Hitachi HTDK150EBS User manual

JULY 2001
SM0151
H
TD
K150EBS
SERVICE MANUAL
MANUEL D’ENTRETIEN
WARTUNGSHANDBUCH
CAUTION:
Before servicing this chassis, it is important that the service technic
ian
read the “Safety Precautions” and “Product Safety Notices” in this
service manual.
ATTENTION:
Avant d’effectuer l’entretien du châassis, le technicien doit lire les
«Précautions de sécurité» et les «Notices de sécuritédu produit
»
présentés dans le présent manuel.
VORSICHT:
Vor Öffnen des Gehäuses hat der Service-
Ingenieur die
„Sicherheitshinweise“und „Hinweise zur Produktsicherheit“in diese
m
Wartungshandbuch zu lesen.
Data contained within this
Service manual is subject to
alteration for improvement.
Les données fournies dans le
présent manuel d’entretien
peuvent faire l’objet de
modifications en vue de
perfectionner le produit.
Die in diesem
War
tungshandbuch enthaltenen
Spezifikationen kö
nnen sich
zwecks Verbesserungen ändern.

ENGLISH
SAFETY PRECAUTIONS
WARNING: The following precautions must be observed.
ALL PRODUCTS
Before any service is performed on the chassis an
isolation transformer should be inserted between the
power line and the product.
1. When replacing the chassis in the cabinet, ensure
all the protective devices are put back in place.
2. When service is required, observe the original
lead dressing. Extra precaution should be taken to
ensure correct lead dressing in any high voltage
circuitry area.
3. Many electrical and mechanical parts in
HITACHI products have special safety related
characteristics. These characteristics are often not
evident from visual inspection, nor can the
protection afforded by them necessarily be
obtained by using replacement components rated
for higher voltage, wattage, etc. Replacement
parts which have these special safety
characteristics are identified by marking with a
!on the schematics and the replacement parts
list.
The use of a substitute replacement component
that does not have the same safety characteristics
as the HITACHI recommended replacement one,
shown in the parts list, may create electrical
shock, fire, X-radiation, or other hazards.
4. Always replace original spacers and maintain lead
lengths. Furthermore, where a short circuit has
occurred, replace those components that indicate
evidence of overheating.
5. Insulation resistance should not be less than 2M
ohms at 500V DC between the main poles and
any accessible metal parts.
6. No flashover or breakdown should occur during
the dielectric strength test, applying 3kV AC or
4.25kV DC for two seconds between the main
poles and accessible metal parts.
7. Before returning a serviced product to the
customer, the service technician must thoroughly
test the unit to be certain that it is completely safe
to operate without danger of electrical shock. The
service technician must make sure that no
protective device built into the instrument by the
manufacturer has become defective, or
inadvertently damaged during servicing.
CE MARK
1. HITACHI products may contain the CE mark on
the rating plate indicating that the product
contains parts that have been specifically
approved to provide electromagnetic
compatibility to designated levels.
2. When replacing any part in this product, please
use only the correct part itemised in the parts list
to ensure this standard is maintained, and take
care to replace lead dressing to its original state,
as this can have a bearing on the electromagnetic
radiation/immunity.
PICTURE TUBE
1. The line output stage can develop voltages in
excess of 25kV; if the E.H.T. cap is required to be
removed, discharge the anode to chassis via a
high value resistor, prior to its removal from the
picture tube.
2. High voltage should always be kept at the rated
value of the chassis and no higher. Operating at
higher voltages may cause a failure of the picture
tube or high voltage supply, and also, under
certain circumstances could produce X-radiation
levels moderately in excess of design levels. The
high voltage must not, under any circumstances,
exceed 29kV on the chassis (except for projection
Televisions).
3. The primary source of X-radiation in the product
is the picture tube. The picture tube utilised for
the above mentioned function in this chassis is
specially constructed to limit X-radiation. For
continued X-radiation protection, replace tube
with the same type as the original HITACHI
approved type
4. Keep the picture tube away from the body while
handling. Do not install, remove, or handle the
picture tube in any manner unless shatterproof
goggles are worn. People not so equipped should
be kept away while picture tubes are handled
LASERS
If the product contains a laser avoid direct exposure to
the beam when the cover is open or when interlocks are
defeated or have failed.

FRANÇAIS
CONSIGNES DE SECURITE
AVERTISSEMENT: vous devez respecter les précautions suivantes
POUR TOUS LES PRODUITS
Avant d’effectuer une intervention d’entretien sur le
châssis, vous devez insérer un transformateur d’isolement
entre la ligne d’alimentation électrique et le produit.
1. Lors de la remontage du châssis dans le coffret,
vérifiez que tous les dispositifs de protection sont
remis en place.
2. Lorsqu’une intervention d’entretien s’avère
nécessaire, respectez l’agencement d’origine des
conducteurs. Vous devez prendre des précautions
supplémentaires pour garantir un agencement correct
des conducteurs dans toutes les zones où des circuits
haute tension sont présents.
3. De nombreux composants électriques et mécaniques
des appareils HITACHI ont des caractéristiques
spéciales de sécurité. Bien souvent, ces
caractéristiques ne sont pas évidentes lors d’un
examen visuel et la protection qu’ils offrent n’est pas
forcément garantie si vous utilisez des composants de
rechange conçus, par exemple, pour une tension plus
élevée, une puissance plus forte. Les pièces de
rechange qui offrent des caractéristiques spéciales de
sécurité sont identifiées par un repérage comportant
le symbole !sur les schémas et sur la
nomenclature des pièces de rechange.
L’emploi d’un composant de rechange qui ne
respecte pas les mêmes caractéristiques de sécurité
que la pièce de rechange que recommande HITACHI
et qui figure dans la nomenclature risque de
provoquer un choc électrique, un incendie, des rayons
X ou d’autres dangers.
4. Remettez toujours en place les entretoises d’origine
et respectez la longueur des conduites. En outre, à la
suite d’un court-circuit, remplacez les composants
présentant des signes de surchauffe.
5. La résistance d’isolement doit être supérieure ou
égale à 2 méga ohms à 500 V c.c. entre les pôles
principaux et des composants métalliques
accessibles, quels qu’ils soient.
6. Aucun claquage et aucune rupture ne doit se produire
pendant l’essai de résistance diélectrique à la suite de
l’application d’une tension de 3 kV c.a. ou de 4,35
kV c.c. pendant deux secondes entre les pôles
principaux et des composants métalliques
accessibles.
7. Avant de remettre au client un produit qui a fait
l’objet d’un entretien, le technicien qui s’est chargé
de cette intervention doit tester à fond cet ensemble
pour s’assurer qu’il ne présente aucun danger
opérationnel et aucun risque de choc électrique. Ce
technicien doit s’assurer qu’aucun des dispositifs de
protection intégrés à cet instrument par le fabricant
n’est défectueux ou n’a été endommagé de façon
accidentelle lors de l’entretien.
LABEL CE
1. Les produits HITACHI peuvent avoir reçu le label
CE qui figure sur la plaque signalétique pour indiquer
que cet ensemble contient des composants qui ont fait
l’objet d’une homologation spécifique de respect des
normes de compatibilité électromagnétique en
fonction de niveaux bien spécifiés.
2. Lors du remplacement d’un des composants de ce
produit, utilisez uniquement le composant correct
identifié dans la nomenclature afin de maintenir le
respect de cette norme ; en outre, vous devez
également ramener l’agencement des conducteurs à
son état d’origine car cela peut avoir une influence au
niveau des rayonnements électromagnétiques et sur la
protection contre ces rayons.
PICTURE TUBE
1. L’étage de sortie des lignes peut développer des
tensions de plus de 25 kV ; s’il faut retirer le chapeau
de protection contre les tensions extrêmement
élevées, il convient de décharger l’anode contre le
châssis par le biais d’une résistance de forte valeur
avant de déposer ce chapeau du tube image.
2. La haute tension doit toujours se maintenir à la valeur
nominale du châssis et ne pas dépasser cette dernière.
Un fonctionnement à des températures élevées peut
provoquer une défaillance du tube image ou l’entrée
d’une tension élevée. Dans certains cas, cela peut
même provoquer des rayons X d’un niveau
légèrement supérieur aux valeurs de calcul. Cette
haute tension ne doit en aucun cas dépasser 29 kV sur
le châssis (à l’exception des téléviseurs de
projection).
3. La principale source de rayons X de cet appareil est
le tube image. Le tube image employé pour assurer la
fonction susmentionnée dans ce châssis est
spécialement construit pour limiter des rayons X.
Pour maintenir cette protection contre les rayons X, il
faut remplacer le tube d’origine d’un type agréé par
HITACHI par un autre tube de même type.
4. Lors des manipulations, ne tenez jamais le tube
image contre le corps. Pendant toutes les opérations
d’installation, de dépose et de manipulation de ce
tube image, quelle que soit la méthode employée,
vous devez toujours porter des lunettes de sécurité
anti-éclatements. Les personnes qui ne portent pas ce
type de lunettes doivent se tenir à l’écart du tube
image lors de la manipulation de ce dernier.
RAYONS LASER
Si ce produit contient un rayon laser, évitez toute
exposition directe à ce faisceau lors de l’ouverture du
couvercle ou lors de l’élimination des verrouillages de
sécurité ou après défaillance de ces verrouillages.

