Honeywell GSMV4G Assembly instructions

I
In nt te el ll li iP Pa at th hT
TM M
S Se er ri ie es s 4 4G G G GS SM M C Co om mm mu un ni ic ca at to or r
A
Au ut to o- -s se el le ec ct ts s O Op pt ti im mu um m G GS SM M p pa at th h – – 2 2G G, , 3 3G G, , o or r 4 4G G
G
GS SM MV V4 4G G
/
/
G
GS SM MV VC CN N4 4G G
s
su up pp po or rt ts s t tw wo o- -w wa ay y v vo oi ic ce e
Installation and Setup Guide
800-11119 1/12 Rev. E

i
Table of Contents
•••••••••••••••••••••••••••••••••••••••••••••••••
SECTION 1: General Information.................................................................................................................. 1-1
System Overview...................................................................................................................................... 1-1
Introduction ....................................................................................................................................... 1-1
General Information.......................................................................................................................... 1-1
System Features....................................................................................................................................... 1-1
Encryption ................................................................................................................................................ 1-2
Remote Services ....................................................................................................................................... 1-2
Modes of Operation .................................................................................................................................. 1-2
ECP Mode........................................................................................................................................... 1-2
Zone Trigger Mode............................................................................................................................. 1-3
4204 Mode and Two-4204 Mode ....................................................................................................... 1-3
Supervision Features ............................................................................................................................... 1-3
Antenna.............................................................................................................................................. 1-4
Specifications............................................................................................................................................ 1-5
Compatibility............................................................................................................................................ 1-6
Compliance ............................................................................................................................................... 1-6
SECTION 2: Mounting and Wiring ................................................................................................................ 2-1
Determine the Signal Strength and Select a Location .......................................................................... 2-1
Mounting the Communicator .................................................................................................................. 2-2
Mounting Procedure, GSMV4G (no rear tamper switch)............................................................... 2-2
Mounting Procedure, GSMVCN4G (with rear tamper switch) ..................................................... 2-3
Wiring the Communicator ....................................................................................................................... 2-4
Wiring for two-way voice................................................................................................................... 2-4
Wiring for ECP, 4204 and Two-4204 Modes.................................................................................... 2-5
Wiring for Zone Trigger Mode .......................................................................................................... 2-5
Wiring the Fault Relay...................................................................................................................... 2-6
Power Connections and Options ............................................................................................................. 2-7
Powering the Communicator ............................................................................................................ 2-7
Backup Battery Connection .............................................................................................................. 2-8
Initial Power-Up Sequence ............................................................................................................... 2-8
SECTION 3: Programming the Communicator .......................................................................................... 3-1
General Information ................................................................................................................................ 3-1
Using the AlarmNet Direct Website ................................................................................................ 3-1
Using a 7720P Programming Tool.................................................................................................... 3-1
Using the Control Panel Programming Mode ................................................................................. 3-2
Programming Conventions ............................................................................................................... 3-3
ECP Mode Programming ......................................................................................................................... 3-3
ECP Status Codes.............................................................................................................................. 3-7
Alternative Mode Programming (Zone Trigger, 4204 and Two-4204).................................................. 3-8
Zone Trigger Mode............................................................................................................................. 3-8
4204 Emulation Mode ....................................................................................................................... 3-8
4204 Emulation Mode Options ......................................................................................................... 3-8
Alternative Mode Programming ........................................................................................................... 3-10
Exiting Programming Mode .................................................................................................................. 3-18
Setting Factory Defaults ................................................................................................................. 3-18
SECTION 4: Registration................................................................................................................................. 4-1
Registering the Communicator ............................................................................................................... 4-1
Registering through AlarmNet Direct Website ............................................................................... 4-1

