Honeywell AlarmNet 7847i-E Assembly instructions

7 78 84 47 7i i- -E E
I
In nt tr ra an ne et t C Co om mm mu un ni ic ca at ti io on n M Mo od du ul le e
Installation and Setup Guide
800-19325 2/15 Rev B
Requires
Compass Version
1.5.8.54A (or higher)
for IP Downloading

Glossary
AES – Advanced Encryption Standard
DHCP – Dynamic Host Configuration Protocol. Provides a mechanism for allocating IP
addresses dynamically so that addresses can be reused when hosts no longer need them.
DNS – Domain Name System. A distributed hierarchical naming system used to resolve
domain names (e.g., www.yahoo.com) into numerical IP addresses (e.g., 204.17.25.1.).
DSL – Digital Subscriber Line
Gateway IP Address – A gateway (sometimes called a router) is a computer and/or software
used to connect two or more networks (including incompatible networks) and translates
information from one network to the other. The Gateway IP address is the IP address for
the gateway.
IP – Internet Protocol
IP Address – A unique number consisting of four parts separated by periods, sometimes
called a "dotted quad.," for example: 204.17.29.11, assigned to every computer/workstation
connected to the Internet. IP numbers can be "static" (assigned and unchanging) or
"dynamic," assigned via DHCP at each and every startup.
ISP – Internet Service Provider
LAN – Local Area Network
MAC Address – The hardware address of a device connected to a network.
NAT – Network Address Translation
PPP – Point-to-Point Protocol
PPPoE – Point-to-Point Protocol over Ethernet
Subnet Mask – A Subnet is a portion of a network that shares a network address with other
portions of the network, and is distinguished by a subnet number. The Subnet Mask is a
32-bit address mask used in IP to indicate the bits of an IP address that are being used for
the subnet address.
TCP/IP – Transmission Control Protocol / Internet protocol

i
Table of Contents
•••••••••••••••••••••••••••••••••••••••••••••••••
Glossary .......................................................................................................................................................................2
SECTION 1: General Information................................................................................................................ 1-1
Introduction .............................................................................................................................................................. 1-1
System Features..................................................................................................................................................... 1-1
About Private Network Application....................................................................................................................... 1-1
Encryption ................................................................................................................................................................ 1-2
Installation Key........................................................................................................................................................ 1-2
Recovery Mode ....................................................................................................................................................... 1-2
Modes of Operation................................................................................................................................................ 1-2
ECP Mode ................................................................................................................................................. 1-2
Zone Trigger Mode................................................................................................................................... 1-3
Module Supervision Features ............................................................................................................................... 1-3
Specifications .......................................................................................................................................................... 1-3
Mechanical ................................................................................................................................................ 1-3
Electrical .................................................................................................................................................... 1-3
Ethernet...................................................................................................................................................... 1-3
Environmental ........................................................................................................................................... 1-3
Programming for UL864 Compliance .................................................................................................................. 1-4
SECTION 2: Mounting and Wiring ................................................................................................................ 2-1
Mounting the 7847i-E ............................................................................................................................................. 2-1
Wiring the 7847i-E .................................................................................................................................................. 2-2
Wiring for ECP Mode ............................................................................................................................... 2-2
Wiring for Zone Trigger Mode................................................................................................................. 2-2
Wiring the Fault Relay ............................................................................................................................. 2-3
Power Connections and Options.......................................................................................................................... 2-4
Ethernet Connections............................................................................................................................................. 2-4
Initial Power-Up Sequence...................................................................................................................... 2-4
SECTION 3: Programming the 7847i/7847i-E .............................................................................................. 3-1
General Information................................................................................................................................................ 3-1
Using a 7720P Programming Tool......................................................................................................... 3-1
Using the Control Panel Programming Mode....................................................................................... 3-2
Programming Conventions...................................................................................................................... 3-2
ECP Mode Programming....................................................................................................................................... 3-2
ECP Status Codes ........................................................................................................................................... 3-7
Alternative Zone Trigger Mode ............................................................................................................................. 3-7
Zone Trigger Mode................................................................................................................................... 3-7
Alternative Mode Programming ............................................................................................................................ 3-7

7847i-E Installation and Setup Guide
ii
Exiting Programming Mode................................................................................................................................. 3-16
Setting Factory Defaults.............................................................................................................................. 3-16
SECTION 6: Registration .......................................................................................................................... 4-1
Registering the 7847i-E ......................................................................................................................................... 4-1
Using the Tamper Switch........................................................................................................................ 4-1
Using the Programming Tool.................................................................................................................. 4-1
SECTION 5: Programmer Keyboard Commands ........................................................................................ 5-1
Programmer Keyboard Commands ..................................................................................................................... 5-1
System Status Displays........................................................................................................................... 5-2
Running Network Diagnostics on the 7847i-E.................................................................................................... 6-1
Possible Errors Running Network Diagnostics .................................................................................... 6-2
Appendices................................................................................................................................................... A-1
Appendix A : Summary of LED Operation ..........................................................................................................A-1
Status Display Operation.........................................................................................................................A-1
Network Connectivity Display .................................................................................................................A-3
Mode and Status LED Display................................................................................................................A-4
Mode and Status Indicator Switch .........................................................................................................A-4
Appendix B : Central Station Messages..............................................................................................................B-1
Appendix C : IP Downloading ...............................................................................................................................C-1
General Information .................................................................................................................................C-1
Direct Wire Setup .....................................................................................................................................C-1
Appendix D : 7847i-e Code Updating ..................................................................................................................D-1
General Information .................................................................................................................................D-1
Procedure ..................................................................................................................................................D-1
Summary....................................................................................................................................................D-2
Summary of Connections Diagram…………………………………………………………..……….Inside Back Cover

