Introduction
Dear Camper,
Congratulations on the purchase of your new HOBBY motor home. The trust you have
placed in us is both an incentive and an obligation to continuously implement new ideas,
technical innovations and ne touches to make our motor homes even better. Our fully tted
and highly sophisticated models enable us to offer you the perfect setting for the most enjo-
yable days of the year.
Please read this user manual carefully, even if you have already been driving a motor home
for quite some time. This will help to prevent operating errors and damage to the vehicle and
its equipment. Handling all of the technical details correctly will increase the pleasure you get
from driving this vehicle and help to retain the value of your motor home.
If this user manual should be unable to provide the required assistance, a close, pan-Europe-
an network of dealers is available for further help. Take advantage of your authorised dealer's
experience and technical knowledge - we recommend speaking to him in detail before taking
your rst trip with your HOBBY motor home.
We wish you and your fellow travellers many enjoyable trips and hope you will always have a
safe journey with your new HOBBY motor home.
Your
HOBBY – Wohnwagenwerk
Ing. Harald Striewski GmbH

Introduction
Chapter 1: Introduction
1.1 General information................................................ 01-1
1.2 Before taking your rst drive.................................. 01-1
1.3 Designations in the operating instructions............. 01-2
Chapter 2: Safety
2.1 General information................................................ 02-1
2.2 Fire protection ........................................................ 02-1
2.3 Road safety............................................................ 02-2
2.4 What to observe before taking your rst drive....... 02-2
2.5 Before and while driving......................................... 02-3
2.6 Notes for your journey ........................................... 02-5
2.7 Emergency equipment ........................................... 02-8
2.8 When you stop driving ........................................... 02-9
Chapter 3: Chassis
3.1 Chassis .................................................................. 03-1
3.2 Loading .................................................................. 03-1
3.3 Leveling supports................................................... 03-3
3.4 Entrance step......................................................... 03-4
3.5 Vehicle identication number (VIN) ........................ 03-5
3.6 Additional pneumatic springs ................................ 03-5
3.7 Towing xture......................................................... 03-7
3.8 Externally mounted xtures ................................... 03-8
3.9 Automatic transmission ......................................... 03-8
Chapter 4: Wheels, tyres, brakes
4.1 Wheels ................................................................... 04-1
4.2 Tyres....................................................................... 04-1
4.3 Tyre pressure.......................................................... 04-2
4.4 Tread depth ............................................................ 04-2
4.5 Wheel rims ............................................................. 04-3
4.6 Snow chains........................................................... 04-3
4.7 Fast tyre repair kit .................................................. 04-4
4.8 Changing a tyre...................................................... 04-5
4.9 Brakes.................................................................... 04-6
Chapter 5: Exterior Structure
5.1 Overview of tank and service aps ........................ 05-1
5.2 Ventilation............................................................... 05-5
5.3 Opening and closing doors and aps.................... 05-7
5.4 Rear ladder........................................................... 05-13
5.5 Bicycle carrier ...................................................... 05-16
5.6 VELO eBike Carrier .............................................. 05-17
5.7 Sun awning .......................................................... 05-18
Chapter 6: Interior Structure
6.1 Opening and closing doors and aps.................... 06-1
6.2 Television holder for at-screen monitor................ 06-4
6.3 Tables ..................................................................... 06-5
6.4 Bed conversion ...................................................... 06-6
6.5 Washroom with sliding elements ........................... 06-7
6.6 Rearranging the cushions ...................................... 06-9
6.7 Widening the beds ............................................... 06-13
6.8 Alcoves/queen-size bed, crossways/Alcove Bed 06-14
6.9 Windows .............................................................. 06-17
6.10 Dimming system for driver's cabin ...................... 06-19
6.11 Skylight ................................................................ 06-20
00-1

