Honeywell Home DR65A3000 User manual

INCLUDED IN THIS BOX
OPTIONAL CONTROLS SOLD SEPARATELY
D1D3
D2D4D5
D5
D
Tools required to install DR65A3000 dehumidifier
3/8” hex drive
Drill or duct cutting tool
Wire stripper/cutter
Standard screwdriver
T20 Torx screwdriver
Duct tape
8” round duct and starter collar
1822 gauge, 5 conductor thermostat wire
1/2” diameter drain line (8’)
1/2” drain clamps (2)
3/4” male NPT drain outlet
Options
1/2” drain p-trap (may be required by local code)
Drain pan
Float switch or water sensor (normally closed)
C
A
B
D1
D2
D3
D4
DR65A3000 (1)
MERV 11 Filter (1)
Installation Guide
Prestige IAQ Kit
DG115 IAQ Control
H8908 Manual Dehumidistat
VisionPRO™ Smart or VisionPRO™ RedLINK
H6062 HumidiPRO Digital Humidity Control
T10 Pro Smart
DR65A3000
PROFESSIONAL INSTALLATION GUIDE
GUIDE D’INSTALLATION PROFESSIONNELLE
GUÍA DE INSTALACIÓN PROFESIONAL
A B C
INCLUDED IN THIS BOX
OPTIONAL CONTROLS SOLD SEPARATELY
D1D3
D2D4D5
D5
D
Tools required to install DR65A3000 dehumidifier
3/8” hex drive
Drill or duct cutting tool
Wire stripper/cutter
Standard screwdriver
T20 Torx screwdriver
Duct tape
8” round duct and starter collar
1822 gauge, 5 conductor thermostat wire
1/2” diameter drain line (8’)
1/2” drain clamps (2)
3/4” male NPT drain outlet
Options
1/2” drain p-trap (may be required by local code)
Drain pan
Float switch or water sensor (normally closed)
C
A
B
D1
D2
D3
D4
DR65A3000 (1)
MERV 11 Filter (1)
Installation Guide
Prestige IAQ Kit
TruelAQ
H8908 Manual Dehumidistat
VisionPRO™ Smart or VisionPRO™ RedLINK
H6062 HumidiPRO Digital Humidity Control
T10 Pro Smart
DR65A3000
PROFESSIONAL INSTALLATION GUIDE
GUIDE D’INSTALLATION PROFESSIONNELLE
GUÍA DE INSTALACIÓN PROFESIONA L
A B C
33-00297EFS-05
INCLUDED IN THIS BOX
OPTIONAL CONTROLS SOLD SEPARATELY
D1D3
D2D4D5
D5
D
Tools required to install DR65A3000 dehumidifier
3/8” hex drive
Drill or duct cutting tool
Wire stripper/cutter
Standard screwdriver
T20 Torx screwdriver
Duct tape
8” round duct and starter collar
1822 gauge, 5 conductor thermostat wire
1/2” diameter drain line (8’)
1/2” drain clamps (2)
3/4” male NPT drain outlet
Options
1/2” drain p-trap (may be required by local code)
Drain pan
Float switch or water sensor (normally closed)
C
A
B
D1
D2
D3
D4
DR65A3000 (1)
MERV 11 Filter (1)
Installation Guide
Prestige IAQ Kit
TruelAQ
H8908 Manual Dehumidistat
VisionPRO or Prestige Thermostat
H6062 HumidiPRO Digital Humidity Control
T10 Pro Smart
DR65A3000
PROFESSIONAL INSTALLATION GUIDE
GUIDE D’INSTALLATION PROFESSIONNELLE
GUÍA DE INSTALACIÓN PROFESIONAL
A B C
33-00297EFS-03
INCLUDED IN THIS BOX
OPTIONAL CONTROLS SOLD SEPARATELY
D1D3D2D4D5
D5
D
Tools required to install DR65A3000 dehumidifier
3/8” hex drive
Drill or duct cutting tool
Wire stripper/cutter
Standard screwdriver
T20 Torx screwdriver
Duct tape
8” round duct and starter collar
1822 gauge, 5 conductor thermostat wire
1/2” diameter drain line (8’)
1/2” drain clamps (2)
3/4” male NPT drain outlet
Options
1/2” drain p-trap (may be required by local code)
Drain pan
Float switch or water sensor (normally closed)
C
A
B
D1
D2
D3
D4
DR65A3000 (1)
MERV 11 Filter (1)
Installation Guide
Prestige IAQ Kit
TruelAQ
H8908 Manual Dehumidistat
VisionPRO or Prestige Thermostat
H6062 HumidiPRO Digital Humidity
Control
DR65A3000
PROFESSIONAL INSTALLATION GUIDE
GUIDE D’INSTALLATION PROFESSIONNELLE
GUÍA DE INSTALACIÓN PROFESIONAL
A B C
33-00297EFS-03
DR65A3000
D6
D6
D6
D6
D6
D6
33-00297EFS-09