GSMV4G/GSMVCN4G Installation and Setup Guide
ii
Register using the Tamper Switch ................................................................................................... 4-2
Register using the Programming Tool ............................................................................................. 4-2
Replacing an existing communicator ............................................................................................... 4-3
Register by Phone.............................................................................................................................. 4-3
SECTION 5: Programmer Keyboard Commands ....................................................................................... 5-1
Programmer Keyboard Commands......................................................................................................... 5-1
Identification Displays ...................................................................................................................... 5-1
GSM Status Displays ........................................................................................................................ 5-2
System Status Displays..................................................................................................................... 5-4
Appendices ......................................................................................................................................................... A-1
Appendix A : Summary of LED Operation .............................................................................................A-1
Appendix B : Central Station Messages .................................................................................................B-1
Appendix C : Glossary..............................................................................................................................C-1
Summary of Connections Diagram…………………………………………………………..……….Inside Back Cover

1-1
SECTION 1
General Information
•••••••••••••••••••••••••••••••••••••••••••••••••
System Overview
Introduction
Congratulations on your purchase of Honeywell's GSMV4G GSM Communicator (referred to
as the GSMV4G, or GSMVCN4G in Canada). It represents the latest and most innovative
communication technology for the security industry and uses sophisticated encryption to
ensure the highest level of security for your customer.
The new 4G connectivity brings faster GSM data transfers with lower latency (response
time); together it results in speedier data transfers.
The communicator requires an AlarmNet–i account. For new installations, please obtain the account
information from the central station prior to programming this communicator. For replacement
installations, the AlarmNet-i account is created automatically when the communicator is registered
(based on the existing account).
In addition to alarm reporting, the communicator provides two-way voice communications
with the central station (when used with Honeywell’s AVS Audio Verification System) and
provides upload/downloading capability of Honeywell's control panel data over the Internet
(via the AlarmNet-G network), using GSM (Global System for Mobile) technology.
UL / ULC
Two-way voice has not been evaluated by UL/ULC.
NOTE: Two-way voice is not compatible with Honeywell Commercial Control Panels (such
as the VISTA-128/250 series).
Due to Honeywell's continuing effort to improve our products, your device may look slightly
different than pictured.
General Information
The communicator transmits signals to the AlarmNet-G network (GSM cellular network,
using GPRS) and forwards them to your central station.
If the GPRS network is unavailable, the communicator (if enabled by the dealer) will attempt
to send the transmission via SMS (Short Message Service) and/or email.
ULC
SMS has not been evaluated for ULC central station communication.
The communicator also provides support for AlarmNet Remote Services. These services
allow users remote access to their security systems and provide the ability for users to be
notified of system events via email.
ULC The GSMVCN4G is only employed for supplemental use. A listed DACT is required to be
used in conjunction with the GSMVCN4G to provide passive communication for fire and
Level P2 channel security for burglary.
System Features
Basic features of the communicator include:
•Remote Services allow the end user to access their security system from their computer
via a website. Availability of this service is controlled by the dealer via the web-based
programming tool on the AlarmNet Direct website. Once enabled, remote access can be
programmed via web or 7720P programming tool.
•Quick connection to compatible Honeywell series control panels

