Hitachi LP-WU9100B User manual

User's Manual
DLP®Projector
LP-WU9100B
Thank you for purchasing this product.
Read this manual before you use your projector.
Keep the manual for future reference.
ENGLISH
FRANÇAIS
DEUTSCH
ESPAÑOL
PORTUGUÊS
ㆶ։ѣᮽ
㑷儊ѣᮽ
뼑霢꽩
ɊɍɋɋɄɂɃ

English-3
INDEX
Warning, Notices, and Safety Instructions 4
Notice 4
Contents of package 4
Do not open 4
About Electro-Magnetic Interference 4
Description pertaining to FCC Rules Part 15 4
Disposal of Old Equipment and Batteries Only for
European Union and countries with recycling systems 5
Sunlight Warning 5
Never look into the projector light source directly 5
Keep any object away from concentrated projection light beam 5
Electric shock 5
Do not overload outlets/extension cords 6
Cleaning 6
Dampness, smoke, steam, dust, high temperature and direct
exposure to sunlight 6
Ventilation 6
Intrusion of foreign objects 6
&RROLQJÀXLG 
Carrying the projector 6
Install the projector on an even and stable surface 7
Servicing 7
Replacing parts 7
Power cord 7
Notices you should read prior to the installation of the
projector 8
Installation environment for the projector 8
&RQ¿JXUDWLRQVIRUSURMHFWRURSHUDWLRQDWKLJKDOWLWXGHV 
Protect the projector with care 8
Keep obstacles away from the projector's ventilation
inlets and outlets 8
Positioning Precautions 9
Take frequent breaks to rest your eyes 10
Caution for 3D 10
LASER WARNING 11
CLASS 3R LASER PRODUCT 11
Laser Parameters 11
Product labels 12
Location of laser aperture 14
Interlock switches 14
Projector parts and functions 15
Front view 15
LED indicator 15
Rear view 16
Control panel 16
Ports 17
Bottom view 18
Effective range of remote control signal 19
Installing batteries in the remote control 19
Installation of the projector 20
1. Installing the projector towards the screen 20
2. Removing the mount cap on the projector 20
3.
Selecting the correct input voltage depending
on your area 20
4. Connecting the power cord to the projector 20
5.
Connecting the projector to your PC and
VZLWFKLQJWR³ʜ´WRWXUQRQWKHSRZHU 
20
6. Starting up the projector 21
7. Adjusting the projector's angle, Lens Shift,
Zoom, Lens Centering, and Focus 21
8. Correcting the distortion 22
9. Turning off the projector 23
Throw distance 24
Modes of installation 24
Front/Desktop 24
Front/Ceiling 25
Rear/Desktop 25
Rear/Ceiling 25
Rear with a Mirror 25
Horizontal and vertical lens shift 26
Moving the lens vertically 26
Moving the lens horizontally 26
Connecting the projector to other devices 27
HDMI / DVI connection 27
12V OUTPUT connection 27
RGB connection 28
HDBaseT / LAN connection 28
SDI connection 29
Turning on the projector 29
Changing OSD language 29
Adjusting screen position 30
Front/Ceiling 30
Rear/Desktop 30
Rear/Ceiling 31
Adjusting the projector lens 31
Warranty and after-service 31

English-4 English-4
Warning, Notices, and Safety Instructions
Warning, Notices, and Safety Instructions
Notice
This product is intended for the adults who have the ability to operate this machine.
Write down your projector model number and serial number to keep the information for maintenance
purposes in the future. If the projector is lost or stolen, the information could also be used for the
police report.
Model number:
Serial number:
Contents of package
&KHFNWKHIROORZLQJDFFHVVRULHVWKDWFRPHZLWKWKHSURMHFWRU,I\RX¿QGDQ\PLVVLQJDFFHVVRU\
contact your dealer immediately.
1. AC Power Cord 4. AA battery (x2) 7. RS232 cable(cross)
2. Wired Remote Cable 5.
CD-ROM (User's Manual) 8. RGB cable
3. Remote control 6. Printed Manual 9. Mount cap
Do not open
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with an arrowhead within a triangle
is intended to tell the user that inside this product
may cause risk of electrical shock to persons.
The exclamation point within a triangle is intended to tell
the user that important operating and/or servicing instructions
are included in the technical documentation for this equipment.
CAUTION / TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER(OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
About Electro-Magnetic Interference
This is a Class Aproduct. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
This product may cause interference if used in residential areas. Such use must be avoided unless
the user takes special measures to reduce electromagnetic emissions to prevent interference to the
reception of radio and television broadcasts.
In Canada
CAN ICES-3(A) / NMB-3(A)
Description pertaining to FCC Rules Part 15
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment.

