Hitachi G 13SC2 Operator's manual

TACH
MODEL
MODELE G13SC2
MODELO
DiSC GRINDER
MEULEUSE
AlVlOLADORA ANGULAR
iNSTRUCTION MANUAL AND SAFETY iNSTRUCTIONS
z_ WARNING
Improper and unsafe use of this power tool can result indeath or serious bodily injury!
This manual contains important information about product safety. Please read and
understand this manual before operating the power tool. Please keep this manual
available for others before they use the power tool,
MODE D'EMPLOI ET INSTRUCTIONS DE SECURITE
Z_ AVERTISSEMENT
Une utilisation incorrecte et dangereuse de cet outil motorise peut entra_nerla mort ou de
serieusesblessurescorporelles!
Ce mode d'emploi contient d'importantesinformationsapropos de la securite de ce produit.
Prierede lire et de comprendrece mode d'emploi avant d'utiliser I'outil motorise.Garder ce
moded'emploia la disponibilitedesautresutilisateursavantqu'itsutilisentI'outil motorise.
MANUALDEINSTRUCCIONESE INSTRUCCIONESDE SEGURIDAD
/_ ADVERTENCIA
iLa utilizacion inapropiada e insegura de esta herramienta electrica puede resultar en
lesiones sedas oen la muerte!
Este manual contiene informacion importante sobre la seguddad del producto. Leay com-
prenda este manual antes de utilizar la herramienta electrica. Guarde este manual para
que puedanleerlo otras personas antes de que utilicen la herramienta electrica.
[_ OUBLE INSULATION
DOUBLE ISOLATION
AISLAMIENTO DOBLE

CONTENTS
page
IMPORTANT INFORMATION ............ 3
MEANINGS OF SIGNAL WORDS ...... 3
SAFETY .......................................... 4
GENERAL SAFETY RULES ............ 4
SPECIFICSAFETYRULESANDSYMBOLS...7
DOUBLEINSULATIONFORSAFEROPERATION...8
FUNCTIONAL DESCRIPTION ............ 9
NAME OF PARTS ........................... 9
SPECIFICATIONS ........................... 9
ASSEMBLY AND OPERATION ......... 10
page
APPLICATIONS ........................... 10
PRIOR TO OPERATION ............... 10
GRINDER OPERATION .................. 1t
DEPRESSED CENTER WHEEL
ASSEMBLY AND DISASSEMBLY "'13
MAINTENANCE AND INSPECTION ...14
ACCESSORIES .............................. 15
STANDARD ACCESSORIES ......... 15
OPTIONAL ACCESSORIES ............ 15
PARTS LIST .................................... 42
TABLE DES MATIERES
page
INFORMATIONS IMPORTANTES'"I 6
SIGNIFICATIONDESMOTS
D'AVERTISSEMENT.................. 16
SECURITE .................................... 17
REGLESGENERALESDESECURITE...17
REGLESDESECURITESPECIFIQUES
ETSYMBOLES........................ 20
DOUBLEISOLATIONPOURUN
FONCTIONNEMENTPLUSSUR ...21
DESCRIPTION FONCTIONNELLE ...22
NOM DES PARTIES ..................... 22
SPECIFICATIONS ........................ 22
page
ASSEMBLAGEETFONCTIONNEMENT...23
UTtLtSATIONS.............................. 23
AVANT L'UTILISATION .................. 23
UTILtSATION DE LA MEULEUSE ...24
ASSEMBLAGEETDESASSEMBLAGEDELA
MEULEADEPRESSIONCENTRALE...26
ENTRETJENET INSPECTION ............ 27
ACCESOIRES ................................. 28
ACCESSOIRES STANDARD ......28
ACCESSOIRES OPTIONNELS '..28
LISTA DES PI_CES ........................ 42
iNDICE
P&gina Pagina
INFORMACK_N IMPORTANTE ...... 29
SIGNIFICADO DE LAS PALABRAS
DE SENALIZACION ............ 29
SEGURIDAD ................................. 30
NORMASGENERALESDESEGURIDAD-"30
NORMASYSiMBOLOSESPECiFICOS
DESEGURIDAD........................ 33
AISLAMIENTODOBLEPARAOFRECER
UNAOPERACIONM/_SSEGURA'"34
DESCRIPCK)N FUNCIONAL ............ 35
NOMENCLATURA ........................ 35
ESPECIFICACIONES .................. 35
MONTAJE YOPERACION ............... 36
APLICACIONES ........................... 36
ANTES DE LAOPERACION ............ 36
OPERACIONDELAAMOLADORAANGULAR'"37
MONTAJEYDESMONTAJEDELARUEDADE
DISCOABOMBADO.................. 39
MANTENIMIENTO E INSPECCION...... 40
ACCESORIOS .............................. 41
ACCESOR!OS ESTANDAR ......... 41
ACCESORIOS OPClONALES ......41
LISTA DE PIEZAS ........................... 42

