Hohem iSTEADY X User manual

User Manual
V3.1
3-Axis Palm Gimbal for Smartphone

DISCLAIMER
Thank you for purchasing the Hohem product. By using this
product, you hereby signify that you have read this disclaimer
and warning carefully and that you understand and agree to
abide by the terms and conditions herein. You agree that you
are solely responsible for your own conduct while using this
product, and for any consequences thereof. You agree to use this
product only for purposes that are proper and in accordance
with all applicable laws, rules, and regulations, and all terms,
precautions, practices, policies and guidelines Hohem has made
and may make available. Hohem accepts no liability for damage,
injury or any legal responsibility incurred directly or indirectly
from the use of this product. The user shall observe safe and
lawful practices including, but not limited to, those set forth in
this document.
This document and all other collateral documents are subject to
change at the sole discretion of Hohem. For up-to-date product
information, visit www.hohem.com and click on the product
page for this product.
Email: [email protected]
Website: www.hohem.com
Manufacturer: Hohem Technology Co., Ltd
Hohem Technology Co., Ltd
Connect us at
Facebook

01EN
* Please turn on the gimbal for the 󽘀rst use.
Some features are disabled until Hohem Pro
app is activated. Download the APP to register
for free membership and one-year extended
warranty.
* Mount your mobile phone before powering on
iSteady X. If not, you will hear beep as warning.
Scan the QR code or search for " Hohem Pro "
on the App Store or Google Play.
Download APP—Hohem Pro

iSteady X Diagram
❶ Phone Holder
❷ Folding Lock
❸ Pan Motor Lock
❹ Battery Indicator
❺ Zoom Slider
❻ Shutter
❼ Tilt Motor
❽ Knob
❾ Pan Motor
❿ Bluetooth Light
⓫ Joystick
⓬ Power Button (ON/OFF)
⓭ Type C
⓮ Reset
⓯ 1/4 inch Screw Port
⓰ Roll Motor
⓱ Handle (Battery built-in)
⓲ Wrist Strap
02EN
❸
⓬
⓭
⓮
⓯
⓰
⓱
⓲
❹
❷
❻
❼
❿
❽
⓫
❾
❺
❶

How to mount and balance mobile
phone on the gimbal?
03EN
The gimbal would work improperly if not screw the knob up.
Clench the holder, ensuring that
your phone is cling to the rubber
mat, otherwise the gimbal would
vibrate or turn o󽗿 automatically.
❶ Unfold the gimbal
❸ Make the
“HOHEM”logo upward.
❺ Slide the holder to
the middle of phone to
balance the gimbal.
❷ Screw up the knob
❹ Put your phone stuck in
the bottom of holder and
pull the head of holder to
mount your phone.

Booting up for the 󽘀rst time
Activate iSteady X & Activate APP
Feature
04EN
Please turn on the gimbal for the 󽘀rst use. Some features are disabled
until Hohem Pro app is activated. Download the APP to register for free
membership and one-year extended warranty.
❶ Startup
Long press the function button.
When it is turned on for the
󽘀rst time, it will enter a to-be-
activated state and the Bluetooth
indicator light will 󽘁ash “red and
green” alternately.
❷ Bluetooth connected
directly in the Hohem
Pro App.
Turn on the phone's
Bluetooth, open the APP,
and log into the home page.
Follow the prompt at the top
and click “Connect”.
❸ Activate APP Feature
After the Bluetooth is
connected, an activation
prompt box will pop up.
Click "Con󽘀rm" to complete
the activation. After that,
you will hear a prompt tone
of ticking, which means the
stabilizer starts to work.

05EN
Controls and Operations
How to switch working mode via button?
Press and hold shutter button ④ and tap power button ① :
Single Tap: Pan& Tilt Follow
Double Tap: Pan Follow
Triple Tap: All Lock
Quartic Tap: POV (All Follow)
*Release power button 󽘀rst, then release shutter button.
❸
Zoom (Available in the App)
❹
Press once to take photo or start video or end video.
Press twice to switch photo mode or video mode.
Press three times to switch between front and back cameras.
（Available in the App）
❷
Joystick：Move vertically to tilt the mobile phone.
Move horizontally to pan the mobile phone.
Control roll axis can be set in Hohem Pro.
❶
Press and hold to power on/ o󽗿.
Single tap to switch between landscape and portrait mode.
Press twice to recenter the gimbal.
❶
❷
❸
❹

06EN
Why the Lights Flash?
Power Indicator Lights
* Staying on: fully charged or charging complete
* Single 󽘁ashing: charging
* Flashing in turn: calibrating
Bluetooth Indicator Light
Blinks red and green alternatively : App feature
is waiting for activation
Color indicates the current status of Bluetooth
Blinking indicates the current status of working modes
Color indicates the current status of Bluetooth:
Green: Bluetooth is connected
Yellow: Bluetooth is to be connected
Red: Warning of abnormal loads on the stabilizer or 󽘀rmware update failed
Solid Light: Pan & Tilt Follow
Flash for twice: Pan Follow
Flash for triple: All Lock
Flash for four times: POV (All Follow)

07EN
Speci󽘀cations
Model iSteady X
Folded
Dimensions 179 X 79 X 39 mm
Weight 259 g
Operating Time 8 hours
Mechanical
Range
* Pan: 320°
* Roll: 320°
* Tilt: 320°
Controllable
Range
* Pan: 320°
* Roll: 320°
* Tilt: -30° ~+30°
Compatible
Phones
Weight ：≤ 280g
Thickness：≤ 11 mm
Width：55mm~90mm
Battery 18650li-ion 2000 mAh/3.7V

08EN
CALL CENTER -Toll Free
Within 15 days upon the purchase date. Any functional
disorder or quality problem enjoys free replacement service.
But ensure the commodity and package with no damage,
and we will o󽗿er a brand new replacement after con󽘀rming
the product problem.
Warranty valid only under normal use.
Used in the normal circumstances, 1 year warranty,
maintenance of life (not include the All accidents or arti󽘀cial
damage, improper disassembly or misuse damage is NOT
covered by the warranty).
Please keep and o󽗿er the warranty card for claiming the
warranty service.
1.
2.
3.
4.
UNITED STATES:
[phone] Mon-Fri: 9:00AM-5:00PM(EST)
UNITED KINGDOM:
[phone] Mon-Fri: 2:00PM-10:00PM(GMT +0)
CANADA:
[phone] Mon-Fri: 9:00AM-5:00PM(EST)
BRAZIL:
[phone] Mon-Fri: 10:00AM-6:00PM(GMT -3)
Warranty Terms

09EN
Warranty Card
Service Record：
Failure Cause：
Prod. Serial No.：
Purchase Date：
Address：
Contact No.：
User Name：
