Home HME030343N User manual

Window AC
HME030343N
Thank you for selecting our quality appliance. Please be sure to read this user manual carefully before using. Any question, please contact the professional service for help.

Important Satety Instructions
Electrical Requirements
Operating Instructions
Cleaning and Maintenance
Troubleshooting
Warranty
Manufacturing Info
Warning
Contact Us
6-7
8-9
10-24
25
26
27
27
27
27
TABLE OF CONTENTS
BEFORE FIRST USE:
To prevent any internal damage, it is very important to keep
refrigeration units (like this one) upright throughout their journey.
Please leave it standing upright and outside the box for 24 HOURS
before plugging it in.
In the event this product malfunctions or customer believes
it is defective, the customer should contact Customer Service
and retain the defective product pending further instructions.
Defective product should be clearly marked or stored where it
cannot be used again by mistake. Failure to retain the product
may impede hOme™’s ability to correct any legitimate problem
and may limit the extent to which hOme™may provide recourse.

on bringing home your new appliance!
Congratulations
Don’t forget to register your product at homelabs.com/reg
for updates, coupons, and other relevant information.
Although greatly appreciated, product registration is not
required to activate any warranty.

6 7
Before installing and using your air conditioner, please read this owners manual carefully. Store
this manual in a safe place for future reference. Your safety and the safety of others is very
important to us. Please pay attention to all safety messages outlined in this owners manual.
WARNING
To reduce the risk of re, electrical shock or injury when using your air conditioner, follow the
following basic precautions.
• Plug into a grounded 3 prong outlet.
• Do not remove the ground prong.
• Do not use a plug adapter.
• Do not use an extension cord.
• Unplug the air conditioner before servicing.
• Use two or more people to move and install the air conditioner.
WARNING
• This is a safety alert symbol.
• This symbol alerts you to potential hazards that can harm you or others or even cause
death.
• All safety messages will directly follow the safety alert symbol and/or the words “DANGER”
or “WARNING”.
• Failure to immediately follow these instructions may cause serious injury or even death.
• All Safety messages alert you of potential hazards, how to reduce the chance of injury, and
what can happen if instructions are not followed correctly.
WARNING
• Please read the manual before installation, using, maintenance.
• Do not use means to accelerate the defrosting process or to clean, other than those
recommended by the manufacturer.
• Do not pierce or burn the appliance.
• The appliance shall be stored in a room without continuously operating sources (for
example: open ames, an operating ignition gas appliance or an operating electric heater.)
• Please contact the nearest after-sale service center when maintenance is necessary. At the
time of maintenance, the maintenance personnel must strictly comply with the Operation
Manual provided by the corresponding manufacturer and any non-professional is prohibited
to maintain the air conditioner.
• The handling, installation, storage, servicing and disposal must comply with the provisions of
gas-related national laws and regulations, and also national wiring regulation.
• It is necessary to clear away the refrigerant in the system when maintaining or scrapping an
air conditioner. Be aware that refrigerants may not contain an odor.
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or supervision or instruction concerning use of the appliance
by a person responsible for their safety. Children should be supervised to ensure that they
do not play with the appliance.
Important Safety Instructions
SAVE THESE INSTRUCTIONS
For Household Use Only
Important Safety Instructions
INSTALLATION & ASSEMBLY INSTRUCTIONS
Please note that:
1. The installation site should be in a well-ventilated condition.
2. When installing an air conditioner, it is necessary to take appropriate anti-static measures such as
wear anti-static clothing and/or gloves.
3. It is necessary to choose the site convenient for installation or maintenance wherein the air inlets
and outlets of the indoor and outdoor units should be not surrounded by obstacles or close to any
heat source or combustible and/or explosive environment.
4. If the indoor unit suffers refrigerant leak during the installation, all the personnel should go out till
the refrigerant leaks completely for 15 minutes. If the product is damaged, it is a must to carry such
damaged product back to the maintenance station and it is prohibited to weld the refrigerant pipe
or conduct other operations on the user’s site.
5. It is necessary to choose the place where the inlet and outlet air of the indoor unit is even.
6. It is necessary to avoid the places where there are other electrical products, power switch plugs
and sockets, kitchen cabinet, bed, sofa and other valuables right under the lines on two sides of the
indoor unit, and also prevent mechanical damage from occurring.