1-1
SECTION 1
General Information
Introduction
The 7847i-E Intranet Communication Module transports alarm signals via a Private LAN.
This easy-to-install device provides sophisticated data security and communicates directly to
a 7810PC or 7810iR-ent Intranet receiver (herein referred to as the “receiver”) in a private
network application. In addition to alarm reporting, the 7847i-E provides
upload/downloading capability via a Private LAN.
NOTE: The communicator is evaluated for Level A3 Active Channel Security and P3 Passive
Channel Security. If used in zone trigger mode or for Passive Channel Security, a Listed
DACT must be used and connected to the MX8000 central station receiver.
System Features
Basic features of the 7847i-E include:
•Easy CAT-5 10 BaseT connection to a hub or router
•Installs behind firewalls without compromising network security
•Supports dynamic or static IP addressing
•Quick connection to compatible Honeywell series control panels
•Simple programming using a 7720P programming tool
•Reports fire, burg, and status messages via a Private LAN
•Allows uploading and downloading of control panel data over aPrivate LAN
About Private Network Application
The 7847i-E transmits signals within a private network application to a 7810PC or
7810iR-ent receiver. Up to 300 7847i-E Intranet Communication Modules may be routed to a
single receiver.
For receivers:
MX8000: UL/ULC. can be used for secondary reporting in ECP. Required for Zone Trigger or
Passive Channel Security.
7810ir-ENT UL/ULC. primary receiver
7810PC - UL commercial burg only
Figure 1. 7810PC or 7810iR-ent/7847i-E Private LAN Block Diagram

7847i-E Installation and Setup Guide
1-2
Encryption
The 7847i-E and receiver support private key encryption. Private key encryption means that
both the sender and the receiver know the KEY used to encrypt the data. Each device
produced by Honeywell is loaded with a globally unique identifier called a MAC number, and
a large random number or KEY. When a device contacts the receiver it sends the MAC
number in the clear followed by the message that is encrypted using the KEY data.
The communication devices use 256 bit AES (Rijndael) encryption (which is required for
certain government installations). The AlarmNet-i AES Encryption Software Module
Version 1.0 contained in the Honeywell products has NIST approval. Listings for this
approval can be found at http://csrc.nist.gov/groups/STM/cavp/documents/aes/aesval.html
Certification number 979.
Installation Key
At installation a 10-digit installation key needs to be programmed into every device in the
network. This 10-digit key should be the same for all devices used in the Private LAN mode.
The communication device uses this key to encrypt its private key when it registers with the
receiver. This way its MAC and private key can be learned. This installation key is used for
registration purposes only and is not used for supervision or alarm transmission. Once a
device is registered the receiver will have a copy of the 7847i-E’s factory KEY. From this
point on the unique factory key is used for communications.
Recovery Mode
In the event of a failure of the receiver requiring the replacement of the hardware or the
erasure of its memory, the receiver supports a Recovery Mode. In Recovery Mode, the
receiver is programmed with the same 10-digit installation key. When a 7847i-E
communicates with the receiver and is found not to exist in its database, a special response is
sent back to the 7847i-E requesting it to re-register itself. The 7847i-E then registers using
the 10-digit installation key. When all accounts have been recovered, Recovery Mode can be
turned off to provide better control of registration.
Modes of Operation
UL/ULC
Only ECP Mode has been approved for ULC installations.
ECP and Zone Trigger have been approved for UL installations
The 7847i-E provide four modes of operation so they can be used with various types of control
panels, as summarized below:
ECP Mode
•This mode is for use with Honeywell controls that support communication device (LRR)-ECP
communication
•The module connects to the control’s keypad terminals and provides 2-way communication
with the control using ECP messaging
•The control treats the module as a communication (LRR) device, so program the control
accordingly, including setting the module’s proper device address
•Panel-generated reports are sent in Contact ID format
•The module also supports two hardwire zone trigger inputs (zones 6 and 7) – these report in
ADEMCO High-Speed format

Section 1: General Information
1-3
Zone Trigger Mode
•This mode is for use with controls that do not support communication device-ECP
communication nor 4204 Relay Modules
•The module provides six input zones
•Each zone can be configured for +V, -V, or EOLR triggering
•Each zone can be programmed for inverted operation, delayed reporting, and restoral
reporting
•Zones should use EOL resistors and programmed as V+ inverted or V- Inverted so a cut line
results in an alarm.
•Zone 1 and 2 inputs can distinguish between pulsed and steady signals and report fire or
burglary alarms respectively
•Zone 1 and 2 inputs can also be programmed to report LYNX panic (if used with LYNX
control)
•Zone 1 and 2 are not for use as fire/burglary zones by UL
•Reports are sent in ADEMCO High-Speed format
Module Supervision Features
The 7847i-E provides the following types of supervision and module fault detection:
•Network communication failure: In the event the receiver does not hear a supervisory
message from the module within a specified time (“Supervision” option), it notifies the central
station of a communication failure.
•Fault output: Terminal 11 can serve as a fail-safe trigger for module fault conditions.
If used, the fault relay will trip when the following conditions occur; tamper*, loss of network
connectivity*, the device is not registered.
*Alarm reporting for the noted condition must be enabled for it to trigger the fault relay.
•Cover tamper condition (“Tamper Rpt” option).
Specifications
Mechanical
Dimensions: 8.4" x 8.0" x 1.5"
Weight: 1 lb.
Electrical
Input Power: 12VDC
Current Drain: 88mA peak
Radio Fault Output: Open collector
Input Trigger Levels: (V+) 2V – 14V, (V-) 0V – 1V
Ethernet
Network Standard: IEEE 802.3u compliant
Data Rate: 10Base-T / 100Base-T with auto detect
Ethernet Cable: Cat. 5 (min.), MDI/MDI-X auto crossover
Environmental
Operating temperature: 0º to +49ºC
Storage temperature: –40º to +70ºC
Humidity: 0 to 95% relative humidity, non-condensing
Altitude: to 10,000 ft. operating, to 40,000 ft. storage

