Hobby 65TL Siesta TI User manual

SIESTA SIESTA ALKOVEN „CLASSIC EDITION“
Version 09/2012
Manual
GB

Introduction
Dear Camper,
Congratulations on the purchase of your new HOBBY motor home. The trust you have
placed in us is both an incentive and an obligation to continuously implement new ideas,
technical innovations and ne touches to make our motor homes even better. Our fully tted
and highly sophisticated models enable us to offer you the perfect setting for the most enjo-
yable days of the year.
Please read this user manual carefully, even if you have already been driving a motor home
for quite some time. This will help to prevent operating errors and damage to the vehicle and
its equipment. Handling all of the technical details correctly will increase the pleasure you get
from driving this vehicle and help to retain the value of your motor home.
If this user manual should be unable to provide the required assistance, a close, pan-Europe-
an network of dealers is available for further help. Take advantage of your authorised dealer's
experience and technical knowledge - we recommend speaking to him in detail before taking
your rst trip with your HOBBY motor home.
We wish you and your fellow travellers many enjoyable trips and hope you will always have a
safe journey with your new HOBBY motor home.
Your
HOBBY – Wohnwagenwerk
Ing. Harald Striewski GmbH

Introduction
Chapter 1: Introduction
1.1 General information................................................ 01-1
1.2 Before taking your rst drive.................................. 01-1
1.3 Designations in the operating instructions............. 01-2
Chapter 2: Safety
2.1 General information................................................ 02-1
2.2 Fire protection........................................................ 02-1
2.3 Road safety............................................................ 02-2
2.4 What to observe before taking your rst drive....... 02-2
2.5 Before and while driving......................................... 02-3
2.6 Notes for your journey ........................................... 02-5
2.7 Emergency equipment........................................... 02-8
2.8 When you stop driving ........................................... 02-9
Chapter 3: Chassis
3.1 Chassis .................................................................. 03-1
3.2 Loading .................................................................. 03-1
3.3 Leveling supports................................................... 03-4
3.4 Entrance step......................................................... 03-5
3.5 Vehicle identication number (VIN) ........................ 03-6
3.6 Additional pneumatic springs ................................ 03-6
3.7 Towing xture......................................................... 03-7
3.8 Externally mounted xtures ................................... 03-8
Chapter 4: Wheels, tyres, brakes
4.1 Wheels ................................................................... 04-1
4.2 Tyres....................................................................... 04-1
4.3 Tyre pressure.......................................................... 04-2
4.4 Tread depth............................................................ 04-2
4.5 Wheel rims ............................................................. 04-3
4.6 Snow chains........................................................... 04-3
4.7 Tyre repair kit.......................................................... 04-4
4.8 Changing a tyre...................................................... 04-7
4.9 Brakes.................................................................... 04-8
Chapter 5: Exterior Structure
5.1 Overview of tank and service aps ........................ 05-1
5.2 Ventilation............................................................... 05-2
5.3 Opening and closing doors and aps.................... 05-4
5.4 Roof rail.................................................................. 05-9
5.5 Bicycle carrier ...................................................... 05-10
5.6 VELO eBike Carrier .............................................. 05-11
5.7 Sun awning .......................................................... 05-13
Chapter 6: Interior Structure
6.1 Opening and closing doors and aps.................... 06-1
6.2 Television holder for at-screen monitor................ 06-5
6.3 Tables..................................................................... 06-7
6.4 Bed conversion .................................................... 06-11
6.5 Washroom with sliding elements ......................... 06-12
6.6 Widening the beds ............................................... 06-16
6.7 Alcoves/queen-size bed, crossways/Alcove Bed 06-17
6.8 Windows .............................................................. 06-21
6.9 Dimming system for driver's cabin ...................... 06-23
6.10 Skylight ................................................................ 06-24
6.11 Seats in the driver's cabin.................................... 06-27
6.12 Construction of the seats..................................... 06-28
00-1

