CP-AW312WN LCD Projector
* Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
lamp life specified are not guaranteed and do not constitute part of the product or lamp warranty. Lamp brightness decreases over time.
** Actual filter life will vary by individual filter and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
filter life specified are not guaranteed and do not constitute part of the product warranty.
Accessories
Supplied
Accessories
Remote control, power cord,
computer cable, user's manual,
network manual
Optional
Accessories
UST1WALLARM, A3WALLARM,
TT-251 tabletop stand, USBWL11N - USB
wireless adapter
Replacement Parts
Lamp DT01411
Remote Control HL02882
Filter UX37191
Specifications
Display
Projection Technology 3LCD, 3 chip technology
Resolution WXGA - 1280 x 800
White Light Output 3,000 ANSI lumens
Color Light Output 3,000 ANSI lumens
Colors 16.7 million colors
Aspect Ratio Native 16:10 / 16:9 and 4:3 compatible
Contrast Ratio 4000 : 1 (using active IRIS)
Throw Ratio
(distance : width)
0.1 : 1 from edge of projector to screen
0.3 : 1 from mirror to screen
Lens & Operation
Lens F = 1.8, f = 4.1 mm
Lamp Wattage 250W
Expected Lamp Life* Approximately 2,500 hours (standard mode)
4,000 hours (Eco mode)
Expected Filter Life** Approximately 4,000 hours
Speaker Output 16W
Acoustic Noise Level 37 dB (30 dB in Eco mode)
Keystone H and V: +/- 5º
Compatibility
Computer VGA, SVGA, XGA, WXGA, WXGA+/SXGA/WSXGA+/UXGA
(compressed), MAC 16"
H-Sync 31.5 kHz - 106 kHz
V-Sync 56 Hz - 120 Hz
Composite Video NTSC, NTSC4.43, PAL, PAL-M, -N, SECAM
Component Video 480i, 480p, 576i, 720p, 1080i, 1080p
HDMI 480i, 480p, 576i, 720p, 1080i, 1080p,
computer signal TMDS clock 27 MHz - 150 MHz
Connectors
Digital Input HDMI x 1 (HDCP compliant)
Computer Input 1 15-pin mini D-sub x 1
Computer Input 2 15-pin mini D-sub x 1
Computer Monitor Output 15-pin mini D-sub x 1
Video Input
S-Video Mini DIN 4-pin x 1
Composite Video RCA jack x 1
Component Video 15-pin mini D-sub x 2, (shared with computer in 1/2)
Audio Input 3.5 mm stereo mini jack x 2, RCA jack (L/R) x 1,
MIC-in 3.5 mm mini jack x 1
Audio Output RCA jack (L/R) x 1
Network LAN Wired RJ-45 port (10 base-T / 100 base-TX)
Network LAN Wireless USB-A, IEEE802.11 b/g/n - optional wireless adapter required
USB Type A x 2 (PC-less presentation, wireless adapter)
Type B x 1 (USB display or mouse control)
Control Terminals 9-pin mini D-sub x 1 (RS-232 control)
Ratings & Warranty
Power Supply AC100-120V / AC220-240V, 50/60Hz
Power Consumption 370W
Operating Temperature 32ºF - 104ºF (0ºC - 40ºC)
Dimensions (W x D x H) 13.6" x 11.9" x 3.4" (excl. protruding parts)
Weight approx. 8.4 lbs
Approvals UL 60950-1 / cUL FCC Part 15 subpart B Class B
Warranty 3 year limited parts and labor.
Extended Service Contract available (additional cost)
Ultra Short Throw
Series
Projection Throw Chart (In inches)
Screen Size 16:10 Throw Distance
Diagonal Distance from
leading edge of
projector to screen
Distance from
mirror to screen
60 4.7 16.8
70 7.4 19.5
80 10.1 22.1
90 12.8 24.8
100 15.4 27.5
Throw Ratio: (distance : width)
0.1 : 1 from edge of projector
0.3 : 1 from mirror
CP-AW312WN
Hitachi America, Ltd.
900 Hitachi Way, Chula Vista, CA 91914
Toll Free: 1.800.HITACHI •Email: [email protected]
Web: hitachi-america.us/projectors
HI0116-02/13 WEB
All specifications subject to change without notice.