Installation Checklist
Included in This Box
A DR65A3000 (1)
B MERV 11 Filter (1)
C Installation Guide
Control Options (Sold separately)
D1 Prestige IAQ Kit
D2 DG115
D3 H8908 Manual Dehumidistat
D4 VisionPRO™ Smart
or VisionPRO™ RedLINK
D5 HumidiPRO Digital Control
D6 T10 Pro Smart
Tools Required (Not Supplied)
• 3/8” hex drive
• Drill or duct cutting tool
• Wire stripper/cutter
• Standard screwdriver
• T20 Torx screwdriver
• Duct tape
• 8” round duct and starter
collar
• 1822 gauge, 5 conductor
thermostat wire
• 1/2” diameter drain line (8’)
• 1/2” drain clamps (2)
• 3/4” male NPT drain outlet
Options
• 1/2” drain p-trap (may be
required by local code)
• Drain pan
• Float switch or water sensor
(normally closed)
Liste de vérification
pour l’installation
Inclus dans cette boîte
A DR65A3000 (1)
B Filtre MERV 11 (1)
C Guide d’installation
Options de régulateurs (vendus
séparément)
D1 Nécessaire Prestige IAQ
D2 DG115
D3 Déshumidistat manuel H8908
D4 VisionPRO™ Smart
ou VisionPRO™ RedLINK
D5 Régulateur d’humidité
numérique HumidiPRO
D6 T10 Pro Smart
Outils requis (non fournis)
• Tournevis cruciforme 3/8 po
• Outil de perçage ou de coupe
de conduit
• Dénudeur/coupe-fils
• Tournevis normal
• Tournevis Torx T20
• Ruban adhésif
• Collet de conduit et de départ
rond de 8 po
• Fil de thermostat à 5
conducteurs calibre 1822
• Tuyau de vidange de 1/2 po de
dia. (8 pi)
• Attaches de tuyau de vidange
de 1/2 po (2)
• Sortie de vidange ¾ po NPT
mâle
Options
• SiphonP de vidange d’1/2 po
(peut-être requis par le code
local)
• Bac de récupération
• Flotteur ou capteur d’eau
(normalement fermé)
Lista de verificación
para la instalación
Esta caja incluye
A DR65A3000 (1)
B Filtro MERV 11 (1)
C Guía de instalación
Opciones de control (se venden por
separado)
D1 Kit Prestige IAQ
D2 DG115
D3 Deshumidistato manual H8908
D4 VisionPRO™ Smart
o VisionPRO™ RedLINK
D5 Control de humedad digital
HumidiPRO
D6 T10 Pro Smart
Herramientas necesarias (no se
suministran)
• Impulsor de cabeza hexagonal de
3/8 pulgada (9,5 mm)
• Taladro o herramienta cortante para
conductos
• Alicates o cortadores de cables
• Destornillador estándar
• Destornillador Torx T20
• Cinta para conductos
• Conducto redondo de 8 pulgadas
(20,3 cm) y collar de arranque
• Cable de termostato calibre 18 a 22,
de 5 conductores
• Línea de desagüe de 1/2 pulgada
(12,7 mm) de diámetro (8 pies [2,4 m])
• Abrazaderas de desagüe de
1/2 pulgada (12,7 mm) (2)
• Tubo de desagüe NPT macho de
3/4 pulgada (19,1 mm)
Opciones
• Trampa en P para desagüe de
½ pulgada (12,7 mm) (es posible
que el código local la exija)
• Bandeja para drenaje
• Interruptor del flotador o sensor de
agua (normalmente cerrado)
Warning: Installation must be
performed by a qualified service
technician and must comply with
local codes.
Remove power to the device before
installing or servicing the device.
Failure to connect the device
according to these instructions may
result in damage to the device or
the controls.
INSTALLATION INSTRUCTIONS
BEGIN ON PAGE 2
Avertissement : L’installation doit
être effectuée par un technicien
d’entretien qualifié et conformément
aux codes en vigueur.
Couper l’alimentation vers l’appareil
avant d’installer ou de réparer cet
appareil.
Un raccordement de cet appareil
non conforme à ces instructions
peut entraîner des dommages à
l’appareil ou aux commandes.
INSTRUCTIONS D’INSTALLATION
COMMENCER À LA PAGE 18
Advertencia: La instalación la debe
realizar un técnico de reparación
calificado y debe cumplir con los códigos
locales.
Retire la fuente de energía del dispositivo
antes de instalar o reparar el dispositivo.
Si no conecta el dispositivo según
estas instrucciones, el dispositivo o los
controles se pueden dañar.
LAS INSTRUCCIONES DE INSTALACIÓN
COMIENZAN EN LA PÁGINA 34