8 9
The electrical ratings for your air conditioner are
listed on the model and serial number label located
on the front left side of the unit (when facing the
front).
Specic electrical requirements are listed in the
chart below. Follow the requirements below for the
type of plug on the power supply cord.
Recommended Ground Method
For your personal safety, this air conditioner must be grounded. This air conditioner is equipped with a
3prong power supply cord with a grounded plug. To minimize the possibility of electrical shock, the cord
must be plugged into a 3 prong outlet and grounded in accordance with all local codes and ordinances.
If a 3 prong outlet is not available, it is the customer’s responsibility to have a properly grounded 3 prong
outlet installed by a qualied electrician.
It is the customer’s responsibility:
• To contact a qualied electrician
• To assure that the electrical installation is adequate and in conformance with the National
Electrical Code, ANSI/NFPA 70 - latest edition, and all local codes and ordinances.
Copies of the standards listed may be obtained from:
• National Fire Protection Association
• One Batterymarch Park
• Quincy, Massachusetts 02269
Electrical Requirements
Power Supply Cord
15K
LCDI POWER CORD AND PLUG
This air conditioner is equipped with an LCDI (Leakage Current Detection and Interruption) power cord that
is required by UL. This power supply cord contains state-of-the-art electronics that sense leakage current.
If the cord is damaged and leakage occurs, power will be disconnected from the unit.
The test and reset buttons on the LCDI Plug are used to check if the plug is functioning properly. To test
the plug:
1. Plug power cord into a grounded 3 prong outlet.
2. Press RESET (on some units a green light will turn on).
3. Press the TEST Button, The circuit should trip and cut all power to the air conditioner (on some
units a green light may turn off).
4. Press the RESET button for use. You will hear a click and the unit is ready for use.
NOTES:
• The RESET button must be engaged for proper use.
• The power supply cord must be replaced if it fails to trip when the
TEST button is pressed and the unit fails to reset.
• Do not use the power supply cord as an ON/OFF switch. The power
supply cord is designed as a protection device.
• A damaged power supply cord must be replaced with a new power
supply cord.
• The power supply cord contains new user serviceable parts. Opening
the tamper-resistant case voids all warranty and performance claims.
NOTES:
The power cord and plug may differ from the one shown above.
Electrical Requirements
A. Reset button
B. Test button

10 11
PACKING LIST
IMAGE PART QUANTITY
Window Air Conditioner 1
Remote Control 1
Top Mounting Rail
(With sponge)
1
Filler Panels
(With “Left” & “Right” remark
on the front face)
2
Sash Lock
(Two holes)
1
Window Sash Seal
(Sponge)
1
5/16” Long Hex-head Screw 10
5/8” Long Hex-head Screw 4
1/2” Long Hex-head Screw 2
5/8” Long Flat Head Bolt and
Locknut
2
Sill Angel Bracket 2
1/2” Long Flat Head Bolt and
Locknut
4
Gasket 2
Foam Top Window Gasket
(Thin sponge for backup using)
1
Insulation strip (Sponge)
(Only for E-star model)
2
Support Bracket (with R and L
remark)
2
Battery 2
Operating Instructions Operating Instructions
WARNING
Avoid fire hazard or
electric shock. Do not use an extension cord
or an adaptor plug. Do not remove any prong
from the power cord.
Grounding type wall receptacle
Power supply cord
with 3-prong grounding
plug and current
detection device
Do not, under any
circumstances , cut,
remove, or bypass the
grounding prong.
INSTALLATION & ASSEMBLY INSTRUCTIONS
Window Preparation
Please read all instructions prior to installing your air conditioner. Two people are recommended to install
this product. If a new electrical outlet is required, have the outlet installed by a qualied electrician before
installing the unit.
Before installing the unit, check the dimensions of your window to make sure the air conditioner will t.
This unit is made to t inside a standard double-hung window. Make sure the window is in good shape
and able to rmly hold the needed screws. If not, make repairs prior to installing the unit.
Model 15K
Unit Height (inches) 17.91
Unit Width (inches) 23.625
Min. Window Opening
(See FIG l) (inches)
19.00
Min. Window Width (inches) 28.00
Max Window Width (inches) 41.00

