Hitachi 32LD8700C B User manual

GB
D
F
I
Instructions for use
Bedienungsanleitung
Notice d'utilisation
Istruzioniperl'uso
32LD8700C

- 1 -
Contents
Remote Control Buttons ....................... 2
LCD TV .................................................... 3
Preparation ............................................. 5
Features ............................................... 5
Panel Features ..................................... 5
Safety Precautions ................................. 5
Before Switc ing On Your TV ............... 8
Power Connection ................................ 8
Connections To The Aerial Input Socket 8
How To Connect Other evices ........... 8
Inserting Batteries In The Remote Control
Handset ................................................ 8
Switc ing T e TV ON/OFF .................... 8
To switch the TV on: ............................. 8
To switch the TV off: ............................. 8
Initial Settings ........................................ 9
Operating T e TV ................................. 10
Operating with the buttons on the TV
set ....................................................... 10
Operating With Remote Control ......... 10
Everyday Operation ............................. 11
Information Banner ............................. 11
ELECTRONIC PROGRAMME GUI E
(EPG) .................................................. 11
isplaying The Subtitles ..................... 12
Teletext ............................................... 12
IDTV Menu System ............................... 12
Channel List........................................ 13
Installation .......................................... 15
Configuration ...................................... 17
Timers ................................................. 20
TV Setup ............................................. 21
Common Interface .............................. 21
Analogue TV Menu System ................. 22
Picture menu ...................................... 22
Sound menu ....................................... 23
Feature menu ..................................... 24
Install menu ........................................ 25
Program menu .................................... 26
Source menu ...................................... 27
PC Mode ................................................ 27
Installation .......................................... 27
Menu System in PC mode .................. 27
PC Picture Position Menu ................... 27
PC Picture Menu ................................ 28
Sound Menu ....................................... 28
Feature Menu ..................................... 28
Source Menu ...................................... 28
Sound in PC mode ............................. 28
Ot er Features ..................................... 28
TV Status ............................................ 28
Mute Indicator ..................................... 28
PIP and PAP modes ........................... 28
Freeze Picture .................................... 29
Zoom Modes ....................................... 29
Teletext .................................................. 30
To Operate Teletext ............................. 30
To Select A Page Of Teletext .............. 30
To Select Index Page .......................... 30
To Select A Subcode Page ................. 30
PAT (Picture and Text) ........................ 30
To Exit Teletext .................................... 30
To isplay The Time ........................... 30
Fastext ................................................ 31
Connect Perip eral Equipment .......... 31
High efinition .................................... 31
Via The Scart ...................................... 31
Via Aerial Input ................................... 31
ecoder .............................................. 31
TV And Video Recorder ...................... 32
Playback NTSC .................................. 32
Copy Facility ....................................... 32
Search For And Store The Test Signal Of
The Video Recorder ........................... 32
Camera And Camcorder ..................... 32
Connect The ecoder To The Video
Recorder ............................................. 32
Connecting Headphones .................... 32
Connecting Subwoofer ....................... 32
Aerial Connection ................................ 33
Tips ........................................................ 34
Specifications ....................................... 35
Appendix A: PC Input Typical Display
Modes .................................................... 36
Appendix B: DVD Player Selection ..... 37
Appendix C: DVD Player Selection
(continued) ........................................... 38
Appendix D: Main and PIP-PAP Picture
Combinations ....................................... 39
UK Guarantee ....................................... 40
1-ENG-3230W-HL02126 UK-32 INCH TFT (CHM)-PEU IDTV-NEW SOFT-50088657.p65 04.08.2006, 14:421

- 2 -
Remote Control Buttons
= Stand by On/Off
= Program Information
SEL= Select TV/ V /SAT
AV3 = AV3 mode
AV2 = AV2 mode
RGB2 = No Function
RGB1= PC mode
= Go back to previous menu
`
= Cursor Right
OK = Enter
b
=Cursor own
= Picture Mode
P+/ - = Programme Up/ own
= Mute On/Off
0 - 9 = igit buttons
= PIP / PAP / TV
BLUE = Only used in Teletext mode
YELLOW = Only used in Teletext mode
= Reveal
SLI E SHOW /

= No function/ Subtitle
PHOTO = No Function
SWIVEL = No Function
= Aspect ratio
= Teletext On/Off
= Time / Update
= Guide for TT/ Index Page for TV
GREEN = Only used in Teletext mode / Subtitle on/off in the digital mode
RE = PAT (Picture and Text)
= Freeze On/Off
/ = Volume Up/ own

= Mono/Stereo - ual A-B

= Equalizer Sound Mode

_
= Cursor Left
** These buttons can control most Hitachi V Players and Recorders. Please see Page 37

a
= Cursor Up

= Menu On/Off

AV5 =AV5 mode

AV4 = AV4 mode

AV1 = AV1 mode

TT/TV = Select button for igital/Analogue mode
1-ENG-3230W-HL02126 UK-32 INCH TFT (CHM)-PEU IDTV-NEW SOFT-50088657.p65 04.08.2006, 14:422

