Homtone DS-0987 User manual

DS-0987
USER MANUAL
Intelligent Toilet Seat
Seeking a Better Quality-of-life
For FAQ and more information, please contact us with your information and order number.
We are glad to be of service.
After-sale Email: [email protected]

Thank you for your recent purchase of the product. Please read the enclosed information to ensure the safe
use of your product.
Be sure to read this User Manual before using your product and keep it in a safe place for future reference.
BE SURE TO FOLLOW THE SAFETY PRECAUTIONS.
Some pictures in this User Manual are schematic diagrams and are for reference only. If the pictures do not
match the actual objects, the actual ones shall prevail.
DS-0987

SAFETY PRECAUTIONS ------------------------------------------------------
PARTS NAMES------------------------------------------------------------------
HOW TO INSTALL-------------------------------------------------------------
CONFIRMATION AND TRIAL OPERATION--------------------------------
HOW TO OPERATE------------------------------------------------------------
HOW TO MAINTAIN IT--------------------------------------------------------
MAINTENANCE UNDER LONG-TERM REST-----------------------------
TROUBLESHOOTING---------------------------------------------------------
SPECIFICATIONS--------------------------------------------------------------
2
8
10
15
16
20
21
22
23
SAFETY PRECAUTIONS
USER MANUAL
In order to prevent harm and property damage to users or others,
please read [Safety Precautions] carefully and be sure to observe!
SYMBOLS AND MEANINGS：
WARNING May result in death or serious injury.
May result in injury or property damage.
CAUTION
SYMBOLS MEANINGS
This symbol indicates mandatory content that must be performed.
This symbol indicates that it is prohibited to disassemble or modify
this product without authorization.
This symbol indicates a prohibited use of the content.
This symbol indicates that do not spray water.
This symbol indicates that do not handle with wet hands.
This symbol indicates ground connection.
This symbol indicates that high temperature and flammable
objects are prohibited.
WARNING
Be aware of low temperature burns.
Refrain from sitting on the seat for long periods. It may cause low-temperature burns.
To prevent the following persons from getting a moderate temperature burn during use,
other person should turn off the toilet seat heater.
-Young children, the aged and other users unable to set the temperature appropriately
themselves.
-The ill, physically disabled and others who do not have freedom of movement.
-Those using any medicines that cause drowsiness (sleeping or cold medicine), those who
have been drinking heavily, anyone severely fatigued and anyone else liable to fall asleep.
People with disabilities and people without common sense need to use this product under
supervision.
-Not doing so may result in burn, electrical shock, fire and injury.
IMPORTANT SAFEGUARDS
When using electrical products, especially when children are present, basic safety
precautions should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING
Homtone
USER MANUALHomtone

