Hommax Sistemas DS-2AF1-5 SERIES User manual

5 Inch High Speed Dome
User Manual
V2.0.0
2010-01

5 Inch High Speed Dome User Manual
1
Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer.
This manual is applicable to 5 Inch High Speed Dome.
This manual may contain several technically incorrect places or printing errors, and the content is subject to change without notice.
The updates will be added into the new version of this manual. We will readily improve or update the products or procedures described
in the manual.

5 Inch High Speed Dome User Manual
2
Safety Instruction
These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution
measure is divided into “Warnings” and “Cautions”:
Warnings: Neglecting any of the warnings may cause serious injury or death.
Cautions: Neglecting any of the cautions may cause injury or equipment damage.
Warnings Follow these safeguards to prevent serious
injury or death.
Cautions Follow these precautions to
prevent potential injury or material
damage.
Warnings
1. In the use of the product, you must be strict compliance with the electrical safety regulations of the nation and region.
2. Please use the power adapter, which is provided by normal company. The standard of the power adapter is AC24V/3A.
3. Do not connect several devices to one power adapter as adapter overload may cause over-heat or fire hazard.
4. Please make sure that the plug is firmly connected on the power socket.
5. When the product is installed on wall or ceiling, the device shall be firmly fixed.
6. If smoke, odors or noise rise from the device, turn off the power at once and unplug the power cable, and then please contact the
service center.
7. If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the
camera yourself. (We shall not assume any responsibility for problems caused by unauthorized repair or maintenance.)
Warnings
1. Do not drop the dome or subject it to physical shock, and do not expose it to high electromagnetism radiation. Avoid the equipment
installation on vibrations surface or places subject to shock (ignorance can cause equipment damage).
2. Do not place the dome in extremely hot, cold (the operating temperature shall be -30°C ~ +65°C), dusty or damp locations, or fire or
electrical shock will occur otherwise.
3. The dome cover for indoor use shall be kept from rain and moisture.
4. Exposing the equipment to direct sun light, low ventilation or heat source such as heater or radiator is forbidden (ignorance can
cause fire danger).
5. Do not aim the camera at the sun or extra bright places. A blooming or smear may occur otherwise (which is not a malfunction
however), and affecting the endurance of CCD at the same time.
6. Please use the provided glove when open up the dome cover, avoid direct contact with the dome cover, because the acidic sweat of
the fingers may erode the surface coating of the dome cover.
7. Please use a soft and dry cloth when clean inside and outside surfaces of the dome cover, not to use alkaline detergents.

5 Inch High Speed Dome User Manual
3
Table of Contents
Table of Contents......................................................................................................................................................... 3
Chapter 1 Brief Introduction........................................................................................................................................ 4
1.1 Description..................................................................................................................................................... 4
1.2 Outline ........................................................................................................................................................... 4
1.3 Functions ....................................................................................................................................................... 4
Chapter 2 Operation Instructions................................................................................................................................. 8
2.1 Power-up Action ............................................................................................................................................ 8
2.2 Basic Operations............................................................................................................................................ 8
2.3 Presets with Special Functions ...................................................................................................................... 9
2.4 Label Display................................................................................................................................................. 9
Chapter 3 Menu Operation ........................................................................................................................................ 10
3.1 Main Menu ...................................................................................................................................................11
3.2 System Information ......................................................................................................................................11
3.3 Dome Settings...............................................................................................................................................11
3.3.1 SYSTEM INFORMATION SETTINGS .......................................................................................... 12
3.3.2 CAMERA SETTINGS...................................................................................................................... 13
3.3.3 MOTION SETTINGS....................................................................................................................... 16
3.3.4 PRESETS.......................................................................................................................................... 17
3.3.5 PATROLS ......................................................................................................................................... 19
3.3.6 TIME TASK...................................................................................................................................... 20
3.3.7 PATTERNS....................................................................................................................................... 21
3.3.8 PRIVACYS ....................................................................................................................................... 21
3.3.9 ALARMS................................................................................................................................... 22
3.3.10 AUXS ........................................................................................................................................ 23
3.3.11 CLEAR SETTINGS .................................................................................................................. 24
3.3.12 PASSWORD .............................................................................................................................. 24
3.3.13 ZONES ...................................................................................................................................... 25
3.3.14 LINE SYN ................................................................................................................................. 25
3.4 RESTORE DEFAULTS............................................................................................................................... 26
3.5 RESTORE CAMERA.................................................................................................................................. 27
3.6 REBOOT DOME......................................................................................................................................... 27
3.7 LANGUAGE ............................................................................................................................................... 27
3.8 SET TITLE .................................................................................................................................................. 27
Appendix 1 Lightning & Surge Protection ................................................................................................................ 29
Appendix 2 RS485 Bus Connection .......................................................................................................................... 30
Appendix 3 24VAC Wire Gauge & Transmission Distance ...................................................................................... 33
Appendix 4 Table of Wire Gauge Standards.............................................................................................................. 34