DEUTSCH
SICHERHEITSVORKEHRUNGEN
WARNUNG: Die folgenden Vorkehrungen müssen eingehalten werden.
ALLE PRODUKTE
Bevor die Grundplatte gewartet wird, sollte ein Trenntrafo
zwischen die Netzleitung und das Produkt eingebracht
werden.
1. Wenn die Grundplatte in das Gehäuse zurückgestellt
wird, stellen Sie sicher, dass alle
Schutzvorrichtungen wieder an ihrem Ort sind.
2. Wenn Wartung erforderlich ist, halten Sie die
originale Verdrahtungsart ein. Besondere Vorsicht ist
nötig, um die korrekte Verdrahtungsart in jedem
Hochspannungsstromkreis zu gewährleisten.
3. Viele elektrische und mechanische Teile von
HITACHI Produkten haben besondere
sicherheitsbezogene Eigenschaften. Diese
Eigenschaften fallen oft nicht ins Auge, aber der
durch sie gewährte Schutz kann nicht unbedingt
erreicht werden, wenn man Ersatzteile benutzt, die
für höhere Spannung, Leistung usw. ausgelegt sind.
Ersatzteile, die diese besonderen
Sicherheitsmerkmale haben, sind in den
Prinzipskizzen und Ersatzteillisten an einem !zu
erkennen.
Der Gebrauch von Ersatzteilen, die nicht dieselben
Sicherheitsmerkmale haben wie die empfohlenen
HITACHI Ersatzteile, wie sie in der Ersatzteilliste
aufgeführt sind, kann zu elektrischem Schlag, Feuer,
Röntgenstrahlung und anderen Gefahren führen.
4. Immer die originalen Abstandsstücke ersetzen und
die Leitungslängen beibehalten. Wo ein Kurzschluss
passiert ist, die Teile ersetzen, bei denen Überhitzung
nachzuweisen ist.
5. Der Isolierwert sollte bei 500 V Gleichstrom
zwischen den Hauptpolen und allen zugänglichen
Metallteilen nicht unter 2M Ohm liegen.
6. Bei der Prüfung auf Durchschlagsfestigkeit sollte
kein Überschlag oder Durchschlag vorkommen,
wenn zwei Sekunden lang 3 kV Wechselstrom oder
4,25 kV Gleichstrom zwischen den Hauptpolen und
allen zugänglichen Metallteilen angelegt wird.
7. Bevor das gewartete Produkt dem Kunden
zurückgegeben wird, muss der Wartungstechniker
das Gerät gründlich prüfen, um sicherzustellen, dass
es betriebssicher ist ohne das Risiko eines
elektrischen Schlages. Der Wartungstechniker muss
sicherstellen, dass keine vom Hersteller im Gerät
eingebaute Schutzvorkehrung schadhaft geworden ist
oder bei der Wartung unabsichtlich beschädigt
wurde.
CE KENNZEICHEN
1. HITACHI Produkte enthalten eventuell das CE
Kennzeichen auf dem Leistungsschild, welches
angibt, dass das Produkt Teile enthält, die eigens
zugelassen sind, um bis zu einem spezifizierten
Niveau elektromagnetische Störfreiheit zu bewirken.
2. Wenn Sie irgendein Teil in diesem Produkt ersetzen,
benutzen Sie bitte nur das korrekte Teil, das in der
Ersatzteilliste aufgeführt ist, um sicherzustellen, dass
dieser Standard eingehalten wird, und geben Sie acht,
die Verdrahtungsart in ihren ursprünglichen Zustand
zurück zu versetzen, weil das einen Einfluss auf die
elektromagnetische Abstrahlung/Störsicherheit haben
kann.
BILDRÖHRE
1. Die Leitungsausgangsstufe kann Spannungen von
mehr als 25 kV entwickeln; wenn die
Höchstspannungskappe entfernt werden muss,
entladen Sie die Anode zum Gehäuse über einen
hochohmigen Widerstand, bevor Sie sie aus der
Bildröhre entfernen.
2. Hochspannung sollte immer auf den festgelegten
Wert des Gehäuses beschränkt bleiben und nicht
mehr. Betrieb bei höherer Spannung kann zum
Versagen der Bildröhre oder zu hoher
Spannungszufuhr führen und kann unter Umständen
auch Röntgenstrahlung hervorbringen, die leicht über
dem Konstruktionsniveau liegt. Die Hochspannung
darf auf keinen Fall 29 kV am Gehäuse überschreiten
(außer bei Projektionsfernsehern).
3. Die Hauptquelle der Röntgenstrahlung im Produkt ist
die Bildröhre. Die Bildröhre, die für die oben
erwähnte Funktion in diesem Gehäuse benutzt wird,
ist eine Spezialkonstruktion zur Begrenzung der
Röntgenstrahlung. Um den Schutz vor der
Röntgenstrahlung zu behalten, ersetzen Sie bitte die
Röhre durch denselben Typ wie den ursprünglichen
von HITACHI zugelassenen.
8. Halten Sie die Bildröhre bei der Handhabung vom
Körper weg. Sie dürfen die Bildröhre nur dann
installieren, entfernen oder handhaben, wenn Sie eine
nicht splitternde Schutzbrille tragen. Personen ohne
derartigen Schutz sollten ferngehalten werden,
solange Bildröhren gehandhabt werden.
LASER
Wenn das Produkt einen Laser enthält, setzen Sie sich
keinesfalls direkt dem Strahl aus, wenn die Abdeckung
geöffnet ist oder wenn die Verriegelung versagt.

LVM0065C001
MAIN PCB DR3.1
CRN
PART NUMBER
DESCRIPTION
C28 PCW1035-220 CHIP CAP 22 pF 50V 5% 0805 TYPE NPO
C29 PCW1035-220 CHIP CAP 22 pF 50V 5% 0805 TYPE NPO
C30 PCW1035-220 CHIP CAP 22 pF 50V 5% 0805 TYPE NPO
C401 PCW1035-101 CHIP CAP 100 pF 50V 5% 0805 TYPE NPO
C402 PCW1035-101 CHIP CAP 100 pF 50V 5% 0805 TYPE NPO
C403 PCW1035-101 CHIP CAP 100 pF 50V 5% 0805 TYPE NPO
C404 PCW1035-101 CHIP CAP 100 pF 50V 5% 0805 TYPE NPO
C405 PCW1035-101 CHIP CAP 100 pF 50V 5% 0805 TYPE NPO
C406 PCW1035-101 CHIP CAP 100 pF 50V 5% 0805 TYPE NPO
C407 PCW1035-101 CHIP CAP 100 pF 50V 5% 0805 TYPE NPO
C409 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
C411 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
C413 PCW1035-470 CHIP CAP 47 pF 50V 5% 0805 TYPE NPO
C415 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
C417 PCW1035-470 CHIP CAP 47 pF 50V 5% 0805 TYPE NPO
C419 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
C422 PCW1035-470 CHIP CAP 47 pF 50V 5% 0805 TYPE NPO
C424 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
C425 PCW1035-470 CHIP CAP 47 pF 50V 5% 0805 TYPE NPO
C427 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
C428 PCW3955-224 CHIP CAP 0.22 uF 50V 20% 0805 TYPE Y5V
C429 PCW3955-224 CHIP CAP 0.22 uF 50V 20% 0805 TYPE Y5V
C430 PCW3955-224 CHIP CAP 0.22 uF 50V 20% 0805 TYPE Y5V
C431 PCW3955-224 CHIP CAP 0.22 uF 50V 20% 0805 TYPE Y5V
C432 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
C433 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
C434 PCW3955-473 CHIP CAP 0.047 uF 50V 20% 0805 TYPE Y5V
C436 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
C444 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
C446 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
C448 PCW1035-470 CHIP CAP 47 pF 50V 5% 0805 TYPE NPO
C451 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
C453 PCW1035-470 CHIP CAP 47 pF 50V 5% 0805 TYPE NPO
C456 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
C457 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
C467 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
C470 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
C472 PCW1035-561 CHIP CAP 560 pF 50V 5% 0805 TYPE NPO
C474 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
C477 PCW1035-561 CHIP CAP 560 pF 50V 5% 0805 TYPE NPO
C479 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
C482 PCW1035-561 CHIP CAP 560 pF 50V 5% 0805 TYPE NPO
C484 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
C486 PCW1035-561 CHIP CAP 560 pF 50V 5% 0805 TYPE NPO
C488 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
C490 PCW1035-561 CHIP CAP 560 pF 50V 5% 0805 TYPE NPO
C492 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
C494 PCW1035-561 CHIP CAP 560 pF 50V 5% 0805 TYPE NPO
C496 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
C499 PCW5645-104 CHIP CAP 0.1 uF 50V 10% 0805 TYPE X7R
R20 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R21 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R22 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R34 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
1

