Homelite HOMCS01 User manual

TABLE OF CONTENTS
General Power Tool Safety
Warnings ......................................... 2-3
Pruning Saw Safety Warnings ........ 3-6
Symbols .......................................... 6-7
Glossary of Terms ...............................8
Features ..............................................9
Assembly ............................................9
Operation .................................... 10-12
Maintenance ............................... 13-16
Bar and Chain Combinations............17
Troubleshooting ................................17
Parts Ordering/Service........ Back Page
TABLE DES MATIÈRES
Avertissements règles de sécurité
relatives aux outils électriques........ 2-3
Avertissements de sécurité relatifs
scie à élagage ................................. 3-6
Symboles ........................................ 7-8
Glossaire .............................................9
Caractéristiques................................10
Assemblage ......................................10
Utilisation .................................... 11-13
Entretien...................................... 14-18
Combinaisons de guide et chaîne ....18
Dépannage........................................18
Commande de pièces/
réparation.......................... Páge arrière
ÍNDICE DE CONTENIDO
Advertencias de seguridad
para herramientas eléctricas........... 2-3
Advertencias de seguridad de la sierra
de poda........................................... 4-7
Símbolos ......................................... 7-8
Glosario de términos...........................9
Características ....................................9
Armado .............................................10
Funcionamiento .......................... 10-13
Mantenimiento ............................ 13-17
Combinaciones de barra y cadena...18
Correción de problemas ...................18
Pedidos de piezas/
servicio........................... Pág. posterior
OPERATOR’S MANUAL
MANUEL D’UTILISATION
MANUAL DEL OPERADOR
12V PRUNING SAW
SCIE À ÉLAGAGE DE 12 V
SIERRA DE PODA DE 12 V
HOMCS01
WARNING: To reduce the risk of
injury, theusermustread andunderstand
the operator’s manual before using this
product.
AVERTISSEMENT : Pour
réduire les risques de blessures,
l’utilisateur doit lire et veiller à bien
comprendrelemanuel d’utilisation avant
d’employer ce produit.
ADVERTENCIA: Parareducirel
riesgo de lesiones, el usuario debe leer
y comprender el manual del operador
antes de usar este producto.
SAVE THIS MANUAL FOR
FUTURE REFERENCE GUARDE ESTE MANUAL PARA FUTURAS CONSULTAS
CONSERVER CE MANUEL
POUR FUTURE RÉFÉRENCE

ii
Fig. 1
See this fold-out section for all of the figures referenced
in the operator’s manual.
Consulter l’encart à volets afin d’examiner toutes les figures
mentionnées dans le manuel d’utilisation.
Consulte esta sección desplegable para ver todas las figuras a
las que se hace referencia en el manual del operador.
A - Charging port (prise de charge, puerto de carga)
B - Switch trigger (gâchette de commutateur, gatillo interruptor)
C - Rear handle (poignée arrière, mango trasero)
D - Lock-out button (bouton de verrouillage, botón de bloqueo)
E - Front hand grip (prise avant, empuñadura delantera)
F - Chain cover lock knob (couvercle de chaîne de bouton de verrouillage,
perilla de fijación de la cobertura de la cadena)
G - Chain tension adjustment ring (anneau de réglage de tension de la
chaîne, anillo de ajuste de la tensión de la cadena)
D
A
L
F
K
G
I
J
C
E
H
B
H - Front chain guard (couvercle de chaîne avant, protector de cadena
delantero)
I - Chain (chaîne, cadena)
J - Scabbard (fourreau, funda)
K - Guide bar (guide de chaîne, barra guía)
L - LED indicator (témoin de DEL, luz indicadora de LED)

iii
INCORRECT
INCORRECTE
INCORRECTO
Fig. 5
Fig. 6
Fig. 2
Fig. 3
A - Chain line (ligne de chaîne, plano de la
cadena)
B - Straight arm position (bras tendu, posición
con el brazo recto)
Fig. 9
Fig. 10
Fig. 8
ROTATIONAL KICKBACK
REBOND ROTATIF
CONTRAGOLPE ROTATORIO
KICKBACK DANGER ZONE
ZONE DE DANGER DE REBOND
ZONA DE PELIGRO DE CONTRAGOLPE
PULL
TIRAGE
TIRÓN
Fig. 4
Fig. 7
CHAIN LINE
LIGNE DE CHAÎNE
PLANO DE LA CADENA
B
A
CORRECT
CORRECT
CORRECTO
Fig. 11
CUT LIMBS ONE AT A TIME AND LEAVE
SUPPORT LIMBS UNDER TREE UNTIL
LOG IS CUT
COUPER LES BRANCHES UNE À UNE ET
LAISSER CELLES SOUTENANT LE TRONC
JUSQU’À CE QU CELUI-CI SOIT DÉBITÉ
CORTE UNA RAMA A LA VEZ Y DEJE
RAMAS DE SOPORTE BAJO EL ÁRBOL
HASTA QUE ESTÉ CORTADO EL TRONCO
4
12
3
A - Load (charge, carga)
B - Finishing cut (clou de finition, corte final)
Fig. 12
A
B
A
C
B
A - LED indicator (témoin de DEL, luz indicadora
de LED)
B - Charge port (port du bloc-piles, puerto de
batería)
C - Charging port (prise de charge, puerto de
carga)
B
A
A - Lock-out button (bouton de verrouillage,
botón de bloqueo)
B - Switch trigger (gâchette de commutateur,
gatillo interruptor)
B
A