SAFETY PRECAUTIONS
● This product must be connected to the cold water supply (the inlet water temperature is
about 41-95℉(5~35℃)), otherwise it may cause burns or machine failure.
● When an abnormality or failure occurs, always unplug the plug from the outlet and close
the T-valve to stop water supply.
● Continued use after malfunction could cause a fire, electric shock, heat, short circuit, injury
or water damage.
WARNING
Possible malfunctions:
-The product is cracked or broken.
-The product emits smoke.
-The product makes a strange noise or emits a strange odor.
-The product is abnormally hot.
-Water is leaking from a pipe or the main unit.
Check if the power outlet is grounded
●This product must be well grounded. Only
connect to the dedicated 120V~60Hz, 10A
circuit with ground fault circuit breaker or
ground leakage protector.
●Doing so may cause fire or excessive heat.
●Doing so may cause electrical shock. ●Doing so may cause fire, electrical shock, heat
or short circuit.
●Doing so may cause the product to crack
resulting in injury or water damage.
●May cause fire, electrical shock.
Do not use too many appliances
on one power strip.
●Remove the plug and clean
it with a dry cloth.
Ground Connection
COMPULSORY
After removing the dust from the plug, be
sure to insert the leakage protection plug
firmly into the socket.
Do not use any power supply other than
the one specified.
AC 120V,60Hz
Do not plug or unplug the power plug
with wet hands.
Do not get any water or cleaning solution
on the main unit or power plug.
Do not use a loose or faulty electrical outlet.
PROHIBITED PROHIBITED
Do not spray
water
Do not handle
with wet hands
DANGER To reduce the risk of electrocution:
1. Do not use while bathing.
2. Do not place or store the product where it can fall or be pulled into a tub or sink.
3. Do not place in or drop into water or other liquid.
4. Do not reach for the product when it has fallen into water. Unplug it immediately.
WARNING To reduce the risk of burns, electrocution, fire
or injury to persons:
1. Close supervision is necessary when this product is used by, on, or near children
or invalids.
2. Use this product only for its intended use as described in this manual. Do not use
attachments not recommended by the manufacturer.
3. Never operate this product if it has a damaged cord or plug, is not working
properly, has been dropped or damaged, or has been dropped in water. Return
the product to a service center for examination and repair.
4. Keep the cord away from heated surfaces.
5. Never block the air openings on the product or place it on a soft surface, such as
a bed or couch, where the air openings may be blocked. Keep the air openings
free of lint, hair, and other similar items.
6. Never use while sleepy or drowsy.
7. Never drop or insert any object into any opening or hose.
8. Do not use outdoors. Do not operate where aerosol (spray) products are being
used or where oxygen is being administered.
9. Connect this product to a properly grounded outlet only.
This product should be grounded. In the event of an electrical short circuit, grounding
reduces the risk of electric shock by providing an escape wire for the electrical current.
The plug must be plugged into an outlet that is properly installed and grounded.
Safety Precautions
Grounding Instructions
(Continued)
DANGER - Improper use of the grounding plug can result in a risk of electric
shock. If repair or replacement of the cord or plug is necessary, do not connect the
grounding wire to either flat-head terminal.The wire with insulation have an outer
surface that is green with or without yellow stripes is the grounding wire.
Check with a qualified electrician or serviceman if the grounding wire instructions are
not completely understood, or if in doubt as to whether the product is properly grounded.
This product is factory equipped with a specific electric cord and plug to permit
connection to a proper electric circuit. Make sure that the product is connected to an
outlet having the same configuration as the plug.
No adapter should be used with this product. Do not modify
the plug provided - if it will not fit in the outlet, have the
proper outlet installed by a qualified electrician.
If the product must be reconnected for use on a different type
of electric circuit, the reconnection should be made by qualifi
ed service personnel.
If it is necessary to use an extension cord, use only a three
wire extension cord that
has a three blade grounding plug, and a three-slot receptacle
outlet that will accept the plug on the product.
Replace or repair a damaged cord.
Save these instructions.
Grounding pin
SAVE THESE INSTRUCTIONS
USER MANUALHomtone USER MANUALHomtone

SAFETY PRECAUTIONS
WARNING
Following safety steps should be followed when using this unit, especially children.
1. Do not place the unit where it is likely to fall into bathtube or basin.
2. Never place the unit in water or other liquid.
3. In case the unit fall into water, please unplug the power and never touch the unit by hand.
4. Do not use the unit when taking a bath.
1. Children or people with sickness must be supervised when using the unit.
2. Children should be supervised to ensure that they do not play with the appliance.
3. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
4. Only use the application as stated in this User's Guide.
Warning: To reduce burn, electrical shock, fire or injury, please follow
●Doing so could damage the product and cause injury.
Do not apply strong force, mechanical shock,
step on or stand on the toilet seat, toilet lid or
main unit. Also do not place any heavy object
on the toilet seat, toilet lid or main unit.
PROHIBITED
●These items could damage
the water supply hose and
cause a water leak.
PROHIBITED
When cleaning or maintaining the plastic parts
(main unit etc.) or the water supply hose, use a
kitchen cleaner diluted with water. Do not use
any of the following.
Toilet cleaner, household cleaner, benzene,
paint thinner, powdered cleanser or nylon
scrubbing pads.
●May damage the product.
PROHIBITED
Do not turn the product upside down.
●May damage the product.
PROHIBITED
Please do not close the lid or seat forcefully.
●Frozen water pipes could cause the top unit and the pipes to break, resulting in a water leak.
●Regulate the room temperature to prevent the pipes and hoses from freezing during cold months.
If the electric cord is damaged, avoid danger by having the manufacturer’s
repair department or equivalent specialist replace it.
If a water leak should occur, always close the shutoff valve.
When the ambient temperature is likely to drop to 32°F (0°C) or lower,
prevent damage to the pipes and hoses due to freezing.
COMPULSORY
WARNING
●Doing so may
result in fire,
electrical shock
or short circuit.
●Failure to do so may cause
electrical shock or fire.
●Failure to do so may
cause fire.
●Doing so may cause water leaks.
●Doing so may cause fire, electrical shock, or
short circuit.
●Doing so may cause irritation to the skin and
malfunction.
PROHIBITED
PROHIBITED PROHIBITED
This is an electrical product. Do not install it anywhere water is likely to get on the product or
anywhere with humidity high enough that water is likely to form on the
surface of this product.
When using in the bathroom, please make sure that the power
outlet is waterproof
●Do not get any water or cleaning solution on the main unit or power plug.
●Doing so may cause fire, electrical shock or short circuit.
●Failure to take waterproof measures may cause electric shock or fire
Do not spray water
Do not do anything that may damage the
power cord or power plug.
Do not strike, yank, twist, excessively bend,
damage, alter, or heat the power cords. Also,
do not place anything heavy on, bind or
pinch the power cords.
Always disconnect the power plug from the
outlet before cleaning, maintenance or
inspection.
Keep cigarettes and other open flames
away from the product.
Do not fold or crush the water supply hose;
do not damage by cutting with a sharp object.
Never disassemble, repair or alter.
Only use tap water or potable well water
(underground water).
Do not use seawater.
Unplug the power plug
Prohibit high
temperature
Do not disassemble
USER MANUALHomtone USER MANUALHomtone