CRN
PART NUMBER
DESCRIPTION
R35 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
R36 QCF0152-223 CHIP RES. 22K OHM 1/10W 5% 0805 SMT TYPE
R37 QCF0152-223 CHIP RES. 22K OHM 1/10W 5% 0805 SMT TYPE
R38 QCF0152-562 CHIP RES. 5.6K OHM 1/10W 5% 0805 SMT TYPE
R39 QCF0152-562 CHIP RES. 5.6K OHM 1/10W 5% 0805 SMT TYPE
R401 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
R402 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
R403 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
R404 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
R405 QCF0152-471 CHIP RES. 470 OHM 1/10W 5% 0805 SMT TYPE
R406 QCF0152-332 CHIP RES. 3.3K OHM 1/10W 5% 0805 SMT TYPE
R407 QCF0152-471 CHIP RES. 470 OHM 1/10W 5% 0805 SMT TYPE
R408 QCF0152-332 CHIP RES. 3.3K OHM 1/10W 5% 0805 SMT TYPE
R409 QCF0152-202 CHIP RES. 2K OHM 1/10W 5% 0805 SMT TYPE
R410 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
R411 QCF0152-153 CHIP RES. 15K OHM 1/10W 5% 0805 SMT TYPE
R412 QCF0152-153 CHIP RES. 15K OHM 1/10W 5% 0805 SMT TYPE
R413 QCF0152-153 CHIP RES. 15K OHM 1/10W 5% 0805 SMT TYPE
R414 QCF0152-153 CHIP RES. 15K OHM 1/10W 5% 0805 SMT TYPE
R415 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
R416 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
R417 QCF0152-104 CHIP RES. 100K OHM 1/10W 5% 0805 SMT TYPE
R418 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
R419 QCF0152-104 CHIP RES. 100K OHM 1/10W 5% 0805 SMT TYPE
R420 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R421 QCF0152-472 CHIP RES. 4.7K OHM 1/10W 5% 0805 SMT TYPE
R422 QCF0152-472 CHIP RES. 4.7K OHM 1/10W 5% 0805 SMT TYPE
R423 QCF0152-104 CHIP RES. 100K OHM 1/10W 5% 0805 SMT TYPE
R424 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
R425 QCF0152-104 CHIP RES. 100K OHM 1/10W 5% 0805 SMT TYPE
R426 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R427 QCF0152-472 CHIP RES. 4.7K OHM 1/10W 5% 0805 SMT TYPE
R429 QCF0152-563 CHIP RES. 56K OHM 1/10W 5% 0805 SMT TYPE
R430 QCF0152-563 CHIP RES. 56K OHM 1/10W 5% 0805 SMT TYPE
R431 QCF0152-563 CHIP RES. 56K OHM 1/10W 5% 0805 SMT TYPE
R432 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
R433 QCF0152-123 CHIP RES. 12K OHM 1/10W 5% 0805 SMT TYPE
R434 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
R435 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
R436 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
R437 QCF0152-123 CHIP RES. 12K OHM 1/10W 5% 0805 SMT TYPE
R438 QCF0152-123 CHIP RES. 12K OHM 1/10W 5% 0805 SMT TYPE
R439 QCF0152-104 CHIP RES. 100K OHM 1/10W 5% 0805 SMT TYPE
R440 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
R441 QCF0152-223 CHIP RES. 22K OHM 1/10W 5% 0805 SMT TYPE
R442 QCF0152-472 CHIP RES. 4.7K OHM 1/10W 5% 0805 SMT TYPE
R443 QCF0152-223 CHIP RES. 22K OHM 1/10W 5% 0805 SMT TYPE
R444 QCF0152-104 CHIP RES. 100K OHM 1/10W 5% 0805 SMT TYPE
R445 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
R446 QCF0152-223 CHIP RES. 22K OHM 1/10W 5% 0805 SMT TYPE
R447 QCF0152-472 CHIP RES. 4.7K OHM 1/10W 5% 0805 SMT TYPE
R448 QCF0152-223 CHIP RES. 22K OHM 1/10W 5% 0805 SMT TYPE
R449 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R450 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R453 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
2

CRN
PART NUMBER
DESCRIPTION
R454 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
R455 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R456 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R457 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R458 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R459 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R460 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R461 QCF0152-223 CHIP RES. 22K OHM 1/10W 5% 0805 SMT TYPE
R462 QCF0152-223 CHIP RES. 22K OHM 1/10W 5% 0805 SMT TYPE
R463 QCF0152-223 CHIP RES. 22K OHM 1/10W 5% 0805 SMT TYPE
R464 QCF0152-223 CHIP RES. 22K OHM 1/10W 5% 0805 SMT TYPE
R465 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R468 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R469 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
R470 QCF0152-152 CHIP RES. 1.5K OHM 1/10W 5% 0805 SMT TYPE
R471 QCF0152-272 CHIP RES. 2.7K OHM 1/10W 5% 0805 SMT TYPE
R472 QCF0152-152 CHIP RES. 1.5K OHM 1/10W 5% 0805 SMT TYPE
R473 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
R474 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R475 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
R476 QCF0152-152 CHIP RES. 1.5K OHM 1/10W 5% 0805 SMT TYPE
R477 QCF0152-272 CHIP RES. 2.7K OHM 1/10W 5% 0805 SMT TYPE
R478 QCF0152-152 CHIP RES. 1.5K OHM 1/10W 5% 0805 SMT TYPE
R479 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
R480 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R481 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
R482 QCF0152-152 CHIP RES. 1.5K OHM 1/10W 5% 0805 SMT TYPE
R483 QCF0152-202 CHIP RES. 2K OHM 1/10W 5% 0805 SMT TYPE
R484 QCF0152-152 CHIP RES. 1.5K OHM 1/10W 5% 0805 SMT TYPE
R485 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
R486 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R487 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
R488 QCF0152-152 CHIP RES. 1.5K OHM 1/10W 5% 0805 SMT TYPE
R489 QCF0152-202 CHIP RES. 2K OHM 1/10W 5% 0805 SMT TYPE
R490 QCF0152-152 CHIP RES. 1.5K OHM 1/10W 5% 0805 SMT TYPE
R491 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
R492 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R493 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
R494 QCF0152-152 CHIP RES. 1.5K OHM 1/10W 5% 0805 SMT TYPE
R495 QCF0152-202 CHIP RES. 2K OHM 1/10W 5% 0805 SMT TYPE
R496 QCF0152-152 CHIP RES. 1.5K OHM 1/10W 5% 0805 SMT TYPE
R497 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
R498 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R499 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
R4100 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R4101 QCF0152-152 CHIP RES. 1.5K OHM 1/10W 5% 0805 SMT TYPE
R4102 QCF0152-202 CHIP RES. 2K OHM 1/10W 5% 0805 SMT TYPE
R4103 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
R4104 QCF0152-223 CHIP RES. 22K OHM 1/10W 5% 0805 SMT TYPE
R4105 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R4106 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R4110 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R4111 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R4112 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R4113 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
3

