Hitachi HDB65 User manual

Instruction manual
To obtain the best performance and ensure years of
trouble-free use. please read this instruction manual
completely.
Model
HDB65
Digital Terrestrial TV Receiver
free to view

- 1 -
CONTENTS
SOME DOS AND DONTS ON THE SAFE USE OF EQUIPMENT ....................... 2
SAFETY PRECAUTIONS ........................................................................................ 3
IN THE BOX ............................................................................................................ 4
AV SWITCHING ....................................................................................................... 4
OVER AIR DOWNLOAD ......................................................................................... 4
WIRING THE PLUG ................................................................................................ 4
WIRING INSTRUCTIONS ........................................................................................ 5
WARNING ................................................................................................................ 5
IMPORTANT ............................................................................................................ 5
YOUR DIGITAL RECEIVER .................................................................................... 6
REMOTE CONTROL HANDSET .............................................................................
REMOTE BUTTONS ................................................................................................ 8
PREPARATION ........................................................................................................ 9
CONNECTIONS ....................................................................................................... 9
CONNECTING A VCR .......................................................................................... 10
MENU INTERFACE ............................................................................................... 11
FIRST TIME INSTALLATION ................................................................................. 11
MAIN MENU .......................................................................................................... 11
CHANNEL LIST ..................................................................................................... 11
NAVIGATING THE CHANNEL LIST ....................................................................... 11
DELETING UNWANTED CHANNEL ..................................................................... 12
RENAMING CHANNELS ..................................................................................... 12
ADDING LOCKS TO CHANNELS ........................................................................ 12
SETTING FAVOURITES ....................................................................................... 12
FAVOURITES ....................................................................................................... 12
TIMERS MENU .................................................................................................... 13
SETTINGS ............................................................................................................ 13
CONFIGURATION ................................................................................................ 13
SUBTITLE ............................................................................................................. 14
TV TYPE ............................................................................................................... 14
TV OUT ................................................................................................................. 14
FAVOURITE MODE .............................................................................................. 14
CHANNEL LIST .................................................................................................... 14
RECEIVER UPGRADE - OAD ............................................................................. 14
PARENTAL SETTINGS ......................................................................................... 15
MENU LOCK ........................................................................................................ 15
SET LOCK KEY ................................................................................................... 15
LANGUAGE ......................................................................................................... 15
INSTALLATION ..................................................................................................... 16
AUTOMATIC SEARCH ......................................................................................... 16
MANUAL SEARCH .............................................................................................. 16
FIRST TIME INSTALLATION ................................................................................ 16
ELECTRONIC PROGRAM GUIDE ...................................................................... 16
( -DAY - EPG) ...................................................................................................... 16
MESSAGES......................................................................................................... 1
CHANNEL NAVIGATION ...................................................................................... 1
VOLUME CONTROL ............................................................................................ 18
DIGITAL TELETEXT ............................................................................................. 18
SUBTITLE ............................................................................................................. 18
WIDESCREEN ..................................................................................................... 18
APPENDIX A - SAFETY ...................................................................................... 19
APPENDIX B - SPECIFICATION ......................................................................... 20
APPENDIX C - TROUBLESHOOTING GUIDE .................................................... 22

- 2 -
SOME DOS AND DONTS ON THE SAFE USE OF EQUIPMENT
This equipment has been designed and manufactured to meet international safety standards but, like any
electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured.
**************
DO read the operating instructions before you attempt to use the equipment.
DO ensure that all electrical connections (including the mains plug, extension leads and inter-connections
between the pieces of equipment) are properly made and in accordance with the manufacturer s instructions.
Switch off and withdraw the mains plug before making or changing connections.
DO consult your dealer if you are ever in doubt about the installation, operation or safety of your equipment.
DO be careful with glass panels or doors on equipment.
DO route the mains lead so that it is not likely to be walked on, crushed, chafed, or subjected to excessive
wear and tear or heat
DONT remove any fixed cover as this may expose dangerous voltages.
DONT obstruct the ventilation openings of the equipment with items such as newspapers, tablecloths,
curtains, etc. Overheating will cause damage and shorten the life of the equipment.
DONT allow electrical equipment to be exposed to dripping or splashing, or objects filled with liquids, such
as vases, to be placed on the equipment.
DONT place hot objects or naked flame sources such as lighted candles or nightlights on, or close to
equipment. High temperatures can melt plastic and lead to fires.
DONT use makeshift stands and NEVER fix legs with wood screws - to ensure
complete safety always fit the manufacturer s approved stand or legs with the fixings
provided according to the instructions.
DONT use equipment such as personal stereos or radios so that you are distracted from
the requirements of traffic safety. It is illegal to watch television whilst driving.
DONT listen to headphones at high volume, as such use can permanently damage your hearing.
DONT leave equipment switched on when it is unattended unless it is specifically stated
that it is designed for unattended operation or has a stand-by mode. Switch off using the
switch on the equipment and make sure that your family know how to do this. Special
arrangements may need to be made for infirm or handicapped people.
DONT continue to operate the equipment if you are in any doubt about it working
normally, or if it is damaged in any way - switch off, withdraw the mains plug and consult
your dealer.
ABOVE ALL
 NEVER let anyone especially children push anything into holes, slots or any other opening in the case
- this could result in a fatal electrical shock;
 NEVER guess or take chances with electrical equipment of any kind
 it is better to be safe than sorry!
******