5 Inch High Speed Dome User Manual
4
Chapter 1 Brief Introduction
1.1 Description
Adopting the high-performance integral dome drive with auto iris, auto white balance and other capabilities, the high speed dome is
integrated with the built-in pan/tilt unit and the digital receiver. The dome provides Manchester code and wiring failure diagnosis; with
precise drive, it features high reaction sensitivity and reliable running, ensuring superior image stability; it also provides 3D intelligent
positioning capability during the use of client application software. The high speed dome has become a high-tech security product in
the surveillance field depending on its outstanding performance and full-integral functions.
The dome is designed with power capabilities, including preset, and pan/tilt/frame/random/panorama/pattern scanning; it also features
manual limit stops, auto flip, privacy masking, backlight compensation, etc. The dome supports PELCO-D, PELCO-P, HIK-Code,
VICON and KALATEL-32 protocols, being self-adaptive to different protocols. For ease of operation, the dome address can be
assigned either by DIP switch settings or software; multi-lingual OSD menu allows user to program the system information display,
display settings, dome settings, preset settings, pattern settings, privacy mask settings, alarm settings, AUX settings, etc.
The high speed dome can be widely applied to various monitoring scenes such as the river, forest, road, railway, airport, harbor, oil
field, sentry, plaza, park, scenic spot, street, station, stadium, etc.
1.2 Outline
Back Bo x
Back Box
Dome Drive
Bubble
5 Inch High Speed Dome
1.3 Functions
zMulti-lingual OSD Menu
The dome provides multi-lingual OSD menu for display of system information and setting of dome parameters.
zSelf-adaptive to Multiple Protocols
The dome is compatible with PELCO-D, PELCO-P, HIK-Code, VICON and KALATEL-32 protocol, etc., and is capable of being
self-adaptive to these protocols without need of selecting protocol by DIP switch settings.
zKeyboard Control

5 Inch High Speed Dome User Manual
5
The pan/tilt movement and zoom actions of dome can be controlled by the control keyboard, DVR, matrix, etc.
zLimit Stops
The dome can be programmed to move within the limit stops (left/right, up/down) which are configurable by the control keyboard,
DVR or client application software.
zAuto Scan
The dome provides 5 scanning modes: pan scanning, tilt scanning, frame scanning, random scanning and panorama scanning. The
scanning speed can be set by OSD menu from level 1 to 40, with the corresponding speed ranging from 1°/second to 40°/second.
zPreset Freeze Frame
This feature freezes the scene on the monitor when going to a preset. This allows for smooth transition from one preset scene to
another and also guarantees that masked area will not be revealed when going to a preset.
zPresets
Each of the user-definable presets can be programmed to use pan, tilt, camera settings and other settings. When preset is called, the
dome will automatically move to the defined position. User is allowed to add, modify, delete and call each preset.
zLabel Display
The on-screen label of the preset title, azimuth/elevation, zoom and other operations can be programmed by menu and displayed on the
monitor.
zAuto Flip
In manual tracking mode, when a target object goes directly beneath the dome, the dome will automatically rotate 180 degrees in
horizontal direction to maintain continuity of tracking. When the dome rotates (flips), the camera starts moving upward as long as you
continue to hold the joystick in the down position. This function can be realized by image center flip depending on different camera
models. The feature can be enabled/disabled through the menu.
zPrivacy Mask
The privacy mask allows a user to program user-defined areas that cannot be viewed by the operator of the dome system. A masked
area will move with pan and tilt functions and automatically adjust in size as the lens zooms telephoto and wide.
z3D Intelligent Positioning
The speed dome can be controlled with the 2 buttons and scroll of mouse can be used under HIK-Code protocols with devices and
client software. Click on a certain area and the device will move to the scene with corresponding point as the center. When a
rectangular area is selected by left-clicking the mouse, device will move to its center and enlarge it. With right-clicking, the lens will
zoom in, and the scroll can easily make the lens zooming, and mouse operation automatically incorporates zooming effect.
zProportional Pan
Proportional pan automatically reduces or increases the pan and tilt speeds in proportion to the amount of zoom. At telephoto zoom
settings, the pan and tilt speeds will be slower for a given amount of joystick deflection than at wide zoom settings. This keeps the
image from moving too fast on the monitor when there is a large amount of zoom.
zAuto Focus
The auto focus enables the camera to focus automatically to maintain clear video images.
zIR Cut Filter
The IR cut filter can be set to Auto, Day and Night.In auto mode, the camera is capable of automatically switching Black & White
mode (Night) and Color mode (Day) with regard to environment lightening conditions. In manual switch mode, user can increase
sensitivity in low light conditions by switching to Black & White mode, while the Color mode is preferred in normal lighting
conditions.
zLow Light Electronic Shutter
The shutter speed will automatically slow down in low illumination conditions to maintain clear video images by extending the
exposure time. The feature can be enabled/disabled by the menu.
zBacklight Compensation (BLC)