7847i-E Installation and Setup Guide
1-4
Programming for UL864 Compliance
The 7847i-E provides a programmable supervision features that allows the system to meet the UL864
Commercial Fire requirements. These requirements are in the following table.
This product incorporates field-programmable software. In order for the product to comply with the requirements in the
Standard for Control Units and Accessories for Fire Alarm Systems, UL 864, certain programming features or options
must be limited to specific values or not used at all as indicated below.
Program feature or option
Possible settings
Settings permitted in UL 864
Supervision
24 Hours •CN 90 Sec
•1 Hour •75 Sec
•6 Min •None
•3 Min •30 Day
•90 Sec
Must be set to:
•3 minutes for UL Comm Fire/Burg or
ULC Active Channel Security.
•24hrs for ULC Passive channel
security
Old Alarm Time
•10 Minutes •4 Hours
•15 Minutes •8 Hours
•30 Minutes •12 Hours
•1 Hour •24 Hours
•2 Hours
•4 Hours
•8 Hours
•12 Hours
•24 Hours
Must be 10 minutes.
IP Fault Time
[00-99] Must be one (01) minute.
Flt Rel ON
[Y], [N] Must be set to "Y."
ECP MODE PROGRAMMING
Zn6 Trigger Type
Zn7 Trigger Type
•(V+)
•(V–)
•(EOLR)
V+ must be set as inverted and V- as
non-inverted
Delay Zn6
Delay Zn7
[01-15]
[00] = no delay
Must be 00
ZONE TRIGGER MODE
PROGRAMMING
Zn1 Trigger Type
to
Zn8 Trigger Type
•(EOLR)
•(V+)
•(V–)
V+ must be set as inverted and V- as
non-inverted
Delay Zn1
to
Delay Zn8
[01-15]
[00] = no delay
Must be 00

2-1
SECTION 2
Mounting and Wiring
Mounting the 7847i-E
UL/ULC
For Commercial Fire the communicator must be mounted to a single or
double gang box.
The 7847i-E must be mounted indoors. To mount the unit, see Figure 2 and complete the
following steps:
1. Unpack the unit and detach the case back by pushing up into the two tabs located at the
bottom of the 7847i-E module with the blade of a screwdriver while pulling the case back
and case front apart.
2. Locate the case back over the mounting surface such that the opening in the case back is
aligned with the wire/cable access opening (in the mounting surface) while passing the
wires/cable through the opening in the case back, or through the removable knockouts
located on the bottom of the back cover.
3. Secure the case back to the mounting surface using four screws (supplied).
4. When all wiring is completed, attach the case front of the unit to the case back. Attach
the top first then press the bottom section inward until it snaps into place securely.
Secure bottom using cover securing screw (supplied) as shown below, (required for UL
installations).
5. Twist and remove cap from handle (supplied) and discard handle. Insert cap in top hole
of case back, as shown.
Figure 2. Mounting the 7847i-E

7847i-E Installation and Setup Guide
2-2
Wiring the 7847i-E
Unshielded, 22 AWG cable is recommended for 7847i-E power/data wires.
ULC
For ULC Household Fire and Burglary installations, use ECP wiring only.
NOTE: The unit is to be mounted with all interconnecting wires between the Listed Control panel
and communicator less than 3 feet in length and contained within the same room. All
interconnecting wiring must be installed in rigid or in flexible metal conduit if run in the walls or
ceiling. A UL/ULC Listed router must also be used.
Wiring for ECP Mode
Most Honeywell ADEMCO control panels support ECP data communication, (e.g., VISTA-
10P, VISTA-15P, VISTA-20P, LynxR-I, VISTA-128BP/BPT and VISTA-250BP/BPT and the
VISTA-128FBP/FBPT and VISTA-250FP/FBPT). However, there are some panels that do
not. Check the Installation and Setup Guide for the control panel you are using to see if it
supports ECP communication.
Connect the 7847i-E to a compatible Honeywell VISTA control panel's ECP terminals, in
parallel with keypads and other peripheral devices, VIP module, etc. Wire length/gauge
limitations are the same for the module as they are for keypads and other peripheral devices.
To wire the module for ECP communication, see Figure 3and do the following:
Table 1. Wiring connections for ECP mode
7847i-E
Control
Terminal 3 V+
+12 V Aux
Terminal 4 GND
Ground
Terminal 5 Data In
Data Out
Terminal 6 Data Out
Data In
Figure 3. Wiring a Vista for ECP Mode
Wiring for Zone Trigger Mode
To trip the zone on the 7847i-E in V+ trigger mode, the positive triggering voltage from the
control panel must be within 2.0V-14V.
Trigger levels above this range may cause permanent damage to the unit.
Trigger levels below this range result in unreliable operation.
To trip the zone on the 7847i-E in V- trigger mode, the negative triggering voltage must be
less than 1.0V.
Connect a wire from the triggering source (bell output, voltage trigger, etc.) of the control
panel to the zone input of the module, and connect a common ground between the module
and control panel.