12 13
Operating Instructions
Storm Window Requirements
A storm window frame will not allow the air conditioner to tilt properly which in turn will keep it from
draining properly. To adjust for this, attach a board or piece of wood to the sill. The board or wood piece
should have a depth of at least 1/2”. Make sure the board or piece of wood is approximately 1/2” higher
than the storm window frame. This will allow the air conditioner to tilt enough for proper drainage. (15K
See FIG.1 ).
Prior to Installing the Air Conditioner
1. Check for anything that could block airow. Check the area outside of the window for things such
as shrubs, trees, or awnings. Check the inside area to make sure curtains, drapes, or blinds will not
prevent proper airow.
2. Check the available electrical outlet. The power supply must be the same as shown on the unit
serial nameplate (located on the left side of the unit, near the front faceplate). Be sure the outlet is
close enough for the power cord to reach.
3. Carefully unpack the air conditioner. Remove all packing material and make sure the oor is
protected when removing. Due to the large size of this air conditioner, two people should move the
unit together.
WARNING
When handling the unit, be careful to avoid cuts from the sharp metal edges and aluminum ns on the
front and rear coils.
Operating Instructions
INSTALLATION &ASSEMBLY INSTRUCTIONS -WINDOW MOUNTING
REMOVE CHASSIS
1. Pull down the front panel and lift upwards. Place to the side (FIG.2).
FIG.2
Front panel
Remove filter
2. Remove the lter.
3. Locate the four faceplate screws and remove. These screws will need to be re-installed prior to
mounting the air conditioner (FIG.3).
4. After removing the screws, gently pull away the faceplate from the air conditioner cabinet (FIG.4).

14 15
Operating Instructions
REMOVE CHASSIS (CONT.)
5. Rotate the detached faceplate to expose the backside of the front panel. Remove the control panel
screw and set aside the faceplate (FIG.5).
Screw
Reversed side of front panel FIG.5
6. Remove the six screws from the cabinet.(There are two screws on the top, left and right.) (FIG.6)
FRONT
7. Hold the cabinet while pulling on the base handle to carefully remove the unit. Do not pull or lift
near the top of the unit (FIG.7)
FIG.7
Do not
pull or
lift in
this
area.
This may
result in
damage.
FRONT
Operating Instructions
Top Angle Rail and Side Bracket Installation
The top rail must be assembled prior to installing the air
conditioner in the window.
Tools Needed: Phillips Screw Driver
Top Rail Hardware QTY
5/16
Long
Hex-head
Screw
4
Top
Rail
1
Aaching the Top Rail to the Air Conditioner
1. Remove the air conditioner from the box and place on a
hard at surface.
2. Remove top rail from the bottom of the packaging material
as shown in FIG. A.
3. Secure the top rail to the unit with the 5/16” Screws as
shown in FIG. B.
4. Slide the “I” section of the window panel into the side
bracket of the cabinet (FIG.8a). Do this for both sides.
FIG.8a
NOTE:
For safety reasons, all 4
screws must be used to attach
the top rail.
Foam Gasket and Top
Angle Rail