English-5 English-5
Warning, Notices, and Safety Instructions
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
CAUTION:
&KDQJHVRUPRGL¿FDWLRQVQRWH[SUHVVO\DSSURYHGE\WKHPDQXIDFWXUHUYRLGWKHXVHU¶VDXWKRULW\WR
operate the equipment.
Disposal of Old Equipment and Batteries Only for European Union and
countries with recycling systems
The above mark is in compliance with the Waste Electrical and Electronic Equipment
Directive 2012/19/EU (WEEE). The mark indicates the requirement NOT to dispose the
equipment including any spent or discarded batteries as unsorted municipal waste, but use
the return and collection systems available. If the batteries or accumulators included with this
equipment display the chemical symbol Hg, Cd, or Pb, then it means that the battery has a
heavy metal content of more than 0.0005% Mercury, or more than 0.002% Cadmium or more
than 0.004% Lead.
Note for the battery symbol (bottom symbol): This symbol might be used in combination
with a chemical symbol. In this case it complies with the requirement set by the Directive for
the chemical involved.
Sunlight Warning
Do not use this projector in direct sunlight.
Sunlight may cause serious damage to the digital mirror device (DMD ™) at the back of the projector
lens.
Never look into the projector light source directly
When turning on the projector, make sure that the projection light does not get
into someone's eye.
Never look into the projector light source directly.
As with any bright source, do not stare into the direct beam, RG2 IEC 62471-5:2015
Keep any object away from concentrated projection
light beam
%ORFNLQJWKHEHDPE\VRPHWKLQJFDXVHVKLJKWHPSHUDWXUHDQGFRXOGUHVXOWLQ¿UHRUVPRNH
Electric shock
Do not turn on the projector during thunderstorm, and unplug it from the outlet. This will prevent the
projector from being damaged by sudden electrical surges due to the thunderbolt.
RG2

English-6 English-6
Warning, Notices, and Safety Instructions
Do not overload outlets/extension cords
3D\DWWHQWLRQWRWKHFXUUHQWORDGRIWKHRXWOHWDQGFRUG\RXDUHXVLQJWRSUHYHQW¿UHRUHOHFWULFDOVKRFN
Cleaning
When cleaning the projector, be sure to unplug it from the outlet to prevent electric shock.
Do not use liquid or aerosol cleaners. Use a dry/damp cloth with excessive moisture removed for
cleaning. Be sure to use cleaning cloth designed to clean monitors for the projector to prevent damages
to the projector cabinet due to abrasion.
Dampness, smoke, steam, dust, high temperature and direct exposure
to sunlight
Do not operate the projector in environments where it could be exposed to dampness, smoke, steam,
dust, high temperature or direct sunlight. For example: bathroom, kitchen, around a washing machine,
damp basement rooms, electric heaters or similar environments. Keeping or operating the projector
in the above-mentioned environment could lead to discoloration, mold growth, adhesion of oil, or
damages to the projector.
Do not place the projector where any oils, such as cooking or machine oil, are used. Oil may harm the
product, resulting in malfunction, or falling from the mounted position. Do not use adhesive such as
threadlocker, lubricant and so on.
Ventilation
The projector cabinet is designed with slots and openings to remove the heat inside the projector
so that it will not overheat and damage the components. Be sure to operate the projector in an
environment with ideal ventilation and do not operate it on a sofa, rug or other closed-in environments
that could obstruct ventilation.
Do not touch around the exhaust vents during use or just after use, since it is too hot.
Intrusion of foreign objects
Be sure to keep all foreign objects away from entering the projector because it could be exposed to
KD]DUGRXVYROWDJHVDQGFDXVHSDUWVWRVKRUWFLUFXLW7KLVFRXOGOHDGWR¿UHKD]DUGRUHOHFWULFVKRFN
Examples of foreign objects include: cockroach, screws, liquid and so forth.
In addition, never spill liquid into the projector.
&RROLQJÀXLG
:KHQWKHSURMHFWRULVGDPDJHGFRROLQJÀXLGPD\FRPHRXWRILQWHUQDOUDGLDWRURUWKHWDQN1HYHU
touch or drink it. When you swallow it or it gets into the eye, consult a physician immediately for
emergency treatment.
Carrying the projector
The projector net weight is 28kg (without the lens). When carrying the projector on a cart,
be sure to handle the cart with care. The projector may fall due to abrupt stops, excessive
jolts, or uneven ground.

