HoMedics ELLE MACPHERSON THE BODY User manual

By
IPL-100-GB
IPL Hair Reduction Device
2 Year Guarantee
Instruction Manual
IB-IPL100GB-0313-01_Layout 1 18/06/2013 15:01 Page 1

2
GB
QUICK START GUIDE
What is IPL?
IPL is a home-use for the permanent reduction of hair growth based on Intense Pulsed Light (IPL) technology
that is found in salons across the globe. It is a non-invasive device which works below the skin's surface and
therefore does not involve any cutting or pulling, reducing hair growth with minimal pain!
Please read all instructions and safety precautions carefully prior to use.
• IPL should ideally be used on the legs, underarms, bikini line, chest, stomach, arms and on the face below
the check bones (not for use on the face by men).
• Do not use the IPL over mucous membranes i.e nose and ears.
• Do not use IPL over piercing or any metal items such as earrings or jewelry.
• Do not use IPL on tanned skin during 4 weeks after sun exposure (more than 15 minutes in direct sunlight
without protection) as this can cause serious burns or skin injury.
• Avoid more than 15 minutes of direct sun exposure for at least 2 weeks post treatment. If recently treated
skin is exposed to sunlight in this period of time, make sure to apply SPF 30 or higher sunscreens.
• Do a spot test on a small patch of skin in the intended treatment area, 48 hours prior to first use of the IPL
(see spot test chapter).
• Do not use IPL on naturally dark skin (see guide on box and on page 10).
• Keep out of children's reach.
• The IPL is to be used for hair reduction purposes only. Do not use it for any other purpose.
• Use the IPL only according to the instructions for use.
IPL set-up
1. Remove all components from the box (base unit, applicator and power cord).
2. Make sure the replaceable lamp cartridge is placed correctly into the applicator.
3. Plug the power cord to the IPL base unit.
4. Only after plugging the power cord to the base unit, plug the other end of the power cord into the
electrical outlet.
Using the IPL for the first time
1. Prior to use, make sure your skin is shaved, clean and dry (free of any residue such as powders, creams,
makeup, antiperspirants or deodorants).
Warning! NEVER use flammable liquids such as alcohol or acetone to clean the skin before using the IPL.
2. When switching on the device always use the black switch by the power socket on the side of the device,
this will turn the device on. The standby button on top of the device can be used to turn off the product
after use.
3. The device sets itself on the lowest energy level. Use the energy level “-” and “+” buttons to decrease or
increase the energy level to reach the level determined in the spot test and according to your convenience.
The energy level lights will light up green according to the selected step.
4. Place the applicator treatment window on the required treatment area with full contact to the skin (the
applicator will not trigger a pulse if there is no full skin contact).
5. Once the applicator is correctly placed, Press the trigger button. You will see a bright flash, hear a popping
noise and you may feel a mild stinging or/and heat sensation. Within 3 seconds the device will be ready for
the next pulse and the indicator light on the applicator will be solid green.
6. Remove the applicator from the skin and place it on the next spot of the treated area. When replacing the
applicator, make sure there are no gaps or overlaps in the treated area.
7. Repeat steps 5 and 6 until all the chosen area has been treated.
NB: If the device is left on but not used for 5 minutes it will automatically switch itself off. If this has
happened, press the black button next to the power cord socket to turn the device back on.
IB-IPL100GB-0313-01_Layout 1 18/06/2013 15:01 Page 2

