MS2421 / MS2422 / MS2431
Bar Code Scanner
Installation and User’s Guide

Disclaimer
Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other
information contained in this document without prior notice, and the reader should in all cases consult HII to
determine whether any such changes have been made. The information in this publication does not
represent a commitment on the part of HII.
HII shall not be liable for technical or editorial errors or omissions contained herein: nor for incidental or
consequential damages resulting from the furnishing, performance, or use of this manual.
This document contains propriety information that is protected by copyright. All rights reserved. No part of
this document may be photocopied, reproduced, or translated into another language without the prior
written consent of HII.
© 2006 - 2011 Honeywell International Inc. All rights reserved.
Web Address: www.honeywellaidc.com
Trademarks
Metrologic, MetroSelect, MetroSet2, StratosSCAN, StratosSPHERE, StratosSYNC, StratosSCOPE,
StratosSWAP, and StratosSCHOOL are trademarks or registered trademarks of Metrologic Instruments,
Inc. or Honeywell International Inc.
Microsoft, Windows, and Windows 95 are trademarks or registered trademarks of Microsoft Corporation.
IBM is a trademark of International Business Machines Corporation.
Other product names mentioned in this manual may be trademarks or registered trademarks of their
respective companies and are the property of their respective owners.

iii
Table of Contents
Introduction
Manual Scope........................................................................................................................................ 1
Product Overview................................................................................................................................... 1
Base Kit Components ............................................................................................................................ 2
Optional Accessories ............................................................................................................................. 2
Replacement Parts ................................................................................................................................ 3
General Precautions .............................................................................................................................. 4
Design Specifications
Operational ............................................................................................................................................ 5
Mechanical............................................................................................................................................. 5
Electrical ................................................................................................................................................ 6
Environmental........................................................................................................................................ 6
Base Model Characteristics
MS2421/MS2431 Components .............................................................................................................. 7
MS2421 Scanner Dimensions................................................................................................................ 8
MS2431 Scanner Dimensions................................................................................................................ 8
MS2421/MS2431 Connector Panel........................................................................................................ 9
MS2421/MS2431 Caution and Serial Number Labels .......................................................................... 10
MS2422 Components .......................................................................................................................... 11
MS2422 Dimensions............................................................................................................................ 12
MS2422 Connector Panel .................................................................................................................... 12
MS2422 Caution and Serial Number Labels ........................................................................................ 13
Installation
Quick Installation Outline ..................................................................................................................... 15
Site Requirements ............................................................................................................................... 15
Vertical Clearance.......................................................................................................................... 15
Ventilation and Spacing.................................................................................................................. 15
Service Access............................................................................................................................... 15
Power Installation........................................................................................................................... 16
Checkout Counter Layout Consideration........................................................................................ 16
Unpacking the Unit............................................................................................................................... 17
Installing the Unit in the Counter .......................................................................................................... 18
MS2421 Mounting Diagram............................................................................................................ 18
MS2422 Mounting Diagram............................................................................................................ 19
MS2431 Mounting Diagram (Two Point Support) ........................................................................... 20
MS2431 Mounting Diagram (Three Point Support)......................................................................... 21
Cable Installation (Interface Specific) ................................................................................................... 22
RS232............................................................................................................................................ 22
Full Speed USB.............................................................................................................................. 24
IBM OEM.................................................................................................................................. 24
USB Serial Emulation Mode ..................................................................................................... 25
Keyboard Emulation Mode ....................................................................................................... 25
RS485............................................................................................................................................ 26
Cable Installation (Secondary Honeywell Scanner).............................................................................. 28
EAS Deactivation ................................................................................................................................. 30

iv
Scanner Operation
Scan Zone ........................................................................................................................................... 31
Wake Activation Area (Photocell LED Output) ..................................................................................... 33
Changing the Wake Area Sensitivity Level..................................................................................... 34
Audible Indicators ................................................................................................................................ 35
Visual Indicators .................................................................................................................................. 36
Failure Modes...................................................................................................................................... 37
Diagnostic Indicator Display; Error Codes............................................................................................ 38
Power Save Modes.............................................................................................................................. 41
Beeper Options and Button Functions ................................................................................................. 42
Beeper Tone and Volume Control.................................................................................................. 42
The Multi-Function Button .............................................................................................................. 42
Startup................................................................................................................................................. 43
Power-Up Test Mode........................................................................................................................... 43
Configuration Mode ............................................................................................................................. 43
Maintenance
Horizontal Scan Window Replacement ................................................................................................ 45
Daily Maintenance ............................................................................................................................... 46
Troubleshooting
Troubleshooting Symptom / Solution Chart.......................................................................................... 47
Scanner and Cable Terminations
Scanner Pinout Connections................................................................................................................ 51
Cable Connector Configurations .......................................................................................................... 53
Regulatory Compliance
Safety .................................................................................................................................................. 55
EMC .................................................................................................................................................... 56
Limited Warranty ..................................................................................................................................... 59
Patents ..................................................................................................................................................... 61
Index......................................................................................................................................................... 63
Customer Support ................................................................................................................................... 65
Technical Assistance ........................................................................................................................... 65
Product Service and Repair ................................................................................................................. 66