English-7 English-7
Warning, Notices, and Safety Instructions
Install the projector on an even and stable surface
Do not put the projector on unstable cart, tripod, table and so forth to prevent it from falling, being
damaged, or causing injuries.
Servicing
,I\RXKDYHDSUREOHPZLWKWKHSURMHFWRUFRQWDFW\RXUORFDOGHDOHURUTXDOL¿HGVHUYLFHSHUVRQQHO'R
not repair the projector by yourself so that you cannot be exposed to high voltage or other potential
hazards.
No servicing is allowed except by authorized personnel.
If you experience any of the following situation, unplug your projector from the outlet and contact a
TXDOL¿HGVHUYLFHSHUVRQQHOIRUDVVLVWDQFH
Damaged power cord or power plug.
If a foreign object has fallen into the projector or if you have spilled water or other liquid into the
projector.
If the projector has been dropped accidentally or damaged.
If you experience noticeably poor performance or malfunction of the projector despite having
followed instructions for normal operation.
Replacing parts
If any part of the projector is damaged, be sure to ask the service personnel to repair or replace with
the genuine parts and perform safety inspections to ensure that the projector operates normally. Using
QRQFHUWL¿HGSDUWVFDQQRWJXDUDQWHHWKHUHOLDELOLW\RIWKHSURMHFWRUDQGPD\UHVXOWLQGDPDJHVWRWKH
SURMHFWRURUKD]DUGVVXFKDV¿UHRUHOHFWULFVKRFN
No maintenance is allowed by users. Do not open the cabinet.
No parts inside are repairable by users.
Power cord
Do not place the projector where the cord can be stepped on. This may result in fraying or damage
to the power cord, especially at the plug and the point of connection between the power cord and the
projector.
,QFRPSOHWHSRZHUFRUGFRQQHFWLRQZLOOFDXVHVSDUNVRU¿UH
8VHWKHSRZHUFRUGEXQGOHGZLWKWKHSURMHFWRURUWKHW\SHRISRZHUFRUGVSHFL¿HGIRUWKHSURMHFWRUUHIHU
to the rating descriptions printed on the power cord). If you are not sure of the power available at the
UHJLRQ\RXDUHLQFRQVXOW\RXUORFDOSRZHUFRPSDQ\8VLQJDZURQJSRZHUFRUGKDVDSRWHQWLDORI¿UH
hazards due to current overload.
Depending on the country and region you are in, the voltage and type of socket of the outlet may be
GLIIHUHQWIURPWKHSURMHFWRU,I\RXDUHXQDEOHWR¿WWKHSRZHUSOXJLQWRWKHRXWOHWFRQWDFW\RXUORFDO
GHDOHU'RQRWUHPRYHWKHH[WUDSLQRQWKHSRZHUSOXJWRIRUFLEO\¿WLWWRWKHVRFNHWDWWKHULVNRI\RXU
own safety.
Connect the ground terminal for the AC inlet of this unit to the ground terminal of the building using
DQDSSURSULDWHSRZHUFRUGEXQGOHGRWKHUZLVHLWFRXOGFDXVH¿UHRUHOHFWULFVKRFN
Install the projector where you can access the power outlet easily.

