Honeywell Dolphin CT40XP User manual

CT40 Series
powered by Android™
Quick Start Guide
CT40-A-EN-QS-01 Rev E
06/20



1
Out of the Box
Make sure that your shipping box contains these items:
• Mobile Computer
Model CT40-L0N, CT40-L1N, CT40P-L0N, or CT40P-L1N
• Rechargeable Li-ion battery (see page 7)
• Hand strap
• Product documentation
If you ordered accessories for your mobile computer, verify that
they are also included with the order. Be sure to keep the original
packaging in case you need to return the mobile computer for
service.
Note: CT40-L0N/CT40P-L0N models do not include a WWAN radio.
Memory Card Specifications
Honeywell recommends the use of Single Level Cell (SLC)
industrial grade microSD™ or microSDHC™ memory cards with
mobile computers for maximum performance and durability.
Contact a Honeywell sales representative for
additional information on qualified memory card options.

2
Mobile Computer Features
Microphone
Power Button
Battery Status/
Notification LED
Speaker
Touch Panel
Scan Button
Microphone
Speaker
Scan Status LED
Scan Button
Imager Window
(LED/Laser Aperture)
Push-to-Talk
Button
(model dependent)
Front Facing Camera
(model dependent)

3
Note: Hand strap not shown.
Scan Button
Volume Button
Camera Lens
and Flash
Laser Safety
Label Location
SIM Card Door
MicroSD Card Door
I/O Connector
Audio Jack Pin
(model dependent)
USB, Type C
(model dependent)
BLE port In
(model dependet)
BLE Speaker Out
(model dependent)

4
Battery Latch (Models
CT40-L0N-xxxxxAx,
CT40-xxx-xxxxxBx,
CT40-xxx-xxxxxHx,
CT40P-L0N-xxxxxAx,
CT40P-xxx-xxxxxBx,
CT40P-xxx-xxxxxHx)
Battery
(Refer to page 7)
Battery Latch (Model
CT40-xxx-xxxxx0x)

5
Install a microSD Card (Optional)
Note: Format the microSD card before initial use.
Note: Always power off the computer before attempting to install or
remove a card.
3
4
1
5
2

6
Install a microSIM Card
Note: Phone feature is only available on CT40-L1N/CT40P-L1N
models. On all models, the SIM slot supports use of a UICC card for
NFC Secure Element NFC link encryption.
Note: Always power off the computer before attempting to install or
remove a card.
3
4
1
5
2

7
About the Battery
The mobile computer ships with a Li-ion battery manufactured
for Honeywell International Inc.
Model Configuration Battery P/N Power
CT40-xxx-xxxxx0x 318-005-011 3.8 VDC, 15.5 watt-hour
CT40-xxx-xxxxxHx 318-055-017 3.8 VDC, 15.5 watt-hour
CT40-LON-xxxxxAx 318-055-015 3.85 VDC, 15.5 watt-hour
CT40-xxx-xxxxxBx
CT40P-xxx-xxxxxHx TBD 3.85 VDC, 15.5 watt-hour
CT40P-L0N-xxxxxAx 318-055-067 3.85 VDC, 15.5 watt-hour
CT40P-xxx-xxxxxBx
Configuration number (CN) is located on the label in the battery well of
the mobile computer.
We recommend use of Honeywell Li-ion battery
packs. Use of any non-Honeywell battery may result
in damage not covered by the warranty.
Nous recommandons l’utilisation de batteries Li-ion
de la marque Honeywell. L’utilisation d’une batterie
d’un autre fabricant est susceptible de provoquer des
dommages non couverts par la garantie.
Ensure all components are dry prior to placing the
battery in the computer. Mating wet components
may cause damage not covered by the warranty.
Assurez-vous que tous les composants sont secs avant
d’insérer la batterie dans l’ordinateur. L’insertion de
composants humides risque de provoquer des
dommages non couverts par la garantie.

8
Install Battery (Model CT40-xxx-xxxxx0x)
3
4
5
1
2

9
Install Battery (Models CT40-LON-xxxxxAx,
CT40-xxx-xxxxxBx, CT40-xxx-xxxxxHx,
CT40P-L0N-xxxxxAx, CT40P-xxx-xxxxxBx,
CT40P-xxx-xxxxxHx)
1
2

10
Install the Hand Strap
3 4
1 2

11
Charge the Mobile Computer
The mobile computer ships with a partially charged battery.
Charge the battery with a CT40 series charging device for a
minimum of 4 hours. Using the computer while charging the
battery increases the time required to reach a full charge.
CT40 series mobile computers are designed for use with the
following CT40 charging accessories: HomeBase, Ethernet
HomeBase, ChargeBase, NetBase, Quad Battery Charger,
Vehicle Power Adapter, Vehicle Dock, and USB Adapter.
We recommend the use of Honeywell accessories and
power adapters. Use of any non-Honeywell
accessories or power adapters may cause damage not
covered by the warranty.
Nous recommandons d’utiliser des accessoires et des
adaptateurs secteur de marque Honeywell.
L’utilisation de tout accessoire ou adaptateur secteur
d’une autre marque est susceptible de provoquer des
dommages non couverts par la garantie.
Ensure all components are dry prior to mating the
computers and batteries with peripheral devices.
Mating wet components may cause damage not
covered by the warranty.
Assurez-vous que tous les composants sont secs
avant de raccorder les ordinateurs et les batteries à
des périphériques. L’insertion de composants
humides risque de provoquer des dommages non
couverts par la garantie.

