Hollywood HW300 User manual

www.hollywood-audio.com
HW300 HW100 HW200
说明书
Instruction Manual

Installation steps(安装步骤)
Use the enclosed installation template to
ascertain the exact size of the wall cutout.
The inner edge indicates the size of the
installation opening.
Now hollow out an appropriate installation
opening in the wall/ceiling. When laying
loudspeaker cable from amplifier to installation
point, be sure that the cable ends about 30 cm
(12”) beyond the wall cutout.
用挖孔板在墙面/天花板上画好开孔尺寸。
开孔后，喇叭线从挖孔处预留出30厘米长。

Please connect the speaker cable to the
screw clamps. Ensure that the polarity is
correct.
If the red mounting tabs are in a horizontal
position and the screws firmly screwded in,
they are ready for installation.
请将喇叭线连接到端子中，请注意极性。
红色安装脚扣被螺丝锁紧在水平位置时，
即可进行安装。

Place the loudspeaker system in the
installation hole and tighten the screws,
so that the speaker is fixed in the installation
opening.
Important: To prevent damage to the mounting
tab, do not twist screws too tightly.
In order to fine-tune the loudspeaker system
to produce an optimal sound for the location,
it is possible to position the tweeter in such a
way as to adjust the dispersion angle.
将喇叭放入安装孔锁紧螺丝，喇叭便可固定
在墙面/天花板上。
注：为了确保脚扣不受损，请不要用太大扭力。
按需要调好高音方向，让喇叭系统有最佳音响
效果。

On the front of the loudspeaker system there
is a switch marked -/+ for adjusting the tweeter
level. For linear reproduction move the -2 dB (
move the switch to the left) or increased by +2
dB (move the switch to the right) .
The magnetic catch allows you to remove
and replace the cover grill of the loudspeaker
system is ready to use.
喇叭面板上有高音调整开关;设定在“-”为-2dB，
设定在“+”为+2dB,在中间为0dB.
将网罩盖上，安装完成。

Model Description Woofer Tweeter Freq
Response
Power
Handling Sensitivity Impedance
WALL/CEILING SPEAKERS
HW100 Ceiling Speaker
Acoustic 6"Aluminum pivoting 1"Aluminum Dome 60Hz-20KHz 40W 87dB 8 ohm
Ceiling Speaker
Acoustic 6"Aluminum 60Hz-20KHz 40W 85dB 8 ohm
6.5"Aluminum pivoting 1"Aluminum
Dome 60Hz-20KHz 40W 87dB 8 ohm
HW200
HW300
pivoting 3/4"Aluminum
Dome
In-Wall Speaker
Reference
9.7”
9.7”
3.83”
3.83”
12.3”X8.6” 3.19”
8.1”
8.1”
10.7”X6.9”
www.hollywood-audio.com
Hollywood Audio, Inc. 7985 Santa Monica Blvd.Suite 109-228 West Hollywood, CA 90046 USA
Dimension Depth Cut Out
1.65KG
1.75KG
1.8KG
Net Weight

型号 描述 低音 高音 频响范围 额定功率 灵敏度 阻抗
墙壁/天花扬声器
HW100 天花音响
天花音响
6寸铝盆架
6寸铝盆架
6.5寸铝盆架
可摇头1寸铝膜高音
可摇头1寸铝膜高音
可摇头0.75寸铝膜高音
60赫兹-20千赫兹 40瓦87分贝 8 欧姆
60赫兹-20千赫兹 40瓦85分贝 8 欧姆
60赫兹-20千赫兹 40瓦87分贝 8 欧姆
HW200
HW300 墙壁音响
9.7寸
9.7寸
3.83寸
3.83寸
12.3寸X8.6寸3.19寸
8.1寸
8.1寸
10.7寸X6.9寸
www.hollywood-audio.com
Hollywood Audio, Inc. 7985 Santa Monica Blvd.Suite 109-228 West Hollywood, CA 90046 USA
尺寸 深度 外径
1.65公斤
1.75公斤
1.8公斤
净重