16 17
Operating Instructions
Aaching the Top Rail to the Air Conditioner
(CONT.)
5. Insert top and bottom legs of window ller
panel frame into channel in the top angle and
bottom rail. Do both sides. Install side retainer
to cabinet as shown. (FIG.8b-9).
5/16" Long
Hex-head Screw
FIG.8b
FIG.9
Placing the Cabinet Inside the Window
1. Open the window and place the cabinet in the
middle of the window sill.
2. Make sure the bottom rail is seated over the
window sill as shown below. Bring the window
down temporarily behind the top angle rail to
hold the cabinet in place. (It is suggested to
keep a downward angle so accumulated rain
water can drain out from the backside of the
unit.)
3. Fasten cabinet to window sill using two 5/8”
Round -Head screws. Pre-drill holes if needed.
Add the bottom rail seal over the screws.
5/8" Long
Hex-head Screw
Gasket
Install Support Brackets
1. Hold each support bracket ush against
the outside of the window sill. Tighten each
bracket to the bottom of the cabinet as shown
below. Mark the brackets at top lever of the
window sill and then remove.
Mark
5/8" Long Flat Head Bolt
Long Flat head
Bolt and Locknut
Operating Instructions
Install Support Brackets (CONT.)
2. Assemble the sill angle brackets to the
support brackets at the marked position as
shown above. Hand tighten, but not all the way
for any changes that may need to be made
later during installation.
3. Install the support brackets (with sill angle
brackets attached) to the bottom of the
cabinet as shown below.
4. Tighten all 6 bolts securely.
Long
Flat head
Bolt and
Locknut
Extend the Accordion Panels
1. Carefully raise the window to expose the
accordion panel and panel frame. Loosen the
locking screws so the accordion panels slide
easily.
5/8" Long
Hex-head Screw
1/2" Long
Hex-head Screw
2. Extend each panel to completely ll the width
of the window. Tighten the locking screws
when the panels are fully extended.
Install the Window Lock and Sash Seal
1. Trim the sash seal to t the width of the
window. Insert the sash seal into space
between the upper and lower sashes.
2. Attach the right angle sash lock as shown
below.
5/8" Long
Hex-head Screw
Sash Lock
Installing the Chassis into the Cabinet
1. Team lift (two people) the air conditioner
chassis and carefully slide it into the cabinet.
Let the front of the air conditioner hang out
approximately 6”.
2. CAUTION: DO NOT PUSH ON THE CONTROLS
OR FINNED COILS.
3. Be sure the chassis is rmly seated in the back
of the cabinet.
4. Insert all screws removed during window
installation and reattach the front face plate,
front panel, and the air lter. Use the REMOVE
CHASSIS instructions and gures 5-11 for
reference.

18 19
Operating Instructions
THRU-THE-WALL INSTALLATION
NOTE: Consult local building codes prior to
installation and/or a qualied carpenter.
Select the Wall Location
This air conditioner has a slide-out chassis, so
that it can be installed through an outside wall as
specied below:
MAX WALL THICKNESS: 8”
IMPORTANT: The side louvers must never be blocked.
NOTE: All parts needed for Thru-The-Wall
Installation are provided, except a wood frame,
shims, and 10 wood screws (10-1” long minimum).
Select a wall surface that:
1. Does not support major structural loads such
as the frame construction at ends of windows,
and under truss-bearing points, etc.
2. Does not have plumbing or wiring inside.
3. Is near existing electrical outlets, or where
another outlet can or will be installed.
4. Does not have objects blocking the air vents
which limits cooling.
5. Allows unblocked airow from the rear and
sides of the air conditioner.
Prepare the Wall
1. Prepare the wall in frame construction
(including brick and stucco veneer). Working
from inside the room, nd the wall stud that is
nearest the center of the installation area.
2. Cut a hole on each side of the center stud.
3. Measure between the inside edges of every
other stud as shown below.
FIG.10
Carefully measure and cut an opening with the
following dimensions depending on your model.
WIDTH “X” = inside model plus twice the thickness
of the framing material used.
HEIGHT “Y” = inside model height plus twice the
thickness of framing material used.
Model 15K
Inside Frame Height 18 1/4” (46.4 cm)
Inside Frame Width 23 7/8” (60.6 cm)
Y
FIG.11
4. Build a wooden frame with the INSIDE
dimensions of your model listed above
(Measure twice). The frame depth should be
the same as the wall thickness. Fill in extra
space from the opening to the studs with
wood spacers as shown below.
Operating Instructions
Prepare the Wall (CONT.)
5. Nail the spacers to the studs. They should be
ush with the dry wall.
NOTE: If wall thickness is 6-1/2” or more, add
aluminum ashing over the bottom of the frame
opening to assure water is unable to enter the area
between the inner and outer wall.
Prepare and Install the Cabinet
1. Slide the chassis from the cabinet. Refer back
to the REMOVE CHASSIS instructions in the
WINDOW MOUNTING SECTION.
2. Place the cabinet into the opening with the
bottom rail resting nnly on the bottom board
of the wood frame.
3. Position the cabinet so it is tilted properly for
water removal as seen below.
FIG.12
4. Secure the bottom rail to the wood frame with
two large 1” (2.5 cm) long wood screws as
shown below.
FIG.13
Refer to the SUPPORT BRACKET ASSEMBLY in the
WINDOW MOUNTING section to assemble the
support brackets. A wooden ship nailed to the
outside well ahould be used in conjunction with
the angled sill support brackets.
FIG.14