GSMV4G/GSMVCN4G Installation and Setup Guide
1-2
•Simple programming using a 7720P programming tool
•Reports fire, burg, and status messages via wireless network
•Allows uploading and downloading of control panel data via the wireless network
•Supports remote control of alarm systems via Remote Services feature
•Two-way voice capability
Encryption
The communicator uses 256 bit AES (Rijndael) encryption (which is required for certain
government installations). The AlarmNet-i AES Encryption Software Module Version 1.0
contained in the Honeywell products has NIST approval. Listings for this approval can be
found at http://csrc.nist.gov/groups/STM/cavp/documents/aes/aesval.html and search for
“Certificate number 979.”
Remote Services
Honeywell now offers a new series of web based services that provides consumers with the
ability to communicate with their security system remotely in a number of ways. These new
web services will allow users to:
•Access their security system from a computer via a website (Remote Access feature)
•Receive email and text message notifications of system events (Multi-Mode feature)
•Perform system functions and receive confirmations using text messages (SMS feature)
Dealers will initially enroll their customers for web services during account programming
through the AlarmNet Direct website. The features that can be enabled include Remote
Access and Multi-Mode. Once enabled, the specific programming fields associated with
these features can be programmed into the communications device either remotely using
the AlarmNet Direct website or locally using the 7720P local keypad programming tool.
UL
Remote Access and Multi-Mode have not been evaluated by UL.
Modes of Operation
The communicator provides four modes of operation so it can be used with various types of
control panels, as summarized below.
ULC
Only ECP Mode has been approved for ULC installations.
UL
Only ECP Mode and Zone Trigger Mode have been evaluated.
ECP Mode
•This mode is for Honeywell control panels that support ECP communication
•The communicator connects to the control panel’s keypad terminals and provides 2-way
communication with the control panels using ECP messaging
•The control panel treats the communicator as an ECP device, so ensure to program the
control panel with the communicator’s device address
•Reports are sent in Contact ID format
•The communicator also supports two hardwire zone trigger inputs (zones 6 and 7)
UL •Opening and Closing ring back is fully supported.
•Only the V+ inverted, V– non-inverted, and EOL options have been evaluated.

Section 1: General Information
1-3
Zone Trigger Mode
•This mode is for use with control panels that do not support ECP communication nor 4204
Relay Modules
•The communicator provides six input zones
•Each zone can be configured for +V, –V, or EOLR triggering
UL: For the communicator, only the V+ inverted, V– non-inverted, and EOL options have
been evaluated.
•Each zone can be programmed for inverted operation, delayed reporting, and restoral
reporting
•Zone 1 input can distinguish between pulsed and steady signals and report fire or
burglary alarms respectively
•Zone 1 can also be programmed to report LYNX panic (if used with LYNX control)
UL: This feature has not been evaluated by UL.
•Reports are sent in ADEMCO High-Speed format
UL
Opening and Closing ring back is supported by the control panel’s digital dialer.
4204 Mode and Two-4204 Mode
•This mode is for use with Honeywell control panels that do not support ECP communica-
tion, but do support 4204 Relay Modules
•The communicator connects to the control panel’s keypad terminals
•The control panel treats the communicator as 4204 Relay Module(s), so program the
control panel accordingly, including setting the communicator’s proper 4204 device
address
•4204 mode provides up to four zone inputs, plus two optional trigger zones, depending on
options programmed
•Two-4204 mode provides up to eight zone inputs, depending on options programmed
•Each 4204 zone can be programmed for delayed reporting and restoral reporting
•Reports are sent in ADEMCO High-Speed format
UL •Opening and Closing ring back is supported by the control panel’s digital dialer.
•4204 Mode and Two-4204 Mode has not been evaluated by UL.
Supervision Features
The communicator provides the following types of supervision and communicator fault
detection:
•Network communication failure: In the event the AlarmNet network does not hear a
supervisory message from the communicator within a specified time (“Supervision” option,
24 hours, 30 days, or none), AlarmNet notifies the central station of a communication
failure.
•Communication path failure: In the event the module detects a communication path
failure, both the Central Station and the control panel can be notified of the trouble
condition. The failure is considered a true fault when the fault time has expired ("GSM
Fault Time" option) provided it has been set to a non-zero value. Notification is sent to
the central station upon this expiration.

GSMV4G/GSMVCN4G Installation and Setup Guide
1-4
•Fault output: Terminal 11 can serve as a fail-safe trigger for communicator fault
conditions.
If used, the fault relay will trip when the following conditions occur: tamper*, power loss*,
low battery*, battery charger fault*, loss of network connectivity*, the device is not
registered and the device is remotely disabled by AlarmNet.
* Alarm reporting for the noted condition must be enabled for it to trigger the fault relay.
•Primary power loss and low battery conditions (“Pwr Loss Rpt,” “Low Bat Rpt” options).
•Cover tamper condition (“Tamper Rpt” option).
Antenna
The communicator comes equipped with an internal antenna. This feature provides
additional security to the installation by making the device tamper resistant.
UL / ULC
External antenna has not been evaluated by UL.
AMPS antennas, such as the 7825-OC antenna, cannot be used with this product.