- 3 -
LCD TV
FRONT VIEW
REAR VIEW
3RZHU&RUG
,QSXW
3RZHU2Q2II
EXWWRQ
1-ENG-3230W-HL02126 UK-32 INCH TFT (CHM)-PEU IDTV-NEW SOFT-50088657.p65 04.08.2006, 14:423

- 4 -
TV/AV button
MENU button
Prog. Up, Prog. own buttons
Volume Up, Volume own buttons
Operate/Standby switch
Power cord input
Power On/Off button
S-VHS Input
Video Input
Audio Inputs
Headphone
Audio Line Outs
Subwoofer Out
PC Audio Input
Aerial
Scart 2 (AV-2)
Scart 1 (AV-1)
H MI Input (AV-5)
Component Audio Inputs
Component Video (YPbPr) Inputs
VGA Input
CI (Common Interface) Slot
AV-4 AV-3
AV-4S
1-ENG-3230W-HL02126 UK-32 INCH TFT (CHM)-PEU IDTV-NEW SOFT-50088657.p65 04.08.2006, 14:424

- 5 -
Preparation
For ventilation, leave a space of at least 10
cm free all around the set. To prevent any
fault and unsafe situations, please do not
place any objects on top of the set.
Use this apparatus in tropical and/or moder-
ate climates.
Features
 Remote controlled colour television.
 Fully integrated igital TV ( VB-T)
 100 programmes from VHF, UHF bands or
cable channels can be preset.
 It can tune cable channels.
 Controlling the TV is very easy by its menu
driven system.
 It has 2 Scart sockets for external devices
(such as video, video games, audio set, etc.)
 3 S Virtual Surround Sound
 Stereo sound system (German+Nicam).
 Full function Teletext .
Fastext (1000 Pages), TOP text.
 Headphone connection.
 irect channel access.
 A.P.S. (Automatic Programming System).
 All programmes can be named.
 Forward or backward automatic tuning.
 Sleep timer.
 Child Lock.
 Automatic sound mute when no transmis-
sion.
 NTSC Playback.
 AV in and S-VHS in are available.
 It has VGA connector for external devices
such as computer.
 It has an H MI connector for igital Video
and Audio. This connection is also designed
to accept High efinition signals.
 It has PIP / PAP / PAT functions.
 AVL (Automatic Volume Limiting)
 TV Picture in PC
 When no valid signal is detected, after 5 min-
utes the TV switches itself automatically to
stand-by mode.
 PLL (Frequency Search)
 PC Input (Support up to WXGA 1366 x 768)
 Stereo PC Audio Input
 Plug&Play for Windows 9X, ME, 2000, XP
 3 Comb Filter
 Audio Line Out
Panel Features
 32-inch TFT LC display.
 High resolution (1366x768)
 Contrast ratio (1000:1 typical)
 Brightness (typical) 550 cd/m2.
 isplay colour 16.7 Million.
Safety Precautions
Please read the following recommended
safety precautions carefully for your safety.
IMPORTANT SAFETY
INFORMATION ON OPERATING
YOUR TV
Dos and Donts
DOs
This Television has been designed and manu-
factured to meet international safety standards,
but like any electrical equipment, care must be
taken if you are to obtain the best results and
safety is to be assured.
DO read the operating instructions before you
attempt to use the equipment.
DO consult your dealer if you are in any doubt
about installation, operation or safety of your
equipment.
DO be careful with glass panels or doors on
equipment.
This TV is supplied with a fitted mains plug. This
plug must not be cut off as it may contain a
special radio interference filter, the removal
of which could lead to impaired performance. If
you wish to extend the lead, obtain an appropri-
ate safety approved extension lead or consult
your dealer.
Observe the manufacturers instructions when
connecting extension leads to the TV. Check
the fuse rating on the new plug, this should be
fitted with a 5 Amp fuse which conforms to either
1-ENG-3230W-HL02126 UK-32 INCH TFT (CHM)-PEU IDTV-NEW SOFT-50088657.p65 04.08.2006, 14:425

