INSPECTIONS BEFORE FLIGHT
PLEASE PAY ATTENTION TO THE AGING AND WORN PARTS, AND FLY WHEN THEY ALL
WORK WELL. PLEASE DO CHECK EVERY ASSEMBLY CAREFULLY BEFORE FLIGHT,
especially lapses in these parts will easily cause DANGER.
1. Check that the propellers are secured properly.
2. Check that the receiver is receiving a stable signal.
3. Check that the battery is secured tightly and the battery is fully charged.
4. Check that the receiver is attached correctly.
5. Check the antenna is assembled tightly enough.
6. Check that the brushless motor and brushless ESC are secured to the
airframe.
Before flight, please assemble receiver or connect ESC to FC as the company factory
defaults, if not, please DO CHECK the operations of Remote Control channels and
consistence of motor reactions.
FLIGHT CONTROL INSTRUCTION
1. Start: Set the throttle stick to the lowest then turn on the transmitter.
Connect the flight battery then slowly apply the throttle until all motors
begin to run.
2. Stop: Move the throttle stick to the minimum. All motors should stop to
work in about one second. First cut off the Bumblebee then the RC powers
off.
3. Any emergency occurs when taking off or landing, please move the throttle
stick to the lowest position immediately to keep safe.
4. Flight control to the front, back, left and right is similar to the traditional RC
helicopters but each motion is controlled by a separate channel. Do not use
any channel mixing in your RC transmitter such as v-tail or swashplate
mixing etc.
START TO FLY
Power ON/OFF Operations: Before plugging in the quad you have to turn on the RC
and set the throttle stick to the lowest position. When powering off, you have to cut
off the aircraft first then the RC powers off. Disorder in the on and off procedure will
cause an accident.
1. Place the aircraft on the ground. Put the throttle stick to the lowest position
then turn on the transmitter.
2. Connect the battery to the ESC board.
3. Start the Quad by applying power slowly with the throttle stick. When all the
motors rotate at a slow speed you can move the stick to check the X650
Value actions according to your operation.
4. If you can not calibrate the tilt on one side during your flight, please
connect Bumblebee to the PC and use the company configuration software to do
the calibration.
-6-