5 Inch High Speed Dome User Manual
6
If a bright backlight is present, the subjects in the picture may appear dark or as a silhouette. Backlight compensation (BLC) enhances
objects in the center of the picture. The dome uses the center of the picture to adjust the iris. If there is a bright light source outside of
this area, it will wash out to white. The camera will adjust the iris so that the object in the sensitive area is properly exposed.
zWide Dynamic Range (WDR)
When the Wide Dynamic Range (WDR) function is on, the dome is able to balance the brightest and darkest sections of a scene to
produce a picture that is better balanced in lighting and provides more details.
zWhite Balance (WB)
This feature automatically processes the viewed image to retain color balance over a color temperature range. The default setting for
white balance is AUTO.
zPatrol
The high speed dome provides up to 8 patrols. In each patrol, user is allowed to specify the scanning track by a group of user-defined
presets, with the scanning speed between two presets and the dwell time at the preset separately programmable.
zPattern
A pattern is a memorized, repeating series of pan, tilt, zoom, and preset functions that can be recalled with a command from a
controller or automatically by a configured function (alarm, park, time task, or power-up). By default the focus and iris are in auto
status during the preset is being memorized.
zPower-off Memory
This feature allows the dome to resume its previous position or status after power is restored. By default setting, the dome supports the
power-off memory capability with the dwell time of 3 minutes.
zAlarm Response Action
The speed dome supports 7 alarm inputs which can be set to NO or NC. Upon having received the alarm input signal, the dome will
automatically activate a user-defined action, which can be programmed to: preset 1-8, pattern 1-4, patrol 1-8, pan scan, tilt scan,
random scan, frame scan, panoramic scan, color/B&W mode or none. After the alarm is cleared, the dome is capable of resuming its
previous activity or position.
zAUX Output
An auxiliary output is a configurable signal from the dome back box that can trigger another device to operate. The dome provides two
auxiliary outputs: AUX1 andAUX2. The auxiliary output type can be set to NO (normally open) or NC (normally closed) by menu.
And the alarm dwell time is configurable as well.
zManchester Code Self-test
Enable the Manchester code diagnosis capability by setting the positions 4, 5 and 6 of DIP Switch SW2 to ON.
During the use of the Manchester code diagnosis, the corresponding fault code will be displayed on the screen (not available during
park time).
The detailed fault code is defined as below:
Fault Code Description
E0 Normal control
E1 Cable is unconnected
E2
The cable is connected, and data can be normally received, but the address
analysis is incorrect.
E3
The cable is connected, and data can be normally received, but the command
analysis is incorrect.
E4
The cable is connected, and data can be normally received, but the analysis of
address and command is incorrect.
E5
The cable is connected, but the received data does not comply with the
requirements of Manchester code.

5 Inch High Speed Dome User Manual
7
zTime Task
A time task is a preconfigured action that can be performed automatically at a specific date and time. The programmable actions
include: preset 1-8, pattern 1-4, patrol 1-4, pan scan, tilt scan, random scan, frame scan, panorama scan, day/night mode or none.
zZone
A zone is a pan and tilt area defined by a left/right and up/down limit stops. The dome provides eight zones, each with configurable
label and limit stops. If the dome has dwelled at a zone without receiving any command over 4 minutes, this feature will enable the
dome to perform panorama scanning within the zone.
zPassword
The dome features password protection to prevent unauthorized changes to the dome settings.
zCamera Title
Title text is the label used to identify the camera viewed on the monitor. Up to 15 characters can be used for a title
Compass Direction
The dome will show the direction when user manually controls it to rotate. The detailed display information is as below:
Display N NE E SE S SW W NW
Indication North Northeast East Southeast South Southwest West Northwest
The azimuth zero indicates the north direction.
zRS-485 Failure Diagnostics
In the presence of failure at the transmitting and receiving terminals of RS-485 communications, the speed dome is capable of
performing self-test and detecting the fault results which will be displayed on the screen.
zSoft Baud Rate
The baud rate of dome can be configured by the menu without need of DIP switch settings.

5 Inch High Speed Dome User Manual
8
Chapter 2 Operation Instructions
2.1 Power-up Action
After the power is applied, the speed dome will perform self-test action that begins with lens actions and then pan and tilt movement.
After completion of power-up self-test actions, the interface as shown in Figure 2.1 will be displayed on screen for 120 seconds.
The System Information displayed on the screen includes the Dome Address, Protocol, Version and other information. The COM
FORM refers to the baud rate, data bit and stop bit of the dome, e.g., “2400, 8, 1” indicates the dome is configured with the baud rate
of 2400, 8 data bits and 1 stop bit.
TYPE DS- 2AF1-507
ADDRESS 0
COM FORMAT 2400,8,1
PROTOCOL AUTO MATCH
VERSION 2. 10
BUILD DATE 09 11 20
Figure 2.1
2.2 Basic Operations
The following operation shall be done with the use of control device or client software. The control devices include control keyboard
and DVR, etc. And the client refers to the client application software. Examples are given here for common operation provided that the
current control system supports following operation. Please refer to Client Software User Manual for detail operation guide.
Pan and tilt movement: move the joystick to the desired direction, or press the Up/Down/Left/Right buttons.
Zoom operation: press ZOOM+/TELE button to make the lens closer and magnify the scene. Press ZOOM-/WIDE button to make
the lens farther and minify the scene.
Focus operation: After FOCUS+/FAR button is pressed, the object far away will become clearer while the object in vicinity will be
ambiguous. After FOCUS-/NEAR button is pressed, the object in vicinity will become clearer while the object far away will become
ambiguous.
In auto focus mode, camera will focus automatically to maintain clear image. This feature can also be achieved by manually as well.
However, after other operation of device, camera will resume auto focus.
Iris operation: press IRIS+/OPEN to enlarge the iris and increase the image brightness. And by pressing IRIS-/CLOSE, the iris will
gradually shrink that decreases image brightness. In auto iris mode, the IRIS+/OPEN and IRIS-/CLOSE buttons are still operable.
However, after finishing other operation by dome, camera will resume auto iris action.
Preset operation:
Preset can be programmed or called through keyboard or menu. The dome provides 256 presets. Press the SHOT button and then the
numeric keys to call the programmed preset. E.g., the callup of preset 08 can be achieved by pressing PRESET button and then the