CRN
PART NUMBER
DESCRIPTION
R4114 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R4115 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R4116 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
IC401 RCI4052-001 IC 16 PIN TC4052BFN CHIP 4 CH MULTIPLEXER
IC402 RCI4558-001 IC 8 PIN JRC4558D JRC OP AMP (SMD)
IC403 RCI4558-001 IC 8 PIN JRC4558D JRC OP AMP (SMD)
IC404 RCI4558-001 IC 8 PIN JRC4558D JRC OP AMP (SMD)
IC405 RCI4053-001 IC 16 PIN TC4053BFN CHIP
IC406 RCI4053-001 IC 16 PIN TC4053BFN CHIP
IC407 RCI4558-001 IC 8 PIN JRC4558D JRC OP AMP (SMD)
IC408 RCI6244-001 IC 42 PIN M62446FP
IC409 RCI4558-001 IC 8 PIN JRC4558D JRC OP AMP (SMD)
IC410 RCI4558-001 IC 8 PIN JRC4558D JRC OP AMP (SMD)
IC411 RCI4558-001 IC 8 PIN JRC4558D JRC OP AMP (SMD)
RB101 CCN2032-L15 CONNECTOR TUC-P15X-B1 SIDE PITCH=2.0 mm
CN102# CL150GBEGBE SHLD CABLE 150 mm BLACK 75 OHM UL1354
JK002 CTP0006-001 ANT JACK 2P+ANT PLUG AJ-2016-040
CF101 JFR7047-009 CER FILTER 10.7 MHZ MURATA SFE-10.7MA
CF102 JFR7047-012 CER FILTER MURATA SFE-10.7MS3 10.7MHZ
CF103 JFR6067-102 CER FILTER 450 KHZ MIDIS SFU450B
CF104 JRD5588-005 CER FILTER CDA10.7MG-18A
CF105 JRN6078-110 RESONATOR MIDAS CRB456F18
16 GTN0040-001 PCB BKT AM715D
TC102 MCT0520-005 COND TRIM 4.2 - 20 PF N450
TC103 MCT0510-006 COND TRIM 3 - 10 PF NP0
C012 PVD3545-223 COND DISC 0.022 uF 50V 10%
C101 PVD3545-223 COND DISC 0.022 uF 50V 10%
C104 PVD3545-223 COND DISC 0.022 uF 50V 10%
C107 PVD1385-309 COND DISC 3 pF 50V +-0.25pF NP0 HI PITCH=5 mm
C108 PRP3935-391 COND POLY 390 pF 50V 5%
C111 PVD4965-473 COND DISC 0.047 uF 50V +80-20% Z5V,II
C112 PVD4965-473 COND DISC 0.047 uF 50V +80-20% Z5V,II
C113 PVD4965-473 COND DISC 0.047 uF 50V +80-20% Z5V,II
C115 PVD4965-473 COND DISC 0.047 uF 50V +80-20% Z5V,II
C116 PVD1335-470 COND DISC 47 pF 50V 5% NP0
C119 PVD3545-223 COND DISC 0.022 uF 50V 10%
C120 PVD1335-101 COND DISC 100 pF 50V 5% NP0
C121 PVD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C122 PVD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C123 PVD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C126 PVD3545-103 COND DISC 0.01 uF 50V 10% Y5P,II
C140 PVD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C142 PVD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C143 PVD1335-250 COND DISC 25 pF 50V 5% NP0
C144 PVD1335-180 COND DISC 18 pF 50V 5% NP0
C147 PVD3545-223 COND DISC 0.022 uF 50V 10%
C148 PVD3545-223 COND DISC 0.022 uF 50V 10%
C149 PVD3545-223 COND DISC 0.022 uF 50V 10%
C150 PVD3545-223 COND DISC 0.022 uF 50V 10%
C150 PVD3545-223 COND DISC 0.022 uF 50V 10%
C152 PVD3545-203 COND DISC 0.02 uF 50V 10% Y5P
C155 PVD3545-203 COND DISC 0.02 uF 50V 10% Y5P
C157 PVD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C159 PVD3545-103 COND DISC 0.01 uF 50V 10% Y5P,II
C160 PVD1335-101 COND DISC 100 pF 50V 5% NP0
4

CRN
PART NUMBER
DESCRIPTION
C164 PVD3545-331 COND DISC 330 pF 50V 10% Y5P,II, PITCH=5 mm
C167 PVD3545-561 COND DISC 560 pF 50V 10% Y5P/B
C168 PVD1335-330 COND DISC 33 pF 50V 5% NP0
C169 PVD1335-330 COND DISC 33 pF 50V 5% NP0
C173 PVD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
IC101-T RHI8132-001 IC 24 PIN TA8132AN TOSHIBA 3V AM/FM IF+MPX
IC102-T RCI9257-001 IC 20 PIN TC9257F TOSHIBA
IC103-T RCI7272-002 IC 24 PIN LC72720NM
XL101-T JQC6070-433 CRYSTAL 4.332 MHZ
XL102-T JQC6070-720 CRYSTAL 7.2000 MHZ HC-49/U
VD102 RHT6066-011 DIODE TUNG AM TOSHIBA 1SV149B
VD103 RHT6066-011 DIODE TUNG AM TOSHIBA 1SV149B
L105 SHC7414-393 CHOKE 39 mH
L106 SHC7414-393 CHOKE 39 mH
L101 SHV0491-101 ANT OSC AM 4-6:10T 1-3:86T COILS:R2523-0A10
T101 SHV2020-201 OSC AM 108uH (796 KHz) COIL R2523-0H07-502522
T101# DTB0003-013 TUBING SRK DIA=3 L=13 mm BLACK 50% SHRINKAGE UL
T102 SHI9724-049 IFT AM 455KHZ Q:105+/_20% 1-2:86T 2-3:59T
T103 SHV1492-001 FILTER SUMIDA KM-10DF
WTP0001-003 TUNER PACK SEO BONG FTA4-460V FM F/E TUNER
5

LVF0064C001
94VO MPEG PCB DR3.1
CRN
PART NUMBER
DESCRIPTION
C039 PCW1035-470 CHIP CAP 47 pF 50V 5% 0805 TYPE NPO
C408 PRE3953-470 COND ELECT 47 uF 25V 20% 85'C
C410 PRE3953-470 COND ELECT 47 uF 25V 20% 85'C
C412 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C414 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C416 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C418 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C420 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C421 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C423 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C426 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C435 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C437 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C438 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C439 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C440 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C441 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C442 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C443 PRE3953-470 COND ELECT 47 uF 25V 20% 85'C
C445 PRE3953-470 COND ELECT 47 uF 25V 20% 85'C
C447 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C449 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C450 PRE3953-470 COND ELECT 47 uF 25V 20% 85'C
C452 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C454 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C455 PRE3953-470 COND ELECT 47 uF 25V 20% 85'C
C458 PRE3953-470 COND ELECT 47 uF 25V 20% 85'C
C459 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C460 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C461 PRM3737-822 COND MYLAR 0.0082 uF 100V 5%
C462 PRM3737-153 COND MYLAR 0.015 uF 100V 5%
C463 PDP3937-474 COND MPEM 0.47 uF 100V 5% MINI SIZE CAMEL:MPEM
C464 PRM3737-822 COND MYLAR 0.0082 uF 100V 5%
C465 PRM3737-153 COND MYLAR 0.015 uF 100V 5%
C466 PDP3937-474 COND MPEM 0.47 uF 100V 5% MINI SIZE CAMEL:MPEM
C468 PRE3953-470 COND ELECT 47 uF 25V 20% 85'C
C469 PRE3953-470 COND ELECT 47 uF 25V 20% 85'C
C471 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C473 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C475 PRE3953-470 COND ELECT 47 uF 25V 20% 85'C
C476 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C478 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C480 PRE3953-470 COND ELECT 47 uF 25V 20% 85'C
C481 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C483 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C485 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C487 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C489 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C491 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C493 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C495 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C498 PRE3953-101 COND ELECT 100 uF 25V 20% 85'C
C501 PRD3545-472 COND DISC 4700 pF 50V 10% Y5P,II
C502 PRD3545-472 COND DISC 4700 pF 50V 10% Y5P,II
6

