Hisense RF702N4IS1 Mounting instructions

RF702N4 I S1
RF715N4AS1

2
Contents
Safety and warning information2
Installing your new appliance 8
Description of the appliance14
Display controls16
Using your appliance 18
Cleaning and care21
Helpful hints and tips22
Troubleshooting23
Disposal of the appliance25
Safety and warning information
For your safety and correct usage, before installing and first
using the appliance, read this user manual carefully, including
its hints and warnings. To avoid unnecessary mistakes and
accidents, it is important to make sure that all people using the
appliance are thoroughly familiar with its operation and safety
features. Save these instructions and be sure that they remain
with the appliance if it is moved or sold, so that anyone using it
throughout its life, will be properly informed on its usage and
safety notices.
For the safety of life and property, keep the precautions of
these user's instructions as the manufacturer is not
responsible for damages caused by omission.
Safety for children and others who are ulnerable people
According to EN standard
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children
without supervision.
According to IEC standard
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the
appliance by a person responsible for their safety.

3
Keep all packaging away from children as there is risk of
suffocation.
If you are discarding the appliance, pull the plug out of the
socket, cut the connection cable (as close to the appliance as
you can) and remove the door to prevent children playing
from suffering an electric shock or from closing themselves
inside it.
If this appliance, featuring a magnetic door seals, is to replace
an older appliance having a spring lock (latch) on the door or
lid, be sure to make the spring lock unusable before you
discard the old appliance. This will prevent it from becoming a
death trap for a child.
General safety
WARNING —This appliance is intended to be used in
household and similar applications such as
-staff kitchen areas in shops, offices and other working
environments;
-farm houses and by clients in hotels, motels and other
residential type environments;
-bed and breakfast type environments;
-catering and similar non-retail applications.
WARNING —Connect to potable water supply only.
WARNING — Do not store explosive substances such as
aerosol cans with a flammable propellant in this appliance.
WARNING — If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
WARNING — Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
WARNING — Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
WARNING — Do not damage the refrigerant circuit.
WARNING — Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are of the

4
type recommended by the manufacturer.
WARNING — The refrigerant and insulation blowing gas are
flammable. When disposing of the appliance, do so only at an
authorized waste disposal centre. Do not expose to flame.
WARNING —When positioning the appliance, ensure the
supply cord is not trapped or damaged.
WARNING —Do not locate multiple portable socket-outlets
Replacing the LED
WARNING—The LED light must not be replaced by the user!
If the LED light is damaged, contact the customer helpline for
assistance.
Refrigerant
The refrigerant isobutene (R6 a) is contained within the
refrigerant circuit of the appliance, a natural gas with a high
level of environmental compatibility, which is nevertheless
flammable. During transportation and installation of the
appliance, ensure that none of the components of the
refrigerant circuit becomes damaged.
The refrigerant (R6 a) is flammable.
WARNING — Refrigerators contain refrigerant and gases in
the insulation. Refrigerant and gases must be disposed of
professionally as they may cause eye injuries or ignition.
Ensure that tubing of the refrigerant circuit is not damage prior
to proper disposal.
Caution: risk of fire /flammable materials
If the refrigerant circuit should be damaged:
-Avoid opening flames and sources of ignition.
-Thoroughly ventilate the room in which the appliance is
situated.

5
It is dangerous to alter the specifications or modify this product
in any way.
Any damage to the cord may cause a shortcircuit, fire, and/or
electric shock.
Electrical safety
1. The power cord must not be lengthened.
2. Make sure that the power plug is not crushed or damaged. A
crushed or damaged power plug may overheat and cause a
fire.
3. Make sure that you can access the main plug of the
appliance.
4. Do not pull the main cable.
5. If the power plug socket is loose, do not insert the power
plug. There is a risk of electric shock or fire.
6. You must not operate the appliance without the interior
lighting lamp cover.
7. The fridge is only applied with power supply of single phase
alternating current of 22 ~24 V/5 Hz. If fluctuation of voltage
in the district of user is so large that the voltage exceeds the
above scope, for safety sake, be sure to apply A.C. Automatic
voltage regulator of more than 35 W to the fridge. The fridge
must employ a special power socket instead of common one
with other electric appliances. Its plug must match the socket
with ground wire.
Daily use
Do not store flammable gass or liquids in the appliance.
There is a risk of an explosion.
Do not operate any electrical appliances in the appliance
(e.g.electric ice cream makers, mixers etc.).
When unplugging always pull the plug from the mains socket,
do not pull on the cable.
Do not place hot items near the plastic components of this
appliance.

6
Do not place food products directly against the air outlet on
the rear wall.
Store pre-packed frozen food in accordance with the frozen
food manufacture’s instructions.
The appliances manufactures storage recommendations
should be strictly adhered to. Refer to relrelevant instructions
for storage.
Do not place carbonated or fizzy drinks in the freeze
compartment as it creates pressure on the container, which
may cause it to explode, resulting in damage to the appliance.
Frozen food can cause frost burns if consumed straight from
the freezer compartment.
Do not place the appliance in direct sunlight.
Keep buring candles, lamps and other items with naked
flames away from the appliance so that do not set the
appliance on fire.
The appliance is intended for keeping food stuff and/or
beverages in normal household as explained in this
instruction booklet The appliance is heavy. Care should be
taken when moving it.
Do not remove nor touch items from the freezer compartment
if your hands are damp/wet, as this could cause skin
abrasions or frost/freezer burns.
Never use the base, drawers, doors etc. to stand on or as
supports.
Frozen food must not be refrozen once it has been thawed
out.
Do not consume ice popsicles or ice cubes straight from the
freezer as this can cause freezer burn to the mouth
and lips.
To avoid items falling and causing injury or damage to the
appliance, do not overload the door racks or put too much
food in the crisper drawers.
caution!
Care and cleaning
This refrigerating appliance is not intended to be
used as a built-in appliance.