Section 1: General Information
1-5
Specifications
Mechanical: Dimensions: 8.4" x 8.0" x 1.5" Weight: 2.4 lbs., with battery
Input Power:
16.5VAC, 40VA transformer, or for ULC installations 12VDC from
the control panel.
(Honeywell transformer # 1361 included with GSMV4G.)
(Honeywell transformer # 1361CN not included with the
GSMVCN4G.)
Current Drain: 220mA standby, 380mA active
Backup Battery:
6V, 3.1AH, (Honeywell # K14139 included with GSMV4G only.)
Expected Battery Life: 5 Years (approx.)
Note: The sealed lead acid battery used for backup will have
reduced life expectancy when exposed to elevated temperatures.
The use
ful life of the battery at 25ºC (77ºF) is approximately 4 years.
At 35ºC (95ºF) this will drop to 2 years and at 45ºC (113ºF) 1 year.
Battery life expectancy should be taken into account when locating
the radio.
Fault Relay Output: Open collector, 12VDC, 0.25W max.
Positive Trigger
Level:
6V or greater = positive trigger. (4V or less = restore.)
Negative Trigger
Level:
4V or less = negative trigger. (6V or greater = restore.)
RF Frequency: 2G GSM/GPRS/EDGE Quad Band, 850/900/1800/1900 MHz
3G/4G UMTS/HSPA+ Band V, Band II
RF Output Power:
2G GPRS +33dBm, GMSK modulation
EDGE +27dBm, 8-PSK modulation
3G UMTS +24dBm, QPSK modulation
WCDMA +24dBm, QPSK modulation
4G HSPA+ +24dBm, 64 QAM modulation
WCDMA +24dBm, 64 QAM modulation
Environmental:
Operating temperature: –20º to +55ºC, for UL/ULC installations 0ºC
to +49ºC
Storage temperature: –40º to +70ºC
Humidity: 0 to 95% relative humidity, non-condensing
for UL installations 0% to 85%; for ULC installations 0% to 93%
Altitude: to 10,000 ft. operating, to 40,000 ft. storage

GSMV4G/GSMVCN4G Installation and Setup Guide
1-6
Compatibility
For a list of control panels that are compatible with various features of this device, go to:
https://mywebtech.honeywell.com/.
After logging on, select the applicable communication product, and then select “Compatibility
Chart” under Essential Docs.
For UL installations and ULC Commercial Burglary Installations, any compatible UL or ULC (respectively)
Listed Control Panel may be used. Note, that any control panel that does not communicate via Honeywell's
ECP data bus is compatible using zone Trigger Mode. For ULC Commercial Fire Installations, only ULC
Listed Subscriber's Unit Panels which use Honeywell's ECP data bus are compatible.
For UL and ULC Fire and Burglary installations, compatible receivers are:
•
MX8000 (UL – can be used for secondary reporting in ECP mode and Zone
Trigger mode. Shall be used for opening and closing ring back with the
control panel dialer)
•
7810iR-ENT (
UL
– must be the primary alarm receiver.)
•
Ademco 685
UL The Automation System must be UL1981 listed.
The GSMV4G has been evaluated for connection to police station receivers.
ULC The GSMVCN4G has only been evaluated for communication with listed Model 7810iR-ENT
internet receiver and Model MX8000 central station receiver.
Compliance
This device complies with the following ULC Installation Codes and Standards:
1. The Canadian Electrical Code, Part I, Safety Standard for Electrical Installations,
CSA C22.1.
2. National Building Code (NBC).
3. Standard for Installation and Services for Fire Signal Receiving Centers and
Systems, CAN/ULC-S561-03.
4. Standard for Installation of Fire Alarm Systems, CAN/ULC-S524-06.
5. Standard for Installation and Classification of Burglar Alarm Systems for Financial
and Commercial Premises, Safes and Vaults, CAN/ULC-S302-M91.