Introduction
6.13 Seatbelts in the caravan....................................... 06-29
6.14 Overview of the seating arrangements ................ 06-30
6.15 Overview of day and night positions.................... 06-31
Chapter 7: Electrical Installations
7.1 Safety instructions ................................................. 07-1
7.2 Elements of the electrical system .......................... 07-1
7.3 Electric power supply............................................. 07-6
7.4 Function of the power generating unit................... 07-8
7.5 Caravan battery.................................................... 07-10
7.6 Fuse protection of the electric system................. 07-12
7.7 Mobile navigation................................................. 07-13
7.8 Subsequently installed devices............................ 07-13
Chapter 8: Water
8.1 General information................................................ 08-1
8.2 Water supply .......................................................... 08-1
8.3 Hot water supply ................................................... 08-5
8.4 Flushing toilet......................................................... 08-5
Chapter 9: Gas
9.1 General safety rules when using LPG ttings ........ 09-1
9.2 Gas supply ............................................................. 09-3
Chapter 10: Built-in devices
10.1 General Information ............................................... 10-1
10.2 Heating................................................................... 10-2
10.3 Electric Heating...................................................... 10-7
10.4 Auxiliary Heating in the Driver's Cab ..................... 10-8
10.5 Refrigerator ............................................................ 10-9
10.6 Gas Cooker.......................................................... 10-13
10.7 Oven..................................................................... 10-15
10.8 Fume Hood .......................................................... 10-16
10.9 Rooftop Air Conditioning ..................................... 10-17
Chapter 11: Maintenance and Care
11.1 Maintenance .......................................................... 10-1
11.2 Airing...................................................................... 10-2
11.3 Care........................................................................ 10-3
11.4 Winter Lay Up for the Motor home ........................ 11-7
11.5 Winter Operation.................................................... 11-9
Chapter 12: Sanitation and Environmental Protection
12.1 The environment and traveling............................... 12-1
12.2 Returning the vehicle ............................................. 12-4
Chapter 13: Technical Data
13.1 Weights according to 92/21/EWG......................... 13-1
13.2 Ination pressures ................................................. 13-2
13.3 Technical data........................................................ 13-3
13.4 Tyres and rims for basic motor home vehicles...... 13-7
13.5 Accessory weights ................................................ 13-9
Index ................................................................................ Ix-1
Appendix ............................................................................A-1
00-2

Introduction
01-1
Chapter 1: Introduction
Our motor homes are continuously being further develo-
ped and for this reason we must reserve the right to make
changes to the equipment, shape and technology. Certain
kinds of accessories are also described in this user manual
that are not part of the standard scope of delivery. For this
reason, no claims may be asserted against HOBBY based
on the contents of this user manual. Those accessories that
are available at the time of going to print are described here.
They have been applied on a par for all oor plans. Please
note that it was not possible to describe all of the individual
variations here. If you have any special questions concerning
accessories or the technology of the vehicle, your dealer will
be happy to answer them.
1.1 General information
Your HOBBY motor home has been built in accordance
with the latest technology and approved safety regulations.
Despite all precautionary measures, however, it is possible
that passengers may be hurt or the motor home damaged if
the safety instructions in this user manual and the warning
stickers placed throughout the motor home are not observed.
Please use the motor home only when it is technically in top
condition.Any defects that affect the safety of passengers or
the motor home should be remedied immediately by trained
personnel.
The brake system and the gas system should only be checked
and repaired by an authorised workshop.
Please ensure that all of the deadlines for checking equipment
and inspections are met.
1.2 Before taking your rst drive
Please do not consider this manual to be just a means of refe-
rence, but familiarize yourself thoroughly with it before taking
your rst drive.
Fill out the guarantee cards in the different manuals for the instal-
led equipment and ttings and send them to the manufacturers.
This will ensure guarantee claims for any of the equipment.
In accordance with guarantee conditions, HOBBY's dealer
will give you a 5-year guarantee on the consistency of the
motor home. Your dealer will give you a guarantee booklet,
“5 Years‘ Guarantee on Consistency“ when you pick up
your vehicle.
Note: If a consistency test has not been carried out, you will
forfeit any claims for a 5-year guarantee on consistency.