1
Introduction
Manual Scope
This guide provides information on the installation, setup and operation of the MS2421, MS2422, and
MS2431 scanner only models. If the MS2421or MS2431 scanner has been integrated with a scale, please
refer to the Scale Addendum for detailed instructions on the appropriate cable connections, communication
specifications and calibration procedures required by the scale manufacturer and local Weights and
Measures Authorities.
Product manuals are also available for download in Adobe®Acrobat®file format at
www.honeywellaidc.com.
Product Overview
MS2421, MS2422 and MS2431 scanner models are designed to meet the demanding needs of high
volume supermarket and point-of-sale applications. With advanced features like 5-sided, 360° scanning,
5400 scans per second, a comprehensive scan zone and advanced decoding software, this high
performance series of in-counter scanner/scale ready products guarantees fast customer checkouts with
minimal operator fatigue and stress. The MS2421, MS2422, and MS2431 scanners are equipped with a
multitude of standard features including:
StratosSCAN™ – 5-sided, 360° scanning that minimizes product orientation
StratosSPHERE™ – Decoding software that reads poor quality and damaged bar codes
StratosSYNC™ – Horizontal and vertical scanning zones operate independently from one another
GS1 DataBar Decoding – Decodes GS1 DataBar, GS1 DataBar Limited, and GS1 DataBar
Expanded symbologies
Flash ROM – Upgrade latest software enhancements on site
Powered Aux Port – Connect hand-held scanner for large or bulky items
Scale Ready Model – The MS2421/MS2431 model is designed for custom scale integration
Loud Speaker – 3 volume/7 tone settings can be heard in all environments
Easy Configuration – Windows®based utility or simple bar code setup
Fully Automatic – “No touch” wake up from power save modes
EAS Deactivation – Electronic Article Surveillance (EAS) included
Field Replaceable Vertical Window – Quickly remove vertical window for cleaning or replacement
StratosSCOPE™ – Visual diagnostic indicator for easy to read feedback on scanner condition
StratosSWAP™ – Modular optics engine technology – small, pre-aligned, field replaceable modules
StratosSCHOOL™ – Operator training software

2
Base Kit Components
Part # Description
MS24xy-105Nz Bar Code Scanner
x 2 MS2420
3 MS2430; 508 mm (20.0")
y 1 Scanner Only, Scale Ready – Compact
2 Scanner Only – Sub-Compact
z D Diamonex Horizontal Window
S Sapphire Horizontal Window
00-02407 MetroSelect®Configuration Guide
00-02034 MS2xxx Stratos Series Configuration Addendum
00-05311 MS2421 / MS2422 / MS2431 Bar Code Scanner Installation and User’s Guide
Guides also available for download at www.honeywellaidc.com.
Other items may be ordered for the specific protocol being used. To order additional items, contact the
dealer, distributor or call the customer service department.
Optional Accessories
Part # Description
57-57210x-N-3 RS232 Interface Cable, Straight Cord with Short Strain Relief
57-57212x-N-3 RS485Port 9 Cable, Straight Cord
57-57201x-N-3 USB Full Speed Communication Cable, Straight Cord, Type A (Non-Locking)
Connector
57-57227x-N-3 USB Full Speed Communication Cable, Straight Cord, Locking 12V Plus-Power™
Type A
57-57008x-N-3 Aux Program Cable, Straight Cord with Short Strain Relief
57-57099x-3 LSO RS232 PowerLink AUX Cable with built in power jack, Straight Cord
57-57099x-3-12 RS232 AUX, Straight Cord, 3.7 m (12') (for 95xx, 5145 and 7580 scanners)
CBL-420-300-C00 RS232 AUX, Coiled Cord (for 1200, 1300 and 1900 Series scanners)
52-52511x EAS cable, 24"
52-52556x EAS cable, 6'
Applicable for IBM®Host applications.

