HOMEPURE Water Filter User manual

USER MANUAL HOMEPURE WATER PURIFIER

3
USER MANUAL
CONTENTS
1. Features ����������������������������������������������������������������������� 04
2. Filter Components �������������������������������������������������������������� 06
3. Accessories and Operating Instructions ������������������������������������������� 07
4. Filter Media Functions����������������������������������������������������������� 08
5. Precautions �������������������������������������������������������������������� 09
6. Installation Guidelines ����������������������������������������������������������� 10
7. Filter Replacement �������������������������������������������������������������� 11
8. Display ������������������������������������������������������������������������ 13
9. Troubleshooting ���������������������������������������������������������������� 14

4
Antibacterial Silver-lite stone
An antibacterial silver-impregnated mineral stone
protects the lter against contamination from the
lter outlet.
Activated carbon ceramic balls
The activated carbon ceramic balls reduce
chlorine and odours from the water and also give
it a better taste.
7 stages in 1 lter
The quality of seven single filtration stages is
combined in one cartridge. The high-quality lter
media allows extraordinarily clean and safe lter
performance.
Pi-water ceramics from Japan
Pi-water ceramics provide nourishment and wellness
for your body by producing healthier water.
Tourmaline ceramic balls
Tourmaline ceramic balls have the function to purify
and release mineral microelements into the drinking
water.
Ultraltration membrane 0.01-0.1
micron
The membrane with a pore size of 0.01- 0.1 micron
removes all bacteria and provides microbiologically
safe and clean drinking water for you and your family.
USER MANUAL
FEATURES

5
Filter replacement
The HomePure lter cartridge is easy to change.
Professional plumbing and tools are not needed.
Flexible pipe
This pipe can be rotated 360o to maximise
convenience and save space for the user.
One-way nozzle
This nozzle at the outlet of the exible pipe allows
water and air to only ow from the inside to the outside
direction. It is impossible for any contamination from
water or air from the pipe outlet to get back into
the unit.
Display with indicator and beeper
The indicator and beeper alarm will sound if the lter
has to be changed, based on ow volume and time.
USER MANUAL
FEATURES

6
USER MANUAL
FILTER COMPONENTS
1
2
3
4
5
6
7
8
9
10
11
12
13
Flexible pipe
Display
Top cover
Nipple
Battery cover
Reset
Ejector
Controller cover
Filter retaining ring
Base housing
Front valve
One-touch elbow tting
7-in-1 lter cartridge

7
USER MANUAL
ACCESSORIES AND OPERATING INSTRUCTIONS
1
2
3
4
5
6
Plastic tube [1.5 m x 1]
Flexible pipe [x 1]
Manual [x 1]
Diverter valve with O-ring and cap [x 1]
Battery AA size [x 2]
Adapter [x 3], O-ring [x 3]
Model
Characteristics
Water Filter
Type name
Installation type
Filter cartridge
Housing material
Max. operating pressure
Min. operating pressure
Max. operating temperature
Min. operating temperature
HomePure
Countertop
7-in-1 composite lter
ABS resin
4 bar
1 bar
35˚C
4˚C
Rated Service
Rated service ow
Rated service life*
*NOTE: The lifetime will depend on the water quality. It is based on the daily
consumption of 12 litres.
2.0 litres per minute at 1 bar of water pressure
with a new lter (actual ow rate will depend
on water pressure and the time the lter has
been in service).
The lter is designed to serve a family’s cooking
and drinking water needs for 12 months or
4,320 litres, whichever comes rst.

8
USER MANUAL
FILTER MEDIA FUNCTIONS
1. Sediment pre-lter
2. Activated carbon block lter
3. Activated carbon ceramic balls
4. Pi-water ceramic from Japan
5. Tourmaline ceramic balls
6. Ultraltration hollow bre
membrane
7. Antibacterial Silver-lite stone
Filter step Functions
PE material of non-woven fabrics effectively removes
suspended solids such as rust, mud and sand larger
than 5 µm (micron).
This lter absorbs and eliminates residual chlorine, heavy
metals, and all sorts of organic compound such as
agricultural chemical components, carcinogenic
substances, etc.
The activated carbon ceramic balls reduce chlorine and
odours from the water and give it a better taste. They
have excellent absorption, adhesion and deodorisation
and prevent any dust or dregs from coming out of the
unit’s body.
This Pi-water ceramic suppresses oxidation and
disintegration, by neutralising the harmful effects of active
oxygen and controlling the oxidation reduction reaction.
The tourmaline ceramic balls have the function to
purify and release mineral microelements into the
drinking water.
0.1 µm-0.01 µm Ultraltration hollow bre membrane
lters out bacteria and other microscopic organisms
while letting through minerals, consequently providing
fresh water at all times.
This prohibits bacteria from entering through the outlet
of the lter. It gradually releases mineral substances to
the water and prevents recontamination of the lter with
its silver-impregnated mineral stone.

9
USER MANUAL
PRECAUTIONS
The water lter can only be used with pre-ltered water from a
water supply facility, such as a tap. The lter cannot be used
with water from unsafe water sources such as rivers and wells.
To reach an optimum and satisfactory lter result, HomePure
should only be installed in houses with a pipe pressure between
1 to 4 bars.
HomePure must be installed at a far distance from inammable
materials and heating sources in order to avoid deformation.
HomePure should only be installed inside the house.
HomePure can only be installed with a cold water supply at
temperatures ranging between 4°C to 35°C.
Do not clean the lter cartridge. Doing so may contaminate
the lter unit.
HomePure can only be installed as a countertop unit by using a
diverter valve. It cannot be used under the sink.
HomePure should not be exposed to force or shock.
HomePure must be kept away or protected from direct light
(e.g. sunlight).
Do not spill water on the water lter.
Do not open the lter during water ow.
Do not twist the exchange lter too tight into the adapter as the
neck of the lter cartridge can crack and break easily.

