1
Projector
CP-X2514WN/CP-X3014WN/
CP-X4014WN/CP-WX3014WN
User's Manual (detailed)
Operating Guide
Thank you for purchasing this projector.
►Before using this product, please read all manuals for this
product. Be sure to read Safety Guide rst. After reading them, store them in a
safe place for future reference.
WARNING
• The information in this manual is subject to change without notice.
• The manufacturer assumes no responsibility for any errors that may appear in
this manual.
• The reproduction, transfer or copy of all or any part of this document is not
permitted without express written consent.
NOTE
Trademark acknowledgment
Various symbols are used in this manual. The meanings of these symbols are
described below.
About this manual
WARNING
CAUTION
This symbol indicates information that, if ignored, could possibly
result in personal injury or even death due to incorrect handling.
This symbol indicates information that, if ignored, could possibly
result in personal injury or physical damage due to incorrect
handling.
Please refer to the pages written following this symbol.

• Mac® is a registered trademark of Apple Inc.
• Windows®, DirectDraw® and Direct3D® are registered trademarks of Microsoft Corporation
in the U.S. and/or other countries.
• VESA and DDC are trademarks of the Video Electronics Standard Association.
•
HDMI, the HDMI logo, and High-Denition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC in the United States and other countries.
• Trademark PJLink is a trademark applied for trademark rights
in Japan, the United States of America and other countries and
areas.
• Blu-ray DiscTM is a trademark.
All other trademarks are the properties of their respective owners.
NOTICE This entry notices of fear of causing trouble.

2
Contents
Introduction . . . . . . . . . . . . . . . 3
Features ......................3
Checking the contents of package ...3
Part names ....................4
Setting up . . . . . . . . . . . . . . . . . 7
Arrangement ...................7
Connecting with your devices
.....10
Connecting to a power supply
.....15
Fastening the adapter cover ......
16
Using the security bar and slot . . . . 16
Remote control ............17
Installing the batteries ...........17
About the remote control signal . . . 17
Changing the frequency of remote control signal . . 18
Using as a simple PC mouse & keyboard . . 18
Power on/off . . . . . . . . . . . . . . 19
Turning on the power . . . . . . . . . . . 19
Turning off the power . . . . . . . . . . . 19
Operating . . . . . . . . . . . . . . . . 20
Adjusting the volume ............20
Temporarily muting the sound .....20
Selecting an input signal .........21
Searching an input signal . . . . . . . . 22
Selecting an aspect ratio .........22
Adjusting the projector's elevator . . 23
Adjusting the zoom and focus .....23
Using the automatic adjustment feature ...24
Adjusting the position . . . . . . . . . . . 24
Correcting the keystone distortions . . 25
Using the magnify feature ........26
Temporarily freezing the screen . . . 27
Temporarily blanking the screen . . 27
Using the menu function . . . . . . . . 28
EASY MENU. . . . . . . . . . . . . . . 30
As p e c t , Au t o k e y s t o n e , k e y s t o n e
,
pi c t u r e m o d e , ec o m o d e , mi r r o r , re s e t ,
Fi l t e r t i m e , lA n g u A g e , Ad v A n c e d m e n u , ex i t
PICTURE menu . . . . . . . . . . . . 32
Br i g h t n e s s , co n t r A s t , gA m m A , co l o r t e m p ,
co l o r , ti n t , sh A r p n e s s , Ac t i v e i r i s , mym e m o r y
IMAGE menu . . . . . . . . . . . . . . 35
As p e c t , ov e r s c A n , v p o s i t i o n , h p o s i t i o n ,
h p h A s e , h s i z e , Au t o A d j u s t e x e c u t e
INPUT menu . . . . . . . . . . . . . . 38
pr o g r e s s i v e , vi d e o n r , co l o r s p A c e ,
co m p o n e n t , vi d e o F o r m A t , hd m i F o r m A t ,
hd m i r A n g e , co m p u t e r i n , Fr A m e l o c k ,
re s o l u t i o n