iv
A - Sprocket (pignon, rueda dentada)
B - Guide bar (guide de chaîne, barra guía)
C - Chain (chaîne, cadena)
D - Chain cover lock knob (couvercle de chaîne
de bouton de verrouillage, perilla de fijación
de la cobertura de la cadena)
Fig. 13
E
D
C
I
J
B
A
F
Fig. 15
Fig. 14 Fig. 16
A - Chain drive links (maillons d’entraînement,
eslabones de impulsión de la cadena)
B - Bar groove (rainure du guide, ranura de la
barra)
LIFT THE TIP OF THE GUIDE BAR UP TO
CHECK FOR SAG
RELEVER L’EXTRÉMITÉ DU GUIDE POUR
VÉRIFIER LE MOU
LEVANTE LA PUNTA DE LA BARRA
GUÍA PARA REVISAR LA HOLGURA
DE LA CADENA
A - Chain tension adjustment ring (anneau de
réglage de tension de la chaîne, anillo de
ajuste de la tensión de la cadena)
B - To loosen (pour desserrer, para aflojar)
C - To tighten (pour serrer, para ajustarlos)
A
B
A
C
A - Top plate (plaque supérieure, placa superior)
B - Cutting corner (coupe de coin, esquina de
corte)
C - Side plate (plaque latérale, placa lateral)
D - Depth gauge (limiteur de profondeur, calibre
de profundidad
E - Toe (sabot, puntera)
F - Gullet (creux, garganta)
G - Heel (talon, talón)
H - Rivet hole (trou de rivet, orificio del remache)
Fig. 20
Fig. 19
Fig. 21
APPROX. .050 IN.
ENVIRON 1,25 MM (0,050 PO)
APROX. 1,25 MM (0,050 PULG. )
A - Chain cover lock knob (couvercle de chaîne
de bouton de verrouillage, perilla de fijación
de la cobertura de la cadena)
B- To loosen (pour desserrer, para aflojar)
C - To tighten (pour serrer, para ajustarlos)
A
C
A - Flats on tie straps (parties plates sur les liens
de traverse, partes planas de los amarres)
A
ABC
D
E
F
G
H
A - Chain tension assembly (assemblage du
tendeur de chaîne, conjunto de tensión de la
cadena)
B - To loosen (pour desserrer, para aflojar)
C - To tighten (pour serrer, para ajustarlos)
A
C
B
Fig. 17
B
B
Fig. 18
GH
E - Chain cover (carter de la chaîne, tapa de la
cadena)
F - Bar mount stud (goujon de fixation de la
barre, perno de montaje de barra)
G - Chain catcher (attrape-chaîne, sostén de la
cadena)
H - Locating hole (trou de repère, orificio de
localización)
I - Chain tension assembly (assemblage du
tendeur de chaîne, conjunto de tensión de la
cadena)
J - Screw (vis, tornillo)

v
Fig. 22 Fig. 25
Fig. 26
Fig. 23
Fig. 24
INCORRECT TOP PLATE FILING ANGLE
ANGLE D’AFFÛTAGE DE LA PLAQUE
SUPÉRIEURE INCORRECT
ÁNGULO INCORRECTO DE LIMADURA DE
LA PLACA SUPERIOR
MORE THAN 30°
PLUS DE 30°
MÁS DE 30°
LESS THAN 30°
MOINS DE 30°
MENOS DE 30°
30°
CORRECT TOP PLATE FILING ANGLE
ANGLE D’AFFÛTAGE DE LA PLAQUE
SUPÉRIEURE CORRECT
ÁNGULO CORRECTO DE LIMADURA DE
LA PLACA SUPERIOR
INCORRECT SIDE PLATE FILING ANGLE
ANGLE D’AFFÛTAGE DE LA PLAQUE
LATÉRALE INCORRECT
ÁNGULO INCORRECTO DE LIMADURA DE
LA PLACA LATERAL
BACKWARD
SLOPE
ANGLE ARRIÈRE
PENDIENTE
HACIA ATRÁS
HOOK
CROCHET
GANCHO
80°
CORRECT SIDE PLATE FILING ANGLE
ANGLE D’AFFÛTAGE DE LA PLAQUE
LATÉRALE CORRECT
ÁNGULO CORRECTO DE LIMADURA DE
LA PLACA LATERAL
A - Check for wear or damage (s’assurer de
l’absence d’usure ou de dommages, revise
para ver si hay desgaste o daños)
A
B
A -Left hand cutters (dents de gauche, dientes
de corte izquierdos)
B - Right hand cutters (dents de droite, dientes
de corte derechos)
A
Fig. 27 A
B
A - Depth gauge jointer (coupleur de limiteur
de profondeur, igualador de calibres de
profundidad)
B - Flat file (lime plate, lima plana)
Fig. 28
A
A - Restore original shape by rounding the front
(rendre la forme d’origine en arrondissant
l’avant, restablezca la forma original
redondeando la parte frontal)
A - Scabbard (fourreau, funda)
Fig. 29
AB
A - Mounting holes (trous de montage, orificios
de montaje)
B - Sprocket lubrication hole (trou de la
lubrification de la pignon, orificio de
lubricación de rueda dentada)
Fig. 30
A

Page 2 — English
WARNING
Read all safety warnings, instructions, illustrations
and specifications provided with this power tool.
Failure to follow all instructions listed below may result
in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
WORK AREA SAFETY
Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
Donotoperatepowertoolsinexplosiveatmospheres,
such as in the presence of flammable liquids, gases
or dust. Power tools create sparks which may ignite the
dust or fumes.
Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
Avoidbody contact with earthed or groundedsurfaces
such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body
is earthed or grounded.
Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of electric
shock.
Donotabusethecord.Neverusethecordfor carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of electric shock.
When operating a power tool outdoors, use an exten-
sioncordsuitable for outdoor use. Use of a cordsuitable
for outdoor use reduces the risk of electric shock.
If operating a power tool in a damp location is un-
avoidable, use a ground fault circuit interrupter (GFCI)
protected supply. Use of a GFCI reduces the risk of
electric shock.
PERSONAL SAFETY
Stay alert, watch what you are doing and use com-
mon sense when operating a power tool. Do not use
a power tool while you are tired or under the influence
of drugs, alcohol or medication. A moment of inatten-
tion while operating power tools may result in serious
personal injury.
Use personal protective equipment. Always wear eye
protection.Protectiveequipmentsuch as dustmask,non-
skid safety shoes, hard hat, or hearing protection used
for appropriate conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the switch is in
the off-position before connecting to power source
and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or
energising power tools that have the switch on invites
accidents.
Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to
a rotating part of the power tool may result in personal
injury.
Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpected situations.
Dress properly. Do not wear loose clothing or jewel-
lery. Keep your hair, clothing and gloves away from
moving parts. Loose clothes, jewellery or long hair can
be caught in moving parts.
If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
Do not let familiarity gained from frequent use of tools
allow you to become complacent and ignore tool
safety principles. A careless action can cause severe
injury within a fraction of a second.
POWER TOOL USE AND CARE
Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
Disconnect the plug from the power source and/or
the battery pack from the power tool before making
any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool
or these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
Maintainpowertools.Checkformisalignmentorbind-
ing of moving parts, breakage of parts and any other
condition that may affect the power tool’s operation.
If damaged, have the power tool repaired before use.
Many accidents are caused by poorly maintained power
tools.
GENERAL POWER TOOL SAFETY WARNINGS