English
iMPORTANT iNFORMATiON
Read and understand all of the operating instructions, safety precautions and warn-
ings in the Instruction Manual before operating or maintaining this power tool.
Most accidents that result from power tool operation and maintenance are caused by
the failure to observe basic safety rules or precautions. An accident can often be
avoided by recognizing a potentially hazardous situation before it occurs, and by
observing appropriate safety procedures.
Basic safety precautions are outlined in the "SAFETY" section of this Instruction Man-
ual and in the sections which contain the operation and maintenance instructions.
Hazards that must be avoided to prevent bodily injuly or machine damage are identi-
fied by WARNINGS on the power tool and in this instruction Manual.
Never use this power tool in a manner that has not been.specifically recommended
by HITACHI, unless you first confirm that the planned use will be safe for you and
others.
MEANINGS OF SIGNAL WORDS
WARNING indicates a potentially hazardous situations which, if ignored, could result
in serious personal injury.
CAUTION indicates a hazardous situations which, if ignored, could result in moderate
personal injury, or could cause machine damage.
NOTE emphasizes essential information.

English I
GENERAL SAFETY RULES
z_ WARNING :Read and understand all instructions.
Failure to follow alJ instructions listed below, may result in
electric shock, fire and!or serious personal injury.
SAVE THESE INSTRUCTIONS
1. Work Area
(1) Keep your work area clean and well lit. Cluttered benches and dark areas
invite accidents.
(2) Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases, or dust. Power tools create sparks
which may ignite the dust or fumes.
(3) Keep bystanders, children, and visitors away while operating a power
toot. Distractions can cause you to lose control.
2. Electrical Safety
(1) Double Insulated tolls are equipped with a polarized plug (one blade is
wider than the other .) This plug will fit in apolarized outlet only one
way. If the plug does not fit fully in the outlet, reverse the plug. If it still
does not fit, contact a qualified electrician to install a polarized outlet.
Do not change the plug in any way. Double Insulation [] eliminates the
need for the three wire grounded power cord and grounded power supply
system.
(2) Avoid body contact with grounded surfaces such pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your
body is grounded.
(3) Don't expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
(4) Do not abuse the cord. Never use the cord to carry the tools or pull the
plug form a receptacle. Keep cord away from heat, oil, sharp edges or
moving parts. Replace damaged cords immediately. Damaged cords
increase the risk of electric shock.
(5) When operating a power tool outside, use an outdoor extension cord
marked "W-A" or "W". These cords are rated for outdoor use and reduce
the risk of electric shock.
3. Personal Safety
(1) Stay alert, watch what you are doing and use common sense when
operating apower tool. Do not use tool while tired or under the influ-
ence of drugs, alcohol, or medication. A moment of inattention while oper-
ating power tools may result in serious personal injury.
(2) Dress properly. Do not wear loose clothing or jewelry. Contain long
hair. Keep your hair, clothing, and gloves away from moving parts.
Loose clothes, jewelry, or long hair can be caught in moving parts.
(3) Avoid accidental starting. Be sure switch is off before plugging in.
Carrying tools with your finger on the switch or plugging in tools that have
the switch on invites accidents.

English
(4) Remove adjusting keys or switches before turning the tool on. A wrench
or a key that is left attached to a rotating part of the tool may result in per-
sonal injury.
(5) Do not overreach. Keep proper footing and balance at all times. Proper
footing and balance enables better control of the tool in unexpected situa-
tions.
(6) Use safety equipment. Always wear protective glasses. Dust mask, nonskid
safety shoes, hard hat, or ear plugs must be used for appropriate conditions.
4. Tool Use and Care
(1) Use clamps or other practical way to secure and support the workpiece
to astable platform. Holding the work by hand or against your body is
unstable and may lead to lose of control.
(2) Do not force tool. Use the correct tool for your application. The correct
tool will do the job better and safer at the rate for which it is designed.
(3) Do not use tool if switch does not turn it on or off. Any tool that cannot
be controlled with the switch is dangerous and must be repaired.
(4) Disconnect the plug form the power source before making any adjust-
ments, changing accessories, or storing the tool. Such preventive safety
measures reduce the risk of starting the tool accidentally.
(5) Store idle tools out of reach of children and other untrained persons.
Tools are dangerous in the hand of untrained users.
(6) Maintain tools with care. Keep cutting tools sharp and clean. Properly
maintained tools, with sharp cutting edges are less likely to bind and easier
to control.
(7) Check for misalignment or binding of moving parts, breakage of parts,
and any other condition that may affect the tools operation, if dam-
aged, have the tool serviced before using. Many accidents are caused by
poorly maintained tools.
(8) Use only accessories that are recommended by manufacturer for your
model. Accessories that may be suitable for one tool, may become haz-
ardous when used on another tool.
5. Service
(t) Tool service must be performed only by qualified repair personnel. Service
or maintenance performed by unqualified personnel could result in a risk of injury.
(2) When servicing a tool, use only identical replacement parts. Follow
instructions in the Maintenance section of this manual. Use of unautho-
rized parts or failure to follow Maintenance Instruction may create a risk of
electric shock or injury.
6. Never touch moving parts.
Never place your hands, fingers or other body parts near the tool's moving parts.
7. Never operate without all guards in place.
Never operate this tool without all guards or safety features in place and in proper
working order. If maintenance or servicing requires the removal of a guard or
safety feature, be sure to replace the guard or safety feature before resuming
operation of the tool.
8. Use right tool.
Don't force small tool or attachment to do the job of a heavy-duty tool. Don't use
tool for purpose not intended-for example-don't use circular saw for cutting tree
limbs or logs.
9. Never use a power tool for applications other than those specified.