English-8 English-8
Warning, Notices, and Safety Instructions
Notices you should read prior to the installation of the projector
Installation environment for the projector
Do not install the projector at place with excessive dampness, dust or smoke. If installation in such
environment is unavoidable, be sure to clean the interior of the projector routinely to prolong the
SURMHFWRUVOLIHF\FOH7KHSURMHFWRUVLQWHULRUVKRXOGEHFOHDQHGRQO\E\TXDOL¿HGVHUYLFHSHUVRQQHO
dispatched by your local dealer so do not clean the inside of the projector by yourself.
If other light source is directly projected onto the projector screen, the color of the picture from the
projector will appear to be pale and the picture quality will be lower. In addition, your eyes would be
more prone to fatigue. Therefore, it is recommended that the projector be installed in places without
direct exposure to sunlight or other strong light source.
The ideal operating temperature range : 0°C ~ 45°C (32°F ~ 113°F)
The ideal storage temperature range : -10°C~ 60°C (14°F ~ 140°F)
&RQ¿JXUDWLRQVIRUSURMHFWRURSHUDWLRQDWKLJKDOWLWXGHV
When operating the projector at higher altitudes, be sure to set the fan mode manually to “HIGH-1”,
“HIGH-2”, or “HIGH-3”. Otherwise, it could shorten the life of the optical system in the projector.
+LJKDOWLWXGHLVGH¿QHGDVSODFHVDWPHWHUVIHHWKLJKRUKLJKHU
For details, see User's Manual - Operating Guide.
Protect the projector with care
:KHQSODFLQJWKHSURMHFWRUDWDKLJKSRVLWLRQEHVXUHWRVHFXUHWKHSURMHFWRU¿UPO\VRWKDWLWZRXOG
not fall and cause injuries. Take care to protect the projector's lens from collision, abrasion or other
damages. Be sure to close the lens cover or cover the projector with a dust cover if you need to store
the projector or if it will not be used for a long time.
Keep obstacles away from the projector's ventilation inlets and outlets
3D\DWWHQWLRQWRWKHGLUHFWLRQRIDLUÀRZDWWKHGHVLJQDWHGVSRWRILQVWDOODWLRQ'RQRWOHWWKHKRWDLU
UHOHDVHGIURPWKHRXWOHWÀRZEDFNWRWKHLQOHWEHFDXVHLWZLOOSUHYHQWSURSHUFRROLQJDQGOHDGWR
damage of the projector's internal structure.
In the event of high temperature due to malfunctioning of the internal cooling fan caused by clogging at the
ventilation inlets and outlets, the projector will activate its automatic protection mode and shutdown. When
this happens, it does not necessarily mean that the equipment is malfunctioning. Unplug the power cord
from the outlet and wait approximately 15 minutes before operating the projector again (remember to remove
the objects that have caused poor ventilation so that the projector will not go into the protection mode again).
Description: Temperature inside the projector is automatically adjusted by cooling fans. Therefore, it does
not mean that a problem has occurred in the projector even if you hear the sound of cooling fan and its
operating speed change.

English-9 English-9
Warning, Notices, and Safety Instructions
Positioning Precautions
Although this projector can be installed in 360° range (including Portrait), life of optical parts will be
shorten in the following situation:
1. If the projector is installed with the lens facing downward.
2. If the projector is installed with the IO ports side facing upward at the Portrait situation.
90°
0°
180°
When there are the obstacles on both sides of the projector.
When there are the obstacles behind the projector.
30cm or greater 30cm or greater
50cm or greater Lens
Installing the projector with
the lens facing downward
is not recommended.
Installing the projector with the
IO ports side facing upward is
not recommended.
Portrait position
Tilt position