7
Before maintenance, switch off the appliance and disconnect
the mains plug from the mains socket.
Do not clean the appliance with metal objects, steam cleaner,
ethereal oils, organic solvents or abrasive cleansers.
Do not use sharp objects to remove frost from the appliance.
Use a plastic scraper.
Installation Important!
For electrical connection carefully, follow the instructions
given in this manual.
Unpack the appliance and check if there are damages on it.
Do not connect the appliance if it is damaged. Report possible
damages immediately to the place you bought it. In this case
retain packing.
It is advisable to wait at least four hours before connecting the
appliance to allow the oil to flow back in the compressor.
Adequate air circulation should be around the appliance,
lacking this leads to overheating. To achieve sufficient
ventilation, follow the instructions relevant to installation.
Wherever possible the back of the product should not be too
close to a wall to avoid touching or catching warm parts
(compressor, condenser) to prevent the risk of a fire, follow
the instructions relevant to installation.
The appliance must not be located close to radiators or
cookers.
Make sure that the mains plug is accessible after the
installation of the appliance.
Ser ice
Any electrical work required to do the servicing of the
appliance should be carried out by qualified electrician or
competent person.
This product must be serviced by an authorized Service
Center, and only genuine spare parts must be used.
1) If the appliance is Frost Free.
2) If the appliance contains freezer compartment

8
Installing your new appliance
Before using the appliance for the first
time, you should be informed of the
following tips.
Warning!
For proper installation, this refrigerator
must be placed on a level surface of hard
material that is the same height as the rest
of the flooring. This surface should be
strong enough to support a fully loaded
refrigerator.
The rollers, which are not castors, should
be only used for forward or backward
movement. Moving the refrigerator
sideways may damage your floor and the
rollers.
Ventilation of appliance
Install the appliance in a plane
and stable surface. Assure
good ventilation.
We recommend letting a space at least:
- 5 -7 mm from the back to the wall
- 1 mm from the top to the wall
- 1 mm from its side to the wall
Enough space must be provided in the
front of the appliance to allow the doors to
open as shown in follow diagrams.
Note:

Climate class Ambient temperature
SN +1 °C to +32°C
N +16°C to +32°C
ST +16°C to +38°C
T +16°C to +43°C
 Stand your appliance in a dry place to
avoid high moisture.
 Keep the appliance out of direct sunlight,
rain or frost. Stand the appliance away
from heat sources such as stoves, fires or
heaters.
Le eling of appliance
For sufficient leveling and air circulating
in the lower rear section of the appliance,
This appliance performs well from N to ST.
The appliance may not work properly if it is left for
a longer period at a temperature above or below
the indicated range.

9
the bottom feet may need to be adjusted.
You can adjust them manually by hand or
by using a suitable spanner.
To allow the doors to self-close, tilt the
top backwards by 1 -15 mm.
Whenever you want to move the
appliance, remember to turn the feet back
up, so that the appliance can roll freely.
Reinstall the appliance when relocating.
Doors remo al
In case when your access door is too
narrow for the refrigerator to pass through,
remove the refrigerator door and drawers.
Then pass the refrigerator laterally. If you
do not need to remove the appliance
doors, go to ‘Installing the water lines’ on
page 11.If you need to remove the doors,
continue below.
Warning!
When reversing the door, the appliance
must be unplugged.
The tools you will need (Not pro ided):
Allen Wrench(4mm)
Wrench(8mm)
Philips screwdriver
Disassembling the fridge door
Some models may be slightly different
from pictures. If some parts shown in the
picture cannot found in your appliance,
please ignore the relevant description.
1. With the door closed, remove the 3
screws holding the top cover (A) with
Philips (+) screwdriver, and then remove
the top cover carefully with the
entire-harnesses unattached.
2.Take out connectors and the water
coupler from the installation clip.
Remove the two wire connectors (press
the top of the connector (B) and separate
it from the other one) on the left side
door .To remove the water coupler from
the hinge, twist and pull the clips from the
coupler then remove the water line (C)
while pressing the movable part (D) of the
water line coupler.

1
3. Remove the 3 screws (B) fixed on the
hinges with a Wrench (8mm) and 1 ground
screws (C) attached to the hinge with
Philips (+) screwdriver. Remove the upper
left and right door hinges (D).
4. Use your both hands to open the door
more than 9 ° . Lift it up and take it off.
（ Be careful of racks while remove the
door. ）
5. Remove the 4 hex head bolts (E) with
an Allen wrench (4 mm). Remove the 2
screws with screwdriver. Then remove the
lower left and right door hinges (F).
Re-attaching the fridge doors
To reattach the fridge doors after you have
moved the appliance to its final location,
assemble the parts in reverse order.
1. To prevent water leaks, the water line
should be fully inserted into the center of
the coupler until the guide lines are
coincided exactly with the head of the
movable part.
Note ：
：：
：
Arrow on the water line coupler point to
the direction of the door.
2. Make sure the clips are properly
connected to the coupler.
Caution!
In case the fridge doors can’t be
self-closed, please make sure the door
opened more than 9 ° when you remove
or re-attaching the fridge doors.
Disassembling the freezer door
1. Pull out the freezer door and the upper
freezer drawer (A) to the final position.
Then take out the ice box (B) by lifting it up
in the direction of the arrow.
