The specification above and photography is for
reference only and may be subject to change.
CP-X880 & CP-X885
Technical Specifications
Image size Projector Distance
Diagonal Width (m) Min Max
CP-X880
3000 ANSI Lumens
CP-X885
3500 ANSI Lumens
CP-X880
CP-X885
OPTICAL CP-X880 CP-X885
Optical Structure 3 LCD Panels, One Projection Lens, RGB 3 LCD Panels, One Projection Lens, RGB
Shutter Method Shutter Method
LCD Panel 0.99”, P-Si TFT Panel x 3 0.99”, P-Si TFT Panel x 3 with Micro Lens
Resolution 1024 x 768 1024 x 768
Lens f=1.7~2.4 (f=31~46mm) f=1.7~2.4 (f=31~46mm)
Lamp 275W UHB 275W UHB
Lamp Life Over 2000 Hours Over 2000 Hours
Brightness 3000 ANSI lumens 3500 ANSI lumens
Contrast Ratio 500:1 800:1
Focus Distance 0.9~13.9m 0.9~13.9m
Display Size 30-300inches 30-300inches
Colour 8Bit/Colour, 16.7 Million Colours 8Bit/Colour, 16.7 Million Colours
COMPATIBILITY
Composite Video NTSC, NTSC4.43, PAL(-BGDHI), NTSC, NTSC4.43, PAL(-BGDHI),
PAL60, SECAM, PAL M,N PAL60, SECAM, PAL M,N
Component Video HDTV: 750p (720p), 1125i, HDTV: 750p (720p),1125i,
(1080i/1035i), (1080i/1035i),
SDTV: 525i (480i), 525p (480p), SDTV: 525i (480i), 525p (480p),
625i (575i) 625i (575i)
Computer VGA,SVGA, XGA, SXGA, UXGA, VGA,SVGA, XGA, SXGA, UXGA
MAC13”, MAC16”, MAC19” MAC13”, MAC16”, MAC19”
Plug & Play DDC1/2B DDC1/2B
Frequency Range Horizontal: 15~80kHz, Horizontal: 15~80kHz,
Vertical: 50~120Hz Vertical: 50~120Hz
FEATURES
Keystone Correction Keystone Automatic on Vertical only Keystone Automatic on Vertical only
Start Up Screen My Screen with Lock System My Screen with Lock System
Image Control H & V Keystone H & V Keystone
User Controls Picture in Picture, 11 Language Menus, Picture in Picture, 11 Language Menus,
Freeze Function, Magnifying, Freeze Function, Magnifying,
Digital Gamma Correction Digital Gamma Correction
Speakers 1W x 2 1W x 2
CONNECTORS
Computer Input 15pin D-sub, 5 x BNC, 1 x DVI 15pin D-sub, 5 x BNC, 1 x DVI
Video Input S-Video: Jack Terminal x 1, S-Video: Jack Terminal x 1,
Composite Video: RCA Jack terminal x 1, Composite Video: RCA Jack Terminal x 1
Component Video: RCA Jack Terminal x 3, Component Video: RCA Jack Terminal x 3,
Component Share RGB1 : BNC Terminal x 3 Component Share RGB1 : BNC Terminal x 3
RGB Output 15-pin Mini-Dsub Terminal x 1 (Selected OUT) 15-pin Mini-Dsub Terminal x 1 (Selected OUT)
Audio Output Stereo-mini Jack Terminal x 1 (Selected OUT) Stereo-mini Jack Terminal x 1 (Selected OUT)
Control 1 x RS-232 - 15-pin D-sub, 1 x USB 2 x RS-232 - 15-pin D-sub, 1 x USB
POWER
Power Supply AC100-120V/AC220~240V AC100-120V/AC220~240V
Power Consumption 430W 430W
PHYSICAL
Dimensions (WxHxD) 380 x 120 x 290mm 380 x 120 x 290mm
(excluding lens & legs) (excluding lens & legs)
Weight 5.7kg 5.7kg
Noise Level 35dB Whisper Mode 35dB Whisper Mode
Approvals UL60950/C-UL, FCC Part 15, UL60950/C-UL, FCC Part 15,
Class B, CE, TUV EN60950 Class B, CE, TUV EN60950
SUPPLIED WITH Remote Control, Power Cord, RGB Cable, Remote Control, Power Cord, RGB Cable,
Video Cable, USB Cable, Video Cable, USB Cable,
8-language Operators Manual 8-language Operators Manual
OPTIONS Long Throw Lens Long Throw Lens
Wireless RGB Wireless RGB
Wired Remote Control Wired Remote Control
Fabric Wheel Case (FLC800) Fabric Wheel Case (FLC800)
0
2
4
6
8
10
12
14 Width
Distance Min (m)
Distance Max (m)
6
3
12457
Screen distance - metres
Screen width - metres
30” (0.76m) 0.61 0.9m (34”) 1.3m (52”)
40” (1.02m) 0.81 1.2m (46”) 1.8m (71”)
50” (1.27m) 1.02 1.5m (58”) 2.3m (89”)
60” (1.52m) 1.22 1.8m (71”) 2.7m (107”)
70” (1.78m) 1.42 2.1m (83”) 3.2m (126”)
80” (2.03m) 1.62 2.4m (95”) 3.7m (144”)
90” (2.29m) 1.83 2.7m (108”) 4.1m (162”)
100” (2.54m) 2.03 3.0m (120”) 4.6m (181”)
120” (3.05m) 2.44 3.7m (144”) 5.5m (217”)
150” (3.81m) 3.04 4.6m (181”) 6.9m (272”)
200” (5.08m) 4.06 6.2m (243”) 9.2m (364”)
250” (6.35m) 5.08 7.7m (304”) 11.6m (455”)
300” (7.62m) 6.10 9.3m (366”) 13.9m (547”)

●3500 ANSI Lumens (CP-X885)
3000 ANSI Lumens (CP-X880)
●Full Connectivity
●Horizontal and Vertical Keystone Correction
●My Screen Option
●1.5x Zoom Lens
●35dB Whisper Mode
●Picture in Picture
●Full Function Remote Control
O tional Wireless and
Network Module (WNM80)
The optional wireless and network module is equipped with a communication card slot and a 10/100
BASE-TX Ethernet port. The benefit of this is that it allows both wireless and wired operation. For
wireless and presentations without a PC you can operate the projector without any cables being
connected to the PC, or you can give a presentation without a PC at all by using the PC card.
