Hitachi Zaxis 250lc-7 User manual

ZX250LC(N)-7 HE15LD HE18LD・300LC(N)-7 HE15LD HE18LD・350LC(N)-7 HE15LD HE18LD HE20LD HE22 SUPER LONG FRONT OPERATOR'S MANUAL

ENMDFY-ENSL1-1

Serial No.

ZX250-7 Class 70001 and up

ZX300-7 Class 80001 and up

ZX350-7 Class 90001 and up

250LC(N)-7

Type HE15LD

Type HE18LD

Super Long Front

300LC(N)-7

Type HE15LD

Type HE18LD

350LC(N)-7

Type HE15LD

Type HE18LD

Type HE20LD

Type HE22

PRINTED IN THE NETHERLANDS 2020, 04

URL:http://www.hcme.com

ENMDFY-ENSL1-1

PART NO.

Operator's Manual

INTRODUCTION

For All Machine Users

This instruction manual describes the basic knowledge for the operation and inspection and maintenance procedures

applied when a super long front is mounted to the hydraulic excavator (main system).

This manual contains only the additional information related to the Super Long Front operation that differ from the

parts in the Operation Manual for the standard Hydraulic Excavator. Be sure to thoroughly read and understand the

Operator's manual for the standard machine (base machine) before operating this machine.

Contents described in this manual have priority.

Before starting to operate the machine, read this manual thoroughly and understand the contents.

Operate and service the machine safely and correctly.

Keep the operator's manual at the operating seat so that an operator can check the content anytime he/she needs. Any

operation that does not conform to contents of this manual will lead to serious accidents and/or system failure.

In addition, when you are replacing consumable parts, refer to the list of consumable parts before ordering them. Also,

always use Hitachi genuine parts. Using other than genuine parts will lead to serious accidents and/or system failure.

If you have any questions regarding the machine, provide the Model/type (model name) and the PIN (Product

Identification Number) of your machine.

Model/type and PIN are marked on the nameplate at the front side of the main frame.

Confirm the information beforehand and make a note in the blank after “PIN indication” on the first page of this

manual.

This manual is an important part of this machine. If you hand over your machine, surely attach this manual to the

machine for the new user. Any operation that does not conform to contents of this manual will lead to serious

accidents and/or system failure.

Due to modifications of the machine, contents of this manual and delivered machine may partially differ from each

other.

If you have any questions or find any part that concerns you, contact our branch office or our sales office nearest to

you.

This manual mainly applies SI (international) units for descriptions of amounts and quantities. In addition, it provides a

numeric value in traditional (MKS) or conventional unit as a reference value in parenthesis followed as needed.

Ex. 25.0 MPa (255 kgf/cm2)

Be sure to use fuel that complies with JIS K-2204, EN-590 or ASTM D-975 which contains 15 ppm or lower sulfur. Also

use fuel that complies with solid contamination level of class 18/16/13 of ISO4406-1999 (solid contamination includes

dust). If the fuel specifiedabove is not used, exhaust gas that exceeds the regulation values may be discharged, causing

serious problem on the engine. Consult your authorized dealer.

Intended use

sAFetY

COMPOnents nAMe

t

DISASSEMBLING • ASSEMBLING

OPeRAtInG tHe MACHIne

tRAnsPORtAtIOn

MAIntenAnCe

tROuBLesHOOtInG

sPeCIFICAtIOns

CAPACItIes

IndeX

ENMDFY-ENSL1-1

CONTENTS

INTENDED USE ..................................................................1

Intended Use.........................................................................................1

SAFETY .......................................................................... S-1

Drive Machine Safely......................................................................S-1

Transport Safely ...............................................................................S-2

Avoid Rapid Machine Operation................................................S-3

Avoid Work Other than Specified..............................................S-3

COMPONENTS NAME.................................................... 1-1

Components Name ........................................................................1-1

Super Long Front Attachment .............................................1-1

Additional Devices for the Super Long Front

Attachment ............................................................................1-2

OPERATING THE MACHINE........................................... 3-1

Increase in Counterweight...........................................................3-1

Operating Backhoe (Super Long Front Attachment) .........3-2

Avoid one side operation ............................................................3-3