Introduction 01-2
Please note the following before operating the vehicle:
• Check the tyre pressure.
Please refer to the section on tyre pressure
• Load the vehicle correctly. Keep to the technically per-
missible overall mass.
Please refer to the section on loading.
• Charge up the batteries fully before each journey
Please refer to the section on the starter battery.
• Switch on battery circuit breaker.
• If the temperature outside is below 0° C, heat the vehicle
before lling up the water system.
Please refer to the section on water supply/lling the fresh
water tank.
• T ighten the wheel nuts after having driven the rst 50 km.
• Switch off all tted devices that operate on gas before
lling the petrol tank.
• Tightly strap gas bottles in the gas bottle box during
transportation.
• When camping in winter, heat the vehicle at night if there
is danger of frost.
Please refer to the section on operating in winter/heating.
• Keep compulsory ventilation clear.
Please refer to the section on windows/roof fan/airing.
1.3 Designations in the operating instructions
This manual explains the motor home in the following
manner:
Texts and illustrations
Texts that refer to illustrations are found directly below the
illustrations.
Details in illustrations (here: entrance) have been given item
numbers j.
Lists
Lists are given in the form of key words and shown as bullet
points using “-“.
1

Introduction
01-3
Handling instructions
Handling instructions are also given in the form of key words
beginning with the symbol “•“.
Notes
Notes point out important details that ensure your motor
home and its ttings will function perfectly. Please remem-
ber that there may be some differences in description to the
various kinds of equipment that can be supplied.
Warnings
Warnings make you aware of dangers that may lead to
material being damaged or even people being hurt if they
are not observed.
Environmental Tips
Environmental tips give you possibilities for lessening the
impact on the environment.

Introduction 01-4

Safety
02-1
2.2 Fire protection
Precautions against re
• Never leave children alone in the vehicle.
• Keep inammable materials away from all heating and coo-
king devices.
• Any changes to the electric system, accelerator system or
built-in devices may only be carried out by an authorised
workshop.
• Install a re extinguisher next to the main entrance.
• Store a re blanket near the cooker.
• Do not block any escape routes.
• Familiarise yourself with all safety measures set up on the
property.
Fighting re
• Immediately evacuate all passengers.
• Close the main stop valve on the accelerator cylinder and
the accelerator stop valves for the consumer loads.
• Turn off the electric supply.
• Sound the alarm and call the re department.
• Only ght the re yourself if you can do so without risk.
Chapter 2: Safety
2.1 General information
• Ensure that there is sufcient ventilation. Never cover built-
in compulsory ventilation (skylights with compulsory venti-
lation or roof fan). Keep compulsory ventilation free of snow
and leaves - danger of suffocation!
• Operating and user instructions for built-in equipment (re-
frigerator, heating, cooker, etc.) as well as for the basic ve-
hicle must be observed at all times.
• If accessories or optional equipment is to be installed, this
may change the measurements, weight and road perfor-
mance of the engine home. Some accessories must be re-
gistred and entered in the vehicle's papers.
• Use only tyres and rims that have been approved for your
engine home. Please refer to the vehicle's registration pa-
pers for information on tyre and rim sizes.

Safety 02-2
2.4 What to observe before taking your rst drive
Vehicle registration
Every vehicle that drives on public roads must be registered. This
also applies to your new engine home. Apply for registration at
your local Driver and Vehicle Licensing Agency.
You must show the following when applying for registration:
- Motor Vehicle Registration Certicate Part II / Certicate of
Conformity (CoC)
- insurance coverage
- proof of personal identity or conrmation of registration by a
local authority
- if applicable, power of attorney to register the vehicle
- If applicable, the direct debit authorisation for motor vehicle
tax
General inspection
In common with passenger cars new engine homes with a per-
missible total weight up to 3.5 tonnes do not have to undergo
a general inspection for the rst three years after initial regis-
tration. After this they must undergo a general inspection every
two years. Engine homes weighing between 3.5 and 7.5 tonnes
must undergo a general inspection every two years during the
rst six years following initial registration. After this a general
inspection must be carried out every year.
2.3 Road safety
• Before driving, check that the signal and light equipment
(Switch on battery circuit breaker), steering and brakes all
function properly.
• If the vehicle has been standing for a longer period of time
(approx. 10 months) have an authorised workshop check
the brake system and the accelerator system.
• Completely open and fasten the dimming system on the
front and side windows.
• While moving all passengers must be secured with seat
belts and may not move around in the vehicle.
• In winter, the roof must be cleared of snow and ice before
driving.
• Regularly check the tyre pressure before driving. False tyre
pressure can cause excessive wear, damage to the tyres or
even lead to a burst tyre.
• Child seats may only be mounted on seats that have a
three-point seat belt installed by the factory.
• Turn the reversible seats in the direction of travel and lock
them. The seats may not be turned while driving.