Introduction
6.12 Seats in the driver's cabin.................................... 06-22
6.13 Construction of the seats..................................... 06-24
6.14 Seatbelts in the caravan....................................... 06-25
6.15 Overview of the seating arrangements ................ 06-26
6.16 Overview of day and night positions.................... 06-31
Chapter 7: Electrical Installations
7.1 Safety instructions ................................................. 07-1
7.2 Elements of the electrical system .......................... 07-1
7.3 Electric power supply........................................... 07-12
7.4 Function of the power generating unit ................. 07-14
7.5 Caravan battery.................................................... 07-17
7.6 Fuse protection of the electric system................. 07-18
7.7 Mobile navigation................................................. 07-19
7.8 Subsequently installed devices............................ 07-20
Chapter 8: Water
8.1 General information................................................ 08-1
8.2 Water supply .......................................................... 08-1
8.3 Hot water supply ................................................... 08-5
8.4 Flushing toilet......................................................... 08-5
Chapter 9: Gas
9.1 General safety rules when using LPG ttings ........ 09-1
9.2 Gas supply ............................................................. 09-3
Chapter 10: Built-in devices
10.1 General Information ............................................... 10-1
10.2 Heating................................................................... 10-1
10.3 Refrigerator .......................................................... 10-14
10.4 Gas Cooker.......................................................... 10-18
10.5 Oven..................................................................... 10-20
10.6 Fume Hood .......................................................... 10-21
10.7 Rooftop Air Conditioning ..................................... 10-22
Chapter 11: Maintenance and Care
11.1 Maintenance .......................................................... 10-1
11.2 Airing ...................................................................... 10-2
11.3 Care........................................................................ 10-3
11.4 Winter Lay Up for the Motor home ........................ 11-7
11.5 Winter Operation.................................................... 11-9
Chapter 12: Sanitation and Environmental Protection
12.1 The environment and traveling............................... 12-1
12.2 Returning the vehicle ............................................. 12-4
Chapter 13: Technical Data
13.1 Weights according to 92/21/EWG......................... 13-1
13.2 Ination pressures ................................................. 13-2
13.3 Technical data........................................................ 13-3
13.4 Tyres and rims for basic motor home vehicles...... 13-7
13.5 Accessory weights ................................................ 13-9
Index ................................................................................ Ix-1
Appendix ............................................................................A-1
00-2

Introduction
01-1
Chapter 1: Introduction
Our motor homes are continuously being further develo-
ped and for this reason we must reserve the right to make
changes to the equipment, shape and technology. Certain
kinds of accessories are also described in this user manual
that are not part of the standard scope of delivery. For this
reason, no claims may be asserted against HOBBY based
on the contents of this user manual. Those accessories that
are available at the time of going to print are described here.
They have been applied on a par for all oor plans. Please
note that it was not possible to describe all of the individual
variations here. If you have any special questions concerning
accessories or the technology of the vehicle, your dealer will
be happy to answer them.
1.1 General information
Your HOBBY motor home has been built in accordance
with the latest technology and approved safety regulations.
Despite all precautionary measures, however, it is possible
that passengers may be hurt or the motor home damaged if
the safety instructions in this user manual and the warning
stickers placed throughout the motor home are not observed.
In accordance with guarantee conditions, HOBBY's dealer will
give you a 5-year guarantee on the consistency of the motor
home. Your dealer will give you a guarantee booklet, “5 Years‘
Guarantee on Consistency“ when you pick up your vehicle.
Note: If a consistency test has not been carried out, you
will forfeit any claims for a 5-year guarantee on consistency.
1.2 Before taking your rst drive
Please do not consider this manual to be just a means of refe-
rence, but familiarize yourself thoroughly with it before taking
your rst drive.
Fill out the guarantee cards in the different manuals for the in-
stalled equipment and ttings and send them to the manufactu-
rers. This will ensure guarantee claims for any of the equipment.
• Please use the motor home only when it is technically in
top condition.
• Any defects that affect the safety of passengers or the
motor home should be remedied immediately by trained
personnel.
• The brake system and the gas system should only be
checked and repaired by an authorised workshop.
• Please ensure that all of the deadlines for checking
equipment and inspections are met.

Introduction 01-2
Please note the following before operating the vehicle:
1.3 Designations in the operating instructions
This manual explains the motor home in the following
manner:
Texts and illustrations
Texts that refer to illustrations are found directly below the
illustrations.
Details in illustrations (here: entrance) have been given item
numbers j.
Lists
Lists are given in the form of key words and shown as bullet
points using “-“.
1
• Check the tyre pressure.
Please refer to the section on tyre pressure
• Load the vehicle correctly. Keep to the technical-
ly permissible overall mass.
Please refer to the section on loading.
• Charge up the batteries fully before each journey
Please refer to the section on the starter battery.
• Switch on battery circuit breaker.
• If the temperature outside is below 3° C, heat the
vehicle before lling up the water system.
Please refer to the section on water supply/lling the
fresh water tank.
• T ighten the wheel nuts after having driven the rst
50 km.
• Switch off all tted devices that operate on gas
before lling the petrol tank.
• Tightly strap gas bottles in the gas bottle box during
transportation.
• When camping in winter, heat the vehicle at night
if there is danger of frost.
Please refer to the section on operating in winter/
heating.
• Keep compulsory ventilation clear.
Please refer to the section on windows/roof fan/airing.