Page 3 — English
Keepcuttingtoolssharpandclean. Properlymaintained
cutting tools with sharp cutting edges are less likely to
bind and are easier to control.
Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
Keep handles and grasping surfaces dry, clean and
free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the
tool in unexpected situations.
BATTERY TOOL USE AND CARE
Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with
another battery pack.
Usepower tools only with specifically designated bat-
tery packs. Use of any other battery packs may create
a risk of injury and fire.
When battery pack is not in use, keep it away from
othermetalobjects,likepaperclips,coins,keys,nails,
screws or other small metal objects, that can make a
connection from one terminal to another. Shorting the
battery terminals together may cause burns or a fire.
Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes, ad-
ditionally seek medical help. Liquid ejected from the
battery may cause irritation or burns.
Do not use a battery pack or tool that is damaged or
modified. Damaged or modified batteries may exhibit
unpredictable behavior resulting in fire, explosion or risk
of injury.
Do not expose a battery pack or tool to fire or exces-
sive temperature. Exposure to fire or temperature above
265 °F may cause explosion.
Follow all charging instructions and do not charge the
battery pack or tool outside the temperature range
specified in the instructions. Charging improperly or at
temperatures outside the specified range may damage
the battery and increase the risk of fire.
SERVICE
Have your power tool serviced by a qualified repair
personusingonlyidenticalreplacementparts.Thiswill
ensure that the safety of the power tool is maintained.
Whenservicingapowertool,use onlyidenticalreplace-
ment parts. Follow instructions in the Maintenance
section of this manual. Use of unauthorized parts or
failure to follow Maintenance instructions may create a
risk of shock or injury.
Never service damaged battery packs. Service of bat-
tery packs should only be performed by the manufacturer
or authorized service providers.
GENERAL POWER TOOL SAFETY WARNINGS
PRUNING SAW SAFETY WARNINGS
Keep all parts of the body away from the pruner when
the pruner is operating. Before you start the pruner,
make sure the saw chain is not contacting anything. A
moment of inattention while operating pruners can cause
entanglement of your clothing or body with the saw chain.
Always hold the pruner with your right hand on the
rear handle and your left hand on the front handle.
Holding the pruner with a reversed hand configuration
increases the risk of personal injury and should never be
done.
Hold the power tool by insulated gripping surfaces
only, because the saw chain may contact hidden
wiring. Saw chains contacting a “live” wire may make
exposed metal parts of the power tool “live” and could
give the operator an electric shock.
Wear safety glasses and hearing protection. Further
protective equipment for head, hands, legs and feet is
recommended. Adequate protective clothing will reduce
personal injury by flying debris or accidental contact with
the saw chain.
Do not operate a pruner in a tree. Operation of a pruner
while up in a tree can result in personal injury.
Always keep proper footing and operate the pruner
only when standing on fixed, secure and level surface.
Slippery or unstable surfaces such as ladders may cause
a loss of balance or control of the pruner.
When cutting a limb that is under tension be alert
for spring back. When the tension in the wood fibres is
released the spring loaded limb may strike the operator
and/or throw the pruner out of control.
Useextremecaution when cutting brush and saplings.
The slender material may catch the pruner chain and be
whipped toward you or pull you off balance.
Carry the pruner by the front handle with the pruner
switched off and away from your body. When trans-
porting or storing the pruner always fit the guide bar
cover. Proper handling of the pruning saw will reduce
the likelihood of accidental contact with the moving saw
chain.

Page 4 — English
Follow instructions for lubricating, chain tensioning
and changing accessories. Improperly tensioned or
lubricated chain could break the pruner chain.
Keep handles dry, clean, and free from oil and grease.
Greasy, oily handles are slippery causing loss of control.
Cut wood only. Do not use pruner for purposes not
intended. For example: do not use pruner for cutting
plastic, masonry or non-wood building materials. Use
of the pruner for operations different than intended could
result in a hazardous situation.
Maintainafirmgrip,with thumbs and fingers encircling
the pruner handles, with both hands on the pruner.
Maintaining control of the pruner will reduce the risk of
losing control. Do not let go of the pruner.
Do not overreach and do not cut above chest height.
This helps prevent unintended tip contact and enables
better control of the pruner in unexpected situations.
Only use replacement bars and chains specified by
themanufacturer.Incorrectreplacementbars and chains
can cause chain breakage and increase the risk of injury.
Follow the manufacturer’s sharpening and mainte-
nanceinstructionsfortheprunerchain.Decreasing the
depth gauge height can lead to increased risk of injury.
This pruning saw is not intended for tree felling. Use
of the pruning saw for operations different than intended
couldresultinseriousinjurytotheoperatororbystanders.
CAUSES AND OPERATOR PREVENTION OF
KICKBACK
Kickback may occur when the nose or tip of the guide bar
touches an object, or when the wood closes in and pinches
the saw chain in the cut.
Tip contact in some cases may cause a sudden reverse reac-
tion, kicking the guide bar up and back towards the operator.
Pinching the saw chain along the top of the guide bar may
push the guide bar rapidly back towards the operator.
Either of these reactions may cause you to lose control of
the saw which could result in serious personal injury. Do not
rely exclusively upon the safety devices built into your saw.
As a pruner user, you should take several steps to keep your
cutting jobs free from accident or injury.
Kickback is the result of tool misuse and/or incorrect operat-
ing procedures or conditions and can be avoided by taking
proper precautions as given below:
Maintain a firm grip, with thumbs and fingers encircling
the chain saw handles, with both hands on the saw and
position your body and arm to allow you to resist kickback
forces. Kickback forces can be controlled by the operator,
if proper precautions are taken. Do not let go of the chain
saw.
Do not overreach and do not cut above shoulder height.
This helps prevent unintended tip contact and enables
better control of the chain saw in unexpected situations.
Only use replacement guide bars and saw chains speci-
fied by the manufacturer. Incorrect replacement guide
bars and saw chains may cause chain breakage and/or
kickback.
Follow the manufacturer’s sharpening and maintenance
instructions for the saw chain. Decreasing the depth
gauge height can lead to increased kickback.
Do not start cutting until you have a clear work area, se-
cure footing, and a planned retreat path from the falling
tree. Cluttered areas invite accidents.
Keep ALL children, bystanders, visitors, and animals out
of the work area while starting or cutting with the pruning
saw. Do not let visitors contact pruning saw or extension
cord.
Do not operate pruning saw in explosive atmospheres,
such as in the presence of flammable liquids, gases, or
dust. Pruning saws create sparks which may ignite the
dust or fumes.
Dress Properly – Wear snug fitting clothing. Always wear
heavy, long pants, long sleeves, overalls, jeans or chaps
made of cut resistant material or ones that contain cut
resistant inserts. Wear non-slip safety footwear. Wear
non-slip heavy duty gloves to improve your grip and to
protect your hands. Do not wear jewelry, short pants,
sandals, or go barefoot. Do not wear loose fitting clothing,
which could be drawn into the motor or catch the chain
or underbrush. Secure hair so it is above shoulder level.
Wear hearing and head protection.
Heavy protective clothing may increase operator fatigue,
which could lead to heat stroke. During weather that is
hot and humid, heavy work should be scheduled for early
morning or late afternoon hours when temperatures are
cooler.
Always wear eye protection with side shields marked
to comply with ANSI Z87.1 as well as hearing and head
protection when operating this equipment.
Always be aware of what you are doing when using the
pruning saw. Use common sense. Do not operate the
pruning saw when you are tired, ill, upset, or under the
influence of alcohol, drugs, or medication.
Do not expose the pruning saw to rain.
Do not use the pruning saw in damp or wet locations.
Stay alert and pay attention to what you are doing. Use
common sense when using this unit.
Keep all parts of your body away from the saw chain
when the unit is running.
Never let anyone use your pruning saw who has not
received adequate instructions in its proper use. This
applies to rentals as well as privately owned saws.
Before you start the unit, make sure the saw chain is not
contacting any object.
Stop the pruning saw before setting it down.
PRUNING SAW SAFETY WARNINGS

