User Guide
Smart Programmable
Thermostat
RET97E5D Wi-Fi Series
HOLD
M37771

69-2803ES—05 ii
In the box you will find
• Thermostat
• Wallplate (attached to
thermostat)
• Screws and anchors
• Quick Start Guide
• Thermostat ID Card
• Wire labels
• User Guide
• Quick Reference Card

Welcome
Congratulations on your purchase of a
smart programmable thermostat. When
registered to Total Connect Comfort
Solutions, you can remotely monitor and
control the heating and cooling system
in your home or business—you can stay
connected to your comfort system wherever
you go.
Total Connect Comfort is the perfect
solution if you travel frequently, own a
vacation home, a business or manage an
Investment property or if you are simply
looking for peace of mind.

69-2803ES—05 2
This thermostat works with common 24 volt systems such as forced air,
hydronic, heat pump, oil, gas, and electric. It will not work with millivolt systems,
such as a gas fireplace, or with 120/240 volt systems such as baseboard
electric heat.
MERCURY NOTICE: Do not place your old thermostat in the trash if it contains
mercury in a sealed tube. Contact the Thermostat Recycling Corporation at
www.thermostat-recycle.org or 18002388192 for information on how and
where to properly and safely dispose of your old thermostat.
NOTICE: To avoid possible compressor damage, do not run air conditioner if
the outside temperature drops below 50°F (10°C).
Need help?
Visit honeywellhome.com/wifi-thermostat or call 18557335465 for assistance
before returning the thermostat to the store.

69-2803ES—05 3
About your new thermostat
Controls and Home screen
quick reference .................................................. 5
Preset energy-saving schedules................. 6
Installation
Installing your thermostat............................. 8
Connecting to your WiFi network...........26
Registering your thermostat online ........31
Operation
Setting the clock..............................................36
Setting the fan .................................................37
Selecting system mode ................................38
Adjusting program schedules....................39
Overriding schedules temporarily............40
Overriding schedules permanently.........41
Unregistering thermostat............................42
Disconnecting WiFi......................................43
Special features...............................................45
Setting functions and options...................48
Appendices
Frequently asked questions .......................55
Troubleshooting ..............................................61
Limited warranty.............................................67
Table of contents

69-2803ES—05 4
Features of your WiFi thermostat
With your new thermostat, you can:
• Connect to the Internet to monitor and control your heating/cooling system
• View and change your heating/cooling system settings
• View and set temperature and schedules
• Receive alerts via email and get automatic upgrades
Your new thermostat provides:
• Smart Response Technology
• Compressor protection
• Heat/cool auto changeover

5 69-2803ES—05
Controls and home screen quick reference
Once your WiFi thermostat is installed, it will display the home screen. Portions of
this display will change depending on how you are viewing it.
The screen lights when you press any button. It stays lit for 8 seconds after you
complete changes.
M31586
HOLD
Set up messages
describe steps in the
WiFi set up process
WiFi status
Set clock, day,
or schedule
Select fan
settings
Additional
settings
Temperature
adjustment buttons
Permanent override
button
Select system
mode

69-2803ES—05 6
Preset energy-saving schedules
This thermostat is pre-set with energy-saving program settings for four time periods.
Using the default settings can reduce your heating/cooling expenses. Savings may
vary depending on geographic region and usage. To change the settings, see pages
3941.
Default Heat Settings Default Cool Settings
WAKE
6:00 am 70 °78 °
LEAVE
8:00 am 62 °85 °
RETURN
6:00 pm 70 °78 °
SLEEP
10:00 pm 62 °82 °

7 69-2803ES—05
Setting up your thermostat
Setting up your WiFi programmable thermostat is easy. It is preprogrammed and
ready to go as soon as it is installed and registered.
Install your thermostat.
Connect your home WiFi network.
Register online for remote access.
Before you begin, you may want to watch a brief installation video.
Use the QR Code®at the front of this guide, or go to
honeywellhome.com/support
2
3
1

69-2803ES—05 8
Installing your thermostat
You might need the following tools to install this thermostat:
• No. 2 Phillips screwdriver
• Small pocket screwdriver
• Pencil
• Level (optional)
• Drill and bits (3/16” for
drywall,
7/32” for plaster) (optional)
• Hammer (optional)
• Electrical tape (optional)
1 Switch OFF power to your
heating/cooling system.
Important! To protect your
equipment, switch OFF the power to
your heating/cooling system at the
breaker box or the system switch.
or
M31535
Circuit breaker
box
Heating/cooling
system power
switch

9 69-2803ES—05
C
C
MCR33823
If you have an older thermostat with
a sealed mercury tube, turn to page
2 for proper disposal instructions.
Terminal
designation
Installing your thermostat
2 Remove old thermostat faceplate
and leave wires connected.
2a Take a picture of the wire
connections for later reference.
2b If no wire is connected to a
terminal labeled C or no C terminal
exists on the old thermostat,
view the Alternate Wiring videos
at honeywellhome.com/wifi-
thermostat
Important! C wire is required
and is the primary power source
for your thermostat. Without a
C wire, your thermostat will not
power up.