- 3 -
SAFETY PRECAUTIONS
Power Source
The unit should be operated only from a 230-240V~ 50 Hz outlet. Please do not open the cover by yourself.
There is high voltage in the set, which will endanger your life. Please contact local service agent for help
and advice. Repairs should be carried out by a qualified technician only.
The apparatus is not disconnected from the AC power source (mains) as long as it is connected to the wall
outlet, even if the apparatus itself has been turned off.
If you are not going to use the apparatus for a long time, be sure to disconnect the apparatus from the wall
outlet.
Power Cord
Do not place the unit, a piece of furniture, etc., on the power cord (mains lead), or pinch the cord. Handle
the power cord by the plug. Do not pull out the plug by tugging the cord and never touch the power cord when
your hands are wet as this could cause a short circuit or electric shock. Never make a knot in the cord or
tie it with other cords. The power cords should be routed in such a way that they are not likely to be stepped
on. A damaged power cord can cause fire or give you an electrical shock. Check the power cord once in
a while. When you find it damaged, ask closest service agent for help. When the AC power cord needs to
be changed, it should be done at a qualified service shop only.
Choice of Location
Please do not place the set in a place subject to direct sun light, excessive dust or mechanical shock or
in a location near heat sources.
The set should be placed on a solid and safe base. Do not place the apparatus on a soft surface such as
a rug that might block the ventilation holes on the bottom.
A location should not be selected such as a room with high humidity, as the condensation, arising in the kitchen
for example, may cause malfunction or damage the set.
Heating or other thermal radiation under the set also may cause malfunction or damage the set.
The hot air, which arises during the operation, should be ventilated with sufficient air circulation. Please do
not put the set into closed areas and do not cover it.
Please avoid the contact of the set with water or humidity. Do not put into operation near bath, swimming
pools.
Take care to provide a good air circulation. Place the apparatus in a location with adequate ventilation to prevent
heat build-up in the apparatus.
Should any solid object or liquid fall into the cabinet, unplug the apparatus and have it checked by qualified
personnel before operating it any further.





The

- 4 -
IN THE BOX
Inside your DB65 receiver package you should have:
This user guide
DB65 digital terrestrial television receiver
Set of batteries for the remote control
Remote Control
SCART cable
AV SWITCHING
If after connecting the DB65 to your TV as shown you do not see a picture, press AV button on your
TV remote until you see the First Time Install screen.
OVER AIR DOWNLOAD
Over Air Download: To ensure that your digital receiver always has the most up todate information. Please
ensure that after use it is set to its standby mode. The DB65 automatically powers up at 3AM each day
and searches for any new information which may be broadcast and will download this to your box
automatically. This operation will normally take approximately 30 seconds.
If you have an important recording to make at 3AM which must not have a 30 second interrupt then you
can disable the auto OAD search by performing the following:
1. Press Menu button and using the up / down buttons highlight SETTINGS and press the SELECT button,
2. Highlight CONFIGURATION and press the SELECT button,
3. Use the up and down buttons to highlight "RECEIVER UPGRADE" and press SELECT button.
4. The Over Air Download commences.
5. Press button MENU to cancel or to return to Normal operation.
WIRING THE PLUG
If your receiver is fitted with a non-rewireable plug and you need to change the fuse, you will need to refit
the fuse cover. If you lose or damage the fuse cover, do not use the plug until you have replaced the cover
with a new one. You can get one from us. Make sure you replace the fuse cover with one which is the same
colour as the markings on the fuse.
If you have to change the plug because it is not suitable for your socket or it is damaged, cut off the plug
and fit another one following the wiring instructions below. Please throw away the plug you have removed,
as insertion into a mains socket could cause injury.For your own safety, read the following instructions carefully
before attempting to connect this unit to the mains.