- 6 -
ASTA or BSI (BS1 362) approvals, these are
easily identifiable by either the or
symbols. If you are in any doubt about the in-
stallation of an extension lead, please consult a
competent electrician.
DONTs
DONT continue to operate the equipment if you
are in any doubt about it working normally, or if
it is damaged in any way switch off, withdraw the
mains plug and consult your dealer.
DONT place water filled vessels on top of T.V.
cabinets.
DONT remove any fixed cover as this may ex-
pose dangerous voltages.
DONT leave equipment switched on when it is
unattended unless it is specifically stated that it
is designed for unattended operation or has a
stand-by mode. Switch off using the switch on
the equipment and make sure your family know
how to do this. Special arrangements may need
to be made for infirm or handicapped people.
DONT use equipment such as personal ste-
reos or radios so that you are distracted from
the requirements of traffic safety. It is illegal to
watch television whilst driving.
DONT obstruct the ventilation of the equip-
ment, for example with curtains or soft furnish-
ings. Overheating will cause damage and
shorten the life of the equipment.
DONT use makeshift stands and NEVER fix
legs or stands to the TV with any screws other
than those provided - to ensure complete safety
always use the manufacturers approved stand
with the fixings provided.
DONT allow electrical equipment to be ex-
posed to rain or moisture.
ABOVE ALL
 NEVER let anyone, especially children
push anything into holes, slots or any
other opening in the case - this could re-
sult in a fatal electric shock.
 NEVER guess or take chances with elec-
trical equipment of any kind - it is etter to
e safe than sorry!
1. Power Sour e
The set should be operated only from a 220-
240V AC, 50 Hz. outlet. Ensure you select
the correct voltage setting for your conve-
nience.
2. Power Cord
o not place the set, a piece of furniture,etc.
on the power cord(mains lead) or pinch the
cord.Handle the power cord by the plug. o
not pull out the plug by tugging the cord and
never touch the power cord when your hands
are wet as this could cause a short circuit or
electric shock.Never make a knot in the cord
or tie it with other cord.The power cord
should be placed in such a way that they are
not likely to be stepped on.
A damaged power cord can cause fire or
give you an electric shock. When it is dam-
aged and need to be changed, it should be
done by qualified personel.
3. Moisture and Water
o not use this equipment in a humid and
damp place (avoid the bathroom, the sink in
the kitchen, and near the washing machine).
o not expose this equipment to rain or wa-
ter, as this may be dangerous and do not
place objects filled with liquids,such as flower
vases on top of the set. Avoid from dripping
or splashing.
If any solid object or liquid falls into the cabi-
net, unplug the set and have it checked by
qualified personnel before operating it any
further.
4. Cleaning
Before cleaning, unplug the set from the wall
outlet. o not use liquid or aerosol cleaners.
Use soft and dry cloth.
5. Ventilation
The slots and openings on the back cover
are intended for ventilation and to ensure reli-
able operation. To prevent overheating,
these openings must not be blocked or cov-
ered in anyway.
1-ENG-3230W-HL02126 UK-32 INCH TFT (CHM)-PEU IDTV-NEW SOFT-50088657.p65 04.08.2006, 14:426

- 7 -
"T e LCD panel is very ig tec nology
product wit about a million t in film tran-
sistors, giving you fine picture details. Oc-
casionally, a few non-active pixels may
appear on t e screen as a fixed point of
blue, green or red. Please note t at t is
does not affect t e performance of your
product."
DO NOT LEAVE YOUR TV AT STAND-BY
OR OPERATING WHEN YOU LEAVE
YOUR HOUSE
6.Heat and Flames
The set should not be placed near to naked
flames and sources of intense heat,such as
an electric heater. Ensure that no naked
flame sources, such as lighted candles, are
placed on top of the set.
7. Lightning
In case of storm and lightning or when going
on holiday, disconnect the power cord from
the wall outlet.
8. Repla ement Parts
When replacement parts are required, be sure
the service technician has used replacement
parts which are specified by the manufacturer
or have the same specifications as the original
one. Unauthorised substitutions may result in
fire, electrical shock, or other hazards.
9 . Servi ing
Please refer all servicing to qualified person-
nel. o not remove the cover yourself as this
may result in an electric shock.
WARNING: When the device is not in use for
a long time, disconnect from power.
Instructions for waste disposal:
 Packaging and packaging aids are recyclable
and should principally be recycled. Packag-
ing materials, such as foil bag, must be kept
away from children.
 Battery, including those which is heavy metal-
free, should not be disposed of with house-
hold waste. Please dispose of used battery in
an environmentally sound manner. ind out
about the legal regulations which apply in
your area.
 Cold cathode fluoresant lamp in LCD PANEL
contains a small amount of mercury, please
follow local ordinates or regulations for dis-
posal.
 The mains plug is used to disconnect the TV
from the mains and therefore it shall remain
readily operable.
Warning: To prevent injury, this device must
be securely attached to the floor/wall in ac-
cordance with the installation instrutions.
Be sure to ground t e connection properly.
Connect the ground terminal of TV with the ground terminal provided
at the power outlet using the enclosed power cord. If theprovided plug
does not fit your outlet, consult an electrician for replacement
of the obsolete outlet.
1-ENG-3230W-HL02126 UK-32 INCH TFT (CHM)-PEU IDTV-NEW SOFT-50088657.p65 04.08.2006, 14:427