DR65A3000 - Read before installing
NEED HELP? For assistance with this product please visit
http://www.customer.resideo.com or call Customer Care toll-free at
18004681502.
?
DR65A3000 Dehumidification System 3300297EFS09
ABOUT YOUR NEW DEHUMIDIFIER
Benefits .......................................2
Maintaining Ideal Humidity ....................2
Setting the Controls............................3
Control Options ................................3
Specifications..................................4
INSTALLATION
Install to Fit Your Application...................5
Plumbing ......................................6
Terminal Description ...........................7
Wiring .......................................7
Checkout .....................................10
MAINTENANCE
Cleaning ......................................11
Technical Description .........................12
Parts List......................................14
5Year Limited Warranty ......................15
• The DR65A3000 is designed to be installed indoors in a space that is protected from rain and flooding.
• Install the unit with space to access the front panel for maintenance and service.
• Avoid directing the discharge air at people, or over the water in pool areas.
• If used near a pool or spa, be certain there is no chance the unit could fall into the water or be splashed,
and that it is plugged into a ground fault interrupt (GFI) outlet.
• To ensure quiet operation, do not place the device directly on the structural supports of the home.
• A drain pan must be placed under the unit if installed above a living area or above an area where water
leakage could cause damage.
1. Never operate a unit with a damaged power cord. If the power cord is damaged it must be
replaced by the manufacturer, its service agent, or similarly qualified person in order to
avoid a hazard.
2. The appliance is not intended for use by persons (including children) with reduced
physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety. Children should be supervised to ensure that they do not play
with the appliance.
!!

About the DR65A3000 Dehumidifier
The DR65A3000 ensures the home is maintained at proper humidity levels through its high performance and
efficiency.
Benefits
• Removes up to 65 pints (30.8 l) of water per day from the indoor
air.
• Built-in humidity control requires no additional wiring to an
external control. Just plug in and go! Choice of external control
options also available for centrally ducted control.
• Electrocoating reduces coil corrosion and helps prevent
refrigerant leaks
• Built-in transfromer circuit breaker.
Maintaining Ideal Humidity
Dew points and relative humidity (RH) affect the way your body senses heat. Higher humidity levels cause
the air to feel much hotter than the actual temperature. When maintained properly, you can run your cooling
equipment less because dehumidified air feels cooler.
Ideal humidity is defined by industry experts* as being between 4060% on an average annual basis.
When indoor humidity exceeds 60%,
the home is more susceptible to mold
and mildew growth. DR65A3000 safe-
guards against excessive humidity in
the home year-round.
*American Society of Heating, Refrigerating
and Air Conditioning Engineers (ASHRAE).
MCR24780
010203040506070809
01
00
OPTIMUM
ZONE
BACTERIA
VIRUSES
FUNGI
MITES
RESPIRATORY
INFECTIONS
ALLERGIC RHINITIS
AND ASTHMA
CHEMICAL
INTERACTIONS
OZONE
PRODUCTION
ASHRAE RECOMMENDED WINTER DESIGN LEVEL
00159095808570756065505540453035202510150
001 4418312316210215110117014011019979593919
59 631031421811411
0117014011018969493919098878
09 221711311901601201001896959391909887868584838
58 801501201997959391909988
878685848382818089787
08 199888786868583828181808979787777767574737
57 0897978787777767675757474737372727
17079696
07 271717171717070707969686867676666656564646
WHAT THE AIR FEELS LIKE
HOW HOT THE HEAT-HUMIDITY COMBINATION MAKES IT FEEL.
EXAMPLE: AIR AT 90ºF WITH 50% RH FEELS LIKE 96ºF TO THE HUMAN BODY!
RELATIVE HUMIDITY (PERCENTAGE)
EXTREME DANGER
EXTREME CAUTION
CAUTION
M27328
DANGER
AIR TEMPERATURE
(DEGREES FAHRENHEIT)
SOURCE: TEMPERATURE - HUMIDIY INDEX WAS DERIVED BY R.G. STEADMAN, JOURNAL OF APPLIED METEOROLOGY, JULY 1979.
DR65A3000 Dehumidification System 33-00297EFS—09
2

Setting the Controls
BUILTIN HUMIDITY CONTROL: An intuitive ‘set and forget’ humidistat is
built into the DR65A3000 to set the humidity level right on the device. Optional
external control wiring is also available. If an external dehumidistat is used, the
on-board dehumidification control must be set to the Off position.
Control Options
The DR65A3000 may be used with one of the following external controls:
HumidiPRO Digital Control
• Manual dehumidification control
• Dehumidifier compressor protection
• RH% and outdoor temperature calibration
• Adjustable high and low range stops (1090%)
DG115 Digital Control
• Automatic adjustments maintain fresh air in home.
• Sensor for displaying outdoor temperature and humidity.
• Advanced ventilation programming includes economizing and extreme
condition shutdown.
• Maintenance and service reminders.
• Controls other indoor air quality equipment.
Manual Dehumidistat and Automatic Ventilation Controls
• Manual humidity control with intuitive comfort settings.
• Automatic W8150 ventilation control to ASHRAE standard, or for
continuous operation.
Prestige™ IAQ Thermostat Kit
• Controls both heating/cooling and ventilation.
• Wireless sensor for displaying outdoor temperature and humidity.
• Advanced ventilation programming includes economizing and extreme
condition shutdown.
• Maintenance and service reminders.
• High definition color display.
• RedLINK™ Wireless technology
VisionPRO™ Smart or VisionPRO™ RedLINK Thermostat
• WiFi™ (TH8321WF1001) or RedLINK™ Wireless technology (TH8321R1001)
• Controls heating/cooling and ventilation.
• Display outdoor temperature and humidity.
• Ventilation programming for time of day or Ashrae standards.
• Optional ventilation lockouts for high/low temp or humidity conditions.
C7089R1013 wireless outdoor sensor for RedLINK model. Internet
weather for Smart model.
T10 Pro Smart Thermostat
• Controls both heating/cooling and ventilation.
• Ventilation programming for time of day or Ashrae standards.
• Optional ventilation lockouts for high/low temp or humidity conditions
using Internet weather when registered to the app.
DR65A3000 Dehumidification System 33-00297EFS—09 3