3
GB
WARNINGS AND SAFETY PRECAUTIONS
When shouldn’t IPL be used?
• Pregnant or nursing women must avoid the use of the IPL.
• Do not use the device if you have skin cancer or on areas at risk of malignancy.
• Do not use the IPL if you suffer from epilepsy.
• Do not use the IPL if you are/were under radiation therapy or chemotherapy within the past 3 months.
• Do not use the IPL if you have an active implant such as a pacemaker, insulin pumps, or similar devices.
• Do not use on damaged or broken skin or if you have a history of erpes or Psoriasis outbreak in the
treatment area.
• Do not use if you suffer from kelodial scar formation.
• Do not use if you have taken Tetracycline antibiotics within the last two weeks.
• Do not use if you have been taking medication with the following active ingredients within the last two
weeks: Retinoids, Accutane and Retin-A.
• Do not use the IPL if you are photosensitive or have other diseases related to light sensitivity.
• Do not use if you suffer from metabolic conditions, such as diabetes.
• Do not use if you have had a skin peel or other skin resurfacing procedure within the last 6 – 8 weeks.
• Do not use the IPL if you were exposed to strong sunlight or an artificial tanning machine during the past
30 days.
• Do not use the IPL if you have dark spots such as large freckles, moles or blisters on the treatment area.
• NEVER use flammable liquids such as alcohol or acetone to clean the skin before using IPL.
• Do not use the IPL on the face above the cheek line; around the eyes, eyebrows or eyelashes as this could
cause serious eye damage.
• Do not use the IPL over mucous membranes as in the nose and ears
• Do not use IPL over piercing or any metal items such as earrings or jewelry.
• The IPL s should not be used on tattoos, permanent make up and intimate body parts such as nipples,
genitalia or around the anus.
• If you see extreme redness of the skin, blistering, or burns STOP USE IMMEDIATELY!
• Do not leave the device unattended when plugged into an electrical outlet.
• Do not look directly at the light coming from the applicator and the lamp cartridge.
• Do not use the device for any purpose other than hair reduction.
• Use of the IPL may cause temporary skin color changes.
• Do not open or repair the device as it contains dangerous electrical components which may cause physical
damage.
• Do not use the IPL with any additional accessories that are not part of its intended use.
CAUTION:
• This appliance is not intended for use by persons with reduced physical, sensory or mental capabilities
unless they have been instructed by a person responsible for their safety, according to the instructions for
use.
• KEEP OUT OF CHILDREN'S REACH.
Warning!
Do not use this appliance near bathtubs, showers, basins or other vessels containing water.
IB-IPL100GB-0313-01_Layout 1 18/06/2013 15:01 Page 3

4
GB
BASE UNIT
Main power button
Standby button
Energy level selection button – Press "-" or "+" to select energy level
6 Energy levels lights – Light up green when energy level is selected
Replace cartridge light – will stay on when the cartridge needs replacing
Two trigger buttons (flash pulse activation) are located on each side of the applicator hand piece (see
diagram on right). Either one of the trigger buttons will activate the flash lamp. The two buttons are
implemented for right and left handed convenience only.
The replaceable lamp cartridge is located inside the applicator's inner body.
The indicator light is located in the top middle of the applicator head and lights green/red as follows:
No light - Pulse is not ready.
Green light on – Pulse is ready.
Red light on – Pulse is blocked due to lack of full skin contact and/or incompatible skin tone (high Fitzpatrick
level see user instruction section on page 10).
Red LED on applicator comes on and the device switches itself off – Cartridge is not properly connected
when the device is turned on.
PARTS IDENTIFICATION
The IPL consists of the following main components: Base unit, applicator and AC cord.
BASE UNIT AND APPLICATOR
Standby Button
Main Power Button
Trigger Button
Treatment area
Indicator Light
Energy Level
Selection Buttons
Replace
Cartridge Light
6 Energy Level
Lights
APPLICATOR
IB-IPL100GB-0313-01_Layout 1 18/06/2013 15:01 Page 4