English-10 English-10
Warning, Notices, and Safety Instructions
Take frequent breaks to rest your eyes
Viewing the projected screen for a long time could strain your eyes. Be sure to rest your eyes
adequately.
Caution for 3D
Do not let children view in 3D when they are not accompanied by adults.
Refrain from 3D viewing for children under the age of six due to the possibility of vision
impairment. Be sure to check the health of children viewing in 3D because they may not express
that they are feeling unwell.
When viewing in 3D, be sure that you are at an appropriate distance from the front of the screen.
It is recommended to keep a distance of at least three times of the screen height.
Check that the settings are correct and the 3D effect is correctly applied. If the image is inversed
and images seen by the right and the left eye are swapped, the 3D effect is not working and it may
cause eyestrain or make you feel unwell.
Viewing in 3D is not appropriate for the following people because it may make their medical
conditions worse.
People with a history of photosensitive epilepsy
People with heart disease
Pregnant women
People with serious illness
People with a history of epileptic seizures
It is recommended to stop viewing in 3D if any of the following conditions occur.
When you feel unwell, tired, sleep-deprived, fatigued, or drunken.
The 3D image seems doubled or not clear.
Some people may feel like they are moving by themselves and get a symptom like "sea sickness"
when they view in 3D that rotates, rolls, or shakes.
Be sure to take a rest at regular intervals to avoid eyestrain when viewing in 3D for a long time.

English-11 English-11
Warning, Notices, and Safety Instructions
LASER WARNING
This symbol indicates that there is a potential hazard of eye exposure to
laser radiation unless the instructions are strictly followed.
CLASS 3R LASER PRODUCT
This Laser Product is designated as Class 3R during all procedures of operation.
LASER LIGHT - AVOID DIRECT EYE EXPOSURE.
'RQRWSRLQWODVHURUDOORZODVHUOLJKWWREHGLUHFWHGRUUHÀHFWHGWRZDUGRWKHUSHRSOHRU
UHÀHFWLYHREMHFWV
Direct or scattered light can be hazardous to eyes and skin.
There is a potential hazard of eye exposure to laser radiation if the described
instructions are not followed.
Caution – Use of controls, adjustments, or performance of procedures other than those
VSHFL¿HGKHUHLQPD\UHVXOWLQKD]DUGRXVUDGLDWLRQH[SRVXUH
Laser Parameters
Wavelength
Mode of operation
Pulse width
Pulse repetition rate
Maximum laser energy
Total internal power
Apparent light source size
Divergence
450nm - 460nm (Blue)
Pulsed, due to frame rate
0.5ms
240Hz
0.253mJ
>100W
>10mm (When the lens is stopping.)
>100 Milliradian

English-12 English-12
Warning, Notices, and Safety Instructions
Product labels
The position of the labels is shown in the drawing below.
Manufacturer’s ID
Serial No.
Hazard Warning for Aperture,
Certification Statement
and Explanation
POWER
STATUS
LIGHT
TEMP.
AVOID EYE CONTACTTO THE LIGHT
LP-WU9100B
LAN
IN OUT
SDI
COMPUTER IN 2
REMOTE
CONTROL HDBaseT HDMI 1 DVI-D HDMI 2
CONTROL V H B/Cb/Pb G/Y R/Cr/Pr COMPUTER IN 1
EXITMENU
LENS
SHIFT
INPUT ASPECT BLANK
LENS
CENTERING
AUTO
FOCUS ZOOM
12VOUTPUT
(OPTION)

