HiTECH Technologies 328-24 Series User manual

Instruction Manual
Microwave 328-24 Series
Non-Contact Point Level
System
HiTECH Technologies, Inc.
301 Oxford Valley Road, Bldg 505
Yardley, PA 19067-7711 USA
Tel: [phone] Fax: [phone]
www.hitechtech.com [email protected]

1 2 3
-+ Ground -
+ Ground
1 2 3 4 5 6
NCCOMNO
DELAY
SENSITIVITYUNBLOCK
BLOCK
ONOFF
1 2 3 4 5 6
H
L
W
A
T
O
F
S
C
Wiring
Function of receiver switches and potentiometers
Calibration
TransmitterReceiver
Power supply 24 VDC. Power supply 24 VDC.
De-energized
Selection of detection mode and relay configuration.
4 & 5
Closed
Open
Closed
5 & 6
Open
Closed
Open
4 & 5
Closed
Closed
Open Closed
5 & 6
Open
Open
Beam broken
BLOCKED
Beam unbroken
UNBLOCKED
Non-detecting
state
Detection mode
Terminal number
Unpowered state
Powered
state Detecting state
After installation is complete, adjust the following with the sensor in
the UNBLOCK state.
Transmitter
• After supplying 24 VDC, the POWER light (Green) will
come on.
Receiver
• After supplying 24 VDC, either the red BLOCKED LED light
or the green UNBLOCKED light will come on.
• Turn mode selection switch A to BLOCK, turn the sensitivity
switch S to L and turn the time delay potentiometer T fully counter-
clockwise (minimum).
• Set the sensitivity potentiometer S to minimum.
• The red LED output indicator ON O will come on.
• Slowly turn the sensitivity potentiometer C clockwise until the green
output indicator OFF F comes on.
This is to determine the actuation point. If this sensitivity setting
is very high (more than 7 on the potentiometer switch the sensitivity
switch S to H and repeat the above procedure.
• For applications involving mainly paper and/or where there is
little accumulation on the sensing head, increment the
potentiometer S by 1 or 2 levels only.
On the other hand, where the application involves material with a
moderately high water content, i.e. wet garbage etc, then the
potentiometer should be incremented by 3-4 steps.
However, if the object to be detected absorbs microwaves well,
(i.e. coal), then the rpotentiometer S can be incremented by more
than 5 steps.
• For an application where material is introduced from above,
a suitable "delay" time must be provided to to avoid
instantaneous detection of the falling material.
• To use UNBLOCK output mode, switch the mode selection
switch A to UNBLOCK.
BLOCK: Outputs on broken beam
UNBLOCK: Outputs on unbroken beam
0.1 - 10 sec. delay after state changes
ON (red) : Illuminates on output
OFF (green) : Illuminates on no output
H:High L:Low
To adjust sensitivity
Part Name
Mode selection switch
Time delay adjustment
Output indicator
Output indicator
Sensitivity switch
Sensitivity potentiometer
Terminals
Description
W
A
T
O
F
S
C