Specifications
Install DR65A3000 according to National Electric Codes.
Dimensions in inches and (mm):
Product weight: 60lb (27 Kg)
Shipping weight: 68lb (31 Kg)
Shipping dimensions: 16.7” H × 17” W × 32.9” L
Media Filter: MERV 11, 9” H x 11” W x 0.75” D
Drain connection: 3/4” threaded female NPT
connection.
Duct connections: 8” round inlet and outlet. ABS
plastic, compatible for connection to rigid or
flexible ducting with sheet metal screws and/or
tape.
Cabinet: 20 gauge galvanized steel powder-coat
painted.
Insulation: R value 1
Compressor: Rotary-style, 6.1 KBTU
Refrigerant: R410A, 15 oz.
Operating Temp Range (outside cabinet):
34ºF to 135ºF (1.1ºC to 57.2ºC)
Operating Humidity Range: 099% RH
Input ratings
• Electrical input voltage: 120 VAC, 60 Hz
nominal
• Input current: 5.2 A
Output ratings
• Power transformer to R/C terminals:
24 VAC, 0.85 A
• Energy Performance: 2.22 liters (4.7 pints)
per kilowatt hour (KWH)
Standards and approval body
requirements
• ETL Listed per UL 474 and
CSA C22.2 No 92
DryBulb Temp Intake Humidity Capacity (Pints/Day)
80°F (26.7°C) 60% RH 65
70°F (21.1°C) 60% RH 47
60°F (15.6°C) 60% RH 34
Home Size
(square ft) @
8 ft ceiling
Dehumidifier Capacity Required to Maintain Desired Indoor RH*
60% RH Indoor
(pints/day) 50% RH Indoor
(pints/day) 40% RH Indoor
(pints/day)
2080 4954 5558 7178
2600 6168 6572 9097
3120 7582 7986 95110
* Based on extreme climates where outdoor humidity is 7090% RH. For less extreme climates, larger
homes can be adequately served with less capacity. Actual requirements may vary.
Airflow versus external static pressure
(01” water pressure) with collars
attached
0” 160 CFM
0.2” 140 CFM
0.4” 120 CFM
0.6” 100 CFM
M29763
28-1/2 (724)
12 (305)
12
(305)
8 INCH (203)
DIAMETER
DR65A3000 Dehumidification System 33-00297EFS—09
4

Install to Fit Your Application
Ideal when…
• Access to a dedicated central return for
DR65A3000 is available.
• Combined with A/C operation; requires
backdraft damper on the exhaust
port to minimize backdraft when
DR65A3000 is not on but A/C is.
• Providing dry air to a specific area with
an optional 20% open gravity damper
on DR65A3000 supply.
Dedicated Return to Main Supply
SUPPLY
RETURN
AIR HANDLER
DEHUMIDIFIER
M36843
SEPARATE
RETURN
BACKDRAFT
DAMPER
(OPTIONAL)
GRAVITY DAMPER
DR65A3000 Dehumidification System 33-00297EFS—09 5
Flex duct is recommended in connecting to the DR65A3000 collars to reduce vibration noise.
M24745
Electrical requirements:
115 VAC outlet. Ground fault
interrupter (GFI) recommended.
Duct Sizing: Use minimum 8” diameter round for duct
lengths up to 25’ Minimum 10” required for lengths
longer than 25’ Duct branches from the main inlet/
exhaust should be minimum 8” round for 23 branch-
es, and 8” round or larger for 4 branches or more.
Isolated Areas: Effective dehumidification may
require ducting to isolated or stagnant air flow areas.
Main Return to Main Supply Ideal when…
• Running DR65A3000 when not running
A/C.
• Requires damper on the exhaust port to
minimize backdraft when DR65A3000
is not on but A/C is.
• Access to a dedicated central return for
DR65A3000 is not available.
• System fan should run with
dehumidifier for best results.
A
BSUPPLY
RETURN
AIR HANDLER
M36844
BACKDRAFT
DAMPER
DEHUMIDIFIER

Ideal when…
• DR65A3000 will not be ducted to a
forced air HVAC system.
Attach 3/4” male NPT drain nozzle.
Connect 1/2” drain tube to male connection drain outlet.
Secure drain tube to connector with hose clamp.
Run drain hose continuously downhill to an approved drain
or condensate pump.
The drain line must include a water trap to prevent air from
entering or exiting the dehumidifier.
Plumbing
Install to Fit Your Application (continued)
C
DEHUMIDIFIER
M36846
SEPARATE
RETURN
SUPPLY
DR65A3000 Dehumidification System 33-00297EFS—09
6
Dedicated Return to Dedicated Supply
Main Return to Main Return Ideal when…
• Running DR65A3000 with A/C
operation.
• System fan must run with dehumidifier.
• Minimizing discharge air temperature
(DAT) increase is preferred.
• Access to a dedicated central return for
DR65A3000 is not available.
D
SUPPLY
RETURN
AIR HANDLER
M36845
DEHUMIDIFIER