Section 2: Mounting and Wiring
2-3
Figure 4. Wiring Zone 1 Input for a
Positive (+) Trigger
Figure 5. Wiring Zone 1 Input for a Negative
(-V) Trigger
Notes for Trigger Mode with Non- Honeywell Controls:
•Commercial Fire: a) Assign one zone (3-7) between the 7847i-E and triggering device for
each of the following conditions: alarm, trouble, & supervisory events. See Summary of
Connections diagram on inside back cover for wiring detail and refer to the control panel’s
instructions for specific control panel wiring terminals.
b) The control panel used must be UL 864 Listed and evaluated for central station or
proprietary service.
•For voltage trigger mode, the voltage trigger must be within the range of 2.4Vdc - 12.6Vdc
for positive triggers.
•Power must be supplied by a separate power supply with sufficient backup battery Listed
1481 [for fire] or UL603 [for Burg] and wiring must be in conduit in accordance with local
codes. UL 1481 Power supply output must be 12Vdc Regulated.
Figure 6. Wiring the 7847i-E Zone
1 Input for EOL Supervised
N.O./N.C. Triggers
Wiring the Fault Relay
You may wire and program the communicator's fault output trigger for fail-safe mode (see
the question "FLT REL ON Y/N").
To sense a communicator fault at the control panel, see the figure below and make the
following connections. Include the proper EOL resistor required by the control panel.
UL/ULC
For commercial burglary a 24hr zone must be assigned, and the fault relay
wired to that zone
Figure 7. Wiring the Fault Relay to a Control Panel Zone

7847i-E Installation and Setup Guide
2-4
Power Connections and Options
Primary power for the 7847i-E is provided by the auxiliary power output of the control panel
9.6V –13.8V, typical, or other external power source.
When calculating the total load on the auxiliary power output of the control panel, 20mA
must be budgeted for the 7847i-E. Under normal operating conditions, the unit will not pull
more than 20mA; however, it will draw 75mA during a transmission.
Connect the wires from the (+) and (–) terminals of the DC power source to terminals V+ and
GND on TB1 of the 7847i-E. Observe Polarity!
If using an external power source, connect GND from power supply to GND of the control
panel.
Ethernet Connections
UL
1. For UL installations, the Cat. 5 Ethernet connections between the 7847i-E and
the router cannot exceed 12 feet with both the 7847i-E and the router located
within the same room.
2.
Use a Listed cable/DSL router suited for the application.
•Connect one end of the Ethernet cable (Category 5) to the 7847i-E's RJ45 Ethernet
connector and the other end to the cable/DSL router.
Figure 8. Ethernet Connections
Initial Power-Up Sequence
Before connecting power, check that the following have been completed:
•Terminal block TB1 V+ and GND terminals are connected to the control panel's auxiliary
power output: 12 VDC nominal.
•Power up the control panel.
Initially, all 7847i-E programming options are set to the factory default settings.
NOTE: Refer to Appendix A for detailed information on LED functions.

3-1
SECTION 3
Programming the 7847i-E
General Information
To the control panel, the 7847i-E Intranet Communication Module, when in ECP Mode, is
treated as a long-range radio device.
The 7847i-E can be configured to deliver alarms via a Private LAN directly to a 7810PC or
7810iR-ent receiver. Communication is encrypted to ensure security. The 7847i-E uses 256-
bit AES (Rijndael) encryption (which is required for certain government installations).
You can program a 7847i-E by one of the following methods:
•Through use of a 7720P Programming Tool
•Through a programming mode in control panel, on panels that support this option (e.g.,
Vista-128BP and FBP)
Using a 7720P Programming Tool
Connect the 7720P Programming Tool; refer to Figure 8 in Section 2. The 7847i-E powers
the 7720P Programming Tool via the programming jack, and automatically senses the
presence of the 7720P when it is plugged in.
Each key of the 7720P has two possible functions: a normal function and a Shift function.
To perform a normal key function, simply press the desired key. To perform a Shift function,
press the [shift] key, and then press the appropriate key.
The prompts in this document reflect use of the 7720P Programming Tool. Table 2 below
lists each normal and shift key function.
Table 2. 7720P Normal and Shift Key (shift LED lit) Functions
KEY
NORMAL KEY FUNCTION
SHIFT KEY FUNCTION
BS/ESC
[BS]: Press to delete entry
[ESC]: Press to quit program mode; also can reset
programming defaults*
↓
/
↑
[
↓
]: Scroll down programming
[
↑
]: Scroll up programming
N/Y
[N]: Press for "NO" answer
[Y]: Press SHIFT-Y for "YES" answer
SHIFT
Press before pressing a SHIFT key function. Will light SHIFT LED. LED goes out once a key
is pressed. Press again for each SHIFT function desired.
1/A
[1]: For entering the number 1
[A]: For entering letter A
2/B
[2]: For entering the number 2
[B]: For entering letter B
3/C
[3]: For entering the number 3
[C]: For entering letter C
4/D
[4]: For entering the number 4
[D]: For entering letter D
5/E
[5]: For entering the number 5
[E]: For entering letter E
6/F
[6]: For entering the number 6
[F]: For entering letter F
7/S
[7]: For entering the number 7
[S]: For entering letter S
8/T
[8]: For entering the number 8
[T]: For entering letter T
9/X
[9]: For entering the number 9
[X]: For entering letter X
SPACE
[SPACE]: For scrolling option list
No SHIFT function
0
[0]: For entering the number 0
No SHIFT function
#/ENTER
[#/ENTER]: Press to accept entries
No SHIFT function
* Active only when the "Exit Programming Mode" prompt is displayed.