English I
Never use a power tool for applications other than those specified in the Instruc-
tion Manual.
10. Handle tool correctly.
Operate the toot according to the instructions provided herein. Do not drop or
throw the tool. Never allow the tool to be operated by children, individuals unfa-
miliar with its operation or unauthorized personnel.
11. Keep all screws, bolts and covers tightly in place.
Keep all screws, bolts, and plates tightly mounted. Check their condition periodically.
12. Do not use power tools if the plastic housing or handle is cracked.
Cracks in the tool's housing or handle can lead to electric shock. Such tools
should not be used until repaired.
13. Blades and accessories must be securely mounted to the tool.
Prevent potential injuries to yourself or others. Blades, cutting implements and
accessories which have been mounted to the tool should be secure and tight.
14. Keep motor air vent clean.
The tool's motor air vent must be kept clean so that air can freely flow at all times.
Check for dust build-up frequently.
15. Operate power tools at the rated voltage.
Operate the power tool at voltages specified on its nameplate. If using the power
tool at a higher voltage than the rated voltage, it will result in abnormally fast
motor revolution and may damage the unit and the motor may burn out.
16. Never use a tool which is defective or operating abnormally.
If the tool appears to be operating unusually, making strange noises, or otherwise
appears defective, stop using it immediately and arrange for repairs by a Hitachi
authorized service center.
17. Never leave tool running unattended. Turn power off.
Don't leave tool until it comes to a complete stop.
18. Carefully handle power tools.
Should a power tool be dropped or struck against hard materials inadvertently, it
may be deformed, cracked, or damaged.
t9. Do not wipe plastic parts with solvent.
Solvents such as gasotie, thinner, benzine, carbon tetrachloride, and alcohol may
damage and crack plastic parts. Do not wipe them with such solvents.
Wipe plastic parts with a soft cloth lightly dampened with soapy water and dry
thoroughly.
20. Use only depressed center wheels having a maximum operating speed at
least high as 12,300 RPM.

English
SPECiFiC SAFETY RULES AND SYMBOLS
1. Always use proper guard with depressed center wheel. A guard protects
operator from broken wheel fragments,
2. Accessories must be rated for at least the speed recommended on the tool
warning label. Wheels and other accessories running over rated speed can fly
apart and cause injury.
3. Hold tool by insulated gripping surfaces when performing an operation
where the cutting tool may contact hidden wiring or its own cord. Contact
with a "live" wire wilt make exposed metal parts of the tool "live" and shock the
operator.
4. ALWAYS wear ear plugs when using the tool for extended periods. Prolonged
exposure to high intensity noise can cause hearing loss.
5. NEVER operate the disc grinder without its wheel guard in place.
6. NEVER place hands or body parts near the disc during operation.
7. NEVER use a depressed center wheel which is cracked or deformed or worn
away.
8. NEVER use a depressed center wheel with an RPM rating which is less than
12,300 RPM. The wheel can disintegrate during use and cause severe injuries.
9. NEVER use the grinder in places where the sparks generated by the grinder can
cause explosion, such as where flammable materials or gases are present.
10. NEVER push in the push botton while the spindle is running.
11. ALWAYS wear eye protection that meets the requirement of the latest revision of
ANSI Standard Z87.1.
12 ALWAYS wear a mank or respirator to protect yourself form dust or potentially
harmful particles generated during the grinding operation.
13. ALWAYS firmly grip the body handle and side handle while operating the grinder.
14. ALWAYS have a trial run before grinding commence.
15. ALWAYS follow the instructions contained in this manual when replacing the
depressed center wheel.
16. Definitions for symbols used on this tool
V..-volts
Hz-..hertz
A...amperes
no.-no load speed
W...watt
@..,Class _ Construction
--/min ...revolutions per minute