Terminal Description
NOTE: The outer screws on each
terminal block secure the block to the
chassis. They are not used for wiring.
The six terminals for the left hand terminal block are:
FLOAT (2): External low-voltage water sensor or float
switch
DHUM: Compressor and fan operation for
dehumidification
R: 24V output
FAN: Fan activation only for ventilation
C: 24V output
External 24V devices can be powered from R and C
terminals (20VA max.)
The right hand terminal block in the
above figure is used only for interlocking a
DR65A3000 with an equipment fan. The three
terminals are:
Gt: Fan operation from thermostat
Rf: 24V from equipment fan
Gf: Fan operation from equipment fan
Wiring
Wire the DR65A3000
according to the
diagram that applies
to your desired
operation.
Follow this diagram for
ducted operation with the
onboard dehumidistat.
Two wiring terminal blocks are located on the exhaust end of the dehumidifier.
DEHUMIDIFIER
HVAC
THERMOSTAT
GYWRRc
GYWR C
M36847A
Gt
+
+
Rf Gf
DHUM
+
+
RFANC
FLOAT FLOAT
1
IF A FLOAT SWITCH IS NOT USED, THEN JUMPER THE FLOAT TERMINALS.
1
DR65A3000 Dehumidification System 33-00297EFS—09 7
CAUTION: Low voltage hazard.
Can cause equipment damage.
Disconnect HVAC equipment before beginning installation.

Wiring (continued)
Follow this diagram if using an
external manual dehumidistat.
DEHUMIDIFIER
HVAC
THERMOSTAT
GYWRRc
GYWR C
M36848A
DRY
CONTACTS
Gt
+
+
Rf Gf
DHUM
+
+
RFANC
FLOATFLOAT
IF A FLOAT SWITCH IS NOT USED, THEN JUMPER THE FLOAT TERMINALS.
1
1
MECHANICAL
DEHUMIDISTAT
DR65A3000 Dehumidification System 33-00297EFS—09
8
Follow this diagram if using
the HumidiPro Digital
Humidity Controller.
M37492A
C
R
U
U
S
S
24 VAC
(CONSTANT)
RFLOAT
DHUM
FANC
IF A FLOAT SWITCH IS NOT USED, THEN JUMPER
T
HE FLOAT TERMINALS.
1
1

Wiring (continued)
Follow this diagram for ducted
operation with external
ventilation control.
DEHUMIDIFIER
HVAC
THERMOSTAT
GY
W
RRc
GYWR C
M36849A
EARD8TZ
R
C
DAMPER
AUX
REMOTE
W8150A
G
R
C
C
W
G
+
+
Gf
DHUM
+
+
FANC
FLOAT
IF A FLOAT SWITCH IS NOT USED, THEN JUMPER THE FLOAT TERMINALS.
1
1
Gt Rf
HVAC
THERMOSTAT
GYWRRc
M36850A
IF A THERMOSTAT WITH A MECHANICAL SLIDER SWITCH FOR HEAT-OFF-COOL IS USED,
A RELAY MAY BE REQUIRED TO ISOLATE THE G WIRE.
PROGRAM ISU SETTING 60 TO 0 TO FORCE SYSTEM FAN ON WITH DEHUMIDIFICATION CALL.
IF A FLOAT SWITCH IS NOT USED, THEN JUMPER THE FLOAT TERMINALS.
C
R
C
W
Y
G
R
C
SENSOR
SENSOR
SWITCH
W
G
VENT
VENT
DEHUM
DEHUM
HUM
HUM
OUTDOOR
SENSOR
(PROVIDED)
EARD8TZ
DG115
1
3
3
1
DEHUMIDIFIER
2
2
Gt
+
+
Rf Gf
DHUM
+
+
RFANC
FLOAT
DR65A3000 Dehumidification System 33-00297EFS—09 9
Follow this diagram if using
DR65A3000 with a pow-
ered dehumidistat such as
DG115EZIAQ.

Wiring (continued)
Apply power to DR65A3000. Turn the humidity control to a low RH% level to initiate a dehumidification call.
Confirm that the DR65A3000 compressor and fan turn on. The furnace blower will also turn on to circulate
air. This will take up to two minutes. Be sure to turn the control to the desired RH% or to Off when checkout
is complete. Turning the humidity control to Off will turn the DR65A3000 off.
Checkout
U3
U3
U2
U2
U1
U1
DEHUMIDIFIER
Gt
+
+
Rf Gf
DHUM
+
+
RFANC
FLOAT
IN THIS DIAGRAM, U1 CONTROLS THE DR65A FOR DEHUM AND U2
CONTROLS THE DR65A FOR VENTILATION.
INSTALL A JUMPER ON EIM AS SHOWN ONLY
WHEN USING THE DR65
FOR VENTILATION IN ADDITION TO DEHUMIDIFICATION.
IF A FLOAT SWITCH IS NOT USED, THEN JUMPER THE FLOAT TERMINALS.
1
2
12
3
3
EIM
M38419
DR65A3000 Dehumidification System 33-00297EFS—09
10
Follow this diagram if using DR65A3000
with either a Prestige or TH8321R1001
RedLINK VisionPro & EIM.