Introduction
01-3
Handling instructions
Handling instructions are also given in the form of key words
beginning with the symbol “•“.
Notes
Notes point out important details that ensure your motor
home and its ttings will function perfectly. Please remem-
ber that there may be some differences in description to the
various kinds of equipment that can be supplied.
Warnings
Warnings make you aware of dangers that may lead to
material being damaged or even people being hurt if they
are not observed.
Environmental Tips
Environmental tips give you possibilities for lessening the
impact on the environment.
Optional Extras
You have selected a mobile home that is equipped to taste.
This user manual describes all of the models and equipment
offered within the same programme. Therefore, it may include
equipment that you have not selected.
Differences and, thus, all of the optional extras are marked
with an asterisk „*”.
Timeliness of This Manual
The high level of quality and security for mobile homes is
ensured by means of continuous further development. In very
rare cases, there may be a difference between the description
and the vehicle itself.
Should there be any equipment or model that is not descri-
bed in this user manual, please note the enclosed additio-
nal operating instructions.

Introduction 01-4

Safety
02-1
2.2 Fire protection
Precautions against re
• Never leave children alone in the vehicle.
• Keep inammable materials away from all heating and coo-
king devices.
• Any changes to the electric system, accelerator system or
built-in devices may only be carried out by an authorised
workshop.
• Install a re extinguisher next to the main entrance.
• Store a re blanket near the cooker.
• Do not block any escape routes.
• Familiarise yourself with all safety measures set up on the
property.
Fighting re
• Immediately evacuate all passengers.
• Close the main stop valve on the accelerator cylinder and
the accelerator stop valves for the consumer loads.
• Turn off the electric supply.
• Sound the alarm and call the re department.
• Only ght the re yourself if you can do so without risk.
Chapter 2: Safety
2.1 General information
• Ensure that there is sufcient ventilation. Never cover built-
in compulsory ventilation (skylights with compulsory venti-
lation or roof fan). Keep compulsory ventilation free of snow
and leaves - danger of suffocation!
• Operating and user instructions for built-in equipment (re-
frigerator, heating, cooker, etc.) as well as for the basic ve-
hicle must be observed at all times.
• If accessories or optional equipment is to be installed, this
may change the measurements, weight and road perfor-
mance of the engine home. Some accessories must be re-
gistred and entered in the vehicle's papers.
• Use only tyres and rims that have been approved for your
engine home. Please refer to the vehicle's registration pa-
pers for information on tyre and rim sizes.

Safety 02-2
2.4 What to observe before taking your rst drive
Vehicle registration
Every vehicle that drives on public roads must be registered. This
also applies to your new engine home. Apply for registration at
your local Driver and Vehicle Licensing Agency.
You must show the following when applying for registration:
- Motor Vehicle Registration Certicate Part II / Certicate of
Conformity (CoC)
- insurance coverage
- proof of personal identity or conrmation of registration by a
local authority
- if applicable, power of attorney to register the vehicle
- If applicable, the direct debit authorisation for motor vehicle
tax
General inspection
In common with passenger cars new engine homes with a per-
missible total weight up to 3.5 tonnes do not have to undergo
a general inspection for the rst three years after initial regis-
tration. After this they must undergo a general inspection every
two years. Engine homes weighing between 3.5 and 7.5 tonnes
must undergo a general inspection every two years during the
rst six years following initial registration. After this a general
inspection must be carried out every year.
2.3 Road safety
• Before driving, check that the signal and light equipment
(Switch on battery circuit breaker), steering and brakes all
function properly.
• If the vehicle has been standing for a longer period of time
(approx. 10 months) have an authorised workshop check
the brake system and the accelerator system.
• Completely open and fasten the dimming system on the
front and side windows.
• While moving all passengers must be secured with seat
belts and may not move around in the vehicle.
• In winter, the roof must be cleared of snow and ice before
driving.
• Regularly check the tyre pressure before driving. False tyre
pressure can cause excessive wear, damage to the tyres or
even lead to a burst tyre.
• Child seats may only be mounted on seats that have a
three-point seat belt installed by the factory.
• Turn the reversible seats in the direction of travel and lock
them. The seats may not be turned while driving.
• Lock the sliding seat into its original position.