CRN
PART NUMBER
DESCRIPTION
C503 PRD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C504 PRD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C505 PRD3545-472 COND DISC 4700 pF 50V 10% Y5P,II
C506 PRD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C507 PRD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C508 PRD3545-472 COND DISC 4700 pF 50V 10% Y5P,II
C509 PRD3545-472 COND DISC 4700 pF 50V 10% Y5P,II
C510 PRD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C511 PRD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C512 PRM3737-104 COND MYLAR 0.1 uF 100V 5%
C513 PRM3737-104 COND MYLAR 0.1 uF 100V 5%
C514 PRM3737-104 COND MYLAR 0.1 uF 100V 5%
C515 PRM3737-104 COND MYLAR 0.1 uF 100V 5%
C516 PRM3737-104 COND MYLAR 0.1 uF 100V 5%
C517 PRD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C518 PRD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C519 PRD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C520 PRD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C521 PRD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C523 PRE3953-470 COND ELECT 47 uF 25V 20% 85'C
C524 PRE3955-479 COND ELECT 4.7 uF 50V 20% 85'C
C901 PRM3737-223 COND MYLAR 0.022 uF 100V 5%
C902 PRM3737-223 COND MYLAR 0.022 uF 100V 5%
C903 PRM3737-223 COND MYLAR 0.022 uF 100V 5%
C904 PRM3737-223 COND MYLAR 0.022 uF 100V 5%
C905 PVE3953-682 COND ELECT 6800 uF 25V 20%
C906 PRE3955-101 COND ELECT 100 uF 50V 20% 8x12mm 85'C
C907 PVE3953-682 COND ELECT 6800 uF 25V 20%
C915 PRD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C917 PRD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C919 PRE3953-221 COND ELECT 220 uF 25V 20% 85'C
C920 PRE3953-221 COND ELECT 220 uF 25V 20% 85'C
C921 PRD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C922 PRE3953-221 COND ELECT 220 uF 25V 20% 85'C
C923 PRD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C924 PRM3737-223 COND MYLAR 0.022 uF 100V 5%
C925 PRM3737-223 COND MYLAR 0.022 uF 100V 5%
C926 PVE3953-332 COND ELECT 3300 uF 25V 20% 16x25mm P=7.5mm L=10
C927 PRD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C928 PRE3953-221 COND ELECT 220 uF 25V 20% 85'C
C929 PRD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C930 PRE3953-221 COND ELECT 220 uF 25V 20% 85'C
C931 PRE3953-221 COND ELECT 220 uF 25V 20% 85'C
C932 PRD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C933 PRM3737-223 COND MYLAR 0.022 uF 100V 5%
C934 PRM3737-223 COND MYLAR 0.022 uF 100V 5%
C935 PVE3953-222 COND ELECT 2200 uF 25V 20% 13x25mm P=5mm L=10mm
C936 PRD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C937 PRD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C938 PRE3953-471 COND ELECT 470 uF 25V 20% 85'C
C939 PRE3953-221 COND ELECT 220 uF 25V 20% 85'C
C940 PRE3953-221 COND ELECT 220 uF 25V 20% 85'C
C941 PRE3953-221 COND ELECT 220 uF 25V 20% 85'C
C942 PRE3955-101 COND ELECT 100 uF 50V 20% 8x12mm 85'C
C943 PRM3737-223 COND MYLAR 0.022 uF 100V 5%
7

CRN
PART NUMBER
DESCRIPTION
C944 PRM3737-223 COND MYLAR 0.022 uF 100V 5%
C945 PVE3953-332 COND ELECT 3300 uF 25V 20% 16x25mm P=7.5mm L=10
C946 PRD4965-104 COND DISC 0.1 uF 50V +80-20% II Z5V
C947 PRE3955-339 COND ELECT 3.3 uF 50V 20% 85'C
C1002 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1003 PCW3955-102 CHIP CAP 1000 pF 50V 20% 0805 TYPE Y5V
C1004 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1006 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1007 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1009 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1010 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1011 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1013 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1014 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1016 PCW3955-103 CHIP CAP 0.01 uF 50V 20% 0805 TYPE Y5V
C1017 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1018 PCW3955-103 CHIP CAP 0.01 uF 50V 20% 0805 TYPE Y5V
C1019 PCW3955-103 CHIP CAP 0.01 uF 50V 20% 0805 TYPE Y5V
C1020 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1021 PCW3955-103 CHIP CAP 0.01 uF 50V 20% 0805 TYPE Y5V
C1022 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1024 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1025 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1026 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1028 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1029 PCW1035-151 CHIP CAP 150 pF 50V 5% 0805 TYPE NPO
C1030 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1031 PCW1035-220 CHIP CAP 22 pF 50V 5% 0805 TYPE NPO
C1033 PCW1035-220 CHIP CAP 22 pF 50V 5% 0805 TYPE NPO
C1034 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1035 PCW3955-103 CHIP CAP 0.01 uF 50V 20% 0805 TYPE Y5V
C1036 PCW3955-103 CHIP CAP 0.01 uF 50V 20% 0805 TYPE Y5V
C1037 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1038 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1039 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1040 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1041 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1043 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1044 PCW1035-331 CHIP CAP 330 pF 50V 5% 0805 TYPE NPO
C1045 PCW1035-221 CHIP CAP 220 pF 50V 5% 0805 TYPE NPO
C1046 PCW1035-331 CHIP CAP 330 pF 50V 5% 0805 TYPE NPO
C1047 PCW1035-221 CHIP CAP 220 pF 50V 5% 0805 TYPE NPO
C1048 PCW1035-331 CHIP CAP 330 pF 50V 5% 0805 TYPE NPO
C1049 PCW1035-221 CHIP CAP 220 pF 50V 5% 0805 TYPE NPO
C1050 PCW1035-331 CHIP CAP 330 pF 50V 5% 0805 TYPE NPO
C1051 PCW1035-221 CHIP CAP 220 pF 50V 5% 0805 TYPE NPO
C1052 PCW1035-331 CHIP CAP 330 pF 50V 5% 0805 TYPE NPO
C1053 PCW1035-221 CHIP CAP 220 pF 50V 5% 0805 TYPE NPO
C1054 PCW1035-331 CHIP CAP 330 pF 50V 5% 0805 TYPE NPO
C1055 PCW1035-221 CHIP CAP 220 pF 50V 5% 0805 TYPE NPO
C1056 PCW1035-101 CHIP CAP 100 pF 50V 5% 0805 TYPE NPO
C1057 PCW1035-101 CHIP CAP 100 pF 50V 5% 0805 TYPE NPO
C1066 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1070 PCW1035-680 CHIP CAP 68 pF 50V 5% 0805 TYPE NPO
C1071 PCW1035-680 CHIP CAP 68 pF 50V 5% 0805 TYPE NPO
8

CRN
PART NUMBER
DESCRIPTION
C1072 PCW1035-680 CHIP CAP 68 pF 50V 5% 0805 TYPE NPO
C1073 PCW1035-680 CHIP CAP 68 pF 50V 5% 0805 TYPE NPO
C1074 PCW1035-680 CHIP CAP 68 pF 50V 5% 0805 TYPE NPO
C1075 PCW1035-680 CHIP CAP 68 pF 50V 5% 0805 TYPE NPO
C1077 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1078 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1080 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1082 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1083 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1085 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1087 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1088 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1090 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1092 PCW3955-103 CHIP CAP 0.01 uF 50V 20% 0805 TYPE Y5V
C1096 PCW3955-103 CHIP CAP 0.01 uF 50V 20% 0805 TYPE Y5V
C1099 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1106 PCW3955-103 CHIP CAP 0.01 uF 50V 20% 0805 TYPE Y5V
C1107 PCW3955-103 CHIP CAP 0.01 uF 50V 20% 0805 TYPE Y5V
C1108 PCW1035-470 CHIP CAP 47 pF 50V 5% 0805 TYPE NPO
C1108 PCW1035-561 CHIP CAP 560 pF 50V 5% 0805 TYPE NPO
C1109 PCW3955-103 CHIP CAP 0.01 uF 50V 20% 0805 TYPE Y5V
C1110 PCW3955-103 CHIP CAP 0.01 uF 50V 20% 0805 TYPE Y5V
C1111 PCW1035-561 CHIP CAP 560 pF 50V 5% 0805 TYPE NPO
C1111 PCW1035-561 CHIP CAP 560 pF 50V 5% 0805 TYPE NPO
C1112 PCW3955-103 CHIP CAP 0.01 uF 50V 20% 0805 TYPE Y5V
C1113 PCW3955-103 CHIP CAP 0.01 uF 50V 20% 0805 TYPE Y5V
C1114 PCW1035-561 CHIP CAP 560 pF 50V 5% 0805 TYPE NPO
C1114 PCW1035-561 CHIP CAP 560 pF 50V 5% 0805 TYPE NPO
C1115 PCW3955-103 CHIP CAP 0.01 uF 50V 20% 0805 TYPE Y5V
C1116 PCW3955-103 CHIP CAP 0.01 uF 50V 20% 0805 TYPE Y5V
C1117 PCW1035-561 CHIP CAP 560 pF 50V 5% 0805 TYPE NPO
C1117 PCW1035-561 CHIP CAP 560 pF 50V 5% 0805 TYPE NPO
C1118 PCW3955-103 CHIP CAP 0.01 uF 50V 20% 0805 TYPE Y5V
C1119 PCW3955-103 CHIP CAP 0.01 uF 50V 20% 0805 TYPE Y5V
C1120 PCW1035-561 CHIP CAP 560 pF 50V 5% 0805 TYPE NPO
C1120 PCW1035-561 CHIP CAP 560 pF 50V 5% 0805 TYPE NPO
C1121 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1122 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1123 PCW5645-562 CHIP CAP 0.0056 uF 50V 10% 0805 TYPE X7R
C1124 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1126 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1128 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1129 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1130 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1131 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1133 PCW5645-823 CHIP CAP 0.082 uF 50V 10% 0805 TYPE X7R
C1134 PCW5645-823 CHIP CAP 0.082 uF 50V 10% 0805 TYPE X7R
C1136 PCW5645-823 CHIP CAP 0.082 uF 50V 10% 0805 TYPE X7R
C1137 PCW5645-823 CHIP CAP 0.082 uF 50V 10% 0805 TYPE X7R
C1139 PCW5645-823 CHIP CAP 0.082 uF 50V 10% 0805 TYPE X7R
C1140 PCW5645-823 CHIP CAP 0.082 uF 50V 10% 0805 TYPE X7R
C1142 PCW5645-823 CHIP CAP 0.082 uF 50V 10% 0805 TYPE X7R
C1143 PCW5645-823 CHIP CAP 0.082 uF 50V 10% 0805 TYPE X7R
C1145 PCW5645-823 CHIP CAP 0.082 uF 50V 10% 0805 TYPE X7R
C1146 PCW5645-823 CHIP CAP 0.082 uF 50V 10% 0805 TYPE X7R
9

