Holman WXSL001 User manual
2 of 24
PRODUCT CODE: WXSL001
iOS is a trademark of Apple Inc. Android is a trademark of Google LLC. The
Android robot is reproduced or modified from work created and shared by
Google and used according to terms described in the Creative Commons 3.0
Attribution License. All other content is Copyright © Holman Industries 2023
3 of 24
Contents
Overview 4
Package Content 4
Setup 5
Preparation 5
Pairing 8
Key Functions 11
Power on/off 11
Bulb – light mode/dimmer 12
The White Feature 13
Pallete – Scenes 14
Music 15
Plan (timer) 16
Troubleshooting 20
My lights won’t flash red for pairing mode 20
To remove the device from Holman Home, 20
Specifications 21
Warranty 23
4 of 24
Overview
Package Content
1. 1 × String of 9 RGB Wi-Fi, Adjustable Spotlights [a].
IP65 – lights are integrated to the cable, no further cable
connection points after the inline switching adaptor
2. 1 × Inline Switching Adaptor [b], output 12VDC, IP67
3. 1 × Plug [c], input 240V AC – must be installed in a waterproof
power point (GPO) or protected area (i.e this is not IP65)
®440mm between each light [d]
®3m from Adaptor to first light [e]
®Distance between lights with cable in brackets 440mm
®Distance between lights without cable in brackets 570mm
ÁNo modification or addition
to the light configuration is possible
c
d
b
e
a
5 of 24
Setup
Preparation
1. Ensure the power point
(GPO) is within 3m of the
first light, the power point
needs to be in a protected
location (or use a waterproof
outdoor power point)
2. The inline switching adaptor
is able to be up to 90cm
from the power point, you
will then have a further 3m
distance to the first light
ÁThis mini spotlight chain
is not extendable or
adjustable
3. Unpack the cables from
their ties and check there
is no damage to your
lights or cables before
plugging the string in [a]
4. Plug the light string into the
Inline Adaptor – please
check the O-Ring [b] is in
place before connecting
and screwing down
the protective cover
5. Turn on the power and
observe the lights are all
working, they may be a
solid colour or flashing red
6. Red flashing indicates the
lights are in pairing mode
7. If the lights are a solid
colour, please turn the
power point on/off/on/off/
on to force the lights into
pairing mode (red flashing)
b
a
6 of 24
8. When placing the lights in
the garden, you can bend
the ‘neck’ of the Adjustable
Spotlights [c] to give the light
direction. This can be used for
wall washing or other effects.
No great force is needed, a
gentle hand can easily bend
the neck with minimal effort
Setup (continued)
Preparation (continued)
c
7 of 24
Setup (continued)
Installing Holman Home
1. Download Holman Home to
your mobile device via the
App Store or
Google Play
2. Open Holman Home
on your mobile device
®You may be prompted to allow
notifications–the app can
still function if you choose to
opt out
3. Tap SIGN UP
4. Read our User Agreement
and Privacy Policy and tap
AGREE if you wish to proceed
5. Follow the prompts to register
a Holman Home account
with your email address
ÁEnsure your country
details are correct at this
stage
®You must allow the
‘Discovering Nearby
Device’ permission (or
Bluetooth®permission,
depending on your phone
operating system) – this
allows Bluetooth®mesh
products to be added into
Holman Home
®You may be prompted to
allow access to your location.