69-2803ES—05 10
Installing your thermostat
3 Label wires.
Do not label by wire color. Use
the supplied sticky tags to label
each wire as you disconnect
it. Label wires according to
the old thermostat terminal
designations, not by wire color.
Note: If no tag matches a wire
terminal label, write the terminal
label on a blank tag.
4 Remove wallplate.
Remove the old wallplate from
the wall after all wires have been
labeled and disconnected.
Blank sticky
tags
Sticky tags
Terminal
designation
C
C
MCR31537

11 69-2803ES—05
Installing your thermostat
5 Separate WiFi thermostat and its
wallplate.
On your new thermostat, grasp the
finger holds on the top and bottom
of the wallplate with one hand and
the thermostat (front) with the other
hand. Pull pieces apart.
Thermostat
Wallplate (back view)
Finger holds
M33856
PULL HERE
TO REMOVE
PULL HERE
TO REMOVE

69-2803ES—05 12
Installing your thermostat
6 Mount wallplate for WiFi thermostat.
Mount your new wallplate using screws and
anchors included with the thermostat.
If necessary:
Drill 3/16-in holes for drywall.
Drill 7/32-in holes for plaster.
Note: You may be able to use your existing
wall anchors. Hold the wallplate up to the
existing anchors to check for alignment.
Wallplate
MCR33857

13 69-2803ES—05
Important! The WiFi thermostat requires a C wire to operate. The C, or common, wire
brings 24 VAC power to the thermostat. Many older mechanical or battery operated
thermostats do not require a C wire. If you don’t have a C wire, try:
• Looking for an unused wire that is pushed into the wall. Connect that wire to C
and check that it is connected to the 24 VAC common at your heating/cooling
system.
Note: Not all heating/cooling systems label the 24 VAC common C. Check your
system manual or contact the manufacturer to find out which terminal is the 24 VAC
common.
View the Alternate Wiring videos at honeywellhome.com/wifi-thermostat
Wiring
For conventional heating/cooling systems (natural gas, oil or electric furnace, air
conditioner), see page 14. See “Glossary” on page 64 for further definition.
For a heat pump system, see page 15. See “Glossary” on page 64 for further
definition.
Installing your thermostat

69-2803ES—05 14
Installing your thermostat
Wiring (conventional system)
7A Wire the WiFi thermostat to your conventional
system.
a Starting with the C Wire, match the sticky tag on
the wire to the terminal labels.
You must have a C wire. See page 13.
b Loosen screw, insert wire on inside edge
of terminal, then tighten screw.
c Verify wire is firmly secured by gently
pulling on wire.
d Repeat steps a–c for all other wires.
e Push any excess wire back into the wall
opening after all wires are installed.
f Continue to page 20.
Labels don’t match? See alternate
wiring key on pages 1617.
W2 GWYR RCK Y2 C
MCR33878
Y
HEAT PUMP
CONVENTIONAL
AUX/E GO/B YRRCK LC
C
G
W
R
Remove metal
jumper only if you
have both Rand RC
wires
Note: The wiring for your
application might be
different from the wiring
shown above.

15 69-2803ES—05
Installing your thermostat
Wiring (heat pump system only)
7B Wire WiFi thermostat to your heat pump.
a Starting with the C Wire, match the sticky tag on the wire to the terminal
labels.
You must have a C wire. See page 13.
b Loosen screw, insert wire on inside edge
of terminal, then tighten screw.
c Verify wire is firmly secured by gently
pulling on wire.
d Repeat steps a–c for all other wires.
e Push any excess wire back into the wall
opening after all wires are installed.
f Continue to page 20.
Note: If old thermostat has separate wires on AUX
and E, place both wires into the E/AUX terminal.
If old thermostat has wire on AUX with a jumper to E,
place wire on E/AUX terminal. No jumper is required.
Labels don’t match? See alternate
wiring key on pages 1819.
MCR33877
G
O
Y
R
HEAT PUMP
AUX/E GO/B YRRCK LC
Aux
Note: The wiring for your
application might be different
from the wiring shown above.

69-2803ES—05 16
Installing your thermostat
Alternate wiring (conventional system)
Use this if your wire labels don’t match the terminal labels.
Note: You must have
a C wire or equivalent.
See page 13.
See key to 1– 3
on page 17.
Y2
R
4M
V
RHY1
H
W1F
RYWG
RC
W2
W2 GWYRRC
Y2 C
MCR33885
CONVENTIONAL
C
B
C1
X
K
1
2
3

17 69-2803ES—05
Installing your thermostat
Do not use Kterminal. For future use.
If your old thermostat had both Rand RH wires, remove metal jumper.
Connect the Rwire to the RC terminal, and the RH wire to the Rterminal.
Remove metal jumper connecting Rand RC only if you must connect both
Rand RC.
Alternate wiring key (conventional system)
2
3
1

69-2803ES—05 18
Installing your thermostat
Alternate wiring (heat pump system only)
Use this if your wire labels don’t match the terminal labels.
Note: You must have
a C wire or equivalent.
See page 13.
See key to 1– 7
on page 19.
MCR33886
EAUX
XW FH
B
W1
W2
X2
LOG
F
C
R
VRM
VY1
B
X
RY
RC
HEA
T PUMP
AUX/E GO/B YRRCK LC
1
2
3
4
7
6
5
4