Cleaning
On an annual basis, perform the following maintenance requirement to ensure the dehumidifier runs at peak
efficiency.
DR65A3000 Dehumidification System 33-00297EFS—09 11
Unplug the dehumidifier before begin-
ning service. Remove magnetic access
panel to access the filter.
Remove filter and replace with new fil-
ter. Reinstall magnetic access panel.
When service is complete, initiate a
call for dehumidification and check
that the compressor and fan activate.
If your thermostat has maintenance
reminders, reset those. All thermostats
listed in this file have optional mainte-
nance reminders.
Check the drain connection and drain
line to ensure it is clear of debris and
sludge. Ensure all hose connections
are secure once maintenance of the
drain lines is complete.
1 2
3 4

Technical Description
DR65A3000 uses a refrigeration system similar to
an air conditioner to remove heat and moisture from
incoming air and add heat to the air that is discharged.
Hot, high-pressure refrigerant gas is routed from the
compressor to the condenser coil. The refrigerant is
cooled and condensed by giving up its heat to the
air that is about to be discharged from the unit. The
refrigerant liquid then passes through a filter drier and
capillary tubing which causes the refrigerant pressure
and temperature to drop. It next enters the evaporator
coil where it absorbs heat from the incoming air and
evaporates. The evaporator operates in a flooded
condition, which means that all the evaporator tubes
contain liquid refrigerant during normal operation. A
flooded evaporator should maintain nearly constant
pressure and temperature across the entire coil, from
inlet to outlet.
Troubleshooting videos are available on the Resideo Pro YouTube channel playlist.
CONDENSER
EVAPORATOR
CAPILLARY
TUBES
ACCUMULATOR
COMPRESSOR
STRAINER/FILTER
DRIER
M27404
Problem Recommended Troubleshooting Steps
No dehumidification. Neither
fan nor compressor run and the
ventilation timer is OFF.
1. Unit unplugged or no power to outlet.
2. Humidity control set too high or defective.
3. Loose connection in internal or control wiring.
4. Defective compressor relay.
5. Defective control transformer.
6. Optional Condensate Pump Safety Switch open.
No dehumidification. Compressor
does not run but fan runs when
there is a call for dehumidification
and the ventilation control is OFF.
1. Defective compressor run capacitor.
2. Bad connection in compressor circuit.
3. Defective compressor overload.
4. Defective compressor.
5. Defrost thermostat open.
6. Optional Condensate Pump Safety Switch open.
Fan runs when there is a call
for dehumidification and the
ventilation control is OFF, but the
compressor cycles on and off too
frequently.
1. Low ambient temperature and/or humidity causing unit to cycle
through defrost mode.
2. Defective compressor overload.
3. Defective compressor.
4. Defrost thermostat defective.
5. Dirty air filter(s) or airflow restricted.
6. Low refrigerant charge, causing defrost control to cycle.
7. Bad connection in compressor circuit. Fan does not run with
fan switch in either position.
Troubleshooting
CAUTION: Servicing the DR65A3000 with its high pressure refrigerant system and high
voltage circuitry presents a health hazard which could result in death, serious bodily injury,
and/or property damage. Service should only be performed by a qualified service technician.
DR65A3000 Dehumidification System 33-00297EFS—09
12

Troubleshooting (continued)
Problem Recommended Troubleshooting Steps
Fan does not run
with ventilation
activated.
Compressor runs
briefly but cycles on
& off with humidity
control turned to
ON.
1. Loose connection in fan circuit.
2. Obstruction prevents fan rotation.
3. Defective fan.
4. Defective fan relay.
5. Defective fan capacitor.
Evaporator
coil frosted
continuously, low
de-humidifying
capacity.
1. Defrost thermostat loose or defective.
2. Low refrigerant charge.
3. Dirty air filter(s) or airflow restricted.
Unit not providing
ventilation. 1. Check control wire connections (check connections at fresh air damper also).
2. Defective fresh air damper.
3. Dirty air intake. Clean outside intake hood.
Unit removes some
water, but not as
much as expected.
1. Air temperature and/or humidity have dropped.
2. Humidity meter and or thermometer used are out of calibration.
3. Unit has entered defrost cycle.
4. Dirty air filter.
5. Defective defrost thermostat.
6. Low refrigerant charge.
7. Air leak such as loose cover or ducting leaks.
8. Defective compressor.
9. Restrictive ducting.
10.Optional Condensate Pump Safety Switch open.
Unit Test to
determine problem: 1. Detach field control wiring connections from main unit.
2. Connect the R and FAN contacts from the main unit together; only the impeller
fan should run. Disconnect the wires.
3. Connect the R and DHUM contacts from the main unit together; the compressor
and impeller fan should run.
4. If these tests work, the main unit is working properly. You should check the
control panel and field control wiring for problems next.
5. Remove the control panel from the mounting box and detach it from the field
installed control wiring. Connect the blue, yellow, and green wires from the
control panel directly to the corresponding colored pigtails on the main unit.
Leave the violet, white, and red wires disconnected!
6. Turn on the humidity control. The compressor and impeller fan should run.
7. If these tests work, the problem is most likely in the field control wiring.
DR65A3000 Dehumidification System 33-00297EFS—09 13