This allows the app to show
weather information-it will
still function if you choose to
opt out
8 of 24
Setup (continued)
Pairing
1. Pairing of the mini
spotlights is via Bluetooth®
Mesh, please ensure
you have allowed the
Bluetooth®(iOS)or
Nearby Devices (Android)
permission
2. These lights will flash
white/fast to indicate
they are ready to pair
(default/pairing mode)
3. Tap ‘Add Device’ from
the Holman Home Home
screen, you will see the mini
spotlights appear under
‘Discovering Devices’
4. Press ‘Add’ [a] to
commence pairing
5. If this is your first
Holman Home Wi-Fi
device, enter/review
your Wi-Fi name and
password, then tap next
6. If this is not your first
device, your Wi-Fi name
and password will appear
pre-filled – review the
details and tap next
a
9 of 24
Setup (continued)
7. When you see the blue circle
[b] appear on the ‘Add
Device’ screen please tap
this to commence pairing
8. After 30 seconds to 1
minute the lights will be
successfully added
9. Tap ‘Done’ to
complete pairing
10. The lights will now load
and you’ll need to edit
the number of lights
(Default is 30 lights)
11. You can delete this using
your keypad and then type 9
12. Tap ‘Confirm’ to save
the bulb number
Pairing (continued)
b
10 of 24
11 of 24
®Menu options at the bottom of
the home screen
1. Power on/off
2. Bulb - Dimmer - RGB
mode, colour or
white selection
3. Pallet – Scenes
4. Music
5. Plan (timer)
Key Functions
Functions
Power on/off
®Turn the lights on and off
manually
®This is also available on the
home page of
Holman Home [a]
1
2
a
4
35
12 of 24
Tipping bucket – all
lights one colour
®Tap the tipping bucket to
select all lights
®Tap the colour selector to
choose a colour
®Use the brightness slider to
dim the lights as needed [d]
Bulb – light mode/dimmer
Functions
LMenu – (right of screen
top to bottom)
LTipping bucket – all lights
one colour [a]
LSquiggle – individual light
selection [b]
LEraser – take a light out of
the system [c]
b
a
c
d
Bulb – light mode/dimmer (continued)
The White Feature
Functions
Squiggle - individual
light selection
®Tap the squiggle
®Tap the colour selector to
choose a colour, then tap the
light to colour it
®Repeat to colour each light as
you prefer
®Brightness applies to the
entire string – use the slider
to adjust this as needed
®A white feature light (created
from blended RGB spectrum)
is available in the colour
selector, select the fade out at
the top of the colour selector
to access this
®The RGB blend does not
change by selecting varying
areas from the colour selector
(i.e selecting the fade above
yellow does not give warm
white), this is a cool white
feature
®This is available as an
individual selection, or for all
the globes as a group
14 of 24
Bulb – light mode/dimmer (continued)
Pallete – Scenes
Functions (continued)
®Tap paint brush to have a
colour pallete to choose from
®Tap the pixel to have squares
as colour/white selection
®Tap the down facing arrow
head to hide the colour
selector, tap the line
to restore [a]
®Tap to select a Scene
®Use the slider at the bottom of
the page to change the speed
of the colour changes/flashing
Other features – paint brush (pallete) or pixel mode, hide selector
a
15 of 24
Music
®Requires audio recording
permission, as this uses the
device microphone to work
®Lights will change colour
(dance) to the beat
Functions (continued)
16 of 24
Plan (timer)
®To set a timer, select ‘Plan’.
There are 2 options available
®Countdown, single use
countdown timer
®Toggle on the countdown
[a], set the countdown
time (scrolling wheel), tap
‘Confirm’ [b] to save
®The countdown will now
start, and be shown on the
plan page
®To set a Timer, tap the
circle [c] to the bottom right
of the page
®You will need a timer for on
and one for off – you can set
more up for different days
of the week. It is possible
to have a different timer for
each day of the week
Functions (continued)
a
c
b
17 of 24
®AM/PM selection is via the
scroll wheel [d] when setting
the time
®Set the time you want
the lights to come on, by
scrolling the wheel for
hours/minutes
®Set the days of the week by
tapping the box – blue is a
scheduled day, black days
don’t apply to this timer
®‘To perform an action’ is
the state the lights will be in
for this timer – close is the
default and this is ‘off’
®Tap to open the action
selection screen, and for an
on time, select ‘The switch
that move light’
Functions (continued)
d
Plan (timer) (continued)
18 of 24
®The colour selection screen
allows you to set a colour
and brightness for the
system
ÁThere is no individual
bulb selection possible in
the timer settings. Colour
and brightness are the
only options
®Tap save once you’ve set
your preference
If you prefer a scene to be
used, select ‘Turn on the
lights to execute the
scene’ – this will take you to
the scene selection screen.
Repeat the process to set an
off time (Close)
®The completed timer will
now be shown on the ‘Plan’
screen
®You can toggle a timer off
by sliding the switch to the
left [e]
Functions (continued)
e
Plan (timer) (continued)
19 of 24
®To edit the timer, open it by
tapping the box, and then
change it as needed
®If you wish to remove the
timer tap Delete [f]
Functions (continued)
f
Plan (timer) (continued)
20 of 24
Troubleshooting
My lights won’t flash red for pairing mode
®To get the lights to change from solid to flashing, turn the power on
and off as follows: on/off/on/off/on
Please allow 10-20 seconds for the string to respond to the on/off
pattern after the final on – they will then start flashing
To remove the device from Holman Home,
®Tap the pencil at the top
right of the screen, then
‘Remove Device’ at the
bottom of the screen [a]
®You’ll have the option
to ‘Disconnect’, or
‘Disconnect and wipe’:
LDisconnect is a good idea
for something like a modem
change, or moving house
LDisconnect and wipe will
remove all settings from the
lights (and cloud) and restore
factory defaults
The Holman website has a host of additional information on features. Head to
support.holmanindustries.com.au for more tips, tricks and support content.
If you still need help, feel free to email our friendly Customer Service team at
a