English I
DOUBLE INSULATION FOR SAFER OPERATION
To ensure safer operation of this power tool, HITACHI has adopted a double insula-
tion design. "Double insulation" means that two physically separated insulation sys-
tems have been used to insulate the electrically conductive materials connected to
the power supply from the outer frame handled by the operater. Therefore, either the
symbol "i-all"or the words and "Double insulation "appear on the power tool or on the
nameplate.
Although this system has no external grounding, you must still follow the normal
electrical safety precautions given in this instruction Manual, including not using the
power tool in wet environments.
To keep the double insulation system effective, follow these precautions:
_ Only HITACHI AUTHORIZED SERVICE CENTER should disassemble or assem-
ble this power tool, and only genuine HITACHI replacement parts should be
installed.
_ Clean the exterior of the power tool only with a soft cloth moistened with soapy
water, and dry thoroughly.
Never use solvents, gasoline or thinners on plastic components; otherwise the
plastic may dissolve.
SAVE THESE INSTRUCTIONS
AND
MAKE THEM AVAILABLE TO
OTHER USERS OF THiS TOOL!

English
NOTE:
The information contained in this Instruction Manual is designed to assist you in
the safe operation and maintenance of the power tool,
Some illustrations in this Instruction Manual may show details or attachments
that differ from those on your own power tool.
NAME OF PARTS
Push Button
Gear Cover \
Packing Gland
Housing Handle
/I
/ /
"- Switch Lever
Locking Button
[When the switch has locking mechanism]
Depressed
Center Wheel
SPECIFICATIONS
Wheel Guard
Fig. 1
\\ \Side Handle
Motor
Power Source
Current
No-Load Speed
Wheel Size:
external diam.
hole diam.
Weight
Single-Phase Series Commutator Motor
Single-Phase 115V AC 60Hz
+1t.0A
10,000/min i
5"(125mm) t
7/8"(22mm)
j 6.2 Ibs(2.8 kg)

English I
APPLICATIONS
© Removal of casting fin and finishing of varius type of steel, bronze and aluminum
materials and castings.
© Grinding of welded sections or sections cut by means of an acetylene torch.
© Grinding of synthetic resins, slate, brick, marble.
PRIOR TO OPERATION
1. Power source
Ensure that the power source to be utilized conforms to the power source
requirements specified on the product nameplate.
2. Power switch
Ensure that the switch is in the OFF position. If the plug is connected to a recep -
tacle while the switch is in the ON position, the power tool will start operating
immediately and can cause serious injury.
3. Extension cord
When the work area is far away from the power source, use an extension cord of
sufficient thickness and rated capacity. The extension cord should be kept as
short as practicle.
4. Check the receptacle
If the receptacle only loosely accepts the plug, the receptacle must be repaired.
Contact a licensed electrician to make appropriate repairs.
If such a fautly receptacle is used, it may cause overheating, resulting in a seri-
ous hazard.
5. Check your working environment
Ensure the following before operation;
No flammable gas, liquid, or other flammable objects at worksite.
Grinding thin steel sheet may cause a high booming sound.
In this case, place a rubber mat under the workpiece.
Take appropriate noise preventive measures to prevent adverse affects on the
environment by loud noise.
Clear the area of children or unauthorized personnel.
6. Mounting the wheel guard
Be sure to mount the wheel guard at an angle that will protect the operator's body
from injury by a broken wheel piece.
WARNING ' If the wheel guard is not properly attached, it may lead to
severe injury or death if the depressed center wheel should
be broken.
,Inspect the depressed center wheel carefully before mounting.
Thoroughly check that a specified depressed center wheel is free of cracks and
splits before being mounted. Make sure that the depressed center wheel is firmly
clamped and has been mounted in accordance with the instructions contained on
page 13.
10

English
8. Test the grinder before using.
Before actually beginning the grinding work, test the grinder by first clearing the
area of all other personnel. Make sure the wheel guard is in place and that you
are wearing eye protection. Turn the grinder "on" and make sure the grinder runs
smoothly and shows no abnormalities.
Duration of the trial run isas follows:
When depressed center wheel is replaced .................. 3 minutes or more
When starting daily work .......................................... 1 minute or more
9. Use only properly rated depressed center wheels.
Use only depressed center wheels rated at 12,300 RPM or more.
Using a depressed center wheel rated less can lead to wheel disintegration dur-
ing operation and cause serious bodily injury.
10. Check the push button.
Make sure that the push button is disengaged by pushing push button two or
three times before turning on the grinder.(Fig.3)
GRINDER OPERATION
1.
,
Hold the grinder firmly by its body handle and side handle (Fig.1)
The grinder produces a counterforce which must be controlled by firmly holding
onto the grinder.
Switch operation
This enables the grinder always to be controlled with the hand gripppng the
machine for maximum safety during grinding operations.
.
Switch ON : Press the switch lever.
Switch OFF : Release the switch lever.
[Whenthe switchhaslockingmechanism]
Switch ON : Press the switch lever. The switch lever is locked by pulling on
the locking button.
Switch OFF : Press and release the switch lever.
Use light grinding pressure.
There is no need to press hard when grinding. Usually the grinder's own weight is
sufficient for the surface to be ground.
Z_ WARNING : Do not press the grinder forcibly against the surface to be
ground. Heavy pressure can result in wheel breakage and
serious injury, it can also damage the surface being ground
or damage the grinder's motor.
4. Use proper grinding angle.
Grind only with the wheel's edge by lifting the grinder 15to 30, as shown in
Fig. 2.
z_ CAUTION :Do not use the entire surface of the depressed center wheel.
Use only the edge of the depressed center wheel.
11