2-1
SECTION 2
Mounting and Wiring
•••••••••••••••••••••••••••••••••••••••••••••••••
Determine the Signal Strength and Select a Location
The communicator must be mounted indoors within the protected premises. When choosing
a suitable mounting location, understand that signal strength is very important for proper
operation. For most installations using the supplied antenna, mounting the unit as high as
practical, and avoiding large metal components provides adequate signal strength for proper
operation.
You will use the communicator to determine signal strength in order to find a suitable
mounting location.
Note: If the SIM is already activated, the RSSI signal strength indicators will indicate
signal strength.
If the SIM has not been activated, the firmware in the communicator enables it to
communicate with the cellular network towers (without the SIM being activated) so that
signal strength measurements can be determined. In this case, you can display the signal
strength by simultaneously pressing the MODE and TAMPER switches.
Allow at least 60 seconds for a reading to establish.
RF Exposure
Warning – The internal or external antenna(s) used with this product must be installed to
provide a separation distance of at least 7.8 in. (20 cm) from all persons and must not be
co-located or operating in conjunction with any other antenna or transmitter except in
accordance with FCC multi-transmitter product procedures.
Mise en Garde
Exposition aux Frequences Radio:L'antenne (s) utilisée pour cet émetteur doit être
installée à une distance de séparation d'au moins 7,8 pouces (20 cm) de toutes les
personnes.
Note: The communicator must be installed in accordance with the National Fire Alarm
Code, ANSI/NFPA 72.
Unshielded, 22 AWG cable is recommended for the communicator power/data wires.
1. Unpack the communicator and open the case by pushing in the two bottom tabs with a
screwdriver while separating the case front.
2. Temporarily connect the communicator to the AC transformer or battery.
3. Choose the installation site with the best signal strength by
observing the signal strength (RSSI) bar graph (refer to
Appendix A for information about signal strength and status
indications). Signal strength should be within 3-5 bars. The
best signal strength is usually found at the highest point in
the building, near a window.
4. Mark the location for the communicator.

GSMV4G/GSMVCN4G Installation and Setup Guide
2-2
Mounting the Communicator
The communicator can be mounted in two ways depending on the installation requirements.
ULC NOTES:
For Commercial Fire installations, the communicator must be mounted to a single or double
gang box.
1. Locate the Drilling Template (provided) and align with case back. Drill at the appropri-
ate locations for either single or double gang box.
2. Locate the gang box into the mounting surface, align case back over mounting surface
and install using the screws provided. Pass wires/cables through the opening in the gang
box and then through the opening in the case back.
3. When all wiring is completed, attach the case front of the communicator to the case back.
Attach the top first then press the bottom section inward until it snaps into place. Secure
cover using supplied screw.
4. For Commercial Burglary installations, you must install the rear tamper switch.
UL
The cover must be secured with the supplied screw.
Mounting Procedure, GSMV4G (no rear tamper switch)
1. Locate the case back over selected mounting position such that the opening in the case
back is aligned with the wire/cable opening on the mounting surface.
2. Pass the wires/cable through the opening in the case back, or route through the
removable knockouts located on the back cover.
3. Secure the case back to the mounting surface using four screws (supplied).
4. When all wiring is completed, attach the case front. Position the top first, then press the
bottom section until it snaps in place. Secure bottom using the supplied cover screw.
(This is required for UL installations.)
Standard Mounting

Section 2: Mounting and Wiring
2-3
Mounting Procedure, GSMVCN4G (with rear tamper switch)
For Canadian installations where the rear tamper switch is used, this procedure requires the
removal of the printed circuit boards and installation of the tamper screw.
1. Remove the two mounting screws, and standoff from the daughter card, as shown in
Step A below.
2. Remove the daughter card by pivoting upward, as shown in Step B below.
3. Remove the lower printed circuit board by pushing down on the lower tabs and pivoting
the board upward, as shown in Step C below.
STEP A STEP B
STEP C STEP D
4. Locate the case back over selected mounting position such that the opening in the case
back is aligned with the wire/cable opening on the mounting surface.
5. Pass the wires/cable through the opening in the case back, or route through the
removable knockouts located on the back cover.
6. Secure the case back to the mounting surface using four screws (supplied).
7. Install the tamper screw (provided), as shown in Step C above.