- 5 -
WIRING INSTRUCTIONS
Your receiver is designed to operate on 230 to 240V, 50Hz current only. Connecting it to another power source
may damage the receiver.The wires in the mains lead are coloured as follows.
Blue = Neutral Brown = Live
WARNING
To prevent electric shocks, remove the plug from the mains socket before you take off its cover.
IMPORTANT
The colours of the wires in the mains lead from your receiver may not be the same as the coloured markings
identifying the terminals in your plug. So please follow these instructions.
Connect the blue wire to the terminal marked with the letter N or coloured black.
Connect the brown wire to the terminal marked with the letter L or coloured red.
Do not connect any wire to the other terminal on the plug. If you use a 13 Amp (BS1363) plug, you will need
a 5 Amp fuse.
If you use any other type of plug, you will also need a 5 Amp fuse either in the plug or on the distribution
board.
/LYH
%URZQ
1HXWUDO
%OXH
)XVH


$
:$51,1*
'212723(1
5,6.2)(/(&75,&.6+2&.

- 6 -
YOUR DIGITAL RECEIVER
Front
,5,QIUDUHG6WDQGE\/('
Back
$8',2/
79287 $17(11$ 9&5
79
$&9
+]
a
$8',25
79
287 $(5,$/ ,1 796&$57 9&56&$57 $8',2
/()75,*+7

- 7 -
REMOTE CONTROL HANDSET
79'79
6WDQGE\
1XPHULF
:LGH
3URJUDPPHXS
3URJUDPPHGRZQ
 
9ROXPHXS
9ROXPHGRZQ

,QIR+HOS
3DJHXS5HG
8S
/HIW
3DJHGRZQ*UHHQ
([LW
6XEWLWOH
0XWH
*XLGH
0HQX
%OXH
5LJKW
'RZQ
6HOHFW
<
HOORZ
7H[W

- 8 -
REMOTE BUTTONS
Button Function
1 Standby Turn the receiver on and off
2 Mute Mutes the Sound
3 TV/DTV Exit most menus to return to television viewing
Switch the TV set between analogue, digital TV and VCR
4 Menu Display the Main Menu. Exits menus
5 Up, Down, Left, Right Move between menu items
6 Select Make selection in a menu
7 Number keys Change channels
Enter PIN code
Enter numbers and letters into menus
8 Guide Display and exit electronic programme guide
9 V+, V- Adjust the received audio volume
10 P+, P- Change channels
11 Page Up/Red Move up a page through channel list
Move to top in EPG programme details
Select red option in digital teletext
12 Page Down/Green Move down a page through channel list
Select green option in digital teletext
Move to bottom in EPG programme details
13 Yellow Scroll up through EPG programme details
Select yellow option in digital teletext
14 Blue Scroll down through EPG programme details
Select blue option in digital teletext
15 Wide Select screen format
16 i Display menu help
17 Text Start and stop digital teletext
18 Exit Return to Exit from menu
19. Subtitle Turn Subtitles ON and OFF

- 9 -
PREPARATION
CONNECTIONS
Place your DB65 receiver on a firm, level surface with at least a 10cm gap around all sides of the case
and in a position convenient for connection to your television, a mains power outlet and a TV aerial wall outlet
(or the 'flying lead' from your TV aerial, as appropriate).
Please refer to the safety section in Appendix A.
Turn off your television at the mains and disconnect the lead going to the aerial wall outlet (or the flying aerial
lead) and connect this to the ANT IN socket on the rear of the receiver. Connect the aerial cable supplied
from the TV OUT socket on the receiver to the TV set's aerial socket.
Connect the TV SCART socket on the rear of the receiver to a suitable SCART socket on your television.
There may be more than one SCART socket on your television and, if unsure which to use, you should refer
to its manual for guidance.
I
+L)L
79$HULDO
$8',2/
79287 $17(11$ 9&579
$&9
+]
a
$8',25
79
$HULDO
,Q
796FDUW,Q
79
Finally, plug the receiver into the mains outlet.
Remove the battery compartment cover from the rear of the remote control handset by lifting the catch
at one side. Insert two AAA (MN2400) sized batteries, taking care to observe the correct orientation as marked
on the inside of the compartment. Replace the compartment cover.