7847i-E Installation and Setup Guide
3-2
Using the Control Panel Programming Mode
Some control panels support programming of the 7847i-E through the control panel
programming mode (e.g., Vista-128BP). If programming through the control panel, only the
ECP Mode programming options are available. The "mode" questions will not be displayed,
and the mode cannot be changed. For a description of key functions on the control panel
keypad, and how they map to the 7720P Programming tool, refer to the control panel's
Programming Guide.
Programming Conventions
Programming is accomplished by answering a series of prompts (questions). Most prompts
require only a [Y]es or [N]o response, while others require a numerical response (ID
numbers, etc.).
The current value is displayed on the second line in parentheses ( ). A "?" indicates an
invalid entry.
Use the [ENTER] key to accept the current entry and proceed to the next prompt. If the
current value is invalid, pressing [ENTER] re-displays the prompt; the next prompt is not
displayed until a valid answer is entered.
Use the up/down arrow keys to scroll through the programming questions without changing
any values. Press the [ESC] key to go to the end of the list of questions.
ECP Mode Programming
Press the [ENTER] key to begin programming.
NOTES: 1. The central station can remotely block access to local device
programming. If this has been done, the following prompt
appears:
2. The default programming values for ECP mode are listed in
each prompt below.
Access to Prog
Mode Denied
Table 3: Programming a 7847i-E for ECP mode only.
PROMPTS
ENTRY
OPTIONS
DESCRIPTION
1
Strt Prog Mode?
(Y/N)_
[Y], [N]
Enters programming mode.
2
Enter Password:
[0-9, A-F, N, S,
T, X, Y]
If a password has been previously assigned, this prompt
appears.
Enter a 4-digit password (0-9, A-F, N, S, T, X, Y).
The next prompt appears.
3
Program Device?
(Y/N)_
[Y], [N] To begin programming the module, press [Y] and go to
Prompt 9: "Device Mode."
To create a password if none has been assigned, press
[N] and go to Prompt 4: "Create Password."
To change an existing password, press [N] and go to
Prompt 5: "Change Password."
4 Create Password?
(Y/N)_
[Y], [N]
Passwords can be used to protect account and
programming information.
If no password has been assigned, this prompt appears
after pressing [N] at the "Program Device?" prompt.
If a password is desired, press [Y] and go to Prompt 6:
"Enter Password."
5 Change Password?
(Y/N)_
[Y], [N] If a password has already been assigned, this prompt
appears after pressing [N] at the "Program Device?"
prompt. Press [Y] if you want to change the password.
NOTE: To clear an existing password, without entering a
new one, answer [Y] to the "Change Password?" prompt,

Section 3: Programming the 7847i-E
3-3
PROMPTS ENTRY OPTIONS DESCRIPTION
then press the [Enter] key when prompted for the new
password and its confirmation.
6 Enter Password [0-9, A-F, N, S,
T, X, Y]
This prompt is displayed if [Y] was pressed in Prompt 4 or
5.
Enter a 4-digit password (0-9, A-F, N, S, T, X, Y).
7 Verify Password
[0-9, A-F, N, S,
T, X, Y]
Re-enter the password as confirmation.
If the password doesn't match the first entry, the following
is displayed followed by the "Exit Prog. Mode?" prompt:
Verify Not OK
PSWD not created
Otherwise, the "Exit Prog. Mode?" prompt is displayed
directly.
8 Exit Prog. Mode?
(Y/N)_
[Y], [N]
[ESC]
Exits program mode.
Press [N] to go back to Prompt 3.
Press [ESC] to load factory defaults.
Refer to the Exiting Programming Mode paragraph in this
section.
9
Device Mode
(ECP)_
•ECP
•Zone Triggers
•4204 Emu
•Two 4204s
Press the [space] key to scroll through the modes of
operation. Press [ENTER] to select ECP mode.
See Table 5 if programming other modes.
10
CS IP:
255.255.255.255
12 digit:
xxx.xxx.xxx.xxx
Enter the four part primary CS IP address of the receiver
at the reporting center to which this device will report.
The four parts of the address must be separated by
spaces.
NOTE: This entry CANNOT be left a
s 255.255.255.255”. It
MUST be programmed with a valid IP address.
11
CS Port:
(80)
[80] Enter the Central Station Port Number.
NOTE: The CS Port number must match the "Listening
Port" question of the receiver.
12
Alarm Delivery:
Only One CS IP_
[Only One CS IP]
[Fail to CS IP2]
Select the "Only One CS IP" option, if only one Central
Station IP address is desired and go to Prompt 18: Verify
Inst. Key. Select the "Fail to CS IP2" option, if a
secondary Central Station IP address is desired.
13
Secondary CS IP:
255.255.255.255
12 digit:
xxx.xxx.xxx.xxx
Prompts 13-15 apply only if Prompt 12: Alarm Delivery is
set to “Fail to CS IP2".
Enter the four part secondary CS IP address of the receiver
at the reporting center to which this device will report. The
four parts of the address must be separated by spaces.
NOTE: This entry CANNOT be left as “255.255.255.255” if
using the Secondary CS IP. It MUST be programmed with
a valid IP address.
14
Second CS Port:
(80)
[80]
Enter the Central Station Port Number.
NOTE: The CS Port number must match the "Listening
Port" question of the receiver.
15 IP2 Supervision
30 Day_
•30 Day
•Daily
•Full Rate
•None
Sets the supervision timing for the secondary internet
receiver to send a test alarm if set to Daily or 30 Day, or
to send a status message to the receiver if the interval is
set to Full Rate. Selecting Full Rate means secondary
supervision will be the same as primary.
NOTE: The second receiver must be programmed to
supervise subscribers in order to generate a
communication failure.
Press the [space] key to scroll through the choices.

