QUICK START CHECKLIST
™
WARNING!! The instruction manual must be read completely before operating
the Heli-Max AXE CXn Helicopter. It contains specific warnings about safety and
use of the LiPo flight battery supplied with the AXE CXn. All of these warnings and safety
steps must be read and understood before proceeding to the next step.
❏1. Plug the charger into an AC outlet. The
indicator light on the wall transformer will flash
red during initialization and then turn solid green
once initialization has been completed.
❏2. Plug the battery into the charger. The charge
indicator light will turn red; this indicates that
the battery is being charged. Once the battery is
completely charged, the charge indicator light will
turn solid green. Disconnect the battery from the
charger. Under normal operating conditions, the
battery may take up to one hour to recharge.
The battery is
being charged.
The battery is
fully charged.
The charger
is ready.
Solid Red
Solid Green
(with battery connected)
Solid Green
(without battery connected)
Charge Indicator Light
❏
3. Open the battery cover on the back of the
transmitter, and install four AA batteries. Double
check the polarity of each battery before replacing
the battery cover.
❏4. Place the helicopter on its side and slide the
battery into the battery compartment. Connect
the flight battery and place the helicopter onto a
flat surface.

© 2010 Hobbico®Inc. HMXE13xx Quick Start
❏5. Turn the transmitter on and allow the helicopter
to remain still for 10 seconds. Always step 15 feet
[4.5m] away from the AXE CXn Helicopter before
operating the throttle.
Your AXE CXn helicopter has a safe
start feature built in that prevents
the motor from activating unless the
collective stick has been lowered to
the lowest position. If the motor won’t
run and turn the main blades, please
make sure the collective stick is all
the way down and leave it there for a
couple of seconds. Then try moving
the stick up slowly.
❏6. Transmitter Controls
Your AXE CXn is now ready to fly. Please refer to the flying instructions on page 16 in the manual before
operating the model.
Climbs Moves Forward
Nose Rotates Left Moves Left