Avoid using bucket other than specified ...............................3-3

Do Not Operate Machine on Rough Ground .......................3-3

DISASSEMBLING • ASSEMBLING.................................. 4-1

Precautions for Disassembling/Assembling..........................4-1

Preparation for Work ......................................................................4-4

Precautions for Slinging Work.....................................................4-5

Super Long Front Attachment Installation Procedure.......4-6

Additional Counterweight Installation Procedure........... 4-12

Super Long Front Attachment Removal Procedure ........ 4-18

Additional Counterweight Removal Procedure................ 4-21

TRANSPORTATION........................................................ 5-1

Transporting by Road ....................................................................5-1

Loading/Unloading ........................................................................5-1

Loading/Unloading on a Trailer .................................................5-2

Unloading ..........................................................................................5-5

Dimensions and Weight for Transportation...........................5-6

Lifting Machine ................................................................................5-8

Do Not Hoist Whole Machine......................................................5-9

MAINTENANCE.............................................................. 6-1

Maintenance Guide ........................................................................6-1

A. Greasing.........................................................................................6-2

Front Joint Pins ...........................................................................6-2

B. Miscellaneous ..............................................................................6-4

Tightening and Retightening Torque of Nuts and

Bolts...........................................................................................6-4

TROUBLESHOOTING..................................................... 7-1

Troubleshooting ..............................................................................7-1

SPECIFICATIONS ........................................................... 8-1

Specifications....................................................................................8-1

ZX250LC-7, 250LCN-7...............................................................8-1

Working Ranges ZX250LC(N)-7 Super Long Front

Attachment (Type HE15LD) ...................................................8-2

Working Ranges ZX250LC(N)-7 Super Long Front

Attachment (Type HE18LD) ...................................................8-3

Shoe Types and Applications ......................................................8-4

Bucket Types and Applications ..................................................8-5

Specifications....................................................................................8-6

ZX300LC-7, 300LCN-7...............................................................8-6

Working Ranges ZX300LC(N)-7 Super Long Front

Attachment (Type HE15LD) ...................................................8-7

Working Ranges ZX300LC(N)-7 Super Long Front

Attachment (Type HE18LD) ...................................................8-8

Shoe Types and Applications ......................................................8-9

Bucket Types and Applications ...............................................8-10

Specifications.................................................................................8-11

ZX350LC-7, 350LCN-7............................................................ 8-11

Working Ranges ZX350LC(N)-7 Super Long Front

Attachment (Type HE15LD) ................................................8-12

Working Ranges ZX350LC(N)-7 Super Long Front

Attachment (Type HE18LD) ................................................8-13

Working Ranges ZX350LC(N)-7 Super Long Front

Attachment (Type HE20LD) ................................................8-14

Working Ranges ZX350LC(N)-7 Super Long Front

Attachment (Type HE22)...................................................... 8-15

Shoe Types and Applications ...................................................8-16

Bucket Types and Applications ...............................................8-17

CAPACITIES.................................................................... 9-1

Machine capacities .........................................................................9-5

Lifting capacities........................................................................... 9-21

INDEX........................................................................... 10-1

CONTENTS

MEMO

..................................................................................................................................................................................................

1

INTENDED USE

Intended Use

This machine is designed and intended to be used light to moderate excavating and slope finishing with bucket.

Risk assessment related to the specific application and working conditions of the machine may require additional safety

measures such as protective guards, safety glazing, filtration of cabin air, etc. to be installed, enabling the machine to be

operated safely under the specific conditions. Consult your authorized dealer for further information on possibilities to

adapt the machine accordingly.

This machine can be used for lifting applications that are within the lifting capacity of the machine. Use approved lifting

points and lifting devices and follow the instructions provided in this manual.

Local regulations and instructions must be respected when using the machine. Using this machine and its equipment for

operations other than those intended or approved by the manufacturer, are prohibited.

Modifications

No modification affecting the intended use or structural integrity and therefore safety of the machine should be made

without written approval of the manufacturer. Modifications which are not approved include the use of unauthorized

accessories, assemblies, parts or attachments, including but not limiting to those connected with a coupling device.

Any legal or natural person performing unapproved modifications to the machine assumes all liability directly or

indirectly related to the modification.

The manufacturer reserves the right to reject any warranty claim arising from or related to unapproved modifications.

INTENDED USE

2

MEMO

..................................................................................................................................................................................................