20 21
Operating Instructions
Prepare and Install the Cabinet (CONT.)
5. Seal or nail the cabinet to the wooden
frame using shims if the frame is oversized,
to eliminate possible noise. Remember to
maintain proper slope for water elimination.
FIG.15
6. Install the chassis Into the cabinet by
following the steps described in the WINDOW
MOUNTING section.
OPTIONAL: Caulking end installation of the him on
the interior well may be done if desired. caulk the
openings around the top and sides of the cabinet
and all sides of the wood sleeve to the opening.
NOTE: See the WINDOW MOUNTING instructions for
the bottom rail seal location.
MASONRY CONSTRUCTION
1. Cut or build a wall opening in the masonry
wall similar to the frame construction (refer
to the THRU-THEWALL installation for a wall
thickness greater than 8 1/2”).
2. Secure the cabinet in piece using masonry
nails, or masonry anchor saws. Or, build a
frame using the instructions found in the
THRU-THE-WALL installation section.
3. Make sure the masonry above the cabinet is
supported well. Use the existing holes in the
cabinet or additional drilled holes to fasten the
cabinet at various positions. Make sure that
the side louvers are clear of any obstructions.
4. Install the exterior cabinet support brackets
according to the SUPPORT BRACKET
INSTALLATION instructions in the THRU-THE-
WALL installation section. Caulk or ash with
aluminum if needed. This will provide a tight
seal around the top and sides of the cabinet.
Operating Instructions
USING YOUR AIR CONDITIONER
Electronic Control Panel & Remote Control
NOTE:
This display always shows the room temperature in Fan Mode except when setting the Timer.
FILTER
SPEED
SLEEP
ECO
TIMER
MODE
POWER
AUTO
SPEED
AUTO
MODE
HIGH
MED
LOW
COOL
DRY
FAN
POWER
1
2
3
456789
Normal Operating Sounds
• You may hear some noise caused by water hitting the condenser, on rainy days, or when the humidity
is high. This design feature helps remove moisture and improve efciency.
• You may hear the thermostat click when the compressor cycles on and off.
• Water will collect in the base pan during rainy days or days of high humidity. Water may overow and
drip from the outside part of the unit.
• The fan may run even when the compressor is not on.
1. Digital Display: When the timer is not in use, the operation mode and the set temperature will be
displayed. Time will be displayed under the timer setting.
2. and Buon: Use these buttons on the control panel and remote to increase or decrease the
Set Temperature or Timer. Temperature range: 61°F~88°F or 16°C ~31°C.
3. Power Buon: Turn the air conditioner on or off.