7847i-E Installation and Setup Guide
3-4
PROMPTS ENTRY OPTIONS DESCRIPTION
16
Installation Key:
**********_
[0-9] Enter the 10-digit Installation Key necessary for
communication with receiver. If the key entry is invalid,
the prompt is repeated. See the Installation Key
paragraph in Section 1 for more information.
17
Verify Inst. Key:
**********_
[0-9]
Re-enter the 10-digit Installation Key to verify key.
If verification fails, “Verify NOT OK” will be displayed for
one second and the display will return to the entry of the
installation key.
18 Primary City ID
(??)_
[01-99]
Enter the 2-digit primary city ID, 01-99 (decimal).
19
Primary CS ID
(??)
[01-FE] Enter the 2-digit primary central station ID number, 01-FE
(HEX).
20
Primary Sub ID
(????)
[0001-9999] Enter the 4-digit subscriber account number for the
primary central station, 0001-9999 (decimal).
21
Device Address
(03)_
[01-30]
In ECP mode, the 7847i-E communicates with the panel
as a communication (LRR) device. Enter the appropriate
ECP device address. For VISTA-10 and VISTA-20 series
control panels, use address 03. For other controls, see
the control panel’s Installation and Setup Guide.
NOTES:
1. When programming the control, enable the LRR output.
2. The device address must be unique from the "Keypad
Address" entered in Prompt 23.
22 Direct Wire Y/N
(N)_
[Y], [N]
Applies only to VISTA-128BP/250BP and FBP series
controls, and FA1600C and FA1700C series controls.
Enables Direct Wire Downloading over IP.
If [N], skip to Prompt 24: "Supervision."
23
Keypad Address
(28)_
[01-30] Must be programmed if using Direct Wire downloading.
Enter the appropriate device address.
NOTES:
1. This address must also be programmed as an alpha
keypad in the control panel or an AUI (Advanced User
Interface) type device, if a full enhanced graphic
interface to the system is desired and the control panel
supports it. DO NOT connect an actual keypad (or any
other device) assigned to this address.
2. This address must be unique from the "Device Address"
entered in Prompt 21.
24
Supervision
(24 Hours)_
•24 Hours
•1 Hour
•6 Min
•3 Min
•90 Sec
•CN 90 Sec
•75 Sec
•None
•30 Day
The receiver must hear at least one supervisory message
from the module during this supervision period; otherwise,
the receiver notifies the central station that a
communication failure has occurred. (If the supervision
period is changed after registration, you must re-register
the module.)
Press the [space] key to scroll through choices.
Must be set to:
•3 minutes for UL Comm Fire/Burg or ULC Active
Channel Security.
•24hrs for ULC Passive channel security

