Honeywell Home PROLTE Series Assembly instructions

PROLTE Series Wireless
Communication Modules
Installation and Setup Guide
General Information
The Communication Modules allow the control panel to communicate with the Central Station via the cellular radio network. The
PROLTE Series includes the following models:
PROLTE-A (US/Canada, AT&T Network)
PROLTE-V (US, Verizon network)
PROTLTE-CN (Canada, Bell network)
The PROLTE Series wireless communications module is intended to provide compatible PRO Series control panels with a cellular
connection with the central monitoring station. The module connects directly to the control panel and is powered via the control panel’s
connection.
Compatible Control Panels:
PROA7PLUS Series – Quick Installation Guide P/N 800-25079 or higher .
PROH8PLUS Series - Quick Installation Guide P/N 800-25093 or higher.
Installing the Module in the PROA7PLUS Series
!
Ensure that all electrical power is removed from the control before installing the module. Unplug the
power supply and disconnect the backup battery.
1. Affix the provided FCC/IC label (P/N 800-25167 for
the PROLTE-A, 800-25168 for the PROLTE-V OR
800-25170 for the PROLTE-CN) on the control’s case
back (refer to Figure 1).
2. If the Control Panel is not powered up proceed to
step 7. If the Control Panel is powered up, disarm the
system and wait 30-60 seconds:
3. Unplug the power supply.
4. Remove the screw securing the control to the wall or
desk mount.
5. Remove the control from the wall or desk mount.
6. Disconnect the battery.
QS-061-V0
CONTAINS MODULE:
FCC ID: RI7LE910NAV2
IC:5131A-LE910NAV2
CONTAINS MODULE: FCC ID: RI7LE910NAV2 IC:5131A-LE910NAV2
CONTAINS MODULE: FCC ID: RI7LE910SVV2
OR
ADEMCO INC. PROA7PLUS SERIES
FCC / ISED STATEMENT
This device complieswith Part 15 of the FCC Rules,
and ISED’s license-exemptRSSs. Operation is subject
to the followingtwo conditions: (1) This Devicemay
not cause harmful interference.(2) This devicemust
accept any interferencereceived, including
interferencethat may cause undesired operation.
FCC ID: CFS8DL-GRIPAIO7
IC: 573F-GRIPAIO7 HVIN: GRIPAIO7
Figure 1. FCC/IC Label Location
7. Remove the left side from the control.
8. Insert the PROLTE Series module into the slot on the
left side of the control as shown in Figure 2 and
ensure the receptacle is securely seated on the
control’s edge connector.
9. Secure with the screw.
10. Install the left side cover.
11. Connect the battery.
12. Install the control on the wall or desk mount.
13. Plug the power supply into a 24-hour, 110VAC
unswitched outlet.
PROLTE-SERIES
MODULE
COVER
MACHINE
SCREW
QS-057-V0
EXT INT
Figure 2. Installing the PROLTE Module

Installing the Module in the PROH8PLUS Series
!
Ensure that all electrical power is removed from the control before installing the module. Unplug the
power supply and disconnect the backup battery and earth ground.
1. Affix the provided FCC/IC label (P/N 800-25167
for the PROLTE-A, 800-25168 for the PROLTE-V
OR 800-25170 for the PROLTE-CN) on the
PROH8PLUS cabinet (refer to Figure 3).
2. If the Control Panel is not powered up proceed to
step 5. If the Control Panel is powered up, disarm
the system and wait 30-60 seconds:
3. Unplug the power supply.
4. Disconnect the battery.
Ensure that all electrical power is
removed from the control panel
before installing the module. Unplug
the power supply and disconnect the
backup battery and earth ground.