English I
.Move the grinder in the proper
direction.
When using a new depressed center
wheel in direction A (Fig. 2), the
wheel edge may cut into the work-
piece. In this case, grind in direction B
(Fig. 2).
Once the wheel edge is worn, the
workpiece can be ground in both
directions.
NOTE: The wheel provided (resinoid wheel) is rated as Class A grain and #36 grain
size. It is most suitable for heavy grinding of steel and other types of materi-
als.
6. Adjust operation to desired finish.
For a fine finish, decrease pressure by lifting slightly. Grind slowly and at the
appropriate speed.
z_CAUTION "The revolving depressed center wheel will create air turbulence.
Do no lay grinder down in areas of dust or dirt until it has come
to a complete stop.
12

English
DEPRESSED CENTER WHEEL ASSEMBLY AND DISASSEMBLY
WARNING : Never attempt to assemble or disassemble the depressed
center wheel while the grinder is capable of being
turned"on".
Be sure power switch is in the "OFF'position and the elec-
trical cord has been disconnected from the receptacle.
1, Assembling
(1) Turn the disc grinder upside-
down so that the spindle is fac-
ing upward.
(2) Align the oval-shaped indenta-
tion of the wheel washer with
the notched part of the spindle,
then attach them.
(3) Fit the protuberance of the
depressed center wheel onto
the wheel washer.
(4) Screw the wheel nut onto the
spindle.
(5) While pushing the push button
with one hand, lock the spindle
by turning the depressed center
wheel slowly with the other
hand.
Tighten the wheel nut by using
the supplied wrench as shown
in Fig.3.
Wrench ....
Wheel Nut
i
Depressed Center . /_"
Wheel
Wheel Washer i
0
Spindle !
Wheel Guard .... ii
Push Button "....."....
Fig. 3
z_CAUTtON " Tighten the wheel nut securely and confirm that the depressed
center wheel does not wobble.
2. Disassembling
To remove the depressed center wheel, follow the above-mentioned procedure in
reverse order.
13

English I
z_ WARNING 'Be sure to switch the power switch OFF and disconnect the
ptug from the receptacle during maintenance and inspec-
tion.
1. Replacing the depressed center wheel
Replace the depressed center wheel when it has been worn out to about 2-3/8"
(60mm) in external diameter. Confirm that there is no crack or any damage to the
depressed center wheel. If there is a crack or a transformation in the wheel,
replace it immediately.
2. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure that they are properly tight-
ened. Should any of the screws be loosened, retighten them immediately.
zL WARNING "Using this grinder with loosened screws is extremely dan-
gerous.
,
4,
Confirm that there is no damage in the
wheel guard, the cord and housing, etc.
Furthermore, confirm that there is no abnormali-
ty in the activation of the switch.
Inspecting the carbon brushes(Fig. 4)
The motor employs carbon brushes which are
consumable parts. Replace the carbon brush
with a new one when it becomes worn to its
wear limit. Always keep carbon brushes clean
and ensure that they slide freely within the
brush holders.
Z_CAUTION "Using this grinder with a carbon
brush which is worn in excess of
the wear limit will damage the
motor.
No. of carbon
Wear limit brush
I i _.24"(6mm)
L._ ..................................................
0.67"(17mm)
Fig. 4
NOTE "Use HITACHI carbon brush No.43 indicated in Fig. 4.
'_' Replacing a carbon brush:
Remove the brush cap (Fig. 1) with a slotted screwdriver. The carbon brush can
then be easily removed.
5. Service and repairs
All quality power tools will eventually require servicing or replacement of parts
because of wear from normal use. To assure that only authorized replacement
parts will be used, all service and repairs must be performed by a HITACHI
AUTHORIZED SERVICE CENTER, ONLY.
14

English
WARNING "NEVER use any accessories other than those mentioned
below,
The use of any accessories other than those mentioned
below or attachments not intended for use such as cup
wheel, cut-off wheel or saw blade is dangerous and may
cause personal injury or property damage,
NOTE :
Accessories are subject to change without any obligation on the parts of the HITACHI.
STANDARD ACCESSORIES
O Depressed Center Wheel ............... :........................................................ 1
5"(125mm) external dia. x 1/4"(6mm) thickness x 7/8"(22mm) hole dia.
(Code No. 701050)
O Wrench(Code No. 937913Z) ..................................................................... 1
O Side Handle (Code No. 956633) ............................................................... 1
NOTE :
Specifications are subject to change without any obligation on the part of the
HITACHI.
15