- 10 -
CONNECTING A VCR
If you have a VCR or other equipment connected to your television, please connect the receiver as described
here.
Unplug the aerial lead and connect this to the ANT IN socket on the rear of your receiver. Connect the aerial
lead (supplied) from theTV OUT on the receiver to the ANT IN on the rear of the VCR. Then connect an aerial
lead from the TV OUT on the VCR to the ANT IN socket on the rear of your TV.Connect a scart lead from
the TV SCART socket on the rear of the receiver to the SCART 1 socket on the rear of the TV. Connect
a scart lead from the VCR SCART to the SCART 1 on the VCR.
79
$8',2/
79287 $ 17 (11$ 9&579
$& 9
+]
a
$8',25
79$HULDO
+L)L
9&5
6FDUW
79
$HULDO $HULDO,Q
79 , 1 $17(11$
You can now record digital terrestrial television programmes by selecting SCART 1 on the VCR. The VCR
will also be able to record analogue television channels in the usual way. Both live and recorded digital terrestrial
television programmes can be viewed on the TV by selecting the TV's AV input.

- 11 -
MENU INTERFACE
FIRST TIME INSTALLATION
When the box is first turned on from stand-by mode
and if there is no channel stored in the database,
First Time Installation Menu window is displayed on
the screen. In the first window, you have to set your
TV type.
If you press SELECT then Do you want to start
automatic search? pop-up menu is displayed. Auto
search can be started by selecting Yes button. The
box will automatically find the channels and store
them for you.
See Page 16 for more information about Installation
MAIN MENU
The Main Menu is accessed, pressing the MENU
key.
The items accessed through the Main Menu are:
1.) Channel List 2.) Favourites
3.) Timers 4.) Settings
CHANNEL LIST
The following operations can be performed
in this menu:
1. Navigating the whole list of channels
2. Deleting unwanted channels
3. Renaming channels
4. Adding locks to channels
5. Setting the favorite list
Channel table is the place where the
channels are managed.
NAVIGATING THE CHANNEL LIST
In the channel table [UP] or [DOWN] keys serves
for moving the focus to the previous or next
channel, RED BUTTON / GREEN BUTTON for page
up and page down. To watch a specific channel
highlight it using, [UP] or [DOWN] then press
SELECT key while the SELECT button is
highlighted. Then the name and number of the
selected channel will be displayed in the top-right
corner of the screen. If the selected channel is
password protected then a pop up menu is
displayed. If the correct code is entered then the
selected channel can be watched. After the
password box disappears, you can navigate through
the other channels using the [UP] or [DOWN] keys.
The scroll Bar in middle of the screen shows relative
position of the currently visible channels with
respect to the whole list.

- 12 -
DELETING UNWANTED CHANNEL
To delete a channel highlight it using [UP] and
[DOWN] and RED/GREEN buttons, then highlight
the Delete button using [LEFT] or [RIGHT] keys
and press SELECT. A message is displayed to
confirm your decision, if you still want to delete
press SELECT once more and the channel will be
deleted, else the operation will be cancelled if you
select NO.
RENAMING CHANNELS
To rename a specific channel, the name must be
highlighted and then select the Edit Name button
and SELECT key must be pressed. The name
appears on the right side of the menu with the first
character highlighted. Now [LEFT] or [RIGHT] keys
moves to the previous/next character. [UP] or
[DOWN] toggles the current character, i.e., b
character becomes a on UP and c on DOWN.
Pressing the numeric buttons 0...9 replaces the
highlighted character with the characters printed
above the button one by one as the button is
pressed. Pressing MENU cancels the editing and
SELECT saves the new name.
ADDING LOCKS TO CHANNELS
Channel Locking provides a password-protected
access to channels selected by parents. In order to
lock a channel you should know the parental Lock
password (set to 0000 in the factory and can only
be changed from the Configuration Menu), highlight
the channel to be locked and select the Lock
button, when SELECT is pressed a password dialog
is displayed. Enter the parental Lock code, press
SELECT and the Lock icon will be displayed in front
of the selected channel. Repeat the same operation
to cancel the Lock.
SETTING FAVOURITES
In channel list highlight Favourites by pressing
[LEFT] or [RIGHT]  keys then press SELECT. The
unit will automatically switch to menu Edit Favourite
List in the Main menu. For detailed explanation see
Favourites
FAVOURITES
Favourite lists provide an easy way to group
programs in a customizable way. Five favourite lists
are available on this product named as List1, List2,
List3, List4 and List5.
1. To access the favourite menu press
MENU then use [UP] and [DOWN] buttons to
highlight favourites and press SELECT to enter the
Edit favourite Lists menu.
2. Press SELECT to add the highlighted
programme to your list and continue to add
the programmes you want included in your
favourites.
3. Once complete press MENU to save your
settings.
To access your favourites follow the steps
below:
1.Press MENU button.
2.Press [UP] and [DOWN] buttons to highlight
SETTINGS and press SELECT to enter.
3.Press SELECT again to enter the Configuration
menu.
4.Use the [UP] and [DOWN] to highlight Favourite
Mode and press the [LEFT] or [RIGHT]  buttons
to select your preferred favourite list (e.g. OFF/
List1/List2/ List3/List4/ List5).
5. Press menu to exit.
6.Now when you press the P-/P+ buttons only the
programmes selected in your favourites list will
appear on the screen.

