HOLOPHANE Jefferson Series Manual

IM-37-C
HOLOPHANE
HOLOPHANEHOLOPHANE
HOLOPHANE

Arlington®/ Installation and
Jefferson Series Maintenance
Manual
AFTER INSTALLATION DELIVER THIS
MANUAL TO OWNER
Arlington Jefferson
GR163, GR1193
IMPORTANT SAFETY INSTRUCTIONS
WARNING – READ THESE INSTRUCTIONS
CAREFULLY BEFORE ATTEMPTING TO INSTALL OR
MAINTAIN THIS FIXTURE. WORK MUST BE DONE BY
QUALIFIED PERSONNEL.
WARNING – BE CERTAIN THAT ALL ELECTRICAL
POWER IS DISCONNECTED
FROM THE FIXTURE BEFORE INSTALLING
OR MAINTAINING THE FIXTURE.
WARNING – FOLLOW LAMP MANUFACTURER’S
OPERATING AND MAINTENANCE INSTRUCTIONS.
FAILURE TO FOLLOW THESE WARNINGS
MAY RESULT IN DEATH, INJURY OR SIGNIFICANT
PROPERTY DAMAGE.
1. INTRODUCTION
1.1 Product Description.
•The Arlington and Jefferson products are suitable for use in wet
locations and with ambient temperatures up to 25 degree C.
•These luminaires are designed to distribute specific patterns of
light on the surface below. All optics including glass,
polycarbonate, and acrylic have street side orientation
embossed on the flange of the refractor.
•These luminaires are designed for easy maintenance.
•The lamp can be accessed by disengaging the latch and raising
the top cover.
•Electrical components are mounted on an easily removable
ballast assembly plate.
1.2 Alternate Information Sources.
Holophane
Field Service Department
P.O. Box 3004
Newark, OH 43058-3004
[phone]
2. INSTALLATION
2.1 Tools and Material Required.
Table 1. Installation Tools and Materials
DESCRIPTION USE
1/8" Allen socket Set screws (mounting)
1/4" nut driver or medium Ballast assembly plate
flat screwdriver and wire way cover
Torque wrench Set screws
2.2 Installation of Luminaire without Photocontrol
Receptacle.
2.2.1 Disengage latch and open top cover. See Figure 1.
2.2.2 Remove refractor.
2.2.3 Loosen the two keyway screws and turn ballast plate
assembly clockwise to disengage. Rotate ballast plate assembly 90
degrees and gently lay the socket between two ribs opposite the
hinge. See Figure 2.
2.2.4 Loosen screw to wire way cover and remove wire way cover.
Feed supply leads from the pole through the wire way hole.

IM-37-C
2.2.5 Place and level the luminaire on the pole. Position with one
rib pointed toward the street. Alternate tightening of the four set
screws will assist in centering the luminaire on the post capital.
Tighten the four set screws to 45-50 inch pounds.
2.2.6 Wire ballast and line leads accordingly. Connect incoming
ground wire to ground wire attached to inside of wiring chamber.
Connect incoming common wire to wire marked COM from the
ballast. If a single voltage ballast is used, check the voltage number
on the only remaining wire to verify the ballast voltage. Connect this
voltage wire. Note: Lead may require to be stripped. If a multivolt
ballast is used, find the correct voltage number marked on one of the
remaining wires and make the connection. Carefully, place
connections in wiring chamber for future access. See
Figure 1.
2.2.7 Replace wireway cover. Tighten screw.
2.2.8 Gently move ballast plate assembly to an upright position and
place the assembly over the two keyway screws and turn
counterclockwise into position. Tighten screws.
Figure 1
GR206
OPTICS ORIENTATION NOTES
Some of the fixtures in this series are equipped with optical
components that produce distributions of light that are not symmetric
and are intended to be aimed by orienting the prismatic glass
refractor a specific direction. The “Street Side” marking on the top of
the refractor should be pointed toward the street.
2.2.9 Replace the refractor. Orient the refractor by locating the
markings on the refractor flange. Position the "street side" marking
toward the street and align the "rib" markings with the ribs of the
casting.
2.2.10 Install correct wattage and type lamp.
2.2.11 Close top cover and engage latch.
2.2.12 Energize the luminaire. Check for proper operation.
2.3 Installation of Luminaire with Photocontrol
Receptacle.
The photocontrol receptacle is shipped partially installed with the
luminaire. The receptacle will accept a standard twist-lock
photoelectric control conforming to standards in NEMA Published
No. SH-1959. The receptacle is specified with a catalog number
suffix of -R.
Figure 2
GR207
Figure 3
GR208
2.3.1 Disengage latch and open top cover. See Figure 1.
2.3.2 Disengage electrical connector and remove wires from wire
support. See Figure 3.
2.3.3 Remove refractor. Loosen the two keyway screws and turn
ballast plate assembly clockwise to disengage. Rotate ballast plate
assembly 90 degrees and gently lay the socket between two ribs
opposite the hinge. See Figure 2.
2.3.4 Loosen screw to wire way cover and remove wire way cover.
Feed supply leads from the pole through the wire way hole.
2.3.5 Place and level the luminaire on the pole. Position with one
rib pointed toward the street. Alternate tightening of the four set
screws will assist in centering the luminaire on the post capital.
Tighten the four set screws to 45-50 inch pounds.

