Hisense RL462N4WC1 Mounting instructions

Contents
Hisense Refrigerator
2
Safety and warning information.......................….2
Installing your new appliance………....................7
Description of the appliance……................…….11
Display controls…………………….....................12
Using your appliance………………................…14
Helpful hints and tips………………................... 16
Cleaning and care……………….....................…17
Troubleshooting…………………….................…18
Important safety instructions………...........……20
Safety for children and others
who are vulnerable people
For your safety and correct
usage, before installing and
first using the appliance,
read this user manual
carefully, including its hints
and warnings. To avoid
unnecessary mistakes and
accidents, it is important to
make sure that all people
using the appliance are
thoroughly familiar with its
operation and safety
features. Save these
instructions and be sure that
they remain with the
appliance if it is moved or
sold,
For the safety of life and
property, keep the
precautions of these user's
so that anyone using it
throughout its life, will be
properly informed on its
usage and safety notices.
instructions as the
manufacturer is not
responsible for damages
caused by omission.
This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or
mental capabilities or lack
of experience and
knowledge if they have
been given supervision or
instruction concerning use
of the appliance in a safe
way and understand the
hazards involved. Children
shall not play with the
appliance. Cleaning and
user maintenance shall
not be made by children
without supervision.
Keep all packaging away
This appliance is in accordance with the following EU guidelines:
and 2004/108/EC and 2009/125/EC and EC.643/2009 and 2002/96/EC
2006/95/EC

Hisense Refrigerator
3
from children as there is
risk of suffocation.
If you are discarding the
appliance, pull the plug out
of the socket, cut the
connection cable (as close
to the appliance as you
can) and remove the door
to prevent children playing
from suffering an electric
shock or from closing
themselves inside it.
If this appliance, featuring
a magnetic door seals, is
to replace an older
appliance having a spring
lock (latch) on the door or
lid, be sure to make the
spring lock unusable
before you discard the old
appliance. This will prevent
it from becoming a death
trap for a child.
General safety
to be used in
and similar applications
such as
household
-staff kitchen areas in
shops, offices and other
working environments;
-farm houses and by
clients in hotels, motels
and other residential type
environments;
-bed and breakfast type
environments;
-catering and similar non-
retail applications
WARNING — Do not store
explosive substances such
as aerosol cans with a
flammable propellant in
this appliance.
WARNING — If the supply
cord is damaged, it must
be replaced by the
manufacturer, its service
agent or similarly qualified
persons in order to avoid a
hazard.
WARNING — Keep
ventilation openings, in the
appliance enclosure or in
the built-in structure, clear
of obstruction.
WARNING — Do not use
mechanical devices or
other means to accelerate
the defrosting process,
other than those
recommended by the
manufacturer.
WARNING — Do not
damage the refrigerant
circuit.
WARNING — Do not use
electrical appliances inside
the food storage
compartments of the
appliance, unless they are
of the type recommended
by the manufacturer.
This
appliance is intended
WARNING —

Electrical safety
WARNING — The
refrigerant and
insulation blowing gas
are flammable. When
disposing of the
appliance, do so only at
an authorized waste
disposal centre. Do not
expose to flame.
WARNING — Fill with
potable water only.
The refrigerant isobutene
(R600a) is contained within
the refrigerant circuit of the
appliance, a natural gas
with a high level of
environmental
compatibility, which is
nevertheless flammable.
During transportation and
installation of the
appliance, ensure that
none of the components of
the refrigerant circuit
becomes damaged.
The refrigerant (R600a) is
flammable.
Refrigerant
specifications or modify
this product in any way.
Any damage to the cord
may cause a shortcircuit,
fire, and/or electric shock.
Caution:risk of fire
If the refrigerant circuit
should be damaged:
-Avoid opening flames and
sources of ignition.
-Thoroughly ventilate the
room in which the
appliance is situated.
It is dangerous to alter the
4
1.
be lengthened.
2. Make sure that the
power plug is not
or damaged. A or
damaged power plug may
overheat and cause a fire.
3. Make sure that you can
plug of
the appliance.
4. Do not pull the main
cable.
5. If the power plug socket
is loose, do not insert the
power plug. There is a risk
of electric shock or fire.
6.You must not operate the
appliance without the
interior lighting lamp cover.
7.The fridge is only applied
with power supply of single
phase alternating current
of 220~240V/50Hz. If
fluctuation of voltage in the
district of user is so large
that the voltage exceeds
the above scope, for safety
sake, be sure to apply A.C.
Automatic voltage
regulator of more than
The power cord must not
crushed
crushed
access the main
Hisense Refrigerator

350W to the fridge. The
fridge must employ a
special power socket
instead of common one
with other electric
appliances. Its plug must
match the socket with
ground wire.
Daily use
Do not store flammable
gass or liquids in the
appliance,There is a risk of
an explosion.
Do not operate any
electrical appliances in the
appliance(e.g.electric ice
cream makers,mixers etc.).
When unplugging always
pull the plug from the
mains socket,do not pull on
the cable.
Do not place hot items
near the plastic
components of this
appliance.
Store pre-packed frozen
food in accordance with
the frozen food
manufacture’s instructions.
The appliances
manufactures storage
recommendations should
be strictly adhered to.Refer
to relrelevant instructions
for storage.
5
Frozen food can cause
frost burns if consumed
straight from the freezer
compartment.
Do not place the appliance
in direct sunlight.
Keep buring candles,lamps
and other items with naked
flames away from the
appliance so that do not
set the appliance on fire.
The appliance is intended
for keeping food stuff
and/or beverages in
normal household as
explained in this instruction
booklet .
The appliance is
heavy.Care should be
taken when moving it.
Do not remove nor touch
items from the freezer
compartment if your hands
are damp/wet,as this could
cause skin abrasions or
frost/freezer burns.
Never use the base,
drawers, doors etc. to
stand on or as supports.
To avoid items falling and
causing injury or damage
to the appliance, do not
overload the door racks or
put too much food in the
crisper drawers.
Hisense Refrigerator

