How to Programyour
HoneywellTimetracker
TM
Timetracker™ Dual Plug , CL600A - 1001
Timetracker™
Wall Switch,CL600B - 1009
Timetracker™
Tabletop,CL600D - 1005

This device automatically turns your lightor applianceon and off upto four
times a day. Use
of the Timetrackeroption isrecommendedfor sunset
schedulingto ensurethat your lightgoeson at dusk, regardlessof the hour at
which dusk occurs.Timetracker automatically adjustsfor the changing hour of
sunset, allowingthe lightto come on every day at nightfall.
Onceyou havestarted setting and programming,Timetracker will lock itself
if 50 secondspasswithout a press of a button. If this happens,pressLOCK,
then FUNCTIONuntil you reachthe placewhere you left off and continue.
For this reason,pleaseread and understandthis entire instructionbookletbefore
you begin setting and programming.
IMPORTANT
Onthe CL600B - 1009 wall switch modelonly, if thedisplay does notshow
when you are ready to begin programming, the unit’s battery needs
recharging.Withthe unitwired andconnected
to thewall,placetheswitch
toAUTO.(ThismodelMUSTbeswitchedtoAUTOtorechargethebattery.)
Thebatterywill rechargesufficientlytobringthedisplayonin
24 hours,but
willtakeseveraldaystobecomefullycharged.Whenthedisplaycomeson,
press RESET, and proceed with programmingaccording to page
4.

FEATURES
PRESS TO SET HOURS
(FOR TIME),
OR MONTH
(FOR DATE).
PRESSTO
SET MINUTES
(FOR TIME), OR DAY
(FOR DATE).
PRESSTO
SET FOR DAYLIGHT
SAVINGS TIME
(DST) OR
STANDARD TIME (STD).
PRESS TO UNLOCK BEFORE
SETTlNGAND PROGRAMMING,
AND
TO LOCK AFTER
PROGRAMMING.
a
PRESS TO STEP THROUGH
GEOGRAPHIC LOCATION,
DATE, TIME SETTINGS.
PRESS TO SETGEOGRAPHIC
LOCATION AND TO STEP
THROUGH
8 DAILY PROGRAMS
FOR TIMETRACKER FEATURE,
PRESSWHILE PROGRAMMING.
PRESSTOCANCELALL
SETTINGSAND
PROGRAMS; START OVER.
LIGHT
IS ONWHEN APPLIANCE
IS ON; OFF WHENAPPLIANCE
IS OFF (INCLUDED ON
CL600A
- 1001 AND CL600D - 1005 ONLY
SWITCH OFF WHILE PROGRAMMING,
ON OR OFF TOOVERRIDE PROGRAM,
AUTO TO RESUME NORMALPROGRAM.
a DURINGPROGRAMMING, TIMETRACKER WlLL AUTOMATICALLYLOCK
12,784
IF NONE OF THE BUlTONS ARE TOUCHED FOR 50 SECONDS.
2

DETERMINE YOUR PROGRAM
Fill in the times onthe dial below.
program time after midnight.
If this
first time isan ON
- time,start with
program
1. If it isan OFF - time,skip
1, and start with 2. Continue
making sure that all program times
are
in sequence,and don't overlap.
Your setting cannot be
12:OO
midnight,but can be 1159 p.m. or
12:Ol a.m. EXAMPLES
Start programming with your first
?ZO:ZGIG>
through the day and evening,
- OFF
ON AND OFF
ONAND OFF
THREE TIMEWDAY ONCE/DAY
?z::zG> lZO:E&>
ON - '

CHANGING FROM STANDARD
TO DAYLIGHT - SAVING TIME (ANDBACK)
❏ PressLOCK.
Press DST/STD. The DST/STD indictor inthe display will change, followed
by the appropriate change intime.
Press LOCK again.
CHANGINGTHE CALENDAR
After several months have passed,your calendar will bea few days ahead,
since each month inthe Timetracker'
" has only 30 days. If desired,you may
updateyour calendar asfollows:
Press LOCK.
❏ Press FUNCTIONuntil calendar appears.
❏ Press MIN./DAY for correct day and HRSJMO.for correct month, if
❏ Press LOCK again.
INCASE OF POWER OUTAGE
A built - in rechargeablebatteryensures that your Timetracker's program isnot
lost in case of a power failure.The batteryis automatically recharged when
the Timetracker is normally wired or plugged in,and switched to theAUTO
position.
If you haveany questions regarding the Timetracker,please contact
HoneywellConsumer Affairs toll
- free at 1 - 800 - 468 - 1502,Monday - Friday, 7:30
a.m. - 4:00 p.m. Centraltime.
necessary.
S.M. Form Number 69-0451-2
Rev. 7 - 90 @Honeywell. Inc. 1990