5
GB
REPLACEABLE CARTRIDGE
FACIAL ADAPTOR
PRIOR TO USE
Instructions and Safety Precautions – please read carefully prior to use
• Do not use IPL on tanned skin, during 4 weeks after sun exposure (more than 15 minutes in direct sunlight
without any protection) as this can cause serious burns or skin injury. Treating skin that has recently been
exposed to sunlight can result in adverse effects such as burns, blisters and skin color changes (hyper- or
hypo-pigmentation).
Remember: The IPL comes with a built-in skin tone sensor that is designed to measure the skin type of the
applied surface and enable application only on suitable skin type. This unique safety feature will not let you
treat areas where your skin is too dark or too tanned, even if your general skin type is lighter.
• Avoid more than 15 minutes of direct sun exposure for at least 2 weeks post treatment. If recently treated
skin is exposed to sunlight in this time period, make sure to apply SPF 30 or higher sunscreen.
• Do a spot test on a small patch of skin in the intended treatment area, 48 hours prior to first use of the IPL
to determine energy level settings for your treatment (see spot test chapter).
• Do not use the IPL on the face above the cheek line; around the eyes, eyebrows or eyelashes as this could
cause serious eye damage.
Note: using IPL to remove facial hair may take more treatments.
• Do not use the IPL over mucous membranes i.e nose and ears.
• Do not treat over piercing or any metal items such as earrings or jewelry.
• Do not treat the same area of skin more than once per treatment.
• If your skin blisters or burns, stop use immediately.
• Never look directly at the light coming from the IPL.
• IPL may cause temporary pigmentation changes.
• Device should never be left unattended while plugged into the electricity.
• Keep the device away from water – do not use while bathing.
• Do not use the device if:
- the cord or plug are damaged
- you see or smell smoke
- the device is not working properly, appears damaged or broken
- the outer shell is damaged or loose
- lamp cartridge or treatment window are damaged/ missing
- becomes damp or wet
Treatment window
Applicator ead Front Cover
Optical Skin Tone Sensor
Opening for
treatment window
Lamp
Opening for optical
skin tone sensor
IB-IPL100GB-0313-01_Layout 1 18/06/2013 15:01 Page 5

6
GB
Recommended treatment protocol:
For body treatment
• The first 1-4 hair reduction sessions should be approximately two weeks apart.
• Sessions 5-7 should be approximately four weeks apart.
• Thereafter the IPL should be used again when needed until the required long term results are achieved.
• Due to hormonal or other physiological changes dormant hair follicles may become active and new hairs
can appear – maintenance hair reduction sessions may be required from time to time.
Note: treating the same area more than once in two weeks is not effective.
For facial treatment
• The first 1-6 hair reduction sessions should be approximately two weeks apart.
• Sessions 7-12 should be approximately four weeks apart.
• Thereafter the IPL should be used again when needed until the required long term results are achieved.
• Due to hormonal or other physiological changes dormant hair follicles may become active and new hairs
can appear – maintenance hair reduction sessions may be required from time to time.
Note: treating the same area more than once in two weeks is not effective.
What to expect when using the IPL
• A flash of light – will not harm the eyes when the applicator is applied with full contact to the skin, on the
recommended treatment areas.
• Fan noise – Lower than that of a hair dryer.
• A pop noise with each pulse – whenever a pulse is activated.
• A sensation of warmth – from the light energy after each pulse.
• A mild stinging sensation - similar to that of being snapped with a rubber band.
• Some mild red or pink color – during and just after use of the IPL.
Minor Side- Effects
Irritation
Redness
Sun Sensitivity
Rare Side- Effects
Burns
Scarring
Pigment Changes
Excessive Redness
Swelling
Extremely Rare Side- Effects Infection
Bruising
POSSIBLE SIDE EFFECTS
When using the IPL according to the instructions for use, side effects are rare. owever, every cosmetic
procedure including the usage of home use devices may cause some degree of side effects:
IB-IPL100GB-0313-01_Layout 1 18/06/2013 15:01 Page 6