Before using the appliance for the first time, you
should be informed of the following tips.
Ventilation of appliance
In order to improve efficiency of the
cooling system and save energy, it is
necessary to maintain good ventilation
around the appliance for the dissipation of heat.
For this reason, sufficient clear space should be
available around the refrigerator.
Suggest: It is advisable for there to be at least
75mm of space from the back to the wall, at least
100mm from its top, at least 50mm from its side to
the wall and a clear space in front to allow the
doors to open 135°. As shown in follow diagrams.
Note:
This appliance performs well within the climate
class showed in the table below.
It may not work properly if being left at a
temperature above or below the indicated
range for a long period.
Stand your appliance in a dry place to avoid high
moisture.
Keep the appliance out of direct sunlight，rain or
frost. Stand the appliance away from heat sources
such as stoves, fires or heaters.
●
●
Leveling of appliance
For sufficient leveling and air circulating in the
lower rear section of the appliance, the bottom feet
may need to be adjusted. You can adjust them
manually by hand or by using a suitable spanner.
To allow the doors to self-close, tilt the top
backwards by about 10mm.
●
●
≤10mm
Installing the door handles
For the convenience of transportation, the door
handles are separately provided in a plastic bag,
you can install the door handles as follows.
1. Lever screw covers on the left side of the door,
and then put them back to the plastic bag.
2. Match the handle on the left side of the door,
keeping axes of screw holes in the handle and the
door in a line, as the picture shows.
3. Fix the handle with the special screws provided
in the plastic bag.
Hisense Refrigerator
Installing your new appliance
7
≥ 100mm
1855mm
≥ 75mm
≥ 50mm ≥ 50mm
712mm
1220mm
1025mm
Climate class Ambient temperature
SN
N
ST
T
+10°C to +32°C
+16°C to +32°C
+16°C to +38°C
+16°C to +43°C
12

Hisense Refrigerator
8
Reversing the door
The side at which the door opens can be changed,
from the right side (as supplied) to the left side, if
the installation site requires.
Warning! When reversing the door, the appliance
must not be connected to the mains. Ensure that
the plug is removed from the mains socket.
Tools you will need:
8mm socket wrench Cross-shaped screwdriver
8mm wrench
Thin-blade screwdriver
Note: Before you start lay the refrigerator on its
back in order to
gain access to the base, you should rest it on
soft foam packaging or similar material to avoid
damaging the backboard of the refrigerator. To
reverse the door, the following steps are
generally recommended.
1. Stand the refrigerator upright. Open the door
to take out all door racks (to avoid racks
damaged) and then close the door.
2. Open part ① on top of the refrigerator body
from right side and then take down part ③ and
part ④ on the door in the same way. Take down
part ② and put it back to the plastic bag.
1
③Upper cover of upper door
②Upper hinge cover (right)
①Upper cover
④Corner cover
3
2
3. Disconnect electrical connector①as well as
electrical connector②and then take down part③.
3
2
1
4. Remove the screws ① , loose wire② , and
remove part③.
Door racks

Hisense Refrigerator
9
Special flange
self-tapping screws
Earth wire
①
②
③
Upper hinge part
Note: Please hold the door by hand during step 4
to prevent door dropping.
5. Remove the door and place it on a smooth
surface with its panel upwards. Lever part①and
part④,then loose screws②, as shown in the
picture. Change handle③to the right side, then
install screws②, part① and part④ in turn. Loose
screws⑦, detach part⑥ and part⑤, turn part ⑥
over and then install part⑤and part⑥to the left
side with screws⑦.
6. Place refrigerator flatwise, remove part③ and
then loose screws④. Remove part ② and part①.
Note: washer may
stick to door.
washer
② Front foot fixed board
④ Self-tapping screws
③ Adjustable bottom feet part
① Lower hinge part（right）
7. Screw out lower hinge, change it to the near
hole site, and then screw up and mount washer.
8.Just remount to the step 6,change part①to left
and part②to right and then fix them with screws④.
Finally install part③.
Lower hinge part (left)
123
② Special self-tapping screws
③ Handle
① Handle covers
④ Screw hole covers
⑤ Door holder
⑥ Stop block
⑦ Self-tapping screws
1
234

Hisense Refrigerator
10
12. Connect electrical connector① in accordance
with step 3 and then install part②(which is in the
plastic bag).
②upper hinge cover(left)
①
13.Reverse part① by 180°and install it onto the
right corner of the door，then mount part②. (both
of which are taken down in step 2)
12
14. Take the reed switch out of the coping
block(part③in step 3)and mount it on another block
for use (which is with mark “R” in the plastic bag).
Put the coping block just removed back to the
plastic bag.
15. ,
connector②, and then install part③ .
Install part ① connect the wire
16. Open the door, mount door racks and then
close it.
Note：Be sure character side of reed switch fits
well with coping block.
1
2
2
3
9. Screw out the upper hinge axis, turn the upper
hinge over and fix axis on it. Then place it at side
for use.
10. Exchange wires both in the left and right slots
of refrigerator body.
11. Move the door to appropriate position, adjust
part① and the door, Move the connecting wire②
in the slot of the door from right to left，and then
fix part①and wire② by screws③. (Please hold
the door by hand when installing)