SETUP menu ..............42
Au t o k e y s t o n e , k e y s t o n e , Au t o e c o m o d e ,
ec o m o d e ,
mi r r o r , st A n d B y m o d e ,
mo n i t o r o u t
AUDIO menu . . . . . . . . . . . . . . 45
vo l u m e , sp e A k e r , Au d i o s o u r c e ,
hd m i A u d i o , mi c l e v e l , mi c v o l u m e
SCREEN menu.............47
lA n g u A g e , me n u p o s i t i o n , Bl A n k ,
st A r t u p ,
MyScreen, MyScreen Lock
,
me s s A g e , so u r c e n A m e , te m p l A t e , c.c.
OPTION menu . . . . . . . . . . . . . 53
Au t o s e A r c h , Au t o k e y s t o n e ,
di r e c t p o w e r o n , Au t o p o w e r o F F ,
us B t y p e B, lA m p t i m e , Fi l t e r t i m e ,
myB u t t o n , mys o u r c e , se r v i c e
NETWORK menu ...........63
wi r e l e s s s e t u p , wi r e l e s s i n F o r m A t i o n ,
wi r e d s e t u p , wi r e d i n F o r m A t i o n ,
pr o j e c t o r n A m e , myi m A g e ,
Am x d.d., pr e s e n t A t i o n , se r v i c e
SECURITY menu ...........74
se c u r i t y p A s s w o r d c h A n g e ,
M
y s c r e e n p A s s w o r d , pi n l o c k ,
tr A n s i t i o n d e t e c t o r , myt e x t p A s s w o r d ,
myt e x t d i s p l A y , myt e x t w r i t i n g
Presentation tools . . . . . . . . . 80
PC-LESS Presentation .......80
Thumbnail Mode, Full Screen Mode,
Slideshow mode, Playlist
USB Display .................. 90
Starting USB Display,
Right-Click menu, Floating menu,
Options window
Maintenance ..............94
Replacing the lamp .............94
Cleaning and replacing the air lter . . 96
Other care ....................98
Troubleshooting . . . . . . . . . . . 99
Related messages . . . . . . . . . . . . . 99
Regarding the indicator lamps . . . 101
Resetting all settings ...........103
Phenomena that may be easy
to be mistaken for machine defects . 103
Specications ............108


3
Introduction
• Keep the original packing materials, for future reshipment. Be sure
to use the original packing materials when moving the projector. Use special
caution for the lens.
• The projector may make a rattling sound when tilted, moved or shaken, since
a ap to control the air ow inside of the projector has moved. Be aware that
this is not a failure or malfunction.
NOTE
Introduction
The projector provides you with the broad use by the following features.
Checking the contents of package
ü This projector has a variety of I/O ports that supposedly cover for any
business scene. The HDMI port can support various image equipment which
have digital interface to get clearer pictures on a screen.
ü If you insert a USB storage device, such as a USB memory, into the USB
TYPE A port and select the port as the input source, you can view images
stored in the device.
ü This projector can be controlled and monitored via LAN connection.
Furthermore, you can use the designated USB wireless adapter (optional) to
establish wireless LAN connection.
ü The built-in 16W speaker can deliver sufcient sound volume in a large space
like a classroom without external speakers.
Please see the Contents of package section in the User’s Manual (concise)
which is a book. Your projector should come with the items shown there. Require
of your dealer immediately if any items are missing.
Features
►Keep small parts away from children and pets. Take care
not to put in the mouth. If swallowed, consult a physician immediately for
emergency treatment.
WARNING

4
Introduction
Part names
Projector
(1) Lamp cover (94)
The lamp unit is inside.
(2) Speaker (20, 45)
(3) Filter cover (96)
The air lter and intake vent are inside.
(4) Elevator feet (x2) (23)
(5) Elevator buttons (x2) (23)
(6) Remote sensor (17)
(7) Lens (98)
(8) Lens cover
(9) Intake vents
(10) Control panel (5)
(11) FOCUS ring (23)
(12) ZOOM ring (23)
(13) AC IN (AC inlet) (15)
(14) Exhaust vent
(15) Rear panel (5)
►Do not open or remove any portion of the product, unless the
manuals direct it.
►Do not subject the projector to unstable conditions.
►Do not apply a shock or pressure to this product.
►Do not look into the lens and the openings on the projector while the lamp is
on.
WARNING
►Do not touch around the lamp cover and the exhaust
vents during use or just after use, since it is too hot.
►Do not attach anything onto the lens except the lens cover of this
projector because it could damage the lens, such as melting the lens.
CAUTION
(continued on next page)
(8)
(9)
(4)
(7) (3) (4)
(5)
(6)
(2)
(13)
(14)
(15)
(10) (1)
(11) (12)
(5)