PARTS NAMES
PARTS NAMES
Leakage protection plug Lid
Occupied sensor
Control panel
wash nozzle
Dimension:20"x18.5"x4.75"
(517x469x120mm)
●Doing so may cause the main unit to come loose and fall, resulting in injury.
●As this may cause discoloration and yellowing,
unstable seat temperature.
●May result water pollution and skin infection.
●To prevent the product from freezing and damaging
components.
●May cause signal interference.
Caution
PROHIBITED
PROHIBITED
PROHIBITED
Do not expose this product to direct sunlight.
When not using this over an extended period
of time, drain the water out of the main unit
and the water supply hose after closing the
water shutoff valve, and pull the electrical
plug from the outlet.
Do not sit or lean against the lid or control panel.
Do not spill urine on the main unit and nozzle. Please unplug the power plug during a
thunderstorm.
Do not use a power source with a DC or AC
voltage other than 120V.
●May cause personal injury or damage to the product.
●Doing so will cause malfunctions or pink and brown
stains. ●Doing so may cause electrical shock.
●Doing so may cause mulfunction.
When the room temperature in the bathroom
is low, please raise the room temperature.
Keep away from the product when using the
radio.
Do not lift up this product by the toilet seat or lid.
Do not raise the toilet seat or lid while objects are resting on top of the toilet.
USER MANUALHomtone USER MANUALHomtone
7

CAUTION
The power socket must be set according to the following regulations
1.Make sure that a properly grounded (3 prong) outlet has been installed.
2.The length of the power cord is about 3.6ft(1.1m). The location of the power socket should be
as far away from the bathtub as possible to facilitate the installation and removal of this product.
3.It is recommended to use waterproof sockets, do not use extension cords to connect products.
●May cause fire or electrical shock
The toilet dimensions must be within those shown below.
Do not install this appliance on a toilet that does not meet those dimensional requirements.
A.Distance between mounting hole and water tank > 1.5"(40mm)
B.Mounting hole spacing = 5"-7.25"(130-185mm)
C.Distance between mounting hole and ceramic inner ring < 2.38"(60mm)
D.The best distance between the water tank and the outer end of the ceramic
=20"-20.5"(510-525mm)
E.The best size of ceramic inner ring =14.13-15"(360-380mm)
PRODUCT INSTALLATION
PARTS NAMES
Fader button
Filter
Adapters
Mounting plate
Spare parts
1.Installing spare parts 3.User manual
2.Water inlet spare parts
Mounting plate Mounting bolts and nuts
2pcs
T-valve Water supply hose
Adjust slide
2pcs
Bolt guides
2pcs
User Manual
USER MANUALHomtone USER MANUALHomtone