- 13 -
TIMERS MENU
Timer Menu is entered from the Main Menu. There
is a five column summary information, such as
timer no, channel name, start time, end time, start
date and mode, for each of the five timers.
There are two ways to set a timer. If the start/end
time and date are valid numbers, the timer can be
set directly by changing the mode from Inactive
to Active using [LEFT] or [RIGHT] cursors.If the
start/end times and date are invalid or if the set
values are to be changed totally, OK must be
pressed while the desired timer is highlighted in the
summary list. A new window where the timer details
are to be entered will be displayed on the lower part
of the screen. The timer details are as follows:
Name: According to the type that is chosen above, [LEFT] or
[RI HT] keys will navigate the user through the TV or Radio list
and name of the program is selected.
Start: By using 0,1,2,9 keys start time of the
timer is entered.
End: By using 0,1,2,9 keys end time of the
timer is entered.
Date: By using 0,1,2,9 keys date of the timer
is entered.
Mode: By using [LEFT] or [RIGHT] keys, timer
mode is selected as Once, Daily or  Weekly .
Password: By using 0,1,2,9 keys Password is
entered.(If the programme you wish to record is
password protected)
Start, End and Date field data are entered using
number keys. Current time and date are shown on
the lower-right part of the screen to help you.After
the desired detail fields are filled, you can turn back
to the timer info summary list by pressing OK to
save the settings, or by pressing Menu to cancel
these new settings. A set timer is cancelled
(disabled) by changing the mode to Inactive in
timer summary list.When a timer start time is
reached, the Set-Top-Box switches to the set
channel, then when the end time is reached, the box
goes to stand-by mode. This utility helps the box to
be used as a sleep-timer.
SETTINGS
The submenus in the Settings are:
· Configuration · Language · Installation
CONFIGURATION
You can configure the settings of your box. Select
Configuration from Settings Menu and Press
SELECT to enter this menu. Press MENU button to
exit. Configuration Menu includes the following main
items.
· Subtitle
· TV Type
· TV Out
· Favourite Mode
·Channel List
· Receiver Upgrade
·Parental Settings.