- 8 -
Before Switching On Your
TV
Power Conne tion
IMPORTANT: The TV set is designed to op-
erate on 220-240V AC, 50 Hz.
 After unpacking, allow the TV set to reach the
ambient room temperature before you con-
nect the set to the mains.
Conne tions To The Aerial Input
So ket
 Connect the aerial or cable TV plug to the
Aerial input socket located at the rear of the
TV and connect the cable plug coming out
from the TV out socket located on the devices
(VCR, VB-T etc.) to this socket as well.
How To Conne t Other Devi es
IMPORTANT: Switch off the TV before con-
necting any external device.
Sockets for external connections are at the
rear side of the TV. For connection of other
devices via Scart refer to the manuals of the
related devices.
Inserting Batteries In The Remote
Control Handset
 Remove the battery cover located on the
back of the handset by gently pulling down-
wards from the indicated part.
 Insert two AA/R6 or equivalent type batteries
inside. Place the batteries in the right direc-
tions.
 Replace the battery cover.
NOTE: Remove the batteries from remote
control handset when it is not to be used for
a long period.Otherwise it can be damaged
due to battery leakage.
Switching The TV O /OFF
To swit h the TV on:
Your TV will switch on in two steps:
1- Connect the power supply cord to the sys-
tem. Press Power On/Off switch  located
by the mains input socket. Then the TV
switches itself to stand-by mode and the led
on the front of the TV becomes Red.
2- To switch on the TV from stand-by mode ei-
ther:
Press a digit button on the remote control so
that a programme number is selected,
or,
Press the "-P/CH" or "P/CH+" button at the
right side of the TV or press the P- or P+
button on the remote control, so that last
mode switched off is selected.
By either method the TV will switch on and
the led becomes green.
To swit h the TV off:
 Press the  (stand-by) button on the re-
mote control or Operate/Standby switch at
the right side of the TV, so the TV will switch
to stand-by mode and the GREEN LED will
become RED.
To power down the TV completely, press
Power On/Off button at the rear side of the
TV, or,
Unplug the power cord from the mains
socket.
1-ENG-3230W-HL02126 UK-32 INCH TFT (CHM)-PEU IDTV-NEW SOFT-50088657.p65 04.08.2006, 14:428

- 9 -
Initial Settings
When the TV is turned on for the first time,
I TV is on first. Because this is the first time
that I TV has been used, there are no chan-
nels stored in the memory.
When the TV is turned on for the first time,
the menu for the language selection appears
on the screen. The message Welcome
please select your language! is written in
all language options sequentially in the menu
on the screen.
By pressing or buttons highlight the
language you want to set and press OK
button. In the menu Set Language is written
next to OK item to indicate that Press OK
button to set the highlighted language op-
tion.
You can get information about the menu us-
age by pressing   button. And press  
button again to exit the help menu.
After pressing "OK" the first time Installation
Menu will appear on screen. Press or
buttons, to select country item you want to
set and press OK button.
After the First Time Installation is set, the fol-
lowing message appears on the screen.
<HV 1R
To start automatic search, select Yes, to
cancel select No.
 To select an option Yes or No, highlight
the item by using or buttons and press
OK button.
The I TV will automatically tune to the VHF
and UHF transmission channels looking for
digital terrestrials. TV broadcasts and dis-
playing the names of channels found. This
process will take about five minutes. To can-
cel searching, you can press   button at
any time during the process.
After Automatic Searc process is com-
pleted, the following message asking for ana-
logue channel search appears on the screen.
TV switches to the analogue TV mode.
<HV
'R\RXZDQWWRVHDUFKIRU
DQDORJXHFKDQQHOV"
1R
Press the BLUE button to cancel APS if you
do not want to delete your existing
programme list.
To continue APS, first select the language
and country by pressing
_
/
`
button and then
press the RE or OK button.
After initial APS is finalized, a programme
list will appear on the screen. In the
programme list you will see the programme
numbers and names assigned to the
programmes.
1-ENG-3230W-HL02126 UK-32 INCH TFT (CHM)-PEU IDTV-NEW SOFT-50088657.p65 04.08.2006, 14:429