GSMV4G/GSMVCN4G Installation and Setup Guide
2-4
8. Replace lower printed circuit board and then daughter card, as shown in Step D above.
Be sure to engage receptacle pins by pushing in before securing the daughter card with
mounting screws.
When all wiring is completed, attach the case front. Position the top first, then press the
bottom section until it snaps in place. Secure bottom using the supplied cover screw.
Wiring the Communicator
UL
•Installation must be in accordance with the National Electrical code and UL681, Installation and
Classification for Burglar and Hold-Up Alarm Systems.
•The communicator must be connected to a UL Listed dry contact or voltage trigger outputs of a UL
Listed compatible control panel.
•All interconnecting wires between the UL Listed control panel and the communicator must be less
than 3 feet in length contained in the same room. All interconnecting wiring must be installed in rigid
or EMT (where exposed on interior walls) or in flexible metal tubing if run in the walls or ceiling.
•Requires dialer reporting with a UL Listed control panel. Reporting occurs over both paths.
•A UL listed control panel must monitor the radio fault output of the communicator. A No. 659 or other
UL listed Telco Line Fault Monitor’s output must be connected to an input zone on the communicator.
Premises openings and closings should be sent via the UL listed control panel.
ULC For ULC Commercial Fire and Burglary installations, only use the ULC wiring specified in the “Power
Connections and Options” topic.
Wiring for two-way voice
The GSMV4G requires an optional audio cable (GSMV-AUDIO, grey) to support two-way
voice using the AVS Base Unit. Note the AVS Base Unit is part of Honeywell’s AVS Audio
Verification System. This system consist of the AVS Base Unit, Remote Station, and the
Remote Station PC board. For detailed information, refer to the AVS Audio Verification
System documentation. Follow the guidelines below for connecting the audio cable.
1. Power down the communicator, control panel and AVS Audio Verification System.
(When the communicator is fully wired up, restore power to the communicator, control
panel and AVS Audio Verification System.)

Section 2: Mounting and Wiring
2-5
2. Connect one end of the audio cable to the audio connector located on the small PC board.
3. Route the audio cable to the connector on the AVS Base Unit and connect the cable.
4. Ensure the audio cable ends are secured with tie wraps to reduce strain.
Wiring for ECP, 4204 and Two-4204 Modes
Most Honeywell ADEMCO control panels support ECP data communication, (e.g., VISTA-
10P, VISTA-15P, VISTA-20P, VISTA-128BP and VISTA-128FBP). However, there are some
panels that do not. Check the Installation and Setup Guide for the control panel you are
using to see if it supports ECP communication.
Connect the communicator to a compatible Honeywell VISTA control panel's ECP terminals,
in parallel with keypads and other peripheral devices such as RF receiver, VIP module, etc.
Wire length/gauge limitations are the same for the communicator as they are for keypads
and other peripheral devices. To wire the communicator for ECP or 4204 modes, see the
figure below and make the following connections:
Wiring a VISTA for ECP Mode or 4204 Modes
Wiring for Zone Trigger Mode
To trip a zone using a positive trigger, the voltage level must be:
6V or greater = positive trigger. (Levels above +14V may cause damage to the unit.)
4V or less = restore.
To trip a zone using a negative trigger, the voltage level must be:
4V or less = negative trigger.
6V or greater = restore. (Levels above +14V may cause damage to the unit.)
Note: Remember to program the communicator’s zone for the desired trigger type.
Connect a wire from the triggering source (bell output, voltage trigger, etc.) of the control
panel to the zone input of the communicator, and connect a common ground between the
communicator and control panel. Examples of zone connections follow:
Wiring the Zone 1 Input for a Positive (+) Trigger