5 Inch High Speed Dome User Manual
9
numeral 08. Please refer to Section 3.3.4 for the configuration of presets.
Note: the callup of presets, including the presets with special functions, will be restricted by the limit stops if defined. Callup of presets
programmed out of the limit stops will be invalid.
2.3 Presets with Special Functions
The following presets are predefined with special functions:
Call Preset Function Call Preset Function
33 Auto flip 93 Set manual limit stops
34 Pan zero 94 Remote reboot
35 Patrol 1 95 Access main menu
36 Patrol 2 96 Stop a scan
37 Patrol 3 97 Start random scanning
38 Patrol 4 98 Start frame scanning
39 IR cut filter in 99 Start pan scanning
40 IR cut filter out 100 Start tilt scanning
41 Pattern1 101 Start panorama scanning
42 Pattern2 102 Patrol 5
43 Pattern3 103 Patrol 6
44 Pattern4 104 Patrol 7
92 Enable limit stops setting 105 Patrol 8
Note: In Manchester code control, the presets predefined with special functions are shown as below:
Set PresetFunctionCall Preset Function
65Remote reboot67Auto flip
66Access main menu70Start pattern1
69Stop programming pattern 71Start pattern2
70Program pattern172Start pattern3
71Program pattern2
72Program pattern3
2.4 Label Display
The dome allows you to configure how labels are displayed on the monitor. The following labels are available:
Zoom: Identifies the amount of magnification.
Direction: Displays compass direction, with the format of NEXXX TXXX. The XXX following NE refers to the degrees in northeast
direction, while the XXX following T indicates the degrees in vertical position. The north direction can be set by menu. E.g., NE235
T035 indicates the current position of the dome is in 235 degrees in northeast and 35 degrees in vertical position.
Alarm Message: Displays activated alarm message.
Time: Support for time display.
Preset Title: Identifies preset being called.

5 Inch High Speed Dome User Manual
10
Chapter 3 Menu Operation
Note: The menu varies depending on camera models.
Menu Tree
LINE SYNC
LINE LOCK ON
V-PHASE 0
BACK EXIT
LABLE [PRESET 1 ]
INS
ZOOM+DELETE CONTENTS
FOCUS+CHANGE CONTENTS
FOCUS- CHANGE MARKER
ROCKER CHO OSE CONT EN TS
OPEN: SURE CLOSE: BACK
LABEL [PRESET 1 ]
INS
LOWCASE[a b c d e f g h I j]
ZOOM+DELETE CONTENTS
FOCUS+CHANGE CONTENTS
FOCUS- CHANGE MARKER
ROCKER CHO OSE CONT EN TS
OPEN: SURE CLOSE: BACK
PATRO LS
PATROL NUM 1
EDIT PATROL
PREVIEW
DELE PATH
BACK EXIT
NUM P RESET DWELL SP EED
1 0 6 30
2 0 6 30
3 0 6 30
4 0 6 30
5 0 6 30
6 0 6 30
7 0 6 30
DONE: OPEN QUIT:CLOSE
PATTERNS
PATTERN NUM 1
EDIT PATTERN
PREVIEW
DELE PATTERN
REMAINING 100
BACK EXIT
REMAIN MEMORY 100
DONE: OPEN
QUIT: CLOSE
PRIVACYS
BLANK NUM 1
BLANK STATUS OFF
SET BLANK
DELE BLANK
BACK EXIT
ADJUST BLANK POS
FOCUS+SHIFT STATUS
SAVE: OPEN
QUIT: CLOSE
TIME TASK
TASK NUM 1
TASK STATE ON
TASK ACTION NONE
TASK TIME
TASK PREVIEW
TASK CLEAN
BACK EXIT
WEEK WHOLE WEEK
START(H-M) 00 00
END(H-M) 00 00
DONE: OPEN
QUIT: CLOSE
NUM TIME ACTION STATE
1 WHO 0 0 0 0 NONE OFF
2 WHO 0 0 0 0 NONE OFF
3 WHO 0 0 0 0 NONE OFF
4 WHO 0 0 0 0 NONE OFF
5 WHO 0 0 0 0 NONE OFF
6 WHO 0 0 0 0 NONE OFF
7 WHO 0 0 0 0 NONE OFF
8 WHO 0 0 0 0 NONE OFF
ALARM
ALARM RESUME ON
ALARM SEQUENCE 5
ALARM REST DELAY 5
ALARM SETTING
BACK EXIT
ALARM SETTING
ALARM NUM 1
PRIORITY HIGH
ALARM ACTION NONE
AUX NONE
ALARM INPUT OPEN
BACK EXIT
CLEAR SETTINGS
CLEAR ALL PRESETS
CLEAR ALL PATROLS
CLEAR ALL PATTERNS
CLEAR ALL BLANKS
CLEAR ALL ZONES
CLEAR ALL TIME TASKS
<DIAGNOSTICS>
BACK EXIT
DIAGNOSTICS
HIGH TEMP 0
HIGHEST TEMP 35° C
LOW TEMP 0
LOWEST TEMP 14° C
VIDEO LOSS 0
LOW VOLATE 0
POWER UP 0
BACK EXIT
DIAGNOSTICS
PAN LOST 0
TILT LOST 0
CAMERA LOST 0
BACK EXIT
MAI N MENUS
<SYS INFO>
<DOME SETTINGS>
<RSTORE DEFAULTS>
<RSTORE CAMERA>
<RSBOOT DOME>
LANGUAGE ENGLISH
SET TITLE OFF
EXIT
SYS IN FO
TYPE DS-2AF1‐507
ADDRESS 0
COM FORMAT 2400,8,1
PROTOCOL AUTO MATCH
TEMPERATURE 27℃
VERSION 2. 10
BUILD DATE 09 11 20
BACK EXIT
DOME SETTINGS
<S YS INF O SETTING>
<DOME PARAMETER>
<MOTION PARAMETER>
<PRESETS>
<PATROLS>
<TIME MASK>
<P ATTERNS>
BACK EXIT
DOME SETTINGS
<PRIVACYS>
<ALARMS>
<AUXS>
<CLEAR SETTINGS>
<PASSWORD>
<ZONE>
<LINESYNC>
BACK EXIT
SYS INFO SETTINGS
SOFT ADDRESS 1
SOFT ADDR ACTIVE OFF
SOFT BAUD 2400
SOFT BAUD ACTIVE OFF
BROADCAST ADDRESS ON
PELCO CHECKSUM ON
SYS TIME
BACK EXIT
SYS INFO SETTINGS
ZERO ANGLE
DISPLAY SETTINGS
FAN CONTROL TEMP
BACK EXIT
Y- M - D 07 01 18
H - M - S 15 33 25
DONE: OPEN
QUIT: OPEN
DISPLAY SETTINGS
ZOOM SHOW 2
PT SHOW 2
ALARM SHOW ON
TIME SHOW ON
PRESET SHOW ON
ZONE SHOW ON
BACK EXIT
DISPLAY SETTINGS
ADDRESS SHOW OFF
ERRO R RATE S H OW OFF
BACK EXIT
CAMERA
BLC/WDR OFF
BLC LEVEL N /A
AE MODE AUTO
IRIS 10
SHUTTER 60
GAIN 1
EXPOSURE COMP 7
BACK EXIT
CAMERA
WHITE BALANCE AUTO
RED 210
BLUE 150
IMAGE FLIP OFF
FOCUS LIMIT 1M
INIT LENS OFF
NOISE REDUCE N/A
BACK EXIT
MOTION
AUTO FLIP ON
PROPORTIONAL PAN OFF
PARK TIME 5
PARK ACT NONE
SCAN SPEED 40
IMAGE FREEZE OFF
DOME SPEED MID
BACK EXIT
MOTION
PRESET SPEED 4
LIMIT STOP OFF
<S ETTING STOPS>
CLEAR STOPS
BACK EXIT
PRESETS
PRESET NUM 1
[ UNDEFINED]
<EDIT LABEL>
<PRESET PTZ>
CLEAR PRESET
BACK EXIT
CAMERA
FOCUS AF
ZOOM LIMIT 36
ZOOM SPEED HIGH
SLOW SHUTTER O N
IRCUT FILTER AUTO
D/N LEVEL HIGH
SHARPNESS 9
BACK EXIT