BATT+ BATT-
AUX/BELL_OCLED
RUNLED
IB2/ACTIVELED
RESERVEDLED
TRIGGER 2 12V GND TRIGGER 1
BATTERYPOWER LED
NOT
USED
HI
LO
ZONE2
2000
OHMS
EOLR
ZONE1
USEFOR
2-WIRESMOKE
DETECTORS
MAXIMUM
NUMBEROF
2-WIRESMOKE
DETECTORS
ONZONE 1
IS16
ZONE1
2000
OHMS
EOLR
HI HI
LO LO
HI
LO
2000
OHMS
EOLR
ZONE3
2000
OHMS
EOLR
ZONE4
HI HI
LO LO
2000
OHMS
EOLR
ZONE5
2000
OHMS
EOLR
ZONE6
HI HI
LO LO
2000
OHMS
EOLR
ZONE7
2000
OHMS
EOLR
ZONE8
EARTH
GROUND
300-10211
13.5VDC, 1.8A
POWER
SUPPLYTO
10VAC
UNSWITCHED
OUTLET
(24HR)
DC+
DC-
DC+
DC-
ADTHYBWL-Series - Summary of Connections
800-24129 2/18 Rev.A
RJ-45
CONNECTOR
TAMPER
SWITCH
BLACK
RED
RECHARGEABLE BATTERY
(12V,7AH)
SEALED LEAD ACID TYPE
SEE
INSTRUCTIONS**
FORPROPER
GROUNDING
TOINTERNET
CONNECTION
©2018 ADT Security Ser vices
GND
AUX
SLOT3
GENERAL
SLOT 2
WiFi / ZWAVE
SLOT 1
LTE
8-PIN TRIGGER
CONNECTOR
ACPOWER LED
TRIGGER OUTPUT 1:100mA MAX
TRIGGER OUTPUT 2:100mA MAX
AUXOUTPUT LED
NOT USED
24-HRBATTERY
STANDBYREQUIRED
FORFIRE
INSTALLATIONS.
USE12V, 7AH
BATTERYFOR
120mAAUX POWER.
SEEINSTRUCTIONS.
BATTERYCAPACITY FOR EMERGENCY
BURGLARYSTANDBY USE AT LEAST
4HRS.
CHARGINGVOLTAGE 13.8VDC.
MAXIMUMCHARGING CURRENT
650mA.
SEALED LEAD-ACID TYPE. BATTERY
NORMALLYNEED NOT BE REPLACED
FORAT LEA ST THREE YEARS
TODETERMINE TOTAL STANDBY LOAD
ONBATTERY, ADD 100mA TO TOTAL OF
AUX.POWER AND REMOTE TOUCHPAD
CURRENTS
WEEKLYTESTING IS REQUIRED TO ENSURE PROPER OPERATION OF THIS SYSTEM. IN ADDITION, THIS
SYSTEMMUST BE CHECKED BY A QUALIFIED TECHNICIAN AT LEAST ONCE EVERY THREE (3) YEARS.
BLACK:TOUCHPADGND(-)RETURN YELLOW:TOUCHPADIB2A GREEN:TOUCHPADIB2B RED:TOUCHPADPOWER(+)
AUX.PWR
OUTPUT
10.5-13.8VDC
200mAMAX.
(120mAMAX.
FORUL
INSTALLATIONS)
ALLOUTPUTS
AREPOWER
LIMITED.
}
CONNECTIONOF
THEFIREALARM
SIGNALTOA FIRE
ALARMHEAD-
QUARTERSOR
CENTRALSTATION
SHALLBEPERMIT-
TED ONLYWITH
THEPERMISSION
OFTHELOCAL
AUTHORITYHAVING
JURIDICTION.THE
BURGLARALARM
SIGNALSHALLNOT
BECONNECTED
TOA POLICE
EMERGENCY
NUMBER
THISEQUIPMENT
SHOULDBE
INSTALLED
INACCORDANCE
WITHTHENATIONAL
FIREPROTECTION
ASSOCIATION'S
STANDARD72
(NATIONALFIRE
PROTECTION
ASSOCIATION,
BATTERYMARCH
PARK,QUINCY,
MA02169).PRINTED
INFORMATION
DESCRIBING
INSTALLATION,
TESTING,
MAINTENANCE,
EVACUATION
PLANNINGAND
REPAIRSERVICEIS
TOBE PROVIDED
WITHTHIS
EQUIPMENT.
820OHMS
EOLR
ALARM
OUTPUT
10.5–13.8VDC,
2AMAX.(600mA
MAX.FORUL
USAGE,INCLUDING
AUXPOWER)
STEADYFOR
BURGLARY/PANIC,
TEMPORALPULSE
SOUNDINGFORFIRE.