GSMV4G/GSMVCN4G Installation and Setup Guide
2-6
Wiring the Zone 1 Input for a Ground (-V) Trigger
Wiring the Zone 1 Input for EOL Supervised N.O./N.C. Triggers
Wiring the Fault Relay
You may wire and program the communicator's fault output trigger for fail-safe mode (see
the question "FLT REL ON Y/N").
To sense a communicator fault at the control panel, see the figure below and make the
following connections. Include the proper EOL resistor required by the control panel.
UL / ULC
A 24 hour supervisory zone must be assigned on the control panel, with the communicator's fault
relay wired to that zone.
Wiring the Fault Relay to a Control Panel Zone for Normally Closed Fault
UL •Zones should use EOL resistors, and be pro-
grammed as V+ Inverted or V– Inverted
operation such that a cut line results in an
alarm.
•Do not use zones 1 and 2 for UL installations.

Section 2: Mounting and Wiring
2-7
Power Connections and Options
Powering the Communicator
There are three ways to power the communicator (see illustrations below):
Standard Installation – The communicator is powered by the supplied AC plug-in
transformer.
ULC Commercial Fire and Burglary Compliant Installation – The communicator must be
powered by the control panel.
Shared Transformer Installation – In this installation the supplied AC plug-in
transformer may be used to power both the communicator and the control panel under the
following conditions:
•You must use the Honeywell 1361 Transformer.
•This configuration ONLY applies to the VISTA-10P, VISTA-15P, VISTA-20P control
panels when used with the GSMV4G communicator.
•DO NOT use this configuration with any other control panel.
•DO NOT use this configuration if using two-way voice.
•This configuration has not been evaluated by UL.
For all installations the control panel ground (GND) must be connected to TB1-4 GND on the
communicator. In addition, if using ECP communication, you must connect the +12VDC
AUX voltage output on the control panel (9.6V-13.8V typical) to TB1-3 on the communicator.
Standard
Installation
ULC Commercial
Fire and Burglary
Compliant
Installation

GSMV4G/GSMVCN4G Installation and Setup Guide
2-8
NOTE:
When calculating the total load on the auxiliary power output of the control panel, budget 10mA
for the communicator when using ECP mode.
Backup Battery Connection
The included battery (K14139) is used for backup in the event of power loss to the commu-
nicator. It does not provide power to the control panel.
In ULC installations this battery is not connected, and all backup power is supplied by the
control panel.
•The battery can provide over 24 hours of system life in the event of a power failure.
•A programmable power loss message can alert the AlarmNet Control Center when system
power is lost (power loss messages are reported within 1-3 hours of actual loss).
•The communicator transmits a low-battery message (programmable) when the battery
reaches 5.7V ±5%, indicating subsequent messages may not be transmitted.
•The system shuts down when the battery reaches 5.1V, and radio transmissions are no
longer possible.
•If system power is restored before the communicator shuts down, a power restore message
is sent within 1-3 hours after power is restored, and the battery is recharged using the
communicator’s built-in battery charger. If system power is restored after the
communicator has shut down, a power-on reset condition exists, the communicator
initializes itself and the battery will recharge.
Install the battery as follows, and refer to the Summary of Connections diagram at the end of
this document.
1. Place the battery inside the case back.
2. Snap the right side of the battery clip onto the inside of the case back and secure the
left side with the screw provided.
Do not plug the battery in until after you have powered-up the communicator.
Initial Power-Up Sequence
Before connecting power, check that the following have been completed:
•If using ECP, 4204 or 2-4204 Mode, terminal block TB1 V+ and GND terminals are
connected to the control panel’s auxiliary power output: 12VDC nominal.
•Plug in the transformer. Then connect the red and black battery cables to the battery
terminals. Connect battery cable to connector J1.
•Power up the control panel. (Initially, all communicator programming options are set to
the factory default settings.)
Shared
Transformer
Installation