5 Inch High Speed Dome User Manual
11
3.1 Main Menu
In PELCO-P/D or other PTZ protocols, the main menu can be entered by calling preset 95 through DVR, Keyboard or Client Software,
as shown in Figure 3.1.1. For instance, press the PTZ button on DVR front panel to enter the PTZ control mode, and then press the
REC button followed by numeric 095 to access the main menu; or press the SHOT + numeric 095 and then the Enter button from the
control keyboard to access the main menu.
In HIK-Code protocol, directly press the Menu button on DVR front panel to access the main menu.
Change cursor position through joystick or direction buttons on the front panel of DVR and move the cursor to the selected menu item.
Press IRIS+ to confirm, i.e., operation can be done on this menu options. If current menu contains sub-menu, enter the corresponding
sub-menu.
To perform operation on menu option, the selected number behind menu item can be changed by moving joystick up and down. Press
IRIS+ to confirm and return to previous menu. The same procedure is followed for the next operation for which no description is given.
Select Exit menu option to confirm and exit from menu operation.
MAIN MENUS
<SYS INFO>
<DOME SETTINGS>
<RSTORE DEFAULTS>
<RSTORE CAMERA>
<RSBOOT DOME>
LANGUAGE ENGLISH
SET TITLE OFF
EXIT
SYS INFO
TYPE DS- 2AF1-507
ADDRESS 0
COM FORMAT 2400,8,1
PROTOCOL PELCO-D
TEMPERATURE 27
VERSION 2. 10
BUILD DATE 09 11 20
BACK EXIT
Figure3.1.1 Figure3.2.1
3.2 System Information
This menu displays current dome system information, as shown in Figure 3.2.1. Information in menu option cannot be changed and
Temperature refers to internal temperature of dome.
Move the cursor to Back and click IRIS+ to return to the previous menu, or move the cursor to Exit and click IRIS+ to save the settings.
Operation is similar to all other submenus.
3.3 Dome Settings
Enter the Dome Settings menu, as shown in Figure 3.3.1 and Figure 3.3.2.
Note: use the Left and Right direction buttons to enter the next page and back to the previous page of the menu if available.