5
Introduction
Part names (continued)
Control panel
(1) STANDBY/ON button (19)
(2) INPUT button (21)
(3) MENU button (28)
(4) LAMP indicator (101)
(5) TEMP indicator (101)
(6) POWER indicator (101)
Rear panel (10 ~ 14)
(1) LAN port
(2) USB TYPE A port
(3) HDMI port
(4) USB TYPE B port
(5) MIC port (14)
(6) AUDIO IN1 port
(7) AUDIO IN2 port
(8) AUDIO IN3 (R,L) ports
(9) AUDIO OUT (R,L) ports
(10) COMPUTER IN1 port
(11) COMPUTER IN2 port
(12) MONITOR OUT port
(13) CONTROL port
(14) COMPONENT ports (Y, Cb/Pb, Cr/Pr)
(15) VIDEO port
(16) S-VIDEO port
(17) Security slot (16)
(18) Security bar (16)
(continued on next page)
(1) (3)(2) (6)
(4)(5)
(11)(10)(4)(3)(2)
(5)
(8) (16)(7) (9) (14) (13) (12)
(1)
(15)(18)
(6)
(17)

6
Introduction
Part names (continued)
Remote control
(1) VIDEO button (21)
(2) COMPUTER button (21)
(3) SEARCH button (22)
(4) STANDBY/ON button (19)
(5) ASPECT button (22)
(6) AUTO button (24)
(7) BLANK button (27)
(8) MAGNIFY - ON button (26)
(9) MAGNIFY - OFF button (26)
(10) MY SOURCE/DOC.CAMERA button
(21, 57)
(11) VOLUME - button (20)
(12) PAGE UP button (18)
(13) PAGE DOWN button (18)
(14) VOLUME + button (20)
(15) MUTE button (20)
(16) FREEZE button (27)
(17) MY BUTTON - 1 button (56, 57)
(18) MY BUTTON - 2 button (56, 57)
(19) KEYSTONE button (26)
(20) POSITION button (24, 29)
(21) MENU button (28)
(22) ▲/▼/◄/► cursor buttons (28)
(23) ENTER button (28)
(24) ESC button (28)
(25) RESET button (29)
(26) Battery cover (17)
Back of
the remote control
(2)
(1)
(6)
(5)
(16)
(8)
(9)
(19)
(17)
(20)
(22)
(24)
(10)
(4)
(3)
(7)
(12)
(14)
(11)
(13)
(15)
(18)
(21)
(23)
(25)
(26)
VIDEO
DOC.CAMERA
KEYSTONE
ASPECT SEARCH BLANK
MUTE
MY BUTTON
POSITION
ESC
MENU
RESET
COMPUTER MY SOURCE/
AUTO
MAGNIFY PAGE
DOWN
ON
OFF
FREEZE
UP
࡯
㧗
VOLUME

ENTER

7
Setting up
Setting up
Install the projector according to the environment and manner the projector will be
used in.
For the case of installation in a special state such as ceiling mount, the speci ed
mounting accessories (Speci cations in the User’s Manual (concise)) and
service may be required. Before installing the projector, consult your dealer about
your installation.
Arrangement
Refer to tables T-1 and T-2 at the back of User's Manual (concise) as well as the
following to determine the screen size and projection distance. The values shown
in the table are calculated for a full size screen.
Ⓗ×Ⓥ : Screen size
ⓐ : Projection distance (from the projector's end)
ⓑ,ⓒ: Screen height
(continued on next page)
Projector top
Projector bottom