22 23
Operating Instructions
USING YOUR AIR CONDITIONER (CONT.)
4. Mode Buon: Press the Mode button to cycle through the various modes: Cool, Dry, Fan and Auto.
Cool Mode: The cooling function allows the air conditioner to cool the room and at the same
time reduces air humidity. Press the MODE button to activate the cooling function. To optimize
the function of the air conditioner, adjust the temperature and the speed by pressing the button
indicated.
Dry Mode: This function reduces the humidity of the air to make the room more comfortable. Press
the MODE button to set the DRY mode. An automatic function of alternating cooling cycles and air
fan is activated. Dry mode only can be controlled on control panel.
Fan Mode: This function only works when the air conditioner is vented. Press the MODE button
to set the FAN mode. With pressing the FAN SPEED button, the speed changes in the following
sequence: Hi, Med and Lo in FAN mode.
Auto Mode: In AUTO mode the unit automatically chooses the mode of operation (COOL, DRY or FAN).
In this mode the temperature will be set according to the room temperature (tested by the temperature
sensor which is incorporated in the indoor unit.).
5. Timer Buon: Use these buttons on the control panel and remote to set the Timer.
Timer Off: The timed stop is programmed by pressing TIMER button. Set the time by pressing the
button “ ” or “ ” until your desired time is reached. Then press TIMER button again to conrm.
Timer On: When the unit is off, press TIMER button once. Set the temperature by pressing the
button “ ” or “ ”. Press TIMER button a second time, set the time by pressing the button
“” or “ ”. Press TIMER button a third time to conrm the setting.
Note: It can be set to automatically turn off or on in 0.5-24 hours. Each press of the “ ” “ ”
buttons will increase or decrease the timer in 0.5 hour increment below 10hours and 1 hour
increment for 10 hours or above. The SET light will turn on while setting.
To cancel the Timer function, press the TIMER button again.
6. Eco Buon: When the unit is in ECO mode, the light will turn on. In ECO mode, the unit will turn off
once the room is cooled to the set temperature. The fan will also be off at this point. The unit will
turn back on when the room temperature rises above the set temperature. Before the compressor
starts, the fan motor will turn on and off repeatedly to provide comfortable feeling and save energy.
7. Sleep Buon: Press the SLEEP button, all of the display lights will turn off after a while, leaving only
the Sleep light on. In SLEEP mode, the air conditioner will automatically adjust the temperature and
fan speed to make the room more comfortable during night. The set temperature will automatically
raise every 30-60 minutes, and at most change six times until the set temperature is 81°F or 82°F.
Set fan speed to low before turning on the SLEEP mode.
8. Speed Buon: Press the SPEED button for various fan speed options. You can choose Hi, Med, Lo or
Auto speed in COOL mode and choose Hi, Med, Lo in FAN mode.
9. Filter Buon: When the Filter Check light is off, it is not necessary to press the Filter Check button.
When the Filter Check light is on, turn off the light by pressing the Filter Check button. After the
working time of fan motor reaches 500 total hours, the Filter Check light will turn on to remind the
user to clean the lter.
10. Directional Louvers: To direct the airow, use the horizontal wheel to control the horizontal
direction, and the air deectors to control the vertical direction.
Operating Instructions
REMOTE CONTROL
Baery Size: AAA
NOTE: Do not mix old and new
batteries or different types of
AAA batteries.