Drive Machine Safely

Before driving the machine, always confirm that the travel

levers/pedals direction corresponds to the direction you

wish to drive.

Be sure to detour around any obstructions.

Avoid traveling over obstructions. Soil, fragments of rocks,

and/or metal pieces may scatter around the machine. Do

not allow personnel to stay around the machine while

traveling.

Driving on a slope may cause the machine to slip or

overturn, possibly resulting in serious injury or death.

Never attempt to ascend or descend 30 degrees or steeper

slopes.

Be sure to fasten the seat belt.

When driving up or down a slope, keep the bucket facing

the direction of travel, approximately 0.2 to 0.3 m (A) above

the ground. Expand the arm from vertical position on the

face of a slope.

If the machine starts to skid or becomes unstable,

immediately lower the bucket to the ground and stop.

Forbid swinging on a slope. Or it may cause the machine

to skid or turnover. If the direction must be changed, move

the machine to level ground, then, change the direction to

ensure safe operation.

WRONG

Expand the arm from vertical

position on the face of a slope

Expand the arm from vertical

position on the face of a slope

SAFETY

S-1

SA-2342

SA-442

SA-441

SA-2343

90˚ or less

SAFETY

S-2

Transport Safely

Take care the machine may turn over when loading or

unloading the machine onto or off of a truck or trailer.

Observe the related regulations and rules for safe

transportation.

Select an appropriate truck or trailer for the machine to

be transported.

Be sure to use a signal person.

Always follow the following precautions for loading or

unloading:

1) Select solid and level ground.

2) Always use a ramp or deck strong enough to support the

machine weight.

Loading docks must have an incline of less than 15

degrees.

3) Turn the auto-idle switch OFF.

4) Always select the slow speed mode with the travel mode

switch.

5) Never steer the machine while on the ramp. If the

traveling direction must be changed while the ramp,

unload the machine from the ramp, reposition the

machine on the ground, then try loading again.

6) The top end of the ramp where it meets the flatbed is a

sudden bump. Take care when traveling over it.

7) Place blocks in front of and behind the tires. Securely

hold the machine to the truck or trailer deck with wire

ropes.

Be sure to further follow the details described in the

TRANSPORTING section.

M107-06-018

15 ° or less

SAFETY

S-3

Avoid Rapid Machine Operation

Quick operation may cause the machine to tip over.

Especially never attempt to do quick travel or boom lowering

operation.

Avoid Work Other than Specified

This machine increases in weight of the counterweight and

has dedicated hydraulic system to operate the super long front

attachment.

Therefore, the standard front attachment can not be installed

on this machine.

Never install the front attachment of this machine to another

machine and never install front attachment of another

machine to this machine. Failure to do so may cause machine

turnover or damage, serious injury or death may result.

Be sure to use a bucket that has specified capacity, weight and

width. Otherwise, serious personal injury or death may result.

SA-2344

SAFETY

S-4

Take extra care when removing the stay pin. If the pin of

stay is removed, the stay will suddenly drop, your fingers

may be pinched by the stay.

Sign indicates a hazard of

being hit by the working

device of the machine. Keep

away from machine during

operation.

SS3088571

SS3092124

SS-2285

SS-2286

Machine Position Image

Visibility Map for Machine Model ZX250LC-7, ZX250LCN-7 with HE15LD Super Long Front

Personal Hazard

This machine complies with the essential health and safety requirements for visibility set out by Machinery Directive

2006/42/EC. The map shows the residual maskings (blind spots) observed by a seated operator (wearing the

recommended seat restraint) in the cab using direct vision and the standard visual aids supplied with the machine.

Additionally, operators are encouraged to adjust the mirrors provided to the machine to show the area as shown below.

This map shows an approximation of the residual masking. This can be used as a guide when conducting a site risk

assessment, utilized for site management and to consider additional visual aids.