Section 3: Programming the 7847i-E
3-5
PROMPTS
ENTRY
OPTIONS
DESCRIPTION
25
Old Alarm Time
10 Minutes_
•10 Minutes
•15 Minutes
•30 Minutes
•1 Hour
•2 Hours
•4 Hours
•8 Hours
•12 Hours
•24 Hours
Sets how long an undeliverable alarm is retried for
delivery to the central station. If the message is not
validated, it is retried until the old alarm time is reached or
the message is validated.
Press the [space] key to scroll through choices.
UL/ULC NOTE:
Must be 10 minutes.
26
IP Flt Time
(60 mins)_
[00-99]
Enter the time delay (01-99) in minutes before the 7847i-E
notifies the control panel that there is loss of contact with
the network, or enter 00 if you do not want the unit to alert
the control panel of loss of contact with the network. The
7847i-E will alert the control panel of the loss of contact
via a dedicated status message.
UL/ULC NOTE: Must be one (01) minute.
27
Flt Rel ON Y/N
(N)_
[Y], [N]
During normal system operation the open collector fault
output will change states (open or ground) on a fault
condition. The change of state depends on whether (Y) or
(N) is used during programming.
•Tamper *
•Loss of Network Connectivity *
•Message Communication Failure
•Device Not Registered
*Fault must be enabled in programming for these
conditions (tamper & loss of network) to trigger
the fault output
Choosing Flt Rel ON (Y),
•Provides a ground during normal operation.
•Provides an open during a fault.
•“Failsafe mode” (if the radio loses power, the
fault output opens, de-energizing the relay)
Choosing Flt Rel ON (N),
•Provides an open during normal operation.
•Provides a ground during a fault condition.
This mode is lower power consumption.
UL/ULC NOTE: Must be set to "Y."
28
Tamper Rpt Y/N
(Y)_
[Y], [N] Sends a tamper report when the module detects a tamper
condition. A tamper restore is automatically sent when
the tamper condition clears.
UL/ULC NOTE: Must be “Y” for commercial burglary
Important Information Regarding Zone Input Options
ECP mode supports two optional hardwire zone input triggers by making connections to the module’s zone 6 and/or zone
7 terminals and programming the appropriate zone trigger options below.
Each zone input can be programmed to cause an alarm under one of the following conditions:
•(V+), where a positive voltage causes an alarm for normally low connections (voltage trigger, NO, NC)
•(V–), where a ground trigger causes an alarm for normally high connections (open collector, NO, NC)
•(EOLR) End of Line Resistor, where the input is supervised by a 2K EOL resistor. The zone can be triggered by
open collector, voltage trigger, NO, NC.
In addition to the above, zones can be programmed for an Inverted Trigger, where the alarm and normal states of the
zones are inverted; this can serve a fail-safe supervisory purpose for certain installations.
These zone inputs can also be programmed for restore reporting, and for delayed reporting, which allows time for the user
to abort false alarms.
NOTE: Optional hardwire zones report in ADEMCO High-Speed format.
29
Enable Zn6 Y/N
(N)_
[Y], [N] Enables alarm reporting for zone 6.
If [N], skip to Prompt 42: "Enable Zn7."

7847i-E Installation and Setup Guide
3-6
PROMPTS
ENTRY
OPTIONS
DESCRIPTION
30
Zn6 Trigger Type
(V+)_
•(V+)
•(V–)
•(EOLR)
Selects the triggering method for this zone input.
Press the [space] key to scroll through choices.
UL: V+ must be set as inverted and V- as non-inverted
31
Invert Zn6 Y/N
(N)_
[Y], [N] Inverts the alarm and normal states of the zone 6 trigger;
otherwise uses normal input signal.
32
Restore Zn6 Y/N
(Y)_
[Y], [N] Enables restore reporting for zone 6.
33
Delay Zn6 (secs)
(00)_
[01-15]
[00] = no delay
Defines the reporting delay in seconds for zone 6.
UL:
Must be 00
34
Enable Zn7 Y/N
(N)_
[Y], [N] Enables alarm reporting for zone 7.
If [N], skip to Prompt 47: "Use DHCP."
35
Zn7 Trigger Type
(V)_
•(V+)
•(V–)
•(EOLR)
Selects the triggering method for this zone input.
Press the [space] key to scroll choices.
UL: V+ must be set as inverted and V- as non-inverted
36
Invert Zn7 Y/N
(N)_
[Y], [N] Inverts the alarm and normal states of the zone 7 trigger;
otherwise, uses normal input signal.
37
Restore Zn7 Y/N
(Y)_
[Y], [N] Enables restore reporting for zone 7.
38
Delay Zn7 (secs)
(00)_
[01-15]
[00] = no delay
Defines the reporting delay in seconds for zone 7.
UL: Must be 00
39
Use DHCP Y/N
(Y)_
[Y], [N] Dynamically allocates the IP addresses (recommended);
then skip to Prompt 43: "Review?"
If [N], uses fixed IP addresses.
40
NIC IP Address:
255.255.255.255_
12 digit:
xxx.xxx.xxx.xxx
Enter the 4-part address for this device. The four parts of
the address must be separated by spaces (displayed as
periods in Review mode).
49
Subnet Mask:
255.255.255.255_
12 digit:
xxx.xxx.xxx.xxx
Enter the 32-bit address mask used to indicate the portion
(bits) of the IP address that is being used for the subnet
address. The four parts of the address must be separated
by spaces (displayed as periods in Review mode).
41
Gateway IP Addr:
255.255.255.255_
12 digit:
xxx.xxx.xxx.xxx
Enter the 4-part address assigned to the Gateway. The
four parts of the address must be separated by spaces
(displayed as periods in Review mode).
42
DNS Serv IP Addr:
255.255.255.255_
12 digit:
xxx.xxx.xxx.xxx
Enter the 4-part IP address assigned to the DNS (Domain
Name System) server. The four parts of the address must
be separated by spaces (displayed as periods in Review
mode).
43
Review? Y/N
[Y] = review
[N] = exit
Reviewing Programming Mode Entries
To review the programming options (to ensure that the
correct entries have been made), press [Y]. The
programming prompts are displayed again. Use the
up/down arrow keys to scroll through the program fields
without changing any of the values. If a value requires
change, simply type in the correct value. When the last
field is displayed, the “REVIEW?” prompt again appears.
To exit the programming mode, press [N] in response to
the "REVIEW?" prompt, and refer to Exiting Programming
Mode at the end of this section.