3-1
SECTION 3
Programming the Communicator
•••••••••••••••••••••••••••••••••••••••••••••••••
General Information
The communicator is designed to deliver alarms via the GSM network to an AlarmNet
central station when it is registered with a valid AlarmNet account.
The communicator requires an AlarmNet–i account. For new installations, please obtain the account
information from the central station prior to programming this communicator. For replacement
installations, the AlarmNet-i account is created automatically when the communicator is registered.
You can program the communicator by one of the following methods:
•Through the AlarmNet Direct website
•Through use of a 7720P Programming Tool
•Through a programming mode in the control panel on panels that support this option
(e.g., VISTA-128BP and FBP)
UL
Only ECP and Zone Trigger modes have been evaluated by UL.
Using the AlarmNet Direct Website
To program the communicator via the website (if you are already signed up for this service),
go to: https://services.alarmnet.com/AlarmNetDirect/userlogin.aspx
If you are not signed up for this service, click on “Dealer Sign-Up.”
Log in and follow the on-screen prompts.
Please have the following information available when programming the communicator:
1. Primary City ID (two-digit number)
2. Primary Central Station ID (two-digit hexadecimal number)
3. Primary Subscriber ID (four-digit number)
4. MAC ID and MAC CRC number (located on the box and inside the communicator)
After programming is complete, you must transfer the data to the communicator and the
communicator must be registered. Refer to Section 4: Registration, for further instructions.
Using a 7720P Programming Tool
Connect the 7720P Programming Tool as shown below. The communicator powers the 7720P
Programming Tool via the programming jack, and automatically senses the presence of the
7720P when it is plugged in.

GSMV4G/GSMVCN4G Installation and Setup Guide
3-2
7720P Programmer Tool Connection
Each key of the 7720P has two possible functions: a normal function and a Shift function.
To perform a normal key function, simply press the desired key.
To perform a Shift function, press the [Shift] key, and then press the appropriate key.
The prompts in this document reflect use of the 7720P Programming Tool. Table 3-1 below
lists each normal and shift key function.
Table 3-1. 7720P Normal and Shift Key (shift LED lit) Functions
KEY
NORMAL KEY FUNCTION
SHIFT KEY FUNCTION
BS/ESC
[BS]: Press to delete entry
[ESC]: Press to quit program mode; also can reset
programming defaults*
↓
/
↑
[
↓
]: Scroll down programming
[
↑
]: Scroll up programming
N/Y
[N]: Press for "NO" answer
[Y]: Press SHIFT-Y for "YES" answer
SHIFT
Press before pressing a SHIFT key function. Will light SHIFT LED. LED goes out once a key
is pressed. Press again for each SHIFT function desired.
1/A
[1]: For entering the number 1
[A]: For entering letter A
2/B
[2]: For entering the number 2
[B]: For entering letter B
3/C
[3]: For entering the number 3
[C]: For entering letter C
4/D
[4]: For entering the number 4
[D]: For entering letter D
5/E
[5]: For entering the number 5
[E]: For entering letter E
6/F
[6]: For entering the number 6
[F]: For entering letter F
7/S
[7]: For entering the number 7
[S]: For entering letter S
8/T
[8]: For entering the number 8
[T]: For entering letter T
9/X
[9]: For entering the number 9
[X]: For entering letter X
SPACE
[SPACE]: For scrolling option list
No SHIFT function
0
[0]: For entering the number 0
No SHIFT function
#/ENTER
[#/ENTER]: Starts programming mode;
Press to accept entries
No SHIFT function
*Active only when the "Exit Programming Mode" prompt is displayed.
Using the Control Panel Programming Mode
Some control panels support programming of the communicator through the control
panel programming mode (e.g., Vista-128BP). If programming through the control
panel, only the ECP Mode programming options are available. The "mode" questions
will not be displayed, and the mode cannot be changed. For a description of key
functions on the control panel keypad, and how they map to the 7720P Programming
tool, refer to the control panel's Programming Guide.