IM-37-C
2.3.6 Wire ballast and line leads accordingly. Connect incoming
ground wire to ground wire attached to inside of wiring chamber.
Connect incoming common wire to wire marked "COM" from ballast.
(On 35W high pressure sodium and 200W incandescent units,
connect to white wire.) Connect incoming line lead to the black lead
from the photocontrol receptacle electrical connector. Verify the red
lead from the photocontrol receptacle electrical connector is
connected to the correct voltage lead from the ballast. See Figure 4.
Carefully, place connections in wiring chamber for future access.
See Figure 1.
2.3.7 Replace wire way cover. Tighten screw.
2.3.8 Gently move ballast plate assembly to an upright position and
place the assembly over the two keyway screws and rotate into
position. Tighten screws.
OPTICS ORIENTATION NOTES
Some of the fixtures in this series are equipped with optical
components that produce distributions of light that are not symmetric
and are intended to be aimed by orienting the prismatic glass
refractor a specific direction. The “Street Side” marking on the top of
the refractor should be pointed toward the street.
2.3.9 Replace the refractor. Orient the refractor by locating the
markings on the refractor flange. Position the "street side" marking
toward the street and align the "rib" markings with the ribs of the
castings.
2.3.10 Place photocontrol wires into wire support. Reconnect
electrical connector. See Figure 3.
2.3.11 Install correct wattage and type lamp. Close top cover and
reengage latch.
2.3.12 Remove plastic cap from top of luminaire.
2.3.13 Loosen two screws on photocontrol receptacle. Rotate the
receptacle to point the arrow marked "N" in a direction that is
generally North but not pointing directly toward a nearby luminaire.
Tighten screws.
2.3.14 Install a twist-lock type photocontrol into the receptacle.
2.3.15 Energize the luminaire. Check for proper operation.
Figure 4
GR209
3. MAINTENANCE
3.1 Relamping and Cleaning.
3.1.1 Wipe off exterior dirt and debris.
3.1.2 Disengage latch and open top cover. Refer to Figure 1.
3.1.3 Remove lamp.
3.1.4 For photocontrol luminaire, disconnect electrical connector
and remove photocontrol wires from wire support. See Figure 3.
3.1.5 Remove refractor.
3.1.6 Wipe the refractor interior with a clean dry cloth.
3.1.7 Replace cleaned refractor. Orient the refractor by locating
the markings on the refractor flange. Position the "street side"
marking toward the street and align the "rib" markings with the ribs of
the castings.
3.1.8 For photocontrol luminaire, place photocontrol wires into wire
support and reconnect electrical connector. See Figure 3.
3.1.9 Install new lamp of correct wattage and type.
3.1.10 Close top cover and engage latch.
3.1.11 Energize the luminaire. Check for proper operation.
3.2 Electrical Component Replacement Luminaire
without Photocontrol.
3.2.1 Disengage latch and open top cover. Refer to Figure 1.
3.2.2 Remove the lamp.
3.2.3 Remove refractor.
3.2.4 Loosen the two keyway screws and turn ballast plate
assembly clockwise to disengage. Rotate ballast plate assembly 90
degrees and gently lay the socket between two ribs opposite the
hinge. See Figure 2.
3.2.5 Loosen screw to wireway cover and remove wireway cover.
3.2.6 Tag and disconnect common and line leads.
3.2.7 Place the ballast plate assembly to an upright position and
remove.
3.2.8 Unpack replacement ballast assembly. Check voltage leads.
3.2.9 Set replacement ballast assembly down into casting. Orient
with capacitor located on side of casting marked "capacitor." Rotate
ballast plate assembly 90 degrees and gently lay the socket between
two ribs opposite the hinge. See Figure 2. Reconnect electrical
connections in accordance with tags and approved wiring practices.
3.2.10 Replace wireway cover. Tighten screw.
3.2.11 Gently move ballast plate assembly to an upright position
and place the assembly over the two keyway screws and turn
counterclockwise into position. Tighten screws.
3.2.12 Replace the refractor. Orient the refractor by locating the
markings on the refractor flange. Position the "street side" marking
toward the street and align the "rib" markings with the ribs of the
castings.
3.2.13 Replace correct wattage and type lamp.
3.2.14 Close top cover and engage latch.
3.2.15 Energize the luminaire. Check for proper operation.
3.3 Electrical Component Replacement for
Luminaire with Photocontrol.
3.3.1 Disengage latch and open top cover. Refer to Figure 1.
3.3.2 Remove the lamp.
3.3.3 Disconnect electrical connector and remove photocontrol
wires from wire support. See Figure 3.
3.3.4 Remove refractor. Loosen the two keyway screws and turn
ballast plate assembly clockwise to disengage. Rotate ballast plate
assembly 90 degrees and gently lay the socket between two ribs
opposite the hinge. See Figure 2.
3.3.5 Loosen screw to wireway cover and remove wireway cover.
3.3.6 Tag and disconnect common and line leads.
3.3.7 Place the ballast plate assembly to an upright position and
remove.