Safety
02-3
2.5 Before and while driving
As the owner / driver of the vehicle, you are responsible for the
state of the vehicle. Please observe the following points:
Preparing the vehicle
Check the exterior of the vehicle and carry out the following
preparations before driving:
Preparing the vehicle
• If the levelling supports have been extended, retract them.
• Close all the windows in the engine home as well as sky-
lights in the roof.
• Retract the entrance step.
The general inspection can be carried out by the German
Technical Surveyance Association (TÜV), the German Engine
Vehicle Surveyance Association (DEKRA) or an ofcially appro-
ved expert.
Any changes made to the vehicle that underlie German
Road Traffic Licensing Regulations must be officially
authorised!
If you have any further questions or difculties, your autho-
rised Hobby dealer will always be available to assist you!

Safety 02-4
• Close the tap for the waste water tank.
• Close all of the gas stop valves on the gas devices, with
the exception of the stop valve for the heating if the vehicle
has been equipped with a gas pressure regulator for use
while driving. (e.g. Control CS, SecuMotion)
• If necessary remove the 230 V electric cable from the exte-
rior socket.
• If necessary, retract the satellite dish.
• If necessary retract the TV aerial as far as possible or fold
down the satellite dish.
• If necessary secure any loads on the roof ensuring that
they cannot slide.
• If necessary secure bicycles; ensure that they cannot slide
and check that the existing lighting systems are not
covered.
• If necessary turn off the light in the tent in front of the
engine home.
Interior
Some preparations must also be carried out inside the motor
home.
Preparing the interior
• Sort loose objects and stow them in the compartments.
• Place heavy objects in the lower compartments.
• If necessary switch the refrigerator to 12 V operation.
• Ensure that no liquids, including those in the refrigerator,
will leak.
• Secure accelerator cylinders.
• Secure the table and, if possible, lower it.
• Turn off interior lights.
• Close doors (including refrigerator door), drawers and
aps rmly.
• Heavy and/or voluminous objects (e.g. TV, radio) must be
secured before driving.
• Completely open and secure the optional cockpit dimming
system.
• Lock and secure the washroom sliding wall.
Place a not with all important measures and weights in a
visible place in both the caravan and the driver‘s cabin.
Do not overload the vehicle! It is imperative that you not the
permissible axle loads, the technically permissible overall
mass as well as the permissible height, width and length
of the motor home.

Safety
02-5
2.6 Notes for your journey
Your motor home is not an automobile!
In many situations, it reacts very differently to a “normal“ au-
tomobile. Therefore, you should be prepared for the following
differences:
Loading
The following applies for loading:
• Load evenly. Heavy or bulky objects should be placed in the
lower compartments!
• In the interior, store luggage in cupboards and compart-
ments.
• Secure all doors and aps.
Driver‘s cabin
Do not forget the following:
• Adjust the interior and exterior mirrors as well as your
seat.
• Check the lights.
In addition:
• Check your tyre pressure.
• Check all liquids, such as oil, cooling water, brake uid and
windscreen cleaning liquid, and ll them up if necessary.
• Turn off all accelerator devices (heating, refrigerator, etc.)
before putting petrol in the tank.
Before driving off
Before you drive off you should be able to answer the following
questions with “yes“:
• Is there a rst-aid kit; a warning triangle and a warning
jacket on board?
• Are all the lights working (headlights, dipped headlights,
brake lights and indicators)?