PRODUCT INSTALLATION
CAUTION
PROHIBITED
Be sure to use the mounting plate delivered with this package.
Do not use the product if the main unit is unstable.
●Doing so may cause the main unit to come loose and fall, resulting in injury.
How to mount the plate
How to install the main unit
Mounting bolts and nuts 、
Adjust slide、Bolt guides
Mounting plate
Ceramic mounting holes
Ceramic body
1.Install the expansion rubber plug
into the ceramic mounting hole.
2.Place the mounting plate above
the mounting hole of the ceramic.
3.Mounting bolts and nuts into the
bolt guides and adjust slide.
4.Use mounting bolts and nuts to
lock the adjust slide and the bolt
guides to the mount the plate.
Mounting
plate
1.Align the bottom of the main unit to the
direction of the mounting plate.
2.Push in the direction of the arrow.
When you hear a click, it means
installation is complete.
3.Pull it slightly towards you to make
sure the product will not loosen
after installation.
TIPS：
Tips for mount the plate installation:
First install the mounting plate IN A
LOOSE WAY, install the main unit,
adjust the position, then press the
push rod to remove the unit, lock
the mounting plate firmly. Then you
are done.
Expansion
rubber plug
Confirmation of bathroom space
Preparation before installation
Before installation：
1.Turn off the ceramic water supply system.
2.Press the ceramic flush button to release
the pressure from the water supply pipe.
3.Place a container under the T-valve to hold
excess water.
4.Close the T-valve to stop water supply.
All outline drawings of the ceramic body in
this manual are for reference only.
As shown in the figure below:
Please make sure there is enough space in the bathroom.
Unit:mm/Inch
USER MANUALHomtone USER MANUALHomtone
7.63"(195mm)
10.75"(272mm)
20.5"(517mm)

PRODUCT INSTALLATION
Power supply
Turn on the valve
1.Install the 120V (greater than 15A) socket at a
position above 23.5"(60cm) from the ground.
2.The socket should be installed in a place
where water is not easy to splash.
3.Use a grounded socket.
4.Insert the leakage protection
plug of the product into
the socket.
WARNING
Please connect the power according to the
power supply requirements of the product,
otherwise it may cause product failure;
the plug should be connected to an
effectively grounded socket,
Otherwise, in the case of power failure or
leakage,
it may cause electric shock.
Before turning on the power, valve must be turned on for water supply to the unit.
Valve
CAUTION
When power is turned on,unit self-check system will be activated.
You will hear an alarm under water supply failure. The following steps should be taken then:
Turn off the power-- turn on the valve---power on again.
Power and water supply
Installation diagram
Water supply
Waterproof 10A socket with
ground fault circuit breaker
The installation location of water
and electricity should be set
separately
Wall
T-valve Valve
T-valve
It is recommended to
be larger than 23.5"(60cm)
The water supply source is transferred through the T-valve, one end is connected to the
ceramic water tank to enter the water,the other end is connected to the water supply hose ,
and finally the water supply hose outlet is connected to the adapter of the unit.
1. Applicable water pressure range is
10.87~108.7psi(0.075MPa-0.75MPa)；
2. Applicable water temperature range
is 41-95℉(5~35℃);
3. Water supply hose length 23.5"(60cm);
Valve should be close to the installation
and disassembly position of this product.
4. Use the new hose set included with this
equipment.
Do not reuse an old hose set.
Main unit
Adapters
Connect to water tank
Connect main unit
WARNING
Valve (shut-off/turn-on)
USER MANUALHomtone USER MANUALHomtone

STOP REAR WASH
NIGHT
LIGHT
SEAT
TEMP.
WATER
TEMP.
CHILDRENFRONT WASH
COLD&
HOT SPA WATER PRESSUR
NOZZLE POSITION
●Switch on/off
●Stop rear wash
●Stop front wash
●Stop children cleaning
●Stop nozzle cleaning
Wash alternately with hot
and cold water
Night light turn on or off
Water pressure adjustment
4 different levels
Rear wash
Move cleaning
Front wash
Move cleaning
Suitable for children
STOP/POWER
REAR WASH
FRONT WASH
CHILDREN
WATER TEMP
SEAT TEMP
POSITION
COLD & HOT SPA
NIGHT LIGHT
WATER PRESSURE
NIGHT LIGHT
SENSOR
4 levels optional
4 levels optional
Nozzle position adjustment
4 different levels
Do not block
USER'S MANUAL
Confirmation and trial operation
1.Check power
3.Check rear wash 4.Check front wash
2.Occupied sensor
Confirm that the leakage protection plug is
plugged in tightly. The LED lits up that the
system has been powered on.
If the LED is not on, you can press the
Reset button on the plug to power on.
After power on, you can hear a beep sound
from the system.
The area shown in the figure is the occupied
sensor. Only when the system senses that the
human body is in the sitting state, the system
function start.
Occupied sensor
Press the rear wash button on the armrest
to activate the rear wash function (need to
maintain the seated state)
Press the front wash button on the armrest
to activate the front wash function (need to
maintain the seated state)
REAR WASH FRONT WASH
USER MANUALHomtone USER MANUALHomtone