CRN
PART NUMBER
DESCRIPTION
C1148 PCW5645-562 CHIP CAP 0.0056 uF 50V 10% 0805 TYPE X7R
C1149 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1151 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1153 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1154 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1155 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1156 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1163 PCW1035-470 CHIP CAP 47 pF 50V 5% 0805 TYPE NPO
C1164 PCW1035-470 CHIP CAP 47 pF 50V 5% 0805 TYPE NPO
C1166 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1168 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1172 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1174 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1179 PCW1035-331 CHIP CAP 330 pF 50V 5% 0805 TYPE NPO
C1180 PCW1035-331 CHIP CAP 330 pF 50V 5% 0805 TYPE NPO
C1181 PCW1035-331 CHIP CAP 330 pF 50V 5% 0805 TYPE NPO
C1182 PCW1035-331 CHIP CAP 330 pF 50V 5% 0805 TYPE NPO
C1183 PCW1035-331 CHIP CAP 330 pF 50V 5% 0805 TYPE NPO
C1184 PCW1035-331 CHIP CAP 330 pF 50V 5% 0805 TYPE NPO
C1185 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1186 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1187 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
C1188 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1189 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1190 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1191 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1192 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1193 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1194 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1195 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1196 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1197 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1198 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1199 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1200 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1201 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1202 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1203 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1204 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1205 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1206 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1207 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1208 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1209 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1210 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1211 PCW1035-270 CHIP CAP 27 pF 50V 5% 0805 TYPE NPO
C1255 PCW3955-104 CHIP CAP 0.1 uF 50V 20% 0805 TYPE Y5V
CN001 CCN2032-015 CONNECTOR TUC-P15P-B1 TOP PITCH=2.0 mm
CN201 CCN7879-030 CONNECTOR 10 PIN PITCH=2.0mm B10B-PH-K TOP BASE
CN301 CCN7879-027 CONNECTOR 7 PIN PITCH=2.0mm B7B-PH-K TOP BASE
CN601A CCN2032-015 CONNECTOR TUC-P15P-B1 TOP PITCH=2.0 mm
CN902 CCN1500-033 CONNECTOR B9B-XH-A 9 PIN POST BASE TOP P=2.5
CN903 CCN3962-003 CONNECTOR 3 PIN CL3962WVO POST BASE TOP P=3.96
CN904 CCN7879-025 CONNECTOR 5 PIN PITCH=2.0mm B5B-PH-K TOP BASE
D401 RAD4148-001 DIODE SW 1N4148
10

CRN
PART NUMBER
DESCRIPTION
D501 RAD4148-001 DIODE SW 1N4148
D502 RAD4148-001 DIODE SW 1N4148
D503 RAD4148-001 DIODE SW 1N4148
D504 RAD4148-001 DIODE SW 1N4148
D507 RAZ0859-071 DIODE ZENR 6.0-6.3V 0.5W HITACHI HZ6C-2
D508 RAD4148-001 DIODE SW 1N4148
D509 RAD4148-001 DIODE SW 1N4148
D510 RAD4148-001 DIODE SW 1N4148
D901 RHD0802-001 RECTIFIER KBU8B 8A 100V
D906 RHD5401-001 RECTIFIER 1N5401 3.0 A 70 V
D907 RHD5401-001 RECTIFIER 1N5401 3.0 A 70 V
D908 RAD4001-001 RECTIFIER 1N4001 1A 35VRMS
D909 RAD4001-001 RECTIFIER 1N4001 1A 35VRMS
D910 RHD5401-001 RECTIFIER 1N5401 3.0 A 70 V
D911 RAD4001-001 RECTIFIER 1N4001 1A 35VRMS
D912 RAD4001-001 RECTIFIER 1N4001 1A 35VRMS
D913 RAD4001-001 RECTIFIER 1N4001 1A 35VRMS
D914 RAD4148-001 DIODE SW 1N4148
D915 RAD4001-001 RECTIFIER 1N4001 1A 35VRMS
D916 RAD4001-001 RECTIFIER 1N4001 1A 35VRMS
D917 RAD5392-001 RECTIFIER 1N5392 1.5 A 70 VRMS
ZD401 RAZ0859-073 DIODE ZENR 6.9-7.2V 0.5W HITACHI HZ7B-2
ZD402 RAZ0859-073 DIODE ZENR 6.9-7.2V 0.5W HITACHI HZ7B-2
F901 KSA2630-104 FUSE 6.3A 250V SLOW 5x20mm RUL/VDE
F901# CFC2557-001 FUSE CLIP DIA5xL20mm FUSE
F902 KSA2630-104 FUSE 6.3A 250V SLOW 5x20mm RUL/VDE
F902# CFC2557-001 FUSE CLIP DIA5xL20mm FUSE
F905 KSA2160-104 FUSE 1.6A 250V SLOW 5x20mm RUL/VDE
F905# CFC2557-001 FUSE CLIP DIA5xL20mm FUSE
F906 KSA2160-104 FUSE 1.6A 250V SLOW 5x20mm RUL/VDE
F906# CFC2557-001 FUSE CLIP DIA5xL20mm FUSE
F907 KSA2160-104 FUSE 1.6A 250V SLOW 5x20mm RUL/VDE
F907# CFC2557-001 FUSE CLIP DIA5xL20mm FUSE
F908 KSA2160-104 FUSE 1.6A 250V SLOW 5x20mm RUL/VDE
F908# CFC2557-001 FUSE CLIP DIA5xL20mm FUSE
IC103 RCI5122-001 IC 50 PIN SDRAM 512*2*16 YUNDAI'S OR LG'S IC
IC104 RCI5122-001 IC 50 PIN SDRAM 512*2*16 YUNDAI'S OR LG'S IC
IC105 RCI7437-002 IC 20 PIN 74HC374
IC106 RCI7437-002 IC 20 PIN 74HC374
IC107 RCI4408-002 IC 208 PIN ES4408 W/DTS
IC109 RCI4955-001 IC 48 PIN CS4955-CQ
IC110 RCI4340-001 IC 16 PIN CS4340 CRYSTAL'S DAC
IC111 RCI4340-001 IC 16 PIN CS4340 CRYSTAL'S DAC
IC112 RCI4340-001 IC 16 PIN CS4340 CRYSTAL'S DAC
IC113 RCI4408-002 IC 208 PIN ES4408 W/DTS
IC114 RCI4408-002 IC 208 PIN ES4408 W/DTS
IC115 RCI4408-002 IC 208 PIN ES4408 W/DTS
IC116 RCI4408-002 IC 208 PIN ES4408 W/DTS
IC117 RCI4408-002 IC 208 PIN ES4408 W/DTS
IC118 RCI4408-002 IC 208 PIN ES4408 W/DTS
IC119 RCI4408-002 IC 208 PIN ES4408 W/DTS
IC120 RCI4052-001 IC 16 PIN TC4052BFN CHIP 4 CH MULTIPLEXER
IC122 RCI7404-001 IC 14 PIN TC74HC04AFN TOSHIBA
IC501 RHI7265-001 IC 11 PIN TDA7265 SGS THOMSON 25+25 POWER IC
IC502 RHI7265-001 IC 11 PIN TDA7265 SGS THOMSON 25+25 POWER IC
11