12
Turn Power On/Off
The first time you power on the computer, a Welcome screen
appears. You can either scan a configuration barcode or use the
Wizard to manually set up the computer. Once setup is
complete, the Welcome screen no longer appears on startup
and Provisioning mode is automatically turned off (disabled).
To turn the computer on:
• Press and hold the Power button for approximately 3 seconds,
and then release.
To turn the computer off:
1. Press and hold the Power button until the options menu
appears.
2. Touch Power Off.
Battery Replacement
Before removing the battery, always do one of the following:
• Power off the computer.
• Place the unit in Swap Battery mode (feature availability is
model dependent).
Swap Battery Mode
Swap Battery mode places the computer in a low power state so
that the battery can be removed for a short time. This feature is
not available on all models.
To activate Swap Battery mode:

13
1. Press and hold the Power button until the options menu
appears.
2. Touch Swap Battery and follow the on-screen instructions.
3. Once you replace the battery, press the Power button.
Sleep Mode
Sleep mode automatically turns the touch panel display off and
locks the computer to save battery power when the computer is
inactive for a programmed period of time.
1. Press and release the Power button to wake the computer.
2. Drag the toward the top of the display to unlock the
computer.
Adjust the Display Sleep Time
To adjust the amount of time before the display sleeps after
inactivity:
1. Swipe up on the touch screen.
2. Select Settings > Display > Advanced > Sleep.
3. Select the amount of time before the display goes to sleep.
4. Touch to return to the Home screen.

14
About the Home Screen
To learn how to customize the Home screen, see the user guide.
Notification /
Status Bar
Search Bar
Home Screen Panel
Favorites Tray
Navigation Buttons

15
Navigation and Function Buttons
For button locations, see Mobile Computer Features on page 2.
To learn more about how to re-map a button, see the user guide.
Button Description
Back Return to the previous screen.
Home Return to the Home screen.
Recent Apps View and switch between recently
used apps.
Scan Touch the front (on-screen) Scan
button to trigger the scanner.
Volume Press the top of the button to raise
the speaker volume.
Press the bottom of button to
lower the speaker volume.
Scan Press left or right Scan button to
trigger the scanner.
Power See page 13.
Push-to-Talk Push-to-Talk button is model
dependent.

16
About Provisioning Mode
After completing the out-of-box set up process, Provisioning
mode is automatically turned off. Scanning a barcode to install
applications, certificates, configuration files, and licenses on
the computer is restricted unless you enable Provisioning mode
in the Settings app. To learn more, see the user guide.
Scan a Barcode with the Scan Demo
For optimum performance, avoid reflections by scanning the
barcode at a slight angle.
1. Swipe up on the screen.
2. Select Demos > Scan
Demo.
3. Point the computer at
the barcode.
4. Touch Scan on the
screen or press and
hold any Scan button.
Center the aiming beam
over the barcode.
The decode results appear on the screen.
Note: In the Scan Demo app, not all barcode symbologies are enabled by
default. If a barcode does not scan, the correct symbology may not
be enabled. To learn how to modify the default app settings, see
the user guide.

17
Sync Data
To move files between your CT40 and a computer:
1. Connect the CT40 to your computer using a USB charge/
communication accessory.
2. On the CT40, swipe down from the top of the screen to see
the notifications panel.
3. Touch the Android System notification twice, to open the
options menu.
4. Select either File Transfer or PTP.
5. Open the file browser on your computer.
6. Browse to the CT40. You can now copy, delete, and move
files or folders between your computer and CT40 as you
would with any other storage drive (e.g., cut and paste or
drag and drop).
Note: When Provisioning mode is turned off, some folders are hidden
from view in the file browser.

18
Restart the Mobile Computer
You may need to restart the mobile computer to correct
conditions where an application stops responding to the system
or the computer seems to be locked up.
1. Press and hold the Power button until the options menu
appears.
2. Select Restart.
To restart the computer if the touch panel display is
unresponsive:
• Press and hold the Power button for approximately 8 seconds
until the computer restarts.
Note: To learn about advanced reset options, see the user guide.
Support
To search our knowledge base for a solution or log into the
Technical Support Portal and report a problem, go to
www.hsmcontactsupport.com.
Documentation
Product documentation is available at www.honeywellaidc.com.

19
Limited Warranty
For warranty information, go to www.honeywellaidc.com and
click Resources > Product Warranty.
Patents
For patent information, see www.hsmpats.com.
Trademarks
Android is a trademark of Google LLC.
Disclaimer
Honeywell International Inc. (“HII”) reserves the right to make
changes in specifications and other information contained in
this document without prior notice, and the reader should in all
cases consult HII to determine whether any such changes have
been made. The information in this publication does not
represent a commitment on the part of HII.
HII shall not be liable for technical or editorial errors or
omissions contained herein; nor for incidental or consequential
damages resulting from the furnishing, performance, or use of
this material. HII disclaims all responsibility for the selection
and use of software and/or hardware to achieve intended
results.
This document contains proprietary information that is
protected by copyright. All rights are reserved. No part of this
document may be photocopied, reproduced, or translated into
another language without the prior written consent of HII.
Copyright © 2018-2020 Honeywell International Inc. All rights
reserved.