English-13

3262152001
Complies with FDA
performance standards
for laser products
except for deviations
pursuant to Laser
Notice No. 50, dated
June 24, 2007
RISK GROUP 2
CAUTION
Possibly hazardous optical radiation emitted from this product.
Do not stare at operating lamp. May be harmful to the eyes.
GROUPE DE RISQUE 2
ATTENTION
Rayonnements optiques potentiellement dangereux émis par ce produit .
Ne regardez pas la lampe en fonctionnement. Peut être nocif pour les yeux.
RISIKOGRUPPE 2
ACHTUNG
Dieses Gerät gibt möglicherweise gefährliche optische Strahlung aus.
Bei Betrieb nicht direkt in die Lampe blicken. Dies könnte Augenschäden verursachen.
LASER RADIATION
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
Wavelength : 450-460 nm
Max. Pulse energy: 0.253 mJ, Pulse duration: 0.5 ms
IEC/EN 60825-1:2007
RAYONNEMENT LASER
ÉVITER D’EXPOSER DIRECTEMENT LENS YEUX
PRODUIT LASER DE CLASSE 3R
Longueur D’onde : 450-460nm
Énergie D’impulsion Max. : 0.253 mJ, Durée de L’impulsion : 0.5 ms
IEC/EN 60825-1:2007
LASERSTRAHLUNG
DIREKTE EXPOSITION DER AUGEN VERMEIDEN
LASERPRODUKT DER KLASSE 3R
Wellenlänge : 450-460 nm
Max. Pulsenergie: 0.253 mJ, Pulsdauer: 0.5 ms
IEC/EN 60825-1:2007
斵⫂巹⫂
弽󰾬婑䗺䘙䖲㉣㕲旰◦ 㵎᳉
5䯘斵⫂䏠⍿
㮠搵濣QP
㖾⟥俆圛侻悍PM俆圛ㆿ䵊㔀摑濣PV
,(&(1濣
RG2
LASER APERTURE
OUVERTURE LASER
LASERÖFFNUNG
斵⫂巹⫂ᴉ⨒⹏
CLASS 1 LASER PRODUCT
IEC/EN 60825-1:2014
PRODUIT LASER DE CLASSE 1
IEC/EN 60825-1:2014
LASERPRODUKT DER KLASSE 1
IEC/EN 60825-1:2014
ab
c
d
d
Warning, Notices, and Safety Instructions
a. Hazard Warning Symbol
b. Aperture Warning
F&HUWL¿FDWLRQ6WDWHPHQW
d. Explanation

English-14 English-14
Warning, Notices, and Safety Instructions
Location of laser aperture
The following is the laser aperture location. Be careful not to see the light directly.
Laser aperture
Interlock switches
This projector has interlock switches to prevent the laser light leakage.

cThe switch will power off the system when the top cover is opened.
dThe switch will power off the system when the lens is removed or not installed correctly.

English-15
Projector parts and functions
English-15
Projector parts and functions
Front view
POWER
Shows the power status.
Lights in red when the projector is in standby state.
Blinks when the projector is warming up or cooling down.
Lights in green when the projector is ON.
STATUS
Shows the system error status.
LIGHT
Shows the light source status.
TEMP.
Shows the thermal error message.
LED Indicator
Lens
Remote sensor
Adjustable foot
Adjust the height and angle of the
projector with the adjustable foot.
Note: Shorten the adjustable
feet completely when
transporting the
projector.
Ventilation inlet
The internal cooling fan draws cool
air from the ventilation inlet into the
projector.
Ventilation inlet
The internal cooling fan draws
cool air from the ventilation
inlet into the projector.
POWER
STATUS
LIGHT
TEMP.
LED indicator

English-16
Projector parts and functions
English-16
Rear view
Voltage Selector
(115V by default)
Adjustable foot
Remote sensor Power inlet
Control panel
Ports
Power switch
ۄ -> on
ż!RII
Ventilation outlet
STANDBY/ON
Starts up or shuts down the projector.
INPUT
Switches input signal source.
AUTO
Adjusts the signal synchronization automatically.
ASPECT
Adjusts the aspect ratio. )RUGHWDLOVVHH8VHU¶V0DQXDO2SHUDWLQJ
Guide.
LENS CENTERING
Sets the lens to the center and calibrates the parameter of lens shift
for focusing and zooming.
BLANK
Displays the blank image.
MENU
Displays or hides the menu.
Ÿź
ź Ÿ
BUTTONS
6FUROOVFRQ¿JXUHVRUDGMXVWVLWHPVRQWKHPHQXRUVZLWFKHVSLFWXUHV
ENTER
Applies the changed settings.
EXIT
Exits the menu or returns to previous OSD layer.
LENS SHIFT
Adjusts the projected image position.
FOCUS
Adjusts the focus of a projected image.
ZOOM
Zooms in or zooms out the projected image.
Control panel