8
Setting up
Arrangement (continued)
WARNING
(continued on next page)
►Install the projector where you can access the power
outlet easily. If an abnormality should occur, unplug the projector urgently.
Otherwise it could cause a re or electric shock.
►Do not subject the projector to unstable conditions. If the projector falls
or topples over, it could result in injury or damage to the projector and the
surrounding things. Using a damaged projector could result in a re and an
electric shock.
• Do not place the projector in unstable places, such as an inclined surface,
places subject to vibration, on top of a wobbly table or cart, or a surface that is
smaller than the projector.
• Do not put the projector on its side, front or rear position.
• Do not attach nor place anything on the projector unless otherwise specied in
the manual.
• Do not use any mounting accessories except the accessories specied by the
manufacturer. Read and keep the manuals of the accessories used.
• For special installation such as ceiling mounting, be sure to consult your dealer
beforehand.
► Do not install the projector near thermally conductive or ammable
things. Such things when heated by the projector could result in a re and burns.
• Do not place the projector on a metal stand.
►Do not place the projector where any oils, such as cooking or machine
oil, are used. Oil may harm the product, resulting in malfunction, or falling from
the mounted position.
►Do not place the projector in a place where it may get wet. Getting the
projector wet or inserting liquid into the projector could cause a re and an
electric shock, and damage the projector.
• Do not place the projector near water, such as in a bathroom, kitchen, or
poolside.
• Do not place the projector outdoors or by the window.
• Do not place anything containing liquid near the projector.

9
Setting up
Arrangement (continued)
►Place the projector in a cool place with sufcient
ventilation. The projector may shutdown automatically or may malfunction if its
internal temperature is too high.
Using a damaged projector could result in a re and an electric shock.
• Do not place the projector in direct sunlight or near hot objects such as heaters.
• Do not place the projector where the air from an air conditioner or similar unit
will blow on it directly.
• Keep a space of 30 cm or more between a side of the projector and other
objects such as walls.
• Do not place the projector on carpet, cushions or bedding.
• Do not stop up, block nor cover the projector's vent holes. Do not place
anything around the projector that could be sucked in or stuck to the projector's
intake vents.
• Do not place the projector at places that are exposed to magnetic elds, doing
so can cause the cooling fans inside the projector to malfunction.
►Avoid placing the projector in smoky, humid or dusty place. Placing the
projector in such places could cause a re, an electric shock and malfunction of
the projector.
• Do not place the projector near humidiers. Especially for an ultrasonic
humidier, chlorine and minerals contained in tap water are atomized and could
be deposited in the projector causing image degradation or other problems.
• Do not place the projector in a smoking area, kitchen, passageway or by the
window.
• Position the projector to prevent light from directly hitting the
projector's remote sensor.
• Do not place the product in a place where radio interference may be caused.
• Check and correct the setting for FAN SPEED of SERVICE in the OPTION
menu according to the usage environment (57). If the projector is used with a
wrong setting, it may cause damage to the projector itself or the parts inside.
• Keep heat-sensitive things away from the projector. Otherwise, they may be
damaged by the heat from the projector.
CAUTION
NOTICE

10
Setting up
Connecting with your devices
Before connecting the projector to a device, consult the manual of the device to
conrm that the device is suitable for connecting with this projector and prepare
the required accessories, such as a cable in accord with the signal of the device.
Consult your dealer when the required accessory did not come with the product or
the accessory is damaged.
After making sure that the projector and the devices are turned off, perform
the connection, according to the following instructions. Refer to the gures in
subsequent pages.
Before connecting the projector to a network system, be sure to read Network
Guide too.
►Use only the appropriate accessories. Otherwise it could
cause a re or damage the projector and devices.
• Use only the accessories specied or recommended by the projector’s
manufacturer. It may be regulated under some standard.
• Neither disassemble nor modify the projector and the accessories.
• Do not use the damaged accessory. Be careful not to damage the accessories.
Route a cable so that it is neither stepped on nor pinched out.
WARNING
►For a cable with a core at only one end, connect the end
with the core to the projector. That may be required by EMI regulations.
CAUTION
• Plug-and-Play is a system composed of a computer, its operating system
and peripheral equipment (i.e. display devices). This projector is VESA DDC
2B compatible. Plug-and-Play can be used by connecting this projector to a
computer that is VESA DDC (display data channel) compatible.
- Take advantage of this feature by connecting a computer cable to the
COMPUTER IN1 port (DDC 2B compatible). Plug-and-Play may not work
properly if any other type of connection is attempted.
- Please use the standard drivers in your computer as this projector is a Plug-
and-Play monitor.
• Do not turn on or off the projector while connected to a device in
operation, unless that is directed in the manual of the device. Otherwise it may
cause malfunction in the device or projector.
• The function of some input ports can be selected according to your usage
requirements. Check the reference page indicated beside each port in the
following illustration.
• Be careful not to mistakenly connect a connector to a wrong port. Otherwise it
may cause malfunction in the device or projector.
- When connecting a connector to a port, make sure that the shape of the
connector ts the port.
- Tighten the screws to connect a connector equipped with screws to a port.
- Use the cables with straight plugs, not L-shaped ones, as the input ports of
the projector are recessed.
About Plug-and-Play capability
NOTE
(continued on next page)

