HOGG & DAVIS ODP 20-4 User manual

ODP 20-4
The information, specifications, and illustrations in this manual are on the basis of
information available at the time it was written. The specifications, torque values,
pressures of operation, measurements, adjustments, illustrations, and other items can
change at any time. These changes can affect the service of the given product.
For the complete and most current information, contact:
Hogg & Davis, Inc
P.O. Box 405 / 3800 Eagle Loop
Odell, OR 97044-0405
541-354-1001
541-354-1080 Fax
For most recent manual
version please visit:
www.hoggdavis.com
ver. 2.0

ODP 20-4
2,000 Lb. Four Drum Puller
- - 2 - -
© COPYRIGHT 2016 HOGG & DAVIS, INC
Table of Contents
Table of Contents............................................................................................................- 2 -
Product Warnings............................................................................................................- 3 -
General Specifications....................................................................................................- 4 -
Setup on the Job..............................................................................................................- 7 -
Setup of the unit..........................................................................................................- 7 -
Position of unit........................................................................................................- 7 -
Jack Stands / Outriggers..........................................................................................- 8 -
Tie Down/ Brake/ Chock........................................................................................- 8 -
Rope Payout Procedure (Free Wheel).............................................................................- 8 -
Pulling Control................................................................................................................- 9 -
Pulling Control..........................................................................................................- 10 -
Level wind ................................................................................................................- 10 -
LUBRICATION AND MAINTENANCE ...................................................................- 11 -
Drawbar inspection...................................................................................................- 12 -
15-15 Warranty.............................................................................................................- 13 -
Parts and other manufacturer manuals..........................................................................- 14 -

ODP 20-4
2,000 Lb. Four Drum Puller
- - 3 - -
© COPYRIGHT 2016 HOGG & DAVIS, INC
Product Warnings
These warning labels and others like it are
placed in critical areas of the machine. The
warnings are to be read and fully
understood prior to operation of the unit.

ODP 20-4
2,000 Lb. Four Drum Puller
- - 4 - -
© COPYRIGHT 2016 HOGG & DAVIS, INC
General Specifications
This unit is designed to install overhead cable/conductor.
Four Drum Puller
2000 lb. Maximum Line Pull –Single Reel
36” Rope Reel Diameter
Rope Capacity 10,600 ft. of 7/16” per reel
Manual Jack stands (2) Rear –(1) Tongue
Hydraulic Jack stands (optional)
Maximum Line Speed 0-4 mph
Single Axle with Electric Brakes
1
1
2
3
4
5
6
6

ODP 20-4
2,000 Lb. Four Drum Puller
- - 5 - -
© COPYRIGHT 2016 HOGG & DAVIS, INC

ODP 20-4
2,000 Lb. Four Drum Puller
- - 6 - -
© COPYRIGHT 2016 HOGG & DAVIS, INC

ODP 20-4
2,000 Lb. Four Drum Puller
- - 7 - -
© COPYRIGHT 2016 HOGG & DAVIS, INC
Operating Instructions
All persons operating this machine must read and understand
this manual as well as the operating, danger, and warning
decals placed on the machine. Failure to read and
understand these items subjects the operator and others to
DEATH or SERIOUS INJURY.
Operators shall make themselves familiar with the placement of
the following operating and safety features of the machine.
Grounding Lugs and their placement on Machine (1)
Drive Chains and Sprockets (2)
Take Up / Pay-Out / Control (3)
Engine Controls and Gauges (4)
Lubrication Points (various)
Level wind Bearing and Pins (5)
Tie Down Locations (6)
Manual Jack stands (standard)
Hydraulic Jack stands (optional)
Setup on the Job
Setup of the unit
Position of unit
Position the trailer with the centerline
of the trailers in line with the pull.
Place the unit at a minimum of two
times the height of the first block.