USE702SIREN,OR
12VBELL.SEE
INSTRUCTIONS.
FORBELL
SUPERVISION,AND
CONNECT RESISTOR
DIRECTLYACROSS
EXTERNALSOUNDER.
WTP100
TOUCHPAD
1501Yamato Road
Boca Raton,Florida 33431
ALARM STATUS
CANCEL
PANIC OFF
CODE CHIMEINSTANT
READY
TEST BYPASSMAX
STAYAWAY
2 31
5 64
8 97
0 #
TROUBLE
**FOR COMPLETE INFORMATION SEE INSTRUCTIONS 800-24126 OR HIGHER
- + AB
MAX.ZONE RESISTANCE: (EACH ZONE) 300 OHMS (PLUS EOLR)
(USEEOLR PART NUMBER P4100 PART OF KIT SAHDWR1)
ASSEMBLEDIN MEXICO
ETL Listed
Household Fire
and Burglar
Warning Unit
800-21465 10/15 Rev.A
3091091
Conforms to UL STD 985, 1023, 1635
Classified to ANSI/SIA CP01-2010
Model LCP500-L
800-24232 3/18 Rev A
HONEYWELL GRIP HYBRID CONTROLLER
FCC / IC STATEMENT
This device complies with Part 15 of the FCC Rules, and RSS 210 of IC. Operation is subject to the following two conditions:
(1) This Device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired operation.
FCC ID: CFS8DL-GRIPH
IC: 573F-GRIPH
HVIN: GRIPH
For Patent Information see: www.honeywell.com/patents
Country of Origin: Mexico
PROH8-060-005-V0
CONTAINS MODULE: FCC ID: RI7LE910NAV2 IC:5131A-LE910NAV2
CONTAINS MODULE: FCC ID: RI7LE910NAV2 IC:5131A-LE910NAV2
CONTAINS MODULE: FCC ID: RI7LE910SVV2
OR
Figure 3. FCC/IC Label Location
5. Install the PROLTE Series module on the edge
connector on the PCB (refer to Figure 4). Ensure
the receptacle is securely seated on the edge
connector.
6. Install the retainer and secure the module with
the provided screw.
7. Reconnect the battery.
8. Plug the power supply into a 24-hour, 110VAC
unswitched outlet.
PROLTE
MODULE
PROH8-060-004-V0
GENERAL
WiFi
BATT+ GND
LTE
TX RX GND
TX RX GND
EXT INT
RETAINER
SCREW
Figure 4. Installing the PROLTE Module
Programming
1. Programming associated with the PROLTE Series module is accomplished, as part of the control panel programming. Refer to the
control panel installation and setup guide for additional information.
2. When programming is complete, perform a Communications Test.

Using an External Antenna
If adequate signal strength cannot be achieved with the internal antenna, an external antenna can be employed. An PROLTE-ANT kit
with an adapter cable, clamp, and bracket will be required. A connection diagram with the adapter kit and a typical antenna is provided
with the kit.
IMPORTANT NOTE ABOUT EXTERNAL ANTENNAS
If an external cellular radio antenna is used, the antenna may be installed or replaced ONLY by a professional installer.
To the Installer
PROLTE-A: The external antenna gain shall not exceed 6.63 dBi for 700MHz and 850MHz, 6.0 dBi for 1700MHz and 8.5 dBi for
1900MHz. Under no conditions may an antenna gain be used that would exceed the ERP and EIRP power limits as specified in FCC
Parts 22H, 24E and 27.
PROLTE-V: The external antenna gain shall not exceed 6.94 dBi for 700MHz, 6.0 dBi for 1700MHz and 9.01 dBi for 1900MHz. Under no
conditions may an antenna gain be used that would exceed the ERP and EIRP power limits as specified in FCC Parts 22H, 24E and 27.
PROLTE-CN: The external antenna gain shall not exceed 6.63 dBi for 700MHz and 850MHz, 6.0 dBi for 1700MHz and 8.51 dBi for
1900MHz. Under no conditions may an antenna gain be used that would exceed the ERP and EIRP power limits as specified IC RSS-
130, RSS-132, RSS-133, and RSS-139.