3
Optional Accessories
Part # Description
AC to DC Power Transformer - Regulated
Output: +5V @ 3.8A
+12V @ 0.8A
46-00980-R 120V United States and Canada
46-00981-R 220V – 240V Continental European
46-00982-R 220V – 240V United Kingdom
46-00985-R 220V – 240V United Kingdom with 3 Amps fuse
46-00983-R 220V – 240V China
46-00984-R 220V – 240V Australia
Replacement Parts
Part # Description
Caution
Window types (Diamonex and Sapphire) are not interchangeable due to laser safety
and/or scanner performance differences.
To change window type, the scanner must be returned to the manufacturer for
reconfiguration.
46-00233 Diamonex Platter – Compact
46-00296 Diamonex Platter – Compact with Platter Lift Handle
46-00234 Diamonex Platter – Sub-Compact Size
46-01087 Diamonex Platter – 508 mm
46-00235 Sapphire Platter – Compact
46-00297 Sapphire Platter – Compact with Platter Lift Handle
46-00236 Sapphire Platter – Sub-Compact Size
46-01086 Sapphire Platter – 508 mm
Other items may be ordered for the specific protocol being used. To order additional items, contact the
dealer, distributor or call the customer service department.

4
General Precautions
The following are some general precautions to remember when handling the MS2421/MS2422/MS2431
scanner.
Do not turn the unit upside down with the platter in place.
Do not press on the window in the platter or the
vertical window frame.
Platter Removal
No hardware or tools are required to remove the platter
(see Figure 3). Refer to the Maintenance section of
this manual for additional information on platter
replacement.
Note: See caution statement on page 3.
Finger Recesses
There are two finger recess areas provided to assist
when lifting the scanner. Rest both thumbs against the
vertical window frame for added stability when lifting the
unit by the finger recesses.
Figure 4
Figure 2
Figure 1
Figure 3

5
Design Specifications
Operational
Light Source: VLD 650 nm
Peak Laser Power: <1.5 mW
Horizontal Depth of
Field:
0 mm - 100 mm (0"- 4") for 0.33 mm (13 mil) Bar Code
Vertical Depth of Field: 0 mm - 216 mm (0"- 8.5") for 0.33 mm (13 mil) Bar Code
Scan Speed: 5400 Scan Lines per Second
No. of Scan Lines: 54 (38 Horizontal / 16 Vertical)
Motor Speed: 6000 / 6000 RPM (Horizontal / Vertical)
Min Bar Width: 0.114 mm (4.5 mil)
Scan Zone: 360°
Decode Capability: All Standard 1-D Bar Codes, GS1 DataBar, GS1 DataBar - Expanded, and
GS1 DataBar Limited Bar Codes
System Interfaces: RS232, Aux RS232, RS485, and USB
Print Contrast: 35% Minimum Reflectance Difference
No. Characters Read: Up to 80 data characters. Maximum number will vary based on symbology
and density.
Beeper Operation: 7 Tones or No Beep; 3 Volume Settings
Indicators (LED):
Blue Laser ON, Ready to Scan
Blue Flash Good Read, Decoding
Mechanical
Length Width Tower Height
MS2421 L x W x H: 399 mm (15.7") 292 mm (11.5") 130 mm (5.12")
MS2422 L x W x H: 353 mm (13.9") 292 mm (11.5") 130 mm (5.12")
MS2431 L x W x H: 508 mm (20.0") 292 mm (11.5") 130 mm (5.12")
Depth (Below Counter): 100 mm (3.9"), All Models
Weight (with Platter):
MS2421: 7.20 kg (16 lbs.)
MS2422: 6.80 kg (15 lbs.)
MS2431: 8.20 kg (18 lbs.)
Specifications are subject to change without notice.

6
Electrical
Voltage Supply: 4A @ +5V / 0.8A @ +12V
Power: Operating: 11.9 Watts
Standby: 3.25 Watts
Current: Operating: 1.7A @ 5.2V / 0.2A @ 12V
Standby: 0.6A @ 5.2V / 0.07A @ 12V
Current Limits on
Integrated Scale and/or
Scale Display:
Do not exceed maximum current of 12V @ 0.7A / 5V @ 0.2A
DC Transformers: Class I; 5.2VDC @ 3.8A; 12VDC @ 0.8A
For Regulatory Compliance Information, refer to pages 55 - 57.
Environmental
Operating Temperature: 0°C to 40°C (32°F to 104°F)
IP Rating: IP 55
Light Levels: 4842 Lux (450 footcandles)
Storage Temperature: -40°C to 60°C (-40°F to 140°F)
Humidity: 5% to 95% Relative Humidity, Non-Condensing
Contaminants: Sealed to resist airborne particulate contaminants.
Ventilation: None Required
Specifications are subject to change without notice.