7
GB
SPOT TEST
The spot test is intended to determine your skins reaction to the IPL treatment and help you set the optimal
energy level for each treatment area.
Do a spot test on each area you intend to treat 48 hours prior to the full treatment.
Note: For facial area treatments the test should be done in a hair-free area such as below the ear or the side of
the neck.
1. Prior to use, make sure your skin is shaved, clean and dry (free of any residue such as powders, creams,
makeup, antiperspirants or deodorants).
Warning! NEVER use flammable liquids such as alcohol or acetone to clean the skin before using the IPL.
2. Set up the IPL as per user instructions 2 to 5 (see page 8).
3. Place the applicator treatment window on the required test area with full contact to the skin.
4. The device sets itself on the lowest energy level. Deliver the first pulse, on energy level 1, by pressing the
trigger button. You will see a bright flash, hear a popping noise and you may feel a mild stinging or/and
heat sensation. Within 3 seconds the device will be ready for the next pulse and the indicator light on the
applicator will be solid green.
5. Remove the applicator from the skin and place it on the next spot of the test area.
6. Use the energy “+” button to increase the energy level by 1. The energy level lights will light up green
according to the selected energy level. Deliver the second pulse, on energy level 2, by pressing the trigger
button.
7. Only if you feel comfortable repeat steps 5 to 6 until you have reached the maximum energy Level of 6.
Stop the test once you do not feel comfortable, increasing the energy level increases the risk of adverse
effects.
If you see adverse effects such as severe redness or blistering stop the test immediately.
8. Wait 48 hours and examine the tested area.
If the skin in the test area seems normal (no response or milled redness) you can proceed with a full
treatment in the highest comfortable energy level you tested.
If you see extreme redness, swelling or blistering, even in the low energy level settings do not do the full
treatment in that area.
Note: Do not treat full areas in energy levels you have not tested before!
Do not treat the tested area for at least 1 week after the spot test is done.
IB-IPL100GB-0313-01_Layout 1 18/06/2013 15:01 Page 7

USER INSTRUCTIONS
How to Use (Body treatment)
1. Prior to use, make sure your skin is shaved, clean and dry (free of any residue such as powders, creams,
antiperspirants or deodorants).
Warning! NEVER use flammable liquids such as alcohol or acetone to clean the skin before using the IPL.
2. Make sure that the replaceable lamp cartridge is placed correctly into the applicator.
3. Plug the power cord to the IPL base unit.
4. Only after plugging the power cord to the base unit, Plug the other end of the power cord to the electrical
outlet.
The IPL is now ready to be used.
5. When switching on the device always use the black switch by the power socket on the side of the device,
this will turn the device on. The standby button on top of the device can be used to turn off the product
after use.
6. The device sets itself on the lowest energy level. Use the energy level “-” and “+” buttons to decrease or
increase the energy level to reach the level determined in the spot test and according to your convenience.
The energy level lights will light up green according to the selected energy level.
7. Place the applicator treatment window on the required treatment area with full contact to the skin. If the
applicator is not properly applied or your skin tone is too dark/tanned the indicator light on the applicator
will be solid red. In this case the IPL will not trigger a pulse in that area of skin.
8. Press the trigger button (left or right for your convenience, there is no need to press the left and right
trigger buttons simultaneously). You will see a bright flash, hear a popping noise and you may feel a mild
stinging or/and heat sensation.
9. Remove the applicator from the skin and place it on the next spot of the treated area. When replacing the
applicator ensure there are no gaps or overlaps of treated skin. The device will immediately recharge and
will be ready for the next pulse (the indicator light on the applicator will be solid green again) within 3
seconds. Repeat process until the entire treatment area has been covered.
10.Turn off the device and then unplug unit upon each treatment session.
NB: If the device is left on but not used for 5 minutes it will automatically switch itself off. If this has
happened, press the black button next to the power cord socket to turn the device back on.
Facial treatment
The facial skin is a sensitive area that requires special care and caution. Make sure you follow all instructions
and safety precautions carefully in order to avoid adverse effects.
The product includes a facial adaptor in the box, it is recommended that you use this when performing facial
treatment as it focusses the IPL energy on a smaller area.
As the acial adaptor ocusses the energy onto a smaller area, it is important not to exceed energy level 3
or acial treatment. Start the treatment on level 1 and increase only i the treatment is com ortable.
Treating on an energy level higher than 3 may burn the skin.
Fitting the facial adaptor
The facial adaptor simply clicks into place covering part of the
treatment window. When fitting the facial adaptor, take care to
line up the optical skin tone sensor with the appropriate part of
the adaptor. To remove after completing facial treatment, apply
upward pressure on the edge of the facial adaptor that is the
same side as the optical skin tone sensor so that it unclicks and
pulls away from the applicator.
It is recommended you first do a body treatment and get to
know the device, before moving on to facial treatments.
The IPL can be used to treat all facial areas below the check line
such as Upper lip, cheek, jaw, chin and neck.
8
GB
Opening for optical
skin tone sensor
IB-IPL100GB-0313-01_Layout 1 18/06/2013 15:01 Page 8