- 10 -
If you do not accept the locations and / or the
programme names, you can change them in
Programming menu. For details see Program
menu on page 26.
To display channel list in I TV, switch to the
I TV via pressing DTT/TV button. Then
press   button to enter main menu, C an-
nel List will be highlighted press OK button
to enter the menu. For detailed information
see page 13.
Operating The TV
You can operate your TV using both the re-
mote control handset and the buttons on the
set.
Operating with the buttons on the
TV set
Volume setting and programme selection
can be made by using the buttons on the
control panel at the right side of the TV.
Volume Setting
Press the -  button to decrease volume
or the  + button to increase volume, A
volume level scale (slider) will be displayed
at the bottom of the screen.
Programme Selecting
Press the P/CH+ button to select the next
programme or the -P/CH button to select
the previous programme.
Entering T e Menu
Press the MENU button on the control
panel at the side of the TV to enter the menu.
-P/CH / P/CH+ and  + / -  buttons
on the TV are used as navigation buttons in
menu.
AV Mode
Press the TV/AV button on the control
panel at the side of the TV to switch your TV
to AV modes.
Operating With Remote Control
The remote control handset of your TV is de-
signed to control all the functions of your TV.
The functions will be described in accor-
dance with the menu system of your TV.
Functions of the menu system are described
in Menu System section.
Volume Setting
Press the button to increase volume.
Press the button to decrease volume. A
volume level scale (slider) will be displayed
at the bottom of the screen.
Programme Selecting
(Previous or next programme)
 Press the P- button to select the previous
programme.
 Press the P+ button to select the next
programme.
Programme Selecting (direct access):
Press digit buttons on the remote control
handset to select programmes between 0
and 9. The TV will switch to the selected
programme after a short delay.
 For a two digit programme number enter the
second digit after pressing the first digit within
2 seconds.
1-ENG-3230W-HL02126 UK-32 INCH TFT (CHM)-PEU IDTV-NEW SOFT-50088657.p65 04.08.2006, 14:4210

- 11 -
DTT Everyday Operation
Pressing the DTT/TV button at any time
while watching television programmes will
switch the TV set between the digital terres-
trial television broadcasting and the analogue
broadcasting.
Information Banner
 Whenever you change the channel using
the P + or P- buttons or the number but-
tons, TV displays the channel picture along
with an information banner at the bottom of
the screen. This will remain on the screen for
approximately three seconds.
 The information banner can also be dis-
played by pressing the   button at any
time while watching the TV. Pressing the
 button again removes the banner.
The information banner gives a number of
facts on the channel selected and the
programme on it:
 The name of the channel is displayed along
with its channel list number and an indication
of the strength of the signal received on this
channel.
 The current and next programme informa-
tion are given with the start and finish time.
 The current time information is displayed
along with channel name.
Hint
Not all channels broadcast the programme
data. If the name and times of the
programme are not available then No Infor-
mation Available is displayed in the informa-
tion banner.
If the selected channel is locked, you must
enter the correct four digit key to view the
channel.
(QWHU/RFN.H\
ELECTRONIC PROGRAMME
GUIDE (EPG)
The 7 day EPG function may not be avail-
able in all countries or broadcasts.
Some, but not all, channels send information
about the current and next events. Please
note that event information is updated auto-
matically. If there is no event information data
available for channels, only channel name
with No Information Available banner is
displayed.
 Press (GUIDE) button to view the EPG
menu.
 Press or buttons to navigate in Chan-
nels or Programmes.
 Press or buttons to navigate through
the channel and programme list.
 In EPG Menu, you can easily see the ex-
tended help information by pressing the  
button and by pressing this button again you
can close this window.
 In the EPG Menu all channels are dis-
played. The current channel is highlighted
when you enter the EPG menu.Use or
buttons to change the channel. Also press
RE or GREEN buttons to make page up/
down scroll for the channels. And press OK
button to watch the highlighted channel.
 If you highlight an event, short event de-
scription, extended event description, start
and finish time of the event are displayed on
the screen.
 If you press OK button when a next event
is highlighted, a reminder is set for the high-
lighted programme and a clock icon appears
across the highlighted channel line as shown
in the following EPG menu figure.
1-ENG-3230W-HL02126 UK-32 INCH TFT (CHM)-PEU IDTV-NEW SOFT-50088657.p65 04.08.2006, 14:4211

- 12 -
Programme reminders is set to signal that a
programme is about to start when you are
watching another channel. If you set re-
minder to a programme, then you will be
asked for switching to that channel when the
reminder time is reached.
 By pressing the BLUE button you can
view the extended schedule of the
programmes.
 By pressing the  button you can see
the detailed help information easily. And by
pressing  button again you can exit Help
menu.
By pressing the BLUE button, the following
EPG Menu appears on the screen.
 By pressing YELLOW/BLUE button, you
can advance the schedule backward / for-
ward of a day.
 By pressing RE or GREEN buttons you
can change the schedule time.
 If you press   button you can see the de-
tailed help information easily. And by press-
ing   button again you can exit Help
menu.
Displaying The Subtitles
With igital terrestrial broadcasting ( VB-T),
some programmes are broadcast with sub-
titles. Subtitles can be displayed when watch-
ing these programmes.
Whenever GREEN button is pressed, Sub-
title selection OS will be displayed on the
screen. You can set Subtitles as ON or OFF.
For Subtitle Language options, refer to Lan-
guage Settings in the Configuration Menu
section.
TELETEXT
Use of teletext and and its functions are iden-
tical to the analogue text system. Please do
refer to the Analogue teletext explanations.
Note: When subtitles are set to ON, teletext
service cannot be used in the igital Mode.
To enable teletext, set subtitles OFF.
IDTV Menu System
The I TV Menu can only be shown when
watching igital terrestrial broadcasting.
Press the DTT/TV button to turn the I TV
on while TV is in the analogue mode.
1. Press  button.
The menu below appears on the screen:
0DLQ0HQX
1-ENG-3230W-HL02126 UK-32 INCH TFT (CHM)-PEU IDTV-NEW SOFT-50088657.p65 04.08.2006, 14:4212