11
Setting up
Connecting with your devices (continued)
• Before connecting the projector to a computer, consult the computer’s
manual and check the compatibility of the signal level, the synchronization
methods and the display resolution output to the projector.
- Some signal may need an adapter to input this projector.
- Some computers have multiple screen display modes that may include some
signals which are not supported by this projector.
- Although the projector can display signals with resolution up to UXGA
(1600x1200), the signal will be converted to the projector’s panel resolution
before being displayed. The best display performance will be achieved if the
resolutions of the input signal and the projector panel are identical.
• If you connect this projector and a notebook computer, you need output the
display to an external monitor, or output simultaneously to the internal display
and an external monitor. Consult the computer's manual for the setting.
• Depending on the input signal, the automatic adjustment function of this
projector may take some time and not function correctly.
- Note that a composite sync signal or sync-on-green signal may confuse the
automatic adjustment function of this projector (40).
- If the automatic adjustment function does not work correctly, you may not see
the dialog to set the display resolution. In such a case, use an external display
device. You may be able to see the dialog and set an appropriate display
resolution.
NOTE
(continued on next page)
Computer
(45)
(40) (40)
(54)
(39)

12
Computer
Access
point
USB
storage
device
(63)(63)
(54)
(59)
Setting up
Connecting with your devices (continued)
(continued on next page)
• If an oversized USB storage device blocks the LAN port, use a USB
extension cable to connect the USB storage device.
NOTE
► Before connecting the projector to a network system be sure
to obtain the consent of the administrator of the network.
►Do not connect the LAN port to any network that might have the excessive
voltage.
►The designated USB wireless adapter that is sold as an option is required to
use the wireless network function of this projector.
►Before removing the USB storage device from the port of the projector, be
sure to use the REMOVE USB function on the thumbnail screen to secure your
data (83).
►Do not use any extension cable or device when connecting the adapter to
the projector. Before you insert or pull out the USB wireless adapter from the
projector, turn off the power of the projector and pull out the power cord’s plug
from the outlet. Do not touch the USB wireless adapter while the projector is
receiving AC power.
►To connect both the LAN cable and USB device to the projector, use a LAN
cable that is at on the side where the plug’s wire is visible. Otherwise, both of
them cannot be connected correctly, or the wire may break (malfunction).
CAUTION
USB
wireless
adapter
(optional)
External device
(80)

13
(38)
(39)
VCR/DVD/Blu-ray DiscTM player
Setting up
• The HDMI port of this model is compatible with HDCP (High-band-
width Digital Content Protection) and therefore capable of displaying a video
signal from HDCP compatible DVD players or the like.
- The HDMI supports the following signals.
Video signal : 480i@60, 480p@60, 576i@50, 576p@50, 720p@50/60,
1080i@50/60, 1080p@50/60
Audio signal : Format Linear PCM
Sampling frequency 48kHz / 44.1kHz / 32kHz
- This projector can be connected with another equipment that has HDMITM
connector, but with some equipment the projector may not work properly,
something like no video.
- Be sure to use an HDMITM cable that has the HDMITM logo.
- Use a Category 2-certied HDMITM cable to input 1080p@50/60 signal to the
projector.
- When the projector is connected with a device having DVI connector, use a
DVI to HDMITM cable to connect with the HDMI input.
NOTE
Connecting with your devices (continued)
(continued on next page)
(45)
(39)
(40) (40)