Page 5 — English
To avoid accidental starting, never carry the unit with your
finger on the switch trigger.
Maintain the unit with care. Keep the cutting edge sharp
and clean for best performance and to reduce the risk
of injury. Follow instructions for lubricating and changing
accessories.
Do not operate a pruning saw with one hand! Use a firm
grip with thumbs and fingers encircling the pruning saw
handles. Serious injury to the operator, helpers, bystand-
ers, or any combination of these persons may result from
one-handed operation. A pruning saw is intended for
two-handed use.
Guard against electric shock – Avoid body contact with
grounded surfaces such as metal pipes and wire fences.
There is an increased risk of electric shock if your body
is grounded.
Do not operate a pruning saw that is damaged, improp-
erly adjusted, or not completely and securely assembled.
Chain should slow to a stop when the switch trigger is
released. If the chain continues to turn after the switch
trigger has been released, have the unit serviced by an
authorized service center.
Check for damaged parts. Check for alignment of mov-
ing parts, binding of moving parts, breakage of parts,
mounting, and any other conditions that may affect its
operation. A guard or other part that is damaged should
be properly repaired or replaced by an authorized ser-
vice center unless otherwise indicated elsewhere in this
manual.
All pruning saw service, other than the items listed in the
operationandmaintenance sections, shouldbeperformed
by an authorized service center.
Always maintain a proper stance.
Do not use pruning saw if switch does not turn it on and
off. Have switch replaced by an authorized service center.
Do not adapt your power head to a bow guide or use it
to power any attachments or devices not listed for the
saw.
Disconnect pruning saw from power supply when not in
use, before servicing, and when making adjustments and
changing attachments, such as saw chain and guard.
Do not cut vines and/or small underbrush.
Do not operate a pruning saw in a tree, on a ladder, roof-
top, scaffold, or other unstable support; this is extremely
dangerous.
NOTE: The size of the work area depends on the job
being performed as well as the size tree or work piece
involved. For example, felling a tree requires a larger work
area than making bucking cuts.
Do not force the pruning saw. The job can be performed
better and safer at the rate for which it was intended.
Always use the right product for your application. The
pruning saw should be used for cutting wood only. Never
use the pruning saw to cut plastic, masonry or non-wood
building materials.
Store pruning saw when not charging or when not in use.
Pruning saw should be stored in a dry and high or locked
area out of the reach of children. When storing pruning
saw place the scabbard on the bar and chain.
Use this product only with charger HOMCC01.
Battery operated units do not have to be plugged into an
electrical outlet; therefore, they are always in operating
condition. Be aware of possible hazards even when unit
is not operating.
Make sure the switch trigger is locked out in the off posi-
tion when not charging and before cleaning, servicing,
storing, removing material from the unit, changing acces-
sories such as the bar and chain, or when not in use.
Never use water or any liquids to clean or rinse off your
product and do not expose the product to rain or wet
conditions. Store indoors in a dry area. Corrosive liquids,
water, and chemicals can enter the product’s electronic
components and/or battery compartment and damage
electronic componentsand/or the battery pack, which can
result in a short circuit, increased risk of fire, and serious
personal injury. Remove any buildup of dirt and debris by
wiping the product clean with a dry cloth occasionally.
KICKBACK
See Figures 2 - 4.
WARNING
Kickback may occur when the moving chain contacts an
object at the upper portion of the tip of the guide bar or
when the wood closes in and pinches the saw chain in the
cut. Contact at the upper portion of the tip of the guide
bar can cause the chain to dig into the object and stop the
chain for an instant. The result is a lightning fast, reverse
reaction which kicks the guide bar up and back toward
the operator. If the saw chain is pinched along the top of
the guide bar, the guide bar can be driven rapidly back
toward the operator. Either of these reactions can cause
loss of saw control which can result in serious injury. Do
not rely exclusively upon the safety devices built into the
saw. As a pruning saw user, you should take several steps
to keep your cutting jobs free from accident or injury.
PRUNING SAW SAFETY WARNINGS

Page 6 — English
The following precautions should be followed to mini-
mize kickback:
• Always grip the saw firmly with both hands. Hold the
saw firmly with both hands when the unit is running.
Place your right hand on the rear handle and your
left hand on the front handle with your thumbs and
fingers encircling the pruning saw handles. A firm grip
together with a stiff left arm will help you maintain
control of the saw if kickback occurs.
• Make sure that the area in which you are cutting is
free from obstructions. Do not let the nose of the
guide bar contact a log, branch, fence, or any other
obstruction that could be hit while you are operating
the saw.
• Always cut with the unit running at full speed. Fully
squeeze the throttle trigger and maintain a steady
cutting speed.
• Usereplacementpartssuchaslow kickbackchainand
special guide bars that reduce the risks associated
with rotational kickback. Use only the replacement
guide bars and low kickback chains specified by the
manufacturer for the saw.
With a basic understanding of kickback, you can reduce
or eliminate the element of surprise. Sudden surprise
contributes to accidents.
Do not overreach. Keep proper footing and balance at all
times.
Do not cut above chest height or overreach when cutting.
Do not let the nose of the guide bar contact a log, branch,
ground, or any other obstruction while you are operating
the unit.
PRUNING SAW SAFETY WARNINGS
SYMBOLS
The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL MEANING
DANGER: Indicates a hazardous situation, which, if not avoided, will result in death or
serious injury.
WARNING: Indicates a hazardous situation, which, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a hazardous situation, that, if not avoided, may result in minor or
moderate injury.
NOTICE: (Without Safety Alert Symbol) Indicates information considered important, but
not related to a potential injury (e.g. messages relating to property damage).
Follow the sharpening and maintenance instructions for
the saw chain.
Push and Pull – This reaction force is always opposite to
the direction the chain is moving where wood contact is
made. Thus, the operator must be ready to control the
PULL when cutting on the bottom edge of the bar, and
PUSH when cutting along the top edge. See Figure 4.
UNDERSTANDING YOUR PRUNING SAW
SAFETY DEVICES
LOW KICKBACK SAW CHAIN
The rakers (depth gauges) ahead of each cutter can minimize
the force of a kickback reaction by preventing the cutters
from digging in too deeply at the kickback zone. Only use
replacement chain that is equivalent to original chain or has
been certified as low kickback chain per ANSI B175.1.
Low kickback saw chain is chain that has met the kickback
performancerequirementsof ANSIB175.1(AmericanNational
Standard for Power Tools – Gasoline-Powered Chainsaws-
Safety Requirements) when tested on the representative
sampleofchainsaws below3.8c.i.d.specified inANSIB175.1.
As saw chains are sharpened during their useful life, they
lose some of the low kickback qualities and extra caution
should be used.
GUIDE BARS
Generally, guide bars with small radius tips have somewhat
lower kickback potentials.
When making a replacement, be sure to order one of the
bars listed for the saw in this operator’s manual.
Save these instructions. Refer to them frequently and use
them to instruct others who may use this product. If you
loan someone this product, loan them these instructions
also.