7
Base Model Characteristics
MS2421/MS2431 Components
Figure 5. MS2421/MS2431 Components (MS2421 Shown.)
Item No. Description of Item
1 Volume/Tone Multi-Function Button (see page 42)
2 Blue LED Indicators (see page 36)
3 Speaker
4 Finger Recesses for Lifting
5 High Impact Window Frame / Vertical Window (Laser Aperture)
6 Replaceable Stainless Steel Platter with Diamonex or Sapphire Horizontal Window
(Laser Aperture)
7 Flow Direction Indicators
8 Platter Support Bumpers (see page 45)
9 Optional Product Weight Flip Up Bar / Platter Lift Handle
(Option provided with scale ready MS2421-105x or MS2431-105x models only.)
10 Diagnostic Indicator Display (see page 38 for Error Codes)
11 DC Power, Scale, and EAS Connectors (see page 9)
12 System Interface Connection Area (see page 9)
13 Optional Leveling Feet (Option provided with scale ready MS2421-105x/MS2431-105x
models only.)
Note: Scanner label information can be found on page 10.

8
MS2421 Scanner Dimensions
Figure 6. MS2421 Dimensions
MS2431 Scanner Dimensions
Figure 7. MS2431 Dimensions

9
MS2421/MS2431Connector Panel
Figure 8. MS2421/MS2431 Connector Panel
*Scale ready MS2421/MS2431 models supply additional connectors for scale and display communication
cabling. The use of these connections is dependent on the specific manufacturer of the scale being
integrated. Please refer to the custom Scale Installation Guide for detailed instructions on the appropriate
cable hookups and calibration procedures for local Weights and Measures authorities.
Specifications are subject to change without notice.

10
MS2421/MS2431 Caution and Serial Number Labels
Figure 9. MS2421/MS2431 Label Locations (Top) and Examples (Bottom)
Caution: To maintain compliance with applicable standards, all circuits connected to the imager must
meet the requirements for SELV (Safety Extra Low Voltage) according to EN/IEC 60950-1.
To maintain compliance with standard CSA C22.2 No. 60950-1/UL 60950-1 and norm
EN/IEC 60950-1, the power source should meet applicable performance requirements for a
limited power source.

11
MS2422 Components
Figure 10. MS2422 Components
Item No.
Description of Item
1 Volume/Tone Multi-Function Button (see page 42)
2 Blue LED Indicators (see page 36)
3 Speaker (see page 35)
4 Finger Recesses for Lifting (Located Under Platter)
5 High Impact Window Frame / Vertical Window (Laser Aperture)
6 Replaceable Stainless Steel Platter with Diamonex or Sapphire Horizontal Window
(Laser Aperture)
7 Flow Direction Indicator
8 Platter Support Bumpers (see page 45)
9 Diagnostic Indicator Display (see page 38)
10 DC Power, Scale, and EAS Connectors (see page 12)
11 System Interface Connection Area (see page 12)
Note: Scanner label information can be found on page 13.

12
MS2422 Dimensions
Figure 11. MS2422 Dimensions
MS2422 Connector Panel
Figure 12. MS2422 Connectors
Specifications are subject to change without notice.

13
MS2422 Caution and Serial Number Labels
Figure 13. MS2422 Label Locations (Top) and Examples (Bottom)
Caution: To maintain compliance with applicable standards, all circuits connected to the imager must
meet the requirements for SELV (Safety Extra Low Voltage) according to EN/IEC 60950-1.
To maintain compliance with standard CSA C22.2 No. 60950-1/UL 60950-1 and norm
EN/IEC 60950-1, the power source should meet applicable performance requirements for a
limited power source.

14

15
Installation
Quick Installation Outline
The following is a quick preview of the steps required for first time installations. Each item is discussed in
detail later in this section.
•Determine clearance, ventilation, and service access requirements.
•Determine checkout counter layout taking into account package flow, cable routing, and power
requirements.
•Choose the mounting option which provides the best cable/power access and unit stability.
•Unpack the unit.
•Make the appropriate countertop cutouts and install all support brackets.
•Place the unit in the counter.
•Install the platter.
•Follow the steps under the correct interface to connect the cables and power supply.
•Configure the unit for the correct interface.
Site Requirements
Before installing your MS2421/MS2422/MS2431 bar code scanner, please consider the following items.
Vertical Clearance
A minimum clearance height of 5.25" from the checkout counter surface is needed for the vertical 'hood' on
all of the scanner models.
Ventilation and Spacing
The MS2421/MS2422/MS2431 models have a die-cast housing to dissipate heat allowing the unit to
operate without a ventilation fan. The temperature surrounding the unit is recommended not to exceed
40°C (104°F). There should be adequate convection and minimal heat producing equipment in close
proximity of the unit. A cooling fan with a filter is recommended if there will be a conveyor motor or other
heat producing equipment close to the unit that will create a high temperature environment.
Service Access
When routing and installing the cable(s) and power supply, make sure you leave access so that these
components may be swapped easily without the need to remove the unit from the checkout counter.
When changing the StratosSWAP optics engine modules, removing the unit completely from the checkout
counter is recommended.