24 25
Operating Instructions
REMOTE CONTROL (CONT.)
1. POWER: Turn the air conditioner on or off.
2. COOL: Press the COOL button to enter COOL mode.
3. and :Use these buttons on the control panel and remote to increase or decrease the Set
Temperature or Timer. Temperature range: 61°F-88°F or 16°C-31°C.
4. SLEEP: Press the SLEEP button, all of the display lights will turn off after a while with only the Sleep
light on. In SLEEP mode, the air conditioner will automatically adjust the temperature and fan speed
to make the room comfortable while you sleep. The set temperature will automatically rise every
30-60 minutes and at most change six times until the set temperature reaches 81°F or 82°F.
5. TIMER:
Timer Off: When the unit is on, press TIMER button to set timer off. Set the timer by pressing the
button “ ” or “ ” until your desired time is reached. Press TIMER button again to conrm.
Timer On: When the unit is off, press TIMER button once and set the temperature by pressing “ ”
or “ ”. Press TIMER button a second time, set the timer by pressing the button “ ” or “ ”.
Press TIMER button a third time to conrm the setting.
NOTE: It can be set to automatically turn off or on in 0.5-24 hours. Each press of the “ ” “ ”
buttons will increase or decrease the timer in 0.5 hour increment below 10hours and 1 hour
increment for 10 hours or above. The SET light will turn on while setting. To cancel the set function,
press the TIMER button again.
6. AUTO MODE: In AUTO mode the unit automatically chooses the mode of operation (COOL, DRY or
FAN). In this mode the temperature will be set automatically according to the room temperature
(tested by the temperature sensor which is incorporated in the indoor unit.).
7. SPEED: Press the SPEED button for various fan speed options. You can choose Hi, Med, Lo or auto
speed in COOL mode and choose Hi, Med, Lo in FAN mode.
8. DISPLAY: Press the DISPLAY button to switch off/on all lights or LED display.
9. ECO: When the unit is in ECO mode, the light will turn on. In ECO mode, the unit will turn off once
the room is cooled to the set temperature. The unit will turn back on when the room temperature
rises above the set temperature. Before the compressor starts, the fan motor will turn on and off
repeatedly to provide comfortable feeling and save energy.
10. FAN ONLY: Press the FAN ONLY button if you need Fan Only mode.
Cleaning and Maintenance
Clean your air conditioner to keep it looking new and to minimize dust build-up.
AIR FILTER CLEANING
The air lter should be checked at least once every month to see if it needs cleaning. Trapped particles
and dust can build up in the lter and may decrease airow as well as cause the cooling coils to
accumulate frost. To clean the air lter:
1. Remove the lter by pulling down on the indents of the
lter door on the front of the unit. (See FIG. 16)
2. Wash the lter using liquid dish soap and warm water.
Rinse the lter thoroughly. Gently shake the lter to
remove excess water.
3. Let the lter dry completely before placing it into the
air conditioner.
4. If you do not wish to wash the lter, you may vacuum
the lter to remove the dust and other particles.
WEAR AND TEAR
To minimize wear and tear on the air conditioner, always wait at least 3 minutes before changing modes.
This will help prevent the compressor from overheating and the circuit breaker from tripping.
CABINET CLEANING
To clean the air conditioner cabinet:
• Unplug the air conditioner to prevent shock or a re hazard. The cabinet and front panel of the air
conditioner may be dusted with an oil free cloth or washed with a cloth dampened in a solution of
warm water and mild liquid soap. Rinse thoroughly with a damp cloth and wipe dry.
• Never use harsh cleaners, wax or polish on the cabinet front.
• Be sure to wring excess water from the cloth before wiping around the controls. Excess water in or
around the controls may cause damage to the air conditioner.
WINTER STORAGE
To store the air conditioner when it is not in use for an extended period of time, remove it carefully
from the window according to the installation instructions and cover it with plastic or place it in the
original box.
FIG. 15
FIG.16
A. Indents