Page 7 — English
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
Safety Alert Indicates a potential personal injury hazard.
Read Operator’s Manual To reduce the risk of injury, user must read and understand
operator’s manual before using this product.
Eye and Hearing Protection
Always wear eye protection with side shields marked to comply
with ANSI Z87.1 along with hearing protection when operating
this equipment.
Wet Conditions Alert
Do not expose battery, battery compartment, or electronic
components to rain, water, or liquids. Do not charge battery or
expose product to rain or damp locations.
Rain Symbol Do not expose to rain.
Operate With Two Hands Hold and operate the saw properly with both hands.
One Handed Do not operate the saw using only one hand.
Kickback DANGER! BEWARE OF KICKBACK.
Bar Nose Contact
Avoid bar nose contact. Tip contact may cause the
guide bar to move suddenly upward and backward,
which may cause serious injury.
Wear Gloves Wear non-slip, heavy-duty protective gloves when handling the
pruning saw.
Wear Safety Footwear Wear non-slip safety footwear when using this equipment.
Recycle Symbol
This product uses lithium-ion (Li-ion) batteries. Local, state or
federal laws may prohibit disposal of batteries in ordinary trash.
Consult your local waste authority for information regarding
available recycling and/or disposal options.
VVolts Voltage
Direct Current Type or a characteristic of current
SYMBOLS

Page 8 — English
BUCKING
The process of cross cutting a felled tree or log into lengths.
PRUNING SAW POWER HEAD
A pruning saw without the saw chain and guide bar.
DRIVE SPROCKET OR SPROCKET
The toothed part that drives the saw chain.
GUIDE BAR
Asolidrailed structurethatsupports and guidesthesawchain.
KICKBACK
The backward or upward motion, or both, of the guide bar
occurring when the saw chain near the nose of the top
area of the guide bar contacts any object such as a log or
branch, or when the wood closes in and pinches the saw
chain in the cut.
KICKBACK (PINCH)
The rapid pushback of the saw which can occur when the
wood closes in and pinches the moving saw chain in the cut
along the top of the guide bar.
KICKBACK (ROTATIONAL)
The rapid upward and backward motion of the saw which
can occur when the moving saw chain near the upper por-
tion of the tip of the guide bar contacts an object, such as
a log or branch.
LOCK-OUT BUTTON
A movable stop that prevents the unintentional operation of
the switch until manually actuated.
LOW-KICKBACK CHAIN
Achainthatcomplieswiththekickbackperformancerequire-
ments of ANSI B175.1 when tested on a representative
sample of chainsaws.
NORMAL CUTTING POSITION
Those positions assumed in performing the bucking and
pruning cuts.
NOTCHING UNDERCUT
A notch cut in a tree that directs the tree’s fall.
REDUCED KICKBACK GUIDE BAR
A guide bar which has been demonstrated to reduce kick-
back significantly.
REPLACEMENT SAW CHAIN
Achainthatcomplieswiththekickbackperformancerequire-
ments of ANSI B175.1 when tested with specific chainsaws.
It may not meet the ANSI performance requirements when
used with other saws.
SAW CHAIN
A loop of chain having cutting teeth that cut the wood, and
that is driven by the motor and is supported by the guide bar.
SPRINGPOLE
A small tree (sapling) or limb that is bent or trapped under
tension. It may “spring back” rapidly when cut, causing a
dangerous situation.
SWITCH TRIGGER
A device that when operated will complete or interrupt an
electrical power circuit to the motor of the pruning saw.
GLOSSARY OF TERMS

Page 9 — English
PRODUCT SPECIFICATIONS
Motor..................................................................12 Volt DC
Bar Length....................................................................6 in.
Chain Speed................................................13.1 f/s (4 m/s)
NOTE: This saw was designed for occasional light duty use
and has some limitations as to what it can cut.
KNOW YOUR PRUNING SAW
See Figure 1.
The safe use of this product requires an understanding of
the information on the product and in this operator’s manual
as well as a knowledge of the project you are attempting.
Before use of this product, familiarize yourself with all oper-
ating features and safety rules.
FEATURES
UNPACKING
This product has been shipped completely assembled.
Carefully remove the product and any accessories from
the box. Make sure that all items listed in the Packing
List are included.
WARNING:
Do not use this product if it is not completely assembled
or if any parts appear to be missing or damaged. Use of
a product that is not properly and completely assembled
could result in serious personal injury.
Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
Do not discard the packing material until you have care-
fully inspected and satisfactorily operated the product.
If any parts are damaged or missing, please call
1-800-242-4672 for assistance.
PACKING LIST
Pruning Saw
Scabbard
Charger
Operator’s Manual
WARNING:
If any parts are damaged or missing do not operate this
product until the parts are replaced. Use of this product
with damaged or missing parts could result in serious
personal injury.
WARNING:
Do not attempt to modify this product or create acces-
sories not recommended for use with this product. Any
such alteration or modification is misuse and could result
in a hazardous condition leading to possible serious
personal injury.
WARNING:
To prevent accidental starting that could cause serious
personal injury, always make sure the switch trigger is
locked out in the off position when assembling parts.
ASSEMBLY