- 13 -
Channel List
Using or buttons on the remote control
in Main menu, make sure that the first item,
Channel List, is highlighted and press the
OK button to display the C annel List.
The following operations can be performed in
this menu:
1. Navigating t e w ole list of c an-
nels
2. Moving c annels *
3. Deleting c annels
4. Renaming c annels
5. Adding locks to c annels
6. Setting favourites
* Depending on your selection of Country
in t e first time installation, MOVE op-
tion of t e C annel List may not be vis-
ible.
Channel List is the place where the channels
are managed.
Navigating t e w ole c annel list
 Press or keys for selecting the previ-
ous or next channel.
 You can press RE or GREEN buttons to
move the page up or page down.
 To watch a specific channel, highlight it us-
ing or buttons and then press OK
button, while the Select item on Channel
The list menu is highlighted via using or
buttons.
Moving t e c annels in t e c annel list
 Press or buttons to select the chan-
nel that will be moved.
 Press or buttons to select the Move
item on Channel List menu.
Move is written next to OK item to indicate
that press OK to move the highlighted
channel to the desired position on the chan-
nel list.
 Press OK button, the selected channel
becomes highlighted.
 Use or buttons to select the new po-
sition of the channel and press OK button to
place the channel to the selected position
and return the menu.
Deleting t e c annels in t e c annel list
 Press or buttons to select the chan-
nel that will be deleted.
 Press or buttons to select the De-
lete item on Channel List menu.
As seen on Channel List menu,  elete is
written next to OK at the bottom of the
screen to indicate that pressing the OK but-
ton will delete the highlighted channel in the
channel list.
1-ENG-3230W-HL02126 UK-32 INCH TFT (CHM)-PEU IDTV-NEW SOFT-50088657.p65 04.08.2006, 14:4213

- 14 -
Press OK button to delete the highlighted
channel in the channel list. Then the mes-
sage below appears on the screen.
 Press or buttons to highlight the de-
sired option.
 If OK button is pressed while Yes is
highlighted, the highlighted channel is de-
leted.
 Selecting No cancels the delete opera-
tion.
Renaming c annels
To rename a specific channel, the channel
must be highlighted via pressing or
buttons and then highlight the Edit Name
item by pressing or buttons. Press OK
button to activate rename feature.
Now pressing or buttons moves to the
previous/next character. Pressing or
buttons toggles the current character, i.e., b
character becomes a on and c on .
Pressing the numeric buttons 0...9 replaces
the highlighted character as the button
pressed one by one.
Press the   button to cancel the editing or
OK button to save the new name.
Adding locks to c annels
Channel Locking provides a password-pro-
tected access to channels selected by par-
ents.
In order to lock a channel you should know
the Parental Lock password (default value is
set to 0000 in the factory and can only be
changed from the Configuration Menu).
By pressing or buttons, highlight the
channel to be locked and select the Lock
option by pressing or buttons.Then
press theOK button, a password box is dis-
played.
Setting Favourites
You can set various channels as favourites
so that only the favourite channels are navi-
gated. To set a favourite you should highlight
the Favourites item at bottom of the Chan-
nel List menu.
To set a favourite you should highlight the
Favourites item at bottom of the Channel
List menu, and then pressing OK key, Edit
Favourite Lists menu appears on the
screen.
You can list your favourite channels using
List 1, List 2, List 3, List 4 or List 5.
1-ENG-3230W-HL02126 UK-32 INCH TFT (CHM)-PEU IDTV-NEW SOFT-50088657.p65 04.08.2006, 14:4214