5 Inch High Speed Dome User Manual
12
DOME SETTINGS
<PRIVACYS>
<ALARMS>
<AUXS>
<CLEAR SETTINGS>
<PASSWORD>
<ZONE>
<LINESYNC>
BACK EXIT
Figure3.3.1 Figure3.3.2
3.3.1 SYSTEM INFORMATION SETTINGS
The SYS INFO SETTINGS menu is used for displaying the dome drive model, software version, available memory, DIP switch
information, and other diagnostic information. Refer to Figure 3.3.3 and Figure 3.3.4.
zSOFT ADDRESS
When the soft address is enabled, the speed dome will use the soft address, as shown in Figure3.3.3, with the addresses from 1 to 255
selectable. When the SOFT ADDR ACTIVE option is set to OFF, the hard address set by DIP switch is used; if the address of the
control device is 0, then the speed dome of any address can be controlled as well.
SYS INFO SETTINGS
SOFT ADDRESS 1
SOFT ADDR ACTIVE OFF
SOFT BAUD 2400
SOFT BAUD ACTIVE OFF
BROADCAST ADDRESS ON
PELCO CHECKSUM ON
SYS TIME
BACK EXIT
SYS INFO SETTINGS
ZERO ANGLE
DISPLAY SETTINGS
FAN CONTROL TEMP
BACK EXIT
Figure3.3.3 Figure3.3.4
zSOFT BAUD RATE
When the SOFT BAUD option from the menu is set to ON, the speed dome will use the soft baud rate, as shown in Figure 3.3.3, with
2400, 4800, 9600 and 19200 selectable. In this status, it is invalid to set baud rate by DIP switch. When the SOFT BAUD option is set
to OFF, the baud rate can be set by DIP switch.
Note: when the soft baud rate function has been enabled and configured, the dome will reboot to activate the settings; and when the
soft baud rate function is disabled, the dome will reboot as well.
zBROADCASTADDRESS
When the BROADCAST ADDRESS is set to ON, the control device with address 0 is capable of controlling all domes connected to it.
zPELCO CHECKSUM
When the dome in PELCO-P and PELCO-D protocol cannot be controlled, user may enable this function to solve the problem.
zSYSTEM TIME
The SYS TIME allows user to set the date and time of the dome. As shown in Figure 3.3.5, the message indicates the current date and
time is 15:33:25 on January 18th , 2007.
Move the joystick of the keyboard or use the Left and Right buttons on DVR front panel to select the option, and move the joystick of

5 Inch High Speed Dome User Manual
13
the keyboard or use the Up and Down buttons to modify the value.
Y - M - D 07 01 18
H - M - S 15 33 25
DONE: OPEN
QUIT: OPEN
Figure 3.3.5
zZERO ANGLE (North Direction)
Enter the ZERO ANGLE (azimuth/elevation) menu and then use the joystick of keyboard or the direction buttons on DVR front panel
to define the amount of pan from zero degrees vertical and the amount of tilt from zero degrees horizontal, and finally press the Iris+
button to save settings and exit the current menu.
zDISPLAY SETTINGS
The DISPLAY SETTINGS menu is displayed in two pages, as shown in Figure 3.3.6 and Figure 3.3.7.
Each item can be set with the separate display time on screen from 2sec, 5sec and 10 sec selectable, or set to be ON or OFF. The preset
display position can overlapped the display positions of azimuth/elevation and zoom. If both of the ZOOM SHOW and the PT SHOW
are set to ON, then in the preset operation status, the preset label will be displayed all the time; while in other operation status, the
azimuth/elevation and zoom label are displayed all the time in other status. The external alarm response actions can be activated in
non-menu programming mode while disabled in the menu programming mode.
DISPLAY SETTINGS
ZOOM SHOW 2
PT SHOW 2
ALARM SHOW ON
TIME SHOW ON
PRESET SHOW ON
ZONE SHOW ON
BACK EXIT
DISPLAY SETTINGS
ADDRESS SHOW OFF
ERROR RATE SHOW OFF
BACK EXIT
Figure3.3.6 Figure3.3.7
3.3.2 CAMERA SETTINGS
Note:different dome models are programmed with different Camera Settings menu.
The CAMERA menu is displayed in three pages, as shown in Figure 3.3.8, Figure 3.3.9 and Figure 3.3.10.

5 Inch High Speed Dome User Manual
14
CAMERA
FOCUS AF
ZOOM LIMIT 36
ZOOM SPEED HIGH
SLOW SHUTTER ON
IRCUT FILTER AUTO
D/N LEVEL HIGH
SHARPNESS 9
BACK EXIT
Figure3.3.8 Figure3.3.9
CAMERA
WHITE BALANCE AUTO
RED 210
BLUE 150
IMAGE FLIP OFF
FOCUS LIMIT 1M
INIT LENS OFF
NOISE REDUCE N/A
BACK EXIT
Figure 3.3.10
zFOCUS
The camera provides three focus modes for selection: AF (auto), HAF (half-auto) and MF (manual).
In auto focus mode, the camera will allow the lens to remain in focus when using pan, tilt and zoom (PTZ) functions.
In manual focus mode, the focus can be operated manually.
In half-auto focus mode, the camera will remain in a fixed focus position when all PTZ motions are stopped. And when the PTZ
motions are resumed, the camera will focus automatically.
The default setting is AF.
zZOOM LIMIT
Zoom limit allows the user to define a limitation on the amount of telephoto zoom. The settings vary depending on camera model.
Zoom amount＝optical zoom× digital zoom. When the ZOOM LIMIT is set to the minimum value, it indicates the digital zoom is
disabled, and the optical zoom is in its maximum value.
zZOOM SPEED
Zoom speed allows the user to define the speed at which the dome will go from full wide zoom to the optical zoom, with three levels
selectable: HIGH, MID and LOW. The default setting is HIGH.
zSLOW SHUTTER
The shutter will automatically slow down to obtain clearer figure through exposure time extension under low lightening. The default
setting is ON.
zIR CUT FILTER
The IR cut filter can be set to AUTO, DAY and NIGHT.In auto mode, the camera is capable of automatically switching Black &
White mode (NIGHT) and Color mode (DAY) with regard to environment lightening conditions. In manual switch mode, user can
increase sensitivity in low light conditions by switching to Black & White mode, while the Color mode is preferred in normal lighting
conditions. The default setting is AUTO.