Page 10 — English
NOTICE:
Before each use, inspect the entire product for damaged,
missing, or loose parts such as screws, nuts, bolts, caps,
etc. Tighten securely all fasteners and caps and do not
operate this product until all missing or damaged parts are
replaced. Please contact customer service or an autho-
rized service center for assistance.
APPLICATIONS
You may use this product for the following purposes:
Basic limbing and pruning.
CHARGING THE TOOL
See Figure 5.
Make sure the switch trigger is locked out in the off
position.
Insert the charging cable into the product as shown.
Connect the power adapter to an outlet providing normal
household voltage, 120 volts, AC only, 60 Hz.
When the tool is charging, the LED will turn red.
Do not place tool in an area of extreme heat or cold. It
will charge best at normal room temperature.
If the LED does not turn on after connecting to a power
supply, check connections. If all connections are secure,
remove from power supply and recheck after one hour.
After charging is complete, the LED will turn green.
If LED does not turn to green after three hours, an error
has occurred. If all connections are secure, remove from
power supply and recheck after one hour.
Disconnect the power adaptor from the outlet once the
tool is fully charged and ready for use.
Disconnect the charging cable from the tool.
WARNING:
Battery tools are always in operating condition. Therefore,
switch should always be locked with hands free of the
lock-out button when not in use.
WARNING:
Do not use charger outdoors or expose to wet or damp
conditions. Water entering charger will increase the risk
of electric shock.
DANGER:
Never cut near power lines, electric cords, or other electric
sources. If bar and chain jams on any electrical cord or
line, DO NOT TOUCH THE BAR OR CHAIN! THEY CAN
BECOME ELECTRICALLY LIVE AND VERY DANGEROUS.
Continue to hold the pruning saw by the insulated rear
handle or lay it down and away from you in a safe manner.
Disconnect the electrical service to the damaged line or
cord before attempting to free the bar and chain from the
line or cord. Contact with the bar, chain, other conductive
parts of the pruning saw, or live electric cords or lines will
result in death by electrocution, electric shock, or serious
personal injury.
WARNING:
Do not allow familiarity with this product to make you
careless. Remember that a careless fraction of a second
is sufficient to inflict serious injury.
WARNING:
Always wear eye protection with side shields marked to
comply with ANSI Z87.1, along with hearing protection.
Head protection should be worn when making cuts
overhead. Failure to do so could result in objects being
thrown into your eyes resulting in possible serious injury.
WARNING:
Do not use any attachments or accessories not recom-
mended by the manufacturer of this product. The use of
attachments or accessories not recommended can result
in serious personal injury.
WARNING:
Never cut a log or limb that has a diameter greater than the
length of the guide bar. Only properly trained profession-
als should perform these cuts. Performing these types of
cuts can cause an accident and result in death or serious
personal injury.
OPERATION

Page 11 — English
WARNING:
Do not charge the battery in a damp or wet location. Do
not use, store, or charge battery packs or products in
locations where the temperature is less than 50°F or more
than 100°F. Do not store outside or in vehicles.
STARTING/STOPPING THE PRUNING SAW
See Figure 6.
WARNING:
Keep body to the left of the chain line. Never straddle the
saw or chain, or lean over past the chain line. Improper
operation of the pruning saw could result in serious per-
sonal injury.
Starting the pruning saw:
Make sure no objects or obstructions are in immediate
vicinitywhichcouldcome in contact withthebarandchain.
Press and hold the lock-out button. This makes the switch
trigger operational.
Pressandholdtheswitchtrigger,releasethelock-outbutton
and continue to squeeze the switch trigger for continued
operation.
Stopping the pruning saw:
Release the switch trigger to stop the pruning saw.
Upon release of the switch trigger, the lock-out button will
be automatically reset to the lock position.
This cordless pruning saw is designed for limbing and pruning
type cutting up to 6 in. in diameter only.
PREPARATION FOR CUTTING
PROPER GRIP ON HANDLES
See Figures 7 - 9.
Refer to Important Safety Instructions earlier in this manual
for appropriate safety equipment.
Wear non-slip gloves for maximum grip and protection.
Hold the saw firmly with both hands. Always keep your left
hand on the front hand grip and your right hand on the rear
handle so that your body is to the left of the chain line.
WARNING:
Never use a left-handed (cross-handed) grip, or any
stance which would place your body or arm across the
chain line. Improper operation of the pruning saw could
result in serious personal injury.
Maintain a proper grip on the saw whenever the unit is
running. The fingers should encircle the handle and the
thumb is wrapped under the handlebar. This grip is least
likely to be broken (by a kickback or other sudden reaction
of the saw). Any grip in which the thumb and fingers are
on the same side of the handle, is dangerous because a
slight kick of the saw can cause loss of control.
WARNING:
Do not operate the switch trigger with your left hand and
hold the front handle with your right hand. Never allow any
part of your body to be in the chain line while operating a
saw. Improper operation of the pruning saw could result
in serious personal injury.
PROPER CUTTING STANCE
See Figure 10.
WARNING:
Always use the proper cutting stance described in this
section. Never kneel when using the pruning saw. Kneel-
ing could result in loss of stability and control of the saw
resulting in serious personal injury.
Weight should be balanced with both feet on solid ground.
Keep left arm with elbow locked in a “straight arm” position
to withstand any kickback force.
Your body should always be to the left of the chain line.
Thumb should be on underside of handlebar.
BASIC CUTTING PROCEDURE
Practice cutting a few small logs using the following tech-
nique to get the “feel” of using the saw before you begin a
major sawing operation.
Support log on a saw horse or cradle.
Take the proper stance in front of the wood with the saw
off.
Squeeze the switch trigger and let the chain accelerate to
full speed before entering the cut.
Begin cutting with the saw against the log.
Keep the unit running the entire time you are cutting,
maintain a steady speed.
Allow the chain to cut for you; exert only light downward
pressure. If you force the cut, damage to the bar, chain,
or unit can result.
Releasetheswitchtriggerassoonasthecutiscompleted,
allowing the chain to stop. If you run the saw without a
cutting load, unnecessary wear can occur to the chain,
bar, and unit.
Do not put pressure on the saw at the end of cut.
OPERATION

Page 12 — English
WORK AREA PRECAUTIONS
Cut only wood or materials made from wood, no sheet
metal, no plastics, no masonry, no non-wood building
materials.
Never allow children to operate the saw. Allow no person
to use this pruning saw who has not read this Operator’s
Manual or received adequate instructions for the safe and
proper use of this pruning saw.
Keepeveryone- helpers,bystanders,children,andanimals
- a safe distance from the cutting area. During bucking
operations, keep a minimum distance of 15 feet between
workers.
Always cut with both feet on solid ground to prevent being
pulled off balance.
Do not cut above chest height, as a saw held higher is
difficult to control against kickback forces.
Do not prune branches near electrical wires or buildings.
Leave this operation for professionals.
Cut only when visibility and light are adequate for you to
see clearly.
LIMBING
See Figure 11.
WARNING:
Never climb into a tree to limb or prune. Do not stand on
ladders, platforms, a log, or in any position which can
cause you to lose your balance or control of the saw, which
could result in death or other serious personal injury.
Limbing is removing branches from a fallen tree.
Work slowly, keeping both hands on the pruning saw with
a firm grip. Always make sure your footing is secure and
your weight is distributed evenly on both feet.
OPERATION
Leave the larger support limbs under the tree to keep the
tree off the ground while cutting.
Limbs should be cut one at a time. Remove the cut limbs
from the work area often to help keep the work area clean
and safe.
Keep the tree between you and the pruning saw while
limbing. Cut from the side of the tree opposite the branch
you are cutting.
PRUNING
See Figure 12.
Pruning is trimming limbs from a live tree.
Work slowly, keeping both hands on the pruning saw with
a firm grip. Always make sure your footing is secure and
your weight is distributed evenly on both feet.
Do not cut from a ladder, this is extremely dangerous.
Leave this operation for professionals.
Do not cut above chest height as a saw held higher is
difficult to control against kickback.
Whenpruningtreesit is important not to make the finishing
cut next to the main limb or trunk until you have cut off
the limb further out to reduce the weight. This prevents
stripping the bark from the main member.
WARNING:
If the limbs to be pruned are above chest height, hire a
professional to perform the pruning. Failure to do so could
result in death or serious personal injury.