Conditions: Driver's visibility on 1mRB and VTC are evaluated under ISO 5006

Test Height (on 1mRB):

(1mRB to VTC/on VTC):

1.2 m

Ground Level

Operator eye Height: 1.2 m from the cab floor

Machine Configuration: HE15LD Super Long Front

Machine Position: Travel Position (For the detail position, see the image below)

Applicable visual aids: 1. standard mirror (s)

2. standard camera (s)

: Operator’s eye point

A : 1 m Rectangular Boundary (1mRB)

B : 12 m Visibility Test Circle (VTC)

: Standard Mirror (s)

: Standard camera (s)

: Masking area

: Mirror visibility

: Camera visibility

Visibility Map

"Surrounding Image" "Image to Left Side +

Image to Right Side + Image to Rear"

Monitor display

Image to Left Side + Image to

Right Side + Image to Rear

Monitor display

Surrounding Image

A

B

Camera

visibility

Mirror

visibility

Mirror

visibility

Camera

visibility

Camera visibility

ENMDFY-ENSL1-VM-022

SAFETY

S-5

Monitor display

Surrounding Image + Image to Rear

Visibility Map

"Surrounding Image + Image to Rear"

A

B

Camera

visibility

Camera

visibility

Mirror

visibility

Mirror

visibility

Camera visibility

Visibility Map

"Surrounding Image + Image to Right Side + Image to Rear"

"Image to Right Side + Image to Rear"

Monitor display

Surrounding Image + Image to Right Side

+ Image to Rear

Monitor display

Image to Right Side + Image to Rear

Camera

visibility

Mirror

visibility

Mirror

visibility

Camera visibility

A

B

ENMDFY-ENSL1-VM-024

ENMDFY-ENSL1-VM-023

SAFETY

S-6

SAFETY

S-7

Machine Position Image

ENMDFY-ENSL1-VM-007

Visibility Map for Machine Model ZX250LC-7, ZX250LCN-7 with HE18LD Super Long Front

Personal Hazard

This machine complies with the essential health and safety requirements for visibility set out by Machinery Directive

2006/42/EC. The map shows the residual maskings (blind spots) observed by a seated operator (wearing the

recommended seat restraint) in the cab using direct vision and the standard visual aids supplied with the machine.

Additionally, operators are encouraged to adjust the mirrors provided to the machine to show the area as shown below.

This map shows an approximation of the residual masking. This can be used as a guide when conducting a site risk

assessment, utilized for site management and to consider additional visual aids.

Conditions: Driver's visibility on 1mRB and VTC are evaluated under ISO 5006

Test Height (on 1mRB):

(1mRB to VTC/on VTC):

1.2 m

Ground Level

Operator eye Height: 1.2 m from the cab floor

Machine Configuration: HE18LD Super Long Front

Machine Position: Travel Position (For the detail position, see the image below)

Applicable visual aids: 1. standard mirror (s)

2. standard camera (s)

: Operator’s eye point

A : 1 m Rectangular Boundary (1mRB)

B : 12 m Visibility Test Circle (VTC)

: Standard Mirror (s)

: Standard camera (s)

: Masking area

: Mirror visibility

: Camera visibility

Visibility Map

"Surrounding Image" "Image to Left Side +

Image to Right Side + Image to Rear"

Monitor display

Image to Left Side + Image to

Right Side + Image to Rear

Monitor display

Surrounding Image

A

B

Camera

visibility

Mirror

visibility

Mirror

visibility

Camera

visibility

Camera visibility

SAFETY

S-8

Monitor display

Surrounding Image + Image to Rear

Visibility Map

"Surrounding Image + Image to Rear"

A

B

Camera

visibility

Camera

visibility

Mirror

visibility

Mirror

visibility

Camera visibility

Visibility Map

"Surrounding Image + Image to Right Side + Image to Rear"

"Image to Right Side + Image to Rear"

Monitor display

Surrounding Image + Image to Right Side

+ Image to Rear

Monitor display

Image to Right Side + Image to Rear

Camera

visibility

Mirror

visibility

Mirror

visibility

Camera visibility

A

B

ENMDFY-ENSL1-VM-008

ENMDFY-ENSL1-VM-009

SAFETY

S-9

Visibility Map for Machine Model ZX300LC-7, ZX300LCN-7 with HE15LD Super Long Front

Personal Hazard

This machine complies with the essential health and safety requirements for visibility set out by Machinery Directive

2006/42/EC. The map shows the residual maskings (blind spots) observed by a seated operator (wearing the

recommended seat restraint) in the cab using direct vision and the standard visual aids supplied with the machine.

Additionally, operators are encouraged to adjust the mirrors provided to the machine to show the area as shown below.

This map shows an approximation of the residual masking. This can be used as a guide when conducting a site risk

assessment, utilized for site management and to consider additional visual aids.

