HMS Anybus X-gateway Assembly instructions

Anybus X-gateway Modbus-TCP - PROFINET
INSTALLATION SHEET
HMS Industrial Networks AB
Web: www.anybus.com
Tel: [phone]
E-mail: [email protected]
SP1330, rev 2.01, Mar 2012. AB9007. www.anybus.com
Module Front
Top View
Power:
(+) +24 V DC
(-) GND
(A) PE
SD card slot:
Modbus-TCP Connector:
Pin no Description
1 TX+
2 TX-
3 RX+
6 RX-
4, 5, 7, 8 Termination
18
Bottom View
(Front)
X2.1
X2.2
X3
Further informaon and documents about this product can be found at
the product pages on www.anybus.com.
1
2
3
5
6
7
8
4
PROFINET
Connector:
Pin no Description
1 TX+
2 TX-
3 RX+
6 RX-
4, 5, 7, 8 Termination
18
USB port:
Connect a PC to the USB port
for firmware upgrades.
X1.1
X1.2
LEDs: X-gateway and Modbus-TCP Network
No Name Indication Meaning
(GW)
Gateway Status
Off
Alternating red/green
Flashing green
Green
Flashing red
Red
Power off
Missing configuration
Idle
Running
Invalid configuration
Fatal error
(SD)
SD Card Status
Green
Flashing red
Accessing SD card
Failure
(MTCP)
Modbus-TCP Status
Off
Green
Flashing red
Red
No Modbus-TCP network communication
Communicating with Modbus-TCP network
Transaction error or timeout
Fatal error
(LA1, LA2)
Ethernet Link 1 & 2
Off
Flashing green
Flashing yellow
No link
Receiving/transmitting Ethernet packets
at 100 Mbit
Receiving/transmitting Ethernet packets
at 10 Mbit
No Name Indication Meaning
Not used - -
(NS)
Network Status
Off
Green
Flashing green
No connection
Online (RUN): Connection established, IO
controller in RUN state
Online (STOP): Connection established,
IO controller in STOP state
(MS)
Module Status
Off
Green
Green, two flashes
Red
Red, one flash
Red, two flashes
Red, three flashes
Red, four flashes
Not initialized
Normal operation
Used by engineering tools to identify the
module on the network
Fatal error
Configuration error
IP address error
Station name error
Internal error
LEDs: PROFINET Network
1
2
3
4
5
6
7
8
Installation and Startup Summary
• Aach the X-gateway to the DIN-rail.
• Connect the module to the PROFINET network.
• Connect the module to the Modbus-TCP network.
• Turn on the module (+24 V DC).
• Download IPconfig from www.anybus.com to a PC.
• Connect the PC to the module via one of the Modbus-TCP con-
nectors (Ethernet crossover cable not necessary). Use IPconfig
to idenfy the IP address of the module on the network using its
Modbus-TCP MAC address (found at the boom of the module).
• Start a web browser (IE 7.0 or 8.0), enter the IP address and con-
nect to the X-gateway’s web interface.
• Configure the module using the web configuraon pages.
• Include the Anybus X-gateway GSD file in the PROFINET configura-
on tool (download the GSD file from www.anybus.com).
• Configure and start the PROFINET network.
Technical Details
• Power supply:
24 V DC (-15% to +20%).
• Power consumpon:
Maximum power consumpon is 300 mA @ 24 V DC.
Typical power consumpon: 150 mA @ 24 V DC.
• Surrounding temperature
70 degrees C @ 225 mA @ 24 V DC.
• Protecve Earth (PE):
Internal connecon to PE via DIN-rail or, if the DIN-rail can not be
used, via the power connector.
Note: Make sure the DIN-rail is properly connected to PE.
For maintenance and support, contact the HMS support department.
Contact informaon is available at the support pages on
www.anybus.com.

Anybus X-gateway Modbus-TCP
INSTALLATION SHEET
Further informaon and documents about this product can be found at
the product pages on www.anybus.com.
UL Certification
I
Supply voltage: The X-gateway requires a regulated 24 V (20.4 V to 28.8
V) DC power source.
Field wiring terminal markings (wire type (Cu only, 14-30AWG)
“Use 105oC copper (CU) wire only”
Terminal ghtening torque (5-7 lb-in)).
Use in Overvoltage Category I Polluon Degree 2 Environment.
Install in an enclosure considered representave of the intended use.
To comply with ATEX direcves, the equipment must be installed within
an IP54 enclosure and must be installed with a transient suppressor on
the supply that does not exceed 140% (33.6 V DC) of the nominal rated
supply voltage.
Operang temperature/Surrounding temperature:
-25 to +60 degrees C @ 300 mA @ 24 V DC.