USER'S MANUAL
CHILDREN
NIGHT LIGHT
STOP
NOZZLE POSITION FORWARD
NOZZLE POSITION BACK
INCREASED WATER PRESSURE
REDUCED WATER PRESSURE
● Long press this button for 3 seconds to activate children mode.
When children mode is on,short press this button (whether seated or not) to start children cleaning:
move cleaning for 1 minute;
Level 1 of water pressure, level 4 of nozzle position and level 2 of water temperature.
When children mode off,short press this button to activate children cleaning when seated.
● Short press this key to turn on/off night light.
● Press and hold this button for 3 seconds to turn on/off the smart night light mode. The factory default
setting is on.
Smart night light mode: night light turns on/off according to the ambient light automatically.
● When cleaning, press this key to stop the cleaning function.
● Short press this button, water pressure, nozzle position, water and seat temperature are same with
previous setting. Long press to activate standby mode when power on.
● Press this key to move the nozzle position forward in rear wash, front wash, and children.
There are 4 levels in total. Each press, the nozzle moves forward 1 level.
● Press this key to move the nozzle position back in rear wash, front wash, and children.
There are 4 levels in total. Each press, the nozzle moves back 1 level.
● Press this key to increase spray pressure in rear wash, front wash, and children.
There are 4 levels in total. Each press increases the cleaning intensity by 1 level.
● Press this key to reduce spray pressure in rear wash, front wash, and children.
There are 4 levels in total. Each press reduces the cleaning intensity by 1 level.
NOZZLE POSITIONNOZZLE POSITION WATER PRESSURE WATER PRESSURE
REAR WASH
● When the seat senses that the human body is seated, press the rear wash button in the stop or other
mode, the buzzer sounds, the rear wash function is turned on, and it ends automatically after 3
minutes.
● During the cleaning process, press this key again to open or close the move cleaning function.
● If the human body leaves the seat after the function is activated, exit the function.
● When the seat senses that the human body is seated, press the front wash button in the stop or other
mode, the buzzer sounds, the feminine cleaning function is turned on, and it ends automatically after 3
minutes.
● During the cleaning process, press this key again to open or close the move cleaning function.
● If the human body leaves the seat after the function is activated, exit the function.
● Press this key to adjust the water temperature. The water temperature is adjustable in 4 levels. When
the LED is off, the water temperature is the tap water temperature. According to the use environment,
the actual water temperature is about 86~105.8℉(30~41℃).
● Press this key to adjust the seat temperature. The seat temperature is adjustable in 4 levels. When
the LED is off, the seat temperature is the room temperature. According to the use environment, the
actual seat temperature is about 86~107.6℉(30℃~42℃).
When the human body is seated, the anti-low temperature scald function is automatically turned on
after 15 minutes, and the seat temperature is reduced to level 1.
During the cleaning process, press this button to start Cold & Hot SPA; press it again to stop Cold &
Hot SPA, and at the same time the temperature returns to the normal cleaning state. 5 seconds cold
water and 15 seconds set hot water alternate.
FRONT WASH
WATER TEMP
SEAT TEMP
COLD & HOT SPA
Function Explanation
Water temperature level Water temperature level
Water temperature Water temperature
level 1
level 2
level 3
level 4
About 91.4℉(33℃)
About 102.2℉(39℃)
About 95℉(35℃)
USER MANUALHomtone USER MANUALHomtone
About 98.6℉(37℃)

Function Description
Seating detection
There is a seat detection switch on the seat ring, which is used to detect whether there is a person
seated. After the human body is seated, it can run the rear wash and front wash functions; when
the rear wash and front wash functions are turned on, the human body leaves the seat, and the
above functions are automatically turned off.
Manual cleaning
When occupied sensor is not activated, long press the nozzle forward key.
The nozzle extends out for manual clean with a toothbrush. When finish,press "Stop" button to
withdraw the nozzle.
Nozzle will also retracts automatically after 3 minutes of cleaning.
Nozzle self-cleaning
Nozzle will be washed automatically before and after each use.
Portable disassembly
The main unit can be disassembled for easy cleaning and maintenance.
Maintenance instructions
● Doing so may result in fire, electrical shock or short circuit.
WARNING
WARNING
Cleaning the main unit
Main unit surface cleaning (daily)
How to manual clean the nozzle How to clean the filter element
COMPULSORY
Unplug the unit before cleaning the surface.This product is an electric appliance.
Be careful not to let water and cleaner seep inside or leakage protection plug.
Long press the nozzle forward key. Nozzle
will extends out for manual cleaning. Clean
gently with a toothbrush or wet cloth. Press
"Stop" button to return the nozzle.
When water flow becomes small during use,
please try to clean the filter element.
Disconnect water inlet hose and the unit
before take off adapter and clean the filter.
● Do not press or pull the nozzle hard,
Doing so may cause damage or malfunction.
Filter element
Turn off T-valve and unplug the unit before
cleaning. Make sure power off and water
supply shut off.
Unplug the power plug
Always turn off the power before
cleaning the unit. Dirt that is difficult to clean can be wiped with
diluted neutral detergent.
Do not wipe this product with toilet cleaner,
household cleaner, benzene, paint thinner,
powdered cleanser or nylon scrubbing brush.
1.Cut off the power 2. Periodically, wipe off the seat unit with a
soft cloth dampened with water.
TIPS：
If the urine attached to the main unit
is not wiped off in time, the main unit
may be dyed pink or brown.
Do not spray water
USER MANUALHomtone USER MANUALHomtone