26 27
Troubleshooting
PROBLEMS POSSIBLE CAUSES SOLUTIONS
The Air Conditioner
will not start
The air conditioner is
unplugged
• Make sure the air conditioner plug is pushed
completely into the outlet
The fuse is blown/circuit
breaker is tripped
• Check the house fuse/circuit breaker box and
replace the fuse or reset the breaker
Power failure • The unit will automatically restart when
power is restored
• There is a protective time delay (approx.
3 minutes) to prevent tripping of the
compressor overload. For this reason, the unit
may not start normal cooling for 3 minutes
after it is turned back on.
The current interrupter
device is tripped
• Press the RESET button located on the power
cord plug
• If the RESET button will not stay engaged,
discontinue use of the air conditioner and
contact a qualied service technician
The Air Conditioner
does not cool as it
should
Airow is restricted • Make sure there are no curtains, blinds, or
furniture blocking the front of the air conditioner
The temperature control may
not be set correctly
• Lower the set thermostat temperature
The air lter is dirty • Clean the lter. See the Cleaning and Care
Section of the manual
The room may be too warm • Please allow time for the room to cool down
after turning on the air conditioner
Cold air is escaping • Check for open furnace registers and cold air
returns
The cooling coils are frozen • See “Air Conditioner is freezing up” below
The Air Conditioner is
freezing up
Ice blocks the air ow and
stops the air conditioner
from cooling the room
• Set the MODE dial to HIGH FAN or HIGH
COOL and set the thermostat to a higher
temperature
The Remote Control is
not working
The batteries are inserted
incorrectly
The batteries may have run
out
• Check the position of the batteries
• Replace the batteries
Water is dripping
outside
Hot and Humid weather • This is normal
Water is dripping
inside the room
The air conditioner is not
correctly tilted outside
• For proper water drainage, make sure the air
conditioner is slightly tilted downward from
the front of the unit to the rear
Water collects in the
base pan
Moisture removed from the
air is draining into the base
pan
• This is normal for a short period in areas with
low humidity and normal for a longer period
in areas with high humidity
Digital Display reads
“E1”, “E2”
A sensor has failed • Contact customer service
hOme™offers a limited two-year warranty (“warranty period”) on all of our products purchased new
and unused from hOme Technologies, LLC or an authorized reseller, with an original proof of purchase
and where a defect has arisen, wholly or substantially, as a result of faulty manufacture, parts or
workmanship during the warranty period. The warranty does not apply where damage is caused by
other factors, including without limitation: (a) normal wear and tear; (b) abuse, mishandling, accident,
or failure to follow operating instructions; (c) exposure to liquid or inltration of foreign particles; (d)
servicing or modications of the product other than by hOme™ ; (e) commercial or non-household use.
The hOme™ warranty covers all costs related to restoring the proven defective product through repair or
replacement of any defective part and necessary labor so that it conforms to its original specications.
A replacement product may be provided instead of repairing a defective product. hOme™ ’s exclusive
obligation under this warranty is limited to such repair or replacement.
A receipt indicating the purchase date is required for any claim, so please keep all receipts in a safe
place. We recommend that you register your product on our website, homelabs.com/reg. Although
greatly appreciated, the product registration is not required to activate any warranty and product
registration does not eliminate the need for the original proof of purchase. The warranty becomes
void if attempts at repair are made by non-authorized third parties and/or if spare parts, other than
those provided by hOme™ , are used. You may also arrange for service after the warranty expires at an
additional cost.
These are our general terms for warranty service, but we always urge our customers to reach out to
us with any issue, regardless of warranty terms. If you have an issue with a hOme™ product, please
contact us at 1-800-898-3002, and we will do our best to resolve it for you.
This warranty gives you specic legal rights, and you may have other legal rights which vary from state
to state, country to country or province to province. The customer may assert any such rights at their
sole discretion.
HME030343N
Warranty
Manufacturing Info
This manual is to be used with all items with the model number
SKU# : HME030343N
Rated voltage/Frequency: 115V~ 60Hz 11.0A
Keep all plastic bags away from children.
Warning
Contact Us
homelabs.com/chat
Mon–Fri 10AM–5PM EST
1-(800)-898-3002
Mon–Fri 10AM–5PM EST
[email protected]
Respond within twelve hours
CHAT W ITH US CALL U S EMAIL US

© 2016 hOme Technologies, LLC
37 East 18 Street, 7th Floor
New York, NY 10003
For household
Use Only
1-800-898-3002
[email protected]
homelabs.com/help
All rights reserved, hOme®. Printed in China.
