Homelite UT09002 Configuration guide

UT09002 26CC Blower Page 1 of 2
General Assembly
For Homelite Discount Parts Call 606-678-9623 or 606-561-4983
www.mymowerparts.com

UT09002 26CC Blower Page 2 of 2
General Assembly
Ref # Part Number Qty DescriptionS/P/F
1 660621001 Screw (10-14 x 1/2 in.)1 S
2 518537001 Handle1
3 308902018 Power Head and Fuel Tank Assembly1
4 660970002 Screw (M4 x 10 mm)3
5 580800001 Fuel Tank1
6 308682003 Fuel Tank Assembly1
7 308680001 Fuel Cap1
8 308675003 Fuel Tank and Cap Assembly1
9 940747003 Logo Label1
10 308844001 26cc Power Head Assembly1
11 940647043 Choke Label1
12 638091005 Crankshaft Spacer1
13 940477002 Starting Label1
14 518538001 Top Volute1
15 518540001 Upper Nozzle1
16 660674001 Screw (10-14 x 7/8 in.)4 S
17 660970004 Screw (M4)1
18 678126005 Washer1
19 518265002 Fan1
20 650016001 Washer1 /P
21 660730001 Nut (3/8-24)1 S
22 518539001 Bottom Volute1
23 660629001 Screw (10-14 x 3/4 in.)9 S
24 518543001 Volute Plate1
25 870174001 Spark Plug (Champion RCJ6Y) Purchase
Locally
1 /P
26 940734065 Safety Icon Strip1
987000831 Operator’s Manual1