With the ability to connect up to four PCs without wires and the facility to project a maximum of four
screens with the projector, this module will allow you to create more sophisticated presentations.
When used in conjunction with the wireless full function remote control you can control on/off, input
selection and monitoring of lamp status, giving a true wireless presentation.
Convenient Ceiling Installation
Both of these projectors have a lamp replacement panel on the top, so it is easier to change the lamp
when the unit is suspended from the ceiling. Cable connection is stable due to the BNC terminal and
the projector can be controlled from far away using the wireless remote control.
Longer Lam Life
Through the development of new circuitry and improved airflow, the CP-X880 and CP-X885 now offer a
lamp life of over 2000 hours, resulting in lower operational and maintenance costs.
Enhanced Video Quality
Black Level Enhancement: In most video images the darkest areas of the picture are not fully black.
By forcing these areas to be black the perceived quality of the projected image can often be improved.
Normally, black enhancement is a linear adjustment which proportionately darkens all areas of the
picture causing an unwelcome reduction in midrange brightness. Hitachi’s advanced black
enhancement method avoids this by applying a measured adjustment to the darker areas while leaving
the brighter areas unaffected.
Image Noise Reduction
Image Noise Reduction: The CP-X880 and CP-X885 also uses digital image processing to reduce
excessive image noise. By continually comparing the value of each pixel over successive fields, any
abrupt or isolated change can be identified and suppressed resulting in a cleaner sharper image.
With an output of 3500 ANSI Lumens for CP-X885 and 3000 ANSI Lumens for
CP-X880, 0.99” Polysilicon active matix TFT panel and a UHB lamp, even 300”
images displayed are vivid and bright making these ideal projectors for installation
in medium to large venues. XGA resolution means that presentations containing
fine detail such as spreadsheets and diagrams are clear and sharp, whilst the
500:1 contrast ratio delivers superb graphics.
Advanced features enhance presentation quality and make set up and delivery
even easier. A major new development is the optional wireless and network
module, which allows you to operate the projector without any cables connecting
to the PC. You can also give a presentation without a PC at all by using the PC
card. Other features include Keystone correction, which can be made in both
vertical and horizontal directions, while the My Screen feature allows an image to
be displayed at switch on before the presentation begins. With full connectivity the
CP-X885 and CP-X880 models feature the usual DVI and component terminals,
with the addition of BNC terminals.
Advanced User Features
The CP-X885 and CP-X880 models boast a variety of features, which offer
outstanding brightness, picture quality, and convenience for all types
of presentations.
My Screen Function
The new My Screen feature allows the user to store an
image such as a company logo or a product picture in
the projector’s non-volatic memory. This image is then
displayed immediately when the projector is switched
on, even before any input sources are connected,
giving a more professional start to a presentation.
Horizontal and Automatic Vertical Keystone Correction
Setting up is both easier and more flexible thanks to integrated horizontal and
automatic vertical keystone correction, accessed directly via a single button on the
unit’s control panel. This feature means that the projector can be set off to the right
or left off the screen and correction can be applied to remove any image distortion.
Multi le In uts
Both the CP-X885 and CP-X880 offer virtually every input connection required to
accommodate today’s media sources. Video inputs cater for composite, S-video and
component video formats, all with stereo audio. On the computer side there are two
analogue RGB inputs and in addition to the the usual DVI and Component terminals,
these models have a new BNC terminal and also provide a D-sub 9-pin adapter.
Easy O eration
The easy Input Dial lets you check the selected input at a glance and switch it
easily in Jog Dial mode. And you can use the One-Touch button for quick vertical
keystone adjustments and input search.
1.5x Zoom Lens
The CP-X885 and CP-X880 both feature a 1.5x zoom lens as standard, which can be
used at distances from 3.1 to 4.6m to project a 100” screen. A 1.3 optional long
throw lens is also available which allows greater flexibility in
positioning the projector.
Wireless/Wired Full Function Remote Control
The remote control provides a Jog Dial to make
operation easier. Aspect switching is done directly
and in places where the infrared signal is not easy to
receive, it can be used as a wired remote control.
CP-X885 & CP-X880 Features
Pic A Pic B Pic C Pic D
Information
sharing
Output
Input
Normal
enhancement
Hitachi’s
enhancement
No enhancement
Wireless
PC-less
presentations
Wireless and PC-less resentations
+PC
PC Card
