Hitachi CP-RX60 Series User manual

• Compact Size
• Equalizing Function
• Easy Setting Function
• Progressive Scan
• Easy-to-Use Menu
• High Brightness 1,500 ANSI Lumens
• Whisper Mode Ready
A choice of projectors that meet your requirements
for various types of locations and uses.
Printed in Japan (H)NM-E291 0405
• Design and specifications are subject to change without notice.
• The comparison photos in this catalog are simulations.
• LCD panels, polarizers and other optical components and cooling fans may need replacement after
prolonged usage. For more details, please consult a Hitachi sales representative listed below.
• Do not use in places where there is a lot of water, dampness, steam, dust, soot or tobacco smoke.
This may result in fire or malfunction.
49.5mm (1-15/16")
[0˚-9˚ inclination adjustment]
Typical office desk
height 70cm (27-9/16")
a: LCD projector-to-screen distance
b: Screen height from lens center to top
c: Screen height from lens center to bottom
a
b
(top)
c
(bottom)
Screen Size (inch)
40
50
60
70
80
90
100
120
150
200
a
1.5m (57")
1.8m (72")
2.2m (87")
2.6m (101")
2.9m (116")
3.3m (130")
3.7m (145")
4.4m (174")
5.5m (218")
7.4m (291")
b (top)
52.3cm (21")
65.3cm (26")
78.4cm (31")
91.4cm (36")
104.5cm (41")
117.6cm (46")
130.6cm (51")
156.8cm (62")
195.9cm (77")
261.3cm (103")
c (bottom)
8.7cm (3")
10.9cm (4")
13.1cm (5")
15.2cm (6")
17.4cm (7")
19.6cm (8")
21.8cm (9")
26.1cm (10")
32.7cm (13")
43.5cm (17")
Screen Size (inch)
40
50
60
70
80
90
100
120
150
200
a
1.3m (53")
1.7m (66")
2.0m (80")
2.4m (93")
2.7m (107")
3.1m (121")
3.4m (134")
4.1m (161")
5.1m (202")
6.8m (269")
b (top)
52.3cm (21")
65.3cm (26")
78.4cm (31")
91.4cm (36")
104.5cm (41")
117.6cm (46")
130.6cm (51")
156.8cm (62")
195.9cm (77")
261.3cm (103")
c (bottom)
8.7cm (3")
10.9cm (4")
13.1cm (5")
15.2cm (6")
17.4cm (7")
19.6cm (8")
21.8cm (9")
26.1cm (10")
32.7cm (13")
43.5cm (17")
Model name
Liquid crystal panel structure
Number of pixels
Resolution
Brightness
Frequency
Contrast ratio
Noise
Lens
Keystone correction
Lamp
Speaker
Power supply
Operating temperature
Input signals
Input terminals
Agency certifications
Dimensions (WxHxD)
Weight
Standard accessories
fH [kHz]
fV [Hz]
Whisper
Normal
RGB input
Video input
Video input
Audio input
RGB input
Control and mouse
CP-RX60
0.55" polysilicon active-matrix TFT x 3
786,432 pixels (V768 x H1,024)
1,024 x 768 color pixels
1,500 ANSI Lumens
15-91
50-120
300:1
32dB
38dB
Digital zoom 1:1.2
Vertical
165W UHB
1W x 1
AC100-120V/AC220-240V
5-35°C (41-95°F)
VGA, SVGA, XGA, SXGA, MAC13", MAC16"
NTSC, NTSC4.43, PAL, SECAM, M-PAL, N-PAL
HDTV: 750p (720p), 1125i (1080i)
SDTV: 525i (480i), 525p (480p), 625i (575i)
S-Video x 1
Composite video x 1
Stereo-mini jack x 1
Analog RGB x 1
RS232C
UL60950/C-UL, FCC Part 15, Class B, CE, TUV EN60950
285 x 73 x 202mm (11-1/4" x 2-7/8" x 7-15/16") [excl. protruding part]
2.2kg (4.8 lbs.)
RGB cable, Batteries, Safety instruction, Quick Start Guide,
Power cord, 14-language user's manual CD-ROM
CP-RS55
0.55" polysilicon active-matrix TFT x 3
480,000 pixels (V600 x H800)
800 x 600 color pixels
1,500 ANSI Lumens
15-91
50-120
300:1
32dB
38dB
Digital zoom 1:1.2
Vertical
165W UHB
1W x 1
AC100-120V/AC220-240V
5-35°C (41-95°F)
VGA, SVGA, XGA, SXGA, MAC13", MAC16"
NTSC, NTSC4.43, PAL, SECAM, M-PAL, N-PAL
HDTV: 750p (720p), 1125i (1080i)
SDTV: 525i (480i), 525p (480p), 625i (575i)
S-Video x 1
Composite video x 1
Stereo-mini jack x 1
Analog RGB x 1
RS232C
UL60950/C-UL, FCC Part 15, Class B, CE, TUV EN60950
285 x 73 x 202mm (11-1/4" x 2-7/8" x 7-15/16") [excl. protruding part]
2.2kg (4.8 lbs.)