Safety 02-6
• The maximum permissible load for the rear external
storage locker is 200 kg.
• On no account should the permissible rear axle load be
exceeded.
• Due to load removal on the front axle, it is considerably
more difcult to handle the vehicle when the rear garage
is fully loaded.
• After you have nished loading, check the overall weight on
a public scales.
Roof load (50 kg maximum)
The height of the motor home may vary from one journey to the
next due to different roof loads.
The following applies for roof loads:
• Add the measurement of the roof load to the height of the
motor home.
• Place a not visibly in the driver's cab giving the overall height.
This saves having to calculate the height when driving under
bridges and through tunnels.
Rear garage
When loading the rear garage adhere to the permissible axle
loads and the technically permissible total mass. Distribute pay-
load evenly. Excess point loads will damage the oor covering.
Braking
The following applies for braking:
• Not the longer braking distance, especially on wet roads.
• When driving downhill, select a gear that is not higher than
when driving uphill.
Reversing/Manoeuvring
Your engine home is far larger than a car.
The following applies to reversing/manoeuvring
• Even if the wing mirrors are correctly adjusted there is a
signicant blind spot.
• When reversing or parking in places with poor visibility get
help to guide you in.
Passenger safety
The following applies while driving:
• Only those seats equipped with safety belts may be used
by passengers.
• While driving, passengers may not stay in the alcove or
the beds.
• Passengers must remain in their seats with their seat belt
on!
• Do not open the door latch!
• No extra passengers may remain in the vehicle!

Safety
02-7
Driving arround corners
Due to its height, a motor home begins to sway more quickly
than an automobile.
The following applies for driving arround corners:
• Never drive too quickly into a corner!
Driving economically
The engine of your motor home has not been designed to drive
constantly under a full load.
The following applies when driving:
• Do not keep your foot down on the accelerator!
• The nal 20 km/h before reaching top speed require up to
50 % more fuel!
Getting petrol
A number of devices that use an open ame have been built
into your motor home.
The following applies when getting petrol:
• Turn off all accelerator devices (heating, refrigerator, etc.)!
• Turn off all mobile phones!
• Never get anything other than diesel fuel.
• Never mistakenly ll the fresh water tank with fuel.
Driving
Take a trial drive before leaving on your rst large journey in
order to familiarize yourself with the motor home. Remember
to practise reversing. The base vehicle is a commercial vehicle;
adjust your driving style accordingly.
The following applies for driving:
• Do not underestimate the length of the engine home. Due
to the relatively long rear overhang larger vehicles can
veer to one side and, in unfavourable conditions, the rear
can hit the ground.
• Be careful when driving into inner courtyards and through
entrance gates.
• The motor home may start to swing from side to side in
cross-winds, on wet or icy roads.
• Adjust your speed to road and trafc conditions.
• Long descents with a slight gradient can become dangerous.
Adjust your speed from the very beginning to allow you to
speed up if necessary without endangering other automobiles.
• As a general rule, never drive faster downhill than uphill.
• The motor home may be caught up in a slipstream when
overtaking or being overtaken by lorries with trailers or buses.
This effect is counteracted by lightly counter-steering.
• Use foresight while driving; take regular breaks on longer
drives.

Safety 02-8
2.7 Emergency equipment
To be prepared in case of an emergency, you should always
carry the three emergency devices on board and familiarize
yourself with them.
First-aid kit
The rst-aid kit should always be at hand and have a xed
position in your motor home. Any objects removed from the
rst-aid kit should be replaced immediately. Expiry dates should
be checked regularly.
Reective jacket (not included in scope of delivery)
In acc. with EN 471, we recommend that you carry and wear
a reective jacket with white retro-reective stripes whenever
you leave the vehicle on open roads and emergency strips. The
driver should wear this jacket when the vehicle
• comes to a stop outside city limits on an obscure rural road
because of an accident or breakdown, if the view is poor
due to bad weather, in twilight or darkness, or
• when it must be secured by means of a warning triangle
on the emergency strip of the engineway because of an
accident or breakdown.
Warning triangle
The warning triangle should also always be at hand and have
a xed position in your motor home, preferably together with
the rst-aid kit.
In an emergency
• Set up the warning triangle at least 100 m in front of the
danger zone!
100 m