Troubleshooting
Trouble tips
Trouble
Trouble
Outlet water temperature is too high
Outlet water temperature is too low
Inlet water temperature is too high
Inlet water temperature is too low
Seat temperature is too high
Seat temperature is too low
Water flow is too low
Water flow is too high
Operating buttons failure
Water temperature fourth level LED flashes
Third level LED flashes
Water temperature second level LED flashes
First level LED flashes
Water pressure / Third level LED flashes
Seat temperature fourth level LED flashes
Seat temperature first level LED flashes
Water pressure / First level LED flashes
Water pressure / Fourth level LED flashes
Night light flashes
Trouble tips
Please check Solutions
Cleaning nozzle does not extend
The nozzle does not spray water
Cleansing water pressure is weak
The cleaning water is cold
The seat is cold
The water supply hose bent and
water blocked
The cleaning nozzle blocked
The water filter clogged with foreign
matter
The water temperature set to room
temperature state
The seat temperature set to room
temperature state
Stretch the inlet water supply hose.
Clean the nozzle
Clean the filter
Reset warm water temperature
Reset the seat temperature
Inlet water temperature and outlet
water temperature difference
Anomalies occur, please contact the company's service center or distributor.
●Please do not disassemble, repair and modify this product by yourself
●Doing so may result in fire, electrical shock or short circuit.
WARNING
COMPULSORY
Drain the water and cut off power
1.Cut off power, unplug the plug. 2. Close the T-valve to stop the water supply
to the system.
● Increase indoor temperature
● Close the valve
● Drain the water out of the water supply hose.
Close the valve, loosen and disconnect the water supply hose, to drain water
in the following situations.
- When the water may freeze in some winter area
- Long Periods of Disuse
● Poor water quality may cause dermatitis and product damage.
Remove the water supply hose from the valve
and drain the water out of the water supply
hose.
（If necessary）
3.Press and hold the putter in the
direction of (arrow 1),
then go in the direction of the
operation itself (arrow 2)
Remove unit horizontally.
Putter
When using the product again, please confirm and test run (page 14).
Winter product maintenance
When the ambient temperature is likely to drop to 32°F (0°C) or lower, prevent damage to the
pipes and hoses due to freezing.
Please take measures to prevent freezing：
WARNING
This product can expose you to chemicals including lead(Pb) , which is known to the
State of California to cause cancer. For more information go to:
www.P65Warnings.ca.gov
USER MANUALHomtoneUSER MANUALHomtone

Rated voltage AC120V 60Hz
Instantaneous type
Length≥3.6ft(1.1m) (grounded)
10.87~108.7psi(0.075MPa-0.75MPa (Static water pressure))
1000W( inlet water temperature 59℉(15℃) , inlet water pressure
29psi(0.2 MPa), water out spray，rear wash and seat temperature
set in highest level.)
Rated power
Type of water heater
Power cord
Inlet water pressure
Inlet water temperature
Operating temperature
Outlet temperature
Heater capacity
Safety device
Surface temperature
Heater capacity
Safety device
Damping device
Rear wash
Front wash
The final interpretation of this product belongs to Homtone. The product is subject to change without notice.
CleaningHeated seat
Spray
volume about 0.1~0.16gal/min(400~600ml/min)
Temperature adjustment range: 91.4~102.2℉(33~39℃)
1300W
Flow sensor + water temperature sensor + thermostat +
Temperature fuse
4 levels (room temp.~about 104℉(40℃))
Temperature Sensor + thermostat + fuse
with seat and cover
41-95℉(5-35℃)
41-105.8℉(5-41℃)
45W
23
USER MANUALHomtone