Conditions: Driver's visibility on 1mRB and VTC are evaluated under ISO 5006.

Test Height (on 1mRB):

(1mRB to VTC/on VTC):

1.2 m

Ground Level

Operator eye Height: 1.2 m from the cab floor

Machine Configuration: HE15LD Super Long Front

Machine Position: Travel Position (For the detail position, see the image below)

Applicable visual aids: 1. standard mirror (s)

2. standard camera (s)

: Operator’s eye point

A : 1 m Rectangular Boundary (1mRB)

B : 12 m Visibility Test Circle (VTC)

: Standard Mirror (s)

: Standard camera (s)

Machine Position Image

: Masking area

: Mirror visibility

: Camera visibility

Visibility Map

"Surrounding Image" "Image to Left Side +

Image to Right Side + Image to Rear"

Monitor display

Surrounding Image

Monitor display

Image to Left Side + Image to

Right Side + Image to Rear

A

B

Camera

visibility Camera

visibility

Mirror

visibility

Mirror

visibility

Camera visibility

ENMDFY-ENSL1-VM-001

SAFETY

S-10

Monitor display

Surrounding Image + Image to Rear

Visibility Map

"Surrounding Image + Image to Rear"

Mirror

visibility

Mirror

visibility

A

B

Camera

visibility

Camera

visibility

Camera visibility

Visibility Map

"Surrounding Image + Image to Right Side + Image to Rear"

"Image to Right Side + Image to Rear"

Monitor display

Surrounding Image + Image to Right Side

+ Image to Rear

Monitor display

Image to Right Side + Image to Rear

A

B

Camera

visibility

Mirror

visibility

Mirror

visibility

Camera visibility

ENMDFY-ENSL1-VM-002

ENMDFY-ENSL1-VM-003

SAFETY

S-11

Visibility Map for Machine Model ZX300LC-7, ZX300LCN-7 with HE18LD Super Long Front

Personal Hazard

This machine complies with the essential health and safety requirements for visibility set out by Machinery Directive

2006/42/EC. The map shows the residual maskings (blind spots) observed by a seated operator (wearing the

recommended seat restraint) in the cab using direct vision and the standard visual aids supplied with the machine.

Additionally, operators are encouraged to adjust the mirrors provided to the machine to show the area as shown below.

This map shows an approximation of the residual masking. This can be used as a guide when conducting a site risk

assessment, utilized for site management and to consider additional visual aids.

Conditions: Driver's visibility on 1mRB and VTC are evaluated under ISO 5006.

Test Height (on 1mRB):

(1mRB to VTC/on VTC):

1.2 m

Ground Level

Operator eye Height: 1.2 m from the cab floor

Machine Configuration: HE18LD Super Long Front

Machine Position: Travel Position (For the detail position, see the image below)

Applicable visual aids: 1. standard mirror (s)

2. standard camera (s)

: Operator’s eye point

A : 1 m Rectangular Boundary (1mRB)

B : 12 m Visibility Test Circle (VTC)

: Standard Mirror (s)

: Standard camera (s)

Machine Position Image

: Masking area

: Mirror visibility

: Camera visibility

Visibility Map

"Surrounding Image" "Image to Left Side +

Image to Right Side + Image to Rear"

Monitor display

Surrounding Image

Monitor display

Image to Left Side + Image to

Right Side + Image to Rear

A

B

Camera

visibility Camera

visibility

Mirror

visibility

Mirror

visibility

Camera visibility

ENMDFY-ENSL1-VM-004

SAFETY

S-12

Monitor display

Surrounding Image + Image to Rear

Visibility Map

"Surrounding Image + Image to Rear"

Mirror

visibility

Mirror

visibility

A

B

Camera

visibility

Camera

visibility

Camera visibility

Visibility Map

"Surrounding Image + Image to Right Side + Image to Rear"

"Image to Right Side + Image to Rear"

Monitor display

Surrounding Image + Image to Right Side

+ Image to Rear

Monitor display

Image to Right Side + Image to Rear

A

B

Camera

visibility

Mirror

visibility

Mirror

visibility

Camera visibility

ENMDFY-ENSL1-VM-005

ENMDFY-ENSL1-VM-006

Hitachi ZAXIS 250LC-7 User manual

Popular Construction Equipment manuals by other brands
