Holtkoetter 2517/1 P1 Series User manual

Major lamp parts manufactured in Germany by Holtkötter Leuchten GmbH.
Bulbs manufactured in Germany by Osram GmbH.
Final assembly by Holtkötter International, Inc. in South St. Paul, MN.
Holtkötter ®and Holtkötter Leuchten®are registered trademarks
of Holtkötter International, Inc. All Rights Reserved.
© Holtkötter International, Inc.
ASSEMBLY INSTRUCTIONS FOR
HOLTKÖTTER INTERNATIONAL, INC.
155 Hardman Avenue South, South St. Paul, MN 55075
fax: [phone] • phone: [phone]
www.holtkoetter.com
e-mail: [e-mail]
Torchiere No. 2517/1*P1
Featuring “Dimm System Punkt 1”
(Dimming System Point 1)
Congratulations, you have just purchased the leading-edge dimming technology from Holtkötter
International, Inc. We have specifically designed the “Dimm System Punkt 1” (Dimming System
Point 1 (P1)) to provide specialized features for ease and convenience of use.
Features of the “Dimm System Punkt 1”
Point Dimming - the lamp may be turned on
with a single click of the P1 dimmer.
Soft On - the lamp may be turned on with a
single click of the P1 dimmer. The lamp will
come on low and continue to brighten to
full brightness. This allows the eye to adjust
to a gradual increase in light.
Soft / Delayed Off - turn the lamp off with a
single click of the P1 dimmer. The lamp will
dim to 60% brightness of the original setting,
remaining briefly at that level to allow you
to exit the room; then the lamp gradually
turns itself off. This “soft” off provides a few
moments of light after turning the lamp off,
rather than immediate darkness as is the
case with other switches.
Dimming Cycle - to adjust the lamp to the
perfect light level for any situation, press
and hold the P1 dimmer. The dimmer will
cycle through all dimming levels. When the lamp achieves the light level of your
choice, release the P1 dimmer.
Tilt Switch - a safety measure is provided with the “Dimm System Punkt 1”. In the
event that the lamp is tipped over, the tilt switch cuts off the power to the lamp.
Care Instructions
Use only a soft, dry cloth to clean. If necessary, a slightly damp, soft cloth can be used to spot
clean. Do not use common household cleaners on lamps or fixtures, as the lacquer on the outside
of the brass may be damaged as a result. Enjoy your new Holtkötter lamp.
CAUTION, IMPORTANT SAFETY INSTRUCTIONS
This portable luminaire has a polarized plug (one blade is wider than the other) as a feature to
reduce the risk of electrical shock. This plug will fit a polarized outlet only one way. If the plug does
not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician.
Never use with an extension cord unless plug can be fully inserted. Do not alter the plug.
INSTRUCTIONS PERTAINING TO A RISK OF FIRE,
ELECTRIC SHOCK, EXPOSURE TO EXCESSIVE
UV RADIATION OR INJURY TO PERSONS
WARNING - To reduce the risk of FIRE,
ELECTRIC SHOCK, EXPOSURE TO EXCESSIVE
UV RADIATION OR INJURY TO PERSONS:
Turn off power/unplug and allow to cool before replacing bulb.1.
Bulb gets HOT quickly. Contact only switch/plug when turning on.2.
Do not touch hot lens, guard or enclosure.3.
Do not remain in light if skin feels warm.4.
Do not look directly at lighted lamp.5.
Keep lamp away from materials that burn.6.
Use only with a 150 Watt, bayonet base halogen bulb or smaller bulb.7.
Do not touch the bulb at any time. Use a soft cloth. Oil from skin may damage bulb.8.
Do not operate the portable luminaire with a missing or damaged guard, lamp containment9.
barrier or UV filter.
SAVE THESE INSTRUCTIONS

Major lamp parts manufactured in Germany by Holtkötter Leuchten GmbH.
Bulbs manufactured in Germany by Osram GmbH.
Final assembly by Holtkötter International, Inc. in South St. Paul, MN.
Holtkötter ®and Holtkötter Leuchten®are registered trademarks
of Holtkötter International, Inc. All Rights Reserved.
© Holtkötter International, Inc.
HOLTKÖTTER INTERNATIONAL, INC.
www.holtkoetter.com
e-mail: [e-mail]
ASSEMBLY INSTRUCTIONS FOR
Torchiere No. 2517/1*P1
Please make sure that the following parts for your torchiere are enclosed:
Torchiere1.
Glass shade2.
Glass shield3.
Bulb: 150 Watt Bayonet-Base Halogen Bulb by Osram4.
Order Code: 9250*150-DC/FR
Install the Bulb
Be sure that the lamp is turned off and unplugged prior to
installation.
Install the new bulb (G), being careful not to touch the bulb
envelope with your bare hands. Hold the bulb at the porcelain
grip, insert it into the socket, push it down slightly and turn it
clockwise.
Note of Caution: The recommended replacement bulb for
this fixture is the 150 Watt Osram Bayonet Base Halogen bulb
(frosted). Use of other brands of unknown quality may cause a
risk of overheating.
Install the Glass Shade (Diagram A)
Once the bulb is installed, the glass shade (F) can be installed.
Prepare the torchiere by removing the following parts from the1.
fixture:
• Screw (A)
• Silicone Ring (C)
• Knurled Nut (D) and
• Washer (E).
Place the Glass Shade (F) onto the lamp. Slide a washer (E) over2.
each of the stems (H) and secure in place with a knurled nut (D).
Prepare the glass shield (B) by placing a screw (A) in each of the3.
holes provided. Slide a small silicone ring (C) over each screw to
hold in place. Place the glass shield over the fixture shiny side up.
Align the screws (A) in the glass shield with the stem of the lamp and4.
screw into place. Do not overtighten.
Replace the Fuse
An integrated fuse to protect the dimming
circuit can be found in the base of the lamp.
Please check the fuse first, in case the lamp
does not come on. A four (4) Amp replacement
fuse can be found at any hardware store or
Radio Shack store.
D
E
A
C
F
G
B
H