Specifications
PROLTE-A
PROLTE-V
PROLTE-CN
Board Dimensions:.............................. 1.625” W x 2.625” L x 0.3125” D
Current Drain: Idle ............................ 30mA, standby
Transmit .................... 490mA, max transmit
Input Voltage: ..................................... 5V (provided by the control panel)
Environmental
Operating Temperature: ........................ -10°F (-23°C) to 131°F (55°C) (for compliance agency 32°F (0°C) to 120°F (49°C)
Storage Temperature: ........................... -40°F (-40°C) to 158°F (70°C)
Humidity: ............................................... 10 to 90% relative humidity, non-condensing (for compliance agency 0% to 85%)
Antenna................................................ Penta-Band diversity antennas for LTE Supports LTE Bands 12, 13, 5, 4 and 2
External Antenna Kit: .......................... PROLTE-ANT
FEDERAL COMMUNICATIONS COMMISSION ISED STATEMENTS
The user shall not make any changes or modifications to the equipment unless authorized by the Installation Instructions or User's Manual. Unauthorized
changes or modifications could void the user's authority to operate the equipment.
FCC CLASS B STATEMENT
This equipment has been tested to FCC requirements and has been found acceptable for use. The FCC requires the following statement for your
information:
This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer's
instructions, may cause interference to radio and television reception. It has been type tested and found to comply with the limits for a Class B computing
device in accordance with the specifications in Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference in a
residential installation. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• If using an indoor antenna, replace it with a quality outdoor antenna.
• Reorient the receiving antenna until interference is reduced or eliminated.
• Move the radio or television receiver away from the receiver/control.
• Move the antenna leads away from any wire runs to the receiver/control.
• Plug the receiver/control into a different outlet so that it and the radio or television receiver are on different branch circuits.
• Consult the dealer or an experienced radio/TV technician for help.
Responsible Party / Issuer of Supplier’s Declaration of Conformity: Honeywell Home, 2 Corporate Center Dr., Melville, NY 11747, Ph: 516-577-2000.
ISED CLASS B STATEMENT
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
FCC / ISED STATEMENT
This device complies with Part 15 of the FCC Rules, and ISED’s license-exempt RSSs. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference (2) This device must accept any interference received, including interference that may cause undesired
operation.
Cet appareil est conforme à la partie 15 des règles de la FCC et exempt de licence RSS d’ISED. Son fonctionnement est soumis aux conditions
suivantes: (1) Cet appareil ne doit pas causer d’interférences nuisibles. (2) Cet appareil doit accepter toute interférence reçue y compris les interférences
causant une réception indésirable.
!
RF Exposure Warning
The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 7.8 inches (20 cm) from all persons and
must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with FCC and ISED multi-
transmitter product procedures.
Mise en Garde
Exposition aux Frequences Radio: La/les antenne(s) utilisée(s) pour cet émetteur doit/doivent être installée(s) à une distance de séparation
d'au moins 20 cm (7,8 pouces) de toute personne et ne pas être située(s) ni fonctionner parallèlement à tout autre transmetteur ou antenne,
excepté en conformité avec les procédures de produit multi transmetteur FCC et ISEDs.

The product should not be disposed of with other household waste. Check for the nearest authorized collection centers or authorized
recyclers. The correct disposal of end-of-life equipment will help prevent potential negative consequences for the environment and
human health.
REFER TO THE INSTALLATION AND SETUP GUIDE FOR THE CONTROL WITH WHICH THIS DEVICE IS USED FOR WARRANTY INFORMATION
AND LIMITATIONS OF THE ENTIRE SYSTEM.
SUPPORT & WARRANTY
For the latest documentation and online support information, please go to:
https://mywebtech.honeywellhome.com
For the latest warranty information, please go to:
https://www.security.honeywellhome.com/hsc/resources/wa/index.html
For patent information, please go to: www.resideo.com/patent
MyWebTech Warranty Patents
This product manufactured by Resideo Technologies, Inc. and its affiliates.
The Honeywell Home Trademark is used under license from Honeywell International Inc
2 Corporate Center Drive
Melville, New York 11747
© 2019 Resideo Technologies, Inc
www.resideo.com
Ê800-25165AŠ
800-25165 3/19 Rev. A