ODP 20-4
2,000 Lb. Four Drum Puller
- - 8 - -
© COPYRIGHT 2016 HOGG & DAVIS, INC
Jack Stands / Outriggers
Actuate the rear outriggers to stabilize the trailer. Attempt to
level the trailer as much as possible. The outriggers have the
ability to raise the tires from the ground, but as a rule they
should be used to stabilize the load across all contact points on
the ground, i.e. Jack stands, tires, front tongue jack stand.
Tie Down/ Brake/ Chock
Chock all wheels and set brakes (if applicable). It should be
noted that a fully loaded trailer may exceed the tension
desired during the pull. As the pull progresses, the weight of the
trailer may increase or decrease, therefore proper securing
procedures should be followed during operation. This unit is
equipped with tie –down eyes for staking to the ground and it
is recommended that the unit stay secured to the tow vehicle
whenever possible.
Rope Payout Procedure (Free Wheel)
When beginning the rope payout feature, be sure that the engine is
turned off.
Ensure that all tension is removed from the pulling rope before attempting
to remove drive pin.
Adjust reel brake to provide tension to the reel of rope.
Disengage the drive pin from reel to be free wheeled. Begin to
pull rope through the blocks while continuing to adjust the over
spin brake. When the rope install is completed, re-apply over
spin brake to maximum pressure. Rotation of the rope reel shaft
may be needed to properly install drive pin. With engine at idle
slowly operate in take-up mode to engage the drive pin of reel
to be pulled.

ODP 20-4
2,000 Lb. Four Drum Puller
- - 9 - -
© COPYRIGHT 2016 HOGG & DAVIS, INC
Refer to the performance chart for proper hydraulic pressure as
it directly relates to conductor tension. This chart is located on
the control panel of the unit.
***These instructions assume that the operator has set the
proper drive pin for the reel to be pulled in. All other reels are
to be disengaged with the over spin brake fully applied.
Pulling Control
The following instructions explain how to properly set up the unit
when it is to be used as a puller and have a pulling rope with
NO TENSION. DO NOT FOLLOW THESE INSTRUCTIONS WHEN YOU
HAVE A ROPE UNDER TENSION!!
1. Apply the brake.
2. Turn the Hydraulic Pressure knob CCW to release
pressure
3. Increase to approximately full throttle.
4. Begin to actuate the joystick to take up.
5. Turn the Hydraulic Pressure Control knob and set to 800
psi.
6. Release the joystick into the neutral position.
7. Wait for confirmation from the tension side of the job for
readiness
8. Release the brake
9. Increase throttle to full.
10. As the rope reel begins to take up, increase the
hydraulic to the maximum line pull desired. As the rope
diameter increases on the reel, it might be necessary to
adjust the Hydraulic Control Knob to keep the pull
moving.
11. Adjust joystick for line speed as also desired.
12. To stop the pull, place control into neutral while
applying the brake.

ODP 20-4
2,000 Lb. Four Drum Puller
- - 10 - -
© COPYRIGHT 2016 HOGG & DAVIS, INC
Pulling Control
The following instructions explain how to properly set up the unit
when it is to be used as a puller and have a pulling rope UNDER
TENSION. Use of these instructions assumes that all controls are
at the same setting when the pulled previously stopped.
1. Begin to slightly actuate the joystick to take up
2. Release the brake
3. Actuate the joystick to take up as desired (if reel does
not begin to move, slightly increase the Hydraulic
Pressure Control until it does.
Level wind
This unit is equipped with an automatic diamond lead screw
level wind system. No manual operation of the unit is required.
Make sure shaft if properly pinned and lubricated prior to
operation.
IF MACHINE IS TO BE USED FOR FIBRE OPTIC INSTALLATION, REFER
TO THE CABLE MANUFACTURER FOR PROPER TENSIONING
TECHNIQUES. FAILURE TO CONSULT MANUFACTURER MAY
DAMAGE CABLE AND VOID WARRANTY.

ODP 20-4
2,000 Lb. Four Drum Puller
- - 11 - -
© COPYRIGHT 2016 HOGG & DAVIS, INC
LUBRICATION AND MAINTENANCE
This unit has no set PM schedule beyond that of the engine
manufacturers suggested maintenance schedule. This unit
should be visually inspected prior to each use while repairing
any and all discrepancies prior to use.
Items to be inspected prior to use are:
Drive Chains and sprockets for wear and slack
Pintle eye (excessive wear)
Safety Chains (wear / damage)
All welds and seams
Loose or missing fasteners (bolts, nuts, set screws)
Loose or leaking hydraulic hoses
Damaged or worn hydraulic hoses
Brake calipers (loose fittings, hoses, worn linings)
Brake Pads
Brake rotors
Tires and trailer brakes
Engine and hydraulic system fluid levels.
Lubrication Schedule
Drive chain and sprockets ( daily )
Reel Shaft Bearings (as needed)
Reel Bearings (as needed)
Engine oil as per manufacturers recommendation
Idler sprocket ( daily )
Axle Bearings (as needed)

