltage exceeds the
above scope, for safety sake, be sure to apply A.C. automatic
voltage regulator of more than 350W to the fridge. The fridge
must employ a special power socket instead of common one
with other electric appliances. Its plug must match the socket
with ground wire.
It is dangerous to alter the specifications or modify this
product in any way.
Any damage to the cord may cause a short circuit, fire, and/or
electric shock.
-Avoid opening flames and sources of ignition.
-Thoroughly ventilate the room in which the appliance is
situated.

●This refrigerating appliance is not intended to be used as
a built-in appliance.
6
Hisense Refrigerator
Do not place food products directly against the air outlet on
the rear wall.
Store pre-packed frozen food in accordance with the frozen
food manufacture’s instructions.
The appliances manufactures storage recommendations
should be strictly adhered to relevant instructions for
storage.
Do not place carbonated or fizzy drinks in the freeze
compartment as it creates pressure on the container,which
may cause it to explode,resulting in damage to the
appliance.
Frozen food can cause frost burns if consumed straight from
the freezer compartment.
Do not place the appliance in direct sunlight.
Keep buring candles,lamps and other items with naked
flames away from the appliance so that do not set the
appliance on fire.
The appliance is intended for keeping food stuff and/or
beverages in normal household as explained in this
instruction booklet, The appliance is heavy.Care should be
taken when moving it.
Do not remove nor touch items from the freezer
compartment if your hands are damp/wet,as this could cause
skin abrasions or frost/freezer burns.
Never use the base,drawers, doors etc. to stand on or as
supports.
Frozen food must not be refrozen once it has been thawed
out.
Do not consume ice popsicles or ice cubes straight from
the freezer as this can cause freezer burn to the mouth
and lips.
To avoid items falling and causing injury or damage to
the appliance, do not overload the door racks or put too
much food in the crisper drawers.

Hisense Refrigerator
Adequate air circulation should be around the appliance,
lacking this leads to overheating. To achieve sufficient
ventilation, follow the instructions relevant to installation.
Wherever possible, the back of the product should not be too
close to a wall to avoid touching or catching warm parts
(compressor, condenser) to prevent the risk of a fire, follow
the instructions relevant to installation.
The appliance must not be located close to radiators or
cookers.
Make sure that the mains plug is accessible after the
installation of the appliance.
Service
Any electrical work required to do the servicing of the
appliance should be carried out by qualified electrician or
competent person.
This product must be serviced by an authorized Service
Center, and only genuine spare parts must be used.
1)If the appliance is Frost Free.
2)If the appliance contains freezer compartment.
Installation Important!
For electrical connection carefully, follow the instructions
given in this manual.
Unpack the appliance and check if there are damages on it.
Do not connect the appliance if it is damaged. Report
possible damages immediately to the place you bought it. In
this case retain packing.
It is advisable to wait at least four hours before connecting
the appliance to allow the oil to flow back in the compressor.
Before maintenance, switch off the appliance and disconnect
the mains plug from the mains socket.
Do not clean the appliance with metal objects, steam
cleaner, ethereal oils, organic solvents or abrasive cleansers.
Do not use sharp objects to remove frost from the appliance.
Use a plastic scraper.
7
Caution!
Care and cleaning

In order to improve
efficiency of the cooling system and
save energy, it is necessary to maintain
good ventilation around the appliance. For
this reason, sufficient clear space should
be available around the refrigerator.
It is advisable for there to be 50-70mm of
space from the back to the wall, at least
100mm from its top,at last 100mm from its
side to the wall and a clear space in front
to allow the doors to open 135°. Please
see the following diagrams.
Installing your new appliance
Ventilation of appliance
Before using the appliance for the first
time, you should review the following tips.
Note:
This appliance performs well within the
climate class from N to STshowed in the
table below.
It may not work properly if left at a
temperature above or below the indicated
range for a long period.
●
Climate class Ambient temperature
SN
N
ST
T
+10°C to +32°C
+16°C to +32°C
+16°C to +38°C
+16°C to +43°C
Stand your appliance in a dry place to
avoid moisture damage.
Keep the appliance out of direct sunlight,
rain or frost. Stand the appliance away
from heat sources such as stoves, fires or
heaters.
●
●
●For sufficient leveling and air circulating in
the lower rear section of the appliance,
the bottom feet may need to be adjusted.
You can adjust them manually using a
suitable spanner.
To allow the doors to self-close, tilt the top
backwards by about 10mm.
Leveling of appliance
●
≤10mm
100
100
607～627
1120～114 0
938
135。
50～70
100
100
8
Hisense Refrigerator

The side at which the door opens can be
changed, from the right side (as supplied)
to the left side, if trequired.
Warning! When reversing the door, the
appliance must not be connected to the
mains. Ensure that the plug is removed
from the mains socket.
Tools you will need
Left Hinge Cover
8mm wrench
8mm socket wrench
Monkey wrench
Thin-blade
screwdriver
Cross-shaped
screwdriver
2. Use a putty knife or thin-blade
screwdriver to prize the screw hole cover
which is at the top left corner of the
refrigerator, and the upper hinge cover
which is at the top right corner of the
refrigerator.
Reversing the door
Note: If required, you may lay the
refrigerator on its back in order to gain
access to the base, you should rest it
on soft foam packaging or similar
material to avoid damaging the
backboard of the refrigerator. To reverse
the door, the following steps are
generally recommended.
1. Stand the refrigerator upright. Open
the upper door to take out all door
racks (to avoid damage) and then close
the door.
Putty knife
3. Unscrew the special flange self-tapping
screws which are used for fixing the right
upper hinge part by a 8mm socket driver
or a spanner (please support the upper
door with your hand when doing it) .
right upper hinge part
special flange
selftapping screws
4.Remove the upper hinge axis, transfer it
to reversed side and tighten securely, then
put it in a safe place.
① ② ③
5. Remove the upper door from the
middle hinge by carefully lifting the door
straight up.
NOTE: When removing the door, watch
for washer(s) between the center hinge
and the bottom of the freezer door that
may stick to the door. Do not lose.
Reversing the door
upper hinge
cover (right)
screw hole cover
Door racks
Hisense Refrigerator
9

①
① Lower hinge part (right)
② Front feet fixed board
②
④
④ Self-tapping screws
③
③ Adjustable bottom feet part
6. Place the upper door on a smooth
surface with its panel upwards. Loose
screw ② and part ①, then Install
them to the left side and tighten securely.
7. Unscrew the two special flange self-
tapping screws which are used for fixing
the middle hinge part, then remove the
middle hinge part that hold the lower door
in place.
NOTE: When removing the door, watch
for washer(s) between the center hinge
and the bottom of the freezer door that
may stick to the door. Don’t lose it.
8. Place the lower door on a smooth
surface with its panel upwards. Loose
screw ② and part ①, then Install
them to the left side and tighten securely.
9. Change screw hole covers on middle
cover plate from left to right (as shown in
figure below).
screw hole covers
screw hole covers
10. Lay the refrigerator on soft foam
packaging or similar material. Remove
both adjustable bottom feet parts, and
remove the front feet board and the lower
hinge part by unscrewing the special
flange self-tapping screws.
① Stop block
①
②
②
Self-tapping screw
① Stop block
② Self-tapping screw
①
②
Hisense Refrigerator
10