Section 3: Programming the 7847i-E
3-7
ECP Status Codes
When the 7847i-E is configured for ECP mode, it sends status messages to the control panels
(e.g., VISTA-10P, VISTA-15P and VISTA-20P series), for tamper, and network connectivity
failures. Some of the control panels display these on the keypad as "LngRng Radio" followed
by a 4-digit code (listed in table 4). In addition, the Contact ID codes (listed in Appendix B)
for these conditions are sent to the central station by the module.
Table 4. Common ECP Keypad Displays Status Codes
STATUS CODE
DESCRIPTION
0000
Control panel lost communication with 7847i-E.
0880
Tamper detected (cover removed).
0005
Lost Ethernet connectivity.
000F
Not registered; account not activated.
0400
Power on reset AND the control panel lost communications with 7847i-E.
0C80
Power on reset AND tamper detected.
0C8F
Power on reset AND tamper detected AND not registered.
Alternative Zone Trigger Mode
Zone Trigger Mode
There are six input zones available on the 7847i-E. Zones 1 and 2 are located on TB1 pin 5
and are selectable for +V, –V, or EOLR modes, which can detect both pulsed and steady
signals. The pulsed signal is reported as an alarm on zone 1 (Fire); the steady signal is
reported as an alarm on zone 2 (Burg). The implied pulse count for zone 1 is fixed to 3
pulses. No restores are reported for this zone.
Zones 3, 4, 5, 6 and 7 are voltage trigger inputs located on TB1 pins 6-10.
Alternative Mode Programming
Press the [ENTER] key to begin programming and follow the prompts for the mode of
operation being programmed.
NOTE:
The central station can remotely block access to
local device programming. If this has been done,
the following prompt appears:
Access to Prog
Mode Denied
Table 5: Programming a 7847i-E for Zone Trigger mode.
PROMPTS ZONE
TRIG.
ENTRY OPTIONS DESCRIPTION
1
Strt Prog Mode?
Y/N_

[Y], [N]
Enters programming mode.
2
Enter Password
[0-9, A-F, N,
S, T, X, Y]
If a password has been previously assigned, this
prompt appears.
Enter a 4-digit password (0-9, A-F, N, S, T, X, Y).
The next prompt appears.
3
Program Device?
Y/N_
[Y], [N] To begin programming the module, press [Y] and go to
Prompt 9: "Device Mode."
To create a password if none has been assigned,
press [N] and go to Prompt 4: Create Password.
To change an existing password, press [N] and go to
Prompt 5: "Change Password."
4 Create Password?
Y/N_
[Y], [N] Passwords can be used to protect account and
programming information. If no password has been
assigned, this prompt appears after pressing [N] at the
"Program Device?" prompt.
If a password is desired, press [Y] and go to Prompt 6:
"Enter Password."
5 Change Password? [Y], [N]
If a password has already been assigned, this prompt
appears after pressing [N] at the "Program Device?"

7847i-E Installation and Setup Guide
3-8
PROMPTS ZONE
TRIG.
ENTRY OPTIONS DESCRIPTION
Y/N_
prompt.
Press [Y] if you want to change the password.
NOTE: To clear an existing password, without entering
a new one, answer [Y] to the "Change Password?"
prompt, then press the [Enter] key when prompted for
the new password and its confirmation.
6 Enter Password
[0-9, A-F, N,
S, T, X, Y]
This prompt is displayed if [Y] was pressed in Prompt
4 or 5.
Enter a 4-digit password (0-9, A-F, N, S, T, X, Y).
7 Verify Password
[0-9, A-F, N,
S, T, X, Y]
Re-enter the password as confirmation.
If the password doesn't match the first entry, the
following is displayed followed by the "Exit Prog.
Mode?" prompt:
Verify Not OK
PSWD not created
Otherwise, the "Exit Prog. Mode?" prompt is displayed
directly.
8 Exit Prog. Mode?
Y/N_
[Y], [N]
[ESC]
Exits program mode.
Press [N] to go back to Prompt 3.
Press [ESC] to load factory defaults.
Refer to the Exiting Programming Mode paragraph in
this section.
9
Device Mode
(ECP)_
•ECP
•Zone Trig.
•4204 Emu
•Two 4204s
Press the [space] key to scroll through the modes of
operation.
Press [ENTER] to select mode.
See Table 3 for ECP mode programming.
10
CS IP:
255.255.255.255
12 digit:
xxx.xxx.xxx.xxx
Enter the 4-part primary CS IP address of the 7810iR-
ent receiver at the reporting center to which this device
will report. The four parts of the address must be
separated by spaces.
NOTE: This entry CANNOT be left as
“255.255.255.255”. It MUST be programmed with a
valid IP address.
11
CS Port:
(80)
[80] Enter the Central Station Port Number.
NOTE: The CS Port number must match the "Listening
Port" question of the receiver.
12
Alarm Delivery:
Only One CS IP_
[Only One CS
IP]
[Fail to CS IP2]
Select the "Only One CS IP" option, if only one Central
Station IP address is desired and go to Prompt 16:
"Installation Key".
Select the "Fail to CS IP2" option, if a secondary
Central Station IP address is desired.
13
Secondary CS
IP:
255.255.255.255

12 digit:
xxx.xxx.xxx.xxx
Enter the 4-part secondary CS IP address of the
receiver at the reporting center to which this device will
report. The 4-parts of the address must be separated
by spaces.
NOTE: This entry CANNOT be left as
“255.255.255.255” if using the Secondary CS IP. It
MUST be programmed with a valid IP address.
14
Second CS Port:
(80)

[80] Enter the Central Station Port Number.
NOTE: The CS Port number must match the "Listening
Port" question of the receiver.