Warning!
Do not use the IPL on the face above the cheek line or around the eyes, eyebrows and
eyelashes as this could cause serious eye damage.
Do not use the IPL over mucous membranes as in the nose and ears
1) Make sure you do a Spot Test 48 hours prior to treatment. The Spot test should be
done in a hair-free area such as below the ear or the side of the neck to determine the
energy level.
Warning! Do not treat the tested area for at least 1 week after the spot test is done
2) Mark the treatment area with a white eye pencil. Use the mark as guidance for
delivering the pluses. In this way you can avoid overlapping treatment areas or
treating unwanted facial areas.
3) Use a mirror to help you place the applicator correctly on the treatment area.
4) Follow the instructions for use (see previous chapter #) with additional care to the
following specific area instructions.
Note: Facial air may be hormonal and as such, it can take more sessions to achieve a
permanent hair reduction.
Upper Lip Treatment
Place the Applicator treatment area as indicated in the picture. Trigger one pulse in each
marked area.
Avoid the nostrils and lip, as these areas are more sensitive.
You can “fold” your lip inward or press the lips together to achieve a better spread
treatment area.
Cheek and Jaw treatment
Place the Applicator treatment area as indicated in the picture. Trigger one pulse on
each spot, moving from one side of the jaw/cheek to the other.
Neck and chin treatments
Place the Applicator treatment area as indicated in the picture. Trigger one pulse on
each spot, moving from one side of the neck/chin to the other.
Note: The skin on lower third of the neck is more sensitive, avoid overlapping
treatment areas.
For Male users
It is not recommend to use the product for facial treatment as this may change the facial characteristics and
result in a feminine look.
Note: Premature ageing characteristics can emerge due to complete loss of facial hair of men.
Post treatment care for facial treatment
Apply a calming lotion such as Aloe Vera.
Avoid using peeling and bleaching creams or products for at least 24 hours as this irritates the treated skin.
Avoid more than 15 minutes of direct sun exposure for at least 2 weeks post treatment. If recently treated
skin is exposed to sunlight in this time period, make sure to apply SPF 30 or higher sunscreen.
Do not wax or pluck hairs from treated areas.
Remember! It may take up to 2 weeks for the hair to grow and fall out.
9
GB
IB-IPL100GB-0313-01_Layout 1 18/06/2013 15:01 Page 9

10
GB
CLEANING/MAINTENANCE/TROUBLES OOTING
Long Term Hair Reduction – Hair Growth Cycle
Two factors play an important role in optimal long-term hair reduction:
• air growth cycle (Anagen, Catagen and Telogen). Anagen is the growth phase while Catagen and Telogen
are the resting phases. Permanent hair reduction can only occur during the Anagen phase.
• Skin type (according to Fitzpatrick scale). Darker skin contains more melanin, which competes with the
targeted hair for energy light absorption. When more light energy is absorbed in the skin there is more risk
of adverse effects and the epidermis may get damaged.
Estimated Treatment protocol for Hair Reduction
✓✓✓ ✓
Do not use the IPL on naturally dark skin types
Note: Response to IPL hair reduction differs between individuals depending on biological factors.
Hair Color Fitzpatrick
Skin Level Energy Levels Treatment Area Average Number o Treatments
Treatment
Interval
Light Brown to
Brown 1-4 Inclusive 1-6
Legs
10-12 The 1-4
treatments will be
approximately
two weeks apart,
followed by four
weeks’ time
intervals
Arms
Underarms
Bikini Lines
Brown to Black 1-4 Inclusive 1-6
Legs
8-10
Arms
Underarms
Bikini Lines
Light Brown to
Brown
1-4 Inclusive 1-6
Facial treatment:
upper lip,
cheek, jaw.
Chin and neck
10-12 The 1-6
treatments will be
approximately
two weeks apart,
followed by four
weeks’ time
intervals
Brown to Black 8-10
12 3 4 5 6
IB-IPL100GB-0313-01_Layout 1 18/06/2013 15:01 Page 10