- 14 -
SUBTITLE
Digital terrestrial television channels can broadcast
with subtitles displayed on-screen for the hard-of-
hearing. This function selects the desired subtitle
language and enables the automatic display of
subtitles whenever subtitle information is broadcast.
Highlight the Subtitle line in the Configuration menu
and use the [LEFT] or [RIGHT] keys to cycle
through the disable and language options.Return NO
MENU to normal TV viewing by pressing the [MENU]
key.
TV TYPE
Digital terrestrial television channels can broadcast
programmes in a widescreen format which must be
output differently to normal and widescreen TV sets.
This function tells the receiver the screen format of
the TV connected so that broadcasts are displayed
correctly.Highlight the TV Type line in the
Configuration menu and use the [LEFT] or [RIGHT]
keys to select 4:3 if you have a standard TV set
connected or 16:9 if it is a widescreen TV. This
function duplicates the selection made at the time
of first installation and can be used if you change
TV sets.Return NO MENU to normal TV viewing by
pressing the [MENU] key.
TV OUT
The receiver can output either an RGB or CVBS
signal from the TV SCART on the rear panel.
Although the RGB format results in a better quality
picture, not all equipment - particularly some VCRs
- can cope with an RGB signal.
FAVOURITE MODE
This function enables or disables the 5 favourite
channel list mode by pressing [LEFT] or [RIGHT]
buttons and press OK .If it has Favourite channel
it will switch to that channel. If there is no favourite
channel, a warning message is displayed.
NOTE: If you select some programmes as
Favourite and Favourite list mode is activated,
only those channels will appear in the EPG.
CHANNEL LIST
Use [UP] or [DOWN] buttons to go to Channel List
option. Use [LEFT] or [RIGHT]buttons to toggle
Channel List Mode. If you select TV Only, only the
TV channels are listed in Channel List. . If you select
Radio Only, only the Radio channels are listed in
Channel List. If you select Text Only, only the Text
channels are listed in Channel List. If you choose
Show All all channels will be displayed. To save
the recent changes press SELECT button.
RECEIVER UPGRADE - OAD

- 15 -
In Configuration menu with the [UP] or [DOWN]
keys Receiver Upgrade is highlighted and with
SELECT, it is activated. With OAD (Over-Air 
Download) you can upgrade your unit. Also you can
see the version of the software in your receiver.
See Page 4 for more details of Over Air Download
PARENTAL SETTINGS
Use [UP] or [DOWN buttons to go to Parental
Settings option. Press SELECT button to enter
Parental Settings Menu.A box asking for the lock
key is displayed.
There you can set/reset locking for the Main Menu,
or the Installation Menu to restrict access. If the
menu lock is disabled, there will be free access to
the menu system. You can change the lock key.
There is only one key which is set to 0000 initially.
Enter lock key. If it is incorrect, the menu will
reappear asking for the Lock Key again.
If it is correct, the Parental Settings Menu including
following items is displayed:
MENU LOCK
Use [UP] or [DOWN] buttons to go to Menu Lock
option. Use [LEFT] or [RIGHT] buttons to toggle
Menu Lock Mode.
DISABLED : All menus are unlocked.
MAIN MENU : Main Menu is accessible only with the
correct lock key.So the user can t add, delete,
rename, channels, can t set timers.
INSTALLATION: Installation menu is locked.So the
user can t add channels.
Changes will be updated after exiting Configuration
Menu .
SET LOCK KEY
Use [UP] or [DOWN] buttons to go to Set Lock Key
option. Use SELECT button to enter new password.
New Password Menu is displayed. Use NUMERIC
buttons to enter new password. New Password is
asked twice for confirmation.If both passwords are
four digits long and the same, the password is
changed. It is updated after exiting the Parental
Menu.
LANGUAGE
In this menu the user can adjust the preferred
language. Language is changed by pressing
SELECT key.
System: to alter the language press SELECT key.
Preferred: press SELECT to activate it. By
pressing [UP] or [DOWN] highlight Audio or Subtitle
Language.
With [LEFT] or [RIGHT] buttons you can set the
preferred language. The chosen language will be
seen in subtitles.
Current: via SELECT button current language can
be changed. By pressing [UP] or [DOWN]highlight
Audio or Subtitle. With [LEFT] or [RIGHT] buttons
you can set the preferred language.

- 16 -
INSTALLATION
The options located in Installation Menu are:
1. Automatic Search
2. Manual Search
3. First Time Installation
AUTOMATIC SEARCH
Automatic search is started by selecting YES in the
auto-search pop up menu. All the multiplexes are
searched and a channel table is created
automatically. All channels found are stored in a
sorted form with respect to their channel numbers.
MANUAL SEARCH
In manual search the number of the multiplex
(channel number)is entered manually and only that
multiplex is searched for the channels. In manual
and auto search, any existing channel in the
database is not re-stored to avoid redundant
duplicates of that channel.
FIRST TIME INSTALLATION
The user can use this item to load default settings,
which had been loaded to the receiver at the factory.
To install factory settings, highlight First Time
Installation menu and press SELECT key, then you
will be asked to confirm for deleting all channels and
settings. Selecting YES and pressing SELECT the
channel table will be deleted all.
ELECTRONIC PROGRAM GUIDE
(7-DAY - EPG)
EPG Menu is reached by pressing GUIDE key, quit
by pressing MENU key. In EPG Menu all channels
are displayed. Current channel is highlighted. Use
[UP] [DOWN] [LEFT] [RIGHT] buttons to navigate.
Some, but not all, channels send information about
the current and next events. Please note that event
information is updated automatically. If there is no
event information data available in channels, only
channel names with No Information banner is
displayed.