5 Inch High Speed Dome User Manual
15
The DAY mode can be set by calling preset 39, and the NIGHT mode set by preset40.
zD/N Level
The D/N level is the light level at which the IR cut filter switches DAY or NIGHT. Three levels are selectable: HIGH, MID and LOW.
The default setting is MID.
Note: This feature varies depending on camera model.
zSharpness
The sharpness function enhances picture detail by increasing the aperture gain of the camera and sharpening the edges in the picture.
Levels from 1 to 16 are selectable, with the default setting of level 9.
zBLC/WDR
If a bright backlight is present, the subjects in the picture may appear dark or as a silhouette. Backlight compensation (BLC) enhances
objects in the center of the picture. The dome uses the center of the picture to adjust the iris. If there is a bright light source outside of
this area, it will wash out to white. The camera will adjust the iris so that the object in the sensitive area is properly exposed.
When the Wide Dynamic Range (WDR) function is on, the dome is able to balance the brightest and darkest sections of a scene to
produce a picture that is better balanced in lighting and provides more details.
Note: The BLC/WDR feature varies depending on camera model. The default setting is for BLC function.
zBLC LEVEL
This feature is used for adjusting the backlight compensation level.
Note:The feature varies depending on camera model.
zAE MODE
The AE mode can be set to AUTO, IRIS, SHUTTER, GAIN or MANUAL. When it is set to AUTO, the auto iris, auto shutter and auto
gain functions are all enabled; when it is set to IRIS, the iris function adopts the defined value while the auto shutter and auto gain
remain to be enabled; when it is set to SHUTTER, the shutter function adopts the defined value while the auto iris and auto gain
remain to be enabled; and when it is set to GAIN or MANUAL, the gain value can be adjusted, or the iris, gain and shutter values are
all adjustable. The default setting is AUTO.
Note: The Gain or Manual feature varies depending on camera model.
zIRIS
The iris is the lens function that opens and closes the iris in response to changing light conditions, with the numeric values from 0 to
17 selectable.
zSHUTTER
The Shutter is the duration of the electronic shutter. User can set the shutter speed to 1, 2, 4, 8, 15, 30, 60, 125, 180, 250, 500, 1000,
2000, 4000 or 10000. The numeric value of X indicates the shutter speed is 1/X second.
zGAIN
The Gain indicates the amplification degree of the original image signal, with the numeric values from 0 to 15 selectable.
zEXPOSURE COMP
The exposure compensation effect can be adjusted through exposure volume adjustment. The numeric values from 0 to 14 are
selectable, with the default setting of 7.
zWHITE BALANCE
This feature automatically processes the viewed image to retain color balance over a color temperature range. The dome provides 5
modes for selection: AUTO, INDOOR, OUTDOOR, SELFDEF (self-defined) and ATW. When the SELFDEF is selected, set the value
of RED and BLUE.
zIMAGE FLIP
This feature allows the video image to be mirrored on the screen.
zFOCUS LIMIT
The focus limit can be set to 1CM, 30CM, 1M or 3M. The feature allows the camera to perform auto focus out of the focus limit . The

5 Inch High Speed Dome User Manual
16
default setting is 1M.
zINIT LENS
This feature enables the camera to perform daily lens initiation action to ensure the normal operation.
zNOISE REDUCE
The noise reduce function can be set to OFF, HIGH, MID and LOW. The default setting is MID.
Note: This feature varies depending on camera model.
3.3.3 MOTION SETTINGS
The MOTION menu is displayed in two pages, as shown in Figure 3.3.11 and Figure 3.3.12.
MOTION
AUTO FLIP ON
PROPORTIONAL PAN OFF
PARK TIME 5
PARK ACT NONE
SCAN SPEED 40
IMAGE FREEZE OFF
DOME SPEED MID
BACK EXIT
Figure3.3.11 Figure3.3.12
zATUO FLIP
The dome will rotate 180 degrees when the camera tilts downward and goes just beyond the vertical position. When the dome rotates
(flips), the camera starts moving upward as long as you continue to hold the joystick in the down position. Once you let go of the
joystick after the dome rotates, joystick control returns to normal operation. The auto-flip feature is useful for following a person who
passes directly beneath the dome. This function can be realized by image center flip depending on different camera models.
zPROPORTIONAL PAN
When the PROPORTIONAL PAN is set to ON, the dome will automatically reduce or increases the pan and tilt speeds in proportion to
the amount of zoom. At telephoto pan and tilt speeds will be slower for a given amount of joystick deflection than at wide zoom
settings. This keeps the image fast on the monitor when there is a large amount of zoom.
When the PROPORTIONAL PAN is set to OFF, it will be difficult to trace the object at low pan and tilt speeds or no movement in
large amount of zoom.
Note: This feature is enabled all the time while setting the patterns.
zPARK TIME
This feature allows the dome to begin a specified operation (scan, preset, or pattern) after a configured period of inactivity.
Park time can be configured from 5 to 720 seconds.
Note: If no control signal is received for a period of time under the following circumstances, no automatic actions will be performed:
1. In the process of performing dome actions by callup of special presets; 2. In the process of performing external alarm response
actions.
zPARK ACTION
This feature will define the activity when the dome parks. The selectable park actions include: presets1-8, patterns 1-4, patrols 1-8, pan
scan, tilt scan, random scan, frame scan, panoramic scan, day mode, night mode, or none.
zSCAN SPEED
Scan speed is the degrees per second of the pan scan, tilt scan, frame scan, random scan and panoramic scan. Scan speed is adjustable