RGB cable, Batteries, Safety instruction, Quick Start Guide,
Power cord, 14-language user's manual CD-ROM
SPECIFICATIONS
PROJECTION DISTANCE
CP-RS55
CP-RX60
TERMINALS
DIMENSIONS 285mm (11-1/4")
83mm
(3-1/4")
73mm
(2-7/8")
202mm
(7-15/16")
69mm (2-11/16")
33.5mm (1-5/16")
49.5mm
(1-15/16")
39.5mm (1-9/16")
216mm (8-1/2")
10mm (3/8")
Control (RS232C) Analog RGB*
Composite VideoS-Video
Audio in
*With an optional dedicated cable, the Analog RGB
terminal makes Component input possible.
Hitachi, Ltd. Digital Media Division
(Yokohama Plant) has received
ISO 14001 certification.
Hitachi Europe Ltd.
Whitebrook Park, Lower Cookham Road, Maidenhead, Berkshire, SL6 8YA, UK
Tel: [phone] Fax: [phone] www.hitachidigitalmedia.com
Hitachi America, Ltd. Digital Media Division
Hitachi Plaza 2000 Sierra Point Parkway, Brisbane, CA 94005-1835, U.S.A.
Tel: +1-800-HITACHI Fax: [phone] www.hitachi.us/digitalmedia
Hitachi Canada Ltd.
2495 Meadowpine Blvd. Mississauga, Ontario L5N6C3, Canada
Tel: [phone] Fax: [phone] www.hitachi.ca
Hitachi Home Electronics Asia (S) Pte. Ltd.
438A Alexandra Road #01-01/02/03, Alexandra Technopark, Singapore 119967
Tel: [phone] Fax: [phone] www.hitachimultimedia.com.sg
Hitachi Sales (Malaysia) Sdn. Bhd.
Wisma Hitachi, No.2, Lorong 13/6A, 46200 Petaling Jaya,
Selangor Darul Ehsan, Malaysia Tel: [phone] Fax: [phone]
Hitachi Sales (Thailand), Ltd.
994, 996 Sol Thonglor, Sukhumvit 55 Road, Klongton, Klongtoey,
Bangkok 10110, Thailand Tel: [phone] Fax: [phone]
Hitachi (Hong Kong), Ltd.
18th Floor, Ever Gain Centre, 28 On Muk Street, Shatin, N.T., Hong Kong
Tel: [phone] Fax: [phone] www.hitachi-hk.com.hk
Hitachi Sales Corp. of Taiwan
2nd Floor, No.65, Nanking East Road, Section 3, Taipei, Taiwan
Tel: [phone] Fax: [phone]
Hitachi Australia Ltd.
Level 3, 82 Waterloo Road, Nor th Ryde, NSW 2113, Australia
Tel: [phone] Fax: [phone] www.hitachi.com.au

Outstanding functionality that’s perfect for business or educational applications.
This basic lineup is also well suited for home use.
0.55" polysilicon active-matrix TFT x 3
1,024 x 768 color pixels
1,500 ANSI lumens
0.55" polysilicon active-matrix TFT x 3
800 x 600 color pixels
1,500 ANSI lumens
The CP-RS55 and CP-RX60 measure W285 x H73 x D202mm
(11-1/4" x 2-7/8" x 7-15/16") and weigh just 2.2kg (4.8 lbs.).
With this compact size, they can be positioned anywhere in your
home or in a conference room or classroom, and can easily be
ceiling mounted. The compact and slim design ensures that they
will look attractive in any type of room.
The CP-RS55 and CP-RX60
feature Progressive Scan
Technology, which lets you
enjoy realistically beautiful
images with no flicker.
The projector's easy and advanced menu
means you will have no trouble adjusting
the Brightness, Contrast, Gamma and My
Memory settings. The remote control can be
operated while watching the screen, so even
beginners can make settings with confidence.
In Whisper mode, fan noise is reduced to
32dB. This provides quiet performance in
a variety of environments, such as living
rooms, meeting rooms or classrooms.
Even though the body is compact, the large 0.55" aperture ratio
LCD panel achieves high brightness of 1,500 ANSI Lumens.
This is more than enough for enjoying home theater and giving
presentations or lessons without having to darken the room.
Gamma correction and color balance can be controlled in eight and
six steps respectively, so you can make the image look just the way
you like it. As you make the adjustments, a grayscale bar lets you
confirm adjustment status.
Three Picture Mode settings (Normal, Cinema and Dynamic) let you
choose the best mode to match the source.
Normal:
Cinema:
Dynamic:
Best for all types of movies.
Best for brighter environments.
For enjoying a broad range of
standard picture qualities.
*Standard mode operating noise is 38dB. Brightness in Whisper
mode is approximately 20% lower.