- 15 -
Using 5 lists enables listing channels for
diffrerent categories (sport, music etc.). And
by activating the favourites list number that
you want in Favourite Mode submenu of
Configuration menu, you enable only the
channels in the selected list. Configuration
menu is entered from the Main Menu.
How To Add A Channel To A Favourite
List:
 By pressing  /   buttons, highlight
the channel that you want to add to the
favourite list.
 Select the list number by pressing   /  
buttons.
 By pressing OK button, the highlighted
channel is added to selected list number.
For each channel, an icon indicates which
favourite list a channel is in. (i.e. In figure
above, icon indicates that BBC ONE is
added to List 1.)
To remove any c annel t at is added to a
favourite list:
 Highlight the channel that you want to re-
move from the favourite list you have added;
 Highlight the list number that the channel
will be removed, and press OK button. The
icon indicating the added list number disap-
pears on the menu.
Note: A c annel can be added to more
t an one favourite list.
To activate Favourites, go to the Configura-
tion menu and select the list number in
Favourite Mode you want to activate by
pressing or buttons. To cancel
Favourites, set Favourite Mode to Off.
Using BLUE button to navigate t roug
t e favourite c annels:
You can navigate through the favourite chan-
nel lists via pressing BLUE button. For each
pressing of BLUE button, you can navi-
gate through the favourite channels that are
top of the each channel list, sequentially.
While a channel list is selected, you can
navigate through the favourite channels in
that list by pressing P + or  P - buttons.
On Screen Help Pressing Button
For all menus press   button to display
the help information about the menu func-
tions. For C annel List menu the following
message is displayed on the screen.
When you see more in a menu; press the
 utton on the remote control for on
screen help on how to use the menu.
Installation
The Installation menu is there to help you for
building a C annel Table in the most effi-
cient way.
1-ENG-3230W-HL02126 UK-32 INCH TFT (CHM)-PEU IDTV-NEW SOFT-50088657.p65 04.08.2006, 14:4215

- 16 -
0DLQ0HQX
This menu includes the following items:
1. Automatic Search
2. Manual Search
3. First Time Installation
,QVWDOODWLRQ
$XWRPDWLFVHDUFK
0DQXDO6HDUFK
)LUVW7LPH,QVWDOODWLRQ
Automatic Searc :
Automatic search is started by pressing
OK button while Automatic Searc item is
highlighted.
The following message appears on the
screen.
Highlight Yes or No via using or but-
tons and press OK button to select.
If Yes is selected, Automatic Search is
started.
Selecting No cancels Automatic Search.
After search is completed for digital chan-
nels, a message asking search for analogue
channels appears on the screen.
Highlight Yes and press OK button to
searh for analogue channels.The following
menu appears on the screen for analogue
channel search.
Press the BLUE button to cancel APS if you
do not want to delete your existing
programme list.
To continue APS, first select the language
and country by pressing
_
/
`
button and then
press the RE or OK button.
After APS is finalized, the programme table
will appear on the screen. In the programme
table you will see the programme numbers
and names assigned to the programmes.
If you do not accept the locations and / or the
programme names, you can change them in
APS sub-menu in the settings menu. (See
page 26 for Program table explanation.)
All the services are searched and a channel
table is created automatically.
All channels found are stored in a sorted
form with respect to their channel numbers.
Some services may not appear with the cor-
rect channel number. At the time of printing,
not all broadcasters are sending their chan-
nel number information.
Manual Searc :
In Manual Searc , the number of the multi-
plex is entered manually and only that multi-
plex is searched for the channels. For every
valid channel number, signal level, signal
quality and network name are shown at the
bottom of the screen.
In both manual and auto search any existing
channel in the database is not re-stored to
avoid redundant duplicates of that channel.
1-ENG-3230W-HL02126 UK-32 INCH TFT (CHM)-PEU IDTV-NEW SOFT-50088657.p65 04.08.2006, 14:4216

- 17 -
First Time Installation
The user can use this item to load default
settings, which had been loaded to the re-
ceiver at the factory.
To install factory settings, highlight First
Time Installation menu item and press
OK button, then you will be asked to con-
firm for deleting all channels and settings.
Selecting Yes by pressing OK button
while the Yes is highlighted and then the
existing channel table will be deleted.
After factory settings are loaded, First Time
Installation menu will be displayed.
The menu which is displayed for language
selection appears on the screen at first. By
using or buttons, select the desired
language option, and press OK button to
activate.
After the language is selected, a message
asking for automatic search start appears on
the screen.
Highlight Yes item by pressing or but-
tons and press OK button to start installa-
tion. After search is completed for digital
channels, a message asking search for ana-
logue channels appears on the screen.
Highlight Yes item by pressing or
buttons and press OK button to search for
analogue channels.The following menu ap-
pears on the screen for analogue channel
search.
Press the BLUE button to cancel APS if you
do not want to delete your existing
programme list.
To continue APS, first select the language
and country by pressing
_
/
`
button and then
press the RE or OK button.
Configuration
Press   button to display the Main Menu
and the button twice to highlight Configu-
ration, then press OK button to display the
Configuration menu. Press   button to exit
the menu.
0DLQ0HQX
&KDQQHO/LVW
,QVWDOODWLRQ
&RQILJXUDWLRQ
7LPHUV
796HWXS
&RPPRQ,QWHUIDFH
The various configuration functions are dis-
played in a list, along with a quarter-screen
image of the currently selected channel. You
can select a function by highlighting the cor-
responding menu line using the or
buttons.
1-ENG-3230W-HL02126 UK-32 INCH TFT (CHM)-PEU IDTV-NEW SOFT-50088657.p65 04.08.2006, 14:4217