14
Speakers
(with an amplier) Monitor
Microphone
system
Setting up
Connecting with your devices (continued)
• If a loud feedback noise is produced from the speaker, move the
microphone away from the speaker.
NOTE
• You can connect a dynamic microphone to the MIC port with a 3.5 mm mini-plug.
In that case, the built-in speaker outputs the sound from the microphone, even
while the sound from the projector is output. You can input line level signal to
the MIC port from equipment such as wireless microphone. Select HIGH in the
MIC LEVEL item of the AUDIO menu when you input line level audio signal to
the MIC port. In the normal mode, the volume of the microphone can be adjusted
separately from the volume of the projector using the menu (46). In the standby
mode, the volume of the microphone is adjustable with the VOLUME +/- buttons
on the remote control, in synchronization with the volume of the projector (20).
Even when the sound of projector is set to mute mode by the AUDIO SOURCE
function (45), the volume of the microphone is adjustable.
In both modes (standby or normal), the MUTE button on the remote control
works on the sounds of the microphone and the projector (20).
• This projector doesn't support plug-in power for the microphone.
Microphone function
(46)
(44)
(45)

15
Connecting to a power supply
1. Put the connector of the power cord into the
AC IN (AC inlet) of the projector.
2. Firmly plug the power cord’s plug into the
outlet. In a couple of seconds after the
power supply connection, the POWER
indicator will light up in steady orange.
►Please use extra caution when connecting the power cord, as
incorrect or faulty connections may result in re and/or electrical shock.
• Do not touch the power cord with a wet hand.
• Only use the power cord that came with the projector. If it is damaged, consult
your dealer to get a new one. Never modify the power cord.
• Only plug the power cord into an outlet whose voltage is matched to the power
cord. The power outlet should be close to the projector and easily accessible.
Remove the power cord for complete separation.
• Do not distribute the power supply to multiple devices. Doing so may overload
the outlet and connectors, loosen the connection, or result in re, electric shock
or other accidents.
• Connect the ground terminal for the AC inlet of this unit to the ground terminal
of the building using an appropriate power cord (bundled).
WARNING
AC IN
Power
cord
Please remember that when the DIRECT POWER
ON function activated (53), the connection of the
power supply make the projector turn on.
Setting up
►This product is also designed for IT power systems with a phase-to-
phase voltage of 220 to 240 V.
NOTICE

16
Use the supplied adapter cover to
prevent the USB wireless adapter from
coming off easily.
1. Loosen the screw (marked with
triangle) on the bottom left of the
USB TYPE A port.
2. Insert the tab of the cover into the
hole at the upper right of the USB
TYPE A port in the direction of the
arrow.
3. Align the screw holes on the
projector and the cover. Then
insert the screw removed from the
projector into the hole and tighten
the screw.
Using the security bar and slot
A commercially available anti-theft chain or
wire can be attached to the security bar on
the projector. Refer to the gure to choose
an anti-theft chain or wire.
Also this product has the security slot for
the Kensington lock.
For details, see the manual of the security
tool.
►Do not use the security bar and slot to prevent the projector
from falling down, since it is not designed for it.
WARNING
►Do not place anti-theft chain or wire near the exhaust vents.
It may become too hot.
CAUTION
• The security bar and slot is not comprehensive theft prevention
measures. It is intended to be used as supplemental theft prevention measure.
NOTE
Security slot
Anti-theft
chain or wire security bar
Setting up
Tab
Fastening the adapter cover
►Keep small parts away from children and pets. Take care not
to put in the mouth.
WARNING
2
1
3
20.3mm
17.5mm
11.7mm

17
(approx.)
Remote control
About the remote control signal
The remote control works with the projector’s remote
sensor. This projector has a remote sensor on the front.
The sensor senses the signal within the following range
when the sensor is active:
60 degrees (30 degrees to the left and right of the sensor)
within 3 meters about.
Installing the batteries
Please insert the batteries into the remote control before using it. If the remote control
starts to malfunction, try to replace the batteries. If you will not use the remote control for
long period, remove the batteries from the remote control and store them in a safe place.
1. Holding the hook part of the battery
cover, remove it.
2.
Align and insert the two AA batteries
(HITACHI MAXELL, Part No.LR6 or R6P)
according to their plus and minus terminals
as indicated in the remote control.
3.
Replace the battery cover in the direction of the arrow and snap it back into place.
►Always handle the batteries with care and use them only as
directed. Improper use may result in battery explosion, cracking or leakage,
which could result in re, injury and/or pollution of the surrounding environment.
• Be sure to use only the batteries specied. Do not use batteries of different
types at the same time. Do not mix a new battery with used one.
• Make sure the plus and minus terminals are correctly aligned when loading a battery.
• Keep a battery away from children and pets.
• Do not recharge, short circuit, solder or disassemble a battery.
• Do not place a battery in a re or water. Keep batteries in a dark, cool and dry place.
• If you observe battery leakage, wipe out the leakage and then replace a battery.
If the leakage adheres to your body or clothes, rinse well with water immediately.
• Obey the local laws on disposing the battery.
WARNING
• The remote control signal reected in the screen or the like may be available.
If it is difcult to send the signal to the sensor directly, attempt to make the signal reect.
• The remote control uses infrared light to send signals to the projector (Class 1
LED), so be sure to use the remote control in an area free from obstacles that
could block the remote control’s signal to the projector.
• The remote control may not work correctly if strong light (such as direct sun
light) or light from an extremely close range (such as from an inverter uorescent
lamp) shines on the remote sensor of the projector. Adjust the position of
projector avoiding those lights.
NOTE
Remote control
21 3