Parts List
Figure Reference Base and Accessory Parts Part Number
1Dehumidifier DR65A3000/U
2Motorized Ventilation Damper EARD8TZ
38” Bypass Damper CPRD8
4 Filter 50049537005
5Replaceable fuse T2.5A L 250V (NOT SOLD BY RESIDEO)
14
M36840
For reference only.
23
LL’
FUSE
COM
COM’
TRANSFORMER
M38433
FLOAT
FLOAT
DEHUM
DEHUMIDISTAT
24 VAC
VAN
24 VAC COM
COMPRESSOR
RELAY
VRISTOR
1
2
3
4
5
6
7
8
9
Gt
Rf
Gf
COMPRESSOR
COMPRESSOR
CAPACTOR
DEFROST
SWITCH
FAN
6
8
7
1
2
4
3
0
FAN
CAPACTOR
FAN RELAY
4
8
12
13
14
5
DR65A3000 Dehumidification System 33-00297EFS—09
14

Resideo warrants this product to be free from defects in workmanship or materials, under normal use and
service, for a period of five (5) years from the date of first purchase by the original purchaser. If at any time
during the warranty period the product is determined to be defective due to workmanship or materials,
Resideo shall repair or replace it (at Resideo’s option).
If the product is defective,
(i) return it, with a bill of sale or other dated proof of purchase, to the place from which you purchased it; or
(ii) call Resideo Customer Care at 18004681502. Customer Care will make the determination whether the
product should be returned to the following address: Resideo Return Goods, 1985 Douglas Dr. N., Golden
Valley, MN 55422, or whether a replacement product can be sent to you.
This warranty does not cover removal or reinstallation costs. This warranty shall not apply if it is shown by
Resideo that the defect was caused by damage which occurred while the product was in the possession of a
consumer.
Resideo’s sole responsibility shall be to repair or replace the product within the terms stated above. RESIDEO
SHALL NOT BE LIABLE FOR ANY LOSS OR DAMAGE OF ANY KIND, INCLUDING ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES RESULTING, DIRECTLY OR INDIRECTLY, FROM ANY BREACH OF ANY
WARRANTY, EXPRESS OR IMPLIED, OR ANY OTHER FAILURE OF THIS PRODUCT.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so this limita-
tion may not apply to you.
THIS WARRANTY IS THE ONLY EXPRESS WARRANTY RESIDEO MAKES ON THIS PRODUCT. THE DURATION
OF ANY IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE, IS HEREBY LIMITED TO THE FIVE YEAR DURATION OF THIS WARRANTY. Some
states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply
to you.
This warranty gives you specific legal rights, and you may have other rights which vary from state to state.
If you have any questions concerning this warranty, please write Resideo Customer Care, 1985 Douglas Dr,
Golden Valley, MN 55422 or call 18004681502.
5Year Limited Warranty
DR65A3000 Dehumidification System 33-00297EFS—09 15

Resideo Technologies Inc.
1985 Douglas Drive North, Golden Valley, MN 55422
1-800-468-1502
33-00297EFS—09 M.S. Rev. 08-20 | Printed in United States
www.resideo.com
© 2020 Resideo Technologies, Inc. All rights reserved.
The Honeywell Home trademark is used under license from Honeywell International, Inc. This product is manufactured by Resideo Technologies, Inc. and its affiliates.
Tous droits réservés. La marque de commerce Honeywell Home est utilisée avec l’autorisation d’Honeywell International, Inc.
Ce produit est fabriqué par Resideo Technologies, Inc. et ses sociétés affiliées.
Todos los derechos reservados. La marca comercial Honeywell Home se utiliza bajo licencia de Honeywell International, Inc.
Este producto es fabricado por Resideo Technologies, Inc. y sus afiliados.