CRN
PART NUMBER
DESCRIPTION
IC503 RHI7265-001 IC 11 PIN TDA7265 SGS THOMSON 25+25 POWER IC
IC901 RHI7812-001 IC 3 PIN 7812 12V 1A REGULATOR
IC901# GAL0052C001 HEAT SINK AL DR3.1
IC902 RHI7912-001 IC 3 PIN 7912 REGULATOR
IC902# GAL0052C001 HEAT SINK AL DR3.1
IC903 RHI7806-001 IC 3 PIN AN7806(MATSUSHITA) (5V2)
IC903# GAL0051C001 HEAT SINK AL DR3.1
IC905 RHI7805-005 IC 3 PIN BA05T ROHM
GAL0025C001 HEAT SINK HEAT SINK 1 DR3.1
JK105 CTP0008-006 RCA JACK 1P BLACK W/GEND PIN RJ-1081-01-0341A
JK106 CJT0002-001 TOSK. JACK TOTX178A(TRANSPORT) TOSLINK JACK
JK401 CJR6506-001 RCA JACK 6P WHTx3/REDx3 RJ-1074-09-0300A
JK402 CTP0008-001 RCA JACK 1P BLACK RJ-1081-01-0300A
JK501 CJS0010-001 SPK JACK 10P W/SPRING RD-RD-BU-GY-GY/BKx5
JW102 QCF0152-000 CHIP RES. 0 OHM JUMP WIRE 0805 SMT TYPE
JW105 QCF0152-000 CHIP RES. 0 OHM JUMP WIRE 0805 SMT TYPE
JW107 QCF0152-000 CHIP RES. 0 OHM JUMP WIRE 0805 SMT TYPE
JW111 QCF0152-000 CHIP RES. 0 OHM JUMP WIRE 0805 SMT TYPE
L501 SHR6619-001 RF COIL 1 uH MDEC T40818-08
L502 SHR6619-001 RF COIL 1 uH MDEC T40818-08
L503 SHR6619-001 RF COIL 1 uH MDEC T40818-08
L505 SHR6619-001 RF COIL 1 uH MDEC T40818-08
L506 SHR6619-001 RF COIL 1 uH MDEC T40818-08
Q401 RAN2878-001 TRANSISTOR NPN 2SC2878-A (TEI.M)
Q402 RAN2878-001 TRANSISTOR NPN 2SC2878-A (TEI.M)
Q403 RAN2878-001 TRANSISTOR NPN 2SC2878-A (TEI.M)
Q404 RAN0945-001 TRANSISTOR NPN 2SC945P
Q501 RAN0945-001 TRANSISTOR NPN 2SC945P
Q502 RAN0945-001 TRANSISTOR NPN 2SC945P
Q503 RAN0945-001 TRANSISTOR NPN 2SC945P
Q504 RAP0733-001 TRANSISTOR PNP 2SA733Q,P NEC
Q505 RAP0733-001 TRANSISTOR PNP 2SA733Q,P NEC
Q506 RAN0945-001 TRANSISTOR NPN 2SC945P
Q901 RAN2878-001 TRANSISTOR NPN 2SC2878-A (TEI.M)
Q905 RHP0772-001 TRANSISTOR PNP 2SB772P/Q NEC
Q906 RAN2878-001 TRANSISTOR NPN 2SC2878-A (TEI.M)
Q907 RHP0772-001 TRANSISTOR PNP 2SB772P/Q NEC
Q908 RAN2878-001 TRANSISTOR NPN 2SC2878-A (TEI.M)
Q909 RAP0733-001 TRANSISTOR PNP 2SA733Q,P NEC
Q910 RAN0945-001 TRANSISTOR NPN 2SC945P
Q911 RAP0733-001 TRANSISTOR PNP 2SA733Q,P NEC
Q912 RAN0945-001 TRANSISTOR NPN 2SC945P
Q913 RAP0733-001 TRANSISTOR PNP 2SA733Q,P NEC
Q914 RAN0945-001 TRANSISTOR NPN 2SC945P
R26 QAS0450-109 RESISTOR 1 OHM 1/4W 5% FUSIBLE METAL FILM
R27 QAS0450-109 RESISTOR 1 OHM 1/4W 5% FUSIBLE METAL FILM
R28 QAS0450-109 RESISTOR 1 OHM 1/4W 5% FUSIBLE METAL FILM
R451 QAF0450-151 RESISTOR 150 OHM 1/4W 5% CF 340X2151934
R452 QAF0450-151 RESISTOR 150 OHM 1/4W 5% CF 340X2151934
R466 QAF0450-221 RESISTOR 220 OHM 1/4W 5% CF 340X2221934
R467 QAF0450-221 RESISTOR 220 OHM 1/4W 5% CF 340X2221934
R501 QAF0650-561 RESISTOR 560 OHM 1/6W 5% CF
R502 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF
R503 QAF0650-561 RESISTOR 560 OHM 1/6W 5% CF
R504 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF
12

CRN
PART NUMBER
DESCRIPTION
R505 QAF0650-104 RESISTOR 100K OHM 1/6W 5% CF
R506 QAF0650-561 RESISTOR 560 OHM 1/6W 5% CF
R507 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF
R508 QAF0650-561 RESISTOR 560 OHM 1/6W 5% CF
R509 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF
R510 QAF0650-104 RESISTOR 100K OHM 1/6W 5% CF
R511 QAF0650-561 RESISTOR 560 OHM 1/6W 5% CF
R512 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF
R513 QAF0650-561 RESISTOR 560 OHM 1/6W 5% CF
R514 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF
R515 QAF0650-104 RESISTOR 100K OHM 1/6W 5% CF
R516 QAF0450-229 RESISTOR 2.2 OHM 1/4W 5% CF 340X2022934
R517 QAF0450-229 RESISTOR 2.2 OHM 1/4W 5% CF 340X2022934
R518 QAF0450-229 RESISTOR 2.2 OHM 1/4W 5% CF 340X2022934
R519 QAF0450-229 RESISTOR 2.2 OHM 1/4W 5% CF 340X2022934
R520 QAF0450-229 RESISTOR 2.2 OHM 1/4W 5% CF 340X2022934
R522 QAF0650-563 RESISTOR 56K OHM 1/6W 5% CF
R523 QAF0650-224 RESISTOR 220K OHM 1/6W 5% CF
R524 QAF0650-473 RESISTOR 47K OHM 1/6W 5% CF
R525 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF
R526 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF
R527 QAF0650-104 RESISTOR 100K OHM 1/6W 5% CF
R528 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF
R529 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF
R530 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF
R531 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF
R532 QAF0650-123 RESISTOR 12K OHM 1/6W 5% CF
R534 QAF0650-123 RESISTOR 12K OHM 1/6W 5% CF
R535 QAF0650-563 RESISTOR 56K OHM 1/6W 5% CF
R901 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF
R902 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF
R903 QAF0650-223 RESISTOR 22K OHM 1/6W 5% CF
R904 QAF0450-102 RESISTOR 1.0K OHM 1/4W 5% CF 340X2102934
R905 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF
R906 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF
R907 QAF0650-223 RESISTOR 22K OHM 1/6W 5% CF
R908 QAF0450-561 RESISTOR 560 OHM 1/4W 5% CF 340X2561934
R909 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF
R910 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF
R911 QAF0650-223 RESISTOR 22K OHM 1/6W 5% CF
R912 QAF0450-102 RESISTOR 1.0K OHM 1/4W 5% CF 340X2102934
R913 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF
R914 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF
R915 QAF0650-223 RESISTOR 22K OHM 1/6W 5% CF
R916 QAF0650-102 RESISTOR 1K OHM 1/6W 5% CF
R917 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF
R918 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF
R919 QAF0650-223 RESISTOR 22K OHM 1/6W 5% CF
R920 QAF0650-102 RESISTOR 1K OHM 1/6W 5% CF
R921 QAF0650-152 RESISTOR 1.5K OHM 1/6W 5% CF
R922 QAF0250-220 RESISTOR 22 OHM 1/2W 5% CF
R923 QAF0650-682 RESISTOR 6.8K OHM 1/6W 5% CF
R924 QAF0650-152 RESISTOR 1.5K OHM 1/6W 5% CF
R925 QAS0250-109 RESISTOR 1 OHM 1/2W 5% FUSIBLE METAL FILM
R926 QAS0250-109 RESISTOR 1 OHM 1/2W 5% FUSIBLE METAL FILM
13