5 Inch High Speed Dome User Manual
17
from 1 to 40 degrees per second through the camera menu.
zIMAGE FREEZE
This feature freezes the scene on the monitor when going to a preset. This allows for smooth transition from one preset scene to
another. Preset freeze frame also reduces bandwidth when used with digital network systems and guarantees that blanked areas will not
be revealed when going to a preset.
zDOME SPEED
The manual dome movement speed can be set to HIGH, MID or LOW.
zPRESET SPEED
The speed of preset callup can be set from level 1 to 8. The higher level corresponds to the faster preset callup.
zLIMIT STOPS
Limit stops are configurable stops that limit the pan and tilt range of the dome. There may be left/right and up/down limit stops
configurable to define an area. When the LIMIT STOP function is set to OFF, the movement of dome will not be limited despite of
defined limit stops.
zSETTING LIMIT STOPS
To set limit stops manually:
1. Enter the SETTING STOPS menu.
2. Follow the directions (SET LEFT LIMIT) displayed on the monitor and use the joystick or the direction buttons on DVR front
panel to the desired location of left limit stop.
3. Press the IRIS + button to finish the setting of left limit stop.
4. Follow the same steps to set the right, up and down limit stops in sequence according to the directions displayed on the
monitor.
The new settings of limit stops will overwrite the existed settings.
zCLEAR STOPS
The defined limit stops can be cleared by this menu.
3.3.4 PRESETS
The PRESETS menu is displayed as shown in Figure 3.3.13
PRESETS
PRESET NUM 1
[UNDEFINED]
<EDIT LABEL>
<PRESET PTZ>
CLEAR PRESET
BACK EXIT
Figure 3.3.13
zPREST NUMBER
The dome provides 256 presets. The PRESET NUM displays the preset under current operation. If the preset has been defined, the
corresponding number will appear; while no preset is defined, it will display UNDEFINED. The presets which are predefined for
specific functions will not be displayed and no change is allowable. Please refer to page 9 for presets with specific functions.
zEDIT LABEL

5 Inch High Speed Dome User Manual
18
Figure 3.3.14
The Preset Label menu is shown in Figure 3.3.14.
Operate the following stops to edit the preset label:
a. Move the cursor beside [PRESET].
b. Press the FOCUS+ button to switch input characters among numbers, lowercases, capitals and symbols.Refer to Figure3.3.15.
Move the Left and Right buttons to position the cursor beside a character and press FOCUS+ to enter selection.
c. To clear a character, use the FOCUS- button to position the cursor under the character to be deleted, and then press ZOOM+.
To modify a character, use the FOCUS- button to position the cursor under the character to be modified, and then enter the new
character by following Step b.
d. When label is completed, press IRIS+ to save the current settings and return to the previous menu.
Use the following functions buttons on the keyboard or the DVR front panel to edit preset label:
ZOOM-: switch between INS and OVR mode.
INS: insert character at the position of cursor;
OVR: enter the character at the position of cursor and overwrite the original character.
ZOOM+: delete the character at the position of cursor.
FOCUS+: switch input characters among numbers, lowercases, capitals and symbols.
FOCUS-: move the cursor at the preset label.
IRIS+: Confirm and save the current settings and return to the previous menu.
IRIS-: Cancel the current operation and return to the previous menu.
Direction Buttons: move the cursor to select the numbers/lowercases/capitals / symbols.
Figure 3.3.15
zPRESET PTZ
Enter the PRESET PTZ menu to edit preset scene. Use the joystick or direction buttons to move PTZ to the desired scene and then
press the IRIS+ to confirm the settings and return to the previous menu, or press IRIS- to cancel settings.

5 Inch High Speed Dome User Manual
19
Note: the setting of preset scene will be restricted by the limit stops if defined.
zCLEAR PRESET
This feature is used for clearing the current preset.
3.3.5 PATROLS
The PATROLS settings menu is shown in Figure 3.3.16.
zPATROLS NUMBER
The number of patrol under current operation. The dome provides 8 patrols numbering from 1 to 8.
PATROLS
PATROL NUM 1
EDIT PATROL
PREVIEW
DELE PATH
BACK EXIT
Figure3.3.16 Figure3.3.17
zEDIT PATROL
The EDIT PATROL settings menu is shown in Figure 3.3.17. A patrol can be configured with 32 presets.
To edit a patrol:
1. Move the joystick up and down or Up and Down direction buttons to select the preset to be edited.
2. Move the joystick left and right or Left and Right direction buttons to select among PRESET, DWELL TIME and SPEED.
3. After having selected the item to be edited, move the joystick up and down or Up and Down direction buttons to set values.
4. Follow the same steps to edit the other presets. Use the joystick or the Right direction button to enter the next page.
The preset edited in the patrol can be modified or deleted as well. In default setting, the preset number is initialized as 0, dwell
time is 6 seconds (0-30 seconds selectable) and the patrol speed is level 30 (level 1-40 selectable).
5. Press IRIS+ to save the current settings or press IRIS- to cancel settings and return to the previous menu.
Note:the patrol speed of the dome is shown as below:
Level Speed（°/s）Level Speed（°/s）Level Speed（°/s）
1 0.3 2 2 3 4
4 6 5 8 6 10
7 12 8 14 9 16
10 18 11 20 12 25
13 30 14 35 15 40
16 45 17 50 18 55
19 60 20 65 21 70
22 80 23 90 24 100
25 110 26 120 27 130
28 140 29 150 30 160
31 170 32 190 33 210
34 230 35 250 36 270
37 290 38 310 39 330
40 350
zPREVIEW PATROL
Enter the PREVIEW menu to view the current patrol if defined, which enables the dome to scan among the presets as predefined.