IM-37-C
3.3.8 Unpack replacement ballast assembly. Check voltage leads.
3.3.9 Set replacement ballast assembly down into casting. Orient
with capacitor located on side of casting marked "capacitor." Rotate
ballast plate assembly 90 degrees and gently lay the socket between
two ribs opposite the hinge. See Figure 2. Reconnect electrical
connections in accordance with tags and approved wiring practices.
3.3.10 Replace wireway cover. Tighten screw.
3.3.11 Gently move ballast plate assembly to an upright position
and place the assembly over the two keyway screws and turn
counterclockwise into position. Tighten screws.
3.3.12 Replace the refractor. Orient the refractor by locating the
markings on the refractor flange. Position the "street side" marking
toward the street and align the "rib" markings with the ribs of the
castings.
3.3.13 Place wires into wire support and reconnect electrical
connector. See Figure 3.
3.3.14 Replace correct wattage and type lamp. Close top cover
and engage latch.
3.3.15 Energize the luminaire. Check for proper operation.
4. ACCESSORIES
4.1 GV1A73 Pole Top Adaptor.
Refer to Figure 5.
4.1.1 Place and level pole top adapter on the pole. Alternate
tightening of the six set screws will assist in centering the adapter on
the tenon. Tighten the four set screws to 70 inch pounds minimum.
4.1.2 Install the luminaire.
Figure 5
GR1044
5. LIMITED WARRANTY AND
LIMITATION OF LIABILITY
The Holophane limited warranty and limitation of liability is published
in the "Terms and Conditions" section of the current Holophane
buyer's guide, and is available from your local Holophane sales
representative.
®
Acuity Lighting Group, Inc.
214 Oakwood Ave., Newark, OH 43055
IM-37-C, 7/02 ©2002 Acuity Lighting Group Inc.
Visit our web site at www.holophane.com
Printed in USA