INFORMATIONS IMPORTANTES
Lire et comprendre toutes les instructions de fonctionnement, les precautions de
securite et les avertissements dans ce mode d'emploi avant d'utiliser ou d'entretenir
cet outil motorise.
La plupart des accidents causes Iors de I'utilisation ou de I'entretien de I'outil
motorise proviennent d'un non respect des regles ou precautions de base de
s6curite. Un accident peut la plupart du temps 6tre evite si I'on reconnait une situa-
tion de danger potentiel avant qu'elle ne se sroduise, et en observant les procedures
de securite appropriees.
Les precautions de base de securite sont mlses en evidence dans la section "SECU-
RITE" de_ce mode d'emploi et dans les sections qui contiennent les instructions de
fonctionnement et d'entretien.
Les dangers qui peuvent 6tre 6vites pour prevenir des blessures corporelles ou un
endommagement de la machine sont identifies par AVERTISSEMENTS sur t'outil
motorise et dans ce mode d'emploi.
Ne jamais utiliser cet outil motorise d'une maniere qui n'est pas specifiquement
recommandee par HITACHI sans avo_r d'abord v6rifie que I'utilisation prevue est
sans danger pour vous et les autres.
SiGNiFiCATION DES MOTS D'AVERTISSEMENT
AVERTISSEMENT indique des situations potentiellement dangereuses qui, si elles
sont ignorees, pourraient entra;ner de serieuses btessures personnelles.
PRECAUTION indique des situations dangereuses qui, si elles sont ignorees, pour-
ra_tentrai'ner de legeres blessures personnelles ou endommager la machine.
REMARQUE met en relief des informations essentielles.
16

Fran£ais
REGLES GENERALE DE SECURITE
/_ AVERTISSEMENT : Lire et comprendre routes les instructions.
Un non respect de routes les instructions ci-dessous
peut entrainer une electrocution, un incendie et/ou
de serieuses blessures personnelles.
CONSERVER CES iNSTRUCTiONS
1. Zone de travail
(1) Garder la zone de travail propre et bien eclairee. Les etablis mal ranges
et les zones sombres invitent aux accidents.
(2) Ne pas utiliser les outils motorises darts une atmosphere explosive,
telle qu'en presence de liquides inflammables, de gaz ou de
poussieres. Les outils motorises creent des etincelles qui risquent d'enflam-
met la poussiere ou les vapeurs.
(3) Tenir les spectateurs, les enfants et les visiteurs eloignes, Iors de Futil-
isation de I'outil motoris&
Une distraction peut faire perdre le contr61e de la machine.
2. Securite electrique
(1) Les outils a double isolation sont equipes d'une fiche polarisee (une
lame est plus large que t'autre). Cette fiche ne penetrera clans une prise
secteur polarisee que darts un sens. Si la fiche ne rentre pas
completement darts la prise, la retourner. Si elle ne rentre toujours pas,
contacter un electricien qualifie pour installer une prise polarisee. Ne
pas modifier ta fiche d'aucune fa(}on. La double isolation [] etimine le
besoin d'un cordon d'alimentation a,trois ills et d'un systeme d'alimentation
avec mises & la terre.
(2) Eviter tout contact corporel avec les surfaces raises a la terre relies
que les canalisations, les radiateurs, les rechauds et les refrigerateurs.
IIy a un risque accru d'electrocution si son corps est mis & la terre.
(3) Ne pas exposer les outils motorises a ta pluie ou a I'humidit& De I'eau
penetrant #,I'interieur de I'outil motorise augmente te risque d'electrocution.
(4) Ne pas abuser du cordon d'alimentation. Ne jamais utiliser le cordon
pour porter les outils ou tirer sur la fiche du receptacle. Garder le cor-
don a Fecart de la chaleur, de I'huHe, des ar_tes coupantes ou des
pieces en mouvement. Remptacer les cordons endommages
Jmmediatement. Des cordons endommages augmentent le risque d'electro-
cution.
(5) Lors de I'utitisation d'un out# motorise, utiliser un cordon de rallonge
exterieur marque "W-A" ou "W". Ces cordons sont prevus pour une utili-
sation exterieure et reduisent tes risques d'electrocution.
3. Securite personneHe
(1) Rester sur ses gardes, regarder ce que I'on fait et utiliser son sens
17