10
Pull out the top cover.
Connect the diverter valve to the
faucet. If needed, use one of the
three faucet adapters.**
Open the battery cover and insert
the batteries.
Insert the other end of the tube
to the elbow tting at the back of
the unit until it is properly locked.
Put the top cover back on the lter
and connect the exible pipe to
the nipple.
Place the lter near the sink and
open the cold water supply. Open
the valves and check all connections
for leakage.
Connect the plastic tube to the
diverter valve. Tighten the cap.*
Before using the ltered water as
drinking water, let the water ow
for at least 10 minutes.
* Push the plastic tube rmly and completely over the valve before locking it in with the ring.
** In case no adapter ts to your faucet, you will need to purchase an additional adapter that will t your faucet style.
Always hold the unit from the bottom as the upper part is not secured to the unit and comes off easily for lter replacement.
USER MANUAL
INSTALLATION GUIDELINES

11
Close the diverter valve.
Remove the retaining ring to
unlock the lter.
Remove the tube by pressing
down on the upper ring on the
connector.*
Press out the ejectors rmly to
remove the lter adapter and lter.**
Open the front valve and remove
the exible pipe.
Separate the old lter from the
adapter.
Pull out the top cover.
Clean the inside of the lter only
with a wet or dry cloth.
* Be prepared that a small amount of water may come out of the elbow tting and lter. Use a spanner to press down on the upper ring on the connector.
** In case it is difcult to remove the lter because of air gap, open and close the valve after a few minutes.
USER MANUAL
FILTER REPLACEMENT

13 14 15 16
12
Assemble the new lter with the
adapter.
Put the top cover back on and
connect the exible pipe to the
nipple.*
During reset, the three LEDs
will light up simultaneously. This
means that the reset is complete.
Open the front valve and press the
assembled lter down rmly into
the base housing.
Connect the plastic tube to the
elbow tting.
Lock the lter retaining ring.
Open the diverter and front valve
to allow water ow for at least
10 minutes before use.
After changing the lter cartridge, the indicator
has to be reset. Press the reset button using
a paperclip or similar for two seconds to reset
the lter.
USER MANUAL
FILTER REPLACEMENT
* It is not necessary to reset the indicator after replacing the batteries. The used water volume remains recorded in the memory.

13
No ickering LEDs and no beeping
Lifetime of the lter is nished.
12 months or 4,380 litres
All LEDs ickering
Overow. Close the valves and check
the lter.
Flickering yellow LED and beeping
The batteries have to be changed immediately.
Flickering red LED and beeping
The lter has to be changed immediately.
11-12 months or 4,300 litres
Flickering red LED
Filter replacement is needed within 1 month.
11 months or 4,000 litres
Flickering blue LED
Normal ow.
1-10 months or 0-4,000 litres
USER MANUAL
DISPLAY

14
Problem Possible Cause(s) Troubleshooting
Black colour or black particles in the water
Slow water ow
Noise in the system
Unusual water or chlorine taste and bad odour
Water leakage
No water ow
No light LEDs are displayed
All LEDs are ickering
No water ow, even though the unit looks ne
After installation or lter exchange, let the water ow for at least 10 minutes
to clean the lter from possible small residual particles of carbon.
Replace the lter cartridge.
Replace the lter cartridge.
After installation, let the water ow for at least 10 minutes to remove all air
from the system.
Replace the lter cartridge.
Open the valves and let the water ow for at least 5 minutes.
Check that every connection is inserted with proper depth.
Open the diverter valve.
Open the front valve.
Change the lter.
The indicator’s electronic board needs to be changed. Please contact your
local Network Support Group (NSG).
The ow rate and water pressure is too high. Close the front valve.
Reduce the water pressure into the unit, or call your local Network
Support Group (NSG) for assistance.
Open the lter and check the lter cartridge. If needed, slightly loosen it.
Remove the water nozzle and check.
The HomePure water lter contains carbon powder. After installation,
small particles can appear in the water.
The lifetime of the lter is nished.
The lter is clogged.
There are air bubbles in the system.
The cartridge is not removing chlorine and other contaminants from the
water. The lifetime of the lter cartridge is nished.
You have not used the lter for a while and some sediments
and contaminants developed a bad smell in the system.
Tubes, ttings, nipples and/or exible pipe might not be connected
properly.
The diverter valve is closed.
The front valve is closed.
The lifetime of the lter is nished.
Improper use causes water inside the indicator’s electronic board.
Overow in the lter.
The lter cartridge is too tight inside the adapter.
The one-way nozzle is broken or clogged.
USER MANUAL
TROUBLESHOOTING

Exclusively available from
QNet Ltd
47/F Bank of China Tower
1 Garden Road
Central, Hong Kong
Tel: [phone]
Fax: [phone]
www.qnet.net or www.homepure.com
Copyright © QNet / 2010. All rights reserved.
Copyrights and/or other intellectual property rights on all designs, graphics,
logos, images, photos, texts, trade names, trademarks, etc., in this
publication are reserved. The reproduction, transmission or modication of
any party of the contents of this publication is strictly prohibited.