- 17 -
NOTE: If you have selected some programmes as
Favourite and Favourite list mode is activated,
only those channels will appear in the EPG.
In EPG Menu, you can easily see the extended help
information by pressing INFO key. If you highlight
an event, short event description, extended event
description, start and finish times of event are
displayed on the screen.
If you press SELECT when a next event is
highlighted, a reminder is set for the highlighted
program and the border colour of the box containing
that event s name changes. Program reminders can
be set to signal that a program is about to start
when you are watching another channel. If you set
reminder to a program, then you will be asked for
switching to that channel when the reminder time is
reached. The starting time for EPG is the current
time. You can see the event information for the next
two hours. By pressing RED/ GREEN keys, you
can go to the next hours, and by pressing BLUE/
YELLOW keys, you can reach the event
information for the next days.
MESSAGES
When the box receives no signal (e.g. the aerial cable
is disconnected), NO SIGNAL message is seen on
the screen.
When there is no channel stored in the box, Timer
Menu, Channel Table Menus are not accessible.
Channel navigation is not allowed. Therefore, trying
to enter these menus or do channel navigation will
display First Add new Channels! message on the
screen.
CHANNEL NAVIGATION
There are two ways to navigate through the
channels:
1. Pressing P+/P- keys will help you to go to the next
or the previous channel in the list.
2. Pressing a number key will activate a small digit
entry window on the left upper corner of the screen.
After a digit is entered, the box will wait for 2
seconds till you enter another digit. If no digit is
entered during these 2 seconds, then the box will
switch to the entered number channel.
If a number that is greater than the maximum
number of channels is entered, the box will switch
automatically to the last channel.Each time the box
switches to the desired channel, an information
window is displayed on the lower part of the screen.
The small bar on top right of the banner indicates the
current signal quality.On this channel info window
there are:
· Current event name next event name, and their
start and end times.
· Program mode (TV, Radio, Text, Show All)
· Signal Quality Indicator
· Channel number
· Name of the channel
· An icon indicating that the channel is set as
favourite (if the channel is not set as favourite the
field is left empty)When the info banner is on
screen, If you press [RIGHT] button, the detailed
event information for current and next event is
displayed. If you press [LEFT]button, current
language is displayed. To close the detailed
information window, press i button. When info
banner is active, if the SELECT key is pressed an
EPG window will appear. If you press YELLOW/
BLUE keys Now & Next Information will be seen.
When switching to a locked channel (channel), lock
code is requested via a window as shown in the
picture. Only after the correct code is entered,is it
possible to access to this channel. To skip this
channel, P+/P- cursor keys must be used.

