Hitachi ZAXIS 120-3 class User manual

INTRODUCTION
Read this manual carefully to learn how to operate and
service your machine correctly. Failure to do so could
result in personal injury or machine damage.
This standard specification machine can be operated
under the following conditions without being modified.
Atmospheric Temperature: −20 °C to 40 °C (−4 °F to 104 °F)
Altitude: 0 m to 2000 m (0 ft to 6600 ft)
In case the machine is used under conditions other than
described above, consult your nearest Hitachi dealer.
This manual should be considered a permanent part of
your machine and should remain with the machine when
you sell it.
This machine is of metric design. Measurements in this
manual are metric. Use only metric hardware and tools as
specified.
Right-hand and left-hand sides are determined by fac-
ing in the direction of forward travel.
Write product identification numbers in the Machine
Numbers section. Accurately record all the numbers to
help in tracing the machine should it be stolen. Your
dealer also needs these numbers when you order parts. If
this manual is kept on the machine, also file the identifica-
tion numbers in a secure place off the machine.
Use only diesel fuel with quality specified in JIS K-2204,
EN-590, ASTM D-975, GOST R52368 or GB252.
Failure to use diesel fuel with quality as specified above
may allow the engine to emit exhaust gas which clean-
ness can not conform to the requests in various relevant
regulations. In addition, serious damage to the engine
may result. Consult with your nearest Hitachi dealer for
detailed information.
Warranty is provided as a part of Hitachi’s support pro-
gram for customers who operate and maintain their
equipment as described in this manual. The warranty is
explained on the warranty certificate which you should
have received from your dealer.
This warranty provides you the assurance that Hitachi will
back its products where defects appear within the war-
ranty period. In some circumstances, Hitachi also provides
field improvements, often without charge to the custom-
er, even if the product is out of warranty.
Should the equipment be abused, or modified to
change its performance beyond the original factory
specifications, the warranty will become void and field
improvements may be denied.
Setting fuel delivery above specifications or otherwise
overpowering machines will result in such action.
Only qualified, experienced operators officially licensed
(according to local law) should be allowed to operate
the machine. Moreover, only officially licensed personnel
should be allowed to inspect and service the machine.
PRIOR TO OPERATING THIS MACHINE, INCLUDING
SATELLITE COMMUNICATION SYSTEM, IN A COUNTRY
OTHER THAN A COUNTRY OF ITS INTENDED USE, IT
MAY BE NECESSARY TO MAKE MODIFICATIONS TO IT
SO THAT IT COMPLIES WITH THE LOCAL REGULATORY
STANDARDS (INCLUDING SAFETY STANDARDS) AND
LEGAL REQUIREMENTS OF THAT PARTICULAR COUN-
TRY. PLEASE DO NOT EXPORT OR OPERATE THIS MA-
CHINE OUTSIDE OF THE COUNTRY OF ITS INTENDED
USE UNTIL SUCH COMPLIANCE HAS BEEN CONFIRMED.
PLEASE CONTACT HITACHI CONSTRUCTION MACHIN-
ERY CO., LTD. OR ANY OF OUR AUTHORIZED DISTRIBU-
TOR OR DEALER IF YOU HAVE ANY QUESTIONS CON-
CERNING COMPLIANCE.
©2008 Hitachi Construction Machinery Co., Ltd.
All rights reserved.
Hitachi machine models are classified into 5 classes and 1 model as shown in the
table below. When referring to the texts and/or illustrations indicated with the
applicable machine class names in this manual, check that the machine models
concerned are included using this table.
Class
ZX120-3 Class ZX110-3, 110M-3, 130-3, 130LCN-3
ZX180-3 Class ZX160LC-3, 180LC-3, 180LCN-3
ZX200-3 Class ZX210-3, 210LC-3, 210LCN-3, 240N-3
ZX270-3 Class ZX250LC-3, 250LCN-3, 280LC-3, 280LCN-3
ZX330-3 Class ZX350LC-3, 350LCN-3
Model
Std. Model ZX110-3, 110M-3, 130-3, 130LCN-3, 160LC-3, 180LC-3, 180LCN-3, 210-3, 210LC-3, 210LCN-3,
240N-3, 250LC-3, 250LCN-3, 280LC-3, 280LCN-3, 350LC-3, 350LCN-3
All information, illustrations and specifications in this manual are based on the latest product information available at the
time of publication. The right is reserved to make changes at any time without notice.

T
MACHINE NUMBERS
SAFETY
SAFETY SIGNS
COMPONENTS NAME
OPERATOR’S STATION
BREAK-IN
OPERATING THE ENGINE
DRIVING THE MACHINE
OPERATING THE MACHINE
TRANSPORTING
MAINTENANCE
HYDRAULIC CIRCUIT AND ELECTRICAL CIRCUIT
MAINTENANCE UNDER SPECIAL ENVIRONMENTAL CONDITIONS
STORAGE
TROUBLESHOOTING
SPECIFICATIONS
OPTIONAL ATTACHMENTS AND DEVICES
INDEX
INDEX

MACHINE NUMBERS
The manufacturing Nos. explained in this group is the individ-
ual number (serial No.) given to each machine and hydraulic
components. These numbers are requested when inquiring
any information on the machine and/or components. Fill these
serial Nos. in the blank spaces in this group to immediately
make them available upon request.
MACHINE
1. MODEL/TYPE
2. Product Identification Number
3. Year of Manufacturing
4. Operating mass (standard version)
5. Engine power in KW according to ISO9249
PRODUCT IDENTIFICATION NUMBER
PRODUCT
IDENTIFICATION
NUMBER:
NOTE:
*HCM1U100L00100001*
ENGINE
TYPE:
MFG. NO.:
M157-00-001
SS3097499
Marks to indicate the
start and end of the PIN
PRODUCT IDENTIFICATION
NUMBER (PIN) (ZX330-3
class)
(ZX200-3,
270-3 class)
M178-00-002
M1U1-00-001
M157-12-008
(ZX120-3,
180-3 class)

MACHINE NUMBERS
TRAVEL MOTOR
TYPE:
MFG. NO.:
SWING MOTOR
TYPE:
MFG. NO.:
HYDRAULIC PUMP
TYPE:
MFG. NO.:
M178-07-086
M178-07-047
M157-00-004