4.
commun Iors de I'utilisation d'un outil motorise. Ne pas utiliser un outil
en _tat de fatigue ou sous I'influence de drogues, d'alcooi ou de
m_dicaments. Un moment d'inattention Iors de rutilisation de I'outil motorise
pout entrafner de s_rieuses blessures personnelles.
(2) S'habiiler correctement. Ne pas porter des v_tements larges ou des
bijoux. Attacher ies cheveux longs. Tenir ses cheveux, v_tements et
ses gants _loign_s des parties mobiles. Les v_tements largos, les bijoux
et los cheveux longs peuvent se prendre dans les parties mobiles.
(3) Eviter tout d_marrage accidentel. S'assurer queie i'interrupteur d'aii=
mentation est sur ia position d'arr_t avant de brancher ia machine.
Transporter l'appareil avec los doigts sur I'interrupteur d'alimentation ou
brancher un outil avec I'interrupteur sur la position marche invite aux acci-
dents.
(4) Retirer les clefs d'ajustement ou les commutateurs avant de mettre
l'outil sous tension. Une clef qui est taissee attachee & une pattie tour-
nante de I'outil peut provoquer une btessure personnelle.
(5) Ne pas trop presumer de ses forces. Garder en permanence une posi-
tion et un 6quilibre correct. Une position et un _quilibre correct permettent
un meilleur contrSle de I'outi!dans des situations inattendues.
(6) Utiliser un _quipement de s_curite. Toujours porter des lunettes de
protection. Un masque & poussiere, des chaussures de securit6
antid6rapantes, un chapeau dur et des bouchons d'oreille doivent 6tre
utilis6s dans les conditions appropri6es.
Utllisation de i'outil et entretien
(1) Utiliser un _tau ou routes autres fa_ons de fixer et maintenir la piece
usiner sur une plate=forme stable. Tenir la piece avec la main ou contre
son corps est instable et pout conduire _ une perte de contr61ede routil.
(2) Ne pas forcer sur I'outil. Utiliser I'outll correct pour I'application
souhait6e. L'outil correct r_alisera un meilleur et plus s0r travail dans le
domaine pour lequel il a 6to con?u.
(3) Ne pas utiliser un outil s'il nese met pas sous ou hors tension avec un
interrupteur. Un outil qui ne pout pas _tre commande avec un interrupteur
est dangereux et dolt 6tre repar6.
(4) D6connecter la fiche de la source d'alimentation avant de realiser tout
ajustement, changement d'accessoires ou pour ranger I'outil. De telles
mesures de s_curit_ reduisent le risque que l'outil ne demarre accidentelle-
ment.
(5) Ranger les outils inutiiis_s hors de la portee des enfants et des autres
personnes inexp_riment_es. Les outils sont dangereux dans les mains de
personnes inexp_riment_es.
(6) Conserver les outils avec soin. Garder les outils de coupe aiguises et
propres. Des outils bien entretenus, avec des lames coupantes aiguisees
risquent moths de se gripper et sont plus faciles _ contrSler.
(7) V_rifier les d_fauts d'alignement ou grippage des parties mobiles, les
ruptures des pieces et routes los autres conditions qui peuvent affecter
le fonctionnement des outils. En cas de dommage, faire reparer i'outil
avant de I'utiliser. Beaucoup d'accidents sont causes par des outils mal
entretenus.
(8) Utiliser uniquement les accessoires recommandes par le fabricant pour
18

Fran£ais
le modele utilis& Des accessoires qui peuvent convenir & un outi!, peuvent
devenir dangereux Iorsqu'ils sont utilises avec un autre outil.
5. Reparation
(1) La reparation de I'outil ne doit _tre realisee uniquement par un repara-
teur qua|ill& Une reparation ou un entretien realis6 par un personnel non
qualifie peut entra_ner des risques de blessures.
(2) Lors de la reparation d'un outil, utiliser uniquement des pieces de
rechange identiques. Suivre les instructions de la section d'entretien
de ce mode d'emploi. L'utilisation de pieces non autorisees ou un non
respect des instructions d'entretien peut creer un risque d'_lectrocution ou
de blessures.
6. Ne jamais toucher les parties mobiles.
Ne jamais placer ses mains, ses doigts ou route autre partie de son corps pres
des parties mobiles de I'outil.
7. Ne jamais utiliser I'outil sans que tousles dispositifs de securite ne soient
en place.
Ne jamais faire fonctionner cet outil sans que tousles dispositifs et
caracteristiques de securit6 ne soient en place et en etat de fonctionnement. Si
un entretien ou une reparation necessite le retrait d'un dispositif ou d'une car-
acteristique de securite, s'assurer de bien remettre en place le dispositif ou la
caracteristique de securite avant de recommencer a utiliser I'outil.
8. Utiliser I'outil correct
Ne pas forcer sur un petit outil ou accessoire pour faire le travail d'un outil de
grande puissance. Ne pas utiliser un outil pour un usage pour lequel il n'a pas
ere prevu: par exemple, ne pas utiliser une scie circulaire pour couper des
branches d'arbre ou des bQches.
9. Ne jamais utiliser un outil motorise pour des applications autres que celles
specifiees.
Ne jamais utiliser un outil motoris_ pour des applications autres que celies
specifiees dans le mode d'emploi.
10. Manipuler I'outi| correctement
Utiliser I'outilde la fa_;on indiqu_e darts ce mode d'emploi. Ne pas laisser tomber
ou lancer I'outil. Ne pas permettre que I'outil soit utilis_ par des enfants, des per-
sonnes non familiarisees avec son fonctionnement ou un personnel non autoris&
11. Maintenir routes les vis, tous les boulons et les couvercles fermement en
place.
Maintenir routes les vis, tousles boulons et les couvercles fermement montes.
Verifier leurs conditions periodiquement.
12. Ne pas utiiiser les outils motorises si le rev_tement de plastique ou la
poignee est fendu.
Des fentes dans le rev_tement ou la poignee peuvent entra_ner une electrocu-
tion. De tels outils ne doivent pas _tre utilises avant d'etre repar&
13. Les lames et les accessoires doivent _tre fermement montes sur I'outil.
Eviter les blessures potentieltes personnelles et aux autres. Les lames, les instru-
ments de coupe et les accessoires qui ont ete montes sur I'outil doivent _tre fixes
et serres fermement.
14. Garder propres les events d'air du moteur
Les events d'air du moteur doivent _tre maintenus propres de fa¢,on que I'air
puisse circuler librement tout le temps. Verifier les accumulations de poussiere
frequemment.
19