- 18 -
VOLUME CONTROL
The volume level of the sound from the receiver
can be altered with the [V+] and [V-] keys on the
remote control handset. Pressing either key
displays a bar graph of the sound volume on the TV
screen.The volume level selected will remain set,
even when the receiver is turned off and on again,
until it is altered with the [V+] and [V-] keys.
The audio volume adjustment for the receiver is
independent of the volume control on your TV set.
Be careful that both volume controls are kept within
reasonable levels so that when switching from
analogue to digital television viewing, or when first
turning on your TV set, the sound level is not
suddenly very high.You can silence the sound from
the receiver by pressing the [MUTE] key. The sound
remains muted until the [MUTE] key is pressed
again, the [V+] or [V-] keys are pressed, or until the
receiver is turned off and on again.
While the sound is muted in this way, the mute
symbol is displayed in the top left of the TV screen.
The symbol is removed after 3 seconds, but the
sound will remain muted until the [MUTE] key is
pressed for the second time,and the mute symbol
will display for 3 seconds.
DIGITAL TELETEXT
Many digital terrestrial television channels not only
broadcast pictures and sound for programmes but
also pages of information on the programmes, the
weather, news and many other topics. This digital
teletext can be displayed by the receiver.Some
channels are entirely given over to digital teletext
and carry no normal TV programme at all. These
dedicated digital teletext channels will not give a
quarter-screen image in the PG or the Channel List
screen. When such a channel is selected, after a
brief pause, they will usually display the opening
page of information automatically. Other channels
have digital teletext pages broadcast alongside the
television programme and often include a reduced-
size broadcast picture within digital teletext
pages.These usually require the [T XT] button to be
pressed to activate the digital teletext pages.In both
cases, moving through the different pages of
information is accomplished in a variety of ways,
dependent on the individual broadcasters, but
including use of the [UP], [DOWN], [LEFT],
[RIGHT] and [SELECT] keys to select items from
on-screen menus, and the coloured keys to jump
directly to particular pages.You can exit any digital
teletext channel by changing channel in any of the
normal ways. You can leave the digital teletext
function of a combined digital teletext/programme
channel, to return to normal television viewing of that
channel, by pressing the [TEXT] key.Calling for the
information banner or any menu on-screen stops the
receiver from displaying the digital teletext pages
and they are temporarily replaced by a blank picture
while the banner or menu is displayed.Digital teletext
cannot be accessed when the Subtitles are enabled.
SUBTITLE
Subtitle key Shows/hides subtitles of channel. When
the subtitle key is pressed,subtitle ON/OFF
message is displayed.
WIDESCREEN
TV sets are available with screens of the standard
(4:3) format and widescreen (16:9) format. When
you first installed your receiver you specified the
formatof the connected TV (this can now be altered
if necessary; see Configuration)Digital terrestrial
television broadcasts are also made in both standard
and widescreen formats. In particular, films and
dramas tend to be broadcast in widescreen format
to closer emulate the cinema experience, but even
some news bulletins are widescreen. To help get the
most from both TV set and programme when a
widescreen film is watched on a standard TV, or a
standard broadcast is viewed on a widescreen set,
the receiver includes the [WID ] key.So long as the
receiver has been correctly set up for the TV set
connected, a widescreen programme will always be
displayed correctly on a widescreen set, and a
standard format programme will correctly fill the
screen of a standard format TV.With a widescreen
TV set displaying a standard format programme the
[WID ] key switches between displaying the picture
with black bars down the sides, and enlarging the
picture so that it fills the whole width of the screen
but the top and bottom are cropped off.With a
standard format TV displaying a widescreen
programme, the [WID ] key switches between
displaying the picture with black bars at the top and
bottom of the screen, and filling the whole height of
the screen but cropping the sides off according to
instructions broadcast with the programme (called
pan and scan).The effect of the [WID ] key on the
picture display is cancelled by pressing [WID ]
again, changing channel or turning the receiver to
standby.

- 19 -
APPENDIX A - SAFETY
POWER
The receiver should be plugged into a 230V to 240V AC, 50Hz supply only.
LEADS
Ensure the power supply lead, and all other leads, are positioned so they are not likely to be walked on or
pinched by things placed on or against them. Pay particular attention to the power lead, where it enters the
mains plug and where it comes out of the receiver. Do not connect or adjust leads when the receiver is plugged
in.
TEMPERATURE AND MOISTURE
Do not leave or use the receiver in a hot, cold or humid area. Do not allow the receiver to get wet - from
drips or splashes - as this may be dangerous. Do not place water-filled objects such as flower vases, on
top of the receiver.
VENTILATION
Slots and openings in the receiver's cover are for ventilation. Do not cover or block them as this could lead
to overheating.
CLEANING
Unplug the receiver before it is cleaned. Use a lightly dampened cloth only. Do not use liquid or aerosol
cleaners.
EAT AND FLAMES
The receiver should not be placed near to naked flames or sources of intense heat, such as an electric fire.
Ensure that no naked flames sources, such as lighted candles, are placed on top of the Receiver.
LIG TNING
Unplug your receiver from the wall socket if there is a storm or lightning, or if it is to be unused for a long
time.
REPLACEMENT PARTS
If your receiver needs a replacement part, ensure the person undertaking the repair uses parts which are
specified by the manufacturer or have the same specifications as the original part. Other parts may cause
a fire, electric shock or other hazards.
BATTERY DISPOSAL
Please ensure that exhausted batteries from the remote control handset are disposed of safely.
SERVICING
Ensure the person who services your receiver is qualified to do so. Do not remove the cover yourself - you
could get an electric shock.
We are proud to offer a high-quality product. To keep this level of quality, your receiver should be serviced
at a ITAC I authorised service centre.
