Hitachi CP-AX3503 User manual

CP-AX3503 LCD Projector
Ultra short throw LCD projector with
a suite of advanced features.
Key Features
■XGA 1024 x 768 resolution
■3,600 ANSI lumens white/color output
■5000:1 contrast ratio
■HDMI 2 inputs
■Accentualizer - advanced image
processing
■High Dynamic Contrast Range (HDCR)
■ImageCare Technology for energy
savings
■Wireless compatible
■Projector Quick Connect iOS App
1.800.HITACHI
[email protected]
hitachi-america.us/projectors
CP-AX3503
Hitachi’s CP-AX3503 ultra short throw LCD projector is ideally suited for
producing large images in limited spaces. It provides vibrant image quality
with cost-effective operation. A suite of advanced features normally found
only on higher end models includes High Dynamic Contrast Range (HDCR),
2 HDMI ports, and Hitachi’s original technology Accentualizer that allows the
projected image to appear more real by enhancing sharpness, gloss and
shade. Along with its light weight and compact design, the CP-AX3503 offers
Hitachi’s most appreciated installation feature, “Perfect Fit”, allowing time
saving and ease of installation. As with all Hitachi projectors, you can expect
vibrant image quality, cost-efficient operation, and long-lasting reliability. Plus,
Hitachi’s Intelligent Eco and Saver Modes with ImageCare combines optimal
picture performance with energy savings for a lower total cost of ownership.
For added peace of mind, Hitachi’s CP-AX3503 is also backed by a generous
3 year warranty and our world-class service and support programs.

CP-AX3503 LCD Projector
* Actual filter life will vary by individual filter and based on environmental conditions, selected operating mode, user settings
and usage. Hours of average filter life specified are not guaranteed and do not constitute part of the product warranty.
** Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user
settings and usage. Hours of average lamp life specified are not guaranteed and do not constitute part of the product or
lamp warranty. Lamp brightness decreases over time.
UNIQUE FEATURES STANDARD FEATURES
Hitachi America, Ltd.
Toll Free: 1.800.HITACHI •Email: [email protected]
Web: hitachi-america.us/projectors
HI0260-Rev.1-04/14
All specifications subject to change without notice.
3LCD and the 3LCD logo are registered trademarks of the Seiko Epson Corporation.
©2014 Hitachi America, Ltd. All Rights Reserved .
Tabletop Presentation
Make any tabletop a projection screen using the optional
tabletop stand. Ideal for a small group environment or in a
room with limited space.
Microphone Input
A microphone can be used via the jack
located on the input panel. Allows for more
dynamic presentations even in standby mode.
Input Source Naming
Users can name input sources in simple
language instead of factory default names.
Network Control, Maintenance and Security
Embedded networking gives you the ability to manage and
control multiple projectors over your LAN. Features include
scheduling of events, centralized reporting, image transfer and
e-mail alerts for reactive and routine maintenance.
PIN Lock / MyScreen / MyText
PIN lock protection can limit projector users. MyScreen PIN
lock keeps captured images on the startup screen. Users can
set any name logo to MyScreen, clearly identifying ownership.
MyText provides the ability to write text on the startup screen
such as model name, serial number or location.
PJMessenger
PJMessenger function allows you to send and display text
messages and audio alerts on your networked projectors. It
is an easy and efficient way to send announcements out to
multiple units.
PC-Less Presentation
By using a USB memory stick or other storage device, you
can use the projector without a computer. Menus are easy
to see with a thumbnail display. Additionally there is also a
slideshow and video function.
Present Content via LAN
Hitachi’s suite of networking software allows you to easily
send content directly from your PC to the projector via your
LAN connection.
Template Function
Line templates in the projector menu can help when writing
on a whiteboard. There are four types of line templates to
choose from.
Cloning Function
Copy setting data from one projector to others of the same
model via USB memory. Cloning not only saves almost all PJ
settings such as gamma and keystone via USB memory, it
saves countless hours in setup and installation.
settings
settings
Intelligent Eco and Saver Modes
Automatically changes the brightness of the lamp according to
the brightness level of the screen. Also, automatically changes
the brightness of the lamp if there is no change in the screen
image. Using ImageCare technology, these features give
optimal picture performance with maximum energy savings.
ImageCare Technology
ImageCare is a lamp power control function that combines
optimal picture performance with maximum energy savings
by decreasing energy usage, improving contrast ratio and
lengthening lamp life. The result is a lower total cost of
ownership and decreased maintenance cost.
Perfect Fit 2
Enables the user to adjust individual corners and sides
independent of one another. Perfect Fit 2 provides vertical
and horizontal digital correction of either barrel or pin
cushion distortions. This feature helps correct geometric and
complicated distortions. Perfect Fit 2 allows the projected
image to fit correctly to the screen quickly and easily.
Projector Quick Connection App For Mobile Devices
Our iOS application offers projector control and also provides
the capability to display photos, document files and web site
contents. Available for iPad®, iPhone®and Android devices.
Works over your LAN via your RJ-45 port or via an optional
USBWL11N wireless adapter.
Wireless Presentation Compatible
Connect the projector to a a computer or your network using
the optional USB wireless adapter (part number USBWL11N).
The adapter supports IEEE802.11b/g and the latest 11n.
HDCR (High Dynamic Contrast Range)
When average projectors are used in bright rooms, the darker colors of an
image deteriorate and images become unclear. Using this function, blurred
images caused by room lighting or outside light sources are corrected, and
an effect similar to increas
ing contrast occurs. This
results in clear images even
in bright rooms.
HDCR OFF HDCR ON
Accentualizer
Hitachi original technology makes pictures look more real by enhancing
sharpness, gloss and shade to make pictures as clear as pictures on a
flat-panel device. You can also adjust the effects by three levels according
to your surroundings so that the colors of projected images are the actual
colors of the
objects they
represent.
Sharpness Gloss Shade

CP-AX3503 LCD Projector
Enhance the experience with
Hitachi’s CP-AX3503.
The CP-AX3503 ultra short throw LCD projector from
Hitachi is specifically designed to enhance the visual
experience — from the audience to presenters. Vivid
colors. Bold graphics. Crisp text. The CP-AX3503
does it all in environments of all sizes. With 3,600
ANSI lumens of brightness and XGA 1024 x 768
resolution, the CP-AX3503 provides the perfect
compatible solution. It also features a high contrast
ratio, long lamp life, cloning function enabling you to
copy settings data from one projector to others of
the same model, and is wireless presentation ready.
Plus, embedded networking gives you the ability to
manage and control multiple projectors over your
LAN (scheduling of events, centralized reporting,
image transfer, and email alerts). Best of all, the high
performance CP-AX3503 is exceptionally reliable and
offers a very low cost of ownership.
Input/Outputs
CP-AX3503
Wall Mounted
(with cable cover)
Front View (without cable cover)
Top View (with cable cover)
1 2
13
3
1215 1416
4
11
5
10
6
9
7
8
1. LAN
2. USB Type A x 2
3. USB Type B
4. HDMI 1
5. Control (RS-232C)
6. HDMI 2
7. Microphone Input
8. Audio in
9. Audio out
10. Computer in 2/
Monitor out
11. Computer in 1
12. Video in
13. Audio in 2
14. AC in (located on back
side of the projector)
15. Kensington lock
16. Security bar
HDMI
AMX Device
Discovery
Hitachi Trade-Up
Program
Crestron
Integrated Partner
3 Year Warranty
Closed Captioning
3LCD Technology
3/4 View
(with cable cover)