ODP 20-4
2,000 Lb. Four Drum Puller
- - 12 - -
© COPYRIGHT 2016 HOGG & DAVIS, INC
Drawbar inspection
Regularly inspect he drawbar for wear and damage. If
wear exceeds 1/8”, replace the drawbar eye.
Check all drawbar mounting fasteners for proper torque
Do not modify or add to the product
Do not weld on this product without written permission
from the factory
Be sure the drawbar size is compatible with the coupling
device on the tow vehicle
Do not damage the coupling components. Be
particularly careful during coupling and uncoupling
Inspect the coupling device on the tow vehicle for proper
locking prior to use
Consult OSHA and DOT regulations and American
Trucking Association guidelines for complete operating
procedures.

ODP 20-4
2,000 Lb. Four Drum Puller
- - 13 - -
© COPYRIGHT 2016 HOGG & DAVIS, INC
15-15 Warranty
Hogg and Davis, Inc. warrants its trailers against Hogg and Davis, Inc. warrants it's trailer main
defects in material or workmanship for period of 15 frame assemblies (except pintle eyes or other
months from the date of shipment from Hogg and towing attachments, spindles and axles)
Davis, Inc. (see General Conditions & Exceptions). against defects in material or workmanship for
Hogg and Davis, Inc. will replace, free of charge, a period of 15 years from the date of shipment
F.O.B. Hogg and Davis, Inc. factory, such parts or from Hogg and Davis, Inc. (see General
parts thereof, that in their judgment have proven Conditions & Exceptions). Hogg and Davis, Inc.
defective. Additionally, Hogg and Davis, Inc. will shall replace or repair, in a manner as it shall
pay reasonable and customary labor charges when determine, free of charge, F.O.B. factory, any
defective part is replaced, installed or repaired by parts or parts thereof, that in its judgment
a fully authorized Hogg and Davis, Inc. trailer have proven defective. Additionally, Hogg and
dealer at his facility. Davis, Inc. will pay reasonable and customary
labor charges when defective part is replaces,
Warranty credit will be issued only upon receipt installed or repaired by a fully authorized
and inspection of defective parts of at the Hogg and Davis, Inc. trailer dealer at his facility
Hogg and Davis, Inc. factory.
General Conditions & Exceptions
All warranties, options and representations made herein shall apply only provide such equipment shall not
have been subject to misuse, negligence or accident and has been operated in accordance with factory
approved procedures. This warranty does not obligate Hogg and Davis, Inc. or its authorized dealers to bear
the cost of parts obtained from or labor performed by unauthorized sources. Nor does it obligate Hogg and
Davis, Inc. or its authorized dealers to bear the cost of transportation of parts or equipment for repair or
replacement purposes. This warranty is in lieu of any other warranty, expressed or implied, or any other
obligation or liability on the part of Hogg and Davis, Inc and no persons or entity is authorized to make any
representation beyond those stated herein.
Hogg and Davis, Inc. shall not be held liable for consequential damage of any kind. Hogg and Davis, Inc.
also reserves the right to make changes and improvements in its products without incurring any obligation to
install any such changes or improvements upon its products previously manufactured.
The above warranty shall not be misconstrued to mean warranty of tires, clutch, transmission assemblies or
customer requested accessory equipment other than the warranty extended by their respective manu-
factures to Hogg and Davis, Inc. In addition, friction, drive rollers are warranted only to extent of bonding
failure. All warranties, options and representations made herein are applicable to the original end-user of the
product and are not sellable or transferable in any manner.

ODP 20-4
2,000 Lb. Four Drum Puller
- - 14 - -
© COPYRIGHT 2016 HOGG & DAVIS, INC
Parts and other manufacturer manuals
The Following drawings are for part identification only. Please reference the unit
V.I.N. number and the corresponding part number when ordering.
The information, specifications, and illustrations in this manual are on the basis of
information available at the time it was written. The specifications, torque values,
pressures of operation, measurements, adjustments, illustrations, and other items can
change at any time. These changes can affect the service of the given product.
For the complete and most current information, contact:
Hogg & Davis, Inc
P.O. Box 405 / 3800 Eagle Loop
Odell, OR 97044-0405
541-354-1001
541-354-1080 Fax
www.hoggdavis.com