CRN
PART NUMBER
DESCRIPTION
R1002 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1003 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1004 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1005 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1006 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1007 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1008 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1009 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1010 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1011 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1012 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1013 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1014 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1015 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1016 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1017 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1018 QCF0152-472 CHIP RES. 4.7K OHM 1/10W 5% 0805 SMT TYPE
R1019 QCF0152-472 CHIP RES. 4.7K OHM 1/10W 5% 0805 SMT TYPE
R1020 QCF0152-472 CHIP RES. 4.7K OHM 1/10W 5% 0805 SMT TYPE
R1021 QCF0152-472 CHIP RES. 4.7K OHM 1/10W 5% 0805 SMT TYPE
R1022 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1023 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1024 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1025 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1026 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1027 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1028 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1029 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1030 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1031 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1032 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1033 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
R1047 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1048 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1049 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1050 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1051 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1052 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1053 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1054 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1055 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1056 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1057 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1058 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1059 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1060 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1061 QCF0152-332 CHIP RES. 3.3K OHM 1/10W 5% 0805 SMT TYPE
R1062 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1063 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1064 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1066 QCF0152-472 CHIP RES. 4.7K OHM 1/10W 5% 0805 SMT TYPE
R1067 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R1068 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1069 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R1070 QCF0152-472 CHIP RES. 4.7K OHM 1/10W 5% 0805 SMT TYPE
14

CRN
PART NUMBER
DESCRIPTION
R1071 QCF0152-472 CHIP RES. 4.7K OHM 1/10W 5% 0805 SMT TYPE
R1072 QCF0152-472 CHIP RES. 4.7K OHM 1/10W 5% 0805 SMT TYPE
R1073 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1076 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1077 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1079 QCF0152-229 CHIP RES. 2.2 OHM 1/10W 5% 0805 SMT TYPE
R1080 QCF0152-229 CHIP RES. 2.2 OHM 1/10W 5% 0805 SMT TYPE
R1082 QCF0112-750 CHIP RES. 75 OHM 1/10W 1% 0805 SMT TYPE
R1083 QCF0112-750 CHIP RES. 75 OHM 1/10W 1% 0805 SMT TYPE
R1084 QCF0112-750 CHIP RES. 75 OHM 1/10W 1% 0805 SMT TYPE
R1085 QCF0112-750 CHIP RES. 75 OHM 1/10W 1% 0805 SMT TYPE
R1086 QCF0112-750 CHIP RES. 75 OHM 1/10W 1% 0805 SMT TYPE
R1087 QCF0112-750 CHIP RES. 75 OHM 1/10W 1% 0805 SMT TYPE
R1088 QCF0152-472 CHIP RES. 4.7K OHM 1/10W 5% 0805 SMT TYPE
R1089 QCF0152-472 CHIP RES. 4.7K OHM 1/10W 5% 0805 SMT TYPE
R1090 QCF0152-561 CHIP RES. 560 OHM 1/10W 5% 0805 SMT TYPE
R1091 QCF0152-332 CHIP RES. 3.3K OHM 1/10W 5% 0805 SMT TYPE
R1092 QCF0152-332 CHIP RES. 3.3K OHM 1/10W 5% 0805 SMT TYPE
R1098 QCF0152-332 CHIP RES. 3.3K OHM 1/10W 5% 0805 SMT TYPE
R1100 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R1101 QCF0152-472 CHIP RES. 4.7K OHM 1/10W 5% 0805 SMT TYPE
R1102 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R1103 QCF0152-562 CHIP RES. 5.6K OHM 1/10W 5% 0805 SMT TYPE
R1104 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R1105 QCF0152-472 CHIP RES. 4.7K OHM 1/10W 5% 0805 SMT TYPE
R1106 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R1107 QCF0152-562 CHIP RES. 5.6K OHM 1/10W 5% 0805 SMT TYPE
R1108 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R1109 QCF0152-472 CHIP RES. 4.7K OHM 1/10W 5% 0805 SMT TYPE
R1110 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R1111 QCF0152-562 CHIP RES. 5.6K OHM 1/10W 5% 0805 SMT TYPE
R1112 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R1113 QCF0152-472 CHIP RES. 4.7K OHM 1/10W 5% 0805 SMT TYPE
R1114 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R1115 QCF0152-562 CHIP RES. 5.6K OHM 1/10W 5% 0805 SMT TYPE
R1116 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R1117 QCF0152-472 CHIP RES. 4.7K OHM 1/10W 5% 0805 SMT TYPE
R1118 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R1119 QCF0152-562 CHIP RES. 5.6K OHM 1/10W 5% 0805 SMT TYPE
R1120 QCF0152-243 CHIP RES. 24K OHM 1/10W 5% 0805 SMT TYPE
R1121 QCF0152-243 CHIP RES. 24K OHM 1/10W 5% 0805 SMT TYPE
R1122 QCF0152-243 CHIP RES. 24K OHM 1/10W 5% 0805 SMT TYPE
R1123 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
R1124 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1125 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1131 QCF0152-333 CHIP RES. 33K OHM 1/10W 5% 0805 SMT TYPE
R1132 QCF0152-153 CHIP RES. 15K OHM 1/10W 5% 0805 SMT TYPE
R1134 QCF0152-333 CHIP RES. 33K OHM 1/10W 5% 0805 SMT TYPE
R1135 QCF0152-153 CHIP RES. 15K OHM 1/10W 5% 0805 SMT TYPE
R1137 QCF0152-333 CHIP RES. 33K OHM 1/10W 5% 0805 SMT TYPE
R1138 QCF0152-153 CHIP RES. 15K OHM 1/10W 5% 0805 SMT TYPE
R1140 QCF0152-333 CHIP RES. 33K OHM 1/10W 5% 0805 SMT TYPE
R1141 QCF0152-153 CHIP RES. 15K OHM 1/10W 5% 0805 SMT TYPE
R1143 QCF0152-333 CHIP RES. 33K OHM 1/10W 5% 0805 SMT TYPE
R1144 QCF0152-153 CHIP RES. 15K OHM 1/10W 5% 0805 SMT TYPE
15

CRN
PART NUMBER
DESCRIPTION
R1145 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R1146 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
R1147 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
R1148 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
R1149 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1150 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1151 QCF0152-000 CHIP RES. 0 OHM JUMP WIRE 0805 SMT TYPE
R1152 QCF0152-000 CHIP RES. 0 OHM JUMP WIRE 0805 SMT TYPE
R1153 QCF0152-000 CHIP RES. 0 OHM JUMP WIRE 0805 SMT TYPE
R1154. QCF0152-000 CHIP RES. 0 OHM JUMP WIRE 0805 SMT TYPE
R1157 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
R1158 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
R1159 QCF0152-104 CHIP RES. 100K OHM 1/10W 5% 0805 SMT TYPE
R1160 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R1161 QCF0152-152 CHIP RES. 1.5K OHM 1/10W 5% 0805 SMT TYPE
R1162 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
R1163 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 0805 SMT TYPE
R1164 QCF0152-104 CHIP RES. 100K OHM 1/10W 5% 0805 SMT TYPE
R1165 QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 0805 SMT TYPE
R1166 QCF0152-152 CHIP RES. 1.5K OHM 1/10W 5% 0805 SMT TYPE
R1167 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1168 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1171 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1172 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1173 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1174 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1175 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1176 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1177 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1178 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1179 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
R1180 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
R1181 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
R1182 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
R1183 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
R1184 QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 0805 SMT TYPE
R1245 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1246 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1247 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1248 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1249 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1250 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1251 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1252 QCF0152-101 CHIP RES. 100 OHM 1/10W 5% 0805 SMT TYPE
R1253 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1254 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1255 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1256 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1257 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1258 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1259 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1260 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1261 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1262 QCF0152-330 CHIP RES. 33 OHM 1/10W 5% 0805 SMT TYPE
R1263 QCF0152-472 CHIP RES. 4.7K OHM 1/10W 5% 0805 SMT TYPE
16