Page 13 — English
WARNING:
To avoid serious personal injury, make sure the switch
trigger is locked out in the off position when cleaning or
performing any maintenance.
WARNING:
Always wear eye protection with side shields marked to
comply with ANSI Z87.1, along with hearing and head
protection. Failure to do so could result in objects being
thrown into your eyes resulting in possible serious injury.
WARNING:
When servicing, use only identical replacement parts.
Use of any other parts could create a hazard or cause
product damage.
WARNING:
Never use water or any liquids to clean or rinse off your
product and do not expose the product to rain or wet
conditions. Store indoors in a dry area. Corrosive liquids,
water, and chemicals can enter the product’s electronic
components and/or battery compartment and damage
electronic components and/or the battery pack, which can
result in a short circuit, increased risk of fire, and serious
personal injury. Remove any buildup of dirt and debris by
wiping the product clean with a dry cloth occasionally.
NOTICE:
Periodically inspect the entire product for damaged,
missing, or loose parts such as screws, nuts, bolts, caps,
etc. Tighten securely all fasteners and caps and do not
operate this product until all missing or damaged parts
are replaced. Please contact customer service or an
authorized service center for assistance.
GENERAL MAINTENANCE
Avoidusingsolventswhen cleaningplasticparts. Mostplastics
are susceptible to damage from various types of commercial
solvents and may be damaged by their use. Use clean cloths
to remove dirt, dust, oil, grease, etc.
WARNING:
Do not at any time let brake fluids, gasoline, petroleum-
based products, penetrating oils, etc., come in contact
with plastic parts. Chemicals can damage, weaken or
destroy plastic which could result in serious personal injury.
REPLACING BAR AND CHAIN
See Figures 13 - 18.
WARNING:
Make sure the switch trigger is locked out in the off posi-
tion and the chain has stopped before you do any work on
the saw. Failure to do so may result in accidental starting
and possible serious injury.
WARNING:
To avoid serious personal injury, read and understand all
the safety instructions in this section.
WARNING:
Never touch or adjust the chain while the motor is running.
The saw chain is very sharp; always wear protective gloves
when performing maintenance to the chain to avoid pos-
sible serious lacerations.
CAUTION:
Always wear gloves when handling the bar and chain;
these components are sharp and may contain burrs.
Make sure the switch trigger is locked out in the off
position.
Rotate chain cover lock knob counterclockwise 1/2 to 1
turns.
Rotatethechain tension adjustmentringcounterclockwise
two clicks.
Rotate the chain cover lock knob counterclockwise until
chain cover can be removed.
Remove chain cover.
Remove the bar and chain from mounting surface.
Remove the old chain from the bar.
Remove the slotted fastener with a screwdriver.
Install the chain tension assembly on the new bar by in-
serting the alignment tab into one bar hole and installing
the screw through the other. Tighten securely.
MAINTENANCE

Page 14 — English
Lay out the new saw chain in a loop and straighten any
kinks. The cutters should face in the direction of chain
rotation. If they face the opposite direction, turn the loop
over.
Place the chain drive links into the bar groove as shown.
NOTE: Make certain of direction of chain.
Position the chain so there is a loop at the back of the
bar.
Hold the chain in position on the bar and place the loop
around the sprocket.
Fit the bar flush against the mounting surface so that the
bar mounts are in the long slot of the bar.
Rotate the chain tension cam clockwise a few turns to
take up enough slack in the chain so it stays in position.
Replace the chain cover.
Rotate chain cover lock knob clockwise to tighten. The
bar should still be free to move for tension adjustment.
Remove all slack from the chain by turning the chain ten-
sionadjustmentringclockwiseuntilthechainseatssnugly
against the bar with the drive links in the bar groove.
Lift the tip of the guide bar up to check for sag.
Release the tip of the guide bar and turn the chain ten-
sioning knob 1 click clockwise. Repeat this process until
sag does not exist.
Hold the tip of the guide bar up and tighten the chain
cover lock knob.
The chain is correctly tensioned when there is no sag on the
underside of the guide bar, the chain is snug, but it can be
turned by hand without binding.
NOTE: If chain is too tight, it will not rotate. Loosen the chain
cover lock knob slightly and turn the chain tension adjust-
ment ring 1 click counterclockwise. Lift the tip of the guide
bar up and retighten the chain cover lock knob. Ensure that
the chain will rotate without binding.
ADJUSTING CHAIN TENSION
See Figures 19 - 20.
WARNING:
Shut off the motor, wait for all moving parts to stop, and
make sure the switch trigger is locked out in the off posi-
tion. Never touch or adjust the chain while the engine
is running. The saw chain is very sharp. Always wear
protective gloves when performing maintenance on the
chain. Failure to follow these instructions can result in
serious personal injury.
Proper chain tension is critical to the performance of your
pruning saw. Always check chain tension before using the
saw and periodically until the work is complete.
A cold chain is correctly tensioned when there is no slack on
the underside of the guide bar. The chain should be snug,
but still able to be turned by hand without binding.
A warm chain is correctly tensioned when the flats on the tie
straps hang approximately .050 inches out of the bar groove.
If adjustment is needed:
Loosen the chain cover screw to finger tight.
Raise the tip of the guide bar and continue to hold up
until the end of this procedure.
Turn the chain tensioning knob clockwise until the flats
on the tie straps of the chain contact the bar, making sure
the drive links are seated inside the bar groove.
Retighten the chain cover screw securely.
Release the tip of the guide bar and verify the chain is
now correctly tensioned using the guidelines above.
NOTE: If the chain is too tight and will not rotate, loosen
the chain cover screw slightly, then turn the chain ten-
sioning knob 1 click counterclockwise. Lift up the tip of
the guide bar, retighten the chain cover screw securely,
then verify the chain will now rotate without binding.
NOTE: New chains tend to stretch; check the chain ten-
sion frequently and adjust as needed.
NOTICE:
A chain tensioned while warm may be too tight upon cool-
ing. Check the “cold tension” before next use.
CHAIN MAINTENANCE
See Figures 21 - 22.
WARNING:
Make sure the switch trigger is locked out in the off posi-
tion and the chain has stopped before you do any work
on the saw to avoid accidental starting and possible
serious personal injury.
Use only low-kickback chain on this saw. This fast-cutting
chain will provide kickback reduction when properly
maintained.
For smooth and fast cutting, chain needs to be maintained
properly. The chain requiressharpeningwhenthewoodchips
are small and powdery, the chain must be forced through the
wood during cutting, or the chain cuts to one side. During
maintenance of your chain, consider the following:
Improper filing angle of the side plate can increase the
risk of a severe kickback.
Raker (depth gauge) clearance.
Too low increases the potential for kickback.
Not low enough decreases cutting ability.
MAINTENANCE