Safety
02-9
2.8 When you stop driving
Selecting a parking space
The following applies for selecting a parking space:
• Select a parking space that is as level as possible.
• If possible, pick your spot in daylight.
Securing the vehicle
The following applies when securing the vehicle:
• Put the vehicle in gear.
• Pull on the handbrake.
• If necessary, extend extra vehicle supports.
• If necessary, use blocks (not in scope of delivery).
If the temperature is below 0°C only put the handbrake
on lightly and ensure that the vehicle is in gear to prevent
the handbrake from freezing up!
When turning the driver‘ seat, ensure that you do not acci-
dently disengage the handbrake.
Switching electric consumption:
The following applies when switching electric consumption:
• Switch the refrigerator from 12 V to accelerator or 230 V.
Otherwise, if the engine is not on, the 12 V electrical supply
will automatically turn itself off after a few minutes.
• Open the main stop valve on the accelerator cylinder and
the accelerator stop valve on the consumer required.
Water system
Empty the entire water system if the vehicle is not heated when
there is danger of frost. Leave the water faucets as well as all
drain valves open to prevent damage from frost.
Water that has been left to stand in the fresh water tank or
water pipes quickly becomes undrinkable. Therefore always
ush the water pipes thoroughly with several litres of fresh
water before using them.

Safety 02-10
Saving energy in winter
It is very easy to save energy inside your motor home. This
applies especially to heating in winter.
The following applies for saving energy:
• Meter the exact use of ventilation in the vehicle and the
heating valve.
• Install winter mats on the inner sides of the driver‘s cabin
and the windscreen (not included in scope of delivery).
• Install an insulation mat between the driver‘s cabin and the
caravan (not included in scope of delivery).
• Open the door as little and as briey as possible.
• When camping in winter, it is possible to put up a small tent
in front of the vehicle as protection against the cold.

Chassis
03-1
Denition of Masses for Motor homes
Throughout Europe, EU Guideline 92/21/EWG is applicable for
calculating the masses (weights) and resulting loads for motor
homes. The terms and basis used for calculations are
explained below.
1. Technically permissible overall mass
Information regarding the technically permissible maximum
weight is based on Hobby Wohnwagenwerk's specication in
cooperation with the manufacturers of the previous construc-
tion stages (FORD). This weight was determined in detailed
calculations and tests. It is specied in the basic approvals
and, for safety reasons, it must not be exceeded under any
circumstances.
2. Mass when the vehicle is ready to start
The mass when the vehicle is ready to start corresponds to the
mass of the empty vehicle including lubricants, tools, spare
tyre (and/or repair kit), petrol (100 %), booster battery, all of the
standard equipment mounted by the factory as well as 75 kg
for the driver, plus basic equipment (gas, water, electric).
3. Basic Equipment
The basic equipment includes the masses for the fresh water
and gas storage containers, which have been lled to 90 %
of their total capacity. The masses for the individual models
are calculated in detail as follows:
Chapter 3: Chassis
3.1 Chassis
The chassis includes parts of the frame and the axles. Please
note that the operating licence will become void if any technical
changes are made!
Technical changes may only be carried out after being
released by the manufacturer.
For further information, please refer to the enclosed ope-
rating instructions for the basic vehicle.
3.2 Loading
The maximum axle loads entered in the documentation for
this vehicle,are the permissible maximum towing weight,
as well as the technically permissible maximum weight,
must not be exceeded.
Please refer to the denition of masses for motor homes!
Weights of motor homes in accordance with 92/21/EWG

Chassis 03-2
If you have an additional seat belt tted as an optional
extra, the volume of fresh water is reduced to 10 l while
driving due to the neck of the overow.
FORD
Siesta, Siesta AK
a) Supply of liqueed petroleum gas
Number of built-in gas regulators: 1
Weight of an 11 kg aluminium bottle: 5,5
Weight of 11 kg gas ination (90 %): 9,9
Total: 15,4
b) Liquids
100 l fresh water tank (90 %) 90
c) Electric power supply
Cable drum 4
Total basic equipment: 109,4 kg
