HOA OGEC-110P User manual
2
Overview
The OGEC-110P is a 10/100/1000Base-T to 1000Base-SX/LX non-managed PoE + media
converter that enables you to extend your network to longer distances. With full gigabit port and
compact design, OGEC-110P not only increases the speed of your network server, but also deliver
both up to 30W of power output and high data transmission speed to Power Devices.
Package Checklist
⚫OGEC-110P Media Converter
⚫Removable 5-pin Terminal Block
⚫Quick Installation Guide (printed)
Features
⚫PoE Support up to 15.4/30W
⚫Auto-negotiation supported
⚫Auto-MDI/MDIX on copper port
⚫Plug and play
⚫Hot Swappable
⚫Layer 2 line switching fabric
⚫Link fault pass through (LFP)
⚫-40 C ~ 75C operating temperature
Panel Layout of the OGEC-110P
10/100/1000Base-
T(X) RJ-45 Port
LED Indicators
1000 Base-X SFP Slot
3
Dimension Diagram (Unit: mm)
Grounding the PoE Media Converter
Grounding and wire routing help limit the effects of noise due to electromagnetic interference
(EMI). Run the ground connection from the ground screw to the grounding surface prior to
connecting devices.
ATTENTION
This product is intended to be mounted to a well-grounded mounting surface such as a metal
panel.
DIP Switch Setting
Pin
Mode
OFF (Default)
ON
1
PoE Output
Enable
Disable
2
Link Transparency
Disable
Enable
3
PoE Mode
End-span (Type-A)
Mid-span (Type-B)
4
Jumbo Frame(9KB)
Disable
Enable
4
LED Indicators
The front/rear panel of media converter contains several LED indicators. The function of each LED
is described in the table below.
LED
Color
State
Description
PWR 1
Green
On
Power On
Off
Power Off
PWR 2
Green
On
Power On
Off
Power Off
FX_Link
Green
On
Link is established and no traffic is detected
Off
Data is not transmitting
PoE
Green
Blinking/Flash
PoE Fault (Over-load or short)
On
PoE normal working
Off
PoE No Power output
FX_LFP
Red
On
The specified interface is forced to link down
cause by LFP
Off
The specified interface is not forced to link
down cause by LFP
TX_LFP
Red
On
The specified interface is forced to link down
cause by LFP
Off
The specified interface is not forced to link
down cause by LFP
LAN
Bi-color
(Speed)
Off
10Mbps connection
Orange
100Mbps connection
Green
1 Gbps connection
Green
(Link/Act)
Off
No link
On
Linked
Blinking
Data is transmitting or receiving
5
Specifications
Standard
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet
IEEE 802.3z 1000Base-X Gigabit Ethernet
IEEE802.3x traffic and back pressure
IEEE802.3 af/at Power over Ethernet/Power over
Ethernet Plus
LAN
10/100/1000Base-T(X)
Jumbo Frame Size
9Kbytes
Transmission Distance
Ethernet
100m
Fiber
SFP
Depends on the SFP selection
Transmission Speed
Ethernet
10/100/1000Mbps
Fiber
1000Mbps
Auto MDI/MDIX
Yes (automatic detection of straight or crossover twisted paircables)
Connectors
1 x RJ-45
1 x SFP slot
PoE Power Output
15.4/30W
PoE Power Supply Mode
End-span / Mid-Span
PoE Pin Assignment
End-span: 1/2(+), 3/6(-) / Mid-Span: 4/5(+), 7/8(-)
LED Indicators
Power: PWR1/PWR 2 (Green)
Fiber Link: FX_LINK (Green)
PoE Status: PoE (Green/Blinking)
Fiber LFP Alarm: FX_LFP(Red)
Ethernet LFP Alarm: TX_LFP(Red)
RJ-45 Port: Speed 10M(Off), 100M(Orange), 1000M (Green)
DIP Switch
PoE Output: Enable/Disable
Link Fault Pass Through (LFP): Enable/Disable
Power Supply Mode: End-Span/Mid-Span
Jumbo Frame: Enable/Disable
Power Input
Unit accepts 9 to 48VDC
Power Consumption
3.5W
Dimensions (W x D x H)
101 x 101 x 32 mm
Weight
357g
Enclosure
Metal shell
Installation
Din-rail / wall-mounted
Power Reverse
Support
Overload Current
Support
Operating temperature
-40 C ~ 75C
6
Storage temperature
-40 C ~ 85C
Operating humidity
5 ~ 95% (non-condensing)
Storage humidity
0 ~ 95% (non-condensing)
MTBF
>50000 Hours
Safety
EN60950-1, IEC60950-1
Certification Compliance
CE, FCC
EMC
EN61000-4-5
RoHS
Yes
