CP-DX250 DLP®Projector
Breakthrough classroom performance
with incredible picture quality, high reliability,
and lower cost of ownership.
Key Features
■XGA 1024 x 768 resolution
■2,500 ANSI lumens light output
■2500:1 contrast ratio
■4.500 hours lamp life (Standard mode)
6,000 hours lamp life (Eco mode)*
■ImageCare Technology for energy
savings
■BrilliantColorTM
■Deeper black levels
■Wall color correction
■Filter free design
1.800.HITACHI
[email protected]
hitachi-america.us/projectors
CP-DX250
The wireless remote control
enables you to easily control
a full complement of projector
functions.
Hitachi’s CP-DX250 DLP®projector represents the new standard for
classroom environments and versatility with high resolution XGA performance,
an innovative feature set and overall value. The CP-DX250
incorporates 2,500 ANSI lumens light output and a
2500 : 1 contrast ratio for vibrant, bold images with
deeper black levels and razor-sharp text. Perfomance
versatility is enhanced by HDMI terminals which
accommodate many types of AV devices. Plus, Hitachi’s Intelligent Eco Mode
with ImageCare combines optimal picture performance with energy savings
for a lower cost of ownership. For added peace of mind, Hitachi’s CP-DX250
is also backed by a generous warranty and our world-class service and
support programs.

CP-DX250 DLP®Projector
* Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user
settings and usage. Hours of average lamp life specified are not guaranteed and do not constitute part of the product or
lamp warranty. Lamp brightness decreases over time.
UNIQUE FEATURES
STANDARD FEATURES
Hitachi America, Ltd.
900 Hitachi Way, Chula Vista, CA 91914
Toll Free: 1.800.HITACHI •Email: [email protected]
Web: hitachi-america.us/projectors
HI0141-Rev.1-04/13-WEB
All specifications subject to change without notice.
DLP
®
and the DLP logo are registered trademarks of Texas Instruments.
©2013 Hitachi America, Ltd. All Rights Reserved .
Intelligent Eco Mode
Automatically changes the brightness of the lamp according
to the brightness level of the screen. Using ImageCare
technology, these features give optimal picture performance
with maximum energy savings.
ImageCare Technology
ImageCare is a lamp power control function that combines
optimal picture performance with maximum energy savings
by decreasing energy usage, improving contrast ratio and
lengthening lamp life. The result is a lower total cost of
ownership and decreased maintenance cost.
2,500 ANSI Lumens Light Output
The light output specification measures the brightness of light
output and with 2,500 ANSI lumens the result is bright, clear,
true to life images with incredible detail.
LIGHT OUTPUT
2500
2500:1 Contrast Ratio
Contrast can be automatically controlled through an active iris
to add depth perspective during both bright and dark scenes.
HDMI Input (HDCP)
Digital connectivity allows for highest image quality from your
HD device. Compliancy with HDCP.
6,000 Hour Lamp Life (Eco mode)*
Another key to low total cost of ownership is a long life lamp.
The lamp is rated at 4,500 hours in standard mode and 6,000
hours in Eco mode.
Power Saving Standby Mode
Power saving mode reduces the standby power consumption
to less than 0.5W.
Easy Maintenance
Easy maintenance is another attractive function, as the lamp
door is on top of the model.
SPECIFICATION HIGHLIGHTS
DLP®Technology
DLP technology was invented, developed and is owned by
Texas Instruments. The DLP chip is a digital semiconductor
that contains millions of microscopic mirrors. These projectors
use DLP technology to project images with amazing quality.
BrilliantColor™
BrilliantColor technology is setting a new
standard in color performance. BrilliantColor
offers color processing to enhance color
performance for rich, vibrant and accurate colors.
Wall Color Correction
This feature corrects the color of images projected on surfaces
that are not white to prevent color differences between the
source and projections. Five wall color modes include light
yellow, light green, blue, black board and pink.
3D Capable
Discover the teaching advantages of 3D! This DLP projector
offers the latest trend for the classroom with 3D viewing. It will
engage your students and can improve the learning process.
3D glasses and a special graphic card are required for 3D
viewing and are not included with the projector.
3D
3D
CAPABLE
3D

CP-DX250 DLP®Projector
Enhance the educational experience
with Hitachi’s CP-DX250.
The CP-DX250 DLP
®
projector from Hitachi is
specifically designed to enhance the educational
experience — for students and teachers. Leading
edge DLP
®
projector technology helps stimulate the
imagination of students of all ages and makes lessons
become more interesting, compelling and memorable.
Vivid colors. Deeper blacks. Bold graphics. Crisp text.
The CP-DX250 does it all in classrooms of all sizes.
With 2,500 ANSI lumens light output, XGA 1024 x
768 resolution, the CP-DX250 provides the perfect
solution. It also features exceptional reliability, a high
contrast ratio, HDMI terminals so you can connect
many types of AV devices, and wall color correction
which corrects the colors of images projected
on surfaces that are not white. With Hitachi’s
CP-DX250, learning has never been easier, more
enjoyable or so engaging.
Input/Outputs
CP-DX250
Right Side Profile
Left Side Profile
Top View
41
12 1011
52 3 7 96 8
1. Control (RS-232C)
2. Service
3. HDMI
4. Computer in 2
5. Computer in 1
6. S-Video
7. Video
8. Audio In
9. Audio Out
10. Lock
11. Monitor Out (1 only)
12. AC In
HDMI
Hitachi Trade-Up
Program 3 Year Warranty
Closed Captioning
Front 3/4 View
Hitachi America, Ltd.
900 Hitachi Way, Chula Vista, CA 91914
Toll Free: 1.800.HITACHI •Email: [email protected]
Web: hitachi-america.us/projectors
HI0141-Rev.1-04/13-WEB
All specifications subject to change without notice.
DLP
®
and the DLP logo are registered trademarks of Texas Instruments.
©2013 Hitachi America, Ltd. All Rights Reserved .

CP-DX250 DLP®Projector
* Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
lamp life specified are not guaranteed and do not constitute part of the product or lamp warranty. Lamp brightness decreases over time.
Accessories
Supplied
Accessories
Remote control, power cord,
computer cable, user’s manual
Optional
Accessories
N/A
Replacement Parts
Lamp DT01461
Remote Control HL02961