18
Changing the frequency of remote control signal
The accessory remote control has the two choices on signal
frequency Mode 1:NORMAL and Mode 2:HIGH. If the remote control
does not function properly, attempt to change the signal frequency.
In order to set the Mode, please keep pressing the combination of
two buttons listed below simultaneously for about 3 seconds.
Using as a simple PC mouse & keyboard
The accessory remote control works as a simple mouse
and keyboard of the computer, when the projector’s USB
TYPE B port and the computer’s type A USB port are
connected and MOUSE is selected for the USB TYPE B
item in the OPTION menu (54).
(1)
(3)
(5)
(2)
(4)
(6)
(1)
(2)
VIDEO
DOC.CAMERA
KEYSTONE
ASPECT SEARCH BLANK
MUTE
MY BUTTON
POSITION
ESC
MENU
RESET
COMPUTER MY SOURCE/
AUTO
MAGNIFY PAGE
DOWN
ON
OFF
FREEZE
UP
࡯
㧗
VOLUME

ENTER
VIDEO
DOC.CAMERA
KEYSTONE
ASPECT SEARCH BLANK
MUTE
MY BUTTON
POSITION
ESC
MENU
RESET
COMPUTER MY SOURCE/
AUTO
MAGNIFY PAGE
DOWN
ON
OFF
FREEZE
UP
࡯
㧗
VOLUME

ENTER
(1) PAGE UP key: Press PAGE UP button.
(2) PAGE DOWN key: Press PAGE DOWN button.
(3) Mouse left button: Press ENTER button.
(4) Move pointer: Use the cursor buttons ▲, ▼, ◄ and ►.
(5) ESC key: Press ESC button.
(6) Mouse right button: Press RESET button.
►Improper use of the simple mouse & keyboard
function could damage your equipment. While using this
function, please connect this product only to a computer. Be
sure to check your computer’s manuals before connecting this
product to the computer.
NOTICE
When the simple mouse & keyboard function of this product does not work
correctly, please check the following.
• When a USB cable connects this projector with a computer having a built-in pointing
device (e.g. track ball) like a laptop PC, open BIOS setup menu, then select the external
mouse and disable the built-in pointing device, because the built-in pointing device may
have priority to this function.
•
Windows 95 OSR 2.1 or higher is required for this function. And also this function may not work
depending on the computer’s congurations and mouse drivers. This function can work with the
computer which can operate general USB mouse or keyboard.
• You cannot do things like press two buttons at once (for instance, pressing two buttons
at the same time to move the mouse pointer diagonally).
•
This function is activated only when the projector is working properly. This function is not
available in any of the following cases:
- While the lamp is warming up. (The POWER indicator blinks in green.)
- When either USB TYPE A or USB TYPE B port is selected.
- While displaying BLANK
(47) , TEMPLATE (51) or MY IMAGE (71) screen.
- When any menu is displayed on the screen.
-
While using the cursor buttons to operate the sound or screen functions such as adjusting the
sound volume, correcting the keystone, correcting the picture position and magnifying the screen.
NOTE
(1) Set to Mode 1:NORMAL... VOLUME - and RESET buttons
(2) Set to Mode 2:HIGH... MAGNIFY OFF and ESC buttons
Please remember that the REMOTE FREQ. in the SERVICE item of
the OPTION menu
(  58) of the projector to be controlled should be
set to the same mode as the remote control.
USB TYPE B
port
Remote control