English-17
Projector parts and functions
English-17
Ports
12V OUTPUT (OPTION)
Power terminal only for an optional
lens. Use this port when you need
power supply for the optional lens.
Do not connect other device to this
port. Put the cover when it is not
used. Refer to the manual of the
optional lens for details.
HDBaseT / LAN (RJ-45 jack)
Connects to HDBaseT source via LAN cable.
LAN
IN OUT
SDI
COMPUTERIN2
REMOTE
CONTROL HDBaseT HDMI1 DVI-D HDMI2
CONTROL V H B/Cb/Pb G/Y R/Cr/Pr COMPUTERIN1
CONTROL
9-pin D-sub socket. Connects to your PC or
automatic home theater /control system.
HDMI 1 & 2 (Digital audio/video connector)
Connects to HDMI or DVI source.
REMOTE
CONTROL
Usable wired-remote-control
with accessory cable. Available
for Niles or Xantech IR repeater
systems.
COMPUTER IN 2
Connects to BNC inputs for RGB (R/B/G/H/V) or component (YPbPr) source.
COMPUTER IN 1
Standard 15-pin VGA connection socket to
FRQQHFWWR5*%KLJKGH¿QLWLRQFRPSRQHQWLQSXW
or PC. The projector will automatically detect the
resolution of the input signal.
SDI IN/OUT
Serial digital interface, use BNC
connects input or output the picture.
Ports
DVI-D
Connects to DVI-D source.

English-18
Projector parts and functions
English-18
Bottom view
Screw hole for Mounting bracket
Used to mount the projector to its designated
mounting bracket using 6 M4x16 screws.
Adjustable foot
Adjusts the height and angle of the projector.
Note: Shorten the adjustable feet completely when
transporting the projector.

English-19
Projector parts and functions
English-19
Effective range of remote control signal
The illustration below shows effective range of remote control signal. (When new batteries are used.)
0°
0°

m
Note: Do not put the remote control at places with high temperature or humidity as it could cause the remote control to
malfunction.
Note: If the effective range of remote control signal reception decreases or if the remote control stops working, replace
the batteries.
1RWH,IWKHUHPRWHVHQVRULVH[SRVHGWRÀXRUHVFHQWODPSRUVWURQJVXQOLJKWWKHUHPRWHFRQWUROPD\QRWRSHUDWHQRUPDOO\
Installing batteries in the remote control
Note: Always handle the batteries with care and use them only as directed.
,PSURSHUXVHPD\UHVXOWLQEDWWHU\H[SORVLRQFUDFNLQJRUOHDNDJHZKLFKFRXOGUHVXOWLQ¿UHLQMXU\DQGRU
pollution of the surrounding.
Note: Keep a battery away from children and pets.
Note: Do not recharge, short circuit, solder or disassemble a battery.
Note: Be sure to insert the batteries in the right direction according to the polarity.
Note: Do not mix new battery with used ones. Otherwise, it would shorten the life of new batteries or cause leakage.
Note: Use AA batteies as instructed; do not insert different types of batteries into the remote control.
Note: If you will not use the remote control for long periods of time, be sure to remove the batteries to prevent leakage,
which could damage the remote control.
Note: The liquid contents in the batteries is harmful to the skin; do not touch the leakage with your bare hands directly.
When installing new batteries, be sure to clean up the leakage thoroughly.
Note: Refer to the regulations enforced by your local government on the disposal of used batteries; improper disposal
could damage the environment.
1.
2. Align and insert the two AAbatteries according to their plus
and minus terminals as indicated in the remote control.
(Use the appropriate AAcarbon-zinc or alkaline batteries
(non-rechargeable) in accordance with laws and regulations.)
3. Put the battery cover back to the former state.
Remove the battery cover.
(approx.)

English-20
Installation of the Projector
English-20
Installation of the projector
1. Installing the projector towards the screen
Screen
2. Removing the mount cap on the projector
3. Selecting the correct input voltage depending on your area
Select 200-240V
Select 100-130V
4. Connecting the power cord to the projector
Be sure that the power cord is not damaged and already connected to the power outlet properly.
Connect the female side of the power cord
to power input socket of projector.
Secure the power plug by locking
the plug holder clamp.
5. &RQQHFWLQJWKHSURMHFWRUWR\RXU3&DQGVZLWFKLQJWR³ʜ´WRWXUQRQWKHSRZHU
POWER indicator turns to red, which means the projector is in standby mode.
12VOUTPUT
(OPTION)
Desktop or laptop
computer