- 18 -
Favourite Mode
This function enables or disables the
favourite channel list mode.
Use or buttons to set Favourite Mode
to List 1, List 2,..., List 5 or Off.
Selecting Off disables the favourite chan-
nel List mode.
If the Favourite Mode is set on via select-
ing a channel list number, in normal operat-
ing mode pressing P + and P - buttons will
only navigate through the channels that
were previously defined as favourites in the
selected channel list.
C annel List
In the Configuration Menu, highlight the
C annel List item by pressing or but-
tons.
Use the or buttons to set the C annel
List to TV only or Radio only.
This feature enables navigation only through
the selected channel list type.
If Radio only is set, you can only navigate
through the Radio channels in the channel
list via using P + or P - buttons.
Language Settings
In the configuration Menu, highlight the Lan-
guage Settings item by pressing or
buttons. Press OK and Language Settings
sub menu will be displayed on the screen:
$XGLR/DQJXDJH
6XEWLWOH/DQ
J
XD
J
H
6\VWHP/DQJXDJH
Use or buttons to highlight the menu
item that will be adjusted.
System Language
System Language determines the on-
screen menu language.
Use or buttons to set the System Lan-
guage setting.
Audio Language
igital terrestrial television channels can
broadcast simultaneous sountracks in more
than one language. This function selects
which language soundtrack you will hear
when switching to a channel broadcasting
with the multiple soundtracks.
Use or buttons to cycle through the
language options.
Subtitle Language
igital terrestrial television channels can
broadcast with subtitles displayed on-screen
for the hard-of-hearing. This function selects
the desired subtitle language and enables
the automatic display of subtitles whenever
subtitle information is broadcast.
Use or buttons to cycle through
Off and language options.
Parental Settings
Some channels broadcast material which
you do not want younger members of the
family to watch. Any channel can be locked
so that it cannot be selected for viewing with-
out first a four-digit PIN code being entered.
In this way any channel not suitable for
younger viewers can be protected.
This function enables or disables the menu
protection system and allows the PIN code to
be changed. Channel And Menu Protection
Lock feature.
(See Channel List menu Favourites on page
14)
Use or buttons to highlight Parental
Settings. Press SELECT button to enter Pa-
rental Settings Menu. A box asking for the
lock key is displayed.
1-ENG-3230W-HL02126 UK-32 INCH TFT (CHM)-PEU IDTV-NEW SOFT-50088657.p65 04.08.2006, 14:4218

- 19 -
(QWHU/RFN.H\
There is only one key which is set to 0000
initially. Enter lock key. If wrong Lock key is
entered, the following message is displayed
on the screen and it is returned back.
If it is correct, the Parental Settings Menu in-
cluding following items is displayed:
0HQX/RFN,QVWDOODWLRQ
6HW/RFN.H\
0DWXULW\/RFN
Use or buttons to highlight the menu
item that will be adjusted.
Maturity Lock:
Use or buttons to set Maturity Lock to
the Off, Age 4, Age 5...........Age17 or Age
18.
Menu Lock:
There you can set/reset locking for the Main
Menu or the Installation Menu to restrict ac-
cess. If the menu lock is disabled, there will
be free access to the menu system.
Off: All menus are unlocked.
Main Menu: Main menu is accessible only
with the correct lock key. So the user cannot
add, delete, rename, move channels, cannot
set timers.
Installation: Installation menu is locked, so
the user cannot add channels.
Changes will be updated after exiting Con-
figuration Menu.
Set Lock Key:
Also in this menu you can change the lock
key and set/change parental lock mode.
Time Settings
In the configuration Menu, highlight the Time
Settings item by pressing or buttons.
Press OK and Time Settings sub menu will
be displayed on the screen:
7LPH=RQH6HWWLQ
J
7LPH=RQH
&XUUHQW7LPH
Use or buttons to highlight the Time
Zone Setting. Time Zone Setting is set using
or buttons. It can be set to AUTO or
MANUAL. When AUTO is selected, Current
Time and Time Zone options will not be avail-
able to be set.
If MANUAL option is selected as the Time
Zone Setting, Time Zone can be altered:
 By pressing or buttons select Time
Zone. Use or buttons to change the
Time Zone between GMT-12 or GMT+12.
Current Time on the top of the menu list will
then change according to the selected Time
Zone.
Receiver Upgrade
The I TV can be upgraded via the configura-
tion menu, entered from the main menu.
In the configuration menu, highlight the Re-
ceiver Upgrade item by pressing or
buttons and press OK button to start up-
grade process. The following menu appears
on the screen.
After the search progress is completed, the
message  Completed searc ing for up-
grade. No new software was found ap-
pears on the screen if no new software is
found.
1-ENG-3230W-HL02126 UK-32 INCH TFT (CHM)-PEU IDTV-NEW SOFT-50088657.p65 04.08.2006, 14:4219