In order to sustain high operang temperatures of up to 70 degrees C
@ 225 mA, the module must be mounted vercally (power connector
facing upwards) to ensure opmal vercal airflow. Addionally, if the
module is mounted side-by-side with other modules, this will affect the
module’s ability to sustain high operang temperatures.
Maximum surface temperature: 135 degrees C.
Pressure: 850 - 1050 millibar.
This product is designed to safely operate in class I, division 2 Hazard-
ous locaon according to ANSI/ISA 12.12.01-2011 and category 3, zone
2 according to EN 60079-0 and EN 60079-15.
SUITABLE FOR USE IN CLASS I, DIVISION 2, GROUPS A, B, C AND D HAZ-
ARDOUS LOCATIONS, OR NONHAZARDOUS LOCATIONS ONLY.
Additional Installation and Operating
Instructions
This product is in accordance with the EMC direcve 2004/108/EC through
conformance with the following standards:
• EN 61000-6-4 (2007)
Emission standard for industrial environment
EN 55016-2-3, Class A (2006)
• EN 61000-6-2 (2005)
Immunity for industrial environment
EN 61000-4-2 (2009)
EN 61000-4-3 (2006)
EN 61000-4-4 (2004)
EN 61000-4-5 (2005)
EN 61000-4-6 (2007)
EMC Compliance (CE)
Warnings
• WARNING - EXPLOSION HAZARD - SUBSTITUTION
OF ANY COMPONENTS MAY IMPAIR SUITABILITY
FOR CLASS I, DIVISION 2.
• WARNING - EXPLOSION HAZARD - WHEN IN HAZ-
ARDOUS LOCATIONS, TURN OFF POWER BEFORE
REPLACING OR WIRING MODULES.
• WARNING - EXPLOSION HAZARD - DO NOT DIS-
CONNECT EQUIPMENT WHILE THE CURCUIT IS
LIVE OR UNLESS THE AREA IS KNOWN TO BE
FREE OF IGNITABLE CONCENTRATIONS.
• WARNING - EXPLOSION HAZARD- THE USB CON-
NECTOR IS NOT FOR USE IN HAZARDOUS LOCA-
TIONS AND FOR TEMPORARY CONNECTION ONLY.
DO NOT USE, CONNECT OR DISCONNECT UNLESS
THE AREA IS KNOWN TO BE NONHAZARDOUS.
CONNECTION OR DISCONNECTION IN AN EXPLO-
SIVE ATMOSPHERE COULD RESULT IN AN EXPLO-
SION.
• WARNING - EXPLOSION HAZARD - DO NOT CON-
NECT OR DISCONNECT THE SD CARD UNLESS
THE AREA IS KNOWN TO BE NONHAZARDOUS.
CONNECTION OR DISCONNECTION IN AN EXPLO-
SIVE ATMOSPHERE COULD RESULT IN AN EXPLO-
SION.
• WARNING - INSTALL IN AN ENCLOSURE CON-
SIDERED REPRESENTATIVE OF THE INTENDED
USE. TO COMPLY WITH ATEX DIRECTIVES, THE
EQUIPMENT MUST BE INSTALLED WITHIN AN IP54
ENCLOSURE AND MUST BE INSTALLED WITH A
TRANSIENT SUPPRESSOR ON THE SUPPLY THAT
DOES NOT EXCEED 140% (33.6 V DC) OF THE
NOMINAL RATED SUPPLY VOLTAGE.
Atex Certification
EX nA IIC T4 Gc
II 3 G
Demko 12 ATEX 1062524X
Y
DIN-rail Mounting
Make sure the DIN-rail fastening
mechanism on the back of the module
is in a fixed and closed posion, i. e.
pushed all the way up.
To mount the module, first hook it on
to the DIN-rail (1), then push it against
the DIN-rail to make it snap on (2).
To unmount the module, a screwdriver
is needed. Use the screwdriver to push
the DIN-rail fastening mechanism on
the back of the module down unl it
locks in a fixed and open posion (1).
Then unhook the module from the
DIN-rail (2).
Note: Do not leave the module with the DIN-rail fastening mechanism in a fixed
and open posion. This may eventually wear the fastening mechanism out so it
cannot be used efficiently. Be sure to push the DIN-rail fastening mechanism back
into the fixed and closed posion aer unmounng the module, according to the
picture below.
HMS Industrial Networks AB
^ƚĂƟŽŶƐŐĂƚĂŶϯϳ
ϯϬϮϰϱ,ĂůŵƐƚĂĚ^ǁĞĚĞŶ
Label Markings
Product name and
descripon
Product number
Product
informaon bar
code
Surrounding air
temperature and
electrical rangs
Cerficaon markings
Warnings
HMS Industrial Networks AB
Staonsgatan 37
302 45 Halmstad
Sweden