?
Système de déshumidification DR65A3000 33-00297EFS—09
BESOIN D’AIDE? Pour obtenir de l’aide sur ce produit, prière de visiter le site
http://www.customer.resideo.com ou d’appeler le service d’assistance
à la clientèle au 18004681502.
DR65A3000 - Lire avant l’installation
À PROPOS DU NOUVEAU DÉSHUMIDIFICATEUR
Avantages ........................................18
Maintien d’une humidité idéale ...................18
Réglage des commandes .........................19
Options de régulateurs............................19
Spécifications.....................................20
INSTALLATION
Installation en fonction de l’application ...........21
Raccordement ....................................22
Description des bornes ...........................23
Câblage ..........................................23
Vérification........................................26
ENTRETIEN
Nettoyage.........................................27
Description technique ............................28
Liste des pièces ...................................30
Garantie limitée de 5 ans..........................31
• Le modèle DR65A3000 est destiné à être installé à l’intérieur dans un lieu protégé de la pluie et des
inondations.
• Installer l’unité en assurant le dégagement nécessaire pour l’accès au panneau pour la maintenance et
l’entretien.
• Éviter de diriger l’air d’évacuation vers les personnes ou sur l’eau des piscines.
• Si le produit est utilisé près d’une piscine ou d’un spa, veiller à garantir que l’unité ne peut pas tomber
dans l’eau ou être éclaboussée, et qu’elle est raccordée à un disjoncteur de fuite à la terre.
• Pour garantir un fonctionnement silencieux, ne pas placer l’unité directement sur les supports de
structure du bâtiment.
• Un bac de récupération doit être placé sous l’unité si elle est installée au-dessus d’une zone habitée ou
d’une zone où une fuite d’eau pourrait causer des dommages.
1. Ne jamais faire fonctionner l’appareil avec un cordon d’alimentation endommagé. Si le
cordon d’alimentation est endommagé, il doit être remplacé par le fabricant, son agent du
service, ou une personne qualifiée afin d’éviter les situations dangereuses.
2. Cet appareil n’est pas conçu pour une utilisation par des personnes (incluant les
enfants) ayant des capacités physiques, sensorielles ou mentales réduites, ou manquant
d’expérience et de connaissance à moins d’avoir reçu la supervision ou les instructions
concernant l’utilisation de l’appareil par une personne responsable de leur sécurité. Les
enfants devraient être supervisés pour s’assurer qu’ils ne jouent pas avec l’appareil.
!!

À propos du déshumidificateur DR65A3000
Le DR65A3000 permet de maintenir les niveaux d’humidité adéquats dans toute la maison grâce à sa haute
performance et son efficacité.
Avantages
• Retire jusqu’à 30,8 litres (65 chopines) d’eau par jour de l’air
intérieur.
• La commande d’humidité intégrée ne nécessite aucun câblage
supplémentaire à un régulateur externe. Il suffit de brancher et
c’est parti! Choix d’options de régulateurs externes également
disponible pour une régulation centrale.
• L’électrodéposition réduit la corrosion sur le serpentin et aide à
prévenir les fuites de réfrigérant.
• Coupe-circuit du transformateur intégré.
Maintien d’une humidité idéale
Les points de rosée et d’humidité relative (HR) affectent la manière dont le corps ressent la chaleur. Des
niveaux d’humidité élevés causent une perception de chaleur accrue par rapport à la température réelle.
S’il est correctement entretenu, l’équipement de refroidissement peut être activé moins souvent car l’air
déshumidifié semble plus frais. L’humidité idéale est définie par les experts de l’industrie* comme se situant
entre 40 et 60 % sur une base annuelle moyenne.
Lorsque l’humidité intérieure
dépasse 60 %, l’habitation est plus
susceptible à la moisissure. L’unité
DR65A3000 protège de l’humidité
excessive tout au long de l’année.
*Société américaine des ingénieurs en
chauffage, refroidissement et climatisation
(ASHRAE).
MFCR24780
010203040506070809
01
00
ZONE
OPTIMALE
BACTÉRIES
VIRUS
CHAMPIGNONS
ACARIENS
INFECTIONS
RESPIRATOIRES
RHINITES ALLERGIQUES
ET ASTHME
INTERACTIONS
CHIMIQUES
PRODUCTION
D’OZONE
TAUX D’HUMIDITÉ TYPE EN HIVER
RECOMMANDÉ PAR L’ASHRAE
00159095808570756065505540453035202510150
001 4418312316210215110117014011019979593919
59 631031421811411
0117014011018969493919098878
09 221711311901601201001896959391909887868584838
58 801501201997959391909988
878685848382818089787
08 199888786868583828181808979787777767574737
57 0897978787777767675757474737372727
17079696
07 271717171717070707969686867676666656564646
NOTRE PERCEPTION DE LA TEMP
É
RATURE DE L’AIR
NOTRE PERCEPTION DE LA CHALEUR COMBINÉE À L’HUMIDITÉ
EXEMPLE : À 90 °F ET 50 % D’HUMIDITÉ RELATIVE, LA TEMPÉRATURE PERÇUE PAR NOTRE CORPS ATTEINT 96 °F!
HUMIDITÉ RELATIVE (POURCENTAGE)
DANGER EXTRÊME
PRUDENCE EXTRÊME
PRUDENCE
MF27328
DANGER
TEMP
É
RATURE DE L’AIR
(DEGRÉ FAHRENHEIT)
SOURCE : INDICE DE TEMPÉRATURE-HUMIDITÉ DÉRIVÉ PAR R.G. STEADMAN, JOURNAL OF APPLIED METEOROLOGY, JUILLET 1979.
Système de déshumidification DR65A3000 33-00297EFS—09
18
Other manuals for DR65A3000
1
Table of contents
Languages:
Other Honeywell Home Dehumidifier manuals
Popular Dehumidifier manuals by other brands

HI-E DRY
HI-E DRY 195 Installation, operation & service instructions

Amana
Amana D030M owner's manual

Innovative Dehumidifier
Innovative Dehumidifier IW-25 Installation & operation manual

Malmbergs
Malmbergs MFD20-522R2 instruction manual

DriSteem
DriSteem RL-31 Installation, operation and maintenance manual

HTW
HTW X2 owner's manual
