Home Decorators Collection SK13560R1 User manual

3R1

Thank you for purchasing this quality product. Be sure to check all
packing material carefully for small parts, which may have came
loose inside the carton during shipment. Count all parts and material
hardware, then compare with parts list to be sure all parts are
present. If any parts are missing or damaged, phone, fax, or mail to
our Customer Service Department for efficient and speedy service.
Please indicate the model number and code letter of part(s) needed.
IMPORTANT NOTE: Follow instructions listed below in proper
sequence as numbered to assure fast,easy and correct assembly.
SUPPORT PANEL-2PCS
2/10

cb
SHOULDER
NOTE: UPON OPENING, THOROUGHLY CLEAN ALL WOOD SURFACES TO REMOVE DUST
AND DIRT THAT MAY HAVE SETTLED ONTO THE FINISH DURING SHIPMENT. IN
ORDER TO PREVENT DAMAGE DURING ASSEMBLY. PLEASE ASSEMBLE THIS ITEM
WITH AT LEAST TWO PEOPLE.
HOW TO USE THE CAM-TOOL
NOTE: THE ARROWS ON THE HIDDEN CAM-LOCKS SHOULD POINT TO THE CAM-BOLTS.
ARROW
NOTE: TURN THE CAM-BOLT SCREWS UNTIL THEY
ARE TIGHT, THE SHOULDER SHOULD BE
AGAINST THE SURFACE OF THE PART.
ARROW
4/10

● INSTALL THE WOOD DOWEL (a) AND THE CAM LOCK BOLT (b) INTO THE TOP PANEL (D).
● JOIN THE TOP PANEL (D) TO THE DIVIDER (C) BY USING WOOD DOWEL (a) FIRST.
● ONCE JOINED, TIGHTEN CAM LOCK (c) ONTO BOLT (b) USING PRE-DRILLED HOLES.
● COVER THE CAM HOLES WITH PLASTIC COVER (f).
FIG 1
5/10

● INSTALL THE WOOD DOWEL (a) AND THE CAM LOCK BOLT (b) INTO THE BOTTOM PANEL (E).
● JOIN THE BOTTOM PANEL (E) TO THE DIVIDER (C) BY USING THE WOOD DOWEL (a) FIRST.
● ONCE JOINED, TIGHTEN CAM LOCK (c) ONTO BOLT (b) USING PRE-DRILLED HOLES.
● COVER THE CAM HOLES WITH PLASTIC COVER (f).
FIG 2
6/10

● INSTALL THE WOOD DOWEL (a) AND THE CAM LOCK BOLT (b) INTO THE LEFT SIDE PANEL
(A) AND THE RIGHT SIDE PANEL (B).
● JOIN THE LEFT SIDE PANEL (A) AND THE RIGHT SIDE PANEL (B) TO THE ASSEMBLED PART,
THE UPPER FRONT CROSS BAR (F), THE UPPER BACK CROSS BAR (G), THE LOWER BACK
CROSS BAR (H), AND THE LOWER FRONT CROSS BAR (I) BY USING WOOD DOWEL (a) FIRST.
● ONCE JOINED, TIGHTEN CAM LOCK (c) ONTO BOLT (b) USING PRE-DRILLED HOLES.
● COVER THE CAM HOLES WITH PLASTIC COVER (f).
FIG 3
7/10

● TIGHTEN THE UPPER FRONT CROSS BAR (F), THE LOWER FRONT CROSS BAR (I),
AND THE LOWER BACK CROSS BAR (H) BY USING THE FLAT HEAD SCREW (e).
● JOIN THE SUPPORTIVE PANEL (J) TO THE BOTTOM PANEL (E) BY USING THE WOOD
DOWEL (a) FIRST.
● TIGHTEN THE SUPPORTIVE PANEL (J) BY USING THE FLAT HEAD SCREW (e) THROUGH
PRE-DRILLED HOLES.
FIG 4
8/10
