Ho-Link HL-HDMI-1V1D1A-T User manual

www.holinktech.com | TEL:[phone]|[e-mail] Page 1 of 4
HDMI Video over Fiber Converter
Part 1 Product Overview
HDMI Optical transmitter and receiver adopts the uncompressed digital
HD video and high-speed digital optical fiber transmission technology
advanced, It can transfer signal source(computer signal source,HDMI
signal source high digital DVD/DVR) to long distance terminal easily,
with strong anti-interference performance, ensure the signal completed
and stable.
Main features
Full digital, Uncompressed HD optical fiber transmission
Support Full HD 1920*1200@60Hz
The attenuation of optical module SFP low to -3db
1 channel analog audio（3.5mm）
Support HDMI 1.3b Protocal
Support KVM
Automatic identification and configure display mode
Automatic equalization inside, stable and clear graphics.
ESD protection circuit inside, to ensure the ESD damage.
Easily to installation, plug and play, no need to set up
Part 2 Standard Package
HDMI transmitter 1 pcs
HDMI receiver 1 pcs
Power Supply Unit 12V/1A 2 pcs
User Guide 1pcs

www.holinktech.com | TEL:[phone]|[e-mail] Page 2 of 4
Part 3 Interface overciew
Transmitter：
Receiver：
Interface
Transmitter and Receiver
HDMI_IN
HDMI signal input port
HDMI_OUT
HDMI signal output port
OPT
Fiber input port
AUDIO_IN
Audio input port
AUDIO_OUT
Audio output port
DC-12V
12V Power port
R T G
RS232 port R(receive) T(transmit) G(ground)
PC
USB port to connect computer
KEYBOARD/MOUSE
Connect to keyboard and mouse
DC-12V
12V Power port
Indicator Light
HDMI Transmitter
HDMI receiver
OPTICAL
On
Optical signal on

www.holinktech.com | TEL:[phone]|[e-mail] Page 3 of 4
Off
No optical signal
VIDEO
On
Video signal on
Off
No Video Signal
RUN
On
Device works smoothly
Off
Device not works smoothly
POWER
On
Power on
Off
Power off
Part 4 Performance and Specification
Temperature
-5°C to +75°C
Humidity
5 to 90 % RH (no condensation)
The signal of Input and output
HDMI
Protocal
HDMI1.3b,HDCP1.2
Pixel band width
165MHz
Video format
Support 1920*1200 and all format below
The signa of Audio input and
output
3.5MM Audio
Audio format
44.1K,48K,96K,176K,192K
RS232 port
3 ports industrial terminal
RS232 Baud rate
Support 115200 and all below
RS 232 Data bits
8 bits
KVM receiver port
A USB port
KVM transmitter port
B USB port
Fiber port
LC
Fiber module
SFP single mode
Fiber wavelength
1550/1310nm
Fiber band width
3Gbps
The Maximum transmission
distance of HDMI and Audio
10KM
20KM
40KM
60KM
Input voltage
DC 12V，inside + outside -
Power consumption
HDMI receiver 4W
HDMI transmitter 4W
Device size
109.5*152*29.3mm(length*width*height)
Packing box size
328*273*90mm(length*width*height)
Weight
1500g
Part 5 Installation
1. Connect HDMI input signal to HDMI_IN port by HDMI cable
2. Connect HDMI output signal to HDMI_OUT port by HDMI cable
3、Connect Audio input signal to AUDIO IN port
4、Connect Audio output signal to AUDIO OUT port
5、Connect LC fiber to OPT IN and OPT OUT
6、Power on.

www.holinktech.com | TEL:[phone]|[e-mail] Page 4 of 4
Part 6 Application Graphics