19
VIDEO
DOC.CAMERA
KEYSTONE
ASPECT SEARCH BLANK
MUTE
MYBUTTON
POSITION
ESC
MENU
RESET
COMPUTER MYSOURCE/
AUTO
MAGNIFY
PAGE
DOWN
ON
OFF
FREEZE
UP
࡯
㧗
VOLUME

ENTER
1. Make sure that the power cord is rmly and
correctly connected to the projector and the
outlet.
Turning on the power
2. Make sure that the POWER indicator is
steady orange (101). Then remove the
lens cover.
3. Press STANDBY/ON button on the
projector or the remote control.
The projection lamp will light up and POWER
indicator will begin blinking in green. When the
power is completely on, the indicator will stop blinking and light in steady
green (101).
Power on/off
To display the picture, select an input signal according to the section Selecting an
input signal (21).
►A strong light is emitted when the projector’s power is on.
Do not look into the lens of the projector or look inside of the projector through
any of the projector’s openings.
►Do not touch around the lamp cover and the exhaust vents during use or just
after use, since it is too hot.
WARNING
1. Press the STANDBY/ON button on the projector or the remote control.
The message “Power off?” will appear on the screen for about 5 seconds.
Turning off the power
2. Press the STANDBY/ON button again while the message appears.
The projector lamp will go off, and the POWER indicator will begin blinking in
orange. Then POWER indicator will stop blinking and light in steady orange
when the lamp cooling is complete (101).
3. Attach the lens cover, after the POWER indicator turns in steady orange.
Do not turn the projector on for about 10 minutes or more after turning it off.
Also, do not turn the projector off shortly after turning it on. Such operations might
cause the lamp to malfunction or shorten the lifetime of some parts including the lamp.
STANDBY/ON button
• Turn the power on/off in right order. Please power on the projector
prior to the connected devices.
• This projector has the function that can make the projector automatically turn on/
off. Please refer to the DIRECT POWER ON (53) and AUTO POWER OFF (54)
items of the OPTION menu.
NOTE
Power on/off
POWER indicator

20
Operating
1.
Adjusting the volume
Use the VOLUME +/VOLUME - buttons to adjust the volume.
A dialog will appear on the screen to aid you in adjusting the
volume. If you do not do anything, the dialog will automatically
disappear after a few seconds.
● When is selected for current picture input port, the volume
adjustment is disabled. Please see AUDIO SOURCE item of AUDIO menu
(45).
● Even if the projector is in the standby mode, the volume is adjustable when
both of the following conditions are true:
- An option other than is selected for STANDBY in the AUDIO SOURCE
item of the AUDIO menu (45).
- NORMAL is selected in the STANDBY MODE item of the SETUP menu (44).
● In the standby mode, the volume of the microphone is adjustable with the
VOLUME +/- buttons on the remote control, in synchronization with the volume
of the projector.
1. Press MUTE button on the remote control.
A dialog will appear on the screen indicating that you have muted
the sound.
To restore the sound, press the MUTE, VOLUME + or
VOLUME - button. Even if you do not do anything, the dialog
will automatically disappear after a few seconds.
Temporarily muting the sound
● When is selected for current picture input port, the sound is always muted.
Please see AUDIO SOURCE item of AUDIO menu (45).
● C.C. (Closed Caption) is automatically activated when sound is muted and an
input signal containing C.C. is received. This function is available only when
the signal is NTSC for VIDEO or S-VIDEO, or 480i@60 for COMPONENT,
COMPUTER IN1 or COMPUTER IN2, and when AUTO is selected for
DISPLAY in the C.C. menu under the SCREEN menu (52).
VOLUME +/- button
MUTE button
VIDEO
DOC.CAMERA
KEYSTONE
ASPECT SEARCH BLANK
MUTE
MY BUTTON
POSITION
ESC
MENU
RESET
COMPUTER MY SOURCE/
AUTO
MAGNIFY PAGE
DOWN
ON
OFF
FREEZE
UP
࡯
㧗
VOLUME

ENTER
VIDEO
DOC.CAMERA
KEYSTONE
ASPECT SEARCH BLANK
MUTE
MY BUTTON
POSITION
ESC
MENU
RESET
COMPUTER MY SOURCE/
AUTO
MAGNIFY PAGE
DOWN
ON
OFF
FREEZE
UP
࡯
㧗
VOLUME

ENTER
Operating