15. Utiliser I'outil motorise a la tension nominale.
Utiliser I'outil motorise #,ta tension specifiee sur sa plaque signaletique.
Si I'on utilise I'outil motorise avec une tension superieure a la tension nominale, il
en resultera une rotation anormalement trop rapide du moteur et cela risque d'en-
dommager I'outil et te moteur risque de griller.
16. Ne jarnais utitiser un outil defectueux ou qui fonctionne anormalement.
Si I'outit n'a pas Fair de fonctionner normalement, fait des bruits etranges ou sans
cela paraTt defectueux, arr6ter de t'utiliser immediatement et le faire reparer par
un centre de service Hitachi autorise.
17. Ne jamais laisser fonctionner I'outil sans surveillance. Le mettre hors ten-
sion.
Ne pas abandonner l'outit avant qu'il ne soit completement arr6t6.
t8. Manipuler I'outil motorise avec precaution.
Si un outil motorise tombe ou frappe un materiau dur accidentellement, il risque
d'etre deforme, fendu ou endommag&
19. Ne pas essuyer les parties en plastique avec du solvant.
Les solvants comme I'essence, les diluants, ta benzine, te tetrachlorure de car-
bone et I'alcoot peuvent endommager et fissurer les parties en plastique. Ne pas
les essuyer avec de tels solvants.
Essuyer les parties en plastique avec un chiffon doux legerement imbibe d'une
solution d'eau savonneuse et secher minutieusement.
20. Utiliser uniquement des rneules a depression centrale ayant une vitesse de
fonctionnement maximale d'au moins 12300 tr/mn.
SREGLES DE SECURITE SPECIFIQUES ET SYMBOLES
1. Se servir systernatiquement d'un capot couvre-meule approprie. En effet, le
capot couvre-meule met I'operateur a I'abri d'eventuettes projections de frag-
ments de meule casses.
2. Les accessoires doivent _tre utilises a une cadence equivalent au moins
la vitesse de rotation de ta meule telle qu'elle est indiquee sur I'etiquette de
mise en garde de I'outil. En effet, les meules et les autres accessoires qui sont
utilises & une cadence superieure a.la vitesse nominale risquent d'etre projetes
aux alentours et de blesser quelqu'un.
3. Tenir les outils par tes surfaces de grippage Iors de la realisation
d'operation ou I'outil de coupe risque d'entrer en contact avec des c&btes
caches ou son propre cordon. Un contact avec un fil "sous tension" mettra tes
parties metalligues de I'outil "sous tension" et electrocutera I'utilisateur.
4. Porter SYSTEMATIQUEMENT des bouchons d'oreille Iorsque I'outil est utilise
pendant de longs moments. En effet, une exposition prolongee & un bruit de forte
intensite peut endommager t'ou;e de I'operateur.
5. NE JAMAIS utiliser la meuleuse sans que le capot couvre-meute ne soit en place.
6. NE JAMAIS placer ses mains ou d'autres parties de son corps pres de la meule
pendant I'operation.
7. NE JAMAIS utiliser de meuie b.depression centrale fendue, deformee ou usee.
8. NE JAMAIS utiliser de meule b.depression centrale ayant un regime nominal
inferieur b.12300 tr/mn.
9. NE JANIAIS utiliser la meuleuse dans des endroits ou les etincelles gen6r6es par
la meuleuse peuvent causer une explosion. Par exemple, en presence de
materiaux inflammables ou de gaz.
2O