Page 15 — English
MAINTENANCE
If cutter teeth have hit hard objects such as nails and
stones, or have been abraded by mud or sand on the
wood, have service dealer sharpen chain.
NOTE: Inspect the drive sprocket for wear or damage when
replacing the chain. If signs of wear or damage are present
in the areas indicated, have the drive sprocket replaced by
a Homelite service dealer.
BAR AND CHAIN LUBRICATION
Using a quality bar oil, oil the bar and chain manually, as
needed.
HOW TO SHARPEN THE CUTTERS
See Figures 23 - 24.
Be careful to file all cutters to the specified angles and to
the same length, as fast cutting can be obtained only when
all cutters are uniform.
WARNING:
The saw chain is very sharp, always wear protective
gloves when performing maintenance to the chain to
prevent serious personal injury.
Properly tension the chain prior to sharpening. Refer to
Adjusting the Chain Tension earlier in this manual. Do
all of your filing at the mid-point of the bar.
Use a 5/32 in. diameter round file and holder.
Keep the file level with the top plate of the tooth. Do not
let the file dip or rock.
Using light but firm pressure, stroke towards the front
corner of the tooth.
Lift file away from the steel on each return stroke.
Put a few firm strokes on every tooth. File all left hand
cutters in one direction. Then move to the other side and
file the right hand cutters in the opposite direction. Oc-
casionally remove filings from the file with a wire brush.
WARNING:
Improper chain sharpening increases the potential of
kickback, which can result in serious personal injury.
WARNING:
Failure to replace or repair damaged chain can cause
serious injury.
NOTICE:
A dull or improperly sharpened chain can cause excessive
engine speed during cutting, which may result in severe
engine damage.
TOP PLATE FILING ANGLE
See Figure 25.
CORRECT 30° - File holders are marked with guide marks
to align file properly to produce correct top plate angle.
LESS THAN 30° - For Cross Cutting.
MORE THAN 30° - Feathered Edge Dulls Quickly.
SIDE PLATE ANGLE
See Figure 26.
CORRECT - 80° Produced automatically if correct diam-
eter file is used in file holder.
HOOK - “Grabs” and dulls quickly. Increases potential of
KICKBACK.
Results from using a file with diameter too small, or file
held too low.
BACKWARD SLOPE - Needs too much feed pressure,
causes excessive wear to bar and chain.
Results from using a file with diameter too large, or file
held too high.
DEPTH GAUGE CLEARANCE
See Figure 27 - 28.
The depth gauge should be maintained at a clearance of
.025 in. Use a depth gauge tool for checking the depth
gauge clearances.
Every time the chain is filed, check the depth gauge
clearance.
Use a flat file and a depth gauge jointer to lower all gauges
uniformly. Depth gauge jointers are available in .020 in. to
.035 in. Use a .025 in. depth gauge jointer. After lowering
each depth gauge, restore original shape by rounding the
front. Be careful not to damage adjoining drive links with
the edge of the file.
Depth gauges must be adjusted with the flat file in the same
direction the adjoining cutter was filed with the round file.
Use care not to contact cutter face with flat file when adjust-
ing depth gauges.
MAINTAINING THE GUIDE BAR
See Figure 29.
CAUTION:
Make sure the switch trigger is locked out in the off posi-
tion and the chain has stopped before you do any work
on the saw to avoid accidental starting or contact with
the moving chain that may result in injury.
Proper maintenance will maximize the useful life of the
guide bar.

Page 16 — English
MAINTENANCE
Each day of use:
Clean the bar and check for wear and damage. Feathering
or burring of the bar rails is a normal process of bar wear,
but such faults should be smoothed with a file as soon as
they occur.
Each week of use:
Reverse the guide bar on the saw to distribute the wear.
Lubricate the sprocket at the end of the guide bar using
a grease syringe in the lubricating hole.
Turn the guide bar and check that the lubrication holes
and chain groove are free from impurities.
A bar with any of the following faults should be replaced
immediately:
Wear inside the bar rails that permits the chain to lay over
sideways
Bent guide bar
Cracked or broken rails
Spread rails
TRANSPORTING AND STORING
See Figure 30.
WARNING:
Make sure the switch trigger is locked out in the off
position and the chain has stopped before transporting
or storing pruning saw. Place pruning saw indoors in a
dry, secure location out of the reach of children when
storing. Failure to follow these instructions may lead to
accidental starting or unauthorized use and result in seri-
ous personal injury.
Do not store or transport the pruning saw when it is
running. The pruning saw should always be idle before
storing or transporting.
Always place the guide bar scabbard on the bar and
chain before storing or transporting the pruning saw. Use
caution to avoid the sharp teeth of the chain.
Store pruning saw on its side.
Clean the pruning saw thoroughly before storing. Store
the pruning saw indoors, in a dry place that is locked and/
or inaccessible to children.
Keep away from corrosive agents such as garden chemi-
cals and de-icing salts.
BATTERIES
This product is equipped with a lithium-ion rechargeable
battery. Length of service from each charging will depend
on the type of work you are doing.
The battery in this product has been designed to provide
maximum trouble-free life. However, like all batteries, it will
eventually wear out.
To obtain the longest possible battery life, we suggest
the following:
Remove the charging cable from the product once it is
fully charged and ready for use.
For product storage longer than 30 days:
Store the product where the temperature is below 80°F
and away from moisture.
Store product in a 30%-50% charged condition.
Everysixmonthsofstorage, chargethe productasnormal.
BATTERY PACK REMOVAL AND
PREPARATION FOR RECYCLING
Drain the battery by running the tool until it shuts off.
Look for the Phillips head screws near the charging port
to locate the battery compartment door.
Unscrewthe screwsandremovethe battery compartment
door.
Pull the battery out of the tool and separate it from the
two wire connectors.
Apply tape over the ends of the wire connectors for bat-
tery disposal.
To preserve natural resources, please recycle or dispose of
batteries properly.
This product contains lithium-ion batteries.
Local, state or federal laws may prohibit dis-
posal of batteries in ordinary trash.
Consult your local waste authority for infor-
mation regarding available recycling and/or
disposal options.
WARNING:
Upon removal, cover the battery pack’s terminals with
heavy-duty adhesive tape. Do not attempt to destroy or
disassemble battery pack or remove any of its compo-
nents. Lithium-ion batteries must be recycled or disposed
of properly. Also, never touch both terminals with metal
objects and/or body parts as short circuit may result.
Keep away from children. Failure to comply with these
warnings could result in fire and/or serious injury.
